EVENT PROCESSING IN THE CLOUD ENVIRONMENT

WITH WELL DEFINED SEMANTICS

Marc Schaaf, Arne Koschel

University of Applied Sciences and Arts, Ricklinger Stadtweg 120, 30459 Hannover, Germany

Stella Gatziu Grivas

University of Applied Sciences Northwestern Switzerland, Riggenbachstr. 16, 4600 Olten, Switzerland

Keywords:

Active DBMS, Activity service, Event condition action (ECA) rules, Cloud computing, Enterprise architecture

frameworks, Event driven architectures, Complex event processing.

Abstract:

The paper presents the OM4SPACE project, which aims to provide an integration of active functionality into

cloud environments to enable applications to further beneﬁt from the agility of this new environment. In

particular, we propose an activity service that incorporates well deﬁned interfaces and the clear semantic of

Active Database Management System (Active DBMS) style event processing combined with the concepts of

modern Event Driven Architectures and the approach of Complex Event Processing. This gives the potential

to provide active functionality across the boundaries of one Cloud and to decouple the usage of active func-

tionality from the concrete cloud provider. In this paper we present our initial prototypic implementation of

this activity service.

1 INTRODUCTION

Cloud computing (Armbrust et al., 2009) is a ’trendy

new kid on the block’ as many recent activities in

research and industry show. Companies and open

source players almost constantly announce new fea-

tures for their cloud platforms.

Event-based active mechanisms are an important

feature for the cloud, be it just in form of messag-

ing or in more elaborated event- or rule-driven behav-

ior (Rozsnayi et al., 2007). Although the necessity of

supporting active behavior is clear, the open issue is

the lack of a well-deﬁned semantic.

The overcome of this drawback is the contribution

of our work. For our OM4SPACE (Open Mediation

4 SOA and P2P Based Active Cloud Components)

project, we proposed an activity service for cloud

computing (Schaaf et al., 2010). The activity service

adopts its semantics from the well-proven and clear

semantics of Active Database Management System

(Active DBMS) style (Widom and Ceri, 1996; Paton,

1999) event-condition-action (ECA) rules. This se-

mantic is modiﬁed and extended for the cloud. The

design of the activity service is based on proven prin-

ciples, patterns, and technologies from service orien-

ted architectures (SOA). Eventually, we will deliver

an activity service with a precisely deﬁned Active

DBMS style ECA rule and execution model for the

cloud.

Event-Driven mechanisms have been extensively

investigated in the 1990s starting with the approach of

active databases supporting ECA-rules. One step be-

yond go approaches concerning ECA rule processing

in distributed environments. In (Koschel and Locke-

mann, 1998), active functionality was extended into

an ECA rule service for CORBA-based distributed

environments. Actually, this approach is one initial

step in our direction. Recently Event Driven Archi-

tecture (EDA) have been proposed as an architecture

style for the creation of distributed systems with the

aim to create agile applications. Event Driven Archi-

tectures are tightly linked to Complex Event Process-

ing (CEP), which is an emerging enabling technology

to apply context-aware knowledge from and against

large amounts of event data in near real-time (Luck-

ham, 2001).

With the activity service we will extend the set of

available cloud services, which can be used by the de-

velopers to rapidly create or adapt their applications

for the cloud. Moreover, it will bridge the gaps be-

176

Schaaf M., Koschel A. and Gatziu Grivas S..

EVENT PROCESSING IN THE CLOUD ENVIRONMENT WITH WELL DEFINED SEMANTICS.

DOI: 10.5220/0003393001760179

In Proceedings of the 1st International Conference on Cloud Computing and Services Science (CLOSER-2011), pages 176-179

ISBN: 978-989-8425-52-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

tween several cloud speciﬁc messaging or notiﬁcation

mechanisms by providing an abstraction across the

vendor speciﬁc API’s. This will enable developers of

event-driven cloud applications to utilize a powerful

middleware for active functionality without the risk

of a vendor lock-in. Application areas include, for ex-

ample, cloud vendor independent complex event pro-

cessing scenarios or the processing of events, which

occur in logistics or ﬁnance applications.

To achieve our goals we need to deal with several

challenges including: Well-deﬁned semantics for the

activity service, architectural issues, highly dynamic

runtime environments, highly heterogeneous system

environments, vendor speciﬁc event or message com-

munication mechanisms etc.

While (Schaaf et al., 2010) sketched the idea and

key high-level architectural concepts of the activity

service, this paper summarizes them only brieﬂy. Its

core contribution is our meanwhile developed initial

prototypic implementation of the activity service.

The remainder of this paper starts with an

overview description of the activity service with its

components. Afterwards we describe our prototypic

implementation followed by an outline of the next

steps for the implementation. Eventually we conclude

with a summary and an outlook on the next steps for

the whole project.

2 AN ACTIVITY SERVICE FOR

THE CLOUD

The aim of our work is to bring active functionality

into the cloud in the form of a simple and easy to use

service, which features a clear semantic. Instead of

deﬁning the semantic for the service from scratch, we

base our approach on the proven and well-deﬁned se-

mantics of active database systems and aim to adapt

them to the new, highly dynamic and massively dis-

tributed environment. The architectural and seman-

tical base of our work uses the unbundling approach

for active functionality from Active DBMS concepts

(Gatziu et al., 1998) for distributed and heterogeneous

environments. Based on these results and in order to

achieve a high ﬂexibility, we base our activity service

on two components: the event service and the rule ex-

ecution service (Figure 1).

The communication between the components is

realized based on the concept of a SOA thus utiliz-

ing services with well-speciﬁed interfaces with clear

semantics. Thereby the concrete implementation of

the different components is interchangeable.

We consider the interaction of applications located

in one cloud with applications located in other clouds

Infrastructure

Platform

Application

Cloud

Mediator

E M

Event Service

CED

Event History

Rule Execution Service

Rule

Management

Event Sources / Event Consumers

publish event

consume

event

consume

event

execute

action

Rule Base

Service

Registry

= Event Monitor

manage

rules

Figure 1: The components of the activity service and their

interactions.

as a common use case. Thus the event producers and

consumers of the activity service are not limited to the

components in the cloud where the activity service is

located.

2.1 Activity Service: Components

Figure 1 illustrates the different components of the ac-

tivity service and their interactions. Their functional-

ity is explained in more detail in (Schaaf et al., 2010)

and thus only summarized in this section.

The event service component provides the means

to be informed about the occurrence of events from

different event sources, to pre-process those events

and to deliver them to appropriate event consumers.

Therefore it provides a service, which can be used

by event producers to send their events to the event

service via a sendEvent method. For each incoming

event, the event service determines if there are event

consumers that are interested in this particular event

and delivers the event to them.

In addition the incoming events are stored into

an event history to support the monitoring of com-

plex/composite events. A complex event detector

(CED) evaluates the events and derives new complex

events, which are fed back into the processing mecha-

nism. Consequently they are handled again as if they

were incoming events.

To receive events from the event service, an event

consumer has to implement an appropriate event han-

dler service, which needs to be published to the ser-

vice registry. The event service discovers those ser-

vices through the service registry. To extend the

mechanism of the event service, we utilize the con-

cept of an event monitor which capsules data sources

that are not able to actively notify the event service

(Schaaf et al., 2010).

The rule execution service receives events from

the event service to evaluate them against sophisti-

cated ECA rules. Therefore it acts as an event con-

sumer of the event service by registering an event han-

dler service. The rules result in the execution of action

handlers. Such an action handler needs to be imple-

EVENT PROCESSING IN THE CLOUD ENVIRONMENT WITH WELL DEFINED SEMANTICS

177

Legacy

App.

EventMonitor

(concrete)

Capsule

API

Converter

sendEvent

WSC

Event Service

Converter EventHandler

EventDispatcher

Esper Handler

Esper

WSC

Rule Execution

Service

Converter EventHandler

Esper Handler

Esper

Event

Consumer

WSC

Action

Handler

WSC

sendEvent

(De)Registration

consume

Event

ExecuteAction

UDDI

Registry

Registration

Figure 2: The Technical Architecture of the Activity Service

mented by each of the components that are intended

to be called from within rules.

2.2 Putting the Activity Service into

Context

Most of the cloud architectures that were reviewed fo-

cus on just technical stacks that lack interoperability

with other providers. In the area of event process-

ing mechanisms, many existing offerings include the

means for message passing like for example Amazon

with their Simple Queuing Service. However these

offerings also lack common interoperable and well-

deﬁned interfaces that prevent a vendor lock-in and

enable applications to use active mechanisms across

the boundaries of a single provider. With our activity

service we ﬁll this gap by providing a well-deﬁned

service with a clear semantic, which is independent

of the concrete cloud provider. Furthermore we will

extend the activity service across the boundaries of

one cloud so that it not only provides a general inter-

face but also provides the means to communicate with

application parts located in different clouds. The long

term objective of our project is to extend the platform

for cloud based applications so that it provides the

means to create applications that can beneﬁt from the

dynamics of cloud environments by utilizing active

mechanisms in a provider independent way.

2.3 Prototypic Implementation

Based on our conceptual work a prototypical imple-

mentation of the activity service was developed. Its

technical system architecture is illustrated in Figure 2

and described in the following subsections.

2.3.1 Technical Architecture

Technically the activity service uses Web Services

to receive events from event producers. After the

event processing, it delivers the events to Web Ser-

vices, which are provided by the event consumers.

The event processing in the event service itself is cur-

rently based on the complex event processing engine

Esper (esper.codehaus.org). However, all details re-

garding the integration of Esper are hidden from the

event producers and consumers. Thus the processing

engine could be replaced with another rule processing

engine such as CLIPS or Drools .

As a starting point we work with an event type

which basically consists of the event type name, the

event source name and a set of timestamps to record

the event occurrence, detection and processing times.

The mentioned ﬁelds provide the header information

of the event, the body of the event contains a ﬂexi-

ble set of key value pairs, which are speciﬁc for each

event type and can be used as needed.

The discovery of event consumers is realized as a

facade in front of an UDDI repository, which informs

the event service of new event consumers by sending

an event whenever a service appears or disappears.

The reason for the introduction of a facade in front of

the repository is the lack of a notiﬁcation mechanism

in UDDI to inform a subscriber about newly added

services

For the notiﬁcation of the event service, the UDDI

facade uses the active mechanisms that are provided

by the event service in the ﬁrst place. Thus the fa-

cade acts as an event producer and informs the event

service of registered or deregistered event hander ser-

vices by raising an event. The event contains the

WSDL of the event handler service. Furthermore it

contains a ﬁlter string to specify events, which the

handler is interested in. The event service receives

the event and thus gets all the required information to

contact the event handler if a matching event has to

be delivered. Due to this mechanism, the event ser-

vice does not require any knowledge about the UDDI

registry.

As the implementation provides all required com-

ponents and functionalities, a complete roundtrip

from the event producer through the (complex) event

processing to the event consumers including the auto-

matic discovery of event handlers is possible.

CLOSER 2011 - International Conference on Cloud Computing and Services Science

178

One of the next steps for the implementation is to

move from the specialized Web Service interfaces to a

dedicated communications layer that is outlined in the

next section. Moreover we are working on the real-

ization of the rule execution service to support the de-

coupled processing of more elaborated and time con-

suming rules that result in the execution of an external

action instead of the generation of new events.

2.3.2 Communication Infrastructure

Abstraction

Our previous descriptions, as well as our current

implementation, are tightly linked to Web services.

However our general concept is not limited to one

communication mechanism. Instead we will extend

our implementation with a layer of abstraction from

the actual communication mechanism to allow the ac-

tivity service to interact with cloud provider speciﬁc

solutions like the messaging facilities provided as part

of Amazon’s cloud offerings.

Moreover the activity service will provide the pos-

sibility to use multiple communication mechanisms in

parallel. This provides the capability to mediate be-

tween different mechanisms in order to combine event

based applications, which use otherwise incompatible

(provider speciﬁc) communication mechanisms.

For this purpose we are currently working on an

abstraction layer, which hides the different provider

speciﬁc methods from the activity service and the

event produces and consumers. This layer will then be

implemented for each speciﬁc communication mech-

anism like Amazons Simple Queuing Service, a JMS

client or a WS-Eventing based system and can thus

provide an optimal mapping of the event structure to

the transport mechanism.

Discovery. With regard to the integration of an ab-

straction layer from the transport mechanisms, a sim-

ilar technology independent approach is required for

the discovery.

Our approach for the discovery of new event han-

dlers is based on events and thus decoupled from the

actual discovery component. For the current imple-

mentation the technology speciﬁc parts of the dis-

covery are handled by the mentioned UDDI facade.

This facade creates events with a technology indepen-

dent description of the requested event types, which

is needed by the event service itself and a technology

speciﬁc description of the endpoint. This mechanism

allows the event service to discover event handlers

that use any of the communication mechanisms that

are supported by the abstraction layer.

3 CONCLUSIONS

With the OM4SPACE project we extend the cloud

platform with active functionality so that cloud based

applications can easily integrate active mechanisms

and therefore react to events just in time. With this

we will assist cloud applications to become even more

dynamic and to reach their full potential. Further-

more we provide this active behavior with the clear

and well-proven semantic of Active DBMS and well-

deﬁned interfaces across the border of a single cloud

and without the limitations given by vendor speciﬁc

messaging mechanisms.

After the deﬁnition of the architecture and a pro-

totypic realization of the activity service, we now fo-

cus on the extension of the concept across the border

of a single cloud and the adaption to the new highly

dynamic environment. Furthermore we focus on the

evaluation of our concept in the scope of real live ap-

plication scenarios.

REFERENCES

Armbrust, M. et al. (2009). Above the Clouds: A Berkeley

View of Cloud Computing. Technical report, EECS

Department, University of California, Berkeley.

Gatziu, S., Koschel, A., et al. (1998). Unbundling active

functionality. ACM SIGMOD Rec., 27(1):35–40.

Koschel, A. and Lockemann, P. C. (1998). Distributed

events in active database systems: letting the genie out

of the bottle. Data Knowl. Eng., 25(1-2):11–28.

Luckham, D. C. (2001). The Power of Events: An Intro-

duction to Complex Event Processing in Distributed

Enterprise Systems. Addison-Wesley Longman Pub-

lishing Co., Inc., Boston, MA, USA.

Paton, N. W., editor (1999). Active Rules for Databases.

Springer, New York.

Rozsnayi, S. et al. (2007). Event Cloud - Searching for

Correlated Business Events. 9th IEEE International

Conference on E-Commerce Technology.

Schaaf, M., Koschel, A., Grivas, S. G., and Astrova, I.

(2010). An active dbms style activity service for cloud

environments. Lisbon, Portugal. XPS (Xpert Publish-

ing Services).

Widom, J. and Ceri, S., editors (1996). Active Database

Systems: Triggers and Rules for Advanced Database

Processing. Morgan Kaufmann Publishers, San Fran-

cisco, CA, U.S.A.

EVENT PROCESSING IN THE CLOUD ENVIRONMENT WITH WELL DEFINED SEMANTICS

179
