PERVASIVE APPLICATION EVALUATION

WITHIN VIRTUAL ENVIRONMENTS

Vassilis-Javed Khan, Koos Nuijten and Nils Deslé

NHTV Breda Univesity of Applied Sciences, Breda, The Netherlands

Keywords: Augmented virtuality, Pervasive computing, Pervasive advertisement, Pervasive computing evaluation.

Abstract: In this position paper, we present a setup for evaluating users’ experience of pervasive applications within a

virtual environment. We review existing literature on mixed reality and pervasive application evaluation. A

conclusion of that review is the potential of evaluating applications such as location-based services in a

virtual environment. Finally, we present our plans of evaluating user experience factors of location-based

advertisements in a virtual supermarket, highlight methodological considerations and sketch future research

directions.

1 INTRODUCTION

1.1 Augmented Virtuality

& Virtual Environments

In their seminal paper Milgram and Kishino (1994)

presented the concept of “virtual continuum” where

real environments appear at the one end of the

continuum and virtual environments on the other

end. In between that continuum the concept of

“Augmented Virtuality” (AV) refers to the merging

of real world objects into virtual worlds. Since the

time of that paper, AV has had an application in a

variety of fields (Dubois et al., 2010) such as

medicine, entertainment, game, architecture, just to

name a few.

The widespread use of a virtual environment

(VE) is obviously routed to its advantages. It is a

completely controllable environment, easy to

manipulate and use it for different purposes. Thus, it

is perfectly suited for experimental research where

researchers need to control the environment while at

the same time be able to observe and meticulously

record observations and participant responses

(Dubois et al., 2010). Compared to a PC application

or low-fi prototypes, a VE is able to reconstruct the

environment and therefore the conducted research

would offer participants the right stimuli to yield

reliable results. Compared to laboratory settings a

VE allows participants to reconstruct their

experience of everyday settings while ensuring that

those settings are exactly the same for all

participants. Thus, a VE would score higher on

ecologically validity when compared to laboratory

studies.

However, developing a VE is still to some extent

expensive and requires extensive technical skills to

create. Besides, there would always be a difference

with the real world and therefore validation studies

would be necessary to measure the effect of that

difference. The immersiveness of the VE can also

have the disadvantage of creating a halo effect to

participants. Thus, there is the chance that

participants would respond differently to such an

environment due to the fact that they would have not

had experiences with a VE before, or as frequent as

with the real world.

Despite the shortcomings, settings that would be

impossible to control and test otherwise would be

partly possible to control in a VE.

It is notable that although tried out for different

objectives, more commercial settings such as of the

retail world seem to have been overlooked.

Nevertheless, there is a resent exception of Renner et

al. (2010) in which the researchers used a virtual

supermarket for evaluating interaction techniques.

The case of supermarket research for product

placement, advertisement and optimization of

shopping experience is already established. A virtual

supermarket would certainly facilitate

experimentation of the aforementioned research

objectives.

261

Khan V., Nuijten K. and Deslé N..

PERVASIVE APPLICATION EVALUATION WITHIN VIRTUAL ENVIRONMENTS .

DOI: 10.5220/0003361902610264

In Proceedings of the 1st International Conference on Pervasive and Embedded Computing and Communication Systems (PECCS-2011), pages

261-264

ISBN: 978-989-8425-48-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

Furthermore, in the field of pervasive computing,

applications are usually evaluated either in a lab or

in-situ. Laboratory evaluations are probably very

useful for usability studies. However, when it comes

to evaluating more abstract concepts such as the user

experience of a certain application a lab study would

affect the ecological validity of the evaluation.

Using virtual environments to evaluate pervasive

computing applications has been explored in the

past. Ubiwise (Barton and Vijayaraghavan, 2002) is

cited as one of the first attempts to evaluate

pervasive applications with the assistance of a

virtual environment. Since that first attempt there

have been several other prototypes tested with the

same purpose. For a review of those prototypes we

would refer to Reynolds, et al. (2006) and

Leichtenstern et al. (2010). There are two

conclusions to be drawn from those research efforts.

First, researchers have been targeting their efforts

into either the technical development of testbeds of

pervasive computing applications (Bruneau et al.,

2009, O'Neill et al., 2005). Second, so far, to our

knowledge, those efforts were simulating the VE on

a desktop computer. The serious shortcoming of

such a setup is the questionable level of immersion

for the user (Leichtenstern et al., 2010). Thus, a VE

presented on a desktop seems not to provide the

expected benefits in early testing of pervasive

computing applications.

In the next section we survey literature of in-situ

pervasive application evaluation to analyse the pros

and cons of such an approach.

1.2 Evaluation of

Pervasive Computing Applications

Current pervasive evaluation techniques include in-

situ evaluations in which systems are being deployed

in the real world. While trying to be ecologically

valid drawbacks of this approach are considerable.

Issues that might seem trivial at first become

serious obstacles for in-situ evaluations. In their

distributed and heterogeneous system for supporting

sergeants and hospital personnel Hansen et al.

(2006) report of such an experience. To give an

example, while the authors thought that finding a

place to place their public displays would be trivial it

actually proved to be a major problem. Trying to

generalize their findings, the authors report no less

than 19 items of a checklist to consider before

actually deploying a prototype in the real setting.

The authors categorized those items into three

categories: hardware, software and user setting.

Items from all three categories could partly be

addressed if a similar evaluation would take place on

a virtual environment. For example, the security of

the environment poses a threat to the equipment of

the research team; the space that the prototype

would need to use; the integration of the prototype

with third-party systems; the developers' support and

the organizational politics that might arise from such

an evaluation could serve as examples which would

be either obsolete or could be addressed in a virtual

environment. Of course that would imply that the

whole setting of a hospital, in this particular case,

would have been implemented in a virtual setting.

However, once it has been implemented, one could

both run numerous studies and keep on enhancing

that VE with more objects or actors.

Another issue that the authors raise that could

again easily be addressed in a virtual environment is

the number of users actually being able to

experience the prototype that is evaluated. In a

hospital situation, and especially in an operating

theatre, it is understandable that only the designated

doctors and personnel would have access to that.

Thus, this is another practical issue that raises

questions of reliability of the evaluation of such

prototypes. What would happen with different

doctors and hospital personnel can only be

hypothesized in this situation. On virtual setting

several users could test the same prototype.

In their evaluation of three pervasive applications

Consolvo et al. (2007) also discuss the limitations of

an in-situ evaluation. Their first study researched a

prototype deployed in a home setting for supporting

eldercare. The prototype was mimicking sensor data

with a Wizard of Oz. In-situ data were collected

daily over the phone. Their second study researched

a location aware application to understand the link

between user preferences and destinations. In this

study, situ self-reports via messages triggered based

on the participants’ arrival at a destination were

collected along with interview data. Their third

study investigated daily physical activity and

whether sharing activity related data with a small

group of friends might influence physical activity

goals. This study combined interviews and

questionnaires with in situ user-initiated logging of

pedometer data mobile phone application.

The authors report that “essential usage context

and pragmatic environmental constraints that might

otherwise go unnoticed in more controlled settings”

are necessary to actually evaluate pervasive

applications since the context of use changes and

plays an important role in the user's motivation and

experiences of the technology.

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

262

However, for the first study, the authors also

report: “a researcher had to call the elder or primary

caregiver up to six times per day from the early

morning until late evening every day for four

deployments, each of which lasted for 3 weeks”.

This makes one critique how ecologically valid

would such an evaluation be since the actual use of

such an application would obviously differ a lot.

Besides, the authors also report other shortcomings;

participants had established a rapport with one

particular researcher and preferred talking with that

researcher only; the study was “fairly labour

intensive” and “required careful planning,

preparation, coordination, and effort”. One would

certainly appreciate the difficulties in executing such

a study but at the same time still wonder how much

would the study itself distort the users' experience.

Khan et al. (2010) also report on the challenges

of in-situ evaluation of a pervasive computing

application targeting working parents. Apart from

technical issues that were also reported in the

aforementioned studies, trivial unforeseen problems

such as participants having to carry a second mobile

device next to their own phone also negatively affect

the evaluation efforts.

Although the theoretical benefits of evaluating

pervasive computing applications in-situ are

substantial, the challenges are still considerable. In

some cases while pursuing to overcome those

challenges the ecological validity of evaluation

studies becomes questionable.

A concluding remark is that the use of a VE has

been limited when it comes to evaluation of

pervasive computing applications; previous studies

have asked users to experience a VE on a PC. We

envision exploring the use of a VE, not presented in

a PC but in an environment where the user is

actually immersed, for pervasive application

evaluation, since the context of usage can to a great

extent be reconstructed.

2 CASE STUDY

Our interest lies in the evaluation of pervasive

advertising in a setting of a virtual supermarket. Our

lab has a CAVE (Cave Automated Virtual

Environment) consisting of four display walls of 3.5

wide by 2.6m high. These displays form an enclosed

room, and images are back-projected on them. The

projections are calculated in such a way that, when a

user stands in the room, the illusion of a continuous,

360 degree, view is created (Figure 1).

Figure 1: Participant interacting with the virtual

supermarket. The participant is wearing a head tracker.

We have created a head-tracking technique using

four Wii-motes, one in each corner of the room. The

user while being inside the CAVE wears a headband

with an infrared LED array. Through the 2D

coordinates each Wii-mote returns to the server, we

triangulate an exact 3D position of the user's head.

We use this position to control motion in the CAVE,

by using a "human joystick" scheme, whereby the

virtual camera will strafe in the direction the user is

standing, relative to the CAVE's center.

Virtual worlds are created in Maya, and rendered

using OGRE as the underlying 3D engine. We have

created several layers of frameworks to be able to do

the network synchronisation, head tracking, model

importing and optimized rendering.

For our first case study, a virtual supermarket has

been created in Maya. The supermarket is a generic

supermarket, based on common denominators found

in typical Dutch supermarkets. It contains isles,

freezers, checkout counters, etc., all rendered with

realistic graphics. Currently, about 1/6 of the shelves

are filled with products, but it is our near future

plans to fill it with a representative product set.

2.1 User Experience Evaluation

of Location based Advertisements

As a first case study we have planned an experiment

to evaluate aspects of user experience of location-

based ads within the virtual supermarket. It has been

shown that perceived intrusiveness of ads leads to ad

irritation (Li and Lee, 2002). High values of ad

irritation lead to high a probability of ad avoidance

(Li and Lee, 2002).

We are interested in exploring whether location

affects the way people perceive ad intrusiveness.

The hypothesis is that when people would receive an

ad in their mobile phone close to a product that is

related to the ad, they would not perceive that ad as

PERVASIVE APPLICATION EVALUATION WITHIN VIRTUAL ENVIRONMENTS

263

intrusive and would not be irritated by it. In other

words, we hypothesize that when there is a match

between an ad and the supermarket shelf in which

the advertised product is sold people will find the ad

less intrusive.

To test this hypothesis we developed an Android

mobile phone application. The application interacts

through Bluetooth with the virtual supermarket.

When the user, carrying the mobile phone, is within

a certain distance of a virtual shelve then the phone

vibrates and sets off an alert sound while presenting

an ad.

2.2 Long Term Plans

Going beyond the case study of perceived

intrusiveness of location based advertisements, our

goals extend into exploring a variety of pervasive

computing applications in the virtual environment.

More generic questions include validation

studies testing the perceived presence of the virtual

supermarket with a real supermarket as well as

exploring the added value of such an immersive

virtual supermarket with a PC version of similar

virtual supermarkets. It is safe to hypothesize that

the immersive version of a virtual supermarket

might well provoke behavior that would resemble

more closely the behavior of a real supermarket.

3 CONCLUSIONS

Having a plethora of online, virtual supermarkets on

the browser of people's PC is something that is

nowadays a reality. With the development of

technology, one would wonder what kind of

behavior would people exhibit when encountered

with a virtual, immersive supermarket compared to

the PC-based.

We set out to execute a series of studies in an

augmented virtual supermarket. We have identified

that pervasive application evaluation with the

assistance of mixed reality environments is still in its

infancy. The advantages of a simulated environment

lie in the fact that such an environment is fully

controllable and adaptable to the researchers' needs.

Evaluating pervasive computing in-situ has many

advantages nevertheless it also poses various

challenges. Many of the challenges could be tackled

with the use of a virtual environment. It lies up to

researchers to make use of the new possibilities that

such a setup would create.

ACKNOWLEDGEMENTS

We would like to express our gratitude to our

financial sponsors: the Dutch Ministry of Education,

Culture and Science (OCW), RAAK scheme. Many

thanks to Arief Ernst Hühn who took the photo

displayed in this paper.

REFERENCES

Barton J. J., & Vijayaraghavan, V., 2002. Ubiwise: A

ubiquitous wireless infrastructure simulation

environment. Tech. report HP. HP Labs.

Bruneau, J., Jouve, W., Consel, C., 2009. DiaSim: A

parameterized simulator for pervasive computing

applications. In Proc. of MobiQuitous’09, pp.1-10.

Consolvo, S., Harrison, B., Smith, I., Chen, M. Y., Everitt,

K., Froehlich, J., Landay, J., 2007. Conducting in situ

evaluations for and with ubiquitous computing

technologies. IJHCI, 22(1-2):103-118.

Dubois E., Gray, P., & Nigay, L. (eds.), 2010. The

Engineering of Mixed Reality Systems, Human-

Computer Interaction Series, doi:10.1007/978-1-

84882-733-2_1.

Hansen, T. R., Bardram, J. E. & Soegaard, M., 2006.

Moving Out of the Lab: Deploying Pervasive

Technologies in a Hospital. IEEE Pervasive

Computing, 5(3):24–31.

Khan, V. J., Markopoulos, P, Eggen, B., & Metaxas, G.,

2010. Evaluation of a pervasive awareness system

designed for busy parents. Pervasive and Mobile

Computing, 6(5):537-558.

Leichtenstern, K., André, E., & Rehm, M., 2010. Using

the Hybrid Simulation for Early User Evaluations of

Pervasive Interactions. In Proc. of NordiCHI2010, pp.

315-324.

Li Hairong, S. & Lee, J., 2002. Measuring the

intrusiveness of advertisements: Scale development

and validation. Journal of Advertising, 31(2):37–47.

Milgram, P. & Kishino, F., 1994. A taxonomy of mixed

reality visual displays. IEICE transactions on

information systems, E77-D(12).

O'Neill, E., Klepal, M., Lewis, D., O'Donnell, T.,

O'Sullivan, D., Pesch, D., 2005. A testbed for

evaluating human interaction with ubiquitous

computing environments. In Proc. of Tridentcom2005.

pp. 60-69

Renner, P., Dankert, T., Schneider, D., Mattar, N. &

Pfeiffer, T., 2010. Navigating and Selecting in the

Virtual Supermarket: Review and Update of Classic

Interaction Techniques. In Virtuelle und Erweiterte

Realität: 7. Workshop der GI-Fachgruppe VR/AR, 71-

82. Aachen, Germany: Shaker Verlag.

Reynolds, V., Cahill, V., & Senart, A., 2006.

Requirements for an ubiquitous computing simulation

and emulation environment. In Proc. of InterSense '06.

Article 1. doi:10.1145/1142680.1142682.

PECCS 2011 - International Conference on Pervasive and Embedded Computing and Communication Systems

264
