A GRAPH-BASED TOOL FOR THE TRANSLATION OF XML
DATA TO OWL-DL ONTOLOGIES
Christophe Cruz and Christophe Nicolle
Laboratory Le2i, UMR-5158 CNRS, Université de Bourgogne, B.P. 47870, 21078, Dijon Cedex, France
Keywords: Ontology population, Ontology enrichment, OWL ontology, XML data, RDF, Semantic annotation.
Abstract: Today most of the data exchanged between information systems is done with the help of the XML syntax.
Unfortunately when these data have to be integrated, the integration becomes difficult because of the
semantics’ heterogeneity. Consequently, leading researches in the domain of database systems are moving
to semantic model in order to store data and its semantics definition. To benefit from these new systems and
technologies, and to integrate different data sources, a flexible method consists in populating an existing
OWL ontology from XML data. In paper we present such a method based on the definition of a graph which
represents rules that drive the populating process. The graph of rules facilitates the mapping definition that
consists in mapping elements from an XSD schema to the elements of the OWL schema.
1 INTRODUCTION
Ontologies are widely used to capture and organize
knowledge about a particular domain. In addition,
the definition of ontolgies is used as an index to
retrieve specific data (Garcìa, 2005), to infer new
knowledge (SWRL, 2004), to semantically annotate
multimedia data (Castano, 2007), to find out Web
Services automatically (Martin, 2007), or to match
knowledge with other knowledge for a more general
purpose.
Ontologies are aimed at representing knowledge
about a specific domain that are understandable by
both developers and computers. For this, ontologies
enumerate concepts and relations between concepts
(Guarino, 1998) and define properties, functions,
constraints and axioms (Studer, 1998). The major
issues in ontology development include ontology
representation, ontology acquisition, evaluation and
ontology maintenance (Zhou, 2007). Ontology
representation is the main issue in ontology
development because its representation has to be
understandable by computers and humans.
Consequently, an ontology representation language
should provide representation adequacy for humans
and inference efficiency for computers. Ontology
dialects based on description logic (DL) provide a
frame-based knowledge representation and profit
from the expressiveness of DL reasoning systems.
Ontology acquisition refers to the process of the
ontology creation such as concepts, relations,
individuals and axioms. From an empirical point of
view, there are two kinds of ontology modeling
processes. The first one is the ontology modeling,
which is traditionally carried out by knowledge
engineers or domain experts. Actually, these
ontologies are built by humans for humans. The
second one is in fact the point of view of the
semantic Web according to which ontologies are
built automatically by computers for computers
within sources such as dictionaries, Web documents
and database schemas. It has to be noticed that the
resulting ontologies are still understandable by
humans. As a result, ontology acquisition can benefit
significantly from ontology learning (Ding, 2002).
Ontology evaluation aims at enhancing the quality of
ontologies in order to improve the interoperability
among systems and to increase the adoption of
ontologies. Ontologies can be evaluated in different
ways (Staab, 2004) using measures such as
completeness, consistency and correctness (Gomez-
Perez, 1995). Ontology maintenance concerns the
organization, the search and the update process on
existing ontologies. The constant evolution of the
environment of ontologies makes it very important
for ontologies to be evaluated and maintained (Sure,
2002) in order to keep up with the change.
This article presents an automatic population
process from XML data to OWL ontologies, a
361
Cruz C. and Nicolle C..
A GRAPH-BASED TOOL FOR THE TRANSLATION OF XML DATA TO OWL-DL ONTOLOGIES.
DOI: 10.5220/0003629603610364
In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2011), pages 361-364
ISBN: 978-989-8425-80-5
Copyright
c
2011 SCITEPRESS (Science and Technology Publications, Lda.)
Table 1: Synthesis of related projects.
Paper XSLT
Automatic XSD
mapping
Automatic XML
instances
Multiple XSD
integration
OWL-DL
Mapping in
RDF
XSD2OWL and
XML2RDF
Ferdinand & al. no yes yes no yes no yes
García & al. no yes yes no no no yes
Bohring & al. yes yes yes no yes no no
Rodrigues & al. yes no yes yes yes no no
Aninic & al no no no no yes yes no
Kim & al. yes no no no yes no yes
Bedini & al no yes no no yes no no
Cruz & Nicolle no no yes yes yes yes no
process which is based on a manual mapping
between the XML schema elements and the OWL
schema elements. If the OWL schema does not
contain the required elements then the ontology has
to be enriched by the system manager. The ontology
enrichment is the activity of extending an ontology
by adding new elements (e.g. concepts, relations,
properties, axioms) (Castano, 2007). Our enrichment
process consists in annotating knowledge which is
contained in XML schemas in order to define the
ontology schema (Faatz, 2004). Some automatic
processes from ontology learning can be used but
this point is beyond the scope of this paper. The
ontology population is the activity of adding new
instances or individuals to an ontology (Castano,
2007).
2 BACKGROUND
In order to populate an ontology, it is first necessary
to define which elements in an XML document will
be processed. In addition, it is also necessary to
identify the nature of the XML element in order to
generate the individuals of the corresponding
ontology. The first step consists in defining mapping
rules which define the mapping of an XML element
to an OWL element. If the required OWL elements
do not exist in the ontology then the ontology has to
be enriched accordingly. Once the mapping rules
have been defined, the second step consists in
populating (automatically) the ontology by using
XML documents validated by the XML schema.
We extend the solution described in (Rodrigues,
2006) by mapping several XML schemas in an
existing OWL ontology (Cruz, 2008), which consists
in defining mapping rules between each XML
schema to a common existing OWL ontology. In
addition, we allow users to define partial mapping of
XML schemas in order to enrich and populate a
relevant OWL-DL ontology for a specific data
management process. Furthermore, we define the
transformation rules in RDF that allow a more
flexible and a more fine-grained rule definition in
order to allow a partial reuse of annotated XML
schemas and data type conversions. Our method
allows also the definition of advanced rules of
transformation in RDF that can be reused for other
mappings. The most important point is that rules are
represented by a graphical graph which is managed
directly by the user. This graph-based rules method
facilitates the definition of rules and the
corresponding results. Some work has been done
specifically on the translation of XML schemas into
OWL ontology (Garcìa, 2005), (Do, 2007),
(Ferdinand, 2004), (Bohring, 2005), (Rodrigues,
2006), (Anicic, 2007), (Kim, 2007), (Bedini, 2008),
(e.g. table 1)
Table 1. summarize all properties of studied
projects . “XSLT” means that the method uses an
XSL style sheet such as XML data for the
conversion process. “Automatic XSD mapping”
means that the user cannot intervene in the mapping
process between XML schema elements and the
OWL ontology. “Automatic XML instances” means
that if instances are generated by the studied method
then the process is automatic. “Multiple XSD
integration” means that the project allows users to
integrate several XML schemas to an OWL
ontology. “OWL-DL” means that the generated
ontology is a description logic ontology which
allows inference and consistency checking.
“Mapping in RDF” means that the method uses RDF
to specify the mapping between schemas. The last
column implies that if the value is “yes” then XML
schemas are mapped to an OWL ontology and the
instances of the XML schemas are translated in an
RDF document. It means that instances are not OWL
instances. The last row of the table presents the
properties of our method. Our method does not use
XSLT because the process is too complex to be used
with an XSLT processor (e.g. regex). The mapping
is done manually but the population of the ontology
is automatic. We also allow the user to integrate
KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development
362
Figure 1: Snapshot of the GXSD2OWL plug-in.
several XML schemas into an existing OWL-DL
ontology. In addition, in order to specify the
mapping between schemas and the ontology, we use
the RDF language in order to permit an advanced
management of mapping rules. Finally, the instances
of the ontology are obviously defined in the model
of the ontology schema.
3 THE GXSD2OWL TOOL
The principle of our solution consists in annotating
and linking the semantic level (OWL schema) and
the schematic level (XML schema). The graphical
interface used to realize this is incorporated in the
tool “protégé” from Stanford as a plug-in (e.g. fig 1)
in order to populate an existing ontology. Once the
graph of mapping rules has been defined, the
population process is automatic. The user has only to
select a list of XML documents which can be
validated by the XSD schema.
The links between XSD annotations are
“subElement” relationships which are added
automatically by the process because these
relationships already exist in the XSD schema. In
addition, links between OWL annotations are also
added automatically because these relationships
already exist in the OWL ontology.
4 CONCLUSIONS
This paper presents a flexible method to enrich and
populate an OWL ontology for the integration of
XML data. Basic mapping rules and advanced
mapping rules are defined by users and can be
reused for other conversions and populations of
ontologies. This conversion is the first part of our
work. The second part consists in improving the
process and in making some suggestions in order to
facilitate the mapping to the user.
ACKNOWLEDGEMENTS
Authors would like to thank Yoan Chabot, for its
contribution.
A GRAPH-BASED TOOL FOR THE TRANSLATION OF XML DATA TO OWL-DL ONTOLOGIES
363
REFERENCES
Anicic, N., Ivezic, N. and Marjanovic, Z.: Mapping XML
Schema to OWL, Enterprise Interoperability, Springer
London (2007)
Aumueller, D., Do, H. H., Massmann, S., Rahm, E.:
Schema and ontology matching with COMA++,
SIGMOD Conference (2005)
Bedini, I. Georges Gardarin and Benjamin Nguyen, Janus:
Automatic Ontology Construction Tool, EKAW, 29th
September-3rd October - Acitrezza, Catania, Italy
(2008)
Berstel, J., Boasson, L.: XML Grammars, MFCS 2000:
182-191 (2000)
Bohring, H.; Auer, S.: Mapping XML to OWL
Ontologies. Leipziger Informatik-Tage (LIT 2005),
Sep. 21-23, 2005, Lecture Notes in Informatics (2005)
Bowers S., Delcambre L.: Representing and Transforming
Model-Based Information, In Proceedings of the
Workshop on Semantic Web at ECDL-00, Lisbon,
Portugal (2000)
Castano, S., Espinosa, S., Ferrara, A., Karkaletsis, V.,
Kaya, A., Melzer, S., Moller, R., Montanelli S.,
Petasis, G.: Ontology Dynamics with Multimedia
Information: The BOEMIE Evolution Methodology.
In Proc. of International Workshop on Ontology
Dynamics (IWOD) ESWC 2007 Workshop - 7 June -
Innsbruck, Austria (2007)
Cruz, C., Nicolle, C.: Ontology Enrichment and Automatic
Population From XML Data, 4th International VLDB
Workshop on Ontology-based Techniques for
DataBases in Information Systems and Knowledge
Systems, ODBIS 2008, Auckland, New Zealand,
August 23, 2008, Co-located VLDB, 17-20 (2008)
Ding, Y.: Ontology research and development part1 – A
review of ontology generation, Journal of Information
Science, 28, 123–136 (2002)
Do, H. H., Rahm, E.: COMA - A System for Flexible
Combination of Schema Matching Approaches, Proc.
28th Intl. Conference on Very Large Databases
(VLDB), Hongkong, Aug (2002)
Faatz, A., and Steinmetz, R.,: Precision and recall for
ontology enrichment. In Proc. of ECAI-2004
Workshop on Ontology Learning and Population,
Valencia, Spain, Aug. (2004)
Ferdinand M., Zirpins, C.and Trastour, D., Lifting XML
Schema to OWL, in: Koch, Nora and Fraternali, Piero
and Wirsing, Martin (Hrsg.): Web Engineering - 4th
International Conference, ICWE 2004, Munich,
Germany, July 26-30, 2004, Proceedings, Springer
Heidelberg, pp. 354-358 (2004)
García, R., Celma, O.: Semantic Integration and Retrieval
of Multimedia Metadata, Proceedings of 4rd
International Semantic Web Conference, Galway,
Ireland (2005)
Gomez-Perez, A.: Some ideas and examples to evaluate
ontologies, presented at Artificial Intelligence for
Applications (1995)
Gruber, T.: Ontology, Encyclopedia of Database Systems,
Ling Liu and M. Tamer Özsu (Eds.), Springer-Verlag
(2008)
Guarino, N.: Formal ontology, conceptual analysis and
knowledge representation, International Journal of
Human-Computer Studies 43, 625–640 (1995)
Huynh Quyet Thang, Vo Sy Nam, XML Schema
Automatic Matching Solution, International journal
on Information Systems Science and Engineering, vo.l
4, number 1, (2008)
Kim, M., Sengupta, A., Extracting knowledge from XML
document repository: a semantic Web-based approach,
Inf. Technol. and Management 8, no. 3, 205-221
(2007)
Klein, M., 2002: Interpreting XML via an RDF schema. In
ECAI workshop on Semantic Authoring, Annotation &
Knowledge Markup (SAAKM 2002), Lyon, France
(2002)
Lakshmannan, L. V., Sadri, F.: Interoperability on XML
Data, In Proceeding of the 2nd International Semantic
Web Conference (2003).
Martin, D., Paolucci, M., Wagner, M.: Towards Semantic
Annotations of Web Services: OWL-S from the
SAWSDL Perspective, In OWL-S Experiences and
Future Developments Workshop at ESWC 2007, June,
Innsbruck, Austria (2007)
OWL XML schema, http://www.w3.org/2007/OWL/wiki/
OWL_XML_Schema (2007)
Rahm, E. and Bernstein, P.: A survey of approaches to
automatic schema matching. The VLDB Journal 10,
334-350 (2001)
Rodrigues, T., Rosa, P. and Cardoso, J.: Mapping XML to
Exiting OWL ontologies, International Conference
WWW/Internet 2006, (Eds) Isaías, Pedro and Nunes,
Miguel Baptista and Martínez, Inmaculada J., pp.72-
77, ISBN:972-8924-19-4 (2006)
Staab, S., Gomez-Perez, A., Daelemana, W., Reinberger,
M.-L. and Noy, N.F.: Why evaluate ontology
technologies? Because it works!, Intelligent Systems,
IEEE 19, 74–81 (2004)
Studer, R. Benjamins, R. and Fensel, D., Knowledge
engineering: Principles and methods, Data and
Knowledge Engineering 25, 161–197 (1998)
Sure, Y., Staab, S. and Studer, R.: Methodology for
development and employment of ontology based
knowledge management applications, SIGMOD Rec
31, 18–34(2002)
SWRL: A Semantic Web Rule Language Combining
OWL and RuleML, http://www.w3.org/Submission
/SWRL/, (2004)
TriG syntax, This document describes TriG, a syntax for
serializing Named Graphs and RDF Datasets.
http://www4.wiwiss.fu-berlin.de/bizer/TriG/
Zhou, L.: Ontology learning: state of the art and open
issues, Information Technology and Management
archive Volume 8, Issue 3, 241 – 252 (2007)
KEOD 2011 - International Conference on Knowledge Engineering and Ontology Development
364
