ALIGNMENT OF OPEN SOURCE TOOLS WITH THE

NEW ISO 25010 STANDARD

Focus on Maintainability

Emanuel Irrazábal, Javier Garzás

University Rey Juan Carlos, Madrid, Spain

Kybele Consulting S. L., Madrid, Spain

Esperanza Marcos

University Rey Juan Carlos, Madrid, Spain

Keywords: ISO 25010, Maintainability, Tools, Product metrics.

Abstract: Nowadays, quality and especially software product quality is becoming a hot topic in the context of

Software Engineering. In this context, measures provide the basis for the improvement and, in particular,

code measures provide direct visibility of product quality. Nevertheless, some organizations cannot afford

these tools. Several studies have revealed that applying quality models in Small and Medium-Sized

enterprises (SMEs) is a very challenging task. Related to this, open-source tools emerge as the answer to

provide with the technical support to collect the information needed to assess the quality of software assets.

In this work, we review how existing open-source tools fulfill the needs for quality measures raised when

you want to assess product quality according to the new ISO/IEC 25010 standard, which has introduced

changes in the characteristics of model quality over the previous model. We have focused on the

characteristic of maintainability because of its historical significance and its direct impact on total costs.

1 INTRODUCTION

Quality is currently recognized by companies as a

major asset to improve their competitiveness. At the

same time it has become an essential requirement to

ensure that the processes and products developed

meet the needs of the customer. Although software

quality can be described according to several points

of view, when it comes to software development,

quality is traditionally related to product quality and

process quality (Ebert 2009).

As a response, different reference models for

product quality assessment have appeared. In

particular, the International Organization for

Standardization (ISO) works in a new quality model,

the ISO/IEC 25010 (ISO/IEC JTC 1 2011) that

revises the standard ISO/IE 9126:2001, Software

engineering – Product quality (ISO 2001).

This new standard is currently published (since

March 2011) and defines two quality models: a

quality in use model and a product quality model.

Basically, the product quality model identifies

quality characteristics and how they are decomposed

into subcharacteristics. In this work we focus on one

of them: maintainability, since it has been

historically recognised as one of the most relevant

issues given its direct impact over the cost of

software development and maintenance. Previous

studies point out at maintenance as the most

expensive phase along the product lifecycle,

involving twice the development costs (Pressman,

2002); (Saiedian and Carr 1997).

Measures provide the basis for the improvement

and, in particular, code measures provide direct

visibility of product quality. Taking these

assumptions into consideration, the most suitable

approach seems to be the use of commercial tools

for the automatic acquisition of such measures

(Pagano, 2006). Nevertheless, some organizations

cannot afford these tools. Several studies have

revealed that applying quality models in Small and

Medium-Sized enterprises (SMEs) is a very

challenging task (Saiedian and Carr 1997); (Staples

111

Irrazábal E., Garzás J. and Marcos E..

ALIGNMENT OF OPEN SOURCE TOOLS WITH THE NEW ISO 25010 STANDARD - Focus on Maintainability.

DOI: 10.5220/0003449201110116

In Proceedings of the 6th International Conference on Software and Database Technologies (ICSOFT-2011), pages 111-116

ISBN: 978-989-8425-77-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

et al. 2007) since it implies huge investments in

terms of money, time and human resources. This

type of organizations needs from adapted Software

Engineering practices to fit their size and the nature

of their business (Dyba, 2005).

All this given, this work reviews the technical

support that existing open-source tools for code

analysis offer to the metrics that need to be collected

to measure the maintainability subcharacteristics

specified by the ISO 25010 standard. This work is

partially carried out based on another work

(Irrazábal, 2010) made on the basis of ISO 9126

standard and taking into account only a selection of

tools found in an open source software repository.

The remainder of the paper is organized as

follows. Section 2 presents a summary of the ISO

25010 standard, section 3 presents a summary of the

basic metrics proposed by the main measurement

models that can be found currently. Section 4 details

the tools chosen to measure the basic metrics and

explains the selection criteria. In Section 5, it has

been performed a qualitative analysis of the found

tools. Finally, Section 6 summarizes the main

findings of the study.

2 THE MAINTAINABILITY

CHARACTERISTIC IN

ISO 25010

Before going deeply into this work, we first provide

with a brief overview of the maintainability

characteristic in ISO 25010 product quality model,

the importance of this characteristic on the quality in

use model and the amendments respect of the ISO

9126 maintainability characteristic.

The main objective of ISO 25010 is to provide a

framework for defining and evaluating the quality of

software. To accomplish this, the standard defines

two models.

The first is the product quality model that

provides a set of quality characteristics relevant and

related to static properties of software and dynamic

properties of the computer system. To that end, it

identifies eight characteristics that compose models

to assess product quality (listed above).

One of these is the maintainability, the most

interesting for this paper. Here we want to know

how easy it would be to modify the software

product. In some sense, it is a measure of the effort

required to correct a defect or make a change that

preserves software functionality. Obviously,

software is maintainable if it is easy to understand

and test (Heitlager, Kuipers & Visser 2007). Each

characteristic in the ISO 25010 product quality

model is composed of a set of related

subcharacteristic. In this case, the maintainability is

composed of the following four subcharacteristics:

analyzability, modifiability, testability and

reusability.

To summarize, the value for the maintainability

subcharacteristics (affecting both models described

above) should be obtained by computing a set of

measurement functions over the capability of the

software. And this capability is determined by a set

of static internal properties that can be measured.

Nevertheless, nothing it is said about how these

functions should be defined, which ones should be

the elements to compute and how the values of them

have to be gathered.

3 CHOICE OF BASIC

MAINTAINABILITY METRICS

This section summarizes the most important

measurement models because of the impossibility of

finding a single measurement model sufficiently

recognized and that details the basic recommended

set of metrics to measure maintainability.

Various measurement models have been

collected. We have added an acronym after each

reference so that it can easily be named in Table 1.

One of the studies that can be considered more

interesting in this regard is (Riaz 2009)[M1]. This is

a systematic review that collects evidence on

software maintainability prediction and metrics. The

search has been made again. Regarding the search,

string has made customizations, adding two new

words: reusability and modifiability. This has been

one of the sources that will yield maintainability

measurement models. Another source has been the

direct search in online databases like ACM Digital

Library, Springer Link, IEEE Xplore, Science

Direct, etc.

The encountered models relate a set of quality

metrics obtained from source code with the

maintainability subcharacteristics. We are not taken

into account those models directly related to the

characteristic of maintainability. This made

impossible to relate the metrics to the different

subcharacteristic. Yet, many of these metrics can be

found in Table 1, named by other models.

Main models found were as follows: Rüdiger

Lincke suggests a software quality model for the

maintainability characteristic and indicate some

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

112

basic metrics associated. (Luijten, Visser & Zaidman

2010) [M2]. In (Alshayeb 2009) [M3] reusability is

associated with a subset of metrics. Another

complete maintainability measurement model is

described in (Heitlager, Kuipers & Visser 2007)

[M4]. In this paper, authors mapped maintainability

subcharacteristics (based on ISO 9126) onto source

code properties, such as volume, complexity,

duplication, unit length and number of modules.

In (Mouchawrab, Briand & Labiche 2005) [M5]

a generic measurement framework for object-

oriented software testability has been presented.

Ioannis Samoladas presents a hierarchical quality

model that evaluates source code and community

processes (Samoladas et al. 2008) [M6].

Results are summarized in Table 1, which

presents the basic set of internal metrics that are

related to the subcharacteristics: analyzability,

modifiability, testability and reusability. It is

noteworthy to see how many of the measurement

models associated with maintainability do not

directly consider the reusability. That is why we

have opted to seek metric articles (Barnard

1998)[M7](Washizaki, Yamamoto & Fukazawa

2003)[M8] dealing directly with basic reusability

metrics.

Metrics acronyms have been added to facilitate

the construction of the subsequent tables.

4 CHOICE OF TOOLS

Given the summary of the basic metrics obtained in

the previous section, we have chosen the open-

source tools that can analyze the software product

code. Once found the open source tools related to

the static analysis of source code and related to the

maintainability we analyze the degree of

contribution of the metrics that are obtained.

It has followed the approach used in

(Wangenheim 2009), reviewing the repositories of

existing open source projects and selecting the main

repository to be examined. The search was

supplemented by two other sources. The former is

the selection of tools shown in similar studies and

recommendations derived from quality managers.

The latter source has been obtained from interviews

with a group of companies involved in a project to

improve its development process, including

measurement of indicators of the software product.

4.1 Primary Tool Selection

According to previous studies (Wangenheim 2009)

the SourceForge repository currently hosts more

open source project compared to Codeplex, Google

Code or Kenai. Then, we have identified the typical

Table 1: Summary of internal metrics related with the maintainability characteristic according to ISO 25010.

Internal metric Analyzability Modifiability Reusability Testability

Cyclomatic complexity (CC)

M6 M2,M4 M3

M2,M4,M5,

Lines of code (LOC) M2,M4 M3,M7 M2,M4,M5

Average size of statements (SS) M6 M2,M6 M2,M5

Comments frecuency(CF) M6 M7

Weighted methods per class (WMC) M6 M8

Number of base classes (NBC) M6

Number of unconditionals jumps (NUJ) M6 M6

Number of nested level (NNL) M6 M6

Coupling between objects (CBO) M1 M1,M6 M7, M8 M1,M5

Lack of cohesion of methods (LCOM) M1 M1,M6 M7,M8 M1,M5

Depth of inheritance tree (DIT) M1 M1,M6 M7,M8 M1,M5,M6

Directly called components (DCC) M6

Number of children (NOC) M1 M1,M6 M1,M5,

Number of exits of conditional structs (ECS) M6

Response for a class (RFC) M5,M6

Number of methods (NOM) M1 M1 M7 M1,M5

Number of attributes (NOA) M7

Unit test coverage (UTC) M4,M5

Unit test errors (UTE) M4,M5

Cyclic dependencies (CDC) M6 M2

Efferent coupling (Ce) M2

Afferent coupling, (Ca) M2

Duplicated blocks (DB) M2,M4 M2,M4

ALIGNMENT OF OPEN SOURCE TOOLS WITH THE NEW ISO 25010 STANDARD - Focus on Maintainability

113

words which conduct the search in the repository

and obtain the measurement tools most valued by

users. According to the reading of the ISO 25010

standard, a set of keywords used for searching the

Web site www.sourceforge.net has been adopted.

Tools have been identified associated with the

languages. NET (VB.NET and C # adding), Java and

C / C + +, since these are the most popular

development frameworks according to the TIOBE

Programming Community Index, updated in January

2011. To complete the previous selection, we

include additional groups of tools. First, we consider

also those freeware tools for .NET static code

analysis boosted by Microsoft (FxCop and

StyleCop). Even so, it is clear that they are not

currently used separately and that they are already

included in the .Net IDE.

Coupling and cyclomatic complexity have been

widely acknowledged as the most valuable metrics

to assess maintainability of object-oriented systems

(Li, S. 1993). Thus, we were also interested in

reviewing open-source projects that support the

extraction of such metrics. Although some of the

previous tools are able of returning the values for

such metrics, they are not focused on analyzing

coupling and cyclomatic complexity. In particular,

we looked at JavaNCSS y JDepend as the most

representative. However, we could have included

any other similar tools instead of these ones.

Finally, we include other free tools analyzed in

other studies (Lincke, Lundberg & Löwe

2008)(Plösch et al. 2009). Table 3 lists all tools

selected and it specifies the basic metrics that can be

obtained on this basis. In this way, with these open

source tools, companies (especially SMEs) can

measure aspects of maintainability according to ISO

25010.

4.2 Assessments by Experts

Between the second half of 2009 and during 2010,

we have conducted initial assessments in the

development process in more than 20 software

companies. The aim of these reviews has been

providing companies with a snapshot of the current

status of their processes, practices and tools used in

the development process. At the end of the

evaluations we have informed the companies about

the missing features and activities needed to improve

its development process.

Quality managers and software developers, as

part of the company evaluation, have been

interviewed to collect information about code static

analysis and testing tools used on its projects.

Results show that there is no extensive use of this

kind of tools. The data collection has taken into

account the tool list presented in Table 3.

According to the obtained results, there are two

main types of tools that companies implement.

First, those associated to the analysis of the

source code and the search for potential problems

(PMD, FxCop). However, the style analysis tools

closely related to the ones mentioned above are not

used widespread. This is due to the big amount of

default rules of this type of tools. That forces

companies to invest a great amount of time and

resources tailoring their own rule set. Likewise, did

not have a standard code convention manual, what

made the successful implementation of this practice

very complex (even in an automated way).

The second type of more used tools has been

those associated to unit tests. However, unit test

practice was not completely widely used. Only some

specific tests were executed, according to some

client needs. Although coverage was taken into

account, neither a deep analysis was applied nor any

decisions were taken.

5 QUALITATIVE ALIGNMENT

OF THE TOOLS

This section aims at putting forward clarifications

and contributions from some of the tools mentioned

in the previous section. To this end it is concluded

that some of the tools and metrics could measure

additional subcharacteristics already discussed.

5.1 Java NCSS

JavaNCSS supports tree different measures gathered

over JAVA source code, namely the Non-

Commenting Source Statements (NCSS), the Lines

Of Code (LOC) and the Cyclomatic Complexity

(CC). We can look at these measures as primary

support for all subcharacteristics. So this is an

indispensable tool for measurement of

maintainability. NCSS provides a good indicator on

how easy it would be to understand or follow the

source code under evaluation. As well, NCSS is

related with testability since the number of non-

commented statements can be used as a clue towards

understanding if the code is easy to test. On the other

hand, the relationship of analyzability with CC is out

of doubt. In fact, the number of cycles has been

traditionally accepted as a measure to assess the

complexity of any software component. Therefore,

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

114

the lower the value of CC, the higher the

analyzability of the component (Heitlager, Kuipers

& Visser 2007).

5.2 PMD

We have analysed how the different rulesets that

drive the static analysis that PMD carries out are

aligned with ISO 25010 maintainability

subcharacteristics. This analysis is based on the

study of the content of each rule and our own

experience using the tool. Just 5 to 10 per cent of

the possible violations are directly related with

modifiability or testability, we have considered that

the tool does present partial alignment with the

corresponding subcharacteristic.

In particular, by studying the PMD

documentation, we can argue that 16 out of the 20

rulesets are directly related with evaluating the

clarity of the code under review. Thus, we can state

that PMD is clearly aligned with analyzability.

Finally, one the rulesset is directly related with

the testability subcharacteristic. In particular the one

that deals with the different problems that can occur

with JUnit tests

5.3 Junit, CPPUnit, NUnit and EMMA

Here we group together the tools focused on testing.

In particular, Junit, CPPUnit and NUnit perform unit

tests while EMMA focuses in code coverage.

Obviously, being focused on testing, all these

tools are fully aligned with the testability

subcharacteristic. Furthermore, since unit tests have

been traditionally acknowledged as an efficient way

of documenting source code and assessing its level

of stability (Heitlager, Kuipers & Visser 2007), we

can state that these tools are partially aligned with

analyzability and modifiability.

6 CONCLUSIONS

After analyzing the results it has been concluded that

current open source tools serve as a good starting

point towards achieving the indicators needed to

support different measurement model that

implement the product quality model according to

the new ISO 25010 standard. In fact these tools,

especially their implementations as IDE plugins can

improve maintenance task.

Not all tools obtain the same results (Lincke,

Lundberg & Löwe 2008) and are equally reliable in

terms of false positives and false negatives when

looking for violations in the source code (Plösch et

al. 2009), making indispensable the task of tool

selection and analysis. It stands for CodePro

AnalytiX tool, which assesses source code written in

Java, as one of the most complete in terms of

number of basic metrics obtained. Still, it is

advisable to check before accuracy of these tools in

real cases, especially those that perform more

complex calculations.

Maintainability is important both from the point

of view of the software product and maintenance

tasks during the development phase. Even though,

tools that assist diagnosis are not used. However,

companies carry out maintenance tasks based on

developers’ experience (whenever there is time).

As we have tried to demonstrate in this work,

open source tools have the capacity to implement

maintainability measurement models. Therefore,

these tools will help to the software product

maintenance.

ACKNOWLEDGEMENTS

This work has been partially funded by the Centre

for Technological-Industrial Development (CDTI)

(IDI-20090175), dependent on the Spanish Ministry

of Science and Innovation and the MODEL-CAOS

project (TIN2008-03582/TIN) financed by the

Spanish Ministry of Education and Science

(TIN2005-00010/).

REFERENCES

Alshayeb, M. 2009, "Empirical investigation of

refactoring effect on software quality", Information

and Software Technology, vol. 51, no. 9, pp. 1319-

1326.

Barnard, J. 1998, "A new reusability metric for object-

oriented software", Software Quality Journal, vol. 7,

no. 1, pp. 35-50.

Dyba, T. 2005, "An empirical investigation of the key

factors for success in software process improvement",

Software Engineering, IEEE Transactions on, vol. 31,

no. 5, pp. 410-424.

Ebert, C. 2009, "Guest Editor's Introduction: How Open

Source Tools Can Benefit Industry", IEEE Software,

vol. 26, pp. 50-51.

Feitelson, D. G., Heller, G. Z. & Schach, S. R. 2006, "An

empirically-based criterion for determining the success

of an open-source project", Software Engineering

Conference, 2006. Australian,IEEE, pp. 6.

Heitlager, I., Kuipers, T. & Visser, J. 2007, "A Practical

ALIGNMENT OF OPEN SOURCE TOOLS WITH THE NEW ISO 25010 STANDARD - Focus on Maintainability

115

Model for Measuring Maintainability", Quality of

Information and Communications Technology, 2007.

QUATIC 2007.IEEE, Lisbon, pp. 30-39.

Irrazábal E, Vara JM, Garzás J, Marcos E. 2010,.

"Alignment of Open Source Tools with ISO norms for

software product quality", Software Measurement

European Forum (SMEF), Rom - Italy, pp. NA.

ISO 2001, ISO/IEC Standard 9126 Software Product

Evaluation–Quality Characteristics and Guidelines

for their Use. International Organization for

Standarization.

ISO/IEC JTC 1 2011, ISO/IEC FDIS 25010 Software and

system engineering – Software product Quality

Requirements and Evaluation (SQuaRE) – Quality

model and guide. International Organization for

Standarization.

Lincke, R., Lundberg, J. & Löwe, W. 2008, "Comparing

software metrics tools", Proceedings of the 2008

international symposium on Software testing and

analysis, ACM, pp. 131.

Luijten, B., Visser, J. & Zaidman, A. 2010, "Faster defect

resolution with higher technical quality of software",

Proc. of the 4th International Workshop on Software

Quality and Maintainability (SQM’10), pp. NA.

Mouchawrab, S., Briand, L.C. & Labiche, Y. 2005, "A

measurement framework for object-oriented software

testability", Information and Software Technology,

vol. 47, no. 15, pp. 979-997.

Pagano, J. 2006. "Benefits and challenges of developing a

public sector metrics program using commercial

tools". In Proceedings of the 1st international

workshop on Contextualized attention metadata:

collecting, managing and exploiting of rich usage

information (CAMA '06). ACM, New York, NY, USA,

5-8.

Plösch, R., Mayr, A., Pomberger, G. & Saft, M. 2009, "An

Approach for a Method and a Tool Supporting the

Evaluation of the Quality of Static Code Analysis

Tools", Proceedings of SQMB 2009 Workshop, held in

conjunction with SE 2009 conference, March 3

, pp.

NA.

Pressman, R. 2002, Ingeniería del Software: un enfoque

práctico, McGraw-Hill, Madrid.

Riaz, M., Mendes, E. and Tempero, E. 2009, "A

Systematic Review of Software Maintainability

Prediction and Metrics", 3rd International Symposium

on Empirical Software Engineering and Measurement

(ESEM 2009), pp. 367 - 377.

Saiedian, H. and Carr, N. 1997. "Characterizing a software

process maturity model for small organizations".

SIGICE Bull. Vol. 23, no. 1, pp. 2-11.

Samoladas, I., Gousios, G., Spinellis, D. & Stamelos, I.

2008, "The SQO-OSS quality model: Measurement

based open source software evaluation", Open Source

Development, Communities and Quality, Vol. 275, pp.

237-248.

Staples, M., Niazi, M., Jeffery, R., Abrahams, A., Byatt, P.

& Murphy, R. 2007, "An exploratory study of why

organizations do not adopt CMMI", Journal of

Systems and Software, vol. 80, no. 6, pp. 883-895.

Wangenheim, C. G. v. 2009, "Enhancing Open Source

Software in Alignment with CMMI-DEV". IEEE

Softw. Vol. 26, no 2, pp. 59-67.

Washizaki, H., Yamamoto, H. & Fukazawa, Y. 2003, "A

metrics suite for measuring reusability of software

components", Software Metrics Symposium, 2003.

Proceedings. Ninth International, ed. IEEE Computer

Society, IEEE, Sydney, Australia, pp. 211.

ICSOFT 2011 - 6th International Conference on Software and Data Technologies

116
