SIMULATING WEB SERVICES TRANSACTIONS

David Paul, Frans Henskens and Michael Hannaford

School of Electrical Engineering and Computer Science, University of Newcastle, Callaghan 2308, NSW, Australia

Keywords:

Web service, Transaction, Simulation, Protocol, Performance, Concurrency.

Abstract:

Transactions in a service-oriented environment are very different to traditional transactions. The typical ACID

properties are not always appropriate when processing transactions where multiple service providers wish to

maintain autonomy and process all requests in a timely manner. Thus, reductions to the ACID properties, such

as semantic atomicity and tentative holds, are often used to provide transactions for Web Services. This paper

describes a simulator for modelling various Web Services transaction strategies. The simulator is deterministic,

allowing the speciﬁcation of network conditions, provider resources, and client workﬂows to be kept constant

while altering the level of transaction support each provider offers. By modelling transaction ﬂow rather than

service ﬂow, this allows true comparison of transaction techniques in various scenarios. The simulator is

demonstrated using a validation experiment, and future use outlines how the simulator is being used to test a

system where providers offer a dynamic level of transaction support to clients.

1 INTRODUCTION

Service-Oriented Architectures (SOAs) are based on

service providers offering services to clients without

clients needing to understand the intricate details of

how a particular service is performed. Typically, the

client simply sends a request asking for a service to be

performed, and the provider either replies with a mes-

sage that the request was unsuccessful, or performs

the service and informs the client that the request has

completed successfully. Thus, the client only sees

whether the service has been performed, with no fur-

ther idea of how the provider completed the required

tasks. This is a powerful model that overcomes the

tight-coupling inherent in other distributed computing

paradigms (Henning, 2006).

One of the most common implementations of an

SOA is that of Web Services (Tiezzi, 2009). Us-

ing open standards (Christensen et al., 2001; Clement

et al., 2004; Gudgin et al., 2007), Web Services al-

low practically any party on the Internet to access and

utilise service-oriented interactions with Web Ser-

vices providers, regardless of any hardware, software,

or other environmental differences between the com-

municating hosts. Further, these standards can be

used as the basis of new standards to add support

for features not included in the original standards.

For example, Web Services Security (WS-Security)

(Lawrence and Kaler, 2006) provides message inte-

grity and conﬁdentiality to Web Services.

While SOAs allow easy abstraction when a client

only wishes to perform one service, it is often the

case that a client will require a workﬂow that utilises

multiple services from different providers to achieve

the results that the client desires (Barker et al., 2009).

The various providers used by such a client may have

no other connection than their services being needed

for that client’s workﬂow. Thus, the client requires a

method to combine these disparate services in such a

way as to ensure correct processing of the workﬂow.

In particular, some assurances of the outcome of the

workﬂow when some providers are unable or unwill-

ing to provide the services required of the client are

needed. Transactions provide a possible way to offer

such assurances (Papazoglou, 2003).

In traditional systems, transactions comply with

the ACID properties (Atomicity, Consistency, Isola-

tion, and Durability) (Gray and Reuter, 1993). How-

ever, complete support for these properties is not al-

ways possible or desirable in the Web Services envi-

ronment (Little, 2003). Instead, slightly weaker trans-

actional properties are typically preferred in Web Ser-

vices transactions to ensure both provider autonomy

and a reasonable quality of service (Buckpesch and

Maur, 2006).

While various alternatives for Web Services trans-

actions have been deﬁned (Lyon et al., 1998; Younas

et al., 2000; Ben Lakhal et al., 2001; Roberts and

615

Paul D., Henskens F. and Hannaford M..

SIMULATING WEB SERVICES TRANSACTIONS.

DOI: 10.5220/0003472206150623

In Proceedings of the 7th International Conference on Web Information Systems and Technologies (WSPA-2011), pages 615-623

ISBN: 978-989-8425-51-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Srinivasan, 2001; Ceponkus et al., 2002; Milanovic

et al., 2003; Bunting et al., 2003; Lin and Liu, 2005;

Wang et al., 2007), there has been very little testing

to compare the possible types of transactions to see

how they perform and to determine strategies to op-

timise transaction use in the Web Services environ-

ment. This paper describes a simulator to allow var-

ious different levels of transaction support to be di-

rectly compared. The simulator models the ﬂow of

transactions rather than the ﬂow of services. A vali-

dation experiment is also presented to show how the

simulator performs.

The remainder of the paper is organised as fol-

lows. Section 2 describes in more detail the differ-

ences between traditional transactions and those in the

Web Services environment. Section 3 then describes

the Web Services transactions simulator. The valida-

tion experiment is then described in Section 4, and

results are given in Section 5. Finally, Section 6 con-

cludes the paper and indicates some future research

directions.

2 TRANSACTIONS IN THE WEB

SERVICES ENVIRONMENT

The traditional ACID transaction properties usually

require either pessimistic or optimistic concurrency

control to ensure that concurrent transactions do not

interfere with each other. When a pessimistic scheme

is used, resources can be locked for long periods of

time. When optimistic schemes are used, many trans-

actions may be required to redo work that they have

already completed if another transaction interferes

with them. Neither of these are greatly appropriate

in the Web Services environment (Little and Freund,

2003), where transactions can take days to complete.

Further, traditional systems usually have a centralised

controller that is in charge of all entities involved with

the transaction. Such a central controller does not ex-

ist in service-oriented environments, where each ser-

vice provider need not even know that other providers

exist, let alone have any control over them.

Very few providers would be willing to give up the

autonomy necessary to support traditional transaction

schemes. Each service provider is an individual entity

with complete control over its actions. While clever

techniques do allow full support for the ACID prop-

erties in the Web Services environment (Choi et al.,

2005; Alrifai et al., 2006), these still require service

providers to lock resources for, potentially, long peri-

ods of time. Further, the length of time required for

any such lock is highly variable because it depends

on the workﬂow of the client requesting the resource.

Thus, the ACID properties are often inappropriate for

Web Services transactions.

2.1 Reductions to ACID Properties

Various reductions to the strength of some of the

ACID properties have been suggested. These include

semantic atomicity (Garcia-Molina, 1983), tentative

holds (Roberts and Srinivasan, 2001), and resilience

(Younas et al., 2006). A brief explanation of these

reduced properties is given below.

2.1.1 Semantic Atomicity

Semantic atomicity replaces the traditional atomicity

property. Rather than requiring transactions to always

appear as either completed or not started, semantic

atomicity only requires that a transaction eventually

resolves into one of those two states. Semantic atom-

icity is based on the concept of compensating ac-

tions (Levy et al., 1991), which logically undo pre-

viously completed actions. Thus, when a provider is

requested to perform an action, the action is processed

immediately. If either the action fails, or the action

succeeds and is never cancelled, then the behaviour

is identical to the behaviour had atomicity been en-

forced. However, if the action succeeds and the trans-

action is later cancelled, then the compensating action

for the performed action is carried out. This compen-

sating action performs any steps required to make it

appear as if the original request had never occurred.

In between the time when the original action is per-

formed and the compensating action completes, other

transactions may see the action as having been per-

formed when logically they should not. Thus, seman-

tic atomicity necessarily removes isolation.

2.1.2 Tentative Holds

Another commonly used reduction for the traditional

ACID properties is the support for tentative holds

(Fauvet et al., 2005). Tentative holds can be thought

of as advice that the requested resources are currently

available, without any guarantee that the resources

will be available in the future. A common example

are items in an online shopping cart. Multiple users

can have the same item in their cart, but when one

checks out and purchases the item then all other holds

on the item are cancelled, and the users are informed

of this fact. When a client has tentative holds on all

the resources required for its workﬂow it is certain

that, at one point in time, the workﬂow could have

succeeded. In such a case, it is possible that some

of the resources will become unavailable before the

client is able to convert the tentative holds to conﬁrm-

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

616

ed holds, but the client has increased conﬁdence that

the transaction can succeed.

2.1.3 Resilience

Resilience allows the transaction to try alternatives

rather than failing as soon as a service call is unsuc-

cessful. Resilience may repeatably request an oper-

ation until it succeeds, or may search for alternative

ways to achieve a goal. For example, when booking

a holiday, if no acceptable ﬂight is available with a

particular airline, a resilient system may book a ﬂight

with another airline instead.

2.2 Describing Reductions

It has been suggested that the ACID properties should

be replaced with the SACReD properties (Younas

et al., 2006) in the Web Services environment. Rather

than being an individual reduction in the strength of

ACID properties, the SACReD properties take advan-

tage of some of the unique features of SOAs to offer

an alternative. The C and D stand for consistency and

durability, as in the traditional ACID properties. SA

stands for semantic atomicity, and Re adds the con-

cept of resilience. However, the SACReD properties

cannot describe all of the possible reductions in trans-

actional strength. For example, the SACReD proper-

ties do not include tentative holds.

The reductions described in Section 2.1 are the

most commonly used reductions to the ACID prop-

erties used for Web Services transactions, but there

are others. Examining the possible reductions, most

can be described by using a combination of ﬁve basic

operations that can be requested by a client:

Enquire. Allows the client to query whether a re-

quest would currently be successful, without any

guarantee that a later request will succeed.

Prepare. Allows the client to query whether a re-

quest would currently be successful and, if so,

guarantees that any such request sent by the client

within a timeout period will succeed. On receipt

of a successful reply, the client has the option to

cancel the request, which relieves the provider of

its responsibility to guarantee the resources to the

client.

Commit. Performs the client’s request. This is the

only required operation for a service.

Compensate. Performs actions to undo a previously

committed request, provided that the call to com-

pensate is received within a timeout period.

Callback. Allows a provider to notify a client that

has previously received a response from the

provider in the case that the provider’s situation

has changed, changing the provider’s response.

Using these ﬁve operations, a traditional ACID

transaction can be described as a Prepare/Commit pat-

tern with an inﬁnite timeout for the Prepare stage.

Similarly, semantic atomicity is provided by having

the provider offer a Commit/Compensate pattern, and

support for tentative holds is achieved through an En-

quire/Callback/Commit pattern.

The concept of resilience cannot be described us-

ing these operations. However, replacing concrete

services with abstract services (Sch

afer et al., 2007)

can allow resilience in a way that is transparent to

both clients and service providers. Clients use the

abstract services rather than the services offered by

the concrete providers, and the abstract service acts

as a broker between all the providers offering alter-

native services. These abstract services can thus be

used in transactions described by the operations de-

ﬁned above.

2.3 Combining Different Levels of

Transactional Support

While the different transaction reductions do greatly

help make transactions more useful in the Web Ser-

vices environment, the use of a single reduction for

every action in a transaction is not always adequate

(Greenﬁeld et al., 2003). Combining different re-

ductions together is possible (Mikalsen et al., 2002;

Paul et al., 2010), and results in systems in which

both clients and providers are better able to have their

needs met. However, strategies on how best to sup-

port and combine different transactional properties

have not been thoroughly investigated. The simula-

tor described in this paper enables such strategies to

be tested much more easily than other current tech-

niques.

3 SIMULATING WEB SERVICES

TRANSACTIONS

Web Services transactions are complex (Paul et al.,

2008). There are many different interacting en-

tities, all working autonomously but cooperatively,

and therefore veriﬁcation and testing of transaction

schemes is also very complex. This makes it difﬁ-

cult for theoretical analysis alone to yield practical

results. Simulation allows the practical characteris-

tics of the various transaction schemes to be compared

with much more control and at a much lower cost than

is possible with real-world testing.

SIMULATING WEB SERVICES TRANSACTIONS

617

Analytical results for Web Services transactions are

important; in particular, it is vital to verify that the

various reductions to the ACID properties work cor-

rectly. Theoretical models have been developed to al-

low such veriﬁcation (Fantechi et al., 2009; Mayer

et al., 2008; Lapadula et al., 2008), but these models

do not easily allow direct comparison between differ-

ent transaction techniques. The models can indicate

whether techniques are valid, but cannot always in-

dicate the application for which (and environment in

which) a technique is most beneﬁcial. We believe an

alternate method is required to allow evaluation of the

real-world performance characteristics of transaction

schemes.

To test the performance of Web Services trans-

action techniques, one option is to set up real sys-

tems and conduct experiments utilising the different

schemes. A major problem with this approach is that

it requires large networks to be set up to perform

the tests. Setting up such an environment is costly,

and any results may be dependant on uncontrollable

variables that are not related to those being tested.

While it may be possible to set up a system in a lo-

cal environment, Web Services are often used to cross

boundaries between organisations, and across large

geographical areas. The results obtained through a

local experiment are only applicable to the environ-

ment in place at the time of the experiment. Similarly,

if a multi-organisational network were deployed for

transactional testing, any results would be dependant

on conditions of the network. For example, consider

a comparison of two different transaction techniques

where the ﬁrst is tested at a time when there is a sig-

niﬁcantly higher amount of unrelated network trafﬁc

than when the second is tested. Any comparison may

unfairly discriminate against the ﬁrst technique be-

cause of the higher network load.

Instead, simulation can be used as a low-cost ad-

dition to analysis, and will yield results that allow in-

tricate comparison of particular transaction strategies.

In a simulation, some or all of a system is abstracted

so that only the features important to the current in-

vestigation are tested (Kelton et al., 2004). To sim-

ulate Web Services transactions, details such as net-

work topology, the timing of various events, and even

the actual services being performed can be abstracted

to isolate the parameters of interest and allow more

efﬁcient study.

Most available Web Services simulation environ-

ments replace a Web Service with a simple, usually

local, program that answers responses in a way appro-

priate to the service being simulated (Winston, 1999;

Kilgore, 2003). This allows the ﬂow of services to

be tested. However, when examining Web Services

transactions, further abstraction can occur. Only the

transaction interaction patterns need be simulated; the

messages need not be exactly formatted as for a par-

ticular service. Section 3.1 describes a simulator that

models transaction ﬂow rather than service ﬂow.

3.1 The Web Services Transaction

Simulator

The Web Services simulator is composed of two dis-

tinct parts: the generator and the simulator. The gen-

erator allows the creation of descriptions of scenarios

that are used as input to the simulator. The simulator

uses the input description and other parameters (de-

scribed in Section 3.1.2) to determine the outcome

of the scenario. Thus, by keeping the scenario de-

scription constant and varying the simulator’s other

parameters, the effect of the changed parameters can

be studied.

This paper concentrates on the simulator only.

Section 3.1.1 describes the details of the scenario de-

scriptions that the simulator takes as input. Section

3.1.2 then describes the other parameters to the sim-

ulator. Details of the operation of the simulator are

given in Section 3.1.3, and Section 3.1.4 describes the

simulator’s output.

3.1.1 Describing Scenarios

A scenario description contains information about the

concrete participants in the scenario. The service

providers are speciﬁed; each provider allows clients

to book resources for a price. The number of re-

sources offered by a particular provider can be limited

or inﬁnite, and booking a resource can either be free

of charge, or at a cost. The likelihood that a provider

will agree to perform the service when sufﬁcient re-

sources are available is also part of the description.

To allow resilience, abstract providers can then be

speciﬁed in a service description. Abstract providers

contain a list of concrete providers. When an abstract

provider receives a service request from a client, it

forwards that request to one of the listed concrete

providers. If the request fails then, rather than noti-

fying the client of the failure, the abstract provider

requests the service from another of the concrete

providers in its list. The client only receives a noti-

ﬁcation of failure if all of the concrete providers that

the abstract provider contacts refuse to perform the

service.

After provider information, a scenario description

contains details of a set of clients and the workﬂows

they wish to complete. Each workﬂow consists of a

sequence of activities to be performed, and speciﬁes

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

618

whether successful completion of each activity is re-

quired, or if the workﬂow is successful when at least

one of the included activities succeeds. When all ac-

tivities are required, the workﬂow fails whenever one

or more included activity fails. Otherwise, the work-

ﬂow only fails when all included activities complete

unsuccessfully. An activity can either be a workﬂow

or a service call. A service call consists of the name

of a provider, the name of the service to be requested

from that provider, and the number of resources to re-

quest from the service.

Finally, a scenario description contains timing in-

formation. When sending messages between clients

and providers, timing is very important. Messages

are not received immediately after they are sent, and

the length of time required for a message to travel

between two parties is dependant on many factors,

such as network bandwidth and congestion, and the

load of the systems involved in the communication.

Similarly, once a message is received, it takes time

for the message to be processed. The scenario de-

scription includes a set of time modellers that specify

how long messages take from when they are ﬁrst sent

to when they begin being processed, as well as how

long the processing of the message takes. There is

a time modeller for each pair of communicating par-

ticipants, allowing simulation of the large range and

rapid changes possible in both network conditions and

the local conditions of the participants involved.

3.1.2 Simulator Parameters

As well as the scenario description, the simulator also

has parameters to control the level of transaction sup-

port offered by the service providers and the risk-

taking behaviour of the clients. Different transac-

tion strategies and techniques can thus be tested on

an identical scenario by varying the simulator’s other

parameters. The simulator is deterministic, so any

change in results can be attributed to the change in

parameter values.

The transaction support offered by concrete

providers is speciﬁed based on the ﬁve operations

deﬁned in Section 3.1.1. Combined with the ab-

stract services in the scenario description, this allows

providers to utilise all of the reductions to the standard

ACID properties. The level of transaction support of-

fered by an abstract service depends on the levels of

support offered by the concrete providers that it con-

tacts. While the simulator does allow abstract services

to offer varying levels of transaction support based on

the client’s requirements and the levels of support of-

fered by the concrete providers, details of this are be-

yond the scope of this paper.

Another important set of parameters for the sim-

ulator is the risk-taking behaviour of the clients. A

client’s risk-taking behaviour determines how likely

it is that the client will perform an action that has the

possibility of leaving a client in a worse state than

when it started. For example, a client with high risk-

taking behaviour would simply ask all parallel opera-

tions to commit simultaneously, without regard to the

fact that some requests may succeed and others may

fail. Alternatively, when minimising risk, a client may

ﬁrst only call services that offer a Prepare or Com-

pensate stage so that, if any action fails, the semantic

atomicity of the transaction can be maintained.

3.1.3 Simulator Operation

Web Services are based on a messaging model by

which a message is sent from one party to another

and is then processed by the receiver. On receipt of

the message, processing may alter the receiver’s state,

and may also send messages either in reply to the orig-

inal sender or on to a third party. The Web Services

transaction simulator follows this messaging model.

When a client or provider wishes to send a message,

it notiﬁes the simulator. The simulator uses the time

modeller associated with the sender and receiver of

the message to determine when the message should be

delivered. All messages are added to a priority queue

and the simulator ensures that each message arrives at

its destination at the correct time.

When a provider has only ﬁnite resources to of-

fer, the simulator tracks the state of the provider’s

interaction with each client that sends it a request.

This allows correct transactional behaviour. For ex-

ample, when an ACID Prepare/Commit pattern is of-

fered, the provider must not offer any resources that

it has guaranteed to be available to one client to any

other client until the ﬁrst client (that requested the re-

sources) has ﬁnished its transaction. If a tentative hold

Enquire/Callback/Commit pattern is used instead, the

provider can have multiple clients with tentative holds

on some of its resources, but if one of those clients

request to commit then the provider must send a noti-

ﬁcation to the other clients that their hold is no longer

valid.

Similarly, under the simulator, clients monitor

their interactions with providers. Each client tracks

the progress of the various activities in its workﬂow.

The risk-taking behaviour of the client is continually

examined to determine how the client should proceed.

This allows three possibilities, depending on whether

the risk of continuing is judged to be acceptable, un-

acceptable, or uncertain. If the risk is acceptable, the

client sends messages to begin its next action. If the

risk is unacceptable then the client cancels as much of

the processed workﬂow as is possible and the transac-

SIMULATING WEB SERVICES TRANSACTIONS

619

tion fails. If the client is uncertain of the risk of con-

tinuing then it waits until its situation changes before

taking any further action.

3.1.4 Simulator Output

Simulation continues until all clients and providers

have ﬁnished processing. As the simulation is ex-

ecuting, a log of all messages is created. This in-

cludes the name of the sender and receiver of the mes-

sage, the time the message was sent, the time it is re-

ceived, and the content of the message. Combined

with the simulator parameters, the message log al-

lows various details to be extracted. This includes in-

formation such as the length of a client’s transaction,

whether the client’s workﬂow completed successfully,

and the cost to the client. From the provider’s point of

view, the number of resources utilised and the amount

clients paid to the provider can be measured. These

results provide the necessary details to allow compar-

ison of the various transaction strategies.

4 VALIDATION EXPERIMENT

This section describes a validation experiment to

demonstrate the simulator’s use. The experiment is

designed to show the shortcomings of the ACID prop-

erties in SOAs (such as thoat provided by Web Ser-

vices).

4.1 Simulation Parameters

This scenario tests a single provider offering 1000 re-

sources with four possible levels of transaction sup-

port. The four levels of transaction support tested

are a traditional ACID Prepare/Commit scheme, a tra-

ditional ACID Prepare/Commit scheme with a time-

out of 500 (so that any call to begin automatically

cancels if not told to commit within 500 time units

of when the ﬁrst call was received), a tentative

hold Enquire/Callback/Commit scheme, and a seman-

tic atomicity Commit/Compensate scheme. Clients

in this scenario wish to book resources from the

provider, and complete some other actions. For the

purpose of this scenario, there are 1000 clients who

each wish to book between 1 and 10 (randomly cho-

sen) resources from the provider. The other actions

are modelled as another service call that takes be-

tween 1 and 50 time units to complete, and has a 20%

likelihood of failure.

4.2 Assumptions

The different transaction types can only be properly

tested when there is resource contention. When re-

sources are plentiful, each client can access the re-

sources they require without affecting other concur-

rent transactions. When resources are limited, but

timing of transactions is spread so that none are exe-

cuting concurrently, the ﬁrst transactions will success-

fully utilise all of the available resources, and later

transactions will fail simply because the resources

they require are unavailable. Since the 1000 clients

are requesting well over the 1000 resources available

from the provider, it is sufﬁcient to ensure that the

transactions are executing concurrently to create true

resource contention. To this end, each client’s trans-

action is set to start between time 0 and time 100; as

each transaction can take over 50 time units, this en-

sures that resource contention occurs.

As mentioned in Section 3, events do not occur

immediately when a message is sent; each message

takes measurable time to travel from the sender to the

recipient. For the purposes of this experiment, it is

assumed that each message takes between 1 and 5

time units from when it is sent to when its process-

ing commences. The processing of a message is also

not instantaneous; the provider in this scenario takes

between 1 and 10 time units to process a request.

5 RESULTS

The results are presented in Table 1. The ﬁrst column

indicates the level of transaction support being tested.

The “provider utility” column gives the percentage of

resources originally offered by the provider that were

booked once all transactions had completed. The

“client successful” column indicates how many trans-

actions completed all operations successfully. This is

in contrast to “client unsuccessful without penalty”,

which shows how many transactions failed without

completing any of the required operations, and “client

unsuccessful with penalty”, which shows the num-

ber of transactions that end partially completed, with

either the resource booking completing successfully

but the rest of the transaction failing, or the resource

booking failing and rest of the transaction completing

successfully. The ﬁnal column indicates the average

duration of the client transactions for each of the dif-

ferent levels of transaction support.

In each case, except where semantic atomicity is

offered, all of the provider’s resources are utilised.

As the number of client transactions is so large and

the number of resources offered by the provider so

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

620

Table 1: Results for Validation Experiment.

Transaction

support

Provider

utility (%)

Client

successful

(%)

Client unsuccessful

without penalty (%)

Client unsuccessful

with penalty (%)

Average

duration of a

transaction

ACID 100 23.0 77.0 0.0 1316

ACID with time

out

100 24.5 72.8 2.7 1245

Tentative hold 100 15.6 57.5 26.9 228

Semantic

atomicity

86.2 16.7 83.3 0.0 134

small, this is hardly surprising; many more resources

would be required to satisfy all clients’ requests, so

there are many clients all wishing to access the same

resources. When the ACID schemes are used, the

resources quickly become locked by the ﬁrst clients

requesting them, and all other clients must wait un-

til a ﬁnal decision (or time out) occurs before dis-

covering whether they have access to the resources

they require. Thus, if ever a client decides against us-

ing the resources it had locked, there are numerous

other clients waiting to place a lock on the resources

freed by that client. Similarly, when the tentative

hold scheme is used, numerous clients have simulta-

neous holds on the resources. Since those holds are

only invalidated when resources are actually booked,

transactions only fail if the other actions in the trans-

action fail, or the requested resources are truly not

available. In contrast, when semantic atomicity is of-

fered, it is possible for a transaction to fail because

another client’s transaction has already booked those

resources. If the other transaction later compensates

that booking, however, then the ﬁrst transaction may

have been able to succeed, but, since the resources

were not available when that transaction needed them,

the transaction has already failed.

Looking at the results of the clients’ transactions,

more transactions succeed when an ACID scheme is

used. This is because clients wait until they are guar-

anteed their request for resources will be successful

before attempting the remainder of the transaction.

This essentially reduces the number of concurrently

executing transactions to only those that have access

to the resources they require; all other executing trans-

actions wait to be given access to the resources before

they continue with the rest of their transaction. When

a timeout is included, it is possible that a client may

have the required resources locked and then attempt

to complete the rest of the transaction, but have the

timeout occur before they can complete their book-

ing. This results in a failure with penalty, as the other

actions may have completed and not be cancellable,

though the longer the timeout period the less likely

this would be. On the other hand, when tentative hold

is used, many clients are granted holds on the same re-

sources and then attempt to complete the rest of their

transaction. Thus it is much more likely that transac-

tions fail with a penalty, as they complete the rest of

their transaction, but their tentative hold expires be-

fore they can ﬁnalise their booking of the resources.

When semantic atomicity is used, as stated in the pre-

vious paragraph, many transactions fail at an earlier

time when they could have succeeded later, which re-

duces the number that complete successfully. How-

ever, as when an ACID scheme with no timeout is

used, transactions only ever fail without penalty.

Thus, traditional ACID techniques are much bet-

ter at ensuring successful transaction completion util-

ising as many resources as possible. However, con-

sidering the average duration of a transaction, it can

be seen why they are not preferred for transactions

in a service-oriented environment. Forcing clients to

wait until a guarantee that the requested resources will

be available means that clients spend a lot of their

transaction time waiting. When a traditional scheme

is used, the average duration of a transaction is over

1200 time units, compared to only 228 when tentative

hold is used, or 134 when semantic atomicity is of-

fered. In many cases, clients would not be willing to

wait that long, and would thus not use the provider

offering the traditional scheme. These results con-

ﬁrm the accepted knowledge that strict adherence to

the ACID properties is typically not suitable for SOA

transactions (Dalal et al., 2003).

6 CONCLUSIONS

The environment offered by SOAs is very different

to that typically utilised by traditional transactions.

The high autonomy of all service providers and the

potential for transactions to run for long periods of

time mean that the typical ACID properties are not al-

ways appropriate. Instead, different techniques, such

as tentative holds and semantic atomicity, which redu-

SIMULATING WEB SERVICES TRANSACTIONS

621

ce the strength of some of the ACID properties, are

used to avoid some of the negative effects introduced

by strong transactional support. Thus, there is a bal-

ancing act between the level of transaction support

offered and the autonomy of the service providers in-

volved in a transaction.

The various reductions used for Web Services

transactions have different strengths and weaknesses.

However, it is difﬁcult to compare the performance of

the various possible reductions, as real-world testing

requires large infrastructure and makes truly repeat-

able tests impossible. While analytical approaches

are important to show the viability and correctness of

the various transaction schemes, it is difﬁcult to com-

pare all schemes using these methods, as they often

lack real-world performance measures. Simulation

can build on the theory to give an indication of prac-

tical results without the difﬁculties associated with

real-world testing. Various scenarios can repeatably

be processed by the simulator to compare changes to

the transaction scheme being used, and the practical

viability of the different schemes can be evaluated.

This paper describes a simulator that models the

ﬂow of transactions to allow testing of different Web

Services transaction techniques. By abstracting over

details such as network setup, timing of messages,

and the actual operations being performed, the sim-

ulator is able to utilise different transaction standards

for various scenarios to determine how the transaction

techniques perform in the given circumstances. The

simulator is deterministic, allowing true comparison

of the transaction techniques when performing iden-

tical operations. This allows much easier evaluation

of the various transaction options, which can lead to

a more informed choice of transactional support for

real-world services.

To demonstrate the simulator’s functionality, a

simple scenario was modelled to show how ACID

transactions compare to transactions with either se-

mantic atomicity or tentative hold support. This

showed that ACID transactions can allow more suc-

cessful completions of transactions, but do this at the

cost of time. The average duration of ACID transac-

tions in this simulation was over ﬁve times longer than

the average time when the weaker transaction guaran-

tees were used. This shows that, in environments such

as that of Web Services, where long transaction times

should be avoided, ACID transactions are often not

the best choice.

In the future, the simulator will be used to

compare different transaction strategies for service

providers. This includes more extensive research

into the use of dynamic transaction support, where

the level of transaction support offered by a service

provider varies based on the provider’s current cir-

cumstances (Paul et al., 2010). This study will al-

low both clients and service providers to negotiate the

level of transaction support being offered to ensure

that all parties involved are satisﬁed with the results.

REFERENCES

Alrifai, M., Dolog, P., and Nejdl, W. (2006). Transactions

concurrency control in Web Service environment. In

The 4th IEEE European Conference on Web Services

(ECOWS’06), pages 109–118.

Barker, A., Walton, C., and Robertson, D. (2009). Chore-

ographing Web Services. IEEE Transactions on Ser-

vices Computing, 2(2):152–166.

Ben Lakhal, N., Kobayashi, T., and Yokota, H. (2001). WS-

Sagas: Transaction Model for Reliable Web-Services-

Composition Speciﬁcation and Execution. DBSJ Let-

ters, 2(2):17–20.

Buckpesch, S. and Maur, M. (2006). Transactions in Web

Services. Technical report, Darmstadt University of

Technology.

Bunting, D., Chapman, M., Hurley, O., Little, M., Mis-

chkinsky, J., Newcomer, E., Webber, J., and Swenson,

K. (2003). Web Services Transaction Management

(WS-TXM) ver1.0. Technical report, Arjuna Tech-

nologies Ltd.

Ceponkus, A., Dalal, S., Fletcher, T., Furniss, P., Green, A.,

and Pope, B. (2002). Business Transaction Protocol

1.0. Technical report, OASIS.

Choi, S., Kim, J., Jang, H., Kim, S. M., Song, J., Kim, H.,

and Lee, Y. (2005). A framework for handling depen-

dencies among web services transactions. In The 14th

International Conference on World Wide Web (WWW

’05), pages 1130–1131, New York, NY, USA. ACM

Press.

Christensen, E., Curbera, F., Meredith, G., and Weer-

awarana, S. (2001). Web Services Description Lan-

guage (WSDL) 1.1. Technical report, World Wide

Web Consortium.

Clement, L., Hately, A., von Riegen, C., and Rogers, T.

(2004). UDDI version 3.0.2. Technical report, OASIS.

Dalal, S., Temel, S., Little, M., Potts, M., and Webber, J.

(2003). Coordinating Business Transactions on the

Web. IEEE Internet Computing, 7(1):30–39.

Fantechi, A., Gnesi, S., Lapadula, A., Mazzanti, F.,

Pugliese, R., and Tiezzi, F. (2009). A logical veri-

ﬁcation methodology for service-oriented computing.

Technical report, Universita’ degli Studi di Firenze.

Fauvet, M.-C., Duarte, H., Duman, M., and Benatallah,

B. (2005). Handling Transactional Properties in

Web Service Composition. In The 6th International

Conference on Web Information Systems Engineering

(WISE’05), pages 273–289.

Garcia-Molina, H. (1983). Using semantic knowledge for

transaction processing in a distributed database. ACM

Transactions Database Systems, 8(2):186–213.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

622

Gray, J. and Reuter, A. (1993). Transaction Processing:

Concepts and Techniques. Morgan Kaufmann Pub-

lishers, San Mateo, Calif.

Greenﬁeld, P., Fekete, A., Jang, J., and Kuo, D. (2003).

Compensation is not enough. In The 7th International

Enterprise Distributed Object Computing Conference

(EDOC), pages 232–239.

Gudgin, M., Hadley, M., Mendelsohn, N., Moreau, J.-J.,

Nielsen, H. F., Karmarkar, A., and Lafon, Y. (2007).

SOAP version 1.2. Technical report, World Wide Web

Consortium.

Henning, M. (2006). The rise and fall of CORBA. Queue,

4(5):28–34.

Kelton, W. D., Sadowski, R. P., and Sturrock, D. T. (2004).

Simulation with Arena. McGraw-Hill: Boston, MA,

third edition.

Kilgore, R. A. (2003). Simulation Web services with .Net

technologies. In Proceedings of the Winter Simulation

Conference, volume 1, pages 841–846. IEEE.

Lapadula, A., Pugliese, R., and Tiezzi, F. (2008). Speci-

fying and Analysing SOC Applications with COWS.

In Concurrency, Graphs and Models, volume 5065 of

Lecture Notes in Computer Science, pages 701–720.

Springer.

Lawrence, K. and Kaler, C. (2006). Web Services Se-

curity: SOAP Message Security 1.1 (WS-Security

2004). Technical report, OASIS.

Levy, E., Korth, H. F., and Silberschatz, A. (1991). An

optimistic commit protocol for distributed transaction

management. SIGMOD Record, 20(2):88–97.

Lin, L. and Liu, F. (2005). Compensation with dependency

in Web Services composition. In The International

Conference on Next Generation Web Services Prac-

tices (NWeSP), pages 183–188. IEEE Computer Soci-

ety.

Little, M. (2003). Web Services transactions: past, present

and future. In XML 2003.

Little, M. and Freund, T. (2003). A comparison of Web

Services transaction protocols. Technical report, IBM

Corporation.

Lyon, J., Evans, K., and Klein, J. (1998). Transaction Inter-

net Protocol version 3.0. Technical report, Microsoft

Corporation and Tandem Computers.

Mayer, P., Schroeder, A., and Koch, N. (2008). A model-

driven approach to service orchestration. In Interna-

tional Conference on Services Computing, Honolulu,

USA.

Mikalsen, T., Tai, S., and Rouvellou, I. (2002). Trans-

actional Attitudes: Reliable Composition of Au-

tonomous Web Services. In Workshop on Dependable

Middleware-based Systems (WDMS’02) at the De-

pendable Systems and Network Conference (DSN’02).

Milanovic, N., Stantchev, V., Richling, J., and Malek, M.

(2003). Towards adaptive and composable services.

Proceedings of the IPSI2003.

Papazoglou, M. P. (2003). Web Services and Business

Transactions. World Wide Web, 6(1):49–91.

Paul, D., Henskens, F. A., and Hannaford, M. (2010). Per-

request Contracts for Web Services Transactions. In

6th International Conference on Web Information Sys-

tems and Technologies (WEBIST-2010). INSTICC.

Paul, D., Wallis, M., Henskens, F. A., and Hannaford, M.

(2008). Transaction support for interactive Web appli-

cations. In The 4th International Conference of Web

Information Systems and Technologies (WEBIST’08).

Roberts, J. and Srinivasan, K. (2001). Tentative Hold Pro-

tocol part 1: White paper. Note, World Wide Web

Consortium.

Sch

afer, M., Dolog, P., and Nejdl, W. (2007). Engineering

Compensations in Web Service Environment. In The

International Conference on Web Engineering, Como,

Italy. Springer Berlin/Heidelberg.

Tiezzi, F. (2009). Speciﬁcation and analysis of Service-

Oriented Applications. PhD thesis, Dipartimento

di Sistemi e Informatica, Universit

a degli Studi di

Firenze.

Wang, T., Vonk, J., and Grefen, P. W. P. J. (2007). TxQoS: A

Contractual Approach for Transaction Management.

In EDOC, pages 327–338.

Winston, C. K. (1999). An Experience Simulating Web Ser-

vices. In CMG Conference, volume 2, pages 665–669.

Computer Measurement Group.

Younas, M., Eaglestone, B., and Holton, R. (2000). A

formal treatment of the SACReD protocol for multi-

database Web transactions. In The 11th International

Conference on Database and Expert Systems Appli-

cations (DEXA’00), pages 899–908, London, UK.

Springer-Verlag.

Younas, M., Li, Y., and Lo, C.-C. (2006). An Efﬁcient

Transaction Commit Protocol for Composite Web

Services. In The 20th International Conference on

Advanced Information Networking and Applications

(AINA’06), volume 1, pages 591–596, Washington

DC, USA. IEEE Computer Society.

SIMULATING WEB SERVICES TRANSACTIONS

623
