TOWARDS POLYGON-BASED SIMILARITY AGGREGATION

IN ONTOLOGY MATCHING

Feiyu Lin and Kurt Sandkuhl

School of Engineering, Jönköping Universiy, Gjuterigatan 5, Jönköping, Sweden

Keywords: Polygon, similarity, aggregation, ontology matching.

Abstract: Due to an increased awareness of potential ontology applications in industry, public administration and

academia, a growing number of ontologies are created by different organizations and individuals. Although

these ontologies are developed for various application purposes and areas, they often contain overlapping

information. In this context, it is necessary to find ways to integrate various ontologies and enable use of

multiple ontologies. A number of concepts and approaches for ontology alignment and matching have been

developed in this field. In this paper, we introduce our preliminary work on ontology matching using

polygon-based similarity aggregation. The main ideas we contribute to the research field are (1) to

aggregate the results of distance calculations between concepts in different ontologies by creating polygons

for each ontology and (2) to compare the area of these polygons for deciding on similarity

1 INTRODUCTION

When people or machines must communicate

between themselves, they need a shared

understanding of the same concepts. This finding

from 19

century philosophy has influenced and

been used in numerous research fields, like

knowledge management, enterprise modeling or

information systems and is one reason for the

increasing use of semantic technologies.

Due to an increased awareness of potential

ontology applications in industry, public

administration and academia, a growing number of

ontologies are created by different organizations and

individuals. Although these ontologies are

developed for various application purposes and

areas, they often contain overlapping information. In

this context, it is necessary to find ways to integrate

various ontologies and enable cooperation. In this

paper, we present our preliminary work on using

polygon similarity for ontology matching.

2 RELATED WORK

There are many approaches that can be seen related

to ontology matching. First we distinguish concepts

about ontology mapping, matching and alignment,

then we introduce different methods that can be used

to calculate distance between concepts and we

discuss related work.

2.1 Ontology Mapping / Matching /

Alignment

The terms mapping, matching and alignment are

frequently used in work about combining ontologies.

Recent studies about combining ontologies (e.g. Noy

and Musen, 2002) or (Keet, 2004)) distinguish

between two principles approaches in this area: if

the main objective is to combine two ontologies of

the same subject area, this is denoted merging. In

case the aim is to combine two ontologies from

different subject areas, the term integration is used.

As a first phase in ontology merging and

integration, the alignment of source ontologies is

performed, aiming at identifying correspondences

between the source ontologies. This process can be

further divided into different steps such as mapping

(i.e. finding equal parts in different source

ontologies), matching (i.e. finding similar parts in

the source ontologies) or finding translation rules

between ontologies.

391

Lin F. and Sandkuhl K. (2007).

TOWARDS POLYGON-BASED SIMILARITY AGGREGATION IN ONTOLOGY MATCHING.

In Proceedings of the Third International Conference on Web Information Systems and Technologies - Web Interfaces and Applications, pages 391-395

DOI: 10.5220/0001271303910395

 SciTePress

2.2 Distance Calculation

Different methods can be used to calculated distance

between concepts in ontologies:

 String Similarity: (Cohen, 2003) has good

survey of the different methods to calculate

string distance.

 Synonyms (with the help of dictionary or

thesaurus): Synonyms can help to solve the

problem of using different terms in the

ontologies for the same concept.

 Structure Similarity: This usually is based on

is-a or part-of hierarchy of the ontology in the

graph. Similarity flooding (Melnik, 2002)

matching algorithm uses graphs to find

corresponding nodes in the graphs based on a

fix-point computation.

 Based on instances: Examples are GULE

(Doan, 2002) or FCA-Merge (Stumme, 2001).

GULE uses multiple machine learners and is

exploiting information in concept instances

and taxonomic structure of ontologies. FCA-

Merge is a method for comparing ontologies

that have a set of shared instances or a shared

set of documents annotated with concepts

from source ontologies.

2.3 Ontologies Matching Systems

There are some ontology matching systems available

using some or all above methods. Examples are

 PROMPT (Noy, 2003) is a semi-automatically

tool and a plug-in for the open-source

ontology editor PROTÉGÉ (Protégé). It

determines string similarity and analyzes the

structure of ontology. It provides guidance for

the user for merging ontologies. It suggests

the possible mapping and determines the

conflicts in the ontology and proposes

solutions for theses conflicts.

 Chimaera (Chimaera) is a tool for the

Ontolingua editor. It supports merging

multiple ontologies and diagnosing individual

or multiple ontologies. If string matches are

found, the merge is done automatically,

otherwise the user is prompted for further

action.

 FOAM (Foam) is a tool to fully or semi-

automatically align two or more OWL (OWL)

ontologies. It is based on heuristics

(similarity) of the individual entities

(concepts, relations, and instances). These

entities are compared using string similarity

and SimSet for set comparisons.

 OLA (Euzenat, 2004.) takes care of all the

possible characteristics of ontologies (i.e.,

terminological, structural and extensional).

String similarity is used to calculate the labels’

similarity. The structures constraints are

considered during the matching.

 ASCO (Bach, 2004) uses as much available

information in ontology as possible (e.g.

concepts, relations, structure). It applies string

similarity. TF/IDF is used for calculating

similarity value between descriptions of the

concepts or relations. WordNet (WordNet) is

integrated to find synonyms. Structure

matching is used for modifying or asserting

the similarity of two concepts or relations.

3 SIMILARITY AGGREGATION

BASED ON POLYGONS

Based on the methods discussed in 2.2, it is possible

to calculate similarity expressed by the distances

between concepts of ontologies. But even if we get

the concepts’ distances, we need an algorithm to

aggregate the results of distance calculation in order

to determine similarity on ontology level.

The main idea of our approach is to compare

similarity between objects by comparing the area of

polygons corresponding to each object, i.e. if

polygons have exactly the same areas, similarity

between the two objects represented by the polygons

is maximal. An object in this context is a class

within an OWL-ontology including properties and

individuals. The creation of the polygon is based on

a coordinate system with one half-axis for each

attribute (i.e. property or individual) of the object.

Furthermore, we use string similarity to determine

the value that is used for representing the attribute

on the corresponding half-axis. Connecting the

values on the different axis with values on the

adjacent axis creates the polygon representing the

object.

3.1 Example Ontologies

We will use two simple ontologies about “match” in

order to illustrate our approach (see Figure 1 and

Figure 2).

In the ontology_1 (see Figure 1), object “match”

has two object properties: “team” (related to

“Idrott_förening” which has four subclasses:

EgnahemsBK, HusqvarnaFF, Bankerydbasket and

Sandabasket) and “plats” (related to “Rosenlunds”),

WEBIST 2007 - International Conference on Web Information Systems and Technologies

392

Table 1: String distance in the ontologies (a).

one datatype property “tid” which is string, and two

subclasses: “Fotbollsmatch” and

“Basketbollsmatch”. In the ontology_2 (see Figure

2), object “match” has two object properties:

“ha_team” (related to “förening” which has four

subclasses: Egnahems_BK, Husqvarna_FF,

Bankeryd_basket and Sandabasket) and “ha_plats”

(related to “Rosenlunds_IP”), one datatype property

“ha_tid” which is date, and two subclasses:

“Fotboll_match” and “Basketboll_match”.

3.2 String Similarity Calculation

Cohen mentions that SoftTFIDF distance metrics

shows the best result in experiments (Cohen, 2003).

Similarity Ontology_1 Ontology_2

0.97 Rosenlunds RosenlundsIP

0.71 Idrott_förening förening

0.71 tid ha_tid

0.71 team ha_team

0.71 plats ha_plats

0.64 Fotbollsmatch fotboll_match

0.65 Basketbollsmatch basketboll_match

We choose Jaro-WinklerTFIDF string-distance

technique, which is based on SoftTFIDF and

extended to use "soft" token-matching with the Jaro-

Winkler distance metric.

After calculating Jaro-WinklerTFIDF string-

distance using SecondString (SecondString) tool, we

get the results shown in Table 1 and Table 2 for the

example ontologies presented in section 3.1.

Table 2: String distance in the ontologies (b).

3.3 Rules for Mapping Ontologies to

Polygons

We are using the following rules to map an object,

i.e. an OWL class with properties and individuals, to

polygons:

1. Choose the standard ontology. In our

example, we will take Ontology_1 as standard

ontology. All the attributes of an object of the

standard ontology, i.e. class properties and

individuals, are marked as 1 unit when creating

the polygon. In the following, the string

distances are mapped to polygons as unit.

2. Calculate string similarity between all

attributes of an object in the standard

ontology and the other ontology. For our

example ontologies, the result of this calculation

is presented in Table 1 and Table 2.

3. Use axes to present the objects’ attributes.

Every axis can only add two object

attributes. The points are added clockwise.

For example, from the Table 1 we know that

“Rosenlunds” in ontology_1 is corresponding to

“RosenlundsIP” in ontology_2. Y axis is used to

present “Rosenlunds” with value 1 and

“Idrott_förening” with value -1 (see Figure 3).

Furthermore, Y axis is used to present

“RosenlundsIP” with value 0.97 (see Table 1)

and “förening” with value -0.71 (see Table1 and

Figure 5).

4. If a new axis is added, it halves the old axes.

For example, X axis is added by halving Y. Z

axis is added by halving X and Y axes (see

Figure 3 and 5).

5. Skip mapping attributes on polygon which

has no similarity. For example, since there is

Similarity Ontology_1 Ontology_2

1.0 Sandabasket Sandabasket

0.68 EgnahemsBK Egnahems_BK

0.68 HusqvarnaFF Husqvarna_FF

0.64 Bankerydsbasket Bankeryd_basket

Figure 1: Ontology_1 relationship.

Figure 2: Ontology_2 relationship.

TOWARDS POLYGON-BASED SIMILARITY AGGREGATION IN ONTOLOGY MATCHING

393

Figure 3: Ontology_1's polygon (a).

Figure 4: Ontology_1's polygon (b).

no string similarity between “string” and “date”,

they are not appearing in Figure 3 and Figure 5.

This kind of skipping nodes will cause

problems. For example, if two ontologies have

many attributes but just three or four attributes

have 100% perfect match, the similarity

between these two ontologies will be 1 if we

just skip attributes which have no similarity.

6. If the objects’ attribute has sub-attributes,

introduce a new polygon based on currently

axis (currently value divided by 2). For

example, if we compare the “match” between

two ontologies, “Idrott_förening” and

“förening” have subclasses. In ontology_1,

“Sandabasket” is mapped to Y axis with value:

1 / 2 * 1= 0.5. Following the above rules 1, 2, 3,

4 and 5, we can get Figure 4. In the same way,

in ontology_2, “Sandabasket” is mapped to Y

axis with value: 0.71 / 2 * 1= 0.355 (Note: 0 .71

is the string distance between “Idrott_förening”

and “förening” (see Figure 5 and table 1); 1 is

the string distance between “Sandabasket” and

“Sandabasket”.) This way we can also get

Figure 6.

-1 -0.8 -0.6 -0.4 -0. 2 0 0.2 0.4 0.6 0.8 1

-1

-0.8

-0.6

-0.4

-0.2

0.2

0.4

0.6

0.8

Area = 2.6213

Rosenlund s

tid

Idrott-förening

team

plats

fotbollsmatchbaske tbollsmatc h

-0. 5 -0.4 -0 .3 -0.2 -0.1 0 0.1 0.2 0.3 0.4 0.5

-0.5

-0.4

-0.3

-0.2

-0.1

0.1

0.2

0.3

0.4

0.5

Area = 0.5

Sandabasket

Eg nahe ms BK

HusqvarnaFF

Bankerydsbasket

3.4 Calculation of Ontologies’

Similarity

In order to determine the similarity of the two

ontologies, we calculate the polygons’ areas which

were done using Matlab:

The area of polygon (a) for ontology_1 is 2.6213

(see Figure 3). The area of polygon (b) for

ontology_1 is 0.5 (see Figure 4).

The area of polygon (a) for ontology_2 is 1.4386

(see Figure 5). The area of polygon (b) for

ontology_2 is 0.13974 (see Figure 6).

We propose to calculate the area similarity by

dividing the sum of the areas of all polygons related

to ontology_1 by the sum of the areas of all

polygons related to ontology_1.

Thus, the area similarity between ontology_1

and ontology_2 is:

(1)

(1.4386 + 0.13974) / (2.6213 + 0.5) = 0.5057

(2)

Since the area calculation is based on an area, i.e

a two dimensional geometric figure, we should

transform it to an expression reflecting just one

dimension. The similarity between ontology_1 and

ontology_2 then would be:

(3)

In order to compare our approach with other

approaches, we can for example calculate the

similarity using mean values of the string distances

or multiplying the string distances. This leads to the

following result:

Another way would be to calculate the similarity

by multiplying the string distances:

0.97 * 0.71 * 0.71 * 0.71 * 0.71 * 0.64 *

0.65 *1.0 * 0.68 * 0.68 *0.64 = 0.0303

(5)

(0.97 + 0.71 + 0.71 + 0.71 + 0

.71 + 0.64 +

0.65 +1.0 + 0.68 + 0.68 +0.64) / 11 = 0.7364

(4)

-1 -0.8 -0. 6 -0.4 -0.2 0 0.2 0. 4 0. 6 0.8 1

-1

-0. 8

-0. 6

-0. 4

-0. 2

0.2

0.4

0.6

0.8

Area = 1.4386

RosenlundsIP

ha-tid

fö reni ng

ha- tea m

ha-plats

fotboll-matchbasketboll-match

Figure 5: Ontology_2's polygon (a).

Figure 6: Ontology_2's polygon (b).

7111.05057.0 =

∑

area

baSimOnto

),(

-0.5 -0.4 -0. 3 -0.2 -0 .1 0 0.1 0.2 0.3 0. 4 0.5

-0.5

-0.4

-0.3

-0.2

-0.1

0.1

0.2

0.3

0.4

0.5

Area = 0.13974

Sanda basket

Egnahems-BK

Husqvarna-FF

Bankeryd-basket

WEBIST 2007 - International Conference on Web Information Systems and Technologies

394

We can see that the area result in this example is

between the mean value and the multiplication

value. Using mean value removes the high and low

values’ effect. Using multiplication zooms out the

low values’ effect. This is the reason we are

proposing to use the area value.

4 SUMMARY AND FUTURE

WORK

This paper presented a new approach for calculating

similarity between objects and their different

attributes based on polygons. The approach

presented is still under development, i.e. the paper

presents work in progress. Currently, a number of

advantage and several shortcomings can be

identified. Since objects can have many attributes,

we consider polygons as suitable to represent these

attributes.

 It is relatively easy to add or remove attributes

in the polygon.

 It is a natural way to estimate object similarity

by using shapes.

 It is easy to calculate similarity between

polygons.

From the simple example presented in chapter 3

we can conclude that polygons are suitable for

representing values derived from objects’ attributes

in an integrated manner. But there are still some

problems which need to be solved in future work:

 The effect of the current approach of skipping

nodes in the polygon with no similarity has to

be investigated (see section 3.3). How to deal

with this problem and improve the approach?

 How to add weights to the polygons reflecting

the importance of attributes?

 How to combine our approach with other

ontology matching methods, like synonyms,

instance matching, structure matching, etc.

 Effects of choosing the standard ontology have

to be investigated including use of the

approach for more than two ontologies.

 Use of an alternative method to calculate

polygon similarity instead of area. Currently,

polygons with the same area have maximal

similarity, even if they in reality are not

identical.

 Comparison of string distance methods (e.g.

Levenstein distance, Jaccard similarity…), to

find the best string distance method for the

polygon similarity.

The above problems will be investigated in

future work. Furthermore, we plan to implement our

polygon similarity approach and evaluate it in

experiments. This will contribute important findings

regarding the users’ perception of accuracy of

similarity calculation with our approach.

ACKNOWLEDGEMENTS

Part of this work was financed by the Hamrin

Foundation (Hamrin Stiftelsen), project Media

Information Logistics.

REFERENCES

Bach T.L., Dieng-kuntz R., Gandon F., 2004 Ontology

Matching: A Machine Learning Approach for building

a corporate semantic web in a multi-communities

organization. In Proc. OFICEIS 2004, Porto (PT).

Chimaera. http://www.ksl.stanford.edu/software/chimaera/

Cohen W. W., Ravikumar P., and S. E. Fienberg, 2003 A

comparison of string distance metrics for name-

matching tasks. In Proceedings of the IJCAI-2003.

http://citeseer.ist.psu.edu/cohen03comparison.html

Doan, A., Madhavan, J., Domingos, P., Halevy, A., 2002.

Learning to map between ontologies on the semantic

web. In: The Eleventh International WWW

Conference. Hawaii, US.

Euzenat J., Valtchev P., 2004. Similarity-based ontology

alignment in OWL-lite, In Proc. 15th ECAI, pp 333–

337, Valencia (ES).

Foam http://www.aifb.uni-karlsruhe.de/WBS/meh/foam/

Keet M., 2004. Aspects of Ontology Integration.

(Unpublished, available at:

http://www.dcs.napier.ac.uk/~cs203/AspectsOntologyI

ntegration.pdf)

Noy N., Musen, M., 2003. The PROMPT suite:Interactive

tools for ontology merging and mapping. Technical

report, SMI, Stanford University, CA, USA,

http://citeseer.ist.psu.edu/noy03prompt.html

Noy N.F., Musen M.A., 2002. Evaluating Ontology-

Mapping Tools: Requirements and Experience. In:

Workshop on Evaluation of Ontology Tools at

EKAW'02 (EON2002).

Owl. http://www.w3.org/TR/owl-features/

Protégé. http://protege.stanford.edu/

Melnik S., Molina-Garcia H., and Rahm E., 2002.

Similarity Flooding: A Versatile Graph Matching

Algorithm. In Proceedings of the International

Conference on Data Engineering (ICDE).

SecondString. http://secondstring.sourceforge.net/

Stumme, G., Madche, A., 2001. FCA-Merge: Bottom-up

merging of ontologies. In: 7th Intl. Conf.on Artificial

Intelligence (IJCAI ’01). Seattle, WA, pp. 225–230.

WordNet. http://wordnet.princeton.edu

TOWARDS POLYGON-BASED SIMILARITY AGGREGATION IN ONTOLOGY MATCHING

395
