A METHOD FOR EARLY CORRESPONDENCE DISCOVERY USING

INSTANCE DATA

Indrakshi Ray and C. J. Michael Geisterfer

Department of Computer Science, Colorado State University, 601 S. Howes Street, Fort Collins, USA

Keywords:

Information Integration.

Abstract:

Most of the research in database integration have focussed on matching schema-level information to determine

the correspondences between data concepts in the component databases. Such research relies on the availabil-

ity of schema experts, schema documentation, and well-designed schemas – items that are often not available.

We propose a method of initial instance-based correspondence discovery that greatly reduces the manual effort

involved in the current integration processes. The gains are accomplished because the ensuing method uses

only instance data (a body of database knowledge that is always available) to make its initial discoveries.

1 INTRODUCTION

The need to integrate information from different

databases arise in many scenarios. For instance, the

latest trend for organizations is to purchase applica-

tions from a outside software company targeted at

speciﬁc business functions and then integrate these

multiple business applications into an organization-

wide operations support system. The result is the par-

titioning of the data of the organization along with

the partitioning of the business functionality. These

applications will work with their own data and data

models, optimized for the speciﬁc business function-

ality. Although these different applications use their

own data models, they will most likely work on data

representing the same real-world concepts and there-

fore will contain some intersection of similar data.

Since these applications were developed by indepen-

dent vendors, they will not share the same schema.

Ultimately, the schemas and data of these various

component databases must be integrated in some

manner before the data can be accessed and manip-

ulated across the greater domain at the organization-

wide level.

In the database integration research (Aslan and

Mcleod, 1999; Chua et al., 2003; Lawrence and

Barker, 2001; Lenzerini, 2002; Parent and Spaccapi-

etra, 1998; Rahm and Bernstein, 2001; Schmitt and

Trker, 1998; Yan et al., 2002; Zhang, 1994), much

effort has gone into developing automated solutions

to integrating the schema (and then, afterwards, the

data itself). In most of the research literature, the so-

lutions and approaches have concentrated on match-

ing schema-level information to determine the corre-

spondences between data concepts in the component

databases. If instance-level information is even uti-

lized, it is used only to augment the correspondences

found using the schema-level information, to catch

what the schema-level matching missed.

In most of the relevant research, the schema trans-

formation step occurs before correspondence inves-

tigation. It is argued that the schemas must be

transformed into a canonical data model before the

schemas can be analyzed for correspondences (Aslan

and Mcleod, 1999; Parent and Spaccapietra, 1998;

Rahm and Bernstein, 2001). Schema transformation

itself can be an involved process, and although there

are a few tools available, this too is a manual process

relying again on the expert knowledge of the schemas

involved.

This paper challenges both these mainstream

positions by considering an instance-based initial

inter-database correspondence discovery method that

greatly reduces the manual effort involved over the

entire integration process. Because this method is ap-

plied before schema transformation, it saves effort by

258

Ray I. and J. Michael Geisterfer C. (2007).

A METHOD FOR EARLY CORRESPONDENCE DISCOVERY USING INSTANCE DATA.

In Proceedings of the Ninth International Conference on Enterprise Information Systems - DISI, pages 258-263

DOI: 10.5220/0002350102580263

 SciTePress

providing for an more efﬁcient transformation pro-

cess at a later step. Because it initially uses instance-

level information, lack of expert schema-knowledge

and poor schema designs do not hinder its progress.

We propose that schema transformation occur af-

ter correspondence discovery. If one determines (dis-

covers) the relationships between the schemas of only

those portions of the databases that are to be inte-

grated, then one has determined the portions of the

schemas that must be integrated. Once those portions

of the schemas have been identiﬁed and related, they

can be transformed to meet the integration model de-

sired. There is now less schema to transform, and the

actual transformation process is simpler because there

is know exacting knowledge of the schemas involved.

The main contribution of this paper is to propose a

method of initial instance-based correspondence dis-

covery that greatly reduces the manual effort involved

in the current integration processes. The gains are ac-

complished because the ensuing method uses only in-

stance data (a body of database knowledge that is al-

ways available) to make its initial discoveries.

The rest of this paper is organized as follows: sec-

tion 2 explains the method; and section 3 concludes

our paper and provides some pointer to future work.

2 THE METHOD

The proposed method focuses on correspondence in-

vestigation – determining correspondences between

two or more databases. We require that the target

databases be intersected as we will be searching the

intersection area for (nearly) exact matches of infor-

mation. Two databases are said to be intersected if the

real world concepts they represent have some com-

mon elements or are otherwise interrelated. An ex-

ample of intersected databases would be two separate

applications, one an order management system and

the other a billing system, that each need to integrate

the concept of a customer. In such cases two elements

from two databases correspond to each other (Par-

ent and Spaccapietra, 1998) because they describe the

same real world concept or fact.

Our approach basically involves two activities:

deﬁning potential correspondences and accepting

those correspondences validated by the method. But

ﬁrst, we need to discuss the matching of instance data.

2.1 Instance Matching

Our goal is to ﬁnd out if two attributes are related to

each other. For this, we need to compare, or match,

these sets of instance values using only the type of

data and not its meaning (semantics). We execute our

initial matching on raw instance data speciﬁcally ig-

noring any schema information.

We deﬁne a function called the RawMatch that

checks whether the the attributes of tables belong-

ing to heterogeneous databases are equal or not. This

function compares the data in the tables looking for

exact or nearly exact matches. Nearly exact matches

are deﬁned as similar data that meets a speciﬁed conﬁ-

dence factor. Conﬁdence factor, expressed as a value

in the range [0..1], deﬁnes the amount of difference

that can be tolerated when comparing two items A

and B, where A and B can be simple instance data,

attributes, or sets of attributes. The conﬁdence fac-

tor is selected by the integration specialist based upon

his/her idea as to the similarities between the data in

the databases.

Algorithm 1 Determine if two instance data match.

Input: (i) d

, d

– instance data and (ii) f – conﬁ-

dence factor.

Output: boolean – indicates whether or not a match

has been found

Proc RawMatch(d

, d

, f)

if compare(d

, d

) > f return true

else return false

The procedure compare compares between two

data instances and calculates a matching factor.

Matching factor, expressed as a value in the range

[0..1], indicates the amount by which two elements

A and B match where A and B can be simple instance

data, attributes or sets of attributes. For exact matches

between two data instances d

and d

, m equals 1. For

no match, m equals 0. The exact procedure compare

depends on the type of data instances. We show what

this procedure does for string type and numeric data.

Comparing String Type Instance Data For charac-

ter string based data, comparisons are made string-to-

string, case insensitive, with and without spaces re-

moved. If a difference is detected, RawMatch will

attempt to re-establish alignment (shift) in the strings

(e.g., a simple case where the ﬁrst string uses a space

to separate characters and the second string does not).

For each comparison, a matching factor, m, is calcu-

lated. For exact matches, m = 1.000. For nearly exact

string matches, m is calculated as a percentage of the

string that was similar. For example, when comparing

the two strings:

s1 = ”

1024 West Valley View Rd.

” and

s2 = ”

1024 West Valleyview Rd

”,

RawMatch will ﬁnd an initial difference at posi-

tion 17, where s1 =

’ ’

and s2 =

’v’

. It will the try to

A METHOD FOR EARLY CORRESPONDENCE DISCOVERY USING INSTANCE DATA

259

re-establish alignment, ﬁnding it again at the next po-

sition (so now it has reset itself and is comparing s1 =

’V’

and s1 =

’v’

. It ﬁnds the next difference when s1

’.’

(because s2 doesn’t have anymore characters).

Now the strings are exhausted.

So, with strings of length 25 (maximum of the

two), and with 2 mismatches, the compare function

computes the matching factor m in the following way:

it calculates the percentage of matching characters in

the string, that is, m = (23/25) = .920. If this value

is above the pre-determined conﬁdence factor f, then

RawMatch counts this as a match between 2 instances

of attributes for tables from different databases.

Comparing Numeric Instance Data Numeric values

are either exact matches or can be a near match. The

matching factor can be calculated by using statistical

functions.

2.2 Correspondence Investigation

We try to ﬁnd the relationships between the attributes

belonging to tables in different databases. An exam-

ple will help to illustrate this. Let element e

refer

to an instance value for the attribute

Name

in a table

in database A, and let elements e

and e

refer to in-

stance values for the attributes

FName

and

LName

re-

spectively, in a table in database B. If the values of e

, and e

are ”John Henry”, ”John”, and ”Henry”, re-

spectively, then we would say that e

corresponds in

an equal manner to the concatenation of e

and e

Instance Data

Selection

Raw Matching

Function

Initial

pICAs

Correspondence

Matrices ->

Accepted ICAs

Matching Rules and

Information Derivation

Updated

pICAs

Complex Matching

Functions

Partially Integrated

Schema

Initial

Correspondence

Matrices

Figure 1: Instance-based Correspondence Discovery

Method.

If we get enough of such instance to instance

matches, then we can become more conﬁdent that

the tables containing those ﬁelds correspond to each

other. The “enough” is speciﬁed by the value of the

conﬁdence factor F, supplied by an integration spe-

cialist. The task is to determine how many times

values from attributes in one database matches val-

Table 3: Table Type in DB2.

id T1 T2 TxCd

1 1 0 1

2 1 1 1

3 2 0 3

4 2 1 4

5 3 0 8

6 3 1 12

7 4 0 2

8 4 1 2

ues from those in another database. Sometimes trans-

formation functions need to be applied to the at-

tributes before they can be compared. The function

transform changes the data to the correct form before

they are input to the RawMatch algorithm for com-

parison. Using the function RawMatch we count the

number of instance matches over the total number of

instance (number of rows in the tables). This will gen-

erate a raw percentage: if 87 out of 100 instance pairs

matched then the matching factor M for the attributes,

is given by, M = .870 (87/100). If the matching factor

M is greater than F, then a correspondence does exist

between the sets of attributes.

Algorithm 2 Correspondence Discovery Algorithm.

Input: (i) {A} – set of instance data corresponding to

attributes of one database, (ii) {B} – set of instance

data corresponding to attributes of second database,

and (iii) F – Conﬁdence factor

Output: boolean – indicating whether a correspon-

dence exists between the two sets of attributes

Proc CorrespondenceInvestigate(A, B, F)

matchInstance = 0

totalInstance = 0

for each a

in A do

totalInstance = totalInstance + 1

for each b

in B do

if RawMatch(transform(a

),transform(b

), f)

matchInstance = matchInstance + 1

M = matchInstance/totalInstance

if M > F return true

else return false

2.3 Method Synopsis

Our method is described in Figure 1.

2.3.1 Instance Data Selection

The initial step is the selection of the initial instance

data which needs to be matched to discover corre-

spondences. When looking at the areas of interest in

ICEIS 2007 - International Conference on Enterprise Information Systems

260

Table 1: Table CustType in DB1.

id Type Cname Fname Mname Xname NamePrfx PriAddr

0 Res Smith David A Mr 1

1 Res Johnson Elaine A Ms 3

2 Bus Redding Alan D DDS Dr 8

3 Edu Dept CS CSU 15

Table 2: Table Addr in DB1.

id Cid Num Preﬁx Street Type AptT AptN City State Post

1 0 123 West 57th Ave Ft. Col. CO 80524

2 0 4167 North Reading Way Apt B Ft. Col. CO 80521

3 14 8008 Hampden Rd Suite 101 Ft. Col. CO 80523

4 1 1001 East Main St Suite 220 Laporte CO 80544

the component databases to be integrated, one must

identify which portions of these databases have poten-

tial intersections of data. If, for example, the choice

has been made to integrate customer and product in-

formation, one only needs to concern themselves with

those portions of the databases that contain informa-

tion (instance data) about those topics (concepts). A

high-level perusal of the schemas and data in these

databases should yield a reliable idea of which tables

contain data concerning customer and product. For

instance, we see that the Tables 1 and 2 in Database 1

have an intersection with Tables 3 and 4 in Database

2. This step should identify any tables that contain

relevant information. This step does not have to be

an exacting, exhaustive search in a particular database

for all customer or product instances. This is not an

initial step of inter-database relationship discovery.

All that is being accomplished here is the identiﬁca-

tion of speciﬁc portions of a database that contains

tables that are of interest to the concept areas we are

trying to integrate.

Once these areas have been identiﬁed, the next

step is to ﬁnd correspondences at the table (relation)

level because it will be these relations that will pro-

vide the initial data for comparison. We will not dis-

cuss this as it has been addressed by other researchers.

2.3.2 Inter-Database Correspondence Assertions

Using the information obtained during information

discovery, we develop inter-database correspondence

assertions (ICAs) over which our matching algo-

rithms can operate. Initially, we do not have any pre-

viously matched relationships, so we can only specify

tests. These tests are referred to as potential ICAs or

p-ICAs. A typical p-ICA consists of two parts that are

separated by the symbol ♦. This basically indicates

that all the data in the tables (relations) to the left of

the ♦ should be compared to all the data in the tables

to the right of the ♦. An example p-ICA that asks to

match data in the tables CustType and Addr in DB1

to the tables Type and Cust in DB2 is given below.

{DB1 :: CustType,DB1 :: Addr}♦{DB2 :: Type,DB2 ::

Cust}

The data is then analyzed by our matching al-

gorithms. The output is a correspondence matrix

that contains the conﬁdence factors comparing the at-

tributes of two tables. Using the data from Tables 1,

2, 4 and 3, one of the correspondence matrices pro-

duced by our matching algorithms is given in Table

2.3. (The factor f for string matches was set at 0.50).

2.3.3 Matching Rules

The next step is to analyze the correspondence ma-

trix to identify relationships. At the completion of

the analysis, more ICAs will have been discovered.

These new ICAs will be the input for the next round

of matching.

Analysis The integration specialist must analyze the

correspondence matrices and decide which relation-

ships are genuine, which are false, and more impor-

tantly, which potential relationships are worth pursu-

ing. This will help in determining the new ICAs. Ac-

cepted correspondences become new ICAs; rejected

matches are explicitly stated as inequality ICAs. This

will prevent the match functions from ”revealing”

these matches again in subsequent processing. By an-

alyzing Table 2.3 above, we can gather that there are

strong relationships between the following attributes:

DB1::CustType::ID

∼

DB2::Cust::ID

DB1::CustType::Cname

∼

DB2::Cust::Lname

DB1::CustType::Fname

∼

DB2::Cust::Fname

DB1::CustType::Mname

∼

DB2::Cust::M

DB1::CustType::Xname

∼

DB2::Cust::Other

DB1::CustType::NamePrfx

∼

DB2::Cust::Sal

A METHOD FOR EARLY CORRESPONDENCE DISCOVERY USING INSTANCE DATA

261

Table 4: Table Cust in DB2.

id ty Sal Fname M Lname Oth Num StrNam Apt City St Zip

1 1 Mr David Smith 123 57th Ft. Col. CO 80524

2 1 Ms Elaine Johnson 1001 Main 220 Laporte CO 80544

3 7 Dr Alan D Redding DDS 321 Medical 200 Ft. Col. CO 80522

4 8 Howard X Hughes 1 Hughes Bellevue CO 80558

Table 5: Correspondence Matrix between DB1::CustType and DB2::Cust.

DB2:Cust

DB1::CustType ID Type Sal Fname M Lname Other Num ...

ID 0.750 0.425 0.000 0.000 0.035 0.000 0.000 0.025 ...

Type 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 ...

Cname 0.000 0.000 0.000 0.000 0.000 0.750 0.000 0.000 ...

Fname 0.000 0.000 0.000 0.750 0.000 0.000 0.000 0.000 ...

Mname 0.000 0.000 0.250 0.000 0.750 0.000 0.000 0.000 ...

Xname 0.000 0.000 0.000 0.000 0.000 0.000 0.750 0.000 ...

NamePrfx 0.000 0.000 0.750 0.000 0.250 0.000 0.000 0.000 ...

PriAddr 0.315 0.425 0.000 0.000 0.000 0.000 0.000 0.175 ...

while there exist some possible relationships be-

tween the following:

DB1::CustType::ID

∼

DB2::Cust::Type

DB1::CustType::ID

∼

DB2::Cust::M

DB1::CustType::ID

∼

DB2::Cust::Num

DB1::CustType::Mname

∼

DB2::Cust::Sal

DB1::CustType::NamePrfx

∼

DB2::Cust::M

DB1::CustType::PriAddr

∼

DB2::Cust::ID

DB1::CustType::PriAddr

∼

DB2::Cust::Type

DB1::CustType::PriAddr

∼

DB2::Cust::Num

Creation of More Match ”Rules” In our analysis,

we will determine which discovered matches we will

accept. For those for which a strong correspondence

was found, we need to add these as ICAs. This will

yield statements like:

{DB1 ::CustType :: CName} = {DB2 ::Cust :: Lname}

These statements must be added to the input ﬁle for

the match function. If there was a match that we

would like to not be used by the match algorithm (a

match that we do not accept), for example to apparent

match between the ID ﬁelds, then we need to place

create an ICA indicating an inequality:

{

DB1::CustType::ID

} 6= {

DB2::Cust::ID

}

This inequality speciﬁcation will indicate to the match

functions that this relationship need not be processed.

This will save some time in processing. We must an-

alyze the weaker matches too, to see if there is a pos-

sibility that there are indeed good candidates for po-

tential matches here. For the example given, there are

no such situations.

More complex comparison ”rules” can now also

be added. For example, in the correspondence ma-

trix comparing DB1::CustType with DB2::Type, we no-

tice that there is no relationship established between

the attributes (other than ID which we have already

discounted). We notice that CustType uses a character

ﬁeld to indicate customer type while Type uses integer

values. To overcome this, an ICA can be developed to

give the match processing hints:

{DB1 :: CustType}♦{{DB2 :: Type}AND

{(”Res” = 1, ”Bus” = 4,”Gov” = 2,”Edu” = 3)}}

This speciﬁcation lets the match processing know that

there may be a relationship between these values. An-

other situation that must be matched would be looking

for relationships between tables based on a single key

ﬁeld that pulls all the information together from mul-

tiple tables. This might be the case for the following

speciﬁcation:

{DB2 :: Cust}♦{{DB1 ::CustType,DB1 :: Addr}

WHERE

{DB1 :: CustType :: ID

DB1 :: Addr ::CID}}

One could also search for a relationship amongst ta-

bles by keying on the particular value of an instance

of an attribute:

{{DB2 ::Cust}WHERE

{DB2 :: Cust = ”Smith”}}♦{{DB1 :: CustType,DB1 ::

Addr}

WHERE

{DB1 :: CustType :: ID = DB1 :: Addr :: CID}}

These ICAs can be come quite complex, allowing for

a powerful correspondence discovery method.

2.3.4 More on Matching Algorithms

As the match processing progresses and the ICAs

become more complex, we no longer ﬁnd matches

based solely on the instance data. Early corre-

ICEIS 2007 - International Conference on Enterprise Information Systems

262

spondence discoveries lead to true knowledge about

the relationships between the actual schemas from

both databases. This relationship knowledge is ex-

tremely reliable because it has been extracted from

the database themselves, through the instance data.

As our knowledge of these relationships increases,

we can specify more exacting and detailed ICAs, re-

sulting in even more knowledge. As the ICAs be-

come more complex, and begin to rely increasingly on

schema-level information, the match functions must

grow in complexity accordingly. There are several

good match algorithms (Aslan and Mcleod, 1999;

Chua et al., 2003; Castano et al., 2001; Gal et al.,

2003; Lawrence and Barker, 2001; Li and Clifton,

2000; Schmitt and Trker, 1998) that could be used

at this stage in the process.

2.4 The Result

The correspondence investigation method proposed

provides an initial discovery of inter-database rela-

tionships. During the implementation of the method,

both information about the individual schemas of the

component databases as well as initial inter-schema

relationship are discovered. Accepted ICAs provide

direct inter-schema relationship information. With

only a portion of the component databases schemas

needing transformation, the information in the ac-

cepted ICAs can be used in building this partial inte-

grated schema. The existence of a partially integrated

schema aids the integration specialist in detecting new

assertions (pICAs) as well as errors with the existing

ICAs. The result is enough information to make the

approaches based on schema integration more viable

and efﬁcient.

3 CONCLUSIONS

This paper has proposed a method for correspondence

investigation that does not suffer if there is a lack of

expert knowledge of the schemas involved nor does it

assume that those schemas are well designed. Imple-

mentation of this method will greatly reduce the man-

ual effort involved in the integration process, which

currently heavily dependent upon such efforts.

In future, we plan to integrate existing match func-

tions developed in the artiﬁcial intelligence ﬁeld with

our work. Sophisticated and efﬁcient match functions

used in comparing instance data may give us more

correspondence than would be otherwise possible. In

future we would also like to develop a language to

formally specify the inter-correspondence assertions.

ACKNOWLEDGEMENTS

The work was supported in part by a grant from

AFOSR under Award No. FA9550-04-1-0102.

REFERENCES

Aslan, G. and Mcleod, D. (1999). Semantic heterogene-

ity resolution in federated databases by metadata im-

plantation and stepwise evolution. The VLDB Journal,

8:120–132.

Castano, S., Antonellis, V. D., and di Vemercati, S. D. C.

(2001). Global Viewing of Heterogeneous Data

Sources. IEEE Transactions on Data Knowledge and

Engineering, 13(2):277–297.

Chua, C. E. H., Chiang, R. H. L., and Lim, E. (2003).

Instance-based attribute identiﬁcation in database in-

tegration. The VLDB Journal, 12:228–243.

Gal, A., Trombetta, A., Anaby-Tavor, A., and Montesi, D.

(2003). A model for schema integration in heteroge-

neous databases. In Proceedings of the 7th Interna-

tional Database Engineering and Applications Sym-

posium IDEAS ’03), pages 2–11.

Lawrence, R. and Barker, K. (2001). Integrating relational

database schemas using a standardized dictionary. In

Proceedings of the 2001 ACM Symposium of Applied

Computing, pages 225–230.

Lenzerini, M. (2002). Data integration: A theoreti-

cal perspective. In Proceedings of the 21st ACM

SIGMOD-SIGACT-SIGART Symposium on Principles

of Database Systems, pages 233–246.

Li, W. and Clifton, C. (2000). SemInt: A Tool for Iden-

tifying Attribute Correspondences in Heterogeneous

Databases Using Neural Network. IEEE Transactions

on Data Knowledge and Engineering, 33(1):49–84.

Parent, C. and Spaccapietra, S. (1998). Issues and Ap-

proaches of Database Integration. CACM, 41(5):166–

178.

Rahm, E. and Bernstein, P. A. (2001). A survey of ap-

proaches to automatic schema matching. The VLDB

Journal, 10:334–350.

Schmitt, I. and Trker, C. (1998). An incremental approach

to schema integration by reﬁning extensional relation-

ships. In Proceedings of the 7th International Con-

ference on Information and Knowledge Management,

pages 322–330.

Yan, G., Ng, W. K., and Lim, E. (2002). Product Schema In-

tegration for Electronic Commerce A Synonym Ap-

proach. IEEE Transactions of Knowledge and Data

Engineering, 14(3):583–598.

Zhang, J. (1994). A formal speciﬁcation model and its ap-

plication on multidatabase systems. In Proceedings of

the 1994 Conference of the Centre for Advanced Stud-

ies in Collaborative Research, pages 76–89.

A METHOD FOR EARLY CORRESPONDENCE DISCOVERY USING INSTANCE DATA

263
