LEARNING FROM DEMONSTRATION

Automatic Generation of Extended Behavior Networks for Autonomous Robots

from an Expert’s Demonstration

Stefan Czarnetzki, S

oren Kerner and Patrick Szcypior

Robotics Research Institute, Section Information Technology, TU Dortmund University, 44221 Dortmund, Germany

Keywords:

Extended behavior networks, Learning, Demonstration.

Abstract:

The recent research focus on autonomous mobile robots has greatly improved their capability to perform

complex tasks, making it more and more difﬁcult to design eligible behavior manually. Therefore this paper

presents an algorithm to automatically derive a behavior network from demonstration by an expert. Different

tasks are evaluated to proof the generalizability and robustness of the proposed demonstration approach.

1 INTRODUCTION

Robotics commonly refers to behavior as deriving the

suitable motion from the current cognition to act pur-

posefully. Due to hardware improvements of mod-

ern autonomous robots the complexity of observa-

tions and possible actions is rising, leading obviously

to a higher behavior complexity. This places classical

methods of Artiﬁcial Intelligence at a disadvantage,

since the majority of these approaches try to reason

based on logic or knowledge bases. While the latter

would require an increasing amount of data and ex-

pert knowledge the same rise in complexity renders a

pure logical reasoning nearly impossible to handle for

mobile hardware. Thus the need for new solution to

design robotic behavior arises to scope with the new

ﬁelds of operation (see for instance (Arkin, 1999) and

(Brooks, 1990)). Being just one example, Behavior

Networks were proposed to develop a mechanism to

reliably select actions even in highly complex and dy-

namic environments, while still being intuitively com-

prehensible.

Developing behavior manually is sufﬁcient for

reasonable tasks but becomes more and more difﬁcult

with rising complexity. As a consequence application

of automatic learning techniques to robotics is ever-

more appealing. Behavior learning distinguishes be-

tween online and ofﬂine approaches. Although being

able to adapt behavior during execution would be very

desirable to react to errors, modern robotics hardware

lags the computational power to do so. Thus this pa-

per will limit itself to ofﬂine learning.

Those machine learning techniques can further be

roughly divided in classes of Supervised, Unsuper-

vised and Reinforcement learning. While all these

have in common that they try to generalize useful ac-

tions from a given database they differ in their applied

technique. Although all these strategies have been

successfully applied to different areas of robotics they

have a common disadvantage in this ﬁeld of applica-

tion. More or less all approaches try to reason useful

actions by letting the robot itself experiment. On the

one hand this is a rather time consuming process and

on the other hand is likely to result in the robot choos-

ing a bad action at one point over the course of time.

While some might just result in a worse result of the

tasks, some of these actions might be harmful to the

hardware of the robot. To prevent such actions before-

hand it’s desirable to combine robotic machine learn-

ing with human interaction, not just by supervision of

the process but also by learning from demonstration.

Section 2 gives a summary over extensions to the

mentioned Behavior Networks providing the funda-

mental algorithms of this paper. In the following sec-

tion 3 further methods to enable the behavior to be

derived from human demonstration are presented and

experimentally tested and evaluated in section 4.

2 EXTENDED BEHAVIOR

NETWORKS

This section gives a brief overview of Behavior Net-

works which were ﬁrst introduced by Maes in (Maes,

1989) and Extended Behavior Networks as in (Pinto

394

Czarnetzki S., Kerner S. and Szcypior P..

LEARNING FROM DEMONSTRATION - Automatic Generation of Extended Behavior Networks for Autonomous Robots from an Expert’s Demonstration.

DOI: 10.5220/0003184503940400

In Proceedings of the 3rd International Conference on Agents and Artiﬁcial Intelligence (ICAART-2011), pages 394-400

ISBN: 978-989-8425-40-9

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

and Alvares, 2005) or (Dorer, 2010).

Behavior networks deﬁne a representation of the

robot’s knowledge about its interaction with the

world. For given objectives this allows a rational

choice of an appropriate action. This knowledge base

is given in form of a network where each node ex-

presses a certain competence M or goal G. A com-

petence represents the knowledge about an action, i.e.

which change in the current world state is expected

by performing the action and which prerequisites are

required for the action to be executed.

Extended Behavior Networks are a means to carry

out behavior selection in dynamic and continuous do-

mains. Goals are explicitly situation-dependent. They

also allow parallel execution of actions by explicitly

modeling a set of resources R. Actions using disjoint

subsets of resources consequently do not conﬂict. The

resulting behavior network is given by (G, M, R, Π)

with Π being a set of parameters and the directed

graph N = (G∪M, K

, K

−

). The nodes are connected

by activating and inhibiting links, K

and K

−

, respec-

tively, according to their prerequisites and expected

consequences. The latter are originally described us-

ing boolean variables: a set of variables which need

to be true as prerequisites, and two lists for the con-

sequences, one for variables expected to become true

and one for those expected to become false. An acti-

vating link exists from a node x

to node x

if a pre-

requisite of x

will be fulﬁlled by the execution of x

Inhibiting links exist for the reverse case.

2.1 Network Deﬁnition

The description of the robot’s surrounding world us-

ing only “crisp” boolean logic however is insufﬁcient

for more complex real-world scenarios. Robot per-

ception and world modeling usually involves real val-

ues of positions and directions with varying uncer-

tainties. For the purpose of a more appropriate world

state representation while keeping close to classical

behavior network speciﬁcation a restricted fuzzy log-

ical system is employed in the presented approach.

Let P be the set of all statements and S the set of all

possible world states, then

τ : P × S → [0, 1] (1)

assigns truth values between 0 and 1 to statements for

a current world state estimation. In the following a

multi-valued logic L = (P, ¬, ∧) is deﬁned. The nega-

tion of a statement p ∈ P for a world state estimation

s ∈ S is given by equation 2.

τ(¬p, s) = 1 − τ(p, s) (2)

The conjunction of statements is given by the operator

∧ and equation 3, where  may be any T-conorm.

τ(p

∧ p

, s) = τ(p

, s)  τ(p

, s) (3)

In the following  is chosen to be T

min

(a, b) =

min(a, b) which fulﬁlls the necessary properties for

a T-conorm.

The robot’s objectives are given in form of goal

nodes G. Those consist of a world state t to be

achieved and a static and dynamic relevance. t is ex-

pressed in L and handled equivalently to the prerequi-

sites of competence modules concerning the linkages

of the extended behavior network. The static rele-

vance i ∈]0, 1] adjusts the overall importance of the

objective. The dynamic relevance rel depends on the

current world state, i.e. the goal only becomes impor-

tant for a truth value above zero for a certain statement

speciﬁed in L.

As mentioned above, the set of competence mod-

ules M represents the robot’s knowledge enabling it

to employ rational behavior. Each competence mod-

ule is made up of an action b ∈ B, a prerequisite c

expressed in L that must be true for the action to be

executable, a set Res ⊆ R of needed resources, a set

E of effect pairs and an activation value a. An effect

pair (e f f , ex) consists of a statement e f f ∈ P and the

probability ex = P(e f f |c) of e f f coming true after

execution. A competence is therefore executable if c

is true, all resources Res are available and the activa-

tion value a is at least as big as the biggest activation

threshold of all necessary resources.

Edges in a behavior network express relations be-

tween nodes which inﬂuence each other. Each ef-

fect of a competence module x

causes relations to

all other nodes x

whose prerequisite c includes the

statement e f f . If the signs of e f f in c and the effect

match, then there is an activating link from x

to x

Otherwise the edge is an inhibiting link.

Finally there is the tuple Π = (β, γ, δ, θ, Θ) of pa-

rameters controlling activity distribution, propagation

and thresholds. β ∈ [0, 1[ controls the inertia of com-

petence modules, i.e. the trade-off between reactivity

and robustness determining how long activated com-

petence modules are staying active. γ, δ ∈ [0, 1[ de-

termine global weights for activating and inhibiting

links, respectively. θ ∈]0, ˆa] is the maximum activa-

tion threshold used as an initial value for activation

thresholds of resources with ˆa =

|G|

1−β

as the maximum

possible activation of a competence module. Θ ∈]0, 1[

controls the reduction of activation thresholds per it-

eration. Both θ and Θ control how much “foresight”

the robot employs when choosing its action. This will

be described more detailed in the next section.

LEARNING FROM DEMONSTRATION - Automatic Generation of Extended Behavior Networks for Autonomous

Robots from an Expert's Demonstration

395

2.2 Activation Distribution and Action

Decision

Using an extended behavior network an autonomous

agent can choose actions evaluating the maximum ex-

pected beneﬁt based on the current situation and a set

of objectives. The normalized beneﬁt of each goal is

assigned by

u(rel, i) = (τ(rel, s) · i)

(4)

with a parameter p ∈]0, 1] controlling the agents

readiness to take chances. Choosing p =

con-

forms to action decisions based on rational choice

theory. p >

results in more risky decisions while

p <

tends to more conservative decisions according

to (Dorer, 2010).

In contrast to the Behavior Networks originally

proposed by Maes (Maes, 1989) activation potential

only originates from goal nodes ensuring a decision

process based only on expected beneﬁt. A compe-

tence module receives activation from a goal if one of

its effects match a precondition of this goal and both

statements have the same sign, i.e. both are atoms

or both are negated atoms. A competence is inhib-

ited if exactly one of the atoms is negated. The same

holds for activating and inhibiting links between com-

petence modules, but dependent on the precondition’s

truth value: the less a precondition is satisﬁed, the

more activation is spread to modules which are ex-

pected to make this precondition come true. Thus un-

satisﬁed preconditions of modules with high activa-

tion values become increasingly demanding subgoals

themselves. For a detailed description of the func-

tions deﬁning the activation propagation see (Dorer,

1999). For each module the activation values from

different goals are calculated separately and only the

highest absolute maximum activation a

from acti-

vating and inhibiting links is taken into account, i.e.

following only the strongest path. The ﬁnal activation

of a module m

at time t is

= β · a

t−1

∑

. (5)

The action selection is done by iteratively prop-

agating activation through the behavior network, a

function h(a

, e

) combines the module’s activation

and its executability e

= τ(d

, s), and decreas-

ing all θ

by Θ until h(a

, e

) is big enough for a

competence module to claim the resources and be ex-

ecuted, in which case the θ

are reset for the next time

step’s action selection.

3 LEARNING BY

DEMONSTRATION

This section presents the behavior learning of au-

tonomous agents from an expert’s demonstrations by

means of automatic generation of an parametrized ex-

tended behavior network out of recorded demonstra-

tion data. An expert needs to demonstrate the correct

behavior for a variety of situations so that the pro-

cess of learning can be able to generalize. This has

to be done for every objective separately. The deduc-

tion of goals themselves from demonstrated behavior

is not covered here. Likewise the difﬁculty of map-

ping effects to one of several parallel executed actions

is neglected here by only allowing one action at a time

to be executed by the expert remotely controlling the

agent.

The demonstration result is several sequences of

demonstration pairs d

= (l

, b

) ∈ D of current world

states l

and behavior choices b

. l

is a statement in

L made up of the atoms with the biggest acceptance

value τ(p

, s

) for each perception.

= p

∧ ··· ∧ p

(6)

The effects of an action must be estimated using a

transition function

T (l

, b

) = z

(7)

to ﬁnd the earliest state l

t+i

with i > 0 where l

 l

t+i

Note that due to the multi-valued logic of L this

change just needs to an change in a truth value big-

ger than a certain threshold.

In the following the direct transformation of those

demonstration pairs to competence modules will be

described. Then induction will be introduced as a

matter of generalization and decision trees will be

used as an intermediate step for the ﬁnal knowledge

representation. Finally an approach is presented to

derive an extended behavior network from decision

trees and a set of demonstration pairs.

The trivial approach to generate a behavior net-

work out of the set of demonstration pairs is to create

a new competence module for each occurrence of a

new combination of precondition and action choice.

An effect can be assigned using the transformation

function of equation 7 assuming total conﬁdence into

this effect since no knowledge about its probability is

available at this point. Note that due to the described

choice of l

it does not contain all atoms of L, but still a

separate competence module is needed for every new

situation to result in a complete description because

no generalization is applied.

To reduce the number of necessary competence

modules a method is required to ﬁnd the smallest

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

396

preconditions indicating a behavior choice. Such

hypotheses can be generated using a subset of the

demonstration pairs and validated of falsiﬁed using

a different subset. This is commonly done by in-

ferring a probability model using methods such as

Bayesian learning, kernel machines or neuronal net-

works (Hertzberg and Chatila, 2008).

Decision trees are classiﬁcation methods in form

of trees with inner nodes commonly representing bi-

nary decisions and leaves representing the classiﬁ-

cation result, i.e. the behavior choice. Generating

a decision tree in analog to the trivial behavior net-

work generation above and applying pruning after-

wards would result in a correct classiﬁcation as long

as the demonstration pairs do not contain any conﬂict-

ing choices.

Finding the smallest decision tree as the most

generalizing hypothesis employs reasoning about the

information gain of the different symbols for vari-

ous subsets of demonstration pairs. The Gini-index

is a common criterion for the inequality of dis-

tributions (Kotsiantis, 2007). Most algorithms in

this domain are based on the Iterative Dichotomiser

3 (ID3) algorithm which is a top-down induction

method (Quinlan, 1987) or any of the later versions

like the C4.5 algorithm (Quinlan, 1993) which is the

basis for the implementation used in this approach.

The full algorithm to generate an extended be-

havior network from demonstration pairs is as fol-

lows. A generalized decision tree is generated from

the demonstration pairs using the C4.5 algorithm with

a parametrization limiting the tree’s growth while en-

suring that the vast majority of the demonstrations are

classiﬁed correctly. For each path in this decision tree

a competence node is added to the decision tree with

the leaf as its action choice while the inner tree nodes

form the competence node’s precondition. Note that

the decision tree itself could be used for a behavior

decision but that its output will not be equivalent to

the Behavior Networks output which instead aims at

robust rational decision planning instead of a simple

mapping of world state to action choice without re-

gard to previous choices or currently executed behav-

ior. Finally the effect pair can be generated using the

transition function of equation 7. In the simple di-

rect transformation described earlier the effect could

only be assumed as deterministic since each compe-

tence was based on a single demonstration. Now the

generalized competence can be used to ﬁnd the sub-

set D

⊆ D of demonstration pairs matching the new

broader precondition and the effect probability can be

estimated using this subset.

Thus all parts of the competence modules are

speciﬁed. These modules represent the robot’s knowl-

edge about its behavior choices and their inﬂuence

and consequences in the world. Together with the

given goals the extended behavior network is com-

plete and was generated only from a specialist’s

demonstrations. The only speciﬁcation remaining is

about the set Π of 5 parameters described in section 2

which need to be deﬁned by the specialist to ﬁnd a

trade-off between reactivity and robustness.

4 EVALUATION

To proof the concept of the proposed algorithm an ex-

perimental setup is chosen addressing two problems

taken from the RoboCup

. Playing soccer with hu-

manoid robots combines a wide variety of modern

robotic problems. Being a benchmark for modern

autonomous robots application, choosing RoboCup

tasks yields the advantage of making results compa-

rable to other research studies. For the evaluation two

skills needed by a soccer robot are chosen - approach-

ing a ball and avoiding obstacles. These cover the ap-

plication of object recognition, localization, precise

motion execution and interaction with objects. The

outcome of the experiments is easy to rate and fur-

thermore both experiments can be combined to fur-

ther test the generalization of the proposed approach.

Testing an algorithm based on human interaction

requires a certain amount of demonstrations to be rep-

resentative. Thus the evaluation of the proposed algo-

rithm is conducted utilizing a 2D simulator rather than

a real robotic platform. As an advantage this allows

a better comparison and more precise analysis of the

results. The expert can teach the simulator by using

a joystick as an input device. To reduce the complex-

ity of the behavior network the possible actions are

discretized to walk straight, turn left by 17

◦

and turn

right by 17

◦

. The simulator provides the robot with

precise perceptions which can be altered by adding

Gaussian noise.

The tested Extended Behavior Networks are de-

rived from demonstration as described in section 3.

The parameters are chosen to be γ = 0.9, β = 0.5,

δ = 0.8, θ = 0.6 and Θ = 0.9 (compare (Pinto and

Alvares, 2005)). The underlying decision trees are

developed from demonstration pairs utilizing the pro-

gram RapidMiner

. In addition these trees are chosen

as a behavior to be compared to the Extended Behav-

ior Networks.

Experiment 1 evaluates the learning of the soccer

skill go to ball. 100 robot positions are randomly

http://www.robocup.org

http://www.rapidminer.com

LEARNING FROM DEMONSTRATION - Automatic Generation of Extended Behavior Networks for Autonomous

Robots from an Expert's Demonstration

397

generated with the properties robot.x = −100 mm,

robot.y = [−2000 mm, 2000 mm] and robot.θ =

[−90

◦

, 90

◦

]. For each of the those starting positions

an expert demonstrates go to ball for three different

ﬁxed ball placements (see ﬁgure 1) resulting in a total

of 300 demonstrations.

Figure 1: The different ball positions.

Another set of 100 different situations is gener-

ated to evaluate the learned skill. This time robot.x

is also chosen randomly from [−1000 mm, 100 mm]

and the ball is also positioned randomly with

ball.x = [750 mm, 2500 mm] and ball.y =

[750 mm, 2500 mm].

The utilized method to discretize the world state

is signiﬁcant for the resulting behavior network. Thus

the experiment evaluates two different approaches.

Fayyad and Irani (Fayyad and Irani, 1993) propose a

automated method of supervised entropy-based dis-

cretization particularly designed to learn decision

trees. This approach is applied and compared to a

manual discretization realized by an expert. These

two Behavior Networks are modeled to be composed

only of one resource. Since the robot is capable of an

omni-directional walk rotation and translation can be

combined enabling the robot to utilize two resources,

which is done in another trial.

The overall success rates of the tested behaviors

can be found in ﬁgure 2. Table 1 compares the su-

pervised observation discretization based on Fayyad

and Irani to the expert tuning. Using the supervised

discretization in combination with the decision tree

achieves always better results than combining it with

manual discretization while the opposite is true for

the Extended Behavior Networks. The network prof-

its from the higher number of competencies, which

still generalize the situation to achieve way better re-

sults. This enables adjustment to error in demonstra-

tion which are clearly committed by the expert by not

being able to always choose the exact same action in

the same world state. This accommodation to error

results in a superiority of the demonstrated Extended

Behavior Networks. Comparing the 1-resource net-

89%

28%

91%

40%

50%

60%

70%

80%

90%

100%

successrate

89%

28%

91%

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

0100200300400

successrate

#ofdemonstrations

1Ͳresourcebaviornetwork decissiontree 2Ͳresourcebehaviornetwork

Figure 2: Success rates of Experiment 1.

Table 1: Comparison between discretization methods of a

behavior network (decision tree).

# situations # competencies success

F&I expert F&I expert

90 3 138 39% (39%) 48% (10%)

180 14 175 48% (31%) 76% (16%)

270 23 193 21% (31%) 85% (21%)

360 33 213 23% (35%) 77% (28%)

work to the 2-resource network shows tendency to

slightly better overall results when utilizing two re-

sources. But ﬁgure 2 also shows a drop in success

of the 2-resource network around the demonstration

mark of 250. Thus a clear superiority can not be

proofed.

Experiment 2 evaluates the skill obstacle avoid-

ance. An obstacle is placed on the center spot of the

ﬁeld (x = 0 mm,y = 0 mm). The expert avoids the ob-

stacle while still trying to head for the ball, which is

placed at position ball.x = 3000 mm, ball.y = 0 mm.

The robot position is determined along the path to the

ball obstructed by the obstacle. It is randomized by

the distance d = [150 mm, 450 mm] to the obstacle

and the robots alignment Θ = [−45

◦

, 45

◦

] towards

the object. The demonstration is conducted 400 times.

The goal only takes the distance to the object in con-

sideration, which should be higher than 500 mm. The

resulting behavior network is tested with another set

of 100 randomly generated situations.

The outcome of the second experiment can be

found in ﬁgure 3 showing also good results utiliz-

ing the proposed demonstration approach. Analyzing

the results of these experiments proof that, given a

proper number of demonstrations, the presented al-

gorithm allows the robot to learn general skills by

demonstrating special situations. But this second ex-

periment does not demonstrate the same beneﬁt of

using multiple resources simultaneously. While the

evaluation reveals that success is achieved faster mod-

eling two resources, which is evident since the robot

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

398

94%

26%

74%

40%

50%

60%

70%

80%

90%

100%

successrate

94%

26%

74%

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

050100150200250300350400

successrate

#ofdemonstration

1Ͳresourcebaviornetwork decissiontree 2Ͳresourcebehaviornetwork

Figure 3: Success rates of Experiment 2.

can execute actions simultaneously, activating a mul-

titude of resources can lead to unforeseen effects. The

discussed drop in success during the ﬁrst experiment

suggests the same conclusion, thus a general advise is

not possible at this time.

Extended Behavior Networks are designed with

the possibility to model different contrary goals.

Therefore Experiment 3 is designed to test this char-

acteristic by combining the Behavior Networks of Ex-

periment 1 and 2. As an experimental setup, robot and

ball are placed according to the setup of Experiment

1. In addition 6 / 8 / 10 obstacles are put randomly be-

tween robot and ball. A set of 300 situations is gener-

ated and used as a test for the demonstrated behavior.

The importance of the obstacle avoidance skill is set

to i = 1.0 and that of go to ball is set to i = 0.6 to

model the skill priority.

Table 2: Results of Experiment 3.

# obstacles success without avoidance success with avoidance

6 46% 59%

8 40% 52%

10 31% 53%

Table 2 demonstrates the results of the combina-

tion experiment. It can be seen that even without the

avoidance skill the robot sometimes can successfully

complete the experiment. Since the placement of the

obstacles is random, this can be explained by a setup

without an obstacle blocking the path to the ball. With

more obstacles placed on the ﬁeld this occurs less of-

ten. Combining goto ball with avoid obstacle results

in a clear increase of the robots success rate. The less

from ideal results can mostly be explained by an in-

sufﬁcient demonstrations taking into account the na-

ture of the experiment. First of all due to the random-

ness of the obstacle placements there are some setups

in which the obstacles are too close to each other for

the robot to pass through without violating the goal.

This is a situation not taught by the obstacle avoid-

ance skill. In addition some times the avoidance of an

obstacle leads to a robot position close to the ball, but

not facing it. This also is not covered by the demon-

strated skill of Experiment 1 leading to a failure of the

experiment.

While the described experiments display the ad-

vantage of the demonstration approach they are con-

ducted with ideal percepts. To test the robustness of

the proposed algorithm Experiment 1 is repeatedly

conducted with increasing normally distributed noise

added to the input.

40%

50%

60%

70%

80%

90%

100%

sucessrate

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

0% 20% 40% 60% 80% 100%

sucessrate

variance

behaviornetwork dessisiontree

Figure 4: Results of Experiment 4.

Figure 4 demonstrates a comparison of the robust-

ness between the extended behavior network and the

decision tree. While the success rate of the extended

behavior network decreases with rising noise ratio as

expected, it does so more slowly than the decision

tree. Even with a noise ration of 15 percent the suc-

cess rate stays above 70 percent allowing the algo-

rithm to be called robust.

5 CONCLUSIONS

This paper presented an algorithm to automatically

derive a behavior network imitating a skill demon-

strated by an expert. The theoretical concept has

been tested in simulation mimicking skills needed by

a soccer robot participating in the RoboCup. The

conducted experiments proof the possibility to apply

skills, learned from demonstrating a speciﬁc behav-

ior, successfully to different situations, requiring the

same skill. But the results indicate the need for a

certain amount of demonstrations to achieve a rea-

sonable success rate, depending on the complexity of

the task. The inﬂuence of the task complexity could

be shown by combining two basic skills to solve a

task not learned by the robot. While principally being

LEARNING FROM DEMONSTRATION - Automatic Generation of Extended Behavior Networks for Autonomous

Robots from an Expert's Demonstration

399

able to solve this assigned task the rising complexity

may result in situations fundamentally different and

not covered by demonstration. Finally the robustness

of the approach has been proven by testing the be-

havior network against a simulation of noisy world

states, indicating a transferability from simulation to

the real robot, but this has still to be proven in future

experiments. Especially due to the necessity of high

quantity of demonstration the desire arises to combine

demonstrations in reality and simulation to reduce the

stress of the robotic hardware.

REFERENCES

Arkin, R. C. (1999). Behavior-based robotics, intelligent

robots and autonomous agents series, mit press, cam-

bridge, mass., 1998, xiv+491 pp, isbn 0-262-

01165-4. Robotica, 17(2):229–235.

Brooks, R. A. (1990). Elephants don’t play chess. Robotics

and Autonomous Systems, 6:3–15.

Dorer, K. (1999). Behavior networks for continuous do-

mains using situation-dependent motivations. In In

Proc. 16th Int. Joint Conf. on Artiﬁcial Intelligence

(IJCAI), pages 1233–1238.

Dorer, K. (2010). Modeling human decision making us-

ing extended behavior networks. In RoboCup 2009:

Robot Soccer World Cup XIII, volume 5949 of Lecture

Notes in Computer Science, pages 81–91. Springer

Berlin / Heidelberg.

Fayyad and Irani (1993). Multi-interval discretization of

continuous-valued attributes for classiﬁcation learn-

ing. In Proceedings of the International Joint Con-

ference on Uncertainty in AI, pages 1022–1027.

Hertzberg, J. and Chatila, R. (2008). AI Reasoning Meth-

ods for Robotics. In Springer Handbook of Robotics,

pages 207–223. Springer Berlin Heidelberg.

Kotsiantis, S. B. (2007). Supervised machine learning:

A review of classiﬁcation techniques. Informatica,

31:249–268.

Maes, P. (1989). How to do the right thing. Connection

Science Journal, 1:291–323.

Pinto, H. and Alvares, L. (2005). An extended behavior net-

work for a game agent: An investigation of action se-

lection quality and agent performance in unreal tour-

nament. 5TH International Working Conference on

Intelligent Virtual Agents.

Quinlan, J. R. (1987). Simplifying decision trees. Int. J.

Man-Mach. Stud., 27(3):221–234.

Quinlan, J. R. (1993). C4.5: programs for machine learn-

ing. Morgan Kaufmann Publishers Inc., San Fran-

cisco, CA, USA.

ICAART 2011 - 3rd International Conference on Agents and Artificial Intelligence

400
