SalamboMiner

A Biomedical Literature Mining Tool for Inferring the Genetics

of Complex Diseases

Leonor Rib

, Ricard Gavald`a

, Jose Manuel Soria

and Alfonso Buil

Unit of Genomics of Complex Diseases, Institut de Recerca del HSCSP, Barcelona, Spain

Departament de Llenguatges i Sistemes Inform`atics, Universitat Polit`ecnica de Catalunya, Barcelona, Spain

Keywords:

Literature mining, Knowledge discovery, Bayesian Networks.

Abstract:

In the Era of Information researchers have utilized the Web to make their knowledge readily available. The

Web is an important tool to improve the communication in the research community. But, the large amounts of

information available makes it difﬁcult to access the information that is needed.

We present SalamboMiner, a Text-Mining tool that helps biomedical researchers to obtain the information

about the genetics of complex diseases which is in the published biomedical literature. The methodology

is based in the idea of co-citation: the co-citation of two concepts gives the signiﬁcance of the relationship

between the pair of concepts. In addition, the co-citation allows to infer new relationships that are not explicitly

said in the literature. By using a Bayesian network, we infer the signiﬁcant relationships between those

concepts that are co-cited in two steps.

1 INTRODUCTION

During the past several years, biomedical research

has accumulated a large amount of knowledge. All

this information is published in professional journals

available to the entire research community. Thanks

to the internet information is available online. Al-

though online information provides an excellent opor-

tunity for interaction among researchers, the amount

of information is enormous and is increasing expo-

nentially year by year (Zweigenbaum, 2007). As a

result, it is increasingly difﬁcult for researchers to uti-

lize the information efﬁciently.

In the last two decades, many tools have been de-

veloped to help researchers obtain information from

the literature databases. These tools are included

in the ﬁeld of Biomedical Text-Mining. Broadly

deﬁned, text-mining includes a range of applica-

tions, from the extraction of facts using Named En-

tity Recognition to thenew knowledge discovery per-

formed with Literature-Based Discovery. All of these

methods can be applied in quite different areas of

biomedicine from drugs discovery to genomics of dis-

eases. SalamboMiner is a text-mining tool that fo-

cuses on obtaining information about the genes that

are involved in complex diseases by analyzing the co-

citation of concepts in the same article. The co-

citation of concepts is a useful tool to uncover the

role of genetics in complex diseases (Weeber, 2005)

(Zweigenbaum, 2007). The co-citation of concepts in

the same biomedical article gives information about

the degree of relationship among themselves in the

real life.

Many aspects of text-mining tools must be deﬁned

very carefully, because the way they are deﬁned af-

fects the computing cost and the reliability of the re-

sults. Many questions arise when developing a text-

mining tool. Is it good to use the full text of the ar-

ticles? What elements should be extracted from the

articles and what is the better way to extract them?

How will the extracted elements be analyzed?

Is it good to use the full text of the articles? The

articles are the source of information we need to do

co-citation analysis but now there are restrictions to

use the full text of all the articles due to copyright is-

sues. The usage of the abstract and the title is now the

more feasible option, because there are no limitations

to access them. In addition, the abstracts provide very

relevant information since they summarize the con-

tents of the articles. Especially, the abstracts are the

part of the articles that contain the more complete in-

formation about the genes, proteins and diseases in-

143

Rib L., Gavaldà R., Manuel Soria J. and Buil A..

SalamboMiner - A Biomedical Literature Mining Tool for Inferring the Genetics of Complex Diseases.

DOI: 10.5220/0003143201430148

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2011), pages 143-148

ISBN: 978-989-8425-36-2

 2011 SCITEPRESS (Science and Technology Publications, Lda.)

cluded in the articles (Shah et al., 2003).

What elements should be extracted from the arti-

cles and what is the better way to extract them? There

are different strategies to approach the extraction of

information from articles. One possibility is to ex-

tract facts from the text by applying Biomedical Lan-

guage Processing methods (Weeber, 2005). There are

some important difﬁculties to be taken into account

(Hunter, 2006). The words can be ambiguous, allow-

ing for multiple interpretations for strings, like genes

whose names are identical to prepositions, acronims

and abbreviations. Another difﬁculty is to deal with

the polysemy of gene symbols, when a single name

or symbol can refer to more than one gene. And

metonymy can also occur when some string can refer

to more than one concept that are related, like the pro-

teins of a gene. This is the case of the p53 described

in Lakoff and Johnson article (Lakoff and Johnson,

1980). Named Entity Recognizers are tools that help

the correct extraction of biomedical terms like genes

and proteins. Now, there is an increasing attention

paid to syntax analyzers (Zweigenbaum, 2007). Their

task is computationally complex but the improvement

of computing power and faster algorithms makes it

more feasible every day.

In addition, from articles can also be retrieved

metadata associated to them. Concretely, the MeSH

Terms are useful information. They are biomedical

terms and, originally, they aimed to index the arti-

cles in such a way that can be found easily in the

databases. At the same time, the MeSH terms are

useful in text-mining because they summarize the rel-

evant contents, especially genes and diseases. More-

over, other information can be included to the analy-

sis. For example, chromosome location (Hristovski

et al., 2005), (Perez-Iratxeta, 2002) can be used to

better identify the desired elements from the articles.

Other biological information can also be used to im-

prove the knowledge base like in the tool developed

by Stein Aerts et al (Aerts, 2006).

Once the desired elements of the text have been

retrieved, the synonimous terms must be uniﬁed into

its concept (Bard and Rhee, 2004). There are initia-

tives called ontologies that build representation sys-

tems biomedical knowledge which unify terms into

concepts. In addition, the concepts are organized in

a semantic manner: they have associated a semantic

category and they are related among themselves by

a semantic relationship. Some extended ontologies

are Gene Ontology (GO), Open Biological Ontolo-

gies (OBO) and Uniﬁed Medical Language System

(UMLS).

How will the extracted elements be analyzed? The

analysis of the co-citation of concepts can be done in

many different ways. For example FACTA (Tsuruoka

et al., 2008) uses Pointwise Mutual Information, Pub-

Gene uses a Network of Co-citations (Jenssen et al.,

2001), PolySearch (Cheng et al., 2008) uses Associa-

tion Rules, Anni 2.0 (Jelier et al., 2008) uses Concepts

Proﬁles, the tool of Varun K. Gajendrana et al (Gajen-

drana et al., 2007) uses a model based in the Zipf law,

Seki et al (Seki and Mostafa, 2007) use a probabilis-

tic network, and Bitola (Hristovski et al., 2005) uses

Association Rules. The last four use these methods to

extract relationships and to discover new relationships

that are not explicitly writen in the articles, while the

others apply only to methods to extract implicit rela-

tionships.

SalamboMiner is a text-mining tool that aims to

obtain a prioritized list of relationships among genes

and diseases. The relationships obtained are twofold:

based on explicit information and based on implicit

relationships found by literature discovery. It ex-

tracts from the title, the abstract and MeSH terms of

PubMed articles the relevant concepts within the arti-

cles. We have deﬁned as relevant concepts those that

represent genes, proteins and diseases. To do the ex-

traction of genes and proteins, we use the BNER Bio-

tagger (McDonald and Pereira, 2005) and we obtain

the diseases from the MeSH terms. It is important to

unify the elements into their respective concepts be-

cause it helps to manage of the extracted terms. In

SalamboMiner we use UMLS because of it gives a

relatively good coverage of genes and protein con-

cepts (Mary, 2004) although it has some problems

in the semantic assignment as described by Huany-

ing Gu et al (Gu, 2007).

In our project, we use the Bayes Factor mea-

sure to extract relevant relationships among concepts.

And, to discover new relationships, we construct a

Bayesian Network with the concepts as nodes and

their co-citations as edges, and we use the Bayes Fac-

tor again to infer new relationships.

We have tested SalamboMiner with data set that

comprised articles that appeared in the database of

Online Mendelian Inheritance in Man (OMIM) that

are related to Thrombosis and Diabetes.

2 METHODS

SalamboMiner has three consecutive modules:

• the ﬁrst aim is to collect the desired articles,

• the second aim is to extract the desired concepts

from the articles, and

• the third aim is to organize the extracted concepts

so that allows to infer relationships among the

concepts.

BIOINFORMATICS 2011 - International Conference on Bioinformatics Models, Methods and Algorithms

144

2.1 Collecting the Articles

This aim is critical because it must construct an im-

partial and exhaustive base of information that will

ultimately allow to obtain results as accurate as pos-

sible with respect to the information published as of

the time the inquiry is initiated. There are some dif-

ﬁculties to overcome. First, a text can include many

different topics. This can hinder the extraction of real

relationships between concepts. In addition, the top-

ics can refer to afﬁrmations and to negations, which

may lead to completely opposite relationships. For-

tunately, the biomedical literature is usually restricted

to a speciﬁc subject. But, we have used only the title

and abstract of the articles because, ﬁrst, it is difﬁcult

to work with the whole texts of an article since their

automated access is not allowed, due to copyright re-

strictions. In addition, processing the whole text of

an article requires a great deal of time. On the other

hand, the title and the abstract are much more use-

ful than the complete article because they are usually

speciﬁc, succinct and written in an afﬁrmative way.

There is a large variety of articles in PubMed but

not all of them are useful for our purpose. The fol-

lowing are desirable characteristics:

• they must be writen in English, because the tools

to process them use English,

• we excluded reviews. Although the information

contained in them is of good quality, it must be

processed using natural language methods to rec-

ognize the structure and understand the contents

of the text. As a ﬁrst approach we have decided to

work without them, and

• the articles should not have been retracted, which

means that their contents are reliable.

We have implemented it by accesing Entrez from

the statistical software R (www.r-project.org).

2.2 Text Processing

Once the base of articles is collected, SalamboMiner

provides lots of information, but it is necessary to

extract the interesting elements. These elements are

those concepts that pertain to the biological pathways

that connect genes with the causative diseases. There

are lots of elements that cause diseases. To start, we

extract the more relevant elements which are genes,

proteins and diseases, since the elements that affect

directly to the occurrence of diseases are proteins

which are produced by genes.

The tools used in this module are:

• MeSH terms were assigned to the articles in the

PubMed database by NCBI curators.

• Uniﬁed Medical Language System (UMLS), a set

of sources and associated software developed in

the US National Library of Medicine was use-

ful to manage our biomedical data. An impor-

tant source of information in SalamboMiner is the

Metatheaurus, which is a uniﬁed set of biomed-

ical thesaurus that includes terms identiﬁed in a

conceptual manner. Another source used in our

project is the Semantic Network, which gives se-

mantics to the concepts and to the relationships

among them. In addition, we have used the soft-

ware MMTx that maps biomedical texts in order

to identify the UMLS concepts included in them.

• Biotagger, a biological Entity Recognizer (Mc-

Donald and Pereira, 2005).

We havedivided the text processing into two parts:

2.2.1 Extraction of Terms

It aims to ﬁlter, from all the terms in an article, those

which refer to genes, proteins and diseases. For that,

we have used MeSH terms assigned to articles. The

original purpose of the MeSH terms was to index the

articles so that they are easy to ﬁnd in the Pubmed

database. But, it is also useful for our purpose be-

cause the MeSH terms have also the ability to de-

scribe the contents of the articles. We used the MeSH

terms to identify genes, proteins and diseases. But, we

must improve the coverage of genes and proteins be-

cause the MeSH database does not cover completely

the known genes (Mary, 2004). To do that, we use the

Biotagger, which is specialized for recognizing genes

and proteins (Yeh, 2005).

2.2.2 Translation of Terms into Concepts

It is necessary to deal with the synonyms and

acronyms that are commonly used to refer to genes,

proteins and diseases. For this purpose we used the

UMLS, that allowed us to obtain the concepts that

unify the terms in refering to the same biological en-

tity. The UMLS thesaurus has a high coverage of

concepts of genes and proteins (Mary, 2004), since

the UMLS includes thesaurus like HUGO, OMIM,

SwisProt, GO, GOA, GeneBank, MeSH and MeSH

SR. The UMLS also covers properly the diseases, be-

cause it includes medical databases such as MeSH,

SNOMED, MEDCIN and ICD-9-CM among others.

We used the MMTx software to parse the ﬁltered in-

put terms and assign them an UMLS concept identi-

ﬁer.

SalamboMiner - A Biomedical Literature Mining Tool for Inferring the Genetics of Complex Diseases

145

2.3 Creating and Querying the

Knowledge Base

The knowledge base consists of the co-citations, as

it contains the concepts and their connections. The

method that we will use to obtain relationships be-

tween genes and diseases has two main components:

one is a probabilistic measure of the association be-

tween the genes and diseases. This is useful to extract

the degree of relationship between concepts that are

co-cited. And the second component is a mechanism

that facilitates the spread of the association probabil-

ity, that allows the discovery of relationships between

concepts that do not appear co-cited in the literature,

but there is at least one intermediate element that con-

nects them.

Association measure: The co-ocurrence of con-

cepts in the same biomedical article provides infor-

mation about the degree of relationship between these

concepts. There exist numerous measures of asso-

ciation between two concepts based on co-citations

(Lenca, 2008). We have selected the Bayes Factor. In

order to conclude that there exists a relationship be-

tween two concepts, we require a Bayes Factor mini-

mum threshold of 3.

A/B

A/¬B

(1)

A Bayes Factor higher than one means that ap-

pearing both concepts A and B is more strongly sup-

ported than appearing A but not B. The Bayes Fac-

tor is an asymetric measure and we will obtain two

Bayes Factors (BFA-¿B and BFB-¿A) associated to a

pair of co-cited concepts (A and B). To conclude that

there exists a relationship between two concepts, we

require a Bayes Factor minimum threshold of 3 (Jef-

freys, 1961).

Spread of the association: Bayesian Networks of-

fer a natural mechanism for the spread of probabilis-

tic information. Given two concepts (C1 and C2) that

are not co-cited directly, we create a Bayesian Net-

work (directed acyclic graph) that includes all of the

concepts that connect C1 with C2 in a path of length

two. Each edge of the network contains a table with

the conditional probability distribution of the states of

a node in respect to their parents. From that informa-

tion we can estimate the joint probability distribution

between C1 and C2. And, with this, we can estimate

the Bayes Factor between C1 and C2.

3 RESULTS

We present a user friendly tool implemented in the

programming language Java and the statistical soft-

ware R. Given a gene, SalamboMiner provides a

sorted list of the resulting relationships with diseases,

based on the co-citations observed in the set of ar-

ticles. Similarly it identiﬁes genes if the input is a

disease.

We have tested our tool using the set of Pubmed

articles that appeared in the OMIM database (Online

Mendelian Inheritance in Man) and that are related to

diabetes and thrombosis. It collected a total of 14,212

articles. After processing them we obtain 4,044 rele-

vant concepts that appear 56,386 times.

To validate the extraction of relationships, we

have taken as reference of accuracy the information

about the relationships between genes and diseases

that appear in the OMIM articles. In addition, we

have evaluated the results of the related concepts in

two steps with the help of an expert in the area of

these diseases.

3.1 The Query: the Gene Factor VIII

Given the gene for Factor VIII, SalamboMiner

searches the diseases in which Factor VIII is involved.

3.2 One-step Relationships

Table 1: Relationships that appear in OMIM.

Disease

Combined Factor V and VIII deﬁciency

Hemophilia A

von Willebrand disease

Table 2: Extracted relationships.

Concept Bayes Factor

Telangiectasia 67.52

Hemophilia A 62.16

von Willebrand Disease 38.49

Two of the three associations are annotated in the

OMIM database, “Hemophilia A” and “von Wille-

brand Disease”. Also, there is an OMIM annotation

not found by SalamboMiner, “Combined Factor V

and VIII deﬁciency”. This is due to the fact that it is a

combined deﬁciency and not a disease in itself. This

ﬁnding does not appear in any thesaurus. It is notable

that the results contain a new concept, that is “Telang-

iectasia”. It is not annotated in OMIM, but it can be

found associated with von Willebrand’s disease in the

BIOINFORMATICS 2011 - International Conference on Bioinformatics Models, Methods and Algorithms

146

literature along with an inhibitor of Factor VIII activ-

ity (Conlon, 1978) (Hanna, 1984) (Sudarshan, 1985)

(Gola, 1977).

3.3 Two-steps Relationships

Some of the relationships we obtained from concepts

that were not co-cited in the articles but have an inter-

mediary element that connect them, are as follows:

Table 3: Discovered relationships.

Concept Bayes Factor

Hemophilia A 125.93

Facial Dermatoses 52.60

Telangiectasia 51.30

Factor VII Deﬁciency 23.54

Photosensitivity Disorders 23.03

Thrombus 20.16

Factor V Deﬁciency 16.07

Cerebellar Diseases 12.59

Puerperal Disorders 11.54

Budd-Chiari Syndrome 11.53

Coagulation Protein Disorders 11.40

Dysgammaglobulinemia 10.64

Mesenteric Vascular Occlusion 10.01

Dog Diseases 9.48

Von Willebrand Disease 9.26

Color Vision Defect 9.05

Blood Platelet Disorders 8.91

Irritable Bowel Syndrome 8.47

Virus Diseases 8.42

Factor XII Deﬁciency 8.31

Carotid Artery Diseases 8.20

Gastrointestinal Diseases 8.20

Bernard-Soulier Syndrome 8.10

Thrombophilia 7.37

The coefﬁcient for the “Hemophilia A” is now

more consistent with reality, because Hemophilia A

is caused directly by a deﬁciency of Factor VIII.

We asked a doctor who specializes in coagula-

tion diseases, to ﬁll in a questionnaire in which we

listed the 61 concepts obtained. We asked him wether

the relationships that we found were “very strong”,

“strong”, “weak” or if there were “no relationship”.

The questionnaire had two stages: First, the doc-

tor completed the questionnaire without using any

auxiliary material. And second, the doctor used the

Pubmed database to ﬁll in the questionnaire.

The 60.7% relationships among the diseases are

actually related to the gene Factor VIII. Also a 39.3%

of the concepts are false positives. There are two main

groups of concepts with these results. One is com-

Table 4: Contingency table of the questionnaire answers.

Without PubMed With PubMed

No relationship 32 (52.5%) 24 (39.3%)

Relationship 29 (47.5%) 37 (60.7%)

posed by diseases associated to hemorrhages. Since

the deﬁciency of Factor VIII causes the characteris-

tic hemorrhages in Hemophilia A, any other mani-

festation associated with them will appear in our re-

sults, even though they do not have a true relationship

with Factor VIII. The group contains diseases or syn-

dromes caused by genes located on the Chromosome

X. These are all false positives. These results illus-

trate a generalized problem in using datamining tools.

However, it is more desirable to have false positives

than false negatives because they can be checked in

the literature.

Importantly, the answers given by the doctor did

not correlate very well with the scores of the two-

steps relationships. This can be due to the selected

measure, the Bayes Factor, and to the fact that we

were working with only 15,000 articles.

The results that we obtained with SalamboMiner

have provided new knowledge: 8 concepts (13%)

have been related by the expert in the second stage of

the questionnaire. These results contrast the informa-

tion that the doctor did not know but SalamboMiner

has automatically provided.

4 CONCLUSIONS

The strategy that we used to process the data in

the articles (Mesh terms + Biotagger + UMLS +

MetaMapTx) was suitable to reveal the essential con-

cepts in the articles. Thus, it is feasible to annotate all

of the articles in the Pubmed database including their

relevant concepts. The more articles used the more

objective and exhaustive will be the relationships.

The strategy of using a Bayesian Network to es-

timate the level of relationship between two non co-

cited concepts is useful, but we have to continue ana-

lyzing the association measures.

Our study analyzed over 15,000 articles. Our re-

sults are informativeand support the strategies that we

used: First, it obtained the expected concepts of the

OMIM database. And, second, it obtained relation-

ships among concepts that were not co-cited in our

sample of articles, but these relationships are exposed

in the Pubmed database.

As a general conclusion, we feel that Salam-

boMiner is a promising tool that can be very useful

for biomedical researchers to help them see relation-

ships in the literature that are not otherwise obvious.

SalamboMiner - A Biomedical Literature Mining Tool for Inferring the Genetics of Complex Diseases

147

REFERENCES

Aerts, S. e. a. (2006). Gene prioritization through genomic

data fusion. Nature Biotechnology, 24:537 – 544.

Bard, J. B. L. and Rhee, S. Y. (2004). Ontologies in biology:

design, applications and future challenges. Nature Re-

views Genetics, 5:213–222.

Cheng, D., Knox, C., Young, N., Stothard, P., Damaraju,

S., and Wishart, D. S. (2008). Polysearch: a web-

based text mining system for extracting relationships

between human diseases, genes, mutations, drugs and

metabolites. Nucleic Acids Res, 36.

Conlon, C. (1978). Telangiectasia and von willebrand’s dis-

ease in two families. Annals of Internal Medicine,

89:921–924.

Gajendrana, V. K., Linb, J.-R., and Fyhrie, D. P. (2007).

An application of bioinformatics and text mining to

the discovery of novel genes related to bone biology.

Bone, 40(5):1378–1388.

Gola, A. (1977). Ein fall von morbus osler mit gleichzeitig

bestehender thrombozytopenie und einem faktor viii-

inhibitor. Folia Haematologica, 104:102–108.

Gu, H. (2007). Evaluation of a umls auditing process of

semantic type assignments. AMIA Annu Symp Proc,

page 294298.

Hanna, W. (1984). A study of a caucasian family with vari-

ant von willebrand’s disease in association with vas-

cular telangiectasia and haemoglobinopathy. Throm-

bosis and Haemostasis, 51:275–278.

Hristovski, D., Peterlin, B., Mitchell, J. A., and Humphrey,

S. M. (2005). Using literature-based discovery to

identify disease candidate genes. International Jour-

nal of Medical Informatics, 74(2-4):289–98.

Hunter, L. (2006). Biomedical language processing: Per-

spective whats beyond pubmed? Molecular cell,

21(5):589594.

Jeffreys, H. (1961). The Theory of Probability. Oxford

University Press.

Jelier, R., Schuemie, M. J., Veldhoven, A., Dorssers, L. C.,

Jenster, G., and Kors, J. A. (2008). Anni 2.0: a multi-

purpose text-mining tool for the life sciences. Genome

Biology, 9(6).

Jenssen, T. K., Laegreid, A., Komorowski, J., and Hovig,

E. (2001). A literature network of human genes for

high-throughput analysis of gene expression. Nature

Genetics, 28(1):21–8.

Lakoff, G. and Johnson, M. (1980). Metaphors we live by.

IL: University of Chicago Press.

Lenca, P. (2008). On selecting interestingness measures for

association rules: User oriented description and mul-

tiple criteria decision aid. European journal of opera-

tional research, 98(5):1031–9.

Mary, V. (2004). Mesh and specialized terminologies : cov-

erage in the ﬁeld of molecular biology. Studies in

Health Technologies and Informatics, 107(Pt 1):530–

McDonald, R. and Pereira, F. (2005). Identifying gene

and protein mentions in text using conditional random

ﬁelds. BMC Bioinformatics, 6(Suppl 1):S6.

Perez-Iratxeta, C. (2002). Association of genes to genet-

ically inherited diseases using data mining. Nature

Genetics, 31:316 – 319.

Seki, K. and Mostafa, J. (2007). Discovering implicit asso-

ciations between gens and hereditary diseases. Paciﬁc

Symposium on Biocomputing, 12:316–327.

Shah, P. K., Perez-Iratxeta, C., Bork, P., and Andrade, M. A.

(2003). Information extraction from full text scientiﬁc

articles: Where are the keywords? BMC Bioinformat-

ics, 4:20.

Sudarshan, A. (1985). Hereditary hemorrhagic telangiecta-

sia and factor viii inhibitor. Southern Medical Journal,

78:623–624.

Tsuruoka, Y., Tsujii, J., and Ananiadou, S. (2008). Facta:

a text search engine for ﬁnding associated biomedical

concepts. Bioinformatics, 24:2559–2560.

Weeber, M. (2005). Online tools to support literature-based

discovery in the life sciences. Brieﬁngs in Bioinfor-

matics, 6(3):277–286.

Yeh, A. (2005). Biocreative task 1a: gene mention ﬁnding

evaluation. BMC Bioinformatics, 6(Suppl 1):S2.

Zweigenbaum, P. (2007). Frontiers of biomedical text min-

ing: current progress. Brieﬁngs in Bioinformatics,

8(5):358–375.

BIOINFORMATICS 2011 - International Conference on Bioinformatics Models, Methods and Algorithms

148
