TEACHING GLOBAL SOFTWARE ENGINEERING AND

INTERNATIONAL PROJECT MANAGEMENT

Experiences and Lessons Learned from Four Academic Projects

Florian Matthes, Christian Neubert, Christopher Schulz

TU M

unchen, I19, Boltzmannstr. 3, D-85748 Garching, Germany

Christian Lescher

TU M

unchen, I1, Boltzmannstr. 3, D-85748 Garching, Germany

Jos

e Contreras

Universidad T

ecnica Federico Santa Mar

ıa, Avenida Espa

na 1680, Valpara

ıso, Chile

Robert Laurini, Beatrice Rumpler

INSA de Lyon, 7 avenue Capelle, F-69621 Villeurbanne, France

David Sol

Tecnol

ogico de Monterrey, campus Puebla V

ıa Atlixcayotl 2301, 72800 San Andr

es Cholula, Mexico

Kai Warendorf

Hochschule Esslingen University of Applied Sciences, Flandernstr. 101, 73732 Esslingen, Germany

Keywords:

Global software engineering, Software project management, Education approach, Experience report, Interna-

tional project management.

Abstract:

As part of the ongoing globalization process, software is no longer developed by a sole enterprise which is

based at one single location only. In turn, distributed engineering teams are continuously producing software

by bringing in their local knowledge and country-speciﬁc expertise. Due to this cooperation on a global-

scale, today’s software engineers require distinct skills and capabilities allowing them to face a paradigm

called Global Software Engineering (GSE). However, regarding today’s universities curricula, the teaching

of GSE can be seen as an emerging discipline which is increasingly gaining attention. This paper depicts the

progression and lessons learned from four different globally distributed software engineering projects executed

by late bachelor and master students from ﬁve different universities of four countries. In doing so, the article

facilitates future GSE endeavors in academia and industry.

1 INTRODUCTION

AND BACKGROUND

Many technological, organizational, and economic

factors have led to the increased globalization of de-

velopment projects (Sangwan et al., 2006). Drivers

for Global Software Engineering (GSE) include cost

competitiveness, access to talent regardless of loca-

tion, the need for a globalized presence, as well as

mergers and acquisitions (Carmel, 1999). Globally-

distributed projects are rapidly becoming the norm

for large software systems (Herbsleb, 2007). Thereby,

GSE imposes new challenges on software engineers,

in which coordination over distance (Damian et al.,

2010; Herbsleb, 2007; Lescher et al., 2007) can be

considered as one of the major ones. In this respect,

Matthes F., Neubert C., Schulz C., Lescher C., Contreras J., Laurini R., Rumpler B., Sol D. and Warendorf K..

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT - Experiences and Lessons Learned from Four

Academic Projects.

DOI: 10.5220/0003272600050015

In Proceedings of the 3rd International Conference on Computer Supported Education (CSEDU-2011), pages 5-15

ISBN: 978-989-8425-50-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

there is a strong need for educating and training IT

employees to act jointly in an international context.

Not only those software engineers are geographically

separated from each other by working at multiple

locations on interdepending modules, they are also

subject to cultural differences including national cul-

ture, native language, as well as organizational cul-

ture (Carmel, 1999; Hofstede and Hofstede, 2004).

In this regard, technical expertise and know-how are

essential but the ability to collaborate effectively in

globally distributed teams is equally important (Gotel

et al., 2009).

When considering the personal requirements

which today’s software engineers are facing in their

daily work life, it is surprising to see that teaching

GSE at universities is still in its infancy. Besides its

recent occurrence and emerging importance in indus-

try, the sparse offering of teaching GSE in academia

maybe caused by the additional coordination work

hosting institutions have to cope with when organiz-

ing such types of courses. Furthermore, different

semester schedules combined with unequal grading

and evaluation schemes complicate the cooperation

among global distributed universities. In the light of

aforementioned situation, ﬁve chairs of ﬁve different

universities speaking three different languages con-

jointly organized a practical course during the winter

semester 2009/10, namely:

• Institute National des Sciences Appliqu

ees de

Lyon (INSA) in France

• Tecnol

ogico de Monterrey campus Puebla (TEC)

in Mexico

• Technische Universit

at M

unchen (TUM) in

Germany

• Universidad Tecnica Federico Santa Maria (USM)

in Chile

• University of Applied Sciences Esslingen (UE) in

Germany

Coined by the name Network of Engineer-

ing universities Educating in Intercultural Design

(NEREID) in July 2008, the cooperative course aimed

at teaching students how to work on software engi-

neering projects given a globally distributed team.

Originally, the NEREID course was launched by

Prof. Laurini in the Information Technology depart-

ment of Institute National des Sciences Appliqu

ees de

Lyon (INSA). Considering the typical syllabus of the

master computer science graduates of INSA de Lyon

six students work conjointly on six projects during a

given time frame of one year. In this vein, each stu-

dent has to take on the role of the project lead, follow-

ing the thought that an expert in software engineering

must not only be a good programmer, but moreover

has to obtain distinctive skills in project management,

especially when dealing with the design and coding of

huge software products. However, the main limitation

is that local students possess the same culture, apply

similar methodologies, and speak the same language.

Regarding the future work of those students, they will

much likely be in contact with colleagues having dif-

ferent cultures, speaking different languages, as well

as mastering different methodologies.

Since INSA de Lyon regards international project

experience as a key aspect of each student’s cur-

riculum

, in fall 2007 the idea came up to organize

cross-country projects, in which students from differ-

ent countries would have to work conjointly on one

project. Thereupon, Prof. Laurini and his colleagues

contacted several international universities in 2008.

With regards to participation constraints, the relation-

ships between students within a project team had to be

on the same level, i.e. each software engineering task

could be assigned to each student. Additionally, the

time schedule of both institutions had to be congru-

ent. Although, the contacted institutions considered

student exchange as being of the utmost importance,

they either denied the proposal or could not meet the

criteria. As for the reasons stated, either project man-

agement was not their priority, time period and dura-

tion were not relevant, or project management was a

priority, but organization could not comply.

In July 2008, Prof. Laurini was invited to the TEC

were the colleagues of the Mexican chair were im-

mediately enthusiastic about his project ideas. As a

fruitful consequence, one student project topic was

selected, and two groups of France-Mexican students

were organized in order to work together from au-

tumn to winter 2008. The subject consisted in the

creation of a small information system for a tourism

ofﬁce based on Google mash-ups. As a follow up of

this experimentation, a ﬁrst post-mortem report was

compiled (Laurini and Sol., 2009), analyzing the dif-

ferent aspects encountered during the project execu-

tion in an international context. In addition, the two

partners jointly decided to extend the NEREID course

in terms of academic partners and number of student

projects facing the upcoming year 2009.

In this paper, we now document and reﬂect the

experiences when teaching GSE during the winter

term 2009/10. In detail, we describe the general ap-

proach being taken by the ﬁve universities as well

as the students including roles and deliverables (Sec-

tion 2), the ﬁnal outcome and experience students

made within three projects (Section 3), and the ex-

Institute National des Sciences Appliqu

ees de Lyon (INSA) is

a very international-oriented institution with more than 25% of its

students being from foreign countries. Moreover, 75% of INSA de

Lyon students are spending one or two semesters abroad.

CSEDU 2011 - 3rd International Conference on Computer Supported Education

perience as well as lessons learned from a teaching

staff’s perspective (Section 4). In doing so, our re-

sults are grounded in the experience we as the teach-

ers made when interacting with the participants as

well as in the information we gained when conduct-

ing four semi-structured interviews with students in-

volved in projects Technische Universit

at M

unchen

(TUM) were tutoring. Having taught GSE to 43 stu-

dents organized in nine different software teams dur-

ing a time span of 4 months, our main goal is to in-

spire the reader how to teach GSE in an academic con-

text. More precisely, we attempt to help teaching staff

to plan, implement, and guide software engineering

projects realized by globally distributed teams who

are compelled to use a communication language other

than their mother tongue.

2 AN APPROACH TO TEACH

GLOBAL SOFTWARE

ENGINEERING

This section delineates the approach which was ap-

plied when carrying out the NEREID course. It orig-

inates from the ﬁrst cooperation between France and

Mexico in 2008 and was reﬁned before the second it-

eration of the course started in October 2009. Fig-

ure 1 illustrates the main phases and their duration by

distinguishing between course preparation, execution,

and post processing stage. Since the NEREID coop-

eration involved universities’ teaching staff as well

as students, a differentiation between both groups

is made through the two gray horizontally aligned

rounded rectangles. In the following, each phase’s

main activities are explained.

2.1 Introduce & Coordinate

The preliminary phase consisted of two main activi-

ties: ﬁrst of all, the participating universities had to be

selected. Afterwards, those members agreed on how

to put the NEREID course into practice during a kick-

off meeting. Since NEREID initially was launched

by Prof. Laurini from INSA de Lyon the acquisi-

tion and the selection of the participating universities

were managed by him and his colleagues. In June

2009, he announced that the members for the win-

ter semester 2009/10 consisted of the ﬁve institutions

(cf. Section 1). After the participants had been identi-

ﬁed, a kick-off meeting was summoned. Date, means

of communication, and the agenda of this initial meet-

ing were mainly arranged through e-mail exchange.

As communication device, an IP-videotelephony sys-

tem was used being available at all universities. The

two-hour meeting was held in English, the professors

and all respective research assistants were participat-

ing. Its main purpose was to get to know all members

and to discuss the boundary conditions for the second

iteration of NEREID course. In addition, mutual trust

and rapport was build on a teaching staff level.

The overall course goal was to allow student teams

to work conjointly on distinct software engineering

projects in order to improve their project management

and communication skills taking differences in geo-

graphical location, academic curriculum, and culture

into account. Less focus was put on technical experi-

ence and tooling skills students would gain through

the implementation of the assigned projects. All

academic institutions agreed that participating stu-

dents would start without any introductory lectures.

Hence, no speciﬁc project management and coopera-

tion methods or models were taught in beforehand.

It was up to each single member to ﬁt the course

in the individual degree program and grading scheme.

For instance, each institution independently deter-

mined the type of the course (e.g. seminar, in-

ternship), the credit points which could be achieved

(e.g. four credit points regarding the European Credit

Transfer System ECTS), as well as the experience and

knowledge representing prerequisites for a participa-

tion in the course (e.g. attended software engineering

lecture, language classes, project management).

All members settled on that the student teams had

to consist of 4-6 students who were enrolled in com-

puter science and business informatics at their corre-

sponding university. The set of team participants had

to originate from 2-3 nations differing in their ﬁrst

languages which made communication in a foreign

language inevitable. In terms of workload, ten hours

per week were estimated by the members, hence 100-

120 hours would be accumulated by each student tak-

ing three month project time as a basis. The univer-

sities agreed that each individual project topic would

be addressed by one student team only.

Due to its world-wide acceptance in terms of writ-

ten and spoken communication, English was cho-

sen as the ofﬁcial project language, for both the or-

ganizing members as well as the participating stu-

dents. Since none of the members came from an An-

glophobe country, each participant was equally chal-

lenged in speaking a foreign language. Regarding

communication devices, no explicit directives were

stated in advance. This allowed the teaching staff and

students to take advantage of a broad lineup of com-

munication devices ranging from simple e-mail and

phone calls to more sophisticated video and web con-

ference solutions.

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT -

Experiences and Lessons Learned from Four Academic Projects

Students

Universities

Introduce &

coordinate

Define

projects

Finalize

preparation

Guide &

assess

Evaluate

results

Conduct

project

Two weeks

Preparation

(six weeks)

Execution

(three month)

Post processing

(two weeks)

Three month

Two weeks

Reflect

course

Select

project

Figure 1: NEREID course execution stages

Regarding the different project roles following

distinctions were made

Project Sponsor: The project sponsor initiated

the project by proposing a speciﬁc topic one stu-

dent team would work on. During the execution, the

sponsor played the role of a local or remote busi-

ness customer, hence formulated functional and non-

functional requirements considering the software en-

gineering product. He or she was also in charge of

validating the ﬁnal outcome from a customer perspec-

tive. In most cases the role of the sponsor was ﬁlled by

a professor of the participating academic institutions.

If local students were involved in the fulﬁllment of

the project, the sponsor could simultaneously act as

the supervising tutor.

Supervising Tutor: Once students enrolled in a

software engineering project, they were automatically

assigned to at least one local supervising tutor who

was appointed by each university in beforehand. The

tutor’s role was to assist the students not only for tech-

nical issues with regards to the results and the com-

munication means, but also help them to overcome

organizational obstacles. Even if the local supervis-

ing tutor often did not know the desired project out-

come in detail, he or she was able to provide help-

ful support considering general project management

techniques as well as the concerned deliverables. In

addition to escalate objections raised by the local stu-

dents to other tutors or to the project sponsor, the local

supervising tutor was also responsible for evaluating

the students he was looking after.

Student Project Lead: Directly at the start of

each project, all student teams had to appoint one

The term local refers to roles whose assigned persons are

working at the same place, hence may have physical contact to

each other. For instance, for a student the local supervising tutor

represents the tutor who is available on-site, thus at the same insti-

tution. In the contrary, remote indicates that the person playing a

speciﬁc role can be only communicated to by using telecommuni-

cation equipment.

project lead who was responsible for classical project

management tasks. In particular, he or she organized

the internal team and external presentation meetings,

assigned different project activities to the team mem-

bers, and kept track of the achievement of the overall

project goals. Furthermore, the student project lead

represented the single point of contact to the project

sponsor by being in regular discussion with regards

to the system’s functional and non-functional require-

ments. Steering the team through the course of the

project in addition to interacting with the customer,

made the lead a pivotal but also a tough role.

Student Project Member: As mentioned, ev-

ery student team consisted of 4-6 students who con-

jointly worked on the software project. The individual

student role within this team was determined inter-

nally by each group regardless of the project spon-

sor and supervising tutor. The spectrum of duties

ranged from quality, design, testing, communication,

etc. tasks and was mostly contingent on the experi-

ence and know-how the respective student could con-

tribute. Each student was assigned to a local super-

vising tutor who could aid with the project work and

approved the student’s overall performance expressed

in participation and deliverables.

Another item discussed by the teaching staff mem-

bers consisted in a common web page (NEREID-

Page, ) enabled by a Wiki (infoAsset, ) in order to

generate a form of corporate feeling. Besides a pre-

sentation of all participating universities, this site also

contained a short description of each student project.

For further information considering a speciﬁc project,

every member was in charge of providing details on

their local web site. It was also intended that the

common Wiki would serve as registration platform

where students could express their interest in a cer-

tain project while sharing their main contact informa-

tion. In this vein, the Wiki would facilitate compo-

sition and initial contact of the team in advance. Fi-

nally, all members were asked to contribute at least

one relevant software engineering project during a

CSEDU 2011 - 3rd International Conference on Computer Supported Education

time frame of two weeks. After this phase, a syn-

chronization meeting was scheduled by applying IP-

videotelephony again.

Regarding the output, the members decided on

subsequent software development artifacts every stu-

dent team had to provide during the individual project.

Each deliverable had to be written and presented in

English language, all students were urged to con-

tribute equally to the ﬁnal outcome. The results were

submitted to the local tutor, who either reviewed them

in case of a document or attended them as for oral pre-

sentations. With respect to the deliverables, all stu-

dent teams had to provide the following items:

Initial presentation: During a period of 10 mi-

nutes, each team presented the general project content

in addition to a project plan and anticipated risks. Af-

terwards, a 5 minutes question & answer section was

held allowing the audience and speakers to discuss.

Final presentation: Students had 10 minutes to

present their project as well as the lessons learned. 5

minutes were reserved for a short live demonstration

of the main results complemented by another discus-

sion round.

Final report: At the end, each student team was

obliged to compile a report composed of approxi-

mately 10-15 pages. The document summarized their

problem and context, the approach which was taken,

lessons learned, as well as possible future work. On

the one hand, the report served as a speciﬁcation by

delineating the solution which was implemented by

the students. On the other hand, it also contained per-

sonal experience and suggestions for developing soft-

ware in international teams.

In terms of the initial and ﬁnal presentation, lo-

cal talks only including the students of the tutoring

university were preferred by the supervising tutors as

well as the respective project team members. This

was mainly caused by organizational and technical

issues, i.e. time differences coupled with problems

considering video communication making it difﬁcult

to gather all stakeholders working on the speciﬁc

project.

2.2 Deﬁne Projects

The main activity in this phase was to propose and

to decide on the different project topics based on the

agreements and general project conditions elaborated

during the kick-off meeting. Thereby, all topics were

restricted to software engineering tasks related to the

current research focus of the universities by targeting

at late bachelor and master students. The complex-

ity of the projects where adequately adjusted, bear-

ing in mind the time constraint of three months all

student teams were exposed to. In case of the spe-

ciﬁc work packages, all proposals consisted of the

implementation or enhancement of a software sys-

tem, however there was no overlapping in terms of

speciﬁc project content. The respective sponsor com-

posed a general project description in addition to a

requirement speciﬁcation containing must as well as

nice-to-have requirements serving as a foundation for

the teams. Concluding, the project descriptions were

published in the Wiki and a second synchronization

meeting among the universities was scheduled.

2.3 Finalize Preparation

Main goal of the synchronization meeting as part of

the ﬁnalization phase was the presentation of the ﬁ-

nal project topics in addition to their start and end

dates. In mid-September 2009, a IP-videotelephony

system was set up as means of communication allow-

ing all universities to participate. Due to the differ-

ent semester schedules, the members decided to start

the projects independently from each other. Hence,

once enough students were registered for a speciﬁc

project matching the criteria agreed upon in the pre-

liminary phase, the team could get down to business.

For the registration process, students were asked to

make use of the project speciﬁc Wiki page. Further-

more, e-mails between the teaching staff were ex-

changed since not all universities took advantage of

the Wiki.

In addition to the above mentioned activities, pre-

liminary discussions were hosted at the particular uni-

versities addressing students who were interested in

the NEREID project. The 30 minutes meeting took

place at the beginning of the semester and provided

a quick rundown of the course. Besides the general

course of action and required deliverables, the differ-

ent software engineering projects were presented. Af-

ter the audience got familiar with the multiple topics

and related questions were answered on the part of the

teachers, a ﬁrst allocation of students to the projects

was carried out. In this process, students had the free-

dom to select the topic of their choice.

2.4 Guide & Assess

When the preparation phase was ﬁnished at the end

of September 2009, universities could pass over to

supervise the different projects which were now ex-

ecuted by the student teams. Since students did not

attend any preparative lecture sessions in advance,

strong support by the supervising tutors as well as a

close cooperation with the project sponsor were in-

dispensable throughout the project’s implementation

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT -

Experiences and Lessons Learned from Four Academic Projects

phase. As depicted in Figure 2, universities undertook

the execution of three parallel activities all serving to

guide and assess the different student teams.

An initial kick-off meeting was held by the project

sponsor which was destined for all student team mem-

bers and targeted at building trust as well as rap-

port among the participants. During this meeting, the

sponsor presented a more detailed project description

including the overall context, a technical description

(e.g. speciﬁcation, architecture, technology) in addi-

tion to further organizational information (e.g. links

to the website, e-mail addresses). The main activities

of this phase were instantiated in the following man-

ner:

Evaluate Results: Each software engineering ar-

tifact delivered by a student team was assessed by

taking advantage of a simple spreadsheet. In this

sheet, supervising tutors made note of strong points

and ﬂaws considering the speciﬁc deliverable as well

as the way latter was presented also by distinguish-

ing between the different team members. Thereby,

the evaluation of the ﬁnal report was part of the post

processing stage. Besides, a continuous assessment

based on student-tutor interaction took place. The

overall assessment of the student teams also includes

an evaluation of the source code (quality of the im-

plementation, functional test) and recommendations

of the partner universities. A second activity of this

phase consisted in the evaluation of the overall course.

In addition to the feedback given by the local students

all members of the participating universities shared

their experience and lessons learned within a 60 min-

utes long ﬁnal IP-videotelephony session.

Tutoring and Organize: Supervising tutors not

only provided technical help in introducing and ex-

plaining different software engineering technologies

to the student teams, they also made recommenda-

tions with respect to organizational issues and deliv-

erables. For instance, this comprised suggestions for

presentation and ﬁnal report structure, hints regarding

escalation paths in case of team-internal problems,

and resolving of project obstacles which could orig-

inate from a lack of team coherence.

Deﬁne and Validate System Requirements: Af-

ter presenting the project topic during the kick-off

meeting, the project sponsor monitored the overall

progress with regards to the afore speciﬁed require-

ments and constraints. In doing so, the sponsor

also validated the deliverables and checked the source

code against the initial demands. Furthermore, ques-

tions raised by the students considering the system

were clariﬁed.

2.5 Conduct Project

After the organizational preparation was performed

by the universities, the students were able to tackle

their speciﬁc software engineering project within the

given time frame of three months. The execution

phase (Figure 2) was subdivided into four distinct ac-

tivities. Final outcome of each activity was the deliv-

erable as mentioned above.

Prepare: Right after the projects have been as-

signed, the student teams started to get familiar with

the other team members as well as the overall project

topic and constraints. Furthermore, they deﬁned the

internal project organization including roles and re-

sponsibilities, set up a project plan, and identiﬁed

work packages. Afterwards they distributed these

packages among the members and prepared the initial

presentation representing the ﬁrst deliverable, which

was discussed together with the local supervising tu-

tors during the initial talk.

Design & Implement: In the core working phase

the student teams had a total of seven weeks for sys-

tem design and implementation. Besides, other soft-

ware engineering tasks e.g. testing, documentation

as described in (Rausch and Broy, 2008) were exe-

cuted. Each team proposed a system design based

on the project sponsor’s requirements complemented

by the results of the initial presentation. This design

was discussed and double-checked during the syn-

chronization meeting (cf. Subsection 2.1) in the pres-

ence of the local supervising tutors. After the design

was approved, students independently implemented

the working packages and integrated them in a sub-

sequent step. After the test cases were carried out, the

overall results were incorporated in the ﬁnal presenta-

tion which was held at the end of the implementation

phase.

Compose & Summarize: Finally, a time frame of

three weeks was scheduled enabling the student teams

to write their ﬁnal report. In order to facilitate the

writing and enhance the quality of the deliverables,

students had the possibility to send in their intermedi-

ate report. This draft was reviewed by the local tutor

and potential suggestions for improvement were com-

monly discussed during a short meeting at the chair.

After the ﬁnal version of the report was submitted, the

students received their ﬁnal grade based on the evalu-

ation criteria as explained in Subsection 2.4.

2.6 Reﬂect Course

To improve the quality of future courses the 43 stu-

dents could voluntarily provide feedback during 20

minutes long interview sessions together with the lo-

CSEDU 2011 - 3rd International Conference on Computer Supported Education

Students

Universities

Initial

presentation

Synchronization

presentation

Final ReportFinal

presentation

Kick off presentation

Prepare

Advise & organize

Define & validate system requirements

Evaluate

Two weeks

Three weeks Four weeks Three weeks

Design Implement

Compose &

summarize

Evaluation I Evaluation III

EvaluateEvaluate

Evaluation II

Execution

(three month)

Figure 2: Execution stage details.

cal supervising tutors.

3 THE STUDENT PROJECTS

In the following, we describe three selected student

projects conducted in the NEREID course. To cap-

ture the experiences and lessons learned, we carried

out semi-structured interviews with the student teams

from TUM, after the projects were completed and

evaluated. Hence, the statements in this Section re-

ﬂect the perspective of the student teams and the col-

laboration between them.

3.1 Project 1: University Foreign

Relations Map

Project 1 aimed at developing a web application to

graphically display partner university relationships.

The application should make it easier for students

to ﬁnd partner universities and compare possible ex-

change partners. The scope included displaying an

university relations map as an overview of partner

universities, basic administration capabilities to edit

university relationship data as well as provisioning of

an online forum for communication between students

and uploading experience reports.

The project team consisted of students of three

sites with two students from each location: INSA

de Lyon, TUM, and UE. The latter was the initiator

of the project thus also the site of the project spon-

sor. Project 1 had a student project lead from the

project sponsor site who was appointed already be-

fore the project was started and had a close contact to

the project sponsor. The worksplit was deﬁned by the

lead, the development tasks were separated by subsys-

tems: The responsibility for the web page was at UE,

the online forum was assigned to INSA de Lyon and

the database development was the task of the team at

TUM. The requirements for the project were provided

by the project sponsor at UE. All communication with

the project sponsor was handled by the project lead at

UE; there was no direct communication between the

team at TUM and the project sponsor. For project

communication, weekly phone calls were scheduled,

however, due to different reasons, the project team

was never fully present at these meetings. Later, e-

mail communication was used instead. The team at

TUM experienced long delays to receive an answer to

e-mails – sometimes up to one week. Another issue

of distribution was the access to the web server at UE,

as the team at TUM developing the database had no

direct access to the server and always needed to go via

the team in UE.

A major problem occurred with the INSA de Lyon

student site, which was responsible for the online fo-

rum. According to the TUM, there was low involve-

ment from the INSA de Lyon team and they were

most of the time arguing why they cannot proceed.

The TUM team kept sending e-mails to the project

lead and asked for an escalation. However, the prob-

lem was not solved. At the very end of the project,

the INSA de Lyon team posted rudimentary code for

an online forum as their contribution, but it was not

integrated with the overall system and therefore not

usable. The TUM student team felt annoyed about

their student colleagues at INSA de Lyon.

The student team at TUM reported in the inter-

view that they saw there were different motivations of

the sites involved. In particular the team at UE treated

the project lightly. When there were discussions about

problems with the project lead, he referred to clarify-

ing all issues with his professor in a personal and in-

formal way. According to the TUM team, there was

no formal ﬁnal presentation at UE, but only an infor-

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT -

Experiences and Lessons Learned from Four Academic Projects

mal meeting with the professor, and the project report

of the TUM team was used instead of writing an own

report.

3.2 Project 2: Picture-based Itineraries

Task of project 2 was to develop a picture-based nav-

igation system for pedestrians. While existing navi-

gation systems usually use street names and a map to

explain the route, many pedestrian ways do not have

names. Therefore the goal of this project was to create

a system which uses pictures augmented with arrows

to explain the route, e.g. view of a crossroad where

one needs to turn left.

The project team involved students from three

sites in three countries – INSA de Lyon, TUM, and

USM – with two students at each site

. The super-

vising professor of the INSA de Lyon site was in the

role of the project sponsor. The student team felt there

was a great latitude with respect to the requirements,

as only high level requirements were given. The stu-

dents organized weekly meetings to exchange on the

current status and to make upcoming decisions. The

team split their work according to subsystems to min-

imize the need for communication: the server part

was taken by the INSA de Lyon team, the client part

was chosen by the TUM team, and the navigation ar-

rows were assigned to the USM team. In contrast to

project 1, this project had no explicitly appointed stu-

dent project lead. While a student from the INSA

de Lyon team suggested himself in his ﬁrst e-mail

as project lead, the TUM team answered the decision

should be deferred to the ﬁrst meeting, where the team

members get introduced to each other. Later at the

meeting, no decision was taken. As the project task

originated from INSA de Lyon, they gave an overview

of the high level requirements during the ﬁrst meeting.

As many aspects of the task were still underspeciﬁed,

the INSA de Lyon team took over the responsibility to

further clarify the requirements and provide a speciﬁ-

cation.

Communication was arranged in weekly meetings

and exchange of e-mails. While the ﬁrst meetings had

no pre-deﬁned agenda, the meetings became more

structured over time. Chat was used as communi-

cation medium as the available network bandwidth

was not sufﬁcient for voice-over-IP or video commu-

nication. The team reported that they made good ex-

periences using this mean, as it allowed for a well-

regulated communication.

A second team consisting of students from INSA de Lyon and

TEC has been working on the same project. However, only the

interview statements of the team in which students from the TUM

were involved are reﬂected in this article

From the beginning of the project, there were prob-

lems in the cooperation with the team in USM. The

students from USM did not attend the ﬁrst meeting,

as they “totally forgot the meeting date”. This lead

to additional effort, as the information provided and

the decisions made needed to be re-discussed with the

USM team. The TUM team did not escalate the prob-

lem in order not to squeal on their colleagues, only

some e-mails were exchanged within the team. There

was no contribution from the USM team visible until

two days before the ﬁnal presentation: A code deliv-

ery was provided on December 20th, which was not

integrated and therefore not working at the ﬁnal pre-

sentation. Also there were problems with the time

synchronization between the three locations. While

the TUM team had to give its ﬁnal presentation and

demonstration of the system on December 22nd, the

INSA de Lyon team went already on holiday from

December 19th, so it nearly happened that the server

needed for the demonstration was not available. For-

tunately, the INSA de Lyon team could run the server

during their holiday from the students’ hall of resi-

dence.

3.3 Project 3: Cadaster System

Project 3 focused on developing a system which uses

geographical data of the cadaster system of Puebla

(Mexico) to map articles to speciﬁc geographic loca-

tions. Users should be able to visualize, create and

modify articles related to a speciﬁc reference point on

the map.

In the project team were three students from TEC,

two from INSA de Lyon and one student from TUM.

The topic was deﬁned by the supervising professor

from TEC who acted as project sponsor. A high level

requirements speciﬁcation was already existent at the

project beginning. Project 3 had a student project lead

from TEC who was designated before the project ac-

tually started. The team members jointly organized

the distribution of work. They decided to have a func-

tional worksplit across locations: One member of the

INSA de Lyon team was responsible for organizing

meetings (e.g. invitation and agenda) and the docu-

mentation (e.g. meeting minutes). TEC was account-

able for the conversation and clariﬁcations with re-

spect to the requirements. The student from TUM

took over the role of the technical implementation

and integration as lead developer. Thereby, each site

was in charge for a part of the system. Furthermore,

for each location the team deﬁned one so-called team

manager who acted as the single point of contact in

case of problems or bug reports with the part of the

system, for which the site was responsible. The team

CSEDU 2011 - 3rd International Conference on Computer Supported Education

had weekly meetings, including both one video con-

ference meeting for organizational issues and status

reports and one chat for technical clariﬁcations. As

and when required, the frequency of meetings was in-

creased. The supervising professor from TEC who

was in the project sponsor role occasionally partici-

pated in the video conferences. Overall the collabora-

tion went well, although it was noticed that there are

cultural differences between the countries: the team

in TEC was perceived to be more relaxed, while the

student colleagues at INSA de Lyon sometimes ex-

pressed their concerns when progress was not as fast

as they wanted. The team had to bear the time dif-

ference in mind, which was 7 hours, but it was not

a serious problem as there was a sufﬁcient overlap

in work time of Mexico and Europe and they could

agree on time slots for the meetings, where all sites

were available. Sometimes it was challenging to ﬁnd

a date for the video conference, as it was difﬁcult for

both the INSA de Lyon and the TEC team to get a

video conference room due to limited resources. One

major issue occurred with respect to understanding

of the requirements: The Europeans and the Mexican

students had different imaginations of a cadaster sys-

tem: While the students at INSA de Lyon and TUM

assumed that they need to implement a cadaster sys-

tem with legal registers – as known in Europe –, the

Mexican expected to build a system with a simple ge-

ographical map. As the team members detected that

they have different domain knowledge, they were able

to resolve this issue.

3.4 Experience and Feedback

Altogether, the problems encountered by the teams

very well reﬂect real-life issues, in particular commu-

nication problems as well as technical, organizational,

and people aspects (Lescher et al., 2009). Due to

the geographic and organizational separation, the stu-

dents perceived themselves being in local sub-teams

instead of one global team. In critical situations this

resulted in a characteristic “us” versus “them” atti-

tude. However, all of the NEREID projects were ﬁ-

nally able to present good results and made an impor-

tant learning experience. Being asked for their lessons

learned and their feedback towards the seminar, the

students mentioned the following points:

Separation by Subsystems: The modular archi-

tecture and separation by subsystems has proven well,

as it reduces complexity and communication needed

across sites. Project tasks should be deﬁned in such a

way, that a modular separation is possible.

Harmonize Deliverables and Schedule: It was

suggested by the students to better harmonize the de-

liverables and the schedule of the projects. In par-

ticular, the dates and the format for the ﬁnal presen-

tation and the ﬁnal report along with the evaluation

criteria should be established in an unique way for all

involved locations.

Joint Kick-off Meeting: The students suggested

to have a joint kick-off meeting with all involved sites

and also with the project sponsor in the role of the

customer. Actually, the sponsor was only available

during the ﬁnal presentation. It would improve un-

derstanding and morale, if this customer contact could

happen already at the kick-off meeting. Instead of a

kick-off meeting at the very beginning of the project,

this could be also organized as a milestone meeting

after 1-2 weeks of the project. This would allow for

a more funded clariﬁcation of open questions, as the

students already had the chance to get into the matter

of their project.

Escalation Path: A clearly deﬁned escalation

path would help the students to deal with problems

which are outside of their responsibility. The current

experience has shown that the students are reluctant to

run down their colleagues in front of their supervising

professor.

All teams interviewed emphasized that the project

was a very valuable learning experience for them, par-

ticularly on aspects that “cannot be learned by just lis-

tening to lectures.”

4 LESSONS LEARNED

AND RECOMMENDATIONS

This section points out major lessons learned of the

universities acting in both roles: as supervising tutor

for the three projects presented in Section 3 and as

project sponsor. At the same time, recommendations

for future GSE courses in academia are provided sub-

stantiated by a short explanation.

Generally, we suggest that all universities agree

upon the three presented deliverables. Not only

project’s performance can be compared more easily

after every student team has to deliver the same re-

sults, standardized software engineering artifacts also

facilitate the composition of a common time sched-

ule which can be followed by the teams irrespective

the individual project topic. The time schedule should

be ready as early as possible (preferably two months

before semester start) allowing students to ﬁt in the

NEREID course in their other academic activities.

Furthermore, we consider a joint kick-off meeting in-

cluding at least all student team members, the project

sponsor, and possibly, all supervising tutors, as being

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT -

Experiences and Lessons Learned from Four Academic Projects

mandatory in order to eliminate initial difﬁculties en-

dangering the participants ambition and engagement.

Assigning 4-6 participants in total to a student

team involving 2-3 locations in which each loca-

tion provides exactly two students has been proven

to be successful throughout the four conducted GSE

projects. The limited size of the team induces the

team members to equally contribute to the project’s

success by simultaneously giving the tutors the pos-

sibility to personally advice and monitor each indi-

vidual student. While communication overhead and

project’s content complexity is reduced for students

and supervising tutors, the project sponsor only needs

to keep track of a very limited project scope of 4-6

engineers working for three months on a prior deﬁned

outcome. Regarding deviating interests on team and

on location level (therefore students from one loca-

tion pursue a goal which differs from the overall team

goal) we propose that all involved sponsors and tutors

consistently state the main objective right at the be-

ginning and commonly evaluate the entire team per-

formance against the actual achievement of this ob-

jective.

When it comes to the project content, we rec-

ommend to closely link a project sponsor’s focus

of research with the proposed topic. Not only the

professor in charge would be acquainted with the

project’s underlying body of knowledge, the spon-

sor would also have an increased interest carrying

out this project since latter’s successful ﬁnalization

may positively contribute to the chair’s research ac-

tivities. In addition, either the individual content or

the type of the project should ensure intensive com-

munication within each student team. For instance,

topics requiring a organizational divide & conquer

phase in order to split up and later on integrate the

different work packages are suitable since they entail

communication among the involved students. Fur-

thermore, projects with an explicit need for country-

speciﬁc knowledge and local information generate

cross-national exchange, too.

Regarding the speciﬁc target group, participants

should be at least in the 5th semester of their com-

puter science study program, hence late bachelors and

master students. On the one hand, those team mem-

bers are already familiar with elementary software

modeling and design techniques (e.g. UML, EPK,

Petri nets, and ER models), on the other hand those

participants were already in contact with functional

and object oriented programming languages almost

always required for the fulﬁllment of the implemen-

tation phase of a project. Being less engaged in the

well-known technical related aspect of a GSE project

would allow participants to focus on the organiza-

tional and communicative part of the course in more

detail.

Nevertheless, we do not deem extensive prepara-

tory classes taught before the actual project start as

an indispensable necessity. Tying in with the pre-

vious point, participants have been already taught

to work on software problems locally and therefore

the introductory courses would only convey knowl-

edge regarding project management with regards to

global distributed projects. In turn, we propose that

a short but crisp GSE overview session in advance

would help to make a start more smoothly for all ac-

tors by also saving planning and coordination time

for the students. This session, which could be cou-

pled with the kick-off meeting during the execution

phase, should also address escalation paths in the case

of team internal and external problems (e.g. deﬁnition

of project lead, team internal friction, lack of commu-

nication with the sponsor), thus whenever the team

cannot solve the issue autonomously.

Furthermore, we suggest to establish a common

evaluation scheme for all participating universities

making each student’s work transparent, comparable,

and traceable by generating a more objective picture

of the participant’s performance at the same time.

This scheme, which could be implemented through a

simple electronic spreadsheet with the columns rep-

resenting the three deliverables and rows depicting

the universities, is exchanged among all supervising

project tutors after the execution phase is ﬁnished.

Nevertheless, we deem important to keep organiza-

tional overhead low for the tutors. Hence, completing

the mentioned sheet should not take longer than 10-15

minutes for each project team and deliverable.

Not surprisingly, we noticed a higher communi-

cation and coordination overhead in comparison to

similar local courses when conducting the different

GSE projects. However, this increased engagement

was paid off by insights in research groups of foreign

countries as well as the international experience we

gained ourselves by carrying out those project. Being

in the role of the supervising tutors and the sponsor,

we learned how to organize, execute, and coordinate

distributed projects by interacting on a cross-country

level with different interest groups. We are satisﬁed

with the solid results delivered in the short amount of

time through the students in hoping to prepare them

for upcoming multi-cultural endeavors in the indus-

try. We are also conﬁdent, that besides academic ex-

change programs courses like ERASMUS, NEREID

will help future software engineers to succeed in an

increasing globalizing work environment. In addition

to foreign language mastering, industrial placement

in companies located in other countries and student

CSEDU 2011 - 3rd International Conference on Computer Supported Education

mobility, we propose and recommend to fully inte-

grate GSE and international project management in

their syllabi.

5 SUMMARY AND OUTLOOK

Presently, graduated software engineers receive ed-

ucation in technology and management. However

in the arising context of globalization, the interna-

tional dimension should be included. In this arti-

cle, we presented our experiences gained when offer-

ing global software engineering projects to university

students. We described the applied approach involv-

ing 43 participants at ﬁve distributed academic insti-

tutions, pointed out three concrete student projects

in detail, and presented the lessons learned and key

recommendations from the teaching staff and student

perspective. We are conﬁdent, that the introduced ap-

proach in combination with the suggestions will serve

as a solid foundation for similar GSE endeavors at

universities.

As the NEREID course was seen very success-

ful, we will re-offer it in upcoming winter semester

by taking the lessons learned into consideration. In

particular, the deliverables, the time schedule, and the

evaluation scheme will be harmonized across all uni-

versities and a clear escalation path for the students

will be set up. Furthermore, the set of partner univer-

sities will be extended by a South-Korean university.

More information on NEREID can be found on our

website:

http://wwwmatthes.in.tum.de/wikis/nereid/home

We express our gratitude to all universities taking

part in the NEREID course during the winter term

2009/10. We are looking forward to jointly organiz-

ing and hosting a second edition of the course next

winter.

REFERENCES

Carmel, E. (1999). Global Software Teams (High Perfor-

mance Cluster Computing). Prentice Hall.

Damian, D., Kwan, I., and Marczak, S. (2010).

Requirements-Driven Collaboration : Leveraging the

Invisible Relationships Between Requirements and

People, volume 2010, chapter 3. Springer-Verlag, Hei-

delberg, Germany, 1st edition.

Gotel, O., Kulkarni, V., Say, M., Scharff, C., and Sunet-

nanta, T. (2009). Quality Indicators on Global Soft-

ware Development Projects: Does “Getting to Know

You” Really Matter? In Proceedings of the IEEE In-

ternational Conference on Global Software Engineer-

ing (ICGSE’09).

Herbsleb, J. D. (2007). Global Software Engineering: The

Future of Socio-technical Coordination. In FOSE ’07:

2007 Future of Software Engineering, pages 188–198,

Washington, DC, USA. IEEE Computer Society.

Hofstede, G. and Hofstede, G. J. (2004). Cultures and Or-

ganizations – Software of the Mind: Intercultural Co-

operation and Its Importance for Survival. McGraw-

Hill.

infoAsset. Website. http://www.infoasset.de; visited on

March 7th 2010.

Laurini, R. and Sol., D. (2009). Post mortem report, assess-

ment of the ﬁrst experimentation of the nereid inter-

national project. page 5. INSA-Lyon, Tec de Monter-

rey/Campus de Puebla.

Lescher, C., Herbsleb, J. D., and Bass, M. (2007). Collab-

oration in Global Software Projects at Siemens: An

Experience Report. In Proceedings of the IEEE Inter-

national Conference on Global Software Engineering

(ICGSE’07).

Lescher, C., Herbsleb, J. D., and Bass, M. (2009). A

Coordination Risk Analysis Method for Multi-Site

Projects: Experience Report. In Proceedings of the

IEEE International Conference on Global Software

Engineering (ICGSE’09).

NEREID-Page. Website.

http://wwwmatthes.in.tum.de/wikis/nereid/home;

visited on March 26th 2010.

Rausch, A. and Broy, M. (2008). Das V-Modell XT : Grund-

lagen, Erfahrungen und Werkzeuge. dpunkt.verlag.

Sangwan, R., Mullick, N., and Paulish, D. J. (2006). Global

Software Development Handbook.

TEACHING GLOBAL SOFTWARE ENGINEERING AND INTERNATIONAL PROJECT MANAGEMENT -

Experiences and Lessons Learned from Four Academic Projects
