BSN MIDDLEWARE

Abstracting Resources to Human Models

Pedro Brand˜ao and Jean Bacon

Computer Laboratory, University of Cambridge, Cambridge CB3 0FD, United Kingdom

Keywords:

Body Sensors, Networks, System Architecture, Models.

Abstract:

In the sensor network area, BSNs encompass a particular set of restrictions and conditions that separate them

from normal WSNs. More so than WSNs, BSNs would proﬁt from different types of sensing information

and the sensor network itself provides more opportunities for different applications to use the same resources.

However, the heterogeneity of sensor HW devices and the myriad of different applications that try to use them

are an obstacle to its development. A problem is the need to address speciﬁc characteristics of the HW with-

out abstractions that 1) provide the freedom to access the needed information while 2) complying to a set of

requirements and 3) optimizing resource usage according to a set of metrics. We propose a middleware ap-

proach for abstracting lower level details from applications. We enrich the approach by building models in the

middle layer fed with data from the sensor network and query-able from the application layer. Furthermore: a)

applications should be able to set requirements to be met in providing the information, b) several applications

should be able to share the same resources, c) the resources should be optimized so as to meet the requirements

and prolong the lifetime of the BSN.

1 INTRODUCTION

Healthcare surveillance and ﬁtness assessment has led

to the proliferation of sensor use for human body

monitoring purposes. This can be seen in commer-

cial products for ﬁtness assessment (eg.: (Vivomet-

rics, 2007)) and research initiatives as (Lo and Yang,

2006; Korhonen et al., 2003) for health monitoring.

Projects like Sesame (Computer Laboratory, 2007) at

University of Cambridge that deal with assessing ath-

letes performances, the Angel project (Garino et al.,

2007) from the 6

Framework EU program that focus

on modelling, simulation and deployment of Body

Sensor Network (BSN) applications and CodeBlue

(Lorincz et al., 2004) from Harvard University that

deals with network concerns in BSNs and Hardware

(HW) for BSNs R&D) are examples of current re-

search projects that focus on BSNs.

The trend and the need is here for BSNs, where

the sensor network lies within the limits of the human

body. There are several applications domains, be it

monitoring vital signals of 1

responders (eg.: (Vivo-

metrics, 2007)) and/or victims (Lorincz et al., 2004)

in disaster scenarios, health monitoring (Korhonen

et al., 2003) (ranging from physical and chemical

measures (Johannessen et al., 2005) to video imag-

ing (Coimbra et al., 2006)) or speciﬁc disease treat-

ment (eg.: diabetes (Steil et al., 2004)). Deriving

user context and performance are also scenarios dealt

with BSNs, for example: (Lukowicz et al., 2006) uses

force sensors to detect muscle work and correlate it

with fatigue and freshness of users to derive recog-

nition patterns and in (Aylward and Paradiso, 2006)

inertial sensors are used to discern group movement

in dance.

It is worth noting that although the current mo-

mentum on BSNs, this research area can be dated

back to 1961 with work from Mackay (Mackay, 1961)

opening prospects for this trend. The area has been

dormant until around a decade ago where interest in

the subject reappeared. First as just a new view of

Personal Area Networks (PANs) and gradually as a

new type of network composed of sensor devices.

One issue that currently remains not addressed in

BSNs is the possible heterogeneity of available infor-

mation. Most of the references mentioned deal with

just one type of information or have to go to great

lengths to use different sources of sensing data. Being

able to have plug-n-play sensors where adding a new

sensor into the BSN would imply its availability as a

source of information is, in our view, a major prob-

245

Brandão P. and Bacon J. (2009).

BSN MIDDLEWARE - Abstracting Resources to Human Models.

In Proceedings of the International Conference on Health Informatics, pages 245-250

DOI: 10.5220/0001545802450250

 SciTePress

lem. This would enable a better and more accurate

estimation of the current situation through the corre-

lation of different sensing information. As an exam-

ple, blood pressure is more accurately measured when

taking blood pressure, blood ﬂow and oxygen levels.

By adding an intermediate layer (middleware) to the

process we could have: i) application requests blood

pressure information; ii) middleware retrieves data

from the available sensors (which could involve acti-

vating them); iii) middleware aggregates the available

information using a deﬁned model, adding metadata

about the information (conﬁdence on the value (based

on the model and the data available), error margin

(taking into account statistics of the sensors used),

time of assessment, etc); iv) middleware provides the

application the information and metadata; v) applica-

tion handles the information taking into account its

metadata. The application request could (and most

likely would) have requirements associated.

As such, we see the main problem in BSNs bound

to the need to address speciﬁc characteristics of the

HW without any abstraction that 1) provides the free-

dom to access the needed information while 2) com-

plying to a set of requirements and 3) optimizing re-

source usage according to a set of metrics.

Our proposal is a middleware layer that abstracts

the underlying BSN to the application, providing an

information model to be queried. The information on

the model itself is derived using the data provided by

the BSN and applications state the models they want

to use. Application requirements and resource opti-

mization are also responsibilities of the middleware.

Section 3 will detail this architecture.

1.1 WSN and BSN

BSNs have several similarities with Wireless Sen-

sor Networks (WSNs), starting with being composed

by sensor nodes (albeit different) that form a net-

work. However we argue that there are several dif-

ferences that lend BSNs prone to different problems,

approaches and optimizations possibilities. Table 1

summarizes the aspects we regard fundamental, stat-

ing differences and similarities.

In our view, BSNs will have a central component

that receives and acts upon the nodes as the applica-

tions using it deem necessary. A PDA, mobile phone

or a more powerful node can be this component or can

act as a Gateway (GW) to the central component(e.g.:

a PC on a home environment). This central compo-

nent (Base Station (BS)) will be able to control all the

BSN, as the topology formed will be one-hop from it

to the nodes, due to the close range. The nodes will

refrain from much processing, delivering most of the

data to the BSs

. The data set treated will be very

heterogeneous, with possibly complex relationships

among the different types of data. BSNs are prone

to have different types of nodes added.

In WSNs the central component may or not exist

and if present will have a more limited view of the

whole system. WSNs tend to process the information

in a distribute approach; with nodes treating, corre-

lating and aggregating information, forming clusters,

etc. The network in WSNs is multi-hop due to the

usual large areas covered. The sensors in WSNs are

homogeneous in terms of HW and data acquisition.

As such, the information processed will normally be

of the same type, although some frameworks do offer

limited support for heterogeneity (see section 2).

Both frameworks have similar energy constraints

(the research on recharging also shares some com-

monality (Paradiso, 2005) and (Roundy et al., 2004)).

The differences stated lead to an easier to manage

network in BSNs in terms of connectivity establish-

ment and coordination/optimization of sensor nodes.

This opens more possibilities for optimizing the sen-

sor network usage. However, BSNs monitor different

types of information with complex interrelations be-

tween them, that can change from application to ap-

plication. To add to this, applications will also have

different requirements on the usage of the network

(Quality of Service (QoS), error, rates, etc). A mid-

dleware should handle these concerns so to provide

the applications with the abstract information they

need releasing them from the speciﬁcities of the un-

derlying resources.

2 RELATED WORK

In this section we will brieﬂy describe some ap-

proaches that try to add ﬂexibility and counteract het-

erogeneity. As an initial note, middleware speciﬁc for

BSNs still remains largely unexplored, thus some of

the work described here is from the WSN world.

As a counter example to the previous statement,

we have the middleware from the Angel EU project

(Garino et al., 2007) mentioned in section 1: Abstract

Middleware Services (Fummi et al., 2007). The ap-

proach provides an environment aimed at early simu-

lation and validation. It abstracts from the program-

mer the speciﬁc implementation to be used in the de-

ployment. For this, it is able to be mapped to current

existent middleware frameworks divided in: database

abstraction, tuple-space based, object oriented and

As counter example, the Equivital node (Equivital,

2007) processes all sensing information incorporating algo-

rithms for producing the processed information.

HEALTHINF 2009 - International Conference on Health Informatics

246

Table 1: BSN vs WSN.

BSN WSN

Distrib.

i. Existence of a Base Station (BS);

ii. BS collects, maintains and processes the data;

iii. Nodes will do minimal processing, sending all data to

the BS;

iv. Centralized system where BS controls all nodes.

i. A BS may or not exist or there may be several BSs (may

be mobile to collect info);

ii. Same as in BSN, but also focus on on-demand querying;

iii. Nodes will do processing, aggregation to alleviate com-

munication or correlate results;

iv. Distributed system where nodes decide cooperatively.

Comm.

i. One hop to BS;

ii. Close range but attenuated by body.

i. Multi hop through network of sensor nodes;

ii. Long range.

Energy

i. Constrained;

ii. Replacement is difﬁcult in in-body sensor nodes;

iii. Recharging may be possible with scavenging or induc-

tive coupling.

i. Constrained;

ii. Replacement is difﬁcult due to location, scale, etc;

iii. Recharging may be possible in some scenarios with nat-

ural energy or scavenging.

Data

i. Correlation of different type of sensing information;

ii. Likely to have new types of sensors added;

iii. Prone to have different applications using the same re-

sources.

i. Usually aggregating the same type of information;

ii. Typically static in terms of node types (adding new sen-

sors of the same type);

iii. Usually deployed with one application in mind.

message based. The programmer is provided with

an abstraction for the HW and network that enables

the simulation of the application. The next phase of

deployment implies letting go the network abstrac-

tion embedded in the middleware and having a sep-

arate model for simulating the network. The ﬁnal

phase maps the application to a speciﬁc implemen-

tation chosen. This approach does not free the appli-

cation developer from the underlying resources char-

acteristics per se, but provides a framework for early

testing. The mapping to a speciﬁc framework carries

the need to understand the framework and how it pro-

vides its results. Application requirements are said to

be speciﬁed in the ﬁrst phase of deployment, but they

lack a description of the process, leading to the idea

that the requirements are deﬁned in the initial pro-

gram by the developer in speciﬁc terms (taking into

account the framework chosen).

Some research proposals for WSNs, tackle some

of the issues we dubbed relevant. Namely: Middle-

ware Linking Applications and Networks (MiLAN)

(Heinzelman et al., 2004) tries to cope with ”the

gap between the protocol and the application [that]

is often too large to allow the protocols to be effec-

tively used by application developers”, by tackling

what they devise as the features of sensor applica-

tions: distribution, dynamicity in the availability of

sensor nodes, constraint application QoS demands,

resource limitation (bandwidth and energy) and coop-

erative applications. This last issue relates to different

applications using the same network to achieve differ-

ent objectives. MiLAN tries to cope with different ap-

plication requests using their QoS requirements as in-

put. It also takes into account the network information

(energy and bandwidth) and the system’s information

on the relevance of the different applications. MiLAN

uses as input: i) the data (variables) that the applica-

tion needs, ii) the required QoS for each variable and

iii) the level of QoS that each sensor or group of sen-

sors can provide for each variable. This information

is deﬁned through the use of two sets of graphs. These

graphs enable the deﬁnition of sets of sensors to fulﬁl

the requirements of the applications. Another compo-

nent related to network characteristics deﬁnes another

set of sensors capable of evaluating the needed infor-

mation. The intersection of the sets gives the sensors

such as to maximize the time that the information can

be given (energy restriction).

In an attempt to ease application development, by

providing a known development environment, some

HW has been developed to directly support the Java

programming language. Sun with SUNSpot (SUN,

2007) and Sentilla (Sentilla, 2008) are deploying sen-

sor nodes that natively support Java. The rationale is

to abstract from the application developer some of the

underlying speciﬁcs of the HW by providing a famil-

iar environment. However, the abstraction provided

is at the language level, and most of the knowledge

about the HW must still be known to correctly and

efﬁciently implement the application. Our proposal

intends to put the abstraction at the information level.

There are other abstractions providing querying

interfaces that ease the development (such as TinyDB

(Madden et al., 2005) and Cougar (Yao and Gehrke,

2002)). They handle some heterogeneity by taking

the information sensed as input for Database (DB)

like functions. However, this abstraction is limited

in terms of functionality (DB like functions related

BSN MIDDLEWARE - Abstracting Resources to Human Models

247

to aggregation and threshold methodology) and does

not provide the abstraction at the information layer.

Other proposals like XMiddle (Mascolo et al., 2002)

and Hood (Whitehouse et al., 2004) enable data shar-

ing across different nodes relying on data structure

abstractions (XML in XMiddle) to deal with the dif-

ferent data. Here the focus is on data replication and

coherence and not explicitely on providing the notion

of correlation between different types of information

at a higher layer.

The work mentioned does not address the speci-

ﬁcities of BSNs mentioned in section 1.1 (short range,

BS availability, etc), which leaves room for further

improvement. Also enabling the applications require-

ments to inﬂuence the resource allocation, thus cross-

ing (or more precisely, adapting) layer information,

will enable more opportunities for optimization (not

needing to take worst case approaches).

3 ABSTRACTION

As introduced in section 1 the motivation for this pro-

posal lies in the lack of an information abstraction

to the sensor resources that copes with: i) collection

and aggregation of sensor data to provide higher level

information; ii) Metadata about the information de-

rived; iii) compliance to application requirements; iv)

management and optimization of resources. The ra-

tionale being that, applications are not interested in

handling the sensors but accessing speciﬁc informa-

tion. This view is similarly defended for WSNs in

(R¨omer, 2004). We introduce a middleware layer that

provides the said abstraction and functionalities.

The general middleware objectives would be: A)

collect data from sensor nodes; B) convert this data

to relevant information in a human body model; C)

collect metadata on the data received and correlate

it to the information on the model; D) answer re-

quests from applications based on the information in

the model providing the related metadata; E) opti-

mize resource usage (turn on/off, increase/decrease

frequencies of data collection, etc) while complying

to requirements set by the applications. Figure 1 de-

picts this architecture.

The next sections brieﬂy describe the most rele-

vant issues on this architecture.

3.1 Human Models

One of the interesting points in the problem at hand

is related to the models to be used by the middleware.

More speciﬁcally, how will the middleware map the

data from the sensor network to the human model?

Middleware

Sensor

Node

Middleware

Sensor

Node

Middleware

Sensor

Node

Middleware

Sensor

Node

Middleware C

Apps

Models

Data sensed

Information

Queries

Information

answers and

metadata

Body Area Network

Control/Optimize

Middleware

Sensor

Node

Sensor

Node

Objective

Figure 1: Architecture Proposed.

One approach is to develop a system similar to

MiLAN (Heinzelman et al., 2004) (see section 2). It

deﬁnes graphs that identify the relationship between

sensed values and information assessment. The value

can then be part of another graph that deﬁnes system

states. The weights in these graphs describe the im-

portance of the sensor data or value in the assessment

of the information.

This system allows for a ﬂexible deﬁnition of

models. It nonetheless lacks some formality and stan-

dardization in terms of having a wider acceptance.

The previous comment arises from the existence of

projects that have a more wider and formal approach

to deﬁne human biological models. As an exam-

ple, the Physiome Project (Hunter et al., 2002) aims

“to use computational modelling to analyse integra-

tive biological function in terms of underlying struc-

ture and molecular mechanisms”. Here, the objective

is to enable a mathematical handling of the Human

body. To achieve this it follows a hierarchical mod-

elling where the human body is divided in organs ⇒

composed of tissues ⇒ made up of cells ⇒ built on

proteins ⇒ that are divided in atoms. The physical

and chemical relationships between the hierarchies

and the modules at each level are to be deﬁned. The

weight of introducing such a system in a middleware

layer could be overwhelming or even an overkill. On

the other hand, it can provide a more comprehensible

(from the application point of view) model to query.

An architecture that enables applications to in-

put the model that they want to use (stating how in-

formation is correlated) provides a ﬂexible approach.

These models should be nonetheless framed such that

the middleware is able to: i) unequivocally iden-

tify the information and its source; ii) infer com-

monalities between different models as to optimize

HEALTHINF 2009 - International Conference on Health Informatics

248

resources and iii) clearly interpret how the meta-

data correlates in the model. Figure 2 gives a draft

view of a possible tree model, where the difference

from

BasicDataType

and

DerivedDataType

could

be made irrelevant when the information that nodes

produce is mapped to any level of the tree. Correla-

tion of metadata information (error, rate, etc) is part

of the model.

Deﬁning a model that characterizes the mapping

from sensor data to model information to serve as an

input to the middleware is a major challenge.

App 1

weight

DerivedData

Type

DerivedData

Type

DerivedData

Type

weight

BasicDataType BasicDataType

App 2

weight

DerivedData

Type

DerivedData

Type

DerivedData

Type

weight

BasicDataType BasicDataType

DerivedData

Type

Can be function

with state

Figure 2: Models with detected common data type.

3.2 Middleware

As stated, the middleware will deal with managing

resources so to fulﬁl applications requirements. As

seen in ﬁgure 1 there will be parts running on the

nodes (Middleware N) and the main block running

on the central component

(Middleware C). The mid-

dleware on the node would be responsible for: i) ad-

vertising the nodes capabilities (sensing information,

accuracy, rate, resources available (energy, process-

ing, network), etc); ii) abide to the central compo-

nent’s commands (turn sensors on/off, change rate,

etc); iii) answer information requests from central

component. The central component, as mentioned,

will have greater responsibilities so to: i) receive and

incorporate models received from apps; ii) receive re-

quests from apps with the associated requirements to

be fulﬁlled; iii) derive from the different models, re-

quirements and resources available a solution that sat-

isﬁes the apps and optimizes resource usage; iv) con-

trol the sensors according to the solution found and

request and receive information from them; v) main-

tain the model information and associated metadata

from the sensor information (data and new sensor ad-

vertisements) so to re-evaluate the solution found.

Point iii) for the central component incorporates

the optimization process and is the most relevant.

The GW architecture is not discussed here, but would

involve an extra block acting as a net GW.

3.2.1 Optimization

Finding a solution to maximize resource usage while

satisfying application requests will mandate a deﬁni-

tion of what are the requirements, metrics and con-

trolled resources and how to map requirements to

metrics so to optimize the said resources.

We have already undertaken work on the ﬁrst

point where requirements (eg.: real time, data updates

frequency, etc), metrics (eg.: QoS related, quality of

measurement related, etc) and resources (eg.: network

architecture, processing power, etc) have already been

drafted. Optimization algorithms will play the rele-

vant role in this issue.

Resources in these networks may change very

abrupt and unpredictably. This raises the problem

of how does the middleware handle the commitment

to fulﬁl requirements when resources are very unsta-

ble. A simple ﬁrst solution is the usage of metadata

indicating the reliability of the information and trig-

gers when resources disappear, letting the application

deal with the failure. However, this should only oc-

cur when no other solution is feasible from the central

middleware’s perspective.

The issues described in section 1.1 that differentiate

BSNs from WSNs will take great inﬂuence on the

middleware. As stated, management will be simpler

with a central point and one hop communication paths

while the range of application and requirements will

pose severe constrains and opportunities on the opti-

mization process. This is then coupled with the need

to merge different models from different applications

to reach the best solution.

4 CONCLUSIONS

Our proposal aims to release the BSN application de-

veloper from the details of the underlying HW by pro-

viding an abstraction to these resources, enabling the

application to access the underlying information cor-

related and aggregated from the data provided by the

BSN. Thus, applications can gain with data from

different types of sensors (for the same or differ-

ent types of information) without needing to address

their speciﬁcities; applications can set requirements

to be met in providing the requested information; sev-

eral applications can more easily be accommodated

on top of the same set of resources; resource usage

can be optimized while taking into account the pre-

vious mentioned points; sensor plug-n-play capabil-

ity can more easily be attained; compartmentaliza-

tion of responsibilities provides better room for im-

BSN MIDDLEWARE - Abstracting Resources to Human Models

249

provements/updates(eg.: updating resource optimiza-

tions algorithms will not imply changes in applica-

tions). Applications can access higher level informa-

tion based on a model that derives its values from the

data on the sensor network.

Models, the mapping between sensor data and

model information and the optimization of resources

while meeting requirements are the main challenges.

Other issues like network topologies and service dis-

covery are also future work as the former will be re-

lated to resources and the latter with the ability to ac-

cess information in a plug-n-play architecture.

Experiments (healthcare and physical assessment)

will be undertaken at a future point to test the pro-

posed architecture.

ACKNOWLEDGEMENTS

Pedro Brand˜ao is partially funded by Fundac¸˜ao para

Ciˆencia e Tecnologia from Portugal.

REFERENCES

Aylward, R. and Paradiso, J. A. (2006). Sensemble: A wire-

less, compact, multi-user sensor system for interac-

tive dance. In NIME, pages 134–139, 1, place Igor-

Stravinsky, 75004 Paris. IRCAM.

Coimbra, M., Campos, P., and Cunha, J. P. (2006). Topo-

graphic segmentation and transit time estimation for

endoscopic capsule exams. In Acoustics, Speech and

Signal Processing, 2006. ICASSP 2006 Proceedings.

2006 IEEE International Conference on, volume 2,

pages 1164–1167.

Computer Laboratory, D. T. G. (2007). Sesame Project.

www.sesame.ucl.ac.uk.

Equivital (2007). Equivital. www.equivital.co.uk.

Fummi, F., Perbellini, G., Pietrangeli, R., and Quaglia, D.

(2007). A middleware-centric design ﬂow for net-

worked embedded systems. In Design, Automation &

Test in Europe Conference & Exhibition, pages 1048–

1053, Nice, France. EDA Consortium.

Garino, P., Gorski, J., Gouw, M. D., Huebner, A., Quaglia,

D., and Willig, A. (2007). An integrated approach for

the design of applications based on body sensor net-

works to improve quality of life. White paper, Angel

Project, Angel project white paper.

Heinzelman, W. B., Murphy, A. L., Carvalho, H. S., and

Perillo, M. A. (2004). Middleware to support sensor

network applications. Network, IEEE, 18:6–14.

Hunter, P., Robbins, P., and Noble, D. (2002). The IUPS

human physiome project. Pﬂugers Arch, 445:1–9.

Johannessen, E. A., Wang, L., Reid, S. W. J., Cumming,

D. R. S., and Cooper, J. M. (2005). Implementation

of radiotelemetry in a lab-in-a-pill format. Lab on a

Chip, 6:39 – 45.

Korhonen, I., Parkka, J., and Gils, M. V. (2003). Health

monitoring in the home of the future. Engineering in

Medicine and Biology Magazine, IEEE, 22:66–73.

Lo, B. P. and Yang, G.-Z. (2006). Body sensor networks:

Infrastructure for life science sensing research. In Life

Science Systems and Applications Workshop, 2006.

IEEE/NLM, pages 1–2.

Lorincz, K., Malan, D. J., Fulford-Jones, T. R., Nawoj, A.,

Clavel, A., Shnayder, V., Mainland, G., Welsh, M.,

and Moulton, S. (2004). Sensor networks for emer-

gency response: challenges and opportunities. Perva-

sive Computing, IEEE, 3:16–23.

Lukowicz, P., Hanser, F., Szubski, C., and Schobersberger,

W. (2006). Detecting and interpreting muscle activity

with wearable force sensors. In Pervasive Computing,

volume 3968/2006 of Lecture Notes in Computer Sci-

ence, pages 101–116. Springer Berlin / Heidelberg.

Mackay, R. S. (1961). Radio telemetering from within the

body. Science, 134:1410.

Madden, S. R., Franklin, M. J., Hellerstein, J. M., and

Hong, W. (2005). Tinydb: an acquisitional query

processing system for sensor networks. ACM Trans.

Database Syst, 30:122–173.

Mascolo, C., Capra, L., Zachariadis, S., and Emmerich, W.

(2002). Xmiddle: A data-sharing middleware for mo-

bile computing. Wireless Personal Communications,

21:77–103.

Paradiso, J. A. (2005). Energy scavenging for mobile

and wireless electronics. IEEE Pervasive Computing,

4:18–27.

R¨omer, K. (2004). Programming paradigms and middle-

ware for sensor networks. GI/ITG Fachgespr¨ach Sen-

sornetze, Karlsruhe.

Roundy, S., Wright, P. K., and Rabaey, J. M. (2004). En-

ergy Scavenging for Wireless Sensor Networks: With

Special Focus on Vibrations. Kluwer Academic Pub-

lishers.

Sentilla (2008). Sentilla. www.sentilla.com.

Steil, G. M., Panteleon, A. E., and Rebrin, K. (2004).

Closed-loop insulin delivery-the path to physiological

glucose control. Adv Drug Deliv Rev, 56:125–144.

SUN (2007). SunSPOT. www.sunspotworld.com.

Vivometrics (2007). VivoMetrics. www.vivometrics.com.

Whitehouse, K., Sharp, C., Brewer, E., and Culler, D.

(2004). Hood: a neighborhood abstraction for sen-

sor networks. In International Conference On Mobile

Systems, Applications And Services, pages 99–110,

Boston, MA, USA. ACM.

Yao, Y. and Gehrke, J. (2002). The cougar approach to in-

network query processing in sensor networks. SIG-

MOD Rec., 31:9–18.

HEALTHINF 2009 - International Conference on Health Informatics

250
