ACCURACY OF MP3 SPEECH RECOGNITION UNDER

REAL-WORD CONDITIONS

Experimental Study

Petr Pollak and Martin Behunek

Faculty of Electrical Engineering, Czech Technical University in Prague, Technick´a 2, 166 27 Prague, Czech Republic

Keywords:

Speech recognition, MPEG compression, MP3, Noise robustness, Channel distortion.

Abstract:

This paper presents the study of speech recognition accuracy with respect to different levels of MP3 compres-

sion. Special attention is focused on the processing of speech signals with different quality, i.e. with different

level of background noise and channel distortion. The work was motivated by possible usage of ASR for off-

line automatic transcription of audio recordings collected by standard wide-spread MP3 devices. The realized

experiments have proved that although MP3 format is not optimal for speech compression it does not distort

speech signiﬁcantly especially for high or moderate bit rates and high quality of source data. The accuracy

of connected digits ASR decreased consequently very slowly up to the bit rate 24 kbps. For the best case

of PLP parameterization in close-talk channel just 3% decrease of recognition accuracy was observed while

the size of the compressed ﬁle was approximately 10% of the original size. All results were slightly worse

under presence of additive background noise and channel distortion in a signal but achieved accuracy was also

acceptable in this case especially for PLP features.

1 INTRODUCTION

Automated speech recognition (ASR) represents a

ﬁeld which is more present in everyday human life

in growing number of applications as in voice op-

erated control of consumer devices, automated in-

formation services, or general conversion of uttered

speech into text record. The systems for automatic

transcription of speech to text are currently well de-

veloped for all important world languages. It is possi-

ble to meet today dictation software for standard PC

enabling users to input texts into documents without

using the keyboard, e.g. Dragon dictate, or for mo-

bile devices, e.g. (Nouza et al., 2009). Further, the

transcription of broadcast news is currently a very im-

portant task solved by many research teams (Chen

et al., 2002), (Gauvain et al., 2002). Probably the

most popular is the transcription of news, but there

are also other applications such as automated subti-

tling of TV programmes, e.g. parliament meetings

(Vanˇek and Psutka, 2010) or sportscasts (Psutka et al.,

2003). Special attention is also paid to the transcrip-

tion and indexing of largeaudio archivesenabling bet-

ter search within them in the future (Makhoul et al.,

2000), (Byrne et al., 2004).

When audio records are transcribed on-line, e.g.

the above-mentioned subtitling of TV programmes,

ASR systems work with full quality input signal. On

the other hand, when they work off-line, recordings

can be saved in formats of different quality and typi-

cally, MP3 format (more precisely MPEG Layer III)

represents one of the most frequently used formats for

the saving of sound ﬁles in compressed form (Bou-

vigne, 2007), (Brandenburg and Popp, 2000). It is

well known that this format uses psychoacoustic mod-

els reducing the precision of components less audible

to human hearing so it makes it possible to decrease

the size of the sound ﬁle to 10% while CD quality is

preserved. Although this format has been developed

especially for saving the music, it is standardly used

also in simple dictation devices or mobile phones en-

abling recording and saving audio speech ﬁles. Some

works in MP3 speech data recognition have been al-

ready done. The recognition of spontaneous speech

from large oral history archives published in (Byrne

et al., 2004) used signals saved in MP3 format but

rather high bit-rate (128 kbps) was used in this case.

In (Barras et al., 2001) the study of automatic tran-

scription of compressed broadcast audio with differ-

ent bit-rates was done. The comparison of various

compression schemes was realized in this study, how-

ever, the quality of the signal was rather better.

Pollak P. and Behunek M..

ACCURACY OF MP3 SPEECH RECOGNITION UNDER REAL-WORD CONDITIONS - Experimental Study.

DOI: 10.5220/0003512600050010

In Proceedings of the International Conference on Signal Processing and Multimedia Applications (SIGMAP-2011), pages 5-10

ISBN: 978-989-8425-72-0

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

This paper presents the results of an experimental

study analyzing ASR accuracy working with respect

to differentquality of compressed data as current ASR

systems need to work accurately under real condi-

tions and often under presence of additive background

noise or channel distortion. It depends mainly on the

quality and the position of the microphone used. The

task of solving robust recognition with low error rate

of possibly distorted speech from real environment is

thus also a blossoming research ﬁeld. Standard fea-

tures used most commonly in ASR systems have typ-

ically modiﬁed versions increasing their robustness in

real environment (Fousek and Poll´ak, 2003), (Boˇril

et al., 2006), (Rajnoha and Poll´ak, 2011) but these

methods are designed usually for uncompressed data.

That is the main reason why our study focuses mainly

on the analysis of the information lost in compressed

speech signals when varying levels of additive noise

and channel distortion appear in speech signal. The

results of this study are supposed to be helpful for

further application of automated speech recognition

from MP3 speech ﬁles.

2 MP3 SPEECH RECOGNITION

We use rather small vocabulary ASR for the pur-

pose of this study. Of course, such small vocabulary

system is much simpler than complex large vocabu-

lary continuous speech recognition (LVCSR) system

which is supposed to be used in a target application.

On the other hand, we want to analyze mainly the

sensitivity of ASR system to loss of information af-

ter MP3 compression without a dependency on fur-

ther blocks such as complex statistic language model

in LVCSR system and it is the main reason for the

choice of digit recognizer in experiments of this study.

2.1 Speech Compression Scheme

MP3 compression was developed for the compression

of music audio ﬁles (Brandenburg and Popp, 2000),

(Bouvigne, 2007) and it is known that this compres-

sion gives slightly worse results for speech signal.

The masking and attenuation of some frequency com-

ponents can yield to a suppression of a phone at the

beginning or at the end of the word, sometimes inter-

word pause shortening can appear. Less naturalness

of decoded utterance is then the main effect of this

fact and consequently, the accuracy of speech recog-

nition can decrease too. Algorithms, which have been

designed and optimized for speech signal, are repre-

sented mainly by G.729 (ITU-T, 2007), AMR (ETSI,

2007), or Speex (Valin, 2007). These encoders are

based typically on CELP algorithm, but they are used

rather in telecommunications and they do not appear

so frequently in standard audio devices.

Consequently, although speech signals can be

compressed in a better way, our attention was paid just

to MP3 compression in this study because the long-

term goal of our work was mainly in off-line mode

of ASR operation on compressed speech data from

wide-spread audio consumer devices. The study was

realized with signals from the database SPEECON

recorded in real environment with full-precision PCM

coding. The MP3 compression was then simulated by

publicly available software LAME (Cheng and et. al.,

2008) which made it possible to simulate also differ-

ent levels of MP3 compression bit-rate.

2.2 Small Vocabulary ASR Setup

Current ASR systems are usually based on Hidden

Markov Models (HMM). HMM based recognizer

consists typically of 3 principal function modules:

feature extraction (parameterization), acoustic mod-

elling, and decoding. Generally known principles of

HMM based recognizer are not explain in this paper,

as they are known or can be found in many sources,

e.g. in (Huang et al., 2001), (Young and et al., 2009),

and others. Only a brief description of our ASR setup

(see block scheme in Fig 1), which is relevant for the

next parts of this paper, is presented.

Concerning the parameterization module, two sets

of features are most standardly used in ASR systems:

mel-frequency cepstral coefﬁcients (MFCC) and per-

ceptually based linear predictive cepstral coefﬁcients

(PLP). All our experiments were carried out just with

these two feature sets. Both of them use their own

non-linear ﬁlter-bank which in both cases models the

perceptual properties of human auditory system, for

more detail see (Huang et al., 2001), (Young and

et al., 2009), (Psutka et al., 2001), or (Hermansky,

1990). Exactly 12 cepstral coefﬁcients plus loga-

rithm of frame energy commonly with the 1st and 2nd

derivatives formed feature vector in our experiments.

MP3 compression was involved within our system as

optional preprocessing module before standard fea-

ture extraction, see Fig 1.

Acoustic modelling was based on monophone

HMM models, i.e. phones modelled without any con-

text to neighbouring phones. Finally, HMM models

of 44 Czech monophones with 3 emitting states were

used as standard subword acoustic element modelling

in ASR. As used phone models were context indepen-

dent, their higher variability was modelled by 32 mix-

tures of Gaussian emitting function of HMM models

and 3 streams were also used for modelling of static,

SIGMAP 2011 - International Conference on Signal Processing and Multimedia Applications

SPEECON

database

extraction

Feature

MP3

modeling

Acoustic

Decoding

text

Recognized

grammar

HMM

models

Word

Welch

Baum

acoustic signal

Speech recognition

utterance

transcription

training

HMM

extraction

Feature

MP3

conversion

analysis

ACC

Figure 1: Block scheme of experimental setup.

dynamic and acceleration features respectively.

Connected digit ASR was used within this study

so that it was possible to use simple grammar in the

phase of decoding. On the other hand, though just ba-

sic digits from 0 to 9 can appear in the utterance, the

number of digits in the utterance can vary and they

can be pronounced with or without pauses and with

possible repetitions. Finally, it means that our digit

recognizer should be sufﬁciently general for our ex-

periments and we can assume that it simulates well

operating mode of target practical application.

2.3 Training of Speech Recognizer

Training of HMM models, which are composed of

Gaussian emitting functions representing probability

distribution of a feature in given state and from proba-

bilities of transitions between particular states, is per-

formed on the basis of iterative embedded training

procedure from large training data (Baum-Welch al-

gorithm). The size of the training database containing

speech signals with precisely annotated content must

guarantee sufﬁcient appearance of each acoustic ele-

ment. The training procedure, which has been based

on Czech SPEECON data in our case, is illustratively

represented by blue part of block scheme in Fig. 1,

more details can be found in (Young and et al., 2009)

or (Huang et al., 2001).

Our acoustic models with 32 Gaussian mixtures

were trained iteratively in 23 steps with ﬂat start for

each parameterization and also for many operating

conditions. As training data had to match these con-

ditions, we have ﬁnally obtained comprehensive set

of HMM models for particular channels, for different

bit-rates in MP3 encoding, and for feature set used.

2.4 Implementation of ASR

Both small vocabulary ASR and the training of acous-

tic HMM models were realized by tools from publicly

available HTK Toolkit (Young and et al., 2009) which

is often used world-wide for the realization of HMM

based recognition. For readers without detail knowl-

edge of HTK Toolkit, typical and core tools of HTK

Toolkit are HCopy as parameterization tool, HERest

as the tool for the training by Baum-Welch algorithm,

or HVite as Viterbi based word recognizer.

The computation of PLP cepstral coefﬁcients was

performed by CtuCopy tool (Fousek and Poll´ak,

2003) and (Fousek, 2006), providing some extensions

of HCopy from the standard set of HTK Toolkit.

3 EXPERIMENTS AND RESULTS

Experiments described in this part comprise the core

contribution of this study, which is mainly in the anal-

ysis of ASR performance for MP3 compressed speech

data under different real-word conditions.

3.1 Speech Data Description

All experiments were carried out with speech sig-

nals from Adult Czech SPEECON database (ELRA,

2009). It is the database (DB) of sentences, digits,

command, names, etc. recorded by 550 speakers un-

der different conditions, i.e. in ofﬁces or home envi-

ronment, at public places, or in the car. For this study,

only well-balanced subset of adult speaker data from

ofﬁce environment were used, i.e. 90% of data for

training and 10% for testing. It contains signals with

similar and not so strong background noise.

ACCURACY OF MP3 SPEECH RECOGNITION UNDER REAL-WORD CONDITIONS - Experimental Study

Table 1: Description of channels recorded in SPEECON database.

Channel ID Microphone type Distance Additive noise Channel distortion

CS0 head-set 2 cm - -

CS1 hands-free 10 cm + -

CS2 middle-talk 0.5-1 m ++ +

CS3 far-talk 3 m +++ ++

Speech data in SPEECON DB are raw 16 bit lin-

ear PCM sound ﬁles sampled by 16 kHz sampling fre-

quency. These signals were then encoded into MP3

sound ﬁles with different bit-rates. The MP3 com-

pression was simulated by successive encoding and

decoding by the above-mentioned lame software en-

coder/decoder (Cheng and et. al., 2008).

Although only data from one environment were

used in our experiments, the inﬂuence of additive

noise and channel distortion could be analyzed, be-

cause signals in SPEECON DB were recorded in 4

channels which differed in microphone type and its

position, see (Poll´ak and

Cernock´y, 2004). Follow-

ing Tab. 1 describes the properties of particular chan-

nels. Although different types and quality of micro-

phones were used, it was mainly the distance from the

speaker’s mouth that played the key role in the quality

of recorded speech signal. Finally, signals from close

talk head-set channel CS0 are then almost without ad-

ditive noise and reasonable channel distortion appears

only in signals from channels CS2 and CS3. These

data can simulate well real MP3 recordings made by

standard devices in various environments.

3.2 Results of Experiments

The accuracy (ACC) of the digit recognizer was mea-

sured standardly on the basis of errors on word level

(Young and et al., 2009) and the following sections

describe obtained results.

3.2.1 Analysis of Optimum Segmentation for

MP3 Speech Data

Within the ﬁrst experiment, the inﬂuence of short-

time analysis setup on target accuracy of MP3 recog-

nition was analyzed. In accordance with phonetically

based assumptions as well as default settings used

in (Young and et al., 2009), the optimum length of

the frame for short-time acoustic analysis is 25 ms

with the period of 10 ms for uncompressed speech

data, while for MP3 compressed data the segmenta-

tion with frame length 32 ms and frame period 16 ms

gives the best results for both studied feature sets.

The reasons for this effect lie in the ﬁrst modules

of both feature extraction algorithms which realize

short-time Fourier analysis followed by non-linear ﬁl-

Table 2: ASR accuracy (ACC) dependence on varying seg-

mentation for MFCC features and WAV or MP3 signals.

Features WAV MP3

MFCC 1608 hmm23 95.55 54.39

MFCC 2510 hmm23 96.89 76.31

MFCC 3216 hmm23 95.22 93.21

Table 3: ASR accuracy (ACC) dependence on varying seg-

mentation for PLP features and WAV or MP3 signals.

Features WAV MP3

PLP 1608 hmm23 95.11 72.64

PLP 2510 hmm23 96.33 81.76

PLP 3216 hmm23 95.11 93.10

ter banks computing perceptually based power spec-

tra. Due to the decrease of short-time frame length,

frequency resolution of Discrete Fourier Transform

decreases too and consequently the masking and dele-

tions of some frequency components within the MP3

compression scheme increase the estimation error of

power spectrum at the output of the ﬁlter bank.

The results of this experiment for both MFCC and

PLP features are in Tab 2 and 3. MP3 compression

was realized with bit-rate 160 kbps and results are

presented for the CS0 channel. It can be supposed

that this error at the output of ﬁlter bank increases for

shorter frame length also when uncompressed speech

signal is more corrupted by additive noise, which is

the case of channels CS1, CS2, and CS3.

Abbreviations used in the following ta-

bles describe the feature extraction used, e.g.

MFCC 3216 hmm23 means MFCC features com-

puted from 32 ms long frame with the period of

16 ms. The ﬂag “hmm23” speciﬁes HMM models

obtained after 23rd training step.

3.2.2 Inﬂuence of MP3 Compression for

Particular Channels

Within the second experiment, the inﬂuence of recog-

nition accuracy in particular channels on different

MP3 bit-rates was analyzed. All these experiments

were realized with optimum segmentation parame-

ters, i.e. 32 ms frame length and 16 ms frame period.

Achieved results are presented numerically in the fol-

lowing tables and for quick illustrative overview also

in ﬁgures showing the same data in graphical form.

Tab. 4 and Fig. 2 present results obtained with

SIGMAP 2011 - International Conference on Signal Processing and Multimedia Applications

Table 4: ASR accuracy (ACC) dependence on varying MP3

bit-rate for MFCC features computed for all channels.

MP3 bit-rate CS0 CS1 CS2 CS3

WAV 95.22 92.44 89.54 61.18

160 kbps 93.21 83.31 42.83 30.03

64 kbps 93.21 84.43 43.60 31.59

48 kbps 93.33 85.54 43.83 32.26

40 kbps 93.33 86.43 43.94 31.59

32 kbps 89.77 88.54 44.75 33.48

24 kbps 89.32 37.71 38.71 27.92

8 kbps 21.02 16.35 12.57 6.90

Table 5: ASR accuracy (ACC) dependence on varying MP3

bit-rate for PLP features computed for all channels.

MP3 bit-rate CS0 CS1 CS2 CS3

WAV 95.11 89.43 88.88 64.63

160 kbps 93.10 82.09 78.75 27.36

40 kbps 92.66 87.32 83.09 28.48

24 kbps 92.32 88.21 80.09 28.70

8 kbps 62.40 36.15 24.25 11.01

mel-frequency cepstral coefﬁcients. Looking at the

results achieved for CS0 channel we can see that for

rather high quality signal the MP3 compression has

just minimum effect up to bit-rate 24 kbps. For other

channels the trend is always similar but the absolute

values of the achieved ACC are lower according to

our assumptions. We can also see that for channels

CS2 and CS3 containing higher level of background

noise and stronger channel distortion, the ACC falls

rapidly already for rather high bit-rates of MP3 com-

pression. Such results disable in principle the recog-

nition of MP3 data collected under similar conditions.

On the other hand it must be mentioned that all experi-

ments in this study were carried out with basic feature

setup, i.e. no algorithm for additive noise suppression

or channel normalization was used.

Tab. 5 and Fig. 3 show similar results for the

recognition with perceptually based linear predictive

cepstral coefﬁcients. The same trends have been ob-

served again, so in the end the experiments were re-

alized just with 4 different bit-rates. In comparison

with MFCC, better performance can be observed for

PLP for channels CS1 and CS2. Especially the results

for channel CS2 represent acceptable values of ACC

for MP3 compressed data up to the bit-rate of 24 kbps

(80.09% as for MFCC it was 38.71%) which is similar

as for high quality CS0 channel. In principle it allows

the practical usage of ASR of MP3 compressed data

collected by middle-distance microphone, e.g. it can

be the case of MP3 recorder placed on the table.

Finally, we computed sizes of compressed data so

we could compare the level of compression (in per-

cent) with the achieved accuracy of speech recogni-

Figure 2: ASR accuracy (ACC) dependence on varying

MP3 bit-rate for MFCC features computed for all channels.

Figure 3: ASR accuracy (ACC) dependence on varying

MP3 bit-rate for PLP features computed for all channels.

Figure 4: Dependence of ASR accuracy (ACC) on ﬁle size

reduction (MFCC features and channel CS0).

tion. These results are shown in Fig. 4 where we

can observe minimum decrease of ASR accuracy up

to 20% compression of sound ﬁle. Strong downfall

appears as far as beyond 10% compression. These re-

sults were obtained for MFCC features and the high

quality CS0 channel.

4 CONCLUSIONS

The analysis of speech recognition using MP3 com-

pressed audio data was done. The achieved results

proved acceptable accuracy of speech recognition of

MP3 compressed speech data. The most important

contributions are summarized in the following points.

• ACC decreases rapidly for shorter frame length

of short-time features when MP3 speech is rec-

ACCURACY OF MP3 SPEECH RECOGNITION UNDER REAL-WORD CONDITIONS - Experimental Study

ognized. It is affected by perceptual masking

in MP3 compression scheme and decreasing of

short-time Fourier analysis frequency resolution

used in computation of MFCC and PLP features.

• Generally, the loss of accuracy is very small up

to bit-rate 24 kbps. In this case the size of com-

pressed data is just 10% of full precision linear

PCM and ACC decreased by 6% for MFCC and

only by 3% for PLP features.

• The results are worse for noisy channels where

50% decrease of ACC can be observed for MFCC

features, comparing standard PCM and 24 kbps

MP3 speech signal from desktop microphone.

This decrease is just about 8% for PLP features.

• Realized experiments proved that MP3 com-

pressed speech ﬁles used in standardly available

consumer devices such as MP3 players, recorders,

or mobile phones, can be used for off-line auto-

matic conversion of speech into text without crit-

ical loss of an accuracy. PLP features seem to be

preferable for speech recognition in this case.

ACKNOWLEDGEMENTS

This research was supported by grants GA

102/08/0707 “Speech Recognition under Real-

World Conditions” and by research activity MSM

6840770014 “Perspective Informative and Commu-

nications Technicalities Research”.

REFERENCES

Barras, C., Lamel, L., and Gauvain, J.-L. (2001). Automatic

transcription of compressed broadcast audio. In Proc.

of the IEEE International Conference on Acoustics,

Speech, and Signal Processing, pages 265–268, Salt

Lake City, USA.

Bouvigne, G. (2007). MP3 standard. Homepage.

http://www.mp3-tech.org.

Boˇril, H., Fousek, P., and Poll´ak, P. (2006). Data-driven

design of front-end ﬁlter bank for Lombard speech

recognition. In Proc. of ICSLP 2006, Pittsburgh, USA.

Brandenburg, K. and Popp, H. (2000). An introduction to

MPEG layer 3. EBU Technical Review.

Byrne, W., Doermann, D., Franz, M., Gustman, S., Hajiˇc,

J., Oard, D., Pichney, M., Psutka, J., Ramabhadran,

B., Soergel, D., Ward, T., and Zhu, W.-J. (2004). Au-

tomatic recognition of spontaneous speech for access

to multilingual oral history archives. IEEE Trans. on

Speech and Audio Processing, Vol.12(No.4):420–435.

Chen, S. S., Eide, E., Gales, M. J. F., Gopinath, R. A.,

Kanvesky, D., and Olsen, P. (2002). Automatic tran-

scription of broadcast news. Speech Communication,

Vol.37(No.1-2):69–87.

Cheng, M. and et. al. (2008). LAME MP3 encoder 3.99

alpha 10. http://www.free-codecs.com.

ELRA (2009). Czech SPEECON database. Catalog No.

S0298. http://www.elra.info.

ETSI (2007). Digital cellular telecommunications system

(Phase 2+) (GSM). Test sequences for the Adaptive

Multi-Rate (AMR) speech codec. http://www.etsi.org.

Fousek, P. (2006). CtuCopy-Universal feature extractor and

speech enhancer. http://noel.feld.cvut.cz/speechlab.

Fousek, P. and Poll´ak, P. (2003). Additive noise and channel

distortion-robust parameterization tool. performance

evaluation on Aurora 2 & 3. In Proc. of Eurospeech

2003, Geneve, Switzerland.

Gauvain, J.-L., Lamel, L., and Adda, G. (2002). The LIMSI

broadcast news transcription system. Speech Commu-

nication, Vol.37(No.1-2):89–108.

Hermansky, H. (1990). Perceptual linear predictive (PLP)

analysis of speech. Journal of the Acoustical Society

of America, Vol.87(No.4):1738–1752.

Huang, X., Acero, A., and Hon, H.-W. (2001). Spoken Lan-

guage Processing. Prentice Hall.

ITU-T (2007). International Telecommunication Union

Recommendation G.729, coding of speech at 8 kbit/s

using conjugate-structure algebraic-code-excited lin-

ear prediction(CS-ACELP). http://www.itu.int/ITU-T.

Makhoul, J., Kubala, F., Leek, T., Liu, D., Nguyen, L.,

Schwartz, R., and Srivastava, A. (2000). Speech

and language technologies for audio indexing and re-

trieval. Proc. of the IEEE, Vol.88(No.8):1338–1353.

Nouza, J.,

Cerva, P., and

Zd´ansk´y, J. (2009). Very large vo-

cabulary voice dictation for mobile devices. In Proc.

of Interspeech 2009, pages 995–998, Brighton, UK.

Poll´ak, P. and

Cernock´y, J. (2004). Czech SPEECON adult

database. Technical report.

Psutka, J., M¨uller, L., and Psutka, J. V. (2001). Compari-

son of MFCC and PLP parameterization in the speaker

independent continuous speech recognition task. In

Proc. of Eurospeech 2001, Aalborg, Denmark.

Psutka, J., Psutka, J., Ircing, P., and Hoidekr, J. (2003).

Recognition of spontaneously pronounced TV ice-

hockey commentary. In Proc. of ISCA & IEEE Work-

shop on Spontaneous Speech Processing and Recog-

nition, pages 83–86, Tokyo.

Rajnoha, J. and Poll´ak, P. (2011). Asr systems in noisy envi-

ronment: Analysis and solutions for increasing noise

robustness. Radioengineering, Vol.20(No.1):74–84.

Valin, J.-M. (2007). The speex codec manual. version 1.2

beta 3. http://www.speex.org.

Vanˇek, J. and Psutka, J. (2010). Gender-dependent acous-

tic models fusion developed for automatic subtitling

of parliament meetings broadcasted by the Czech TV.

In Proc. of Text, Speech and Dialog, pages 431–438,

Brno, Czech Republic.

Young, S. and et al. (2009). The HTK Book, Version 3.4.1.

Cambridge.

SIGMAP 2011 - International Conference on Signal Processing and Multimedia Applications
