MULTI-ATTRIBUTE DECISION MAKING FOR AFFECTIVE

BI-MODAL INTERACTION IN MOBILE DEVICES

Efthymios Alepis, Maria Virvou

Department of Informatics, University of Piraeus

80 Karaoli & Dimitriou St., 18534, Piraeus, Greece

Katerina Kabassi

Department of Ecology and the Environment, Technological Educational Institute of the Ionian Islands

2 Kalvou Sq., 29100 Zakynthos, Greece

Keywords: Mobile devices, m-learning, affective interaction, bi-modal interaction, multi-attribute decision making

theories.

Abstract: This paper presents how multi attributes decision making is used for affective interaction in mobile devices.

The system bases its inferences about users’ emotions on user input evidence from the keyboard and the

microphone of the mobile device. The actual combination of evidence from these two modes of interaction

has been performed based on an innovative inference mechanism for emotions and a multi-attribute decision

making theory. The mechanism that integrates the inferences form the two modes has been based on the

results of two empirical studies, with the participation of human experts and possible users of the system.

1 INTRODUCTION

In the fast pace of modern life, students and

instructors would appreciate using constructively

some spare time. They may have to work on lessons

at any place, even when away from offices,

classrooms and labs where computers are usually

located. At the current state, there are not many

mature mobile tutoring systems since the technology

of mobile computing is quite recent and has not yet

been used to the extent that it could. However, there

have been quite a lot of primary attempts to

incorporate mobile features to this kind of

educational technology and the results so far confirm

the great potential of this incorporation. Moreover,

in many cases it would be extremely useful to have

such facilities in handheld devices, such as mobile

phones rather than desktop or portable computers so

that additional assets may be gained. Such assets

include device independence as well as more

independence with respect to time and place in

comparison with web-based education using

standard PCs.

However, different problems may occur during

people’s interaction with mobile devices. This

especially is the case of novice users who find such

an interaction frustrating and difficult. A remedy to

such problem may be given by providing adaptive

interaction based on the user’s emotional state. For

this purpose, affective computing may be used.

Regardless of the various emotional paradigms,

neurologists/psychologists have made progress in

demonstrating that emotion is at least as and perhaps

even more important than reason in the process of

decision making and action deciding (Leon et al.,

2007). Moreover, the way people feel may play an

important role in their cognitive processes as well

(Goleman, 1995).

Indeed, Picard points out that one of the major

challenges in affective computing is to try to

improve the accuracy of recognizing people’s

emotions (Picard, 2003). Ideally, evidence from

many modes of interaction should be combined by a

computer system so that it can generate as valid

hypotheses as possible about users’ emotions. It is

hoped that the multimodal approach may provide not

only better performance, but also more robustness

(Pantic & Rothkrantz, 2003).

In previous work, the authors of this paper have

implemented and evaluated with quite satisfactory

results emotion recognition systems, incorporated in

educational software applications for computers

(Alepis et al. 2007). As a next step we have

376

Alepis E., Virvou M. and Kabassi K. (2008).

MULTI-ATTRIBUTE DECISION MAKING FOR AFFECTIVE BI-MODAL INTERACTION IN MOBILE DEVICES.

In Proceedings of the International Conference on Signal Processing and Multimedia Applications, pages 376-379

DOI: 10.5220/0001935103760379

 SciTePress

extended our affective educational system by

providing mobile interaction between the users and

handheld device. The system is based on mobile

technology and incorporates the quite recent theory

of Affective Computing.

In view of the above, in this paper we describe a

novel mobile educational system that incorporates

bi-modal emotion recognition. The proposed system

collects evidence from the two modes of interaction

and analyses them in terms of some attributes for

emotion recognition. Finally the system associates

the users’ input data through a multi-attribute model

and makes final assumptions about the user’s

emotional state. For the effective application of the

multi-attribute decision making model, we

conducted an empirical study with the participation

of human experts as well as possible users of the

system.

2 EMPIRICAL STUDY FOR

ATTRIBUTES

DETERMINATION

In order to collect evidence about which information

could be used for emotion recognition, we

conducted an empirical study.

2.1 Settings of the Experiment

The empirical study that we have conducted

concerns the audio-lingual emotion recognition, as

well as the recognition of emotions through

keyboard evidence. The audio-lingual mode of

interaction is based on using a mobile device’s

microphone as input device. The empirical study

aimed at identifying common user reactions that

express user feelings while they interact with mobile

devices. As a next step, we associated these

reactions with particular feelings.

Individuals’ behaviour while doing something

may be affected by several factors related to their

personality, age, experience, etc. Therefore, the

empirical study involved a total number of 100 male

and female users of various educational

backgrounds, ages and levels of familiarity with

computers.

The participants were asked to use a mobile

educational application, which incorporated a user

monitoring component. The user monitoring

component that we have used can be incorporated in

any application, since it works in the background

recording each user’s input actions. Part of the

interaction included knowledge tests, while

participants were asked to use oral interaction via

their mobile device’s microphone. Our aim was not

to test the participants’ knowledge skills, but to

record their oral and written behaviour. Thus, the

educational application incorporated the monitoring

module that was running unnoticeably in the

background. Moreover, users were also video-taped

while they interacted with the mobile application.

After completing the interaction with the

educational application, participants were asked to

watch the video clips concerning exclusively their

personal interaction and to determine in which

situations they where experiencing changes in their

emotional state.

As the next step, the collected transcripts were

given to 20 human expert-observers who were asked

to perform audio emotion recognition with regard to

the six emotional states, namely happiness, sadness,

surprise, anger, disgust and neutral. All human

expert-observers possessed a first and/or higher

degree in Psychology and, to analyze the data

corresponding to the audio-lingual input only, they

were asked to listen to the video tapes without

seeing them. They were also given what the user had

said in printed form from the computer audio

recorder. The human expert-observers were asked to

justify the recognition of an emotion by indicating

the weights of the attributes that they had used in

terms of specific words and exclamations, pitch of

voice and changes in the volume of speech.

2.2 Analysis of the Results

The analysis of the data collected by both the human

experts and the monitoring component, revealed

some statistical results that associated user input

actions through the mobile keyboard and

microphone with possible emotional states of the

users. More specifically, considering the keyboard

we have the following categories of user actions: a)

user types normally b) user types quickly (speed

higher than the usual speed of the particular user) c)

user types slowly (speed lower than the usual speed

of the particular user) d) user uses the “delete” key

of his/her mobile device often e) user presses

unrelated keys on the keyboard f) user does not use

the keyboard.

Considering the users’ basic input actions

through the mobile device’s microphone we have 7

cases: a) user speaks using strong language b) users

uses exclamations c) user speaks with a high voice

volume (higher than the average recorded level) d)

user speaks with a low voice volume (low than the

average recorded level) e) user speaks in a normal

voice volume f) user speaks words from a specific

list of words showing an emotion g) user does not

say anything.

Therefore, each moment the system records a

vector of input actions through the keyboard (k1, k2,

MULTI-ATTRIBUTE DECISION MAKING FOR AFFECTIVE BI-BIMODAL INTERACTION IN MOBILE DEVICES

377

k3, k4, k5, k6) and a vector of input actions through

the microphone (m1, m2, m3, m4, m5, m6, m7).

All the above mentioned attributes are used as

Boolean variables. In each moment the system takes

data from the bi-modal interface and translates them

in terms of keyboard and microphone actions. If an

action has occurred the corresponding attribute takes

the value 1, otherwise its value is set to 0. Therefore,

for a user that speaks with a high voice volume and

types quickly the two vectors that are recorded by

the system are: k= (0, 1, 0, 0, 0, 0) and m= (0, 0, 1,

0, 0, 0, 0). These data are further processed by the

multi-attribute model for determining the emotion of

the user.

3 EMPIRICAL STUDY FOR

WEIGHT CALCULATION

The previous empirical study revealed the attributes

that are taken into account when evaluating different

emotions. However, these attributes are not equally

important for evaluating different emotions. For this

purpose, the human experts who participated in the

first empirical study and selected the final set of

attributes were also asked to rank the 13 attributes

with respect to how important they are in their

reasoning process.

Human experts resulted that one input action does

not have the same weight while evaluating different

emotions. Therefore, the weights of the attributes

(input actions) were calculated for some stereotypes

of different emotions were designed.

Therefore, each human expert was asked to share

21 points into the 6 different attributes with respect

to the keyboard input for each emotion.

As soon as the scores of all human experts were

collected, they were used to calculate the weights of

attributes. The scores assigned to each attribute by

all human experts were summed up and then divided

to the sum of scores of all attributes (21 points

assigned to all attributes by each human expert * 20

human experts = 420 points assigned to all attributes

by all human experts). In this way the sum of all

weights could be equal to 1.

As a result, there was a set of weights for the

attributes that correspond to the keyboards’ input

actions for each different emotion.

Then each human expert was asked to share 28

points into the 7 different attributes with respect to

the microphone input for each emotion. As soon as

the scores of all human experts were collected, they

were used to calculate the weights of attributes. The

scores assigned to each attribute by all human

experts were summed up and then divided to the

sum of scores of all attributes (28 points assigned to

all attributes by each human expert * 20 human

experts = 560 points assigned to all attributes by all

human experts). In this way the sum of all weights

could be equal to 1.

As a result, there was a set of weights for the

attributes that correspond to the microphones’ input

actions for each different emotion.

4 APPLICATION OF THE

MULTI-ATTRIBUTES MODEL

For the evaluation of each alternative emotion the

system uses SAW (Fishburn, 1967, Hwang & Yoon,

1981) for a particular category of users. According

to SAW, the multi-attribute utility function for each

emotion in each mode is estimated as a linear

combination of the values of the attributes that

correspond to that mode.

The SAW approach consists of translating a

decision problem into the optimisation of some

multi-attribute utility function

defined on

The decision maker estimates the value of function

)(

for every alternative

and selects the

one with the highest value. The multi-attribute utility

function

can be calculated in the SAW method

as a linear combination of the values of the n

attributes:

where X

is one alternative and x

is the value of the i

attribute for the X

alternative.

In view of the above, for the evaluation of each

emotion taking into account the information

provided by the keyboard is done using formula 1.

(1)

Similarly, for the evaluation of each emotion

taking into account the information provided by the

other mode (microphone) is done using formula 2.

(2)

44332211

11111

kwkwkwkwem

kekekekeke

44332211

11111

mwmwmwmwem

mememememe

6655

kwkw

keke

776655

111

mwmwmw

mememe

xwXU

∑

)(

SIGMAP 2008 - International Conference on Signal Processing and Multimedia Applications

378

is the probability that an emotion has

occurred based on the keyboard actions and

is the probability that refers to an emotional state

using the users’ input from the microphone

and

take their values in [0,1].

In formula 1 the k’s from k1 to k6 refer to the six

attributes that correspond to the keyboard. In

formula 2 the m’s from m1 to m7 refer to the seven

attributes that correspond to the microphone. The

w’s represent the weights. These weights correspond

to a specific emotion and to a specific input action

and were calculated in the previous empirical study.

In cases where both modals (keyboard and

microphone) indicate the same emotion then the

probability that this emotion has occurred increases

significantly. Otherwise, the mean of the values that

have occurred by the evaluation of each emotion

using formulae 1 and 2 is calculated.

The system compares the values from all the

different emotions and selects the one with the

highest value of the multi-attribute utility function.

The emotion that maximises this function is selected

as the user’s emotion.

5 CONCLUSIONS AND FUTURE

WORK

In this paper we have described how multi-attribute

decision making could be used for affective

interaction in mobile devices. More specifically, we

describe the implementation of an affective

educational application for mobile devices that

recognizes students’ emotions based on their

keyboard and microphone actions. The educational

application employs a bi-modal user interface.

A similar approach to the proposed one has

previously been used in a learning environment

operating over the web (Alepis et al., 2007).

However, the main difference of the approach

described in this paper is that the interaction

provided by mobile devices differentiates from the

human-computer interaction in many ways. The

keyboard and the screen are very different as well as

the places where a user may interact with them. A

user may interact with a mobile device in the places

that s/he can interact with a PC as well as other

places, such as a station, a bus or the beach. In such

places the users’ mood may be affected by other

factors. Therefore, the need for affective interaction

in mobile devices may be even more essential than

in normal computers.

It is among our future plans to incorporate user

modelling techniques such as stereotypes in

combination with the multi-attribute decision

making in order to personalise interaction with each

individual user interacting with the mobile device.

Furthermore, we intend to enrich multi-modal

interaction by incorporating a third mode of

interaction, visual this time (Stathopoulou &

Tsihrintzis, 2005).

ACKNOWLEDGEMENTS

Support for this work was provided by the General

Secretariat of Research and Technology, Greece,

under the auspices of the PENED-2003 program.

Travel funds to present this work were provided by

the University of Piraeus Research Center.

REFERENCES

Alepis, E., Virvou, M., Kabassi, K., 2007. Knowledge

Engineering for Affective Bi-modal Human-Computer

Interaction, SIGMAP.

Fishburn, P.C., 1967. Additive Utilities with Incomplete

Product Set: Applications to Priorities and

Assignments, Operations Research.

Goleman, D., 1995. Emotional Intelligence, Bantam

Books, New York .

Hwang, C.L., Yoon, K., 1981. Multiple Attribute Decision

Making: Methods and Applications. Lecture Notes in

Economics and Mathematical Systems 186, Springer,

Berlin/Heidelberg/New York.

Leon, E., Clarke, G., Gallaghan, V., Sepulveda, F., 2007.

A user-independent real-time emotion recognition

system for software agents in domestic environments.

Engineering applications of artificial intelligence, 20

(3): 337-345.

Pantic, M., Rothkrantz, L.J.M., 2003. Toward an affect-

sensitive multimodal human-cumputer interaction.

Vol. 91, Proceedings of the IEEE, Institute of

Electrical and Electronics Engineers, pp. 1370-1390.

Picard, R.W., 2003. Affective Computing: Challenges. Int.

Journal of Human-Computer Studies, Vol. 59, Issues

1-2, pp. 55-64.

Stathopoulou, I.O., Tsihrintzis, G.A., 2005. Detection and

Expression Classification System for Face Images

(FADECS), IEEE Workshop on Signal Processing

Systems, Athens, Greece.

meke

emem +

MULTI-ATTRIBUTE DECISION MAKING FOR AFFECTIVE BI-BIMODAL INTERACTION IN MOBILE DEVICES

379
