WEB INTERFACE FOR SEMANTICALLY ENABLED

EXPERTS FINDING SYSTEM

Abramowicz Witold, Bukowska El

zbieta, Dzikowski Jakub, Filipowska Agata and Kaczmarek Monika

Department of Information Systems, Faculty of Informatics and Electronic Commerce, Poznan University of Economics

al. Niepodleglosci 10, 61-875 Poznan, Poland

Keywords:

Expert ﬁnding system, Semantic query interface design, Web interface evaluation.

Abstract:

In this paper, we address the issue of designing an interface for a semantic-based expert ﬁnding system that

allows for creation of sophisticated queries in a user-friendly manner. The designed interface supports the

structured way of building queries, the usage of semantic concepts, as well as facilitates the process of deﬁn-

ing complex logical structures. We also discuss the procedure and the outcomes of the interface usability

evaluation.

1 INTRODUCTION

Today, organizations often take advantage of data

available on the Internet to locate experts they re-

quire. As the data available is dispersed and of dis-

tributed nature, a need appears to support the human

resources management process using IT-based solu-

tions, e.g., information extraction and retrieval sys-

tems, especially expert ﬁnding systems. There are

many research and commercial initiatives aiming at

development of expert retrieval systems. One of such

initiatives is the on-going Polish project eXtraSpec

Its main goal is to combine company’s internal elec-

tronic documents and information sources available

on the Internet to provide an effective way of search-

ing experts with competencies in the given ﬁeld.

In order to answer users’ queries on experts, the

eXtraSpec system acquires and extracts information

from various sources, and ﬁnally, taking advantage

of the semantics, reasons over person’s characteris-

tics. One of the problems that arises in this context

is the simplicity and intuitive use of the interface to

formulate the queries by a user. The interface that

would allow to formulate complex queries would not

fulﬁl its goal, if users would not be able to use it in

practice. Therefore, within the project our aim was to

ﬁnd a balance between the possibilities offered by the

querying approach followed within the system and in-

tuitiveness of using the querying interface.

The main goal of this paper is to present the ap-

http://extraspec.kie.ue.poznan.pl/

proach followed within the eXtraSpec project, which

led to the development of a semantic-based mecha-

nism to retrieve experts. In addition, the evaluation

results conﬁrming the usefulness of a system interface

being a front-end to this mechanism are presented.

In order to fulﬁl the mentioned goals, the paper is

structured as follows. First, the related work in the

area of expert ﬁnding systems and interface design

is discussed. Next, the eXtraSpec system along with

query strategies is presented. Then, remarks on the

Web interface developed follow. Finally, the interface

evaluation outcomes are presented and discussed. The

paper concludes with ﬁnal remarks.

2 RELATED WORK

2.1 Expert Finding Systems

First systems focusing on expertise identiﬁcation re-

lied on a database like structure containing a descrip-

tion of experts’ skills (e.g., (Yimam-Seid and Kobsa,

2003)). Such systems faced many problems, e.g., how

to ensure precise results (Kautz et al., 1996) or how

to guarantee the accuracy and validity of stored in-

formation. To address these problems, other systems

were proposed (e.g., (Campbell et al., 2003), (Hawk-

ing, 2004)).

Currently, the Web offers many possibilities to

ﬁnd information on experts. There are a number of

contact management or social portals, where users

291

Witold A., El

zbieta B., Jakub D., Agata F. and Monika K..

WEB INTERFACE FOR SEMANTICALLY ENABLED EXPERTS FINDING SYSTEM.

DOI: 10.5220/0003503902910296

In Proceedings of the 13th International Conference on Enterprise Information Systems (ICEIS-2011), pages 291-296

ISBN: 978-989-8425-56-0

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

can look for experts, potential employees or publish

their curricula in order to be found by future employ-

ers

Regarding the algorithms applied, at ﬁrst, stan-

dard IR techniques to locate an expert on a given

topic were used (Ackerman et al., 2002; Krulwich and

Burkey, 1996). Then, to deal with the well-known IR

problems, methods such as probabilistic techniques or

language analysis techniques to improve the quality

of ﬁnding systems had been proposed (e.g., (Balog

et al., 2006; Fang and Zhai, 2007; Petkova and Croft,

2006; Serdyukov and Hiemstra, 2008)). Finally, the

Semantic Web technology has been used to enrich de-

scriptions within expert ﬁnding systems e.g., (Dorn

et al., 2007).

The expert ﬁnding systems have interfaces similar

to the regular search engines. A typical interface con-

sist of a ﬁeld, where a user poses a query and a but-

ton that starts searching. A more complicated view

is associated with the advanced search, however, even

then interface designers work on making it intuitive.

Nevertheless, even such simple interfaces may pose

severe problems when it comes to keyword speciﬁca-

tion (Muramatsu and Pratt, 2001).

(Shneiderman et al., 1997) speciﬁed eight design

guidelines for the development of search user inter-

faces: offering informative feedback, provision of

mechanisms for ordering of results and reformulating

queries, showing relevant information, providing al-

ternative interface mechanisms, offering simple error

handling mechanisms, striving for consistency in the

interface, permitting easy reversal of actions, apply-

ing graphic design principles established in the HCI

discipline.

These guidelines were taken into account while

developing the interface for the eXtraSpec system.

2.2 A Role of an Interface in the

Software Engineering Lifecycle

A user interface is often one of the most critical fac-

tors for the success or failure of a computerized sys-

tem (Vliet, 2008). A user judges the quality of a sys-

tem based on the interface and the way it helps to ac-

complish users’ tasks. In a technical sense, we per-

ceive a user interface as an architecture layer sepa-

rated from the application logic.

According to (Mayhew, 1999; Vliet, 2008), a

well-designed user interface contributes to the qual-

ity of a system in the following ways: increased ef-

ﬁciency, improved productivity, reduced errors, re-

duced training and improved acceptance.

E.g., www.123people.com, sig.ma, www.bizwiz.com,

www.xing.com or linkedin.com

Evaluation of user interfaces is often performed

using questionnaires (Perlman, 1985; Hornbaek,

2006). There is a number of different approaches

to design questionnaires assessing various aspects of

usability, validity, reliability e.g. (Norman, 1997;

Lewis, 1995; Wiklund, 1994; Lin et al., 1997; Lund,

2001).

The above approaches deﬁned a number of differ-

ent interface evaluation criteria. These criteria may be

further grouped into categories that include inter alia:

• learnability: clarity of wording, support materials,

contextual support, support, etc.

• user satisfaction: understandability, ease of learn-

ing, etc.

• ease of use: focusing on user friendliness, ﬂexi-

bility, etc.

• usefulness supporting efﬁciency, productivity,

time savings, etc.

• computation efﬁciency.

A typical questionnaire besides including ques-

tions from these categories, usually ﬁnishes with an

overall judgement of the interface from the user’s

point of view. This judgement depends however on

user’s knowledge and his previous experience.

Other type of interface evaluation methods include

interviews or user observation methods (Dumas and

Redish, 1993).

3 EXTRASPEC SYSTEM

In order to identify the requirements towards the eX-

traSpec system, ﬁrst some searching scenarios a per-

son looking for experts may be interested in, were

considered. This allowed especially to specify re-

quirements towards the developed ontology, reason-

ing mechanism and GUI.

3.1 Querying Strategies

The mentioned scenarios have been speciﬁed based

on the carefully conducted studies of the literature

and interviews with employers. The six most com-

mon searching goals are as follows:

1. To ﬁnd an expert with some experience on a posi-

tion of interest.

The requirement on the GUI includes enabling

speciﬁcation of job name (a position of interest)

and length of experience required.

2. To ﬁnd an expert having some speciﬁc language

skills on a desired level.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

292

Regarding requirements for GUI, there is a need

to point to a language of interest (a list), indicate

the proﬁciency level and a certiﬁcate name (if de-

sired).

3. To ﬁnd an expert having some competencies.

GUI has to give possibility to point to a name of a

skill/competency of interest.

4. To ﬁnd students who graduated recently/will grad-

uate in a given domain.

A requirement for GUI is to point to a category

of educational organization or a speciﬁc organiza-

tion, to name the result, a start and an end date of

the education.

5. To ﬁnd a person having expertise in a speciﬁc do-

main.

The requirement on GUI is to specify a domain of

interest.

6. To ﬁnd a person with a speciﬁc education, com-

petency, job, etc.

The requirement on GUI is to give possibility

to combine various categories into one complex

query and make it as easy as possible to specify

various logically connected constraints.

The above querying strategies imposed some re-

quirements on the information that should be avail-

able for experts as well as ontologies that needed to

be developed for the project needs. Requirements

on ontologies were further discussed in (Abramowicz

et al., 2011). In addition, the following requirements

may be deﬁned towards the querying mechanism of

the system:

• REQ QM.1: The querying mechanism (QM)

MUST allow to build queries in a structured way

(i.e., feature: desired value);

• REQ QM.2: The QM MUST support deﬁnition of

desired values of attributes in a way suitable to the

type of data stored within the given feature (i.e.,

text ﬁelds using wild-cards, date ﬁelds – after of

before certain dates; numbers – less than . . . );

• REQ QM.3: The QM MUST allow to join a sub-

set of selected criteria within the same category

into one complex requirement (e.g., category: ed-

ucation; education level: university AND ﬁnished

date: after 2010 year) using different logical op-

erators;

• REQ QM.4: The QM MUST allow to formulate a

set of complex requirements within one category

with different logical operators;

• REQ QM.5: It MUST allow to join complex

requirements formulated in various proﬁle cate-

gories into one criteria with different logical oper-

ators;

The logical operators between different set of cri-

teria and criteria themselves, include such operators

as: must, should, must not.

The requirements for the system Web interface

that result from the above deﬁned requirements to-

wards the entire querying mechanism are detailed and

presented in section 4.1.

4 EXTRASPEC WEB INTERFACE

DESIGN

The front-end to the eXtraSpec system should enable

users to build complex queries describing characteris-

tics of the desired experts. Below we present the iden-

tiﬁed requirements together with the interface model

and implementation-related issues.

4.1 Requirements

During the analysis phase the following requirements

for the considered expert ﬁnding system interface

have been deﬁned:

• REQ IN.1: The interface MUST enable a user to

specify constraints on expert’s attributes and se-

lect whether the value of an attribute is required,

desired (but not required) or not allowed.

• REQ IN.2: The interface SHOULD enable group-

ing of constraints e.g. it should be possible to

specify a graduated school and graduation date as

one criterion.

• REQ IN.3: The interface SHOULD provide a pos-

sibility to build queries which include comple-

mentary and alternative constraints.

• REQ IN.4: The interface SHOULD enable pro-

viding some of criteria values typed-in as free text

(with wildcards) and some of them to be selected

from the eXtraSpec system knowledge base.

• REQ IN.5: The interface SHOULD be loosely

coupled with the system (following the Seeheim

approach).

• REQ IN.6: The interface SHOULD be under-

standable and easy to use.

The complexity of the querying eXtraSpec system

should not affect the interface usability. An average

computer-skilled user should facilely express his or

her information needs regardless of their complexity.

WEB INTERFACE FOR SEMANTICALLY ENABLED EXPERTS FINDING SYSTEM

293

Figure 1: User interface — specifying criteria.

4.2 Conceptual Model of Interface

The search criteria are divided into the following cat-

egories: personal data, education, professional expe-

rience, foreign languages, courses, certiﬁcates, addi-

tional skills, organization membership and interests.

Most of them reﬂect categories from the expert’s pro-

ﬁle in the system, but some (like foreign languages)

are created to ease access to frequently used criteria

(foreign languages can be found also in the additional

skills category).

The categories consist of groups of ﬁelds. For ex-

ample, in the expert education category there is an ed-

ucation group which includes such ﬁelds like educa-

tional organization, graduation date or achieved pro-

fessional title. The desired values of these ﬁelds are

speciﬁed in the interface by criteria values, and ﬁeld

groups by criteria groups. Each criterion has a label

and a value typed by the user, selected from list or

from values tree.

4.3 Deﬁnition of Search Criteria

The search criteria are assigned to categories and ini-

tially categories are presented to a user. After clicking

an appropriate button, a category can be activated or

deactivated. Besides, a user can hide criteria in a cat-

egory (without deactivating it), what should be useful

when building complex queries.

A user can also add a group of criteria by click-

ing a button “Add criteria” or selecting a group name

from the list, which is presented instead of a button,

when in a category there are multiple groups of cri-

teria. In ﬁgure 1 there is group for education which

consists of ﬁve criteria (school, achieved professional

title, scope, topic, start date and graduation date) and

there are single-criterion groups, like last name or e-

mail address. Within a group, a user can specify al-

ternate criteria, for example in ﬁgure 1 alternate last

names are speciﬁed. The user can add these criteria

by clicking a button “or...” or “neither...” (depend-

ing on a type constraint for the group). Clicking “x”

button will cause removal of a particular criterion. A

selected type constraint is related with an appropriate

highlighting style of the criteria group.

A user can type some of the criteria, for example

last name or e-mail address; with the use of wildcards,

when needed. The values for some criteria depend on

knowledge base of the eXtraSpec system and possible

values are loaded from the ontology. In this case, a

user speciﬁes them by clicking on a particular ﬁeld

and then selecting appropriate values from a tree in a

pop-up window (see ﬁgure 2). The selected items are

presented on the bottom of the pop-up window and,

ﬁnally, in the appropriate ﬁeld.

5 WEB INTERFACE

EVALUATION

Within our research we followed the remote testing

approach, i.e., the users were not directly observed

while testing the application. The testing procedure

was discussed with them during a meeting, and they

were also informed what is the aim of the experiment

and what is to be tested. Then, they were given a test-

ing task together with an accompanying questionnaire

to ﬁll in.

Figure 2: User interface — window for criteria selection.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

294

5.1 Experiment Description

The experiment that aimed at the evaluation of the

user interface was carried out in two distinct phases

with a 2-weeks’ break in-between.

The ﬁrst phase was focused on learning how to

use the interface and pose the queries using the sys-

tem. The users were provided with a set of free-text

queries (considering query strategies presented in sec-

tion 3.1) and asked to express these queries using the

provided interface. These queries reﬂected common

information needs that may occur in experts ﬁnding

systems. Afterwards, they were to provide the query

generated by the system, which was displayed to them

in addition to the results. They were also to describe

their overall impression from using the system. This

way of interviewing users made them focus on pro-

viding the query as close to requirements as possible.

The user also knew that they may inﬂuence the ﬁnal

version of the interface, so they provided also recom-

mendation what should be changed within the system.

In the second phase users again were asked to ex-

periment with the system, however, this time they

were asked to provide detailed marks for each feature

of the interface. The aim of this phase of the experi-

ment was to evaluate the interface quality.

The users were not initially informed that this is a

two-phase experiment.

In both phases the same group of user’s partici-

pated. The group consisted of 31 students in their ﬁ-

nal year of the bachelor studies. The students have

just ﬁnished their software engineering course during

which they discussed various examples of user inter-

faces as well as guidelines for the interface design.

Some of the students are also part-time employees of

IT companies.

5.2 Experiment Results

As a result of the ﬁrst phase of experiment 70 query

instances with average accuracy at 83% were gath-

ered (all generated queries were checked for com-

pleteness). The best reached accuracy is 95% with

12 query instances, the worst 56% with 8 instances.

The ﬁrst phase of the experiment showed that the

current interface makes the system easy to use, but

the level of error tolerance or user assistance while

generating queries should be improved. The users

suggested to include an automcompletion mechanism

while writing or some pre-check of data introduced

in a ﬁeld. This however, could lead to limiting the

user in expressing the query. In case there are no ex-

pert proﬁles fulﬁlling the requirements, nothing is re-

turned.

Table 1: Detailed results of experiments.

Category 1 2 3 4 5 Average

rating

General 2% 6.5% 15% 59% 18% 3.9

Screen 2% 16% 16% 40% 27% 3.7

Capabilities 0% 2% 13% 32% 53% 4.4

Terminology 0% 16% 18% 42% 24% 3.7

Ease of use 3% 19% 32% 39% 8% 3.3

The detailed evaluation of the system however, was

provided in the second phase of the experiment held.

Here users, were to answer 12 detailed questions

about the features of the system. They were assessing

the interface following the Likert’s approach (with the

use of 1–5 scale) in the below categories:

• general: general impression, appriopriateness for

users with various computer abilities;

• screen: distribution of element of the screen, intu-

itiveness, similarity to front-ends of other known

ﬁnding systems;

• capabilities: speed and reliability;

• terminology: appropriate labels, icons and mes-

sages;

• ease of use.

The best rating the application’s front-end gained

in the capabilities category and the worst in the ease of

use category (mainly because of not enough support

offered to the user while deﬁning the query). Results

of the evaluation are presented in the table 1.

The most interesting, however, are not the average

evaluation results for each category, but their distribu-

tion when it comes to the different values of the scale.

The system was judged as good or very good by most

of the users. They also underlined that the system is

suitable also for a user without the expertise in IT (es-

pecially when it comes to the advanced querying).

6 CONCLUSIONS

Within this paper we have described the eXtraSpec

system together with its querying interface allowing

to ﬁnd persons with speciﬁc characteristics. We ar-

gue that designing a Web interface for a semantically-

enabled system while providing new querying possi-

bilities, poses also new challenges within the interface

design process. The conducted evaluation has proven

that extending the query deﬁnition process using an

appropriate form that need to be ﬁlled in before sub-

mitting the query, while allowing for expressing more

complex queries, is still understandable to users, and

quality of results achieved re-compensates the effort

WEB INTERFACE FOR SEMANTICALLY ENABLED EXPERTS FINDING SYSTEM

295

needed to be invested into the query deﬁnition pro-

cess.

ACKNOWLEDGEMENTS

The work published in this article was supported by

the project titled: “Advanced data extraction meth-

ods for the needs of expert search” ﬁnanced under the

Innovative Economy Framework and partially sup-

ported by European Union in the European Regional

Development Fund programme (contract no. UDA-

POIG.01.03.01-30-150/08-01).

REFERENCES

Abramowicz, W., Bukowska, E., Kaczmarek, M., and

Starzecka, M. (2011). Semantic-enabled efﬁcient and

scalable retrieval of experts. In International Confer-

ence on Information, Process, and Knowledge Man-

agement, eKNOW 2011.

Ackerman, M., Wulf, V., and Pipek, V. (2002). Sharing Ex-

pertise: Beyond Knowledge Management. MIT Press.

Balog, K., L., A., and De. Rijke, M. (2006). Formal models

for expert ﬁnding in enterprise corpora. In Proceed-

ings of the ACM SIGIR, pages 43–50.

Campbell, C. S., Maglio, P. P., Cozzi, A., and Dom, B.

(2003). Expertise identiﬁcation using email commu-

nications. In CIKM ’03: Proceedings of the twelfth in-

ternational conference on Information and knowledge

management, pages 528–321. ACM Press.

Dorn, J., Naz, T., and Pichlmair, M. (2007). Ontology de-

velopment for human resource management. In Pro-

ceedings of 4th International Conference on Knowl-

edge Management, Series on Information and Knowl-

edge Management, pages 109–120.

Dumas, J. and Redish, J. (1993). A Practical Guide to Us-

ability Testing. Norwood, NJ: Ablex.

Fang, H. and Zhai, C. (2007). Probabilistic models for ex-

pert ﬁnding. In Proceedingsof the ECIR, pages 418–

430.

Hawking, D. (2004). Challenges in enterprise search. In

Proceedings of the 15th Australasian database con-

ference – Volume 27, ADC ’04, pages 15–24, Dar-

linghurst, Australia, Australia. Australian Computer

Society, Inc.

Hornbaek, K. (2006). Current practice in measuring usabil-

ity: Challenges to usability studies and research. Int.

J. Hum.-Comput. Stud., 64:79–102.

Kautz, H., Selman, B., and Milewski, A. (1996). Agent

ampliﬁed communication. In Proceedings of the Thir-

teenth National Conference on Artiﬁcial Intelligence

(AAAI-96), pages 3–9.

Krulwich, B. and Burkey, C. (1996). Contactﬁnder agent:

answering bulletin board questions with referrals. In

Proceedings of the National Conference on Artiﬁcial

Intelligence, pages 10–15.

Lewis, J. R. (1995). Ibm computer usability satisfac-

tion questionnaires: Psychometric evaluation and in-

structions for use. International Journal of Human-

Computer Interaction, 7(1):57–78.

Lin, H. X., Choong, Y.-Y., and Salvendy, G. (1997). Pro-

posed index of usability: A method for comparing the

relative usability of different software systems usabil-

ity evaluation methods. Behaviour and Information

Technology, 16 (4/5):267–278.

Lund, A. M. (2001). Measuring usability with the use ques-

tionnaire. Usability Interface, 8(2).

Mayhew, D. J. (1999). The usability engineering lifecy-

cle. In CHI ’99 extended abstracts on Human factors

in computing systems, CHI ’99, pages 147–148, New

York, NY, USA. ACM.

Muramatsu, J. and Pratt, W. (2001). Transparent queries:

investigation users’ mental models of search engines.

In Proceedings of the 24th annual international ACM

SIGIR conference on Research and development in in-

formation retrieval, pages 217–224. ACM.

Norman, B. H. . L. S. . K. (1997). Questionnaire adminis-

tration via the www: A validation and reliability study

for a user satisfaction questionnaire. In Proceesings

of the WebNet 97, Association for the Advancement of

Computing in Education, Toronto, Canada.

Perlman, G. (1985). Behavior research methods. Instru-

ments, and Computers, 17:203–205.

Petkova, D. and Croft, W. (2006). Hierarchical language

models for expert ﬁnding in enterprise corpora. In

Proceedings of the 18th IEEE International Confer-

ence on Tools with Artiﬁcial Intel-ligence, pages 599–

608.

Serdyukov, P. and Hiemstra, D. (2008). Modeling docu-

ments as mixtures of persons for expert ﬁnding. In

Proceedings of the ECIR, pages 309–320.

Shneiderman, B., Byrd, D., and Croft, W. (1997). Clar-

ifying search: A user-interface framework for text

searches. D-lib magazine, 3(1):18–20.

Vliet, H. V. (2008). Software Engineering. John Wiley &

Sons, Ltd.

Wiklund, M., editor (1994). Usability in Practice: How

Companies Develop User-Friendly Products. Boston:

Academic Press.

Yimam-Seid, D. and Kobsa, A. (2003). Expert ﬁnding sys-

tems for organizations: Problem and domain analy-

sis and the demoir approach. In Journal of Organi-

zational Computing and Electronic Commerce, 13(1),

pages 1–24.

ICEIS 2011 - 13th International Conference on Enterprise Information Systems

296
