STUDYING THE RELEVANCE OF BREAST IMAGING FEATURES

Pedro Ferreira, Inˆes Dutra

Department of Computer Science & CRACS-INESC Porto LA, University of Porto, Porto, Portugal

Nuno A. Fonseca

CRACS-INESC Porto LA, Porto, Portugal

Ryan Woods

Department of Radiology, Johns Hopkins Hospital, Baltimore, MD, U.S.A.

Elizabeth Burnside

Department of Radiology, University of Wisconsin School of Medicine and Public Health, Madison, WI, U.S.A.

Keywords:

Mass density, Breast cancer, Mammograms, Classiﬁcation methods, Data mining, Machine learning.

Abstract:

Breast screening is the regular examination of a woman’s breasts to ﬁnd breast cancer in an initial stage. The

sole exam approved for this purpose is mammography that, despite the existence of more advanced technolo-

gies, is considered the cheapest and most efﬁcient method to detect cancer in a preclinical stage.

We investigate, using machine learning techniques, how attributes obtained from mammographies can relate

to malignancy. In particular, this study focus is on how mass density can inﬂuence malignancy from a data

set of 348 patients containing, among other information, results of biopsies. To this end, we applied different

learning algorithms on the data set using the WEKA tools, and performed signiﬁcance tests on the results. The

conclusions are threefold: (1) automatic classiﬁcation of a mammography can reach equal or better results than

the ones annotated by specialists, which can help doctors to quickly concentrate on some speciﬁc mammogram

for a more thorough study; (2) mass density seems to be a good indicator of malignancy, as previous studies

suggested; (3) we can obtain classiﬁers that can predict mass density with a quality as good as the specialist

blind to biopsy.

1 INTRODUCTION

Breast screening is the regular examination of a

woman’s breasts to ﬁnd breast cancer earlier. The sole

exam approved for this purpose is mammography.

Usually, ﬁndings are annotated through the Breast

Imaging Reporting and Data System (BIRADS) cre-

ated by the American College of Radiology. The BI-

RADS system determines a standard lexicon to be

used by radiologists when studying each ﬁnding. De-

spite the existence of more advanced technologies,

mammography is considered the cheapest and most

efﬁcient method to detect cancer in a preclinical stage.

In this work, we were provided with 348 cases of

patients that went through mammography screening.

Our main objective is to apply machine learning tech-

niques to these data in order to ﬁnd non trivial rela-

tions among attributes, and learn models that can help

medical doctors to quickly assess mammograms.

Much work has been done on applying ma-

chine learning techniques to the study of breast

cancer, which is one of the most common kinds

of cancer in the world. In the UCI (University

of California, Irvine) machine learning repository

(http://archive.ics.uci.edu/ml/datasets.html) there are

four data sets whose main target of study is breast

cancer. One of the ﬁrst works on applying machine

learning techniques to breast cancer data dates from

1990. The data set used in this study, donated to the

UCI repository, was created by Wolberg and Man-

gasarian after their work on a multisurface method

of pattern separation for medical diagnosis applied

337

Ferreira P., Dutra I., A. Fonseca N., Woods R. and Burnside E..

STUDYING THE RELEVANCE OF BREAST IMAGING FEATURES.

DOI: 10.5220/0003172903370342

In Proceedings of the International Conference on Health Informatics (HEALTHINF-2011), pages 337-342

ISBN: 978-989-8425-34-8

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

to breast cytology (Wolberg and Mangasarian, 1990).

Most works in the literature applies artiﬁcial neural

networks to the problem of diagnosing breast cancer

(e.g., (Wu et al., 1993) and (Abbass, 2002)). Oth-

ers focus on prognostic of the disease using inductive

learning methods (e.g., (Street et al., 1995)). More

recently, Ayer et al. (Ayer et al., 2010) have evalu-

ated whether an artiﬁcial neural network, trained on

a large prospectively collected data set of consecutive

mammography ﬁndings, could discriminate between

benign and malignant disease, and accurately predict

the probabilityof breast cancer for individual patients.

Other recent studies focus on extracting information

from free textthat appears in medical records of mam-

mography screenings (Nassif et al., 2009), and on the

inﬂuence of age in ductal carcinoma in situ (DCIS)

ﬁndings (Nassif et al., 2010).

Our study is focused on the inﬂuence of mass

density on predicting malignancy, but we also un-

cover other interesting complementary ﬁndings. Pre-

vious works by Jackson et al. (Jackson et al., 1991)

and Cory and Linden (Cory and Linden, 1993) have

argued that, although the majority of high density

masses are malignant, the presence of low density

cancers and more important indicators (like margins,

shape, and associated ﬁndings) make mass density

a less reliable indicator or predictor of malignancy.

Sickles (Sickles, 1991) has the same opinion. A study

carried out by Davis et al. (Davis et al., 2005) indi-

cated that mass density could have more importance

and relevance than previous works had reported. In

another work, Woods et al. (Woods et al., 2009) ap-

plied inductive logic programming to a set of breast

cancer data and concluded the same thing. Woods and

Burnside (Woods and Burnside, 2010) also applied

logistic regression and kappa statistics to another set

of breast cancer data and concluded that mass density

and malignancy are somewhat related.

In this work, we use the same data set used by

Woods and Burnside (Woods and Burnside, 2010),

but we apply machine learning methods and conﬁrm

the ﬁndings of Woods and Burnside. In addition,

we show that the learned classiﬁers generated in this

work can predict mass density and outcome (classi-

ﬁcation of a mammography) with a quality as good

as a specialist, proving to be good helpers to medical

doctors when evaluating mammograms.

2 BREAST CANCER DATA

Our study analyzes 348 consecutive breast masses

that underwent image guided or surgical biopsy per-

formed between October 2005 and December 2007

on 328 female subjects. All 348 biopsy masses were

randomized and assigned to a radiologist blinded

to biopsy results for retrospective assessment us-

ing the Breast Imaging Reporting and Data Sys-

tem (retrospectively-assessed data set). Clinical ra-

diologists prospectively assessed the density of 180

of these masses (prospectively-assessed data set).

Pathology result at biopsy was the study endpoint.

The atributes included in our study are very much

the ones collected by the radiologists from the mam-

mograms, and are based on the BIRADS lexicon.

We selected from the original database all the at-

tributes considered relevant by the specialists and re-

moved some attributes such as identiﬁers, redundant

attributes and attributes that had the same value for all

instances. For our main task, to predict malignancy,

our class attribute was the outcome binary variable as-

suming values benign or malignant.

From the 348 cases, 118 are malignant (≈ 34%),

and 84 cases have high mass density (≈ 24%) retro-

spectively assessed. Other attributes are mass shape,

mass margins, depth, size, among others. For the

purpose of our study, we have two attributes that

represent the same characteristics of the ﬁnding, but

with different interpretations. These are retro density

and density num. Both represent mass densities that

can assume values high or iso/low. Retro density

was retrospectively assessed while density num was

prospectively (at the time of imaging) assessed.

3 EXPERIMENTS AND RESULTS

Our ﬁrst preliminary study was to calculate simple

frequencies from the data and to determine if there

was some evidence of relationship between attributes,

specially, the main focus of our study:

Is mass density related to malignancy?

As mentioned above, from the 348 breast masses,

118 are malignant (≈ 34%), and 84 have high mass

density (≈ 24%). If we consider that mass density

and malignancy are independent, and take 84 cases

from the 348 at random, the probability of these be-

ing malignant should still be ≈ 34%. However, if it

happens that all 84 cases selected at random have high

density, then the percentage of malignant cases raises

to 70.2% (this is the percentage of cases that are both

malignant and have high mass density). The proba-

bility of this being coincidence is very low, given the

data distribution. This simple calculation may already

imply that high density has some relation to malig-

nancy. So may imply that other attributes such as age,

mass shape and mass margins can have some relation

to malignancy. One of the objectives of our study is

HEALTHINF 2011 - International Conference on Health Informatics

338

then to conﬁrm if these attributes have some relation

to the outcome variable.

3.1 Methods

As mentioned before, the data set used in the experi-

ments contains 348 ﬁndings that include data related

to biopsies. A subset of 180 was annotated by a spe-

cialist blind to the biopsies results. The task of this

specialist was to annotate the mass density. The re-

maining ﬁndings, 168 cases, were not annotated by

this specialist.

All experiments were performed using the

WEKA tool, developed at Waikato University, New

Zealand (Hall et al., 2009). We experimented with

several classiﬁcation algorithms, but report only for

the algorithms that produced the best results. The ex-

periments were performed in WEKA using the Exper-

imenter module, where we set several parameters, in-

cluding the statistical signiﬁcance test and conﬁdence

interval, and the algorithms we wanted to use (we

used OneR as reference, ZeroR, PART, J48, Simple-

Cart, DecisionStump, Random Forests, SMO, Naive

Bayes, Bayes with TAN, NBTree and DTNB). The

WEKA experimenter produces a table with the per-

formance metrics of all algorithms with an indica-

tion of statistical differences, using one of the algo-

rithms as a reference. The signiﬁcance tests were per-

formed using standard corrected t-test with a signiﬁ-

cance level of 0.01. The parameters used for the learn-

ing algorithms are the WEKA defaults. In the tables,

the numbers between parentheses represent standard

deviations. From the 348 cases, we trained on the 180

annotated cases. We used the remaining 168 as un-

seen/test data to evaluate the performance of the clas-

siﬁers. During the training, we used 10-fold stratiﬁed

cross validation and reported the results for the aver-

age metrics obtained among all folds.

3.2 Is Mass Density Predictive of

Malignancy?

We considered at least two ways of investigating if

mass density is predictive of malignancy. The ﬁrst

one is to apply association rules or logistic regression

to the 348 ﬁndings, and report the relation between

retro density and outcome. This was already done by

Woods and Burnside (Woods and Burnside, 2010), in

a previous work, using logistic regression and kappa

statistics. Their results showed that high mass density

is a relatively important indicator of malignancy with

an inter-observer agreement of 0.53.

The second way is to use a classiﬁcation method

and predict outcome using mass density and with-

out using mass density and compare results. As we

have two kinds of mass density: one for the retrospec-

tive data and another one for the prospective data, we

used both to build classiﬁers. Our ﬁrst experiment

was then to generate a classiﬁer to predict outcome

with retro density using 10-fold cross-validation on

the 180 ﬁndings. Our second experiment was to gen-

erate a classiﬁer to predict outcome with density num

(prospectively assessed), also using 10-fold cross-

validation on the 180 ﬁndings.

In order to investigate if mass density is predictive

of malignancy, we also generated a classiﬁer to pre-

dict outcome without any information about density

using 10-fold cross-validation on the 180 ﬁndings.

In the three experiments, the best classiﬁers found

were based on Support Vector Machines (Platt, 1998).

Table 1 summarizes the results obtained using the

metrics we found more relevant to the task. CCI is

the percentage of Correctly Classiﬁed Instances. K is

the k-value of kappa statistics. Prec is the Precision,

and F is the F-measure. These results show that mass

density has some inﬂuence on the outcome, specially

when mass density is the one observed on the retro-

spective data. The classiﬁer trained without mass den-

sity has an overall performance of 81.39% while the

classiﬁer trained with the retrospective assessed mass

has an overall performance of 84.78%. These results

are statistically different (p=0.01). If we look at the K

value, we can conﬁrm that the relation between mass

density and outcome is not by chance, given the rela-

tively high observed agreement between the real data

and the classiﬁer’s predicted values. With respect to

Precision, the results also seem to be quite good with

only 16% of cases being incorrectly classiﬁed as ma-

lignant when using the retrospective data. The Re-

call also gives a reasonable rate of correctly classiﬁed

cases of malignancy, although there is still scope for

improvement. The f-measure balances the values of

Precision and Recall and also indicates that the clas-

siﬁers are behaving reasonably well.

Summarising, these results show that attributes

other than mass density are also important, but if

we add mass density, the classiﬁer’s performance im-

proves.

These results also conﬁrm ﬁndings in the litera-

ture regardingthe relevanceof mass density, and show

that good classiﬁers can be obtained to predict out-

come (with a high percentage of correctly classiﬁed

instances and good values of K, precision and recall).

STUDYING THE RELEVANCE OF BREAST IMAGING FEATURES

339

Table 1: Prediction of outcome using 180 ﬁndings. Standard deviation values are between parentheses.

Metric with mass density without mass density

retro density density num

CCI 84.78% (7.96) 82.72% (8.32) 81.39% (8.81)

K 0.68 (0.17) 0.63 (0.17) 0.60 (0.18)

Prec 0.84 (0.12) 0.82 (0.13) 0.81 (0.14)

Recall 0.78 (0.15) 0.75 (0.15) 0.72 (0.15)

F 0.80 (0.11) 0.77 (0.11) 0.75 (0.12)

3.3 Can we Obtain a Classiﬁer that

Predicts Mass Density as Well as the

Radiologist?

Our second question is related to the quality of the

classiﬁer related to a specialist. As we have two an-

notated mass densities, one for the prospective study

and another one for the retrospective, we generated

2 classiﬁers: one is trained on the prospective val-

ues of mass density (density num), and another one

is trained on the retrospective (retro density) values

of mass density. Once more, we used the 180 cases

as training set and 10-fold stratiﬁed cross-validation.

The best classiﬁer obtained by the WEKA Exper-

imenter for these two tasks was based on Naive-

Bayes (John and Langley, 1995). Table 2 shows the

results of these experiments as an average of the met-

rics for the 10 folds.

Table 2: Prediction of mass density using 180 ﬁndings.

Standard deviation values are between parentheses.

Metric retro density density num

CCI 72.83% (9.89) 67.22% (12.14)

K 0.37 (0.23) 0.33 (0.25)

Precision 0.58 (0.20) 0.66 (0.16)

Recall 0.58 (0.22) 0.60 (0.17)

F-Measure 0.56 (0.18) 0.62 (0.15)

70% of masses annotated by the specialist on the

180 ﬁndings agreed to the annotated masses of the

retrospective study. The Naive Bayes classiﬁer pre-

dicted ≈ 73% of correct instances when training on

the retrospective annotated mass (retro density) and

≈ 67% when training on prospective masses anno-

tated by a radiologist. These results are quite good

and indicate that the Bayesian classiﬁer generated in

this study can be well applied as a support tool to

help doctors predicting mass density for unseen mam-

mograms. The values of K, Precision, Recall and f-

measure for this experiment are not so good as the

ones obtained when trying to learn outcome. How-

ever, the K valueindicates that the Naive Bayes classi-

ﬁer has some level of agreement with the actual data,

which is not by chance. One interesting thing to ob-

serve is that, although the classiﬁer trained on the ret-

rospectivedata has a higher rate of correctly classiﬁed

instances, it has lower values for Precision, Recall and

f-measure than the classiﬁer trained on the prospec-

tive data. This may indicate that this could be a better

classiﬁer to be used when one does not have informa-

tion about the biopsy data.

Our last question is related to how well a learned

classiﬁer can predict the outcome (malignant or be-

nign) on unseen data blind to the result of the biopsy.

3.4 Can the Generated Classiﬁers

Behave Well on Unseen Data?

In order to answer this question we need again to

consider classiﬁers generated using the retrospective

mass density attribute and the prospective mass den-

sity attribute. The ﬁrst classiﬁer, based on the retro-

spective values of mass density was generated when

training on the 180 ﬁndings to answer our ﬁrst ques-

tion: “is mass density related to malignancy?” This is

a classiﬁer based on Support Vector Machines. How-

ever, we can use yet another classiﬁer, based on the

prospective values of mass density to predict the 168

unseen cases.

Table 3: Prediction of mass density on unseen data.

Metric retro density density num

CCI 82.14% 75.60%

K 0.45 0.35

Prec 0.48 0.38

Recall 0.68 0.71

F 0.56 0.49

As the 168 unseen cases do not have any prospec-

tive annotated mass density, we will ﬁll up these miss-

ing values using the classiﬁers generated when an-

swering our question 2 (Subsection 3.3). In those

experiments, we generated two classiﬁers to predict

mass density: one that was trained on retro density

HEALTHINF 2011 - International Conference on Health Informatics

340

Table 4: Prediction of outcome on unseen data.

Metric with mass density w/o mass density

retro density retro density density num

(actual) (ﬁll up by NB) (ﬁll up by NB)

CCI 81.55% 79.76% 79.17% 77.38%

K 0.52 0.48 0.46 0.42

Prec 0.70 0.65 0.65 0.61

Recall 0.60 0.60 0.55 0.53

F 0.64 0.62 0.60 0.57

Table 5: Prediction of mass density.

Metric Mass Density

Radiologist density num density num retro density retro density

(180) (180) (168) (180) (168)

CCI 70.00% 67.22% (12.14) 75.60% 72.83% (9.89) 82.14%

K – 0.33 (0.25) 0.35 0.37 (0.23) 0.45

Prec – 0.66 (0.16) 0.38 0.58 (0.20) 0.48

Recall – 0.60 (0.17) 0.71 0.58 (0.22) 0.68

F – 0.62 (0.15) 0.49 0.56 (0.18) 0.56

and another one that was trained on density num.

Both are Bayesian classiﬁers. Once we ﬁll up these

values, we can apply a classiﬁer learned to predict

outcome to this unseen data set.

Results of the prediction of mass density on the

unseen data are shown in Table 3. These results were

produced by the best classiﬁer that was, in both cases,

a naive Bayes network.

These results are very good, given that both clas-

siﬁers have a prediction performance on the unseen

data well above the one obtained on the training set

(180 cases) with respect to CCI. The K-statistics and

the Recall also improved on the unseen data. We see

a slightly fall in performance when predicting benign

cases, and this is observed by the precision and f-

measure values in the unseen data. The rate of false

positives increases on the unseen data. On the other

hand, the algorithm performs better on classifying the

malignant cases.

Once the predicted values of mass densities of

the 168 ﬁndings are ﬁlled, we move to the next step,

which is to predict outcome for the unseen data. Re-

sults of this experiment can be found in Table 4.

In Table 4 we show three different predictions

for outcome, using three different sources for the

mass density. The second column in Table 4 shows

the results of predicting outcome using the attribute

for mass density available on the retrospective data

(retro density attribute). The third and fourth columns

show the predictions when using the mass density

ﬁlled up by the two Naive Bayes classiﬁers (one that

was trained on the retro density attribute and another

that was trained on the prospective density num at-

tribute).

Regarding the comparison among these three pre-

dictions we can observe that the three classiﬁers be-

haved relatively well on the unseen data, capturing

most of the malignant and benign cases. The K value,

once more, indicates that those results are not by

chance. In other words, the classiﬁers are actually

helping to distinguish between malignant and benign

cases. As observed before, the classiﬁer trained on the

actual retrospective data yields better performance,

but the other classiﬁers are not performing that far,

which indicates that the lack of biopsy data is not

harming the classiﬁcation task.

A second observation we take from these results

is that, even using predicted values for mass density

(with prediction errors), the classiﬁers for outcome

in columns three and four, can maintain a reasonable

performance.

The last conclusion we take from these results is

that mass density is somehow related to outcome, and

is an important attribute that contributes to improve

the performance of the classiﬁers. A comparison be-

tween the ﬁgures on the last column of Table 4 (pre-

diction without mass density) with the ﬁgures on the

other columns conﬁrms that fact.

Summarizing, and getting back to our third ques-

tion “3. Can we obtain a classiﬁer that predicts

mass density as well as the radiologist?”, Table 5

shows the performance of all classiﬁers used for this

task on the training data and on unseen data.

Table 5 summarizes our results for predicting

mass density and shows that the classiﬁers generated

have a good performance that in some cases is bet-

ter than the one given by the radiologist. The per-

formance on unseen cases is also quite reasonable re-

STUDYING THE RELEVANCE OF BREAST IMAGING FEATURES

341

garding the precision and recall values.

4 CONCLUSIONS AND FUTURE

WORK

In this work, we were provided with 348 cases of

patients that went through mammography screening.

The objective of this work was twofold: i) ﬁnd non

trivial relations among attributes by applying machine

learning techniques to these data, and; ii) learn mod-

els that could help medical doctors to quickly assess

mammograms. We used the WEKA machine learn-

ing tool and whenever applicable performed statisti-

cal tests of signiﬁcance on the results.

The conclusions are threefold: (1) automatic clas-

siﬁcation of a mammography can reach equal or bet-

ter results than the ones annotated by specialists; (2)

mass density seems to be a good indicator of ma-

lignancy, as previous studies suggested; (3) machine

learning classiﬁers can predict mass density with a

quality as good as the specialist blind to biopsy.

As future work, we plan to extend this work

to larger data sets, and apply other machine learn-

ing techniques based on statistical relational learning,

since classiﬁers that fall in this category provide a

good explanation of the predicted outcomes as well

as can consider the relationship among mammograms

of the same patient. We would also like to investi-

gate how other attributes can affect malignancy or are

related to the other attributes.

ACKNOWLEDGEMENTS

This work has been partially supported by the

projects HORUS (PTDC/EIA-EIA/100897/2008)

and Digiscope (PTDC/EIA-CCO/100844/2008)

and by the Fundac¸˜ao para a Ciˆencia e Tecnologia

(FCT/Portugal). Pedro Ferreira has been supported

by an FCT BIC scholarship.

REFERENCES

Abbass, H. A. (2002). An evolutionary artiﬁcial neural net-

works approach for breast cancer diagnosis. Artiﬁcial

Intelligence in Medicine, 25:265.

Ayer, T., Alagoz, O., Chhatwal, J., Shavlik, J. W., Kahn, C.

E. J., and Burnside, E. S. (2010). Breast cancer risk es-

timation with artiﬁcial neural networks revisited: dis-

crimination and calibration. Cancer, 116(14):3310–

3321.

Cory, R. C. and Linden, S. S. (1993). The mammographic

density of breast cancer. AJR Am J Roentgenol,

160:418–419.

Davis, J., Burnside, E. S., Dutra, I. C., Page, D., and Costa,

V. S. (2005). Knowledge discovery from structured

mammography reports using inductive logic program-

ming. In American Medical Informatics Association

2005 Annual Symposium, pages 86–100.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The weka data mining

software: An update. SIGKDD Explorations, 11:263–

286.

Jackson, V. P., Dines, K. A., Bassett, L. W., Gold, R. H., and

Reynolds, H. E. (1991). Diagnostic importance of the

radiographic density of noncalciﬁed breast masses:

analysis of 91 lesions. AJR Am J Roentgenol, 157:25–

28.

John, G. H. and Langley, P. (1995). Estimating continuous

distributions in bayesian classiﬁers. In Proceedings of

the Eleventh Conference on Uncertainty in Artiﬁcial

Intelligence, pages 338–345. Morgan Kaufmann, San

Mateo.

Nassif, H., Page, D., Ayvaci, M., Shavlik, J., and Burn-

side, E. S. (2010). Uncovering age-speciﬁc invasive

and dcis breast cancer rules using inductive logic pro-

gramming. In Proceedings of 2010 ACM International

Health Informatics Symposium (IHI 2010). ACM Dig-

ital Library.

Nassif, H., Woods, R., Burnside, E., Ayvaci, M., Shavlik,

J., and Page, D. (2009). Information extraction for

clinical data mining: A mammography case study. In

ICDMW ’09: Proceedings of the 2009 IEEE Interna-

tional Conference on Data Mining Workshops, pages

37–42, Washington, DC, USA. IEEE Computer Soci-

ety.

Platt, J. C. (1998). Sequential minimal optimization: A fast

algorithm for training support vector machines. Tech-

nical Report MSR-TR-98-14, Microsoft Research.

Sickles, E. A. (1991). Periodic mammographic follow-up of

probably benign lesions: results in 3,184 consecutive

cases. Radiology, 179:463–468.

Street, W. N., Mangasarian, O. L., and Wolberg, W. H.

(1995). An inductive learning approach to prognos-

tic prediction. In ICML, page 522.

Wolberg, W. H. and Mangasarian, O. L. (1990). Multisur-

face method of pattern separation for medical diagno-

sis applied to breast cytology. In Proceedings of the

National Academy of Sciences, 87, pages 9193–9196.

Woods, R. and Burnside, E. (2010). The mammographic

density of a mass is a signiﬁcant predictor of breast

cancer. Radiology. to appear.

Woods, R., Oliphant, L., Shinki, K., Page, D., Shavlik, J.,

and Burnside, E. (2009). Validation of results from

knowledge discovery: Mass density as a predictor of

breast cancer. J Digit Imaging, pages 418–419.

Wu, Y., Giger, M. L., Doi, K., Vyborny, C. J., Schmidt,

R. A., and Metz, C. E. (1993). Artiﬁcial neural net-

works in mammography: application to decision mak-

ing in the diagnosis of breast cancer. Radiology,

187:81–87.

HEALTHINF 2011 - International Conference on Health Informatics

342
