MULTI-CHIRP SIGNAL SEPARATION

B. Dugnol, C. Fern´andez, G. Galiano and J. Velasco

Dpto. de Matem´aticas, Universidad de Oviedo, c/ Calvo Sotelo s/n, 33007 Oviedo, Spain

Keywords:

Parametric model, Chirplet transform, Instantaneous frequency, Signal separation.

Abstract:

Assuming that an speciﬁc audio signal, such as recordings of animal sounds, may be modelled as an addition

of nonlinear chirps, we use the quadratic energy distribution corresponding to the Chirplet Transform of the

signal to produce estimates of the corresponding instantaneous frequencies, chirp-rates and amplitudes at each

instant of the recording and design an algorithm for tracking and separating the chirp components of the signal.

We demonstrate the accuracy of our algorithm applying it to some synthetic and ﬁeld recorded signals.

1 INTRODUCTION

For many audio recordings obtained from natural

sources, such as emission from animals, it is a conve-

nient approach to use a parametric model in terms of

a super-position of chirps, s(t) =

∑

n

a

n

(t)exp[iφ

n

(t)],

with a

n

the analytic amplitude and φ

n

the phase,

whose derivative determines the chirp instantaneous

frequency (IF).

There are several techniques focused in the am-

plitude and phase estimation of this kind of sig-

nals. McAulay and Quartieri (McAulay and Quatieri,

1986) propose algorithms based on the STFT, while

for instance in (Maragos et al., 1993; Santhanam and

Maragos, 2000) these estimates are obtained through

the use of the Teager-Kaiser operator, E = (x

′

(t))

2

−

x(t)x

′′

(t). The IF estimation via non-parametric

models using Cohen distributions is also an impor-

tant issue, see, for instance, (Stankovi´c and Djurovi´c,

2003; Kwok and Jones, 2000; Zhao et al., 2004;

Boashash, 1992a; Boashash, 1992b).

Other kind of approaches, such as the empirical

mode decomposition (EMC) (et al., 1998)) or the Gi-

anfelici transform (Gianfelici et al., 2007) focus on

the signal decomposition in terms of basis which de-

pend on the given function.

In (Dugnol et al., 2008) we proposed a method-

ology based on the chirplet transform (Mann and

Haykin, 1991) to identify and separate the different

chirps conforming the given signal. To do this, not

only amplitude and IF estimation was needed but also

the so called chirp rate (CR, phase second derivative).

We showed that the quadratic energy corresponding

to the chirplet transform may be used for this task

since for each time of a discrete time mesh the max-

ima points of the energy in the IF-CR plane corre-

spond to some of the IF and CR of the existent chirps.

However, some other maxima are spurious maxima,

not corresponding to any chirp at all. Our previous

algorithm, see (Dugnol et al., 2008), had some inefﬁ-

ciencies regarding the identiﬁcation of these spurious

maxima and, accordingly, to the matching process to

construct the global chirp components of the signal.

In this work we introduce important improvements to

our previous algorithm.

2 CHIRPLET TRANSFORM

ENERGY DISTRIBUTION

For a given signal f ∈ L

2

(R) we consider its chirplet

transform given by

Ψf (τ,ξ,µ;λ) =

Z

∞

−∞

f (t)

ψ

µ,λ

(t − τ)exp[−iξt]dt,

with τ,ξ and µ standing for time, IF and CR, respec-

tively, parameter λ determining the window width and

with ψ

µ,λ

a complex window deﬁned as

ψ

µ,λ

(s) = v

λ

(s)exp

h

i

µ

2

s

2

i

,

with v

λ

(s) = λ

−1/2

v(s/λ) and v a non-negative, nor-

malized, symmetric window. The quadratic energy

corresponding to the chirplet transform is then given

by

P

ψ

f (τ,ξ, µ;λ) = |Ψf (τ,ξ,µ;λ)|

2

. (1)

216

Dugnol B., Fernández C., Galiano G. and Velasco J. (2009).

MULTI-CHIRP SIGNAL SEPARATION.

In Proceedings of the International Conference on Bio-inspired Systems and Signal Processing, pages 216-221

DOI: 10.5220/0001432802160221

Copyright

c

SciTePress

We notice that Ψf may be rewritten as

Ψf (τ,ξ,µ,λ) =

Z

∞

−∞

f

′

(x)exp

h

−i

ξx+

µ

2

x

2

i

dx,

with f

′

(x) = f (x+ τ)v

λ

(x)exp[− iξτ], implying that

the Chirplet Transform provides a correlation mea-

sure of the linear chirp exp

−i

ξx+

µ

2

x

2

and the

portion of the signal centered at τ, . It is, then, clear

that for a linear chirp

f (t) = a

1

(t)exp

h

i

α

1

2

(t − τ)

2

+ β

1

(t − τ)+ γ

1

i

(2)

and for ﬁxed τ and λ, the quadratic energy distribu-

tion P

Ψ

f(τ,ξ,µ;λ) has a global maximum at (ξ,µ) =

(α

1

,β

1

), allowing us to determine the IF and CR of

a given linear chirp at a ﬁxed time by computing the

maximum point of the energy distribution. Moreover,

the following result holds, see (Dugnol et al., 2008):

For

f (t) = a(t)exp[iφ(t)] , (3)

and for all ε > 0 and ξ,µ ∈ R there exists L > 0 such

that if λ < L then

P

Ψ

f (τ,ξ,µ;λ) 6 λε+ P

Ψ

f

τ,φ

′

(τ),φ

′′

(τ);λ

. (4)

In addition,

lim

λ→0

1

λ

P

Ψ

f

τ,φ

′

(τ),φ

′′

(τ);λ

= a(τ)

2

. (5)

In other words, for a general mono-component chirp

the energy distribution maximum provides an arbi-

trarily close approximation to the IF and CR of the

signal. Moreover, its amplitude may also be estimated

by shrinking the window time support at the maxi-

mum point. In fact, these estimates make also pos-

sible to establish criteria for deciding, in the case of

a multi-chirp signal, when two energy maxima points

in the IF-CR plane do belong to the same chirp or to

different chirps, and in this way, it conforms a pro-

cedure for separating the chirp components (Dugnol

et al., 2008).

2.1 Energy Distribution in the CR-IF

Plane

It may be experimentally observed that the support of

the energy distribution of a one-chirp signal like (3)

for a ﬁxed time τ has a geometric shape given by a

double cone with vertex at (φ

′′

(τ),φ

′

(τ)) in the CR-

IF plane, see Figure 1.

Let us analyze the case of a linear chirp like (2) to

get some analytical insight into this property. By us-

ing an appropriate window we may restrict the anal-

ysis to the time interval (τ− λ,τ + λ). Fixing the ξ

value in the energy distribution (1) we obtain a line

I.F.

Chirp-rate

Figure 1: Energy distribution for one chirp signal at the CR-

IF plane.

bundle at (τ,ξ) generated by the different values of

the slope µ, see Fig. 2. For the energy distribution

to be remarkable, the segment deﬁned in the time-

frequency plane by the chirp ω = α

1

(t − τ)+ β

1

must

intersect this bundle. Typically there exists a range

of slopes for which this intersection is not empty, see

Fig. 2. In particular, let r

ξ

(µ) = ξ + µ(t − τ) be the

line passing through (τ,ξ) with slope µ, and let

µ

m

:= min

α

1

+

ξ− β

1

λ

,α

1

−

ξ− β

1

λ

and

µ

M

:= max

α

1

+

ξ− β

1

λ

,α

1

−

ξ− β

1

λ

.

Then if µ ∈ (µ

m

,µ

M

), the segment r

ξ

(µ) = ξ+µ(t − τ)

does not intersect the chirp and therefore the energy

is negligible.

T ime

I.F.

(τ, ξ)

(τ, β

1

)

r

ξ

(µ

1,o

)

r

ξ

(µ

1,f

)

Figure 2: Shadow region corresponds to the chirplet negli-

gible energy set.

MULTI-CHIRP SIGNAL SEPARATION

217

T ime

Instantaneous frequency

ω = α

1

(t − τ) + β

1

r

µ

(ξ

1,0

)

r

µ

(ξ

1,f

)

Figure 3: Shadow region corresponds to the chirplet con-

centration energy set.

In a similar way, if we keep ﬁxed the CR value

µ and move the IF value ξ we obtain that the en-

ergy is negligible outside an interval which depends

on the slopes µ,α

1

y α

2

, see Fig. 3. More precisely,

writing ξ

m

= min{β

1

+ λ(µ− α

1

),β

1

− λ(µ− α

1

)}

and ξ

M

= max{β

1

+ λ(µ− α

1

),β

1

− λ(µ− α

1

)}, we

have that the energy of the chirplet transform is con-

centrated in the interval (ξ

m

,ξ

M

).

Summarizing, for a one-chirp signal of the linear

form (2) we have that, for ﬁxed time, its energy is con-

centrated in a region of the CR-IF plane of the form

(−∞,µ

m

(ξ))∪(µ

M

(ξ),+∞)×R ≡ R ×(ξ

m

(µ),ξ

M

(µ))

which illustrates de double cone shape in Fig. 1.

2.2 Spurious Maxima

For the more interesting case of a signal composed by

several chirps, the energy distribution will have max-

ima not only at ridge points but at the so called spuri-

ous maxima points. To understand this situation, we

consider a signal composed by two linear chirps

f (t) =

2

∑

k=1

a

k

(t)exp

h

i

α

k

2

(t − τ)

2

+ β

k

(t − τ)+ γ

k

]

Considering again a window centered at τ and of

width λ the time-frequency representation of the sig-

nal will be a pair of segments deﬁned on the time

interval (τ− λ,τ + λ). If we keep constant the slope

value µ and move the IF value ξ, we see that the en-

ergy distribution will be negligible outside an interval

which depends on µ,α

1

y α

2

. Since the signal is com-

posed by two chirps, there arises a set S

2

in which

the segment r

µ

(ξ) intersects both chirps, a set S

1

in

which the segment intersects only one chirp and a set

S

0

with empty intersection, see Fig. 4, and therefore

where the energy is negligible.

T ime

Instantaneous frequency

ω = α

1

(t − τ ) + β

1

ω = α

2

(t − τ ) + β

2

S

1

S

1

S

0

S

2

S

0

Figure 4: Two chirps energy regions classiﬁcation.

Since the instantaneous amplitudes are continu-

ous there exists a maximum point in the interval

[max{ξ

1,m

,ξ

2,m

},min{ξ

1,M

,ξ

2,M

}], which is not a

ridge point. It is a spurious maximum. We note that

these maxima do appear for large slope values and

IF’s localized between the IF’s of the corresponding

chirps at time τ.

3 CHIRP-TRACKING

Let us consider the multi-chirp signal

f (t) =

N

∑

k=1

a

k

(t)exp[iφ

k

(t)]

with φ

k

∈ C

3

, i.e., such that there exists M such that

φ

k

(t)

< M for k = 1, ...,N and for all t.

Assume that we know that at

τ,φ

k

(τ)

our signal

has a ridge point in the time-frequency plane and that

its CR is given by φ

k

(τ). Then, for h > 0 small we

have

φ

k

(τ+ h) = φ

k

(τ) + hφ

k

(τ) +

φ

k

(ν)

6

h

2

with ν ∈ (τ,τ+ h). From the regularity assumed on f

we deduce

φ

k

(τ+ h) − φ

k

(τ) − hφ

k

(τ)

6

1

6

Mh

2

.

Therefore, once we know the IF and CR at a given

time, we may estimate the range in which the CR will

be at the next time step.

On the other hand, we have

φ

k

(τ+ h) ≈ φ

k

(τ) + hφ

k

(τ)

i.e., φ

k

(τ+ h) ∈

φ

k

(τ) − hM,φ

k

(τ) + hM

. There-

fore, we may also estimate the range of slopes for the

CR at subsequent times.

Our algorithm is organized as follows:

BIOSIGNALS 2009 - International Conference on Bio-inspired Systems and Signal Processing

218

1. We use a the signal spectrogram to choose the

time components of points at which the spectro-

gram has maxima, t = τ

1

,...,τ

L

. These are candi-

dates to belong to the support of the α

k

functions.

2. For each τ

l

we compute the chirplet energy distri-

bution corresponding to Ψf (τ

l

,ξ,µ;λ) for a dis-

crete set of slopes, µ

1

,...,µ

r

, using the DFT.

3. We compute the maximum of the energy obtain-

ing an estimate of the CR and IF (µ

l

0,1

,ξ

l

0,1

) of one

chirp at the given time.

4. We advance one step in time and compute the en-

ergy at τ

l

+ h.

5. To avoid spurious maxima, we seek the maximum

through the window estimated in the previous sec-

tion, i.e.

µ ∈ (µ

l

0,1

− hM,µ

l

0,1

+ hM)

and

ξ ∈

ξ

l

0,1

+ hµ

l

0,1

−

1

6

Mh

2

,ξ

l

0,1

+ hµ

l

0,1

+

1

6

Mh

2

This maximum provides us with an estimate for

the CR and IF, (µ

l

1,1

,ξ

l

1,1

).

6. We continue this process until the energy maxi-

mum in the selected window is lower than some

ﬁxed threshold. In this way, we obtain a set of

ridge points corresponding to the same chirp.

7. We iterate steps 2-6 on every point computed at

step 1, until all the chirps of signal f are identiﬁed.

We ﬁnally notice that this new algorithm narrows the

search area for maxima points in the CR-IF plane, im-

plying a gain in computational time as well as a reduc-

tion in the spurious maxima processing.

4 NUMERICAL EXPERIMENTS

4.1 Experiment 1. A Synthetic Signal

We consider a synthetic signal composed by

the addition of three chirps (see Fig.5) f (t) =

∑

3

i=1

a

i

(t)cos[φ

i

(t)] with t ∈ [0, 10] and with ampli-

tudes given by amplitudes

a

1

(t) =

1

3

exp

−

(t − 3.5)

2

5

!

X

[1,6]

(t),

a

2

(t) =

1

3

exp

−

(t − 5)

2

4

!

X

[2,8]

(t),

a

3

(t) =

1

3

exp

−

(t − 6)

2

4

!

X

[3.5,9.5]

(t),

0 2 4 6 8

0

500

1000

1500

2000

Time

Frequency

Spectrogram

Figure 5: Spectrogram of synthetic signal of Experiment 1.

with X

[a,b]

(t) the characteristic function of the interval

[a,b], and with phases

φ

1

(t) = −13.07t

5

+ 226.2t

4

− 1434t

3

+ 4055t

2

− 4408t,

φ

2

(t) = 1.733t

5

− 42.92t

4

381.1t

3

− 1459t

2

+ 2798t,

φ

3

(t) = −4.973t

5

+ 166.3t

4

− 2172t

3

+ 0.138t

2

+ 0.411t.

0 2 4 6 8 10

0

500

1000

1500

2000

Time

Frequency

Separation

Figure 6: Separation of the three chirps of Experiment 1.

We used a variable time step h ∈ (0.01,0.05) sec.

The initial step is 0.01 sec. and in subsequent it-

erations we use h = 0.01c + 0.05(1 − c) with c =

min(|µ|,1000)/1000, for µ the CR estimation of the

previous step. Finally, we neglect maxima with am-

plitude lower than 0.001. Relative error results for

amplitude, IF and CR are plotted in Figs. 9, 10 and

11. We observe that, specially the IF, is very accu-

rately approximated, allowing the separation of the

three chirps, see Fig. 6. In a further experiment not

shown in this paper, we repeated the previous experi-

ment adding a noise to the signal with SNR=0. In this

case, the amplitude threshold was set to 0.025 and the

relative error results were very similar to those exhib-

ited by Figs. 9-11.

MULTI-CHIRP SIGNAL SEPARATION

219

0 0.5 1 1.5 2

0

500

1000

1500

2000

Time

Frequency

Spectrogram

Figure 7: Signal spectrogram corresponding to Experiment

2.

0 0.5 1 1.5 2

0

500

1000

1500

2000

Time

Frequency

Separation

Chirp 8

Chirp 7

Chirp 4

Chirp 6

Chirp 3

Chirp 1

Chirp 5

Chirp 2

Figure 8: Separation result corresponding to Experiment 2.

4.2 Experiment 2. A Field Recorded

Wolves Chorus

We use a wolf chorus ﬁeld recorded signal. Parame-

ters are set as follows: window width, λ = 0.15, time

step h ∈ (0.001,0.005) sec. and the amplitude thresh-

old to 0.006. Fig. 7 shows the signal spectrogram

while Fig. 8 shows the separation result.

In Fig. 8 we observe the detection of eight chirps.

Due to the threshold level election some chirps are

split into several pieces due to the usual variation in

the amplitude of wolf howls, e. g. chirps 4, 5 and 6

in Fig. 8. However, if we consider a lower amplitude

threshold, the noise present in the recording induces

the erroneous identiﬁcation of some points as ridge

0 2 4 6 8 10

1e−5

1e0

Amp.

Chirp 1

0 2 4 6 8 10

1e−5

1e0

F.I.

0 2 4 6 8 10

1e−5

1e0

Chirp-rate

Figure 9: Relative errors for chirp 1 of Experiment 1.

points. Hence, a suitable threshold level must be set

to balance these effects.

5 CONCLUSIONS

Many biological audio signals may be modelled as an

addition of modulated chirps being a problem of in-

terest the separation or decomposition of the signal in

its fundamental components. For this separation, spe-

cially at chirps crossing points in the time-frequency

plane, some additional information to instantaneous

frequency is needed in order to track correctly the dif-

ferent components. In a previous work, we introduced

an algorithm using the chirp-rate estimation based on

the chirplet transform. Some drawbacks of this al-

gorithm were the difﬁculties for deﬁning an accurate

matching algorithm for the chirp segments computed

in each time step and the accuracy on the chirp-rate

computation, specially in which respects to the de-

tection of spurious maxima. In this paper we pre-

sented an improved algorithm which avoids the previ-

ous matching algorithm by means of a straight chirp

tracking procedure, based on an improved methodol-

ogy for energy maxima detection and spurious max-

ima identiﬁcation.

ACKNOWLEDGEMENTS

All authors are supported by Project PC07-12, Gob-

ierno del Principado de Asturias, Spain. Third and

fourth authors are supported by the Spanish DGI

Project MTM2007-65088.

BIOSIGNALS 2009 - International Conference on Bio-inspired Systems and Signal Processing

220

0 2 4 6 8 10

1e−5

1e0

Amp.

Chirp 2

0 2 4 6 8 10

1e−5

1e0

F.I.

0 2 4 6 8 10

1e−5

1e0

Chirp-rate

Figure 10: Relative errors for chirp 2 of Experiment 1.

0 2 4 6 8 10

1e0

1e−5

Amp.

Chirp 3

0 2 4 6 8 10

1e0

1e−5

F.I.

0 2 4 6 8 10

1e0

1e−5

Chirp-rate

Figure 11: Relative errors for chirp 3 of Experiment 1.

REFERENCES

Boashash, B. (1992a). Estimating and interpreting the in-

stantaneous frequency of a signal. i. fundamentals.

Proceedings of the IEEE, 80(4):520–538.

Boashash, B. (1992b). Estimating and interpreting the in-

stantaneous frequency of asignal. ii. algorithms and

applications. Proceedings of the IEEE, 80(4):540–

568.

Dugnol, B., Fern´andez, C., Galiano, G., and Velasco, J.

(2008). On a chirplet transform based method applied

to separating and counting wolf howls. Signal Proc.,

88(7):1817–1826.

et al., N. E. H. (1998). The empirical mode decomposi-

tion and the hilbert spectrum for nonlinear and non-

stationary time series analysis. Proc. R. Soc. London

A, 454(1971):903–995.

Gianfelici, F., Biagetti, G., Crippa, P., and Turchetti, C.

(2007). Multicomponent am-fm representations: An

asymptotically exact approach. IEEE Trans. Audio

Speech Lang. Process., 15(3):823–837.

Kwok, H. and Jones, D. (2000). Improved instanta-

neous frequency estimation using an adaptive short-

time fourier transform. IEEE Trans. Signal Process.,

48(10):2964–2972.

Mann, S. and Haykin, S. (1991). The chirplet transform:

A generalization of gabor’s logon transform. In Proc.

Vision Interface 1991, pages 205–212.

Maragos, P., Kaiser, J. F., and Quatieri, T. F. (1993). Energy

separation in signal modulations with applications to

speech analysis. IEEE Trans. Speech Audio Process.,

41(10):3024–3051.

McAulay, R. J. and Quatieri, T. F. (1986). Speech

analysis/synthesis based on a sinusoidal representa-

tion. IEEE Trans. Acoustics Speech Signal Process.,

34(4):744–754.

Santhanam, B. and Maragos, P. (2000). Multicomponent

am-fm demodulation via periodicity-based algebraic

separation and energy-based demodulation. IEEE

Trans. Commun., 48(3):473–490.

Stankovi´c, L. and Djurovi´c, I. (2003). Instantaneous fre-

quency estimation by using the wigner distribution

and linear interpolation. Signal Process., 83(3):483–

491.

Zhao, Z., Pan, M., and Chen, Y. (2004). Instantaneous fre-

quency estimate for non-stationary signal. In Fifth

World Congress on Intelligent Control and Automa-

tion, 2004. WCICA 2004., volume 4, pages 3641–

3643.

MULTI-CHIRP SIGNAL SEPARATION

221
