AN EFFICIENT METHODOLOGY TO LIMIT PATH LENGTH
GUARANTEEING ANONYMITY IN OVERLAY NETWORKS
Juan Pedro Mu˜noz-Gea, Josemaria Malgosa-Sanahuja, Pilar Manzanares-Lopez
Juan Carlos Sanchez-Aarnoutse and Joan Garcia-Haro
Department of Information Technologies and Communications, Polytechnic University of Cartagena
Campus Muralla del Mar, 30202, Cartagena, Spain
Keywords:
Anonymity, multi-hop paths, overlay networks.
Abstract:
An alternative to guarantee anonymity in overlay networks may be achieved by building a multi-hop path
between the origin and the destination. However, one hop in the overlay network can consist of multiple
Internet Protocol (IP) hops. Therefore, the length of the overlay multi-hop path must be reduced in order to
maintain a good balance between the cost and the benefit provided by the anonymity facility. Unfortunately,
the simple Time-To-Live (TTL) algorithm cannot be directly applied here since its use could reveal valuable
information to break anonymity. In this paper, a new mechanism which reduces the length of the overlay
multi-hop paths is presented. The anonymity level is evaluated by means of simulation and good results are
reported.
1 INTRODUCTION
Over the last years, we have witnessed the emergence
of different types of overlay networks in the Internet
(Tsang et al., 2007). In these new scenarios, con-
cerns about anonymity significantly arise among the
user community. Anonymity refers to the ability to
do something without revealing one’s identity (in this
case, the user’s) (Pfitzmann and Hansen, 2007). The
simplest solution to provide anonymity in overlaynet-
works is to select several relay nodes in the route from
the sender to the receiver. In this way, even if a local
eavesdropper observes a message being sent by a par-
ticular user, it can never be sure whether the user is
the current sender, or if the message is forwarded by
a relay node.
Similar techniques have been widely studied in the
past to provide anonymity in IP networks. One of
them is Crowds (Reiter and Rubin, 1998), in which
each node decides to deliver the message to an inter-
mediate or destination node by flipping a biased coin
(with probabilities p
f
and 1 p
f
respectively). Nev-
ertheless, the use of this mechanism in overlay net-
works is not appropriate, because the forwarding pro-
cedure is not limited in any way, and as it known, in
overlay networks neighbour nodes are connected by
means of logical links, each one comprised of an ar-
bitrary number of physical links. Therefore, a serious
increase in the length of the overlay path among the
origin and the destination nodes could imply an expo-
nential cost, in terms of bandwidht consumption and
nodes overload.
A straightforwardimplementation to limit the path
length makes use of the Time-To-Live(TTL) field, but
there are multiple situations in which this implemen-
tation will immediately reveal to an ”attacker” who
the initiator node is. This paper proposes a mecha-
nism that limits the length of overlay multi-hop paths
without using a TTL (Time-To-Live) scheme. Fur-
thermore, simulation results show that this mecha-
nism presents a degree of anonymity equivalent to
Crowds.
The remainder of the paper is organized as fol-
lows. Section 2 overviews some relevant works about
anonymous systems. Section 3 presents the different
requirements that must be satisfied in order to limit
the path length. Section 4 introduces our proposal,
called the Always Down-or-Up (ADU) mechanism.
In section 5 our algorithm is evaluated by means of
simulation. In section 6 the anonymity level achieved
by the proposed mechanism is evaluated by means of
simulation. Finally, section 7 concludes the paper.
205
Pedro Muñoz-Gea J., Malgosa-Sanahuja J., Manzanares-Lopez P., Carlos Sanchez-Aarnoutse J. and Garcia-Haro J. (2008).
AN EFFICIENT METHODOLOGY TO LIMIT PATH LENGTH GUARANTEEING ANONYMITY IN OVERLAY NETWORKS.
In Proceedings of the International Conference on Security and Cryptography, pages 205-208
DOI: 10.5220/0001916202050208
Copyright
c
SciTePress
2 RELATED WORK
The seminal paper on anonymous sytems was written
by David Chaum (Chaum, 1981). He proposed a sys-
tem for anonymous email based on the so called mix
networks. A mix node shuffles a batch of messages
and delivers them in random order. This design has
been followed by many anonymous systems. The first
widely used implementation of mix networks was the
Type I cypherpunk anonymous remailers (Goldberg
et al., 1997), using PGP (Zimmermann, 1995) encryp-
tion to wrap email messages and deliver them anony-
mously. They were followed by MixMaster (M¨oller
et al., 2003), and then MixMinion (Danezis et al.,
2003).
Although the mix design has been quite influen-
tial, there are a number of notable alternatives. A net-
work that uses a different approach is Crowds (Re-
iter and Rubin, 1998), designed for anonymous web
browsing. Briefly, Crowds nodes forward web request
to each other at random, executing a form of a random
walk.
3 BACKGROUND
In Crowds, the initiator node creates a packet con-
taining a random path identifier, the IP address of the
responder and the data. Then, it flips a biased coin.
With probability 1 p
f
(p
f
is the probability of for-
warding and it is a parameter of the system) it delivers
the message directly to the responder or destination
node, and with probability p
f
it chooses randomly
the next relay node. Each node decides- based on p
f
-
whether to forward it to the responder or to another
(randomly chosen) relay node. With this original al-
gorithm the forwarding procedure is not limited and,
as we previously pointed out, it could be a tragedy re-
garding communication costs in an overlay scenario.
A possible solution is to restrict the maximum
length of the paths. The system operates as the tradi-
tional scheme but, when the number of hops reaches
a certain limit (called S), the path will be directed
towards the destination node. A straightforward im-
plementation consists of using a time-to-live (TTL)
field, initially set to S, and processing it like in IPv4
networks (Postel, 1981). However, there are multiple
situations in which this implementation will immedi-
ately reveal to a ”corrupt” node whether the prede-
cessor node is the initiator or not. Therefore, we can
conclude that the TTL methodology is not appropriate
to limit the length of multi-hop paths.
4 PROPOSED MECHANISM
The algorithm proposed in this work, as in Crowds,
is based on the random-walk procedure. However,
the variance associated to the length of the multi-hop
paths is smaller than that in Crowds. Therefore, it
can be viewed as a quasi-deterministic mechanism of
a statistical TTL implementation.
Our first attempt is the always-down (AD) algo-
rithm: The path originator chooses a uniform random
number (called u) between 1 and a predefined param-
eter M. If the value of u is equal to 1, the originator
sends the request directly to the destination. Other-
wise, the node forwards the request to a random node
together with the random number u. The next node
performs the same operation but replacing the upper
bound M with the value of u. The mechanism contin-
ues in a recursiveway, decreasing the size of the inter-
val [1, u) in each step. However, with this algorithm
there is still correlation between the random number
u and the hop length: although little values do not
reveal anything about the path length, great ones do,
since they can only appear at the first steps of the al-
gorithm.
The opposite algorithm, called always-up (AU)
has the same benefits and drawbacks. Now, at each
step the node chooses a uniform random number be-
tween (u, M]. When a node selects M, the random
walk procedure ends and the request is directly sent
to the responder. In this case, great values of u do not
reveal anything about the path length, but small ones
do, since they can only appear at the first steps of the
algorithm.
In order to avoid this critical issue, we propose to
mix both mechanism as follows: The path originator
chooses a random number (called u) between 1 and
M. When this number is equal to 1 or equal to M,
the originator node sends the request to the responder.
If u is lower than a parameter LOW
BORDER, the
algorithm works like AD. However, if u is greater than
a paramater TOP
BORDER, the algorithm operates
like AU. Finally, if u drops between LOW
BORDER
and TOP BORDER, the operation mode (AD or AU)
is chosen randomly.
This new algorithm is called always down-or-up
(ADU) and it is able to statistically limit the length
of the path in an anonymous environment. In order
to speed up the algorithm, we introduce an additional
parameter called e: If the new chosen random num-
ber is smaller than or equal to e (or it is greater than
M e) the originator node delivers the request to the
responder. Figure 1 represents the full set of parame-
ters used by our algorithm in a numerical straight line.
SECRYPT 2008 - International Conference on Security and Cryptography
206
1
e LOW
BORDER BORDER
TOP
random
M−e M
updown
Figure 1: Parameters of the algorithm.
Table 1: Values of parameters for specific
l.
ADU Crowds
l M e p
f
2 100 21 0.5
3 100 8 0.6667
4 100 3 0.75
5 150 2 0.80
6 350 2 0.8333
Table 2: Variance of the length of the paths.
l ADU Crowds
2 1.3337 2
3 2.3559 6
4 3.4135 12
5 4.5062 20
6 5.5821 30
5 EVALUATION
The random variable l that represents the length of
the path has been evaluated by means of simulation.
Table 1 presents the appropriate values for the param-
eters M and e in order to achieve representativevalues
for l. This table also represents the appropriate values
of p
f
to achieve the same values of
l in Crowds. It
is known that the mean length of the multi-hop paths
created using the Crowds mechanism follows the ge-
ometrical expression:
l =
1
1p
f
.
Table 2 presents the variance of the length of the
paths for ADU and Crowds. The variance of the ADU
paths is calculated using:
V(l) = E(l
2
) E(l)
2
(1)
on the other hand, for Crowds it is known that
V(l) =
p
f
(1 p
f
)
2
(2)
It is observed that the variance in ADU is always
significantly smaller than in Crowds. This behaviour
enables to interpret the ADU algorithm like a quasi-
deterministic TTL implementation. Therefore, the
mechanism achieves the target goal.
6 ANALYSIS OF ANONYMITY
The anonymity level achieved by the proposed mech-
anism is evaluated by means of simulation following
the methodology exposed in (Borissov, 2005). This
methodology is based on the use of the entropy as a
measure of the anonymity level. This concept was
presented in (D´ıaz et al., 2002), and it can be sum-
marized as follows: It is assumed that there is a total
number of N nodes,C of them are corrupt and the rest
honest. Corrupt nodes collaborate among them trying
to find out who is the origin of the messages. Based
on the information retrieved from corrupt nodes, the
attacker assigns a probability (p
i
) of being the origin
of a particular message for each node. The degree of
anonymity (d) of the system can be expressed by:
d =
1
H
M
N
i=1
p
i
log
2
(p
i
) (3)
where H
M
is the maximum entropy of the system,
which is satisfied when all honest nodes have the same
probability of being the origin of the message.
If a message goes only through honest nodes the
degree of anonymity will be d|
honest nodes
= d
h
= 1. If
we assume that the message goes through at least one
corrupt node with probability p
c
and it crosses only
through honest nodes with probability p
h
= 1 p
c
,
the mean degree of anonymity of the system is:
d = p
c
· d|
corrupt nodes
+ p
h
· d
h
= p
c
· d
c
+ p
h
(4)
The methodology proposed in (Borissov, 2005)
has been implemented in a simulator written in C lan-
guage. First, in order to obtain an appropriate value
for the number of iterations we simulate an scenario
with
l = 4 for different number of iterations. Figure
2 presents the results with the 95 % confidence in-
tervals. We can see that from 10,000 iterations, the
accuracy of the simulation results is within the 0.1 %
with respect to the stable value. Therefore, in our sim-
ulations the number of iterations is set to 10,000.
Figure 3 compares d for Crowds and ADU when
N=100 and C=10. It represents the anonymity level
according to the mean length of the paths, from 1 to
10. These small values have been selected because,
as it was previously mentioned, our objective is to
achieve shor multi-hop paths. It can be observed that
the degree of anonymity achieved by the ADU al-
gorithm perfectly matches the degree of anonymity
achieved by Crowds.
AN EFFICIENT METHODOLOGY TO LIMIT PATH LENGTH GUARANTEEING ANONYMITY IN OVERLAY
NETWORKS
207
0 10 100 1000 10000 100000
0.75
0.8
0.85
0.9
0.95
1
Number of Samples
d
Figure 2: d with confidence intervals as a function of the
number of iterations.
1 2 3 4 5 6 7 8 9 10
0.9
0.91
0.92
0.93
0.94
0.95
0.96
0.97
0.98
0.99
1
l
d
Crowds
ADU
Figure 3: d as a function of l.
7 CONCLUSIONS
In traditional (like Crowds) anonymous networks, the
anonymity is achieved by building a multiple-hop
path between the origin and the destination nodes.
However, the cost associated with the communica-
tion increases dramatically as the number of hops also
increases. Therefore, in these scenarios limiting the
length of the paths is a key aspect of the protocols de-
sign. Unfortunately, the common TTL methodology
cannot be used to this purpose since corrupt nodes can
employ this field to extract some information about
the sender identity.
In this work an effetive mechanism to reduce the
variance associated with the length of the random
walks in anonymous overlay scenarios is proposed.
Our study reveals that the variance in ADU is always
smaller than in Crowds. In addition, the degree of
anonymity achieved by ADU is equivalent to Crowds.
Thus, this mechanism is a recommended methodol-
ogy to achieve a good trade-off between cost/benefit
associated with the anonymity in overlay networks.
ACKNOWLEDGEMENTS
This research has been supported by project grant
TEC2007-67966-C03-01/TCM(CON-PARTE-1) and
it is also developed in the framework of Programa
de Ayudas a Grupos de Excelencia de la Regi´on de
Murcia, de la Fundaci´on S´eneca, Agencia de Ciencia
y Tecnolog´ıa de la RM (Plan Regional de Ciencia y
Tecnolog´ıa 2007/2010)”. Juan Pedro Mu˜noz-Geaalso
thanks the Spanish MEC for a FPU (AP2006-01567)
pre-doctoral fellowship.
REFERENCES
Borissov, N. (2005). Anonymous routing in structured peer-
to-peer overlays. PhD thesis, University of Califor-
nia at Berkeley, Berkeley, CA, USA. Chair-Eric A.
Brewer.
Chaum, D. L. (1981). Untraceable electronic mail, return
addresses, and digital pseudonyms. Commun. ACM,
24(2):84–90.
Danezis, G., Dingledine, R., and Mathewson, N. (2003).
Mixminion: Design of a type iii anonymous remailer
protocol. In SP ’03: Proceedings of the 2003 IEEE
Symposium on Security and Privacy, page 2, Wash-
ington, DC, USA. IEEE Computer Society.
ıaz, C., Seys, S., Claessens, J., and Preneel, B. (2002).
Towards measuring anonymity. In Dingledine, R. and
Syverson, P., editors, Proceedings of Privacy Enhanc-
ing Technologies Workshop (PET 2002). Springer-
Verlag, LNCS 2482.
Goldberg, I., Wagner, D., and Brewer, E. (1997). Privacy-
enhancing technologies for the internet. In COMP-
CON ’97: Proceedings of the 42nd IEEE Interna-
tional Computer Conference, page 103, Washington,
DC, USA. IEEE Computer Society.
M¨oller, U., Cottrell, L., Palfrader, P., and Sassaman, L.
(2003). Mixmaster protocol version 2. draft, july
2003. http://www.abditum.com/mixmaster-spec.txt.
Pfitzmann, A. and Hansen, M. (2007). Anonymity, unlinka-
bility, undetectability, unobservability, pseudonymity,
and identity management - a consolidated proposal
for terminology (version v0.30 nov. 26, 2007).
http://dud.inf.tu-dresden.de/Anon
Terminology.shtml.
Postel, J. (1981). RFC 791: Internet Protocol.
Reiter, M. K. and Rubin, A. D. (1998). Crowds: anonymity
for web transactions. ACM Trans. Inf. Syst. Secur.,
1(1):66–92.
Tsang, D. H. K., Ross, K. W., Rodriguez, P., Li, J., and
Karlsson, G. (2007). Advances in peer-to-peer stream-
ing systems [guest editorial]. IEEE Journal on Se-
lected Areas in Communications, 25(9):1609–1611.
Zimmermann, P. R. (1995). The official PGP user’s guide.
MIT Press, Cambridge, MA, USA.
SECRYPT 2008 - International Conference on Security and Cryptography
208
