A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT

AWARE APPLICATIONS

Cristina Barbero, Paola Dal Zovo and Barbara Gobbi

Concept Reply (a Business Unit of Santer Reply SPA), via Cardinal Massaia 83, 10147 Torino, Italy

Keywords: Context Aware Computing, Pervasive Computing, Service Oriented Architecture and Middleware, Semantic

Technologies, Automated Reasoning, Internet of Things.

Abstract: The ever-growing complexity of pervasive and Internet of Things enabled environments raises great

challenges to context-aware pervasive application development. In particular, context representation and

reasoning methods, as well as middleware and supporting infrastructures for context sensitive application

engineering, must have a high level of flexibility in order to cope with the increasing dynamicity and

heterogeneity of pervasive scenarios. This paper presents a solution devised to provide the foundations for

the development of context-adaptive applications with diverse requirements. The Context Awareness

component consists of an extensible and configurable framework that integrates a semantic reasoning

module and multiple processing agents providing specialized / optimized processing capabilities. Finally, a

case study shows how the adopted solution allows tackling the complexity of context-aware applications

development.

1 INTRODUCTION

The increasing complexity of pervasive computing

environments, and the Internet of Things (IoT)

vision of a world of everything connected, open

great market opportunities and raise many

challenges. Context-aware pervasive applications,

while potentially offering huge added values, still

suffer from limitations hindering their full

development and spreading.

The development of context-aware applications

for the IoT is complex as it requires considering

aspects related to distributed computing, discovery

of services, network connectivity, limited processing

resources of target devices, mobility. Moreover, the

domain of the IoT is so wide and the requirements of

context-aware applications may be so diverse that a

single automated reasoning methodology cannot

provide a satisfactory answer to all needs.

Context-adaptive application engineering must

be based on an efficient infrastructure and

middleware, in order to reduce engineering effort

and complexity and enhance the soundness of the

produced solutions. Some challenges are related to

the adequacy of context representation and

reasoning methods to cope with increasing complex,

dynamic and heterogeneous pervasive environments

and settings. An extensive review of such issues is

(Soylu, 2009).

This paper presents a Context-Awareness (CA)

solution based on a modular and flexible platform

supporting the creation and management of

pervasive, IoT-enabling applications. The CA

component is given by an extensible framework that

integrates a semantic representation and reasoning

module and multiple processing agents providing

additional, specialized and/or optimized processing

capabilities (e.g. raw data filtering and aggregation,

probabilistic and statistic data management, light

event processing for resource-constrained devices).

Case studies have shown the effectiveness of our CA

solution, which derives from both the strong

platform base and the flexibility of the reasoning

framework.

The paper is organized as follows. Section 2

presents the motivations of our approach and related

works. Section 3 gives an overview of the platform,

while section 4 describes in details the CA

framework. Section 5 presents a case study. Section

6 presents the conclusions and future work.

Barbero C., Dal Zovo P. and Gobbi B. (2011).

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS.

In Proceedings of the 1st International Conference on Pervasive and Embedded Computing and Communication Systems, pages 32-41

DOI: 10.5220/0003363300320041

 SciTePress

2 MOTIVATIONS AND RELATED

WORKS

In the past few years a lot of work has been done in

areas that are key enablers for context-aware

computing, such as pervasive computing, service-

oriented architectures, automated reasoning, and

semantic modeling languages.

In the current state-of-the-art of context-aware

middleware different approaches have been

proposed to sense context and to adapt to changes,

often with a different focus. An overview is

provided by the survey (Kjær, 2007), which

classifies a set of existing context-aware middleware

according to a taxonomy including relevant aspects

such as adaption mechanisms, and concludes that no

single middleware system is appropriate for all

settings.

With respect to the semantic representation of

data we believe that an interesting initiative is the

W3C Semantic Web (W3C Semantic Web, 2001).

The semantic web is intended to allow semantic data

exchange and interoperability at the semantic level,

by relying on a stack of standard languages such as

XML, RDF, and OWL. In particular, OWL adds

more vocabulary for describing properties, classes,

and relations between classes. In addition, SPARQL

is a protocol and query language for semantic web

data sources, while SWRL is the proposed rules

language.

Semantic Web standards are being applied in an

increasingly large spectrum of applications in which

domain knowledge is conceptualized and formalized

usually by means of ontology in order to support

diversified and automated reasoning (Leger, 2008).

Some works choose to adopt the Semantic Web

concept in the Internet of Things field, for context-

aware applications over wireless sensor networks

(Huang, 2008), (Roman, 2002), (Kostelník, 2008),

and the survey in (Strang, 2004) indicates that

ontologies are a valid solution for context modeling.

So far, no standardized sensor ontology still

exists, although there is an initiative to define a

shared vocabulary for sensor networks based on

W3C semantic web languages. Adopting semantic

web languages, considering common concepts in

proposed ontology, means to be in the right direction

towards semantic interoperability. This choice

presents nonetheless some challenges. In fact, some

works highlight some issues in the adoption of

semantic technologies (Wolf, 2009), especially

attempting to exploit them in dynamic environments

and when dealing with data from hardware devices,

often mobiles.

The survey (Perttunen, 2009) shows that OWL is

conveniently used in many recent works to represent

context, while reasoning is seldom based only on

pure OWL inference. Usually, rules are used to

incorporate human knowledge to guide the system.

The survey indicates that some works make use of

other reasoning methods, such as cased based

reasoning, probabilistic reasoning, or hybrid

approaches.

The motivations behind the need of a

probabilistic approach are also well illustrated in

(Garofalakis, 2006). Sensor data is typically a noisy

and uncertain observation of the phenomenon it is

intended to capture, hard to “trust”, and often

conveyed in form of an unreliable stream. Spatial

and temporal correlation between data should be

exploited for better understanding the underlying

physical phenomena, other than for efficiency

reasons.

Another perspective worth notice is the one

brought by the survey (Kapitsaki, 2009), which

focuses on evaluation of the techniques that enable

the exploitation of contextual information (“context

handling” techniques), assessed from the viewpoint

of service developer. The authors don't focus much

on middleware, ontology-based or rules-based

solutions, as they prefer concentrating more on

approaches based on programming, message

interception, and model-driven approaches. We refer

to this analysis of state-of-the-art as in designing our

CA solution we considered criteria such as those that

they mentioned. Those criteria include:

 The flexibility that the context adaptation

mechanism provides to the developer. A

related criterion is about the possibility of

applying the speciﬁc context adaptation

mechanism to an existing system.

 The easiness of use for a developer, not very

familiar with the speciﬁc context adaptation

mechanism.

 The easiness of refactoring a service (if there

are modiﬁcations in either the business logic

or the context handling logic)

 Decoupling from business logic: the degree of

independence between context information

and service logic.

Another recent article addressing context-aware

web service is (Truong, 2009), which analyzes CA

techniques and related works in web service

systems. In the context reasoning techniques section,

it highlights that some systems rely only on XML-

based context information and have scarce reasoning

capabilities, and only few systems are based on

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS

semantic reasoning due to difficulties to integrate

ontology into context-aware systems.

We choose to adopt semantic technologies for

the benefits in term of expressiveness of the

representation and for being in line with current

standardization directions. We also recognize the

need of being open to a probabilistic approach in

some scenarios, and to other automated knowledge

processing techniques that might be needed in some

scenarios.

To summarize, the main goal we pursue in our

work is to provide our middleware with instruments

to facilitate the development of context-aware

services, in particular building an infrastructure to:

 Allow rapid development of a certain class of

rules-based context-aware services, based on

semantic models of devices and services.

 Reduce the development effort needed to

realize context-aware services able to answer

a variety of functional and non-functional

requirements, including the need to deal with

uncertain data and the need of processing on

resource-constrained devices.

3 ARCHITECTURAL OVERVIEW

Our CA solution is part of a platform supporting the

creation and deployment of pervasive, IoT-enabling

applications based on networks of connected

devices. The platform, designed to be modular,

flexible and scalable, is characterized by:

 A Service Oriented Architecture where each

network element can expose its functionalities

by means of a loosely-coupling Web Services

interface. This enhances the modularity of the

system and its interoperability (through the

adopted standards).

 Support for a diverse and changing set of

devices, communication protocols and

technologies (both wired and wireless, long

and short range), service exposure and

discovery (self-configuration) modalities.

 A flexible context reasoning framework that

can be tailored on the basis of the kind of

hosting nodes and of needed applications (e.g.

a resource-constrained device could only host

a lightweight processing agent, a complex

application could require a semantic reasoner

and an event-processing specialized agent).

Figure 1 shows different kinds of nodes (specified

below) managed by the platform. Even the simplest

devices can be part of the infrastructure, through the

support of virtualization nodes.

 Simple Nodes have short range connectivity

(e.g. Wifi, ZigBee, Bluetooth) and reduced

computational capabilities. They don’t support

TCP/IP and Web Services, so they are

connected to the network and expose their

services by means of the Virtualization Nodes.

 Intelligent Nodes have short range and

optionally long range (e.g. GSM, GPRS,

UMTS, Ethernet) connectivity, TCP/IP and

Web Services support, self-configuration

capabilities.

 Virtualization Nodes are similar to Intelligent

Nodes for capabilities and provide

virtualization services to sub-networks of

Simple Nodes (in particular TCP/IP and Web

Services support and self-configuration

capabilities).

 Aggregation Nodes have high processing

power and expose in a homogeneous way the

Web Services offered by the different nodes

and sub-networks to the back-end systems.

Figure 2 shows the layers and the main components

provided by the platform, in particular:

 Network Management component, dealing

with network configuration, performance,

fault and diagnostics.

 Web Services component, managing the

exposure of the services (described with

homogeneous XML logical models) through

different modalities, e.g. dual bindings in

HttpDual protocol, single bindings in Rest

protocol, DPWS

Figure 1: Network nodes managed by the platform.

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

(Devices Profile for Web Services, 2009)

recommended bindings. It also manages

different service discovery modalities, e.g.

based on UDDI or WS-Discovery protocol.

Moreover, it manages the interaction with the

other platform components, and notifies the

registered clients about the updates on data

related to the exposed services.

 Context Awareness component, in charge of

processing contextual information and using

the recognized context to adapt application

behaviour. It will be described in details in the

next section.

 Security / Localization / UI Management

components, providing support for,

respectively, security and trust, location-based

services, UI of applications.

4 CONTEXT AWARENESS

FRAMEWORK

In this section we describe the CA module, in charge

of processing contextual information, recognizing

current context and making decisions about which

actions are needed. This module is designed to be

modular and flexible, and to allow easy extensions

by addition of needed processing agents in the form

of plug-ins. Figure 3 shows the CA framework.

A reasoner host is in charge of retrieving and

loading reasoning components for the system, and,

once loaded, to allow them to exchange information

with other reasoning services and with other nodes

in the system. Communication is based on a

publish/subscribe model.

The CA module is notified, from other

components in the system, of relevant changes it

may need for reasoning about, namely of:

 New entities, as they connect to the network.

Entities may be e.g. devices, software

components in our platform or external web

services, system nodes, people who get known

to the system.

 Disappeared entities, e.g. disconnected

devices.

 Occurred changes in entities, e.g. new sensor

reading, changed location, changed actuators

state, etc.

Our middleware relies on XML logical models to

represent system entities and to exchange and share

information about them between the platform

modules. Thus, the CA module receives information

about entities and handles context adaptation in a

uniform and abstract way, leaving to other

Figure 2: Platform layered view, main components.

middleware modules tasks related to low-level

communication and handling of devices.

For describing the structure and constraining the

contents of XML logical models we used the XML

Schema Definition (XSD) (XSD, 2004). The XML

Schema allows validating XML models as they are

being updated, ensuring that data remain conform to

the defined schema. The XML Schema describes

models and their elements, attributes, data types,

specializing type definitions by extending higher

level types in an entity hierarchy. Among the

Figure 3: Context awareness framework.

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS

Figure 4: A snapshot of the ontology.

defined models there are entities classified as:

 Physical entities such as various sensors,

actuators, people;

 Virtual entities, such as external web services,

e.g. a weather forecast web service;

 Reasoning entities, including reasoner and CA

services.

The latter are used to convey information related to

reasoning and context-aware services from the CA

module to other modules. In fact, a reasoner module

presents itself to the system through its logical

models, which can be used for monitoring and

configuration purposes. The context awareness

module also instantiates another type of Reasoning

entities, to represent the context awareness services

it provides and to disseminate information about

their state and about recognized context. When a

context-aware service requests actuations for

adapting to the context, it requests an update of a

logical model, and the middleware validates the

request, and dispatch it to the appropriate module

(e.g. to the network layer to traduce the request in an

action on a device). The entity hierarchy adopted in

the XML schema is aligned to the class hierarchy in

the ontology model.

4.1 Semantic Reasoning

The Semantic Reasoner module implements a

semantic reasoning approach, takes care of

maintaining a semantic representation of the system

knowledge base (OWL-DL ontology), and perform

rules-based reasoning for context recognition and

adaptation. The semantic reasoner integrates Jena

Semantic Web (Jena, 2009), using it in Microsoft

.NET environment through IKVM.NET

(IKVM.NET, 2010). Jena’s APIs are exploited to

create and manage the ontology model, to execute

queries on it and to make inferences.

The XML schema and the ontology-based model

are very similar, XML types are mapped on OWL

classes, XML models are mapped on OWL classes,

and the subclass hierarchy in the OWL ontology

model is aligned to the complex types specialization

defined in XML schema.

The two representations are maintained aligned to

allow a seamless and automated update of the

ontology based on the information, provided by other

modules, about the current context. A snapshot of the

ontology is shown in Figure 4, as displayed in

Protégé (Protégé, 2010).

Context change events communicated to the

semantic reasoner are queued for processing. When

these events are handled, the knowledge base is

updated accordingly. Sensed context change may

require simply changing a property (e.g. currently

sensed value), or can require creating/deleting

individuals in the ontology. Prior to reasoning,

management of context-aware services may be

needed (in case new context-aware services are to be

instantiated, or existing services are no longer

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

needed). Some basic context information

aggregations are typically performed too. For

instance, an average value is computed from values

measured from sensors of the same type in a certain

area. To these purposes, SPARQL queries are used.

Queries can be extended when new services are

added and when a different aggregation is needed.

When the ontology has been fully updated, the

rules engine is invoked to run the set of concerned

rules (Jena SWRL-like rules). Rules are organized in

two sets, Context Rules and Action Rules, for each

service.

First, context recognition rules are run to

recognize the current context of the system, in

relation to existing services. Then, Action Rules are

executed for decision making based on recognized

context. Decided actions are written in the ontology

along with justification to simplify understanding of

why they were required.

Requests of decided actions affecting actuators

are then handled and propagated to the involved

device. In other cases decisions may simply concern

providing recommendations suitable to the context.

Rules may also trigger internal events such as

delayed rules execution (e.g. to check whether a

certain context situation persists for longer than a

certain time span). Rules are based on an expressive

ontological model, which includes some information

that is not present in the XML models and that is

used only by the semantic reasoner. This knowledge

concerns the relations between the system entities,

e.g. between the context-aware services and the

devices (properties set by the module itself),

information related to rules and queries files and to

other aspects pertaining the semantic reasoner only.

In order to be able to meet requirements of

pervasive computing environments, the reasoning

framework has been designed to manage dynamic

changes in the knowledge base. The semantic

reasoner module allows retrieving needed models,

queries and rules from an external repository. The

ontology model consists of a base ontology and of

ontology models for specific entity classes. The

semantic reasoner supports a dynamic management

of the ontology and instantiates at run time in the

ontology only device/service classes really present

in the system at that moment. The set of classes

present in the ontology is not pre-defined, since

OWL classes are added at run time, only if needed,

and removed when no longer useful. The ontology

can be extended dynamically in terms of both

individuals and classes, without need of recompiling

the software module.

A remarkable aspect is that the semantic reasoner

is able to deal with types of devices not known at

system deployment time or with new context-aware

services, provided that their models are given. When

a new device appears in the system, if its ontology

class is not yet present, the proper OWL model is

downloaded from the model repository and added to

the knowledge base, and finally the individual

representing the device is created.

4.2 Event Processing

The semantic reasoning approach, though offering

many benefits (in terms of expressiveness, use of

formal and standard languages, clear separation of

reasoning logic from application code), also has

some notable limitations, e.g.:

 Significant memory requirements and

performance times, usually not suitable to

resource-constrained devices. For example, no

framework with Jena equivalent reasoning

capabilities is available to run on resource

constrained devices. We are aware of

prototypes like µJena (µJena, 2010) and

Enhanced Micro Jena (Enhanced Micro Jena,

2010), but they seem not mature enough for

commercial solutions and they lack some

needed functionalities.

 Limited support for retraction in ontology-

based reasoning. OWL-DL is mainly designed

for monotonic inference, but context

recognition is typically based on dynamic

sensor measurements: as new measurements

replace previous ones, previous measurements

and derived information need to be retracted.

Jena rules engine was originally designed for

monotonic inference, non-monotonic

inference is supported, but with some

limitations (Jena-dev, 2008).

 No suitable support for uncertain and fuzzy

data management and for managing data

stream and temporal reasoning.

These considerations led us to design a flexible,

plug-in-based architecture able to integrate, besides

the pure ontology-based reasoner, other processing

methodologies. Through the plug-in architecture and

a late binding and reflection mechanism, multiple

Processing Agents can be integrated to the reasoning

framework (retrieving them either locally or from a

remote repository).

Processing Agents have some capabilities of the

semantic reasoner, namely the ability to

communicate with the other modules through XML

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS

logical models and related events (they also presents

themselves to the network through a logical model),

and to filter events of interest.

In case of stateful processing, the Agents are

able to keep in memory the data needed for their

processing, e.g. a collection of XML logical models

or derived structures. Moreover, Processing Agents

can also raise “local events”, providing their

processing results to other reasoning modules

running on the same node, without propagating this

information to other nodes.

Compared to the semantic reasoning approach,

the Processing Agents can provide additional

processing capabilities and perform efficiently a

variety of complex tasks, if needed by integrating

and exploiting specialized libraries or engines. We

summarize below some processing tasks that could

be performed by Processing Agents:

 A Processing Agent can be used as a light

reasoning module on nodes where the

semantic reasoner could not be hosted due to

resource constraints. In this case, it provides

standalone CA services, which could

potentially be used by semantic reasoners on

more powerful nodes for providing higher-

level services.

 Another task that could be performed by a

Processing Agent is the pre-processing

(filtering, aggregating, checking, enriching,

etc) on data which will then be used by the

semantic reasoner. The Agent can provide

simple data transformations, such as

measurement unit conversions (especially in

non-linear transformations), or can add

reconfigurable capabilities that are difficult or

impossible to implement in the semantic

reasoner. For instance, the semantic reasoner

doesn’t address sensor data uncertainty. In

fact, in many cases, data coming from sensor

networks are unreliable and affected by noise

and errors and need some processing as a

preliminary step to use them as context

information.

 Specialized tasks for a Processing Agent could

be given by the application of probabilistic

and statistic methods, e.g. for managing

uncertain and fuzzy data, making predictive

evaluations on the basis of historical values,

analysing user habits and preferences.

With the data centric communication style

adopted in our platform and with the simple defined

interfaces it is possible to build composite services,

sharing basic computations blocks and their results,

and exploiting the different capabilities of the agents

and of the semantic reasoner.

The more recurrent tasks that will be needed in

the system will be accommodated conveniently in

ready-made reasoning blocks, but it will be possible

to add other reasoning blocks when required, after

the deployment.

5 CONTEXT-AWARE

APPLICATION SCENARIOS

We briefly illustrate in this section how the

reasoning modules have been exploited for building

context-aware applications.

As a case study we developed a set of services

for smart buildings, for monitoring of large facilities

and public areas. As shown in Figure 5, we

developed some services for a conference room, in

particular for temperature management, for light

management, for managing projection screen and

lights in case of meeting, for fire prevention. We

also developed some services for an exposition area,

in particular to count the people present in the area

itself, and to estimate waiting time for people in

queue for accessing to the area.

Most of the services have been developed using

the semantic module. As long as there are no strict

response time constraints and computation needs are

limited, in fact, the semantic reasoner can allow

engineering context-aware applications easily,

without coding. Therefore these rules-based

applications can be developed by technical

personnel such as technical matter experts of the

domain without programming skills.

The queue waiting time service, on the contrary, was

developed by using a more convenient, specialized

processing agent.

Figure 5: Services developed on a smart building.

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

The following paragraphs describe the development

of the above applications and present related

evaluation remarks.

5.1 Context-aware Application

Development

The services realized for the conference room (as

well as the people counter service for the exposition

area) have been developed through the semantic

reasoner. Devices involved in these services are

lamps, brightness sensors, thermometers, air

conditioners, projectors, curtains, white screens, and

people counters devices. People presence and

regulations directly requested by user were

considered for regulating room conditions.

The middleware provided a convenient support,

and allowed the context-aware application developer

to focus on the application logic, without need of

caring of communications, localization, networking,

and so forth. Involved entities are handled easily

thanks to the abstracted logical models.

To add a CA service based on already connected

devices it is needed to (see Figure 6):

 Add an OWL model of the service.

 Provide the pair of rules sets for context

recognition and action selection.

 Extend queries related to aggregation of

sensor values, and to conditions for

considering the service ‘available’.

If the location area includes more than one

sensor of the same model, e.g. more than one

brightness sensor, the system aggregates through

SPARQL queries the measures coming from the

sensors, providing an aggregate value, e.g. an

average.

Figure 6: Adding a new CA service.

In case devices to be used by the CA service

being developed are not yet ‘known’ to the system it

is needed to add also their models (XML and OWL)

into the model repository, so that the middleware

will be able to handle them. At run time, entities are

dynamically instantiated when present, and also CA

services are instantiated when instantiation

conditions for the type of service are met. The

relationships between a service and devices and

entities it reasons about are described in the

ontology models. When a CA service of a new type

is instantiated, related rules and queries are loaded

and made available for processing.

The applications above described benefit from

the ontology-based models supporting the context

recognition, which required considering the state of

different devices and entities. Rules expressed

context conditions and adaptation and not many

computations were needed.

The CA service for deriving the average time

that people spend in a certain waiting area, and for

estimating waiting time for incoming people, was on

the contrary developed through the processing

agent’s framework. The sensed data is given

uniquely by a single entity, which provides tracks of

portable Bluetooth enabled devices held by visitors,

but some correlations, computations and statistics

are needed, especially for waiting time estimation.

Thus, we deemed more appropriate to develop it in

form of a processing agent. It required some

programming, but more complex aspects are already

provided by the middleware and by the reasoner

host. It meant specifying filtering condition and

coding the ad-hoc processing, and was quite

straightforward thanks to the provided processing

agent’s framework.

5.2 Evaluation and Remarks

As we could observe by the case study indicated in

section 0, the semantic reasoner demonstrated to be

able to support development of context-aware

application based on models and rules. It allows

dealing with complex domain models.

In particular the following points are worth

noticing:

 The extended syntax provided by ARQ, Jena’s

SPARQL processor, has been used in some

cases for querying the knowledge base instead

of the standard W3C SPARQL syntax, to

exploit some operators not included in

SPARQL 1.0 but supported in ARQ. For

instance, aggregation through ‘GROUP BY’

and negation were used, while they are still in

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS

Figure 7: Comparative test results.

Figure 8: Comparative 5 hrs test results.

working phase in SPARQL W3C working

group for the 1.1 version.

 The extendibility of Jena has been used to add

a few procedural primitives which can be used

in the rules. These built-ins were needed as the

set of Jena primitives is limited and some

required operators, e.g. for certain operations

with dates and time, were not provided in the

framework.

 We had no issue concerning the usage of Jena

in .NET environment through the IKVM

virtual machine, even in introducing

extensions. We used a library we assembled

from the Java version of Jena, not the recently

published Jena .NET library version (Jena

.NET Framework, 2010).

The applications developed on the semantic

reasoning module were used to show information on

a dynamic graphic user interface, tested both in a

simulated environment and in a smart ambient

equipped with real devices, and function properly.

Even if the semantic reasoner worked well with

the required CA services we noticed that other kinds

of data processing would be very complex to

develop in form of rules-based applications. For

example, the implementation of the queue waiting

time estimation service in a rule-based application is

not straightforward. Even with the support of Jena

framework, we would need to develop specialized

built-ins for statistical computation and to use a

persistence system for keeping track of visitors’

movements.

The processing agent infrastructure resulted

beneficial in dealing with complex data processing.

The pluggable processing modules can integrate

reasoning framework capabilities, if needed by also

including specialized libraries. Moreover, the

processing agents and the semantic reasoner can co-

exists and their processing can be staged in multiple

ways, and allow CA service composition based on

hybrid methods.

In the case study described in section 0, we

performed some comparative tests over the

following scenarios:

 Scenario 1: conference room management

services and people counting service in the

queue for the exposition area. A rule-based

approach is adopted (semantic reasoner only).

 Scenario2: all services of scenario 1, plus the

queue waiting time service. A hybrid approach

is adopted (semantic reasoner plus the

processing agent for waiting time estimation).

Figure 7 shows, for both scenarios, the minimum,

maximum and average reasoning times, related to

the semantic reasoner only, the processing agent

only, both the semantic reasoner and the processing

agent (total reasoning times). The tests were

conducted in a simulated environment, on a PC with

Windows XP, 1.99 GB of RAM, 2 GHz CPU.

We can observe that the processing agent has

very good reasoning time performances, and does

not increase significantly the total reasoning times.

We also considered the semantic reasoner

performances as a good result, for the need of the

application developed.

Figure 8 shows the results of the same kind of

tests, performed over a time period of 5 hours. We

can observe that the longer test period did not

significantly affect the reasoning time performances

(the average reasoning time of the processing agent

even decreased).

Another benefit given by the processing agents

approach is that a processing agent can also be

ported to other platforms, including embedded

platforms, thus overcoming a limitation given by

using a resource demanding semantic framework.

Finally, we claim that the criteria related to

flexibility, simplicity and maintainability, defined in

(Kapitsaki, 2009) and referenced in Section 2, are

well satisfied by our solution.

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

6 CONCLUSIONS

AND FUTURE WORK

The paper presented a flexible solution for the

creation and management of context aware

pervasive and IoT-enabling applications. The

solution is based on a modular and extensible

platform, providing an effective support for context-

aware application deployment, from hardware to

network and middleware layers. The CA component

is given by a flexible framework that allows

integrating different reasoning methods (from the

semantic approach to event-processing techniques),

according to application needs.

A case study analysis highlighted the advantages

offered by the solution, which allows reducing the

context-aware application engineering effort and

complexity through the various provided methods

and instruments, which can be flexibly combined

according to application needs.

As a future work, we plan to further investigate

methods and tools for complex event processing

(e.g. for data streams, temporal reasoning, and

uncertain data management) and statistical analysis,

evaluating possible tools integration, e.g. complex

event processing engines (Esper, 2010)

(StreamInsight, 2009), and/or new techniques

development in our system.

ACKNOWLEDGEMENTS

The authors gratefully acknowledge partial funding

of this work by Regione Piemonte within the frame

of the research project “Piattaforma Tecnologica

Innovativa per l’Internet of Things”.

REFERENCES

Devices Profile for Web Services (DPWS), 2009. http://

docs.oasis-open.org/ws-dd/ns/dpws/2009/01.

Enhanced Micro Jena, 2010. http://www.nembes.org/.

Esper, 2010. http://esper.codehaus.org/.

Garofalakis, M., Brown K. P., Franklin M. J., Hellerstein

J. M., Zhe Wang D., 2006. Probabilistic Data

Management for Pervasive Computing: The Data

Furnace Project. Bulletin of IEEE Computer Society

Tech Committee on Data Engineering, 29(1), 2006.

Huang V., Javed M. K., 2008. Semantic Sensor

Information Description and Processing. In

SENSORCOMM'08, 2

International Conference on

Sensor Technologies and Applications.

IKVM.NET, 2010. http://www.ikvm.net/.

Jena, 2009. http://jena.sourceforge.net.

Jena-dev, 2008. http://tech.groups.yahoo.com/group/jena-

dev/message/32818;http://tech.groups.yahoo.com/gro

up/jena-dev/message/43618.

Jena .NET Framework, 2010. http://www.linkeddatatools.

com/downloads/jena-net.

Kapitsaki G., Prezerakos G., Tselikas N., and Venieris I.,

2009. Context-aware service engineering: A survey. In

Journal of Systems and Software, Vol. 82(8), 2009.

Kjær, K. E., 2007. A survey of context-aware middleware.

In SE'07, Proceedings of the 25

IASTED Conference

on Software Engineering. ACTA Press.

Kostelník P., Sabol T., Mach M., 2008. Applications of

Semantic Technologies in AmI. In Ambient

Intelligence Forum 2008 Conference Proceedings.

Leger A., Heinecke J., Nixon L., Shvaiko P., Charlet J.,

Hobson P., Goasdoue F., 2008. Semantic web take-off

in a european industry perspective. In Semantic Web

for Business: Cases and Applications. IGI Global.

µJena, Context-ADDICT, 2010. http://poseidon.ws.

dei.polimi.it/ca/?page_id=59.

Perttunen M., Riekki J., Lassila O., 2009. Context

representation and reasoning in pervasive computing:

a review. In International Journal of Multimedia and

Ubiquitous Engineering, Vol. 4(4), 2009.

Protégé, 2010. http://protege.stanford.edu/.

Roman M., Hess C., Cerqueira R., Ranganathan A.,

Campbell R., Nahrstedt K., 2002. Gaia: A middleware

infrastructure to enable active spaces. In IEEE

Pervasive Computing, 2002: 74-83.

Soylu A., De Causmaecker P., Desmet P., 2009. Context

and Adaptivity in Pervasive Computing Environments:

Links with Software Engineering and Ontological

Engineering. In Journal of Software, Vol. 4(9), 2009.

Strang T., Linnhoff-Popien C., 2004. A Context Modeling

Survey. In 1

International Workshop on Advanced

Context Modelling, Reasoning and Management.

StreamInsight, 2009. http://www.microsoft.com/sqlserver/

2008/en/us/r2-complex-event.aspx.

Truong H., Dustdar S., 2009. A Survey on Context-aware

Web Service Systems. In International Journal of Web

Information Systems, Vol. 5(1), 2009.

W3C Semantic Web, 2001. http://www.w3.org/2001/sw/.

Wolf P., Schmidt A., Klein M., 2009. Applying semantic

technologies for context-aware AAL services: What

we can learn from SOPRANO. In INFORMATIK

2009, Lectures Notes in Informatics, Vol. P-153.

XSD, 2004. http://www.w3.org/TR/2004/REC-xmlschema-

0-20041028/.

A FLEXIBLE MIDDLEWARE COMPONENT FOR CONTEXT AWARE APPLICATIONS
