COMMUNITY DRIVEN REQUESTS FOR PROPOSALS

Applying Semantics to Match Customer Purchase Intents to Vendor Offers

Christophe Debruyne

Semantics Technology and Applications Research Lab, Vrije Universiteit Brussel, Pleinlaan 2, B-1050 Brussels, Belgium

Davor Meersman

Digital Ecosystems and Business Intelligence Institute, Curtin University, GPO Box U1987, Perth, WA, 6845, Australia

Mathias Baert, Rami Hansenne

iChoosr BVBA, Bourlastraat 3 bus 14, B-2000 Antwerpen, Belgium

Keywords:

Product and RFP Ontology, Request for proposals, Semantic matching, Data integration.

Abstract:

This paper presents a platform for requests for proposals and describes how ontologies drive the different com-

ponents: the creation of a proposal, the annotation of vendor data, the transformation of vendor data into other

formats and the semantic matching of a proposal against annotated vendor data. The ontology construction

started from DOGMA, a methodology with its grounding in the linguistic representation of knowledge that is

suitable for community participation in the creation process. The ontologies were created in a modular way,

with general product and meta-models that can be extended depending on the domain. In the case of the pilot,

the product were holiday packages, more precisely winter sports holiday packages.

1 INTRODUCTION

When consumers want to buy a certain item on the

World Wide Web today, they have to browse through

literally hundreds of offerings and results and this

number is expected to increase in the future. In this

model, the vendors drive the process by publishing

products and providing means to buy these online.

For example, travel agencies in the Netherlands need

to query many different tour operators to ﬁnd holi-

day packages meeting their customers’ requirements.

They often have an API that facilitates this process,

but the granularity of the speciﬁc search is often lim-

ited due to the heterogeneous nature of all vendor

databases.

A solution to this problem would be to allow the

consumers to specify their requirements and to match

these to offers of different vendors. Such a speciﬁ-

cation is called a Request for Proposals (RFP). The

COMDRIVE RFP project resulted in a platform en-

abling consumers to drive the requirements process

by expressing their intent to buy a certain product in

a tool and language they are comfortable with. This

platform sends out the request to a distributed vendor

infrastructure, which responds to the request with of-

fers.

The RFP, the heterogeneous vendor data, the

matching of both and an appropriate interface for the

customer all need to be driven by a agreed upon con-

ceptual model, called an ontology. An ontology is

commonly deﬁned as: “a [formal,] explicit speciﬁca-

tion of a [shared] conceptualization” (Gruber, 1995)

and are now key to enable semantic interoperabil-

ity between information systems and services on the

Web (Guarino, 1998). In general, interoperability is

deﬁned as the ability of two or more information sys-

tems or their (computerized) components to exchange

data, knowledge or resources and to interpret the in-

formation in them (De Leenheer and Mens, 2008), in

this case the RFP platform and the different vendor

applications.

This paper presents the platform and explains how

ontologies and semantic technology are key in achiev-

ing success. The content of this paper is organized as

follows: Section 2 provides more context about the

project and the motivation why such a portal should

525

Debruyne C., Meersman D., Baert M. and Hansenne R..

COMMUNITY DRIVEN REQUESTS FOR PROPOSALS - Applying Semantics to Match Customer Purchase Intents to Vendor Offers.

DOI: 10.5220/0003330905250530

In Proceedings of the 7th International Conference on Web Information Systems and Technologies (WEBIST-2011), pages 525-530

ISBN: 978-989-8425-51-5

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

be driven by ontologies. Section 3 presents the on-

tology engineering methodology adopted and applied

within the project as well as how the resulting ontolo-

gies were applied to achieve the platform’s tasks. Sec-

tion 4 provides some preliminary results during the

pilot before concluding and discussion our work in

Section 5. Throughout this paper, the examples used

stem from the domain of winter holiday packages (in-

cluding winter sports, accommodation, facilities).

2 CONTEXT AND PROBLEM

iChoosr BVBA

is an internet company who special-

izes in supporting communities in organizing group

buying events (GBE) in spirit of Vendor Relationship

Management (VRM). VRM means providing cus-

tomers with tools for engaging with vendors in ways

that work for both parties, as it is difﬁcult for ven-

dors to fully relate with customers. These GBEs gives

customers signiﬁcant volume discounts. In return,

iChoosr supports vendors in ﬁnding the appropriate

customers, who also diminish their costs in logistics.

A GBE always consists of a community identiﬁed by

a particular need for a product (e.g., heating oil) who

is represented by a community leader.

Milq Media

is the publisher of the winter-

sporters.nl/ platform and agreed to take part as pilot

partner in this project. Wintersporters.nl’s content is

characterized by its actuality and a large amount of

objective information. With an average reach of more

than 600.000 visitors per month, it is the largest win-

ter sports platform in The Netherlands. The commu-

nity of wintersporters.nl, with Milq Media acting as

the community leader, was therefore chosen to be the

pilot partner within this project.

The pilot of the platform consists of a personal

RFP for travel in cooperation with the publisher of

online travel platforms Milq Media. During this pi-

lot, members of the Milq Media user community can

set out Personal RFPs with the system and get offers

from interested travel vendors. The matching engine

automatically found some of these offers; other offers

were matched manually by an employee of a travel

vendor. The user and the vendor can also commu-

nicate through a message system. This allows them

to further clarify the request and the offer. The main

components of this platform (see Figure 1) are:

• Personal RFP Ontology. A semantic and exten-

sible conceptualization of RFP. An ontology that

http://www.ichoosr.com/

http://www.milq.nl/

describes the domain-speciﬁc Personal RFPs, al-

lowing communities to contribute product- and

domain speciﬁc concepts through collaborative

knowledge engineering.

• An Automated Group Buying. (AGB) module

that allows community leaders to organize their

group buying activities online with their com-

munity members with support for member group

buying process initiation.

• Semantic Matching Engine. Matching of cus-

tomer intent and vendor offering based on shared,

personal customer purchasing proﬁle and commu-

nity proﬁle for accurate offerings based on prede-

ﬁned and implicit criteria. Matching of semantic

product data and ﬂat vendor data annotated with

the ontology.

• Rapid Semantic Node Cloud Navigation. Dy-

namic node cloud underpinned by semantic prod-

uct data for rapid navigation through correlated

product concepts.

Vendor applications/databases

COMDRIVE RFP Platform

Consumer

Portal

request

Ontology

Matcher

commits to

Offers

Requests

Uses

Result matches

offer

Figure 1: COMDRIVE RFP: The role of semantics in the

annotation of vendor data and customer intent for semantic

matching.

For this solution to be truly effective, buyers and

vendors need to share a common vocabulary of the

domain. More speciﬁcally, software agents need to

interpret the information in RFPs to (semi-) automati-

cally match this information with data in the vendors’

product database based on their semantics. The se-

mantic of the domain is provided by its conceptual-

ization, which enables the alignment of the vendors’

and buyers’ perspectives. A conceptualization pro-

vides a shared agreement on the semantics of core

concepts and the relationships between them impos-

ing a structure on the domain that is readable by both

humans and machines. In COMDRIVE RFP, the per-

sonal RFP ontology is thus key in the other modules’

functioning.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

526

3 APPROACH

The creation and application of ontologies within

COMDRIVE RFP were constructed in an iterative

manner. This section explains how the ontologies

came to be and were then used to annotate vendor

data, which were in turn used by the semantic match-

ing to transform that data in a internal format suitable

for the task.

3.1 Ontology Engineering Methodology

Many collaborative ontology engineering method-

ologies exists (Sure et al., 2009). We adopted

DOGMA (Jarrar and Meersman, 2009), which stands

out for its groundings in linguistics. DOGMA re-

lies on the fact that its knowledge building blocks

expressed in natural language are easily obtained

and agreed upon (as inspired by database modeling

methodologies such as NIAM (Wintraecken, 1990)

and ORM (Halpin, 2008)). As a result, domain ex-

perts and knowledge engineers can use natural lan-

guage to communicate and capture knowledge.

These building blocks - called lexons (Jarrar and

Meersman, 2009) - only need in principle to express

“plausible” facts (as perceived by the community of

stakeholders) in order to be entered into the Lexon

Base, a repository containing large sets of such lex-

ons. A lexon is formally described as a 5-tuple hγ,

headterm, role, co-role, tailterm i, where γ is an ab-

stract context identiﬁer pointing to a resource (e.g., a

document on the Web). The context identiﬁer is as-

sumed to identify unambiguously (to human users at

least) the concepts denoted by the term and role la-

bels. Figure 3 shows some examples of lexons.

The Commitment Layer contains selections of lex-

ons to annotate (types of) applications and constraints

rules deﬁning the use of the concepts in the ontol-

ogy. In DOGMA, we distinguish two types of com-

mitments: ontologies and application commitments.

The ﬁrst denotes a meaningful selection of lexons and

rules that capture well the intended semantics of an

application domain. The latter extends the commu-

nity commitments mappings describing how the ap-

plication symbols (e.g., ﬁelds in a table) of one in-

dividual application map to concepts in the ontology.

The application commitment can furthermore contain

additional lexons and constraints that describe how

the application - as a whole - commits to the ontol-

ogy. Figure 2 graphically depicts the different lay-

ers and Section 3.2 and 3.3 discusses respectively the

construction of the ﬁrst and the latter.

Application

Mapping N

...

Application

Mapping 1

Lexons

Ontologies

Application

Commitments

Figure 2: The different layers in DOGMA. Lexons in the

Lexon Base are used to construct ontologies (with addi-

tional) constraints. Application commitments extends those

ontologies with mappings of application symbols to the on-

tology.

3.2 Ontology Construction

Before building an ontology from scratch, one has to

look around for existing meta-models. With meta-

model, we mean any kind of conceptual model, not

necessarily implemented with semantic technology

(such as XML Schemas, or a code-based classiﬁca-

tion). (Hepp et al., 2007) analyzed and compared

four important product meta-models: eCl@ss

, UN-

SPSC

, EOTD

and RosettaNet Technical Dictio-

nary

. Both eCl@ss and UNSPSC are broad, but the

ﬁrst was were created by and driven by the German

industry and thus a “de facto standard”, whereas the

latter was driven by the United Nations Development

Programme. Both UNSPSC and eCl@ss provide very

little detail for the traveling domain. The others were

designed for more technical industries and did not ﬁt

the scope of this project.

Travel meta-models include Hi-Touch

, OnTour

Harmonise (Dell’Erba et al., 2002) and the Open

Travel Alliance (OTA) speciﬁcation

. Harmonise fo-

cuses on accommodation and events (e.g., sports and

conferences), but its main aim is to transfer data be-

tween tourism industry partners. Hi-Touch is a com-

mercial thesaurus implemented in OWL to align dif-

ferent vendor databases. OnTour, a recent initiative,

mainly covers accommodation and activities. OTA

provides a structure for electronic messages, e.g., con-

cerning ﬂights, insurance, etc. Hi-touch and On-

Tour ontologies were developed based on interna-

tional standards whereas OTA and Harmonise provide

their own standards. We drew inspiration from these

http://www.eclass-online.com/

http://www.unspsc.org/

http://www.eccma.org/

http://www.rosettanet.org/

http://www.mondeca.com/

http://e-tourism.deri.at/ont/index.html

http://www.opentravel.org/

COMMUNITY DRIVEN REQUESTS FOR PROPOSALS - Applying Semantics to Match Customer Purchase Intents to

Vendor Offers

527

meta-models to bootstrap an initial product ontology.

By our knowledge, no RFP meta-model exists.

GoodRelations (Hepp, 2008) is a lightweight on-

tology to annotate most aspects of offers and their

goods on the Web. Not exactly modeling an RFP,

GoodRelations captures nicely what could be re-

turned as a response or compared with a customer’s

intent. GoodRelation does provide a construct to de-

scribe what a business entity needs, but does not sep-

arate the concerns. It is thus possible for users to de-

scribe a product they are looking for and specify, for

instance, a serial number.

We bootstrapped the product and RFP ontologies

drawing inspiration from the existing meta-models

and vendor applications, which were then reﬁned and

completed by several domain experts. We consulted

such experts with different views on the domain, tour

operators for the vendor perspective and a community

of skiers for the buyer perspective. Figure 3 shows

some of the lexons created for the purpose of this

project. These lexons were built using Collibra Busi-

ness Semantics Studio (BSS)

Figure 3: Some lexons describing domain knowledge de-

veloped during the project. These lexons describe that both

rooms and accommodations can have facilities, which in

turn have a name.

The ontology was developed in a modular way

(see Figure 4). The Upper Common Ontology (UCO)

contains the conceptualizations and semantic con-

straints that are common to and accepted by a gen-

eral domain such as RFP and Product. For instance,

the lexon hγ, RFP, has, of, Orderline i states

that an RFP has orderlines, is true for all applica-

tions of stakeholders within that domain and there-

fore belongs to that layer. The Domain Application

Ontology (DAO) contains lexons speciﬁc to a cer-

tain application domain. In the case of COMDRIVE

RFP, these lexons will contain the terms Holiday

Package and Accommodation. The Lower Common

Ontology (LCO) represents the interpretation of the

domain from the perspective of an organization or

community. For instance, the representation of a

Price might change depending on the community: it

is represented by a Range from a buyer’s perspective,

while it is represented as a Value from the Vendor’s

http://www.collibra.com/products/

perspective. While the ontology evolves, this layer

contains the information that is going to be reﬁned by

a core domain expert to be integrated in the UCO.

Upper Common Ontology

Domain Application Ontology

Product Elements RFP Elements

Winter Sports

Consumer

Electronics

Lower Common Ontology

Buyers'

Perspective

Vendors'

Perspective

...

Figure 4: The modular structure of ontologies modeled with

DOGMA within the COMDRIVE RFP platform.

3.3 Annotating Vendor Data

An application commitment represents an explicit in-

terpretation of an ontology for an application or a

family of applications. It consists of four things (Ver-

heyden et al., 2004): (i) a selection of lexons from the

ontology which are relevant for the application, (ii)

constraints to specify how that selection can be used

(mandatory and uniqueness constraints, for example),

(iii) some scripting functionalities allowing database

engineers/programmers to manipulate instances dur-

ing the transformation process and (iv) a set of map-

pings between the application-speciﬁc symbols (e.g.,

XPath expressions) and the concepts used in the on-

tology. Figures 5 and 6 show how an application com-

mitment of a vendor application constrains the use of

lexons and the mapping to its application symbols.

The transformation is performed by Collibra Business

Semantic Enabler (included in BSS).

The effort needed to annotate the data of one ven-

dor generally took one day when using BSS. The BSS

commitment editor generates all occurring XPaths

which the users need to annotate with lexons from the

ontology by means of drag and drop. Constraints are

created either via a graphical editor or a controlled

natural language as shown in 5.

3.4 Creation of an RFP

A node cloud navigation is used as the user interface

and lets users ﬁnd the concepts from the ontology de-

scribing their wishes best. It is the result of an itera-

tive design process involving several paper prototyp-

ing sessions and user tests during development. The

interface (see Figure 7) consists of a list of starting

points and a cloud of selected concepts, possibly with

values assigned to them.

The starting points, chosen by the partner commu-

nity since they know their members best, are there to

get people started. After adding the concepts from the

relevant starting points, the user can add more speciﬁc

items using the search function. This is an instant

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

528

Holiday Package is identified by Name. Holiday Package has exactly 1 Name.

Holiday Package has at most 1 Description.

Figure 5: Constraining lexons.

map "/items/item" on Holiday Package. map "/items/item/title" on Name of Holiday Package.

map "/items/item/description" on Description of Holiday Package.

Figure 6: Mapping the application symbols to lexons. In this particular application, each “item” corresponded with one

holiday package.

search-style search: while typing a keyword the re-

sult set is narrowed down. It usually takes only a few

characters to ﬁnd the concept one is looking for and

also looks at possible values for these concepts (e.g.,

“France” for “Country”) and synonyms (e.g., “Desti-

nation” for “Country”). Each time a user ﬁnds a rele-

vant concept, he adds a node to the node cloud.

Figure 7: The user interface for creating an RFP driven by

the ontology. The interface, driven by the ontology, aids the

user in expressing their intent. In this example, the user

is asked to give one (or more) possibilities for Ski Area

(“Skigebied” in Dutch), Auto-completion relies on access-

ing the data through the application commitment.

3.5 Semantic Matching

The matching engine is an advanced search engine

for analyzing structured, semi-structured and free text

data. Contrary to classic searching and querying tech-

nology, matching functionality will take into account

the semantic context of concepts to match upon and it

will also return close matches if no exact matches can

be found. The engine will score and rank the matches

based on the degree in which they match, taking

into account conﬁguration parameters, e.g., weight,

thresholds and optionality/requiredness of conditions.

The matching engine provides generic match-

ing functionality and its interface is not speciﬁcally

geared towards the notions of RFP or vendor offer-

ings. Instead, from the match engine perspective, it

simply matches match queries containing match con-

ditions against a collection of match objects. A match

property is a basic entity upon which can be matched.

These match properties could be criteria such as price,

age, distance, etc. A match object aggregates a num-

ber of match properties and assigns them speciﬁc val-

ues. Examples of match objects are: RFP, vendor

offering, etc. A match condition represents the re-

quested or “ideal” property. It is passed to the engine

to compare with all known match properties that have

the same id (and therefore same semantics) and to re-

turn all match objects which match the query condi-

tions as close as possible.

A list of all properties known to the engine is

deﬁned in the match engines ontology mapping (Ω-

RIDL ﬁle), which maps the relevant concepts in the

ontology to the match engines internal format. The

matching engine commits thus to the ontology in the

same way as a vendor applications. The mapping

used by the engine is quite straightforward and simply

maps each “matchable” concept to a match property

of the corresponding type, using the path in the ontol-

ogy as ID. Figure 8 shows some mapping rules

. The

transformation service mentioned in Section 3.3 takes

care of transforming vendor offers into match objects.

4 PILOT AND OBSERVATIONS

The pilot ran in October 2010. It was agreed with

Milq Media to encourage the wintersporters.nl com-

munity to test the interface to validate the ideas. Their

forum provided feedback, which enabled the pilot to

solve some of the initial bottlenecks (e.g., suggest a

starting point when users don’t know where to start).

38% of the RFP’s where completed.

Users generally welcomed the idea, though the re-

sults were often not accurate enough. This was due to

two reasons. First because of the heterogeneous na-

ture of the vendor data streams; data that was present

The complete Ω-RIDL mapping

for the matching engine is available at

http://starlab.vub.ac.be/website/ﬁles/matchobjects.ridl .txt.

Vendor data mappings within this project are not publicly

available, but parts of it can be requested by contacting the

authors.

COMMUNITY DRIVEN REQUESTS FOR PROPOSALS - Applying Semantics to Match Customer Purchase Intents to

Vendor Offers

529

map "/matchObjects/matchObject/numericalMatchProperty[@id=’Value of Price of Holiday Package’]

/value" on Value of Price of Holiday Package.

map "/matchObjects/matchObject/stringMatchProperty[@id=’Currency of Price of Holiday Package’]

/value" on Currency of Price of Holiday Package.

Figure 8: Mapping the application symbols to lexons.

with one vendor, was sometimes not present with an-

other. Second, and what we considered the most im-

portant issue we have experienced, was a serious dis-

crepancy between what concepts and level of granu-

larity the user thinks are important in deﬁning an in-

tent and what is offered by vendors (e.g., “distance

to the lift”). We have seen that merely building on-

tologies on top of the data that is provided by vendors

does not solve the problem of ﬁnding products that

match user needs. When given the liberty of deﬁning

ones wish, users demonstrate the desire to involve in-

formation that pertains to the product application do-

main. Although some of these concepts were present

in the ontology, there was no data to work with.

5 CONCLUSIONS

This paper presented the COMDRIVE RFP plat-

form that enables customers to deﬁne purchase intent,

called an RFP, which can then be matched against

annotated vendor data. All modules (RFP creation,

vendor data annotation and transformation, semantic

matching) are driven by an ontology with different

layers of abstraction (a general RFP and product on-

tology and extensions for particular domains). The

method for ontology creation was based on linguis-

tics, which facilitated the dialogue with the different

domain experts.

Future work includes the application of the upper

common ontologies (RFP, and product) in other do-

mains for validation and reﬁnement as well as the ap-

plication of the domain application ontology to other

types of holiday packages (e.g., camping). In the fu-

ture, a more prominent role for community aspects

will be investigated. These can be useful to provide

even better matching results, as different communi-

ties behave differently (e.g., younger people tend to

put more emphasis on budget constraints).

ACKNOWLEDGEMENTS

The results of this research were partially funded

by IWT

090214 SME innovation project “COM-

DRIVE RFP”. We also would like to thank Quentin

http://www.iwt.be/

Reul, Maarten Smolders, Tanguy Coenen for the fruit-

ful discussions.

REFERENCES

De Leenheer, P. and Mens, T. (2008). Ontology evolution.

In Hepp, M., De Leenheer, P., de Moor, A., and Sure,

Y., editors, Ontology Management, volume 7 of Se-

mantic Web And Beyond Computing for Human Expe-

rience, pages 131–176. Springer.

Dell’Erba, M., Fodor, O., Ricci, F., and Werthner, H.

(2002). Harmonise: A solution for data interoperabil-

ity. In Monteiro, J. L., Swatman, P. M. C., and Val-

adares Tavares, L., editors, I3E, volume 233 of IFIP

Conference Proceedings, pages 433–445. Kluwer.

Gruber, T. R. (1995). Toward principles of the design of

ontologies used for knowledge sharing. International

Journal of Human and Computer Studies, 43:907–

928.

Guarino, N. (1998). Formal ontology and information sys-

tems. In Int. Conference On Formal Ontology In In-

formation Systems FOIS’98, pages 3–15, Trento, Italy.

Amsterdam, IOS Press.

Halpin, T. (2008). Information Modeling and Relational

Databases. Morgan Kaufmann, San Francisco, CA,

USA.

Hepp, M. (2008). GoodRelations: An ontology for de-

scribing products and services offers on the web. In

Gangemi, A. and Euzenat, J., editors, EKAW, volume

5268 of LNCS, pages 329–346. Springer.

Hepp, M., Leukel, J., and Schmitz, V. (2007). A quan-

titative analysis of product categorization standards:

content, coverage, and maintenance of eCl@ss, UN-

SPSC, eOTD, and the RosettaNet Technical Dictio-

nary. Knowledge Information Systems, 13(1):77–114.

Jarrar, M. and Meersman, R. (2009). Ontology engineering

– the DOGMA approach. In Dillon, T., Chang, E.,

Meersman, R., and Sycara, K., editors, Advances in

Web Semantics I, volume 4891 of LNCS, pages 7–34.

Springer Berlin / Heidelberg.

Sure, Y., Staab, S., and Studer, R. (2009). Ontology en-

gineering methodology. In Bernus, P., Blazewicz, J.,

Schmidt, G

unter, J., Shaw, M. J., Staab, S., and Studer,

R., editors, Handbook on Ontologies, International

Handbooks on Information Systems, pages 135–152.

Springer Berlin Heidelberg.

Verheyden, P., De Bo, J., and Meersman, R. (2004). Seman-

tically unlocking database content through ontology-

based mediation. In Bussler, C., Tannen, V., and Fun-

dulaki, I., editors, SWDB, volume 3372, pages 109–

126.

Wintraecken, J. (1990). The NIAM Information Analysis

Method, Theory and Practice. Kluwer Academic Pub-

lishers.

WEBIST 2011 - 7th International Conference on Web Information Systems and Technologies

530
