TRUSTED SMS

A Novel Framework for Non-repudiable SMS-based Processes

Antonio Grillo, Alessandro Lentini, Gianlugi Me

Department of Computer Science and Engineering, University of Rome Tor Vergata, Rome, Italy

Giuliano Rulli

Spike Reply s.r.l., Reply S.p.A., Rome, Italy

Keywords:

Conﬁdentiality, data security, sms, ECDSA, elliptic curves.

Abstract:

The exponential growth of the Short Message Service (SMS) use has led this service to an indispensable tool

for social, marketing and advertising messaging. Moreover, mobile devices such as smartphones, handsets and

PDAs represent an enabling factor for distributing digital content. Mobile devices are quickly becoming Per-

sonal Trust Device (PTD); mobile devices embed personal data, which allow sending/receiving conﬁdential

information from/to the PTD. This paper aims to introduce Trusted-SMS, a novel framework to exchange se-

cure SMS. This system is composed by three main entities: the Service Supplier, which publishes and delivers

services; the End User, which choices and eventually pays for a speciﬁc service, that belongs to the service-set

offered by a Service Supplier; the Certiﬁcation Authority (CA) which represents the trusted entity shared by

the Service Supplier and the End User. The CA plays the role of the Certiﬁcation Authority. The main re-

quirements of the overall system are strictly non-repudiability, user friendliness and platform portability. The

security requirement includes customer transaction authentication, conﬁdentiality, integrity and non repudia-

tion, in an environment composed of heterogeneous networks and devices, with different security weaknesses.

Trusted-SMS allows exchanging SMS digitally signed with Elliptic Curve Digital Signature Algorithm. SMS

digitally signed are useful in many scenarios, such as commercial transaction, production of delegation from

a remote site and provisioning of e-healthcare services. The signature is fully contained in a single SMS; the

size of a digital signature amount to ﬁfty bytes leaving more than one hundred bytes (110 bytes) for the SMS

payload. Moreover the application of Elliptic Curve Integrated Encryption Schema cryptographic algorithm,

which is based on the same credentials needed by the digital signature algorithm, allows protecting the payload

from intrusions.

1 INTRODUCTION

Short message services (SMS), thanks to its relative

simplicity and ease of use, similar to the e-mail, keeps

on growing in penetrating the market throughout the

world. In fact, during the 2000, just 17 billion SMS

messages were sent; in 2001, the number was up to

250 billion, and 500 billion SMS messages were sent

in 2004 (Kivimaki and Fomin, 2001). At an average

cost of USD 0.10 per message, this generates rev-

enues in excess of $50 billion for mobile telephone

operators and represents close to 100 text messages

for every person in the world.

Text messaging has become so popular that advertis-

ing agencies are now considering it as an irrinuciable

vehicle to keep the customer up to dated about the

new offers and products (Dickinger et al., 2004). The

services providing bulk text messages are also becom-

ing a popular way for clubs, associations, and adver-

tisers to quickly reach a group of opt-in subscribers.

This advertising has proven to be extremely effective,

but some insiders worry that advertisers may abuse

the power of mobile marketing and it will be consid-

ered spam.

Moreover, the proliferation of SMS attracts malware

writers that adapt phishing and other activities based

on social engineering techniques (e.g. spooﬁng be-

come SMS-spooﬁng) in order to manipulate people

into performing actions or divulging conﬁdential in-

formation (van der Merwe et al., 2005).

Grillo A., Lentini A., Me G. and Rulli G. (2008).

TRUSTED SMS - A Novel Framework for Non-repudiable SMS-based Processes.

In Proceedings of the First International Conference on Health Informatics, pages 43-50

 SciTePress

This paper aims to describe a novel framework to ex-

change secure SMS: Trusted-SMS. Due to the well

known, or yet undiscovered, security weaknesses of

SMS, it’s important, for some kind of applications,

to enforce security layers, such as conﬁdentiality, in-

tegrity and non repudiation. The goals of this paper

are concerned with:

a Expressing the requirements of the Trusted-SMS

framework;

b Analyzing and designing a framework meeting

those needs;

c Characterizing that framework,with a sketch of a

case study.

In the remaining of the paper, the Section 2 sketches

the current level of development of modern methods

and products that involve a secure SMS exchange.

The Section 3 describes Trusted-SMS framework;

this section deals with framework needs and goals

in required features, architectural design and some

technical details. The Section 4 presents a proto-

type system compliant to Trusted-SMS framework as

case study. Section 5 presents some conclusions, and

points to the future trends.

2 STATE OF THE ART

The huge success of some modern network protocols,

not designed with security in mind, poses many con-

cerns about fraudulent intrusions and undiscerning vi-

olation of the privacy. As for the TCP/IP case, the

SMS suffer the lack of many features that are desir-

able or needed on an insecure network, as the GSM

can be considered. For this reason, the companies

offer some security-enhancing products, which allow

to protect private information exchanged via SMS.

The available solutions can be divided into two dif-

ferent models: ”‘Peer-to-Peer”’(P2P) and ”‘Client-

Server”’(CS); the former focuses on the SMS ex-

change which involves only mobile devices, while the

latter focuses on the SMS exchange which occurs be-

tween a mobile device, as the Client, and a remote

computer, as the Server.

Many solutions belong to the P2P model, such as

Message in a Bottle (Chirico, 2007), Spider-SMS

(Barbi, 2007), Kryptext (Kryptex, 2007), MultiTasker

(MultiTasker, 2007) and CryptoSMS (CryptoSMS,

2007). Products as Fortress-SMS (FortressSMS,

2007) follow the CS model, this can be view as a gen-

eralization of products based on P2P model. The level

of security of the previous solutions is strictly related

to the key-distribution schema and the security algo-

rithm applied. Miabo and Spider SMS cannot be used

for sending and receiving information as part of busi-

ness transactions and personal communications. They

don’t ﬁt security needs because the former relies on a

PGP schema as public key infrastructure and the latter

relies on a random key generator.

Fortress-SMS relies on a Rijndael engine with ci-

pher block chaining (Advanced Encryption Standard

compliant) as encryption algorithm; CryptoSMS uses

three overlapping strong encryption schemes, em-

ploying both block and stream ciphers. Fortress-SMS

and CryptoSMS are not fully documented about their

execution times; to the best of our understanding en-

cryption schemas adopted by these products require

long processing times on mobile devices (Waadt et al.,

2005).

Many products allow both the SMS digital signature

and the SMS encryption; Trusted-SMS allows SMS

digital signature or alternatively SMS signature on

SMS encrypted.

Furthermore, the GSM speciﬁcations (3GPP, 2007)

don’t deﬁne any mechanism for ensuring integrity of

SMS content and authentication of SMS sender. SMS

digitally signed can be used to avoid SMS-tampering,

ensuring integrity and authentication of the sender

(Center, 2007). SMS encrypted are suitable to avoid

unauthorized access to SMS content.

3 TRUSTED-SMS FRAMEWORK

Trusted-SMS is a complex framework for allow-

ing secure SMS exchange between involved entities.

This framework enables a user to send or receive

SMS messages digitally signed with standard Ellip-

tic Curve Digital Signature Algorithm (ECDSA) and

optionally encrypted with standard Elliptic Curve In-

tegrated Encryption Schema (ECIES). According to

the digitally signed SMS, this framework can be used

to avoid SMS from tampering ensuring integrity and

non repudiation: the recipient can detect the tamper-

ing during the SMS veriﬁcation process. With en-

crypted SMS, this framework can be used to avoid

SMS from unauthorized access. If someone intercepts

an encrypted SMS he cannot eavesdrop the SMS con-

tent.

Trusted-SMS is composed by three main entities:

Service Supplier: this entity is responsible for pro-

viding services;

End User: this entity is the consumer of the supplied

services;

Certiﬁcation Authority: this entity is responsible to

ensure trusting to the involved entities.

HEALTHINF 2008 - International Conference on Health Informatics

3.1 Required Features

The expected use cases and the resulting requirements

suggest the following list of features, trying to depict

the Trusted-SMS framework. For the sake of simplic-

ity, we divide the framework required features in three

subsets, which are related to the previously identiﬁed

entities:

Service Supplier entity features:

1. each Service Supplier owns a Large Account

number; clients of a Service Supplier use its

Large Account number as its identiﬁer;

2. the Service Supplier has to be able to generate,

send and receive different kind of SMS;

3. each SMS, which Service Suppliers have to

send to Customers, must be ECDSA-Signed us-

ing the CA private key (KPrivCA);

4. each SMS, which Service Suppliers receive

from a Customer, must be ECDSA-Veriﬁed us-

ing the Customer public key (KPubMSISDN);

5. the Service Supplier has to manage a large

number of information as end user personal

data which has to be stored in a persistent mem-

ory storage;

6. the Service Supplier wants to preserve SMS

content also from CA access.

End User entity features:

1. the subsystem placed on the End User platform,

a smartphone, has to be realized as a MIDP 2.0

java mobile application;

2. End User platform has to be able to manage dif-

ferent kinds of SMS;

3. each End User is characterized by a key-pair:

a public key(KPubMSISDN) and a private key

(KPrivMSISDN);

4. each SMS, which Customers have to send to

Service Suppliers, must be ECDSA-Signed by

client application using its own private key

(KPrivMSISDN);

5. each SMS, which Customers receive from Ser-

vice Suppliers, must be ECDSA-Veriﬁed by

client application using the CA public key

(KPubCA);

6. the subsystem placed on the End User platform

must be deﬁned on a parameters set which de-

ﬁnes the elliptic curve; that elliptic curve is

used for generating/verifying ECDSA signa-

tures (this curve is shared with server applica-

tion);

7. the subsystem placed on the End User platform

must be deﬁned on a parameters set which de-

ﬁned the hash function; that hash function is

used for creating a digest which must be signed

with the identiﬁed signature algorithm;

Certiﬁcation Authority entity features:

1. a single server realizes the Certiﬁcation Au-

thority (CA); each Service Supplier knows this

server.

2. the CA must be able to sign SMS using ECDSA

with its own private key (KPrivCA);

3. the CA must be able to verify SMS us-

ing ECDSA with an appropriate public key

(KPubMSISDN);

4. the CA has to manage a large number of con-

ﬁdential information (e.g. end users’ keys),

which has to be stored in a persistent memory

storage;

5. each keypair is characterized by a temporal va-

lidity;

6. the CA subsystem offers a graphical user inter-

face in order to allow administration of some

services;

7. inserting/deleting end users in/from CA reposi-

tory has to be an administration task;

8. updating end user status (e.g. able/disable) has

to be an administration task; a disabled user is

temporally excluded from whole system, this

feature is activated when end user’s devices are

lost or stolen, when contract’s temporal validity

is expired and is in line for renewed;

9. updating end user key status (e.g. able/disable)

has to be an administration task, an end user

with a disabled key cannot sign SMS while he

can continue to verify information sent to its

device.

10. inserting/deleting service suppliers in/from CA

repository has to be an administration task;

11. updating service supplier status (e.g.

able/disable) has to be an administration

task.

3.2 Architectural Design

The architectural design evolves naturally from iden-

tiﬁed required features. Figure 1 proposes the overall

architecture of Trusted-SMS framework. Despite of

previous deﬁnition of the framework as result of three

main entities, ﬁgure 5 shows six components:

Published Services: it represents the common space

where Service Suppliers interact with End Users

advertising services and products.

Service Supplier: it represents the subsystem that

realizes the Service Supplier entity features pre-

viously identiﬁed.

TRUSTED SMS - A Novel Framework for Non-repudiable SMS-based Processes

Certiﬁcation Authority: it represents the subsystem

that realizes the Certiﬁcation Authority entity fea-

tures previously identiﬁed.

End User: it represents the subsystem that realizes

the End User entity features previously identiﬁed.

SMS Gateway: it represents a generic Short Mes-

sage Service Center (SMSC).

CA Administrator: it represents the front end to CA

administration services.

Figure 1: Overall architectre of Trusted-SMS framework.

This paper goes on to describe accurately identi-

ﬁed subsystem.

Service Supplier subsystem: The Service Supplier

subsystem can be divided in 4 main components (Fig.

2):

• a component that acts as general purpose end user

interface, publishes provided services;

• a component that acts as interface with the sms

gateway, sends and receives SMS to/from end

users;

• a component that acts as interface with the Certi-

ﬁcation Authority in order to request a signature

for a text or to verify an SMS signed by an user;

• a component that can be view as Service Supplier

core, generates SMS text, interacts with others

components in order to process and store end user

requests and responses.

An end user request for a speciﬁc service could

generally done by interacting with the service supplier

directly or by a dedicated interface. The service sup-

plier subsystem collects end user requests, automat-

ically converts the request into a SMS text, requests

to CA a signature for this text and ﬁnally forwards

the SMS to the end user through the SMS gateway.

In order to preserve conﬁdentiality of the SMS con-

tent the signature is requested for a hash of that con-

tent. Reaction to an end user response involves the

same service supplier subsystem components. The re-

sponse is received through the SMS gateway interface

and it is stored into the database. The service supplier

interacts with the CA to verify the appended signa-

ture. The result of the verifying test is recorded in

the database. If the requested service counts a kind of

conﬁrmation, the end user is informed by a new SMS

communication or a message on the service supplier

interface.

Figure 2: Structure of Service Supplier subsystem.

End User subsystem: The End User interacts with

the remaining system by two different ways.

In the ﬁrst case the End User chooses a speciﬁc ser-

vice from the set of the published services; the Service

Supplier of that service asks for conﬁrmation. The

End User has to conﬁrm its choice to make use of re-

quested service.

In the second case, the End User receives a com-

munication about a service directly from the Service

Supplier; only if necessary the End User answers to

that communication. Service Supplier in this case can

send service-communication without any explicit End

User requests. In the ﬁrst case described above, the

End User realizes its interactions using two different

channels; the ﬁrst channel is used to select a service,

the second one is used to accept the delivery of the se-

lected service. In the second case these channels are

coincident.

Separating the capability of requesting one service

from the capability of accepting or denying the deliv-

ery of that service ensures an high level of security. If

those channels rely on different technologies a poten-

tial attack becomes a very hard challenge. The main

software component of the End User entity is repre-

sented by a midlet: a Java 2 Micro Edition(J2ME)

application that can be executed on a personal mobile

device characterized by low computational capability,

such as a smartphone or a pda. The midlet has two

main responsibilities; it has to verify the signatures

that are carried by the incoming SMS and it has to

generate the signatures that are carried by the outgo-

ing SMS according to the CA and End User creden-

tial. Each midlet deployed on a mobile device has

HEALTHINF 2008 - International Conference on Health Informatics

to be provided with the CA public key and the End

User private key; the former is used to verify CA sig-

natures, while the latter is used to generate End User

signatures.

End User credential (i.e. its cryptographic keys) are

included in the midlet resources and protected by us-

ing a symmetric key injected into the midlet code. Re-

ceived and sent SMS are stored in a secure separate

repository, different from the usual mobile phone’s

SMS repository, secured and encrypted by user’s PIN.

Thus, if someone snafﬂes your mobile phone full of

your private SMS he cannot read them because they

are protected inside the repository.

Figure 3 shows the End User subsystem pointing out

that three units made up this subsystem; SMS I/O In-

terface, which manages the SMS sending and receiv-

ing activities, and Graphical User Interface, which

leads the interaction with the User, are coordinated

by the End User Core. In order to store application

data End User Core interacts with Record Manage-

ment System(RMS). Cryptographic operations (i.e.

signature generation or veriﬁcation) are performed by

the Core unit. Service Supplier Interface represents

the second unit; listing all services offered by sup-

plier and requesting for a service delivery represent

the main issues that the second unit has to resolve.

Figure 3: Structure of End User subsystem.

Certiﬁcation Authority subsystem: The Certiﬁca-

tion Authority represents the trusted entity; End User

and Service Supplier share the same conﬁdence to-

wards the CA entity. The CA subsystem has two main

communication partners: the CA Administrator and

the Service Supplier.

Interactions with CA Administrator are intended for

managing users registered to Trusted-SMS frame-

work. Service Supplier interacts with CA subsystem

in order to obtain the generation/veriﬁcation of signa-

ture carried by SMS.

The CA subsystem is supported in all its activities

by a database, which allows the permanent storage

of needed information. Database keeps informa-

tion about End Users, Service Suppliers and CA it-

self. End Users information concern with personal

data (e.g. name, surname) and personal creden-

tial(e.g. public key, public-key-validity ﬂag, user-

enabled ﬂag). In order to insert new users, delete or

enable/disable existent user, enable/disable users keys

those information are accessed in a ”‘write-mode”’ by

CA Administrator with related services. In order to

verify End User generated signatures, credential in-

formation are accessed in a ”‘read-mode”’ by services

related to the Service Supplier. CA information con-

cern with CA credential and CA Administration priv-

ileges; the former are accessed by Service Supplier

related services in order to generate a signature, the

latter are used in authentication process while acquir-

ing CA management control.

Finally, Service Supplier information are related with

supplier data, which are accessed by Service Supplier

related services in order to verify if that Service Sup-

plier is licensed to use these services.

Figure 4 proposes the structure of the Certiﬁcation

Authority subsystem. Certiﬁcation Authority Core

provides cryptographic and database services to the

other modules of this subsystem. These modules

manage the communication with CA partners.

Figure 4: Structure of Certiﬁcation Authority subsystem.

3.3 Technical Features

Elliptic curve cryptography (ECC) (Martinez et al.,

2005) is a family of public-key algorithms that can

provide shorter key lengths and, depending upon the

environment and application in which it is used, im-

proved performance over systems based on integer

factorization and discrete logarithms (Higgins and

Clement, 2001). ECC has its security based on a dif-

ﬁcult mathematical problem. An elliptic curve can be

thought of as a mathematical structure in which cer-

tain operations can be deﬁned. These operations pro-

vide a one-way function that can be used to produce

efﬁcient cryptographic systems. The one-way func-

tion used in ECC is called the elliptic curve discrete

logarithm problem (ECDLP). The ECDLP is simi-

lar to the one-way function on which DSA (of Stan-

dard et Technology, 2007) and Difﬁe-Hellman are

based, and hence, elliptic curve analogs of each of

TRUSTED SMS - A Novel Framework for Non-repudiable SMS-based Processes

these algorithms have been deﬁned. The most pop-

ular signature scheme which uses elliptic curves is

called the Elliptic Curve Digital Signature Algorithm

(ECDSA) (Jonson et al., 2001). The Secure Hash Al-

gorithm (SHA) (F.I.P.S., 2002) hash functions refer

to ﬁve FIPS-approved (F.I.P.S., 2007) algorithms for

computing a condensed digital representation (known

as a message digest) that is, to a high degree of prob-

ability, unique for a given input data sequence (the

message).

Trusted-SMS relies on ECDSA to sign the ex-

changed data, thus avoiding unnoticed modiﬁcation.

The SHA1 hash function makes a digest of the data.

Reducing a message in a digest lowers computational

capabilities needed by the signing task, as we need,

since the mobile devices involved in the system are

very resource bounded. Trusted-SMS uses ECDSA

with a 192 bit Elliptic Curves (EC) with a consequent

48 byte signature value. The Keys size of 192 bit

agrees with the size of an SMS that is 140 bytes for

binary and 160 bytes for textual SMS. In comparison

to a 1024 bit RSA key, ECC (Elliptic Curve Cryptog-

raphy) provides shorter keys, shorter encrypted mes-

sages and faster private key operations. Comparing

the two cryptographic systems, a 1024 bit RSA key is

considered to have the same secuity of a 160 bit ECC

key. The cellular networks can be broken into two

chief components - the radio, or ”air interface” and

the wired backbone (out of scope of this paper). The

air interface of a cellular network can be divided into

control and trafﬁc channels. Control channels (CCHs)

are used for call setup and SMS delivery. Trafﬁc chan-

nels (TCHs) are used for the duration of voice calls.

It helps to think of control channels as a very small

portion of radio frequency that allow cellular towers

to send information pertaining to call setup, SMS de-

livery and network conditions (such as the availabil-

ity of trafﬁc channels) to mobile phones. The Short

Message Service - Point to Point (SMS-PP) is deﬁned

in GSM recommendation 03.40 (3GPP, 2007). GSM

03.41 (3GPP, 2007) deﬁnes the Short Message Ser-

vice - Cell Broadcast (SMS-CB) which allows mes-

sages (advertising, public information, etc.) to be

broadcast to all mobile users in a speciﬁed geograph-

ical area. Messages are sent to a Short Message

Service Centre (SMSC) which provides a store-and-

forward mechanism. It attempts to send messages to

their recipients. If a recipient is not reachable, the

SMSC queues the message for later retry. Transmis-

sion of the short messages between SMSC and phone

can be done through different protocols such as Sig-

naling System 7 (SS7) within the standard GSM MAP

framework or TCPIP within the same standard. Mes-

sages are sent with the additional MAP operation for-

ward short message, whose payload length is limited

by the constraints of the signalling protocol to pre-

cisely 140 bytes (140 bytes = 140 * 8 bits = 1120

bits). In practice, this translates to either 160 7-bit

characters, 140 8-bit characters, or 70 16-bit char-

acters. General Packet Radio Service (GPRS) is a

packet-switched technology. GPRS that is an exten-

sion of GSM can be used as the bearer of SMS. Spoof-

ing from a mobile is impossible unless you can forge

GPRS radio trafﬁc (Levy and Arce, 2004).

4 A CASE STUDY

Realizing a prototype developed with open source

tool we illustrate the validity of our framework. We

utilized Trusted-SMS framework in a speciﬁc health-

care environment. E-Health involving information

and communication technologies that are at the ser-

vice of a wide range of actors in the health sector,

from doctors, hospital managers, nurses, data pro-

cessing specialists, social security administrators to -

of course - patients and citizens, is a good test-bed for

our framework.

The Certiﬁcation Authority performs its tasks by us-

ing Web Services. The W3C Web service deﬁnition

refers to clients and servers that communicate using

XML messages that follow the SOAP-standard (Lai

et al., 2005). The CA publishes two different lists of

web services, each one for its communication part-

ners: the CA Administrator and the Service Supplier.

The permanent storage of information is achieved us-

ing a mysql database and it is protected by symmetric

key encryption (Zoratti, 2006).

Service Supplier publishes its services on an inter-

face, from which end users can request the delivery

of a speciﬁc service. Once the end user requests

a service the related request is stored into a mysql

database. For each request received the supplier use

the signature generation service in order to produce

the related SMS. Each received SMS is drawn from

the database and it is processed in order to verify its

signature validity. The Service Supplier subsystem

utilizes the signature veriﬁcation/generation services

exported by CA as web services.

A SMS gateway is realized by an external hard-

ware component that behaves as a gateway between

GSM mobile phone network and web applications

(AreaSX, 2007). This component provides the SMS

sending/receiving capability using simple GET or

POST HTTP transactions over Ethernet.

The End User subsystem is mainly represented by a

Java 2 Micro Edition application compliant to MIDP

2.0 and CLDC 1.1 and installed on different models of

HEALTHINF 2008 - International Conference on Health Informatics

Nokia mobile phones: series 40 equipped with Sym-

bian OS 8.0 (i.e. 6630, 6680), series 60 2nd edition

equipped with Symbian OS 8.1 (i.e. N70), and series

60 3rd edition equipped with Symbian OS 9.1 (i.e.

N73, E70). Bouncycastle Crypto APIs offer support

for realizing cryptographic operations. This APIs are

an open source solution, which works with everything

between J2ME and JDK 1.6 (Bouncycastle, 2007).

Next, we present the description of two use cases,

both derived from different ways of the end user in-

teraction with the framework described above.

In ﬁrst use case, the End User (a patient) has a

preliminary contact with a medical professional for

receiving a complete check-up. As soon as the physi-

cians have the results for physical examinations, he

sends a SMS signed to the patient. The SMS car-

ries personal information about patient health status

protecting them with some cryptographic techniques.

Signing the SMS content ensures patient on sender

authenticity; moreover cryptographic protection guar-

antees patient privacy. In this way physicians can in-

form immediately the patient about the examination,

if necessary they can ask for a secondary care.

The second use case, which refers to a more com-

plex situation, will be described using a schematic

representation (Fig. 5). In particular this case-study

depicts the whole scenario including all interaction

from the preliminary registration phase. In order to

reach clearness in exposition, description is organized

as a ﬁnite sequence of steps, which refers to Figure 5.

Figure 5: Structure of Certiﬁcation Authority subsystem.

1. The CA-Administrator add End Users and Service

Suppliers to the framework, this represents the

zero step of the happy scenario of the case study.

This step is executed for every End User/Service

Supplier, who decides to subscribe to Trusted-

SMS services.

2. The Service Supplier that delivers a set of ser-

vices publishes them on its interface (such as a

web site).

3. The End User (a patient) has an initial contact

with a medical professional for receiving health

examination.

4. The End User choices a speciﬁc service (such as

request for its own case history, speciﬁc exam-

ination results, information about personal cure,

reservation for a secondary care, buying a medi-

cal examination, etc.) from that interface and

5. its request reaches the Service Supplier.

6. The Service Supplier produces an SMS related to

the request received.

7. Utilizing the signature generation service offered

by Certiﬁcation Authority, the Service Supplier

signs the SMS content

8. The CA checks both the Service Supplier creden-

tials and the End User credentials; only if the cre-

dentials are valid, CA begins the signature gener-

ation.

9. The CA sends the signed response to the request-

ing Service Supplier.

10. The Service Supplier forwards the digitally signed

SMS to SMS Gateway, (10) which delivers it to

the End User.

11. The End User veriﬁes the signature carried by the

SMS, if necessary accepts or refuses the service

delivery and generate the signature for response

SMS.

12. The response SMS is sent to the SMS Gateway,

13. which forwards it to the Service Supplier.

14. The Service Supplier requests to utilize the digital

signature veriﬁcation process.

15. The CA processes the Service Supplier request by

checking the credentials of entity involved and

16. answer to Service Supplier with the status of ver-

iﬁcation process.

17. The Service Supplier realizes the End User choice

(cfr. step 10 accept or refuse) if the End User dig-

ital signature was successfully checked.

18. The Service Supplier publishes on the web site the

transaction status

19. The End User can control the effective status of

the service delivery. Steps 18 and 19 are condi-

tional on the speciﬁc requested service.

TRUSTED SMS - A Novel Framework for Non-repudiable SMS-based Processes

5 CONCLUSIONS

The growth of mobile technology has opened various

opportunities, both in marketing and in M-Commerce

applications; technologies such as cell phone net-

works are becoming integrated with other systems

such as the Internet. The SMS have been very pop-

ular among mobile phone users because it is silent,

fast, and cheap. Unfortunately, this may lead to new

security risks, for example when conducting phish-

ing attacks using mobile technology and especially

the SMS.

In this paper we proposed a framework to exchange

secure SMS with respect to: (a) security, communi-

cation between principals are based on well crypto-

graphic techniques, (b) traceability, transaction are

not kept anonymous, (c) usability and convenience,

cost of deployment and management for all subsys-

tems involved (consumer, service suppliers, trusted

service provider) are acceptable.

Furthermore, in order to set Trusted-SMS into a spe-

ciﬁc e-healthcare scenario, we made a prototype de-

veloped with open source tool. Since current trends

in mobile phone technology move towards a direc-

tion of miniaturization and higher computational and

graphical performance, allowing a complete transac-

tion procedure in less than a minute, we believe that

Trusted-SMS prototype can shows the validity of our

framework in the ﬁeld.

Finally, the case study covers only one of the possible

uses of Trusted-SMS framework. The systems man-

aging private information, or systems that schedule

a booking/reservation procedure (e.g. system that can

be used by theatre, stadium cinemas, airline company,

university), or involving money transfers, can beneﬁt

of security features provided by Trusted-SMS frame-

work.

REFERENCES

3GPP (2007). 3rd generation partnership project.

AreaSX (2007). Sms machine/htpp.

Barbi, L. (2007). Spidersms - sending and reception of en-

crypted sms.

Bouncycastle (2007). The legion of the bouncycastle.

Center, C. C. R. (2007). Sms spooﬁng - q-a with ccrc staff.

Chirico, U. (2007). Miabo - messages in a bottle.

CryptoSMS (2007). Cryptosms - protecting your conﬁden-

tial sms messages.

Dickinger, A., Haghirian, P., Murphy, J., and Scharl, A.

(2004). An investigation and conceptual model of

sms marketing. In System Sciences, Proceedings of

the 37th Annual Hawaii International Conference on.

F.I.P.S. (2002). Secure hash standard, ﬁps publication.

F.I.P.S. (2007). Federal information processing standards.

FortressSMS (2007). Fortresssms - phone based application

to send and read encrypted sms text messages.

Higgins, J. Z. L. and Clement, M. (2001). Performance of

ﬁnite ﬁeld arithmetic in an elliptic curve cryptosys-

tem. Security Technology, CCST ’05. 39th Annual

2005 International Carnahan Conference on, pages

249 – 256.

Jonson, D., Menezes, A., and Vanstone, S. (2001). The

elliptic curve digital signature algorithm.

Kivimaki, A. and Fomin, V. (2001). What makes a killer

application for the cellular telephony services? Stan-

dardization and Innovation in Information Technol-

ogy, 2nd IEEE Conference, pages 25 – 37.

Kryptex (2007). Kryptex - send and receive encrypted text

sms.

Lai, K. Y., Phan, T. K. A., and Tari, Z. (2005). Efﬁcient

soap binding for mobile web services. Local Com-

puter Networks 30th Anniversary, The IEEE Confer-

ence on, pages 218 – 225.

Levy, E. and Arce, I. (2004). Interface illusions. In IEEE

Security and Privacy, pages 66 – 99.

Martinez, V. G., Avila, C. S., Garcia, J. E., and Encinas,

L. H. (2005). Elliptic curve cryptography: Java im-

plementation issues. Local Computer Networks 30th

Anniversary, The IEEE Conference on, pages 238 –

241.

MultiTasker (2007). Multitasker - messaging made easy.

of Standard et Technology, N. I. (2007). Digital signature

standard.

van der Merwe, A., Seker, R., and Gerber, A. (2005). Phish-

ing in the system of systems settings: mobile technol-

ogy. In Systems, Man and Cybernetics, IEEE Interna-

tional Conference on, pages 228 – 232.

Waadt, A., Bruck, G., Jung, P., Kowalzik, M., Trapp, T., and

Begall, C. (2005). Qos monitoring for professional

short-message-services in mobile networks. Wireless

Communication Systems, 2nd International Sympo-

sium on, pages 228 – 232.

Zoratti, I. (2006). Mysql security best practices. Crime and

Security, The Institution of Engineering and Technol-

ogy Conference on, pages 183 – 198.

HEALTHINF 2008 - International Conference on Health Informatics
