An Efﬁcient and Simple Way to Test the Security of

Java Cards

TM⋆

Serge Chaumette and Damien Sauveron

⋆⋆,⋆ ⋆ ⋆

LaBRI, Laboratoire Bordelais de Recherche en Informatique

UMR 5800 – Universite Bordeaux 1

351 cours de la Liberation, 33405 Talence CEDEX, FRANCE.

Abstract. Till recently it was impossible to have more than one single applica-

tion running on a smart card. Multiapplication cards, and especially Java Cards,

now make it possible to have several applications sharing the same physical piece

of plastic. Today, these cards accept to load code only after an authentication.

But in the future, the cards will be open an everybody should be authorized to

upload an application. This raises new security problems by creating additional

ways to attack Java Cards. These problems and the method to test them are the

topic of this paper. The attacks will be illustrated with code samples. The method

presented here can be applied right now by authorised people (e.g. Information

Technology Evaluation Facility – ITSEF) to test the security of Java Cards since

they have the authentication keys and tomorrow a hacker may also be able to use

this method to attack cards without needing the keys.

1 Introduction

Java Cards [1,2] are multiapplication smart cards proposed by Sun microsystems based

on the Java technology. The main feature of this standard makes it possible to gather on

a unique medium a set of services, called applets, that can cooperate with each other.

Even if it is not currently possible to freely load an applet on the actual Java Cards

without being authenticated, the next generation should allow it. Although these cards

will embed a veriﬁer to protect them against malicious code loading, they raise new

security problems.

The aim of this paper is to describe a method to test the security of the actual Java

Cards and to present the new threats that arise when dealing with open Java Cards. First

we will present the common way to explore and attack classical Java Cards and then we

will precisely explain what is an open Java Card. In section 4 we will show the well-

known attacks against these new cards. Then in the context of the open Java Cards we

⋆

Java and all Java-based marks are trademarks or registered trademarks of Sun microsystems,

Inc. in the United States and other countries. The authors are independent of Sun microsys-

tems, Inc.

⋆⋆

LaBRI (Talence, FRANCE) and LMSI (Limoges, FRANCE).

⋆ ⋆ ⋆

This work was partly supported by a doctoral grant from the french ministry of research and

SERMA Technologies.

Chaumette S. and Sauveron D. (2005).

An Efﬁcient and Simple Way to Test the Security of Java CardsTM.

In Proceedings of the 3rd International Workshop on Security in Information Systems, pages 331-342

DOI: 10.5220/0002574803310342

 SciTePress

will expose in section 5 a characterization method using glitches on I/Os and we will

investigate in section 6 how it is possible to use it in order to quickly and efﬁciently

achieve physical attacks on these cards. Finally we will present our experiments and we

will conclude.

2 Exploring and attacking closed Java Cards

A Java Card is able to embed several applets that do not run simultaneously because the

OS has a single thread. Its architecture (cf. Fig. 1) consists of:

– an embedded virtual and homogeneous Operating System that supports the loading

and the execution of several applets. The OS is a runtime environment (Java Card

Runtime Environment – JCRE) with a virtual machine (VM) that provides security

features (e.g. a ﬁrewall between applets and the system).

– the applets that are interpreted by the VM.

Hardware and native Operating System

JCRE

Applet A Applet B

Java Card APIs

Java Card Virtual Machine

(bytecodes interpreter)

Fig.1. Architecture of a Java Card.

Even though the ways to explore a closed Jard Card (i.e. a Java Card that allows ap-

plets to be uploaded after it has been issued only if the authentiﬁcation was successful)

before trying to attack it are reduced, there are at least two possibilities that remain:

– Software approach. Since an end user cannot load code on a closed Java Card he

can only access its external interfaces. More precisely, the only external interface

visible on a card is the communication layer. One of the possibilities to set up an

attack at the level of the communication layer is to send all the possible APDU

commands [3,4] to the Java Card in order to identify all the services that it makes

available to the outside.

– Hardware approach. Based on the results obtained by Kocher, the main path of at-

tack to explore a card without damaging it, is to observe side channels [5] such

as the physical emanations from the chip or the time consumptions [6]. The meth-

ods that use power analysis (PA) [7,8] or electromagnetic analysis (EMA) [9,10]

make it possible to identify patterns corresponding to the operations achieved by

the card. These attacks are carried out as a blind man, or a semi-blind man if the

speciﬁcations of the card operations are known.

Smart cards are also prone to many other invasive (microprobing, etc.) and non-

invasive (glitch on the different pads of the card, etc.) attacks [11,12,13,14] which

are out of the scope of this paper.

The APDU (Application Protocol Data Unit) is the communication unit between a reader and

a card at the application level.

332

But, if the user owns the authentication keys, he will be able to load his code and he

can apply the characterization method described in section 5 to set up attacks as shown

in section 6. He can also use the internal attacks presented in section 4. We consider

that this method to test the security is mainly intended to be used by the ITSEF or by

card manufacturers.

3 The open Java Cards

Till now the Java Card technology has not completely been proven secure by formal

methods and consequently it is not safe to run uncertiﬁed applets that may be pro-

vided by a hacker to attack the assets of the platform and those of the other applets. To

prevent these problems, the Java Card issuers began to support standards such as Glob-

alPlatform [15] which speciﬁes how to securely load, install and manage applets on a

card. Indeed this standard is used to easily set up and use cryptographic mechanisms

to authorize or prevent the loading of an applet on the card. For example the applet

can be digitally signed off-card by a trusted party (e.g. the card issuer). Once loaded

the card can check the signature and accept or reject the applet. But the major draw-

back of this solution is its centralized model because of the trusted third party required

to sign the applet; it thus decreases ﬂexibility. Therefore, on-card veriﬁers have been

proposed [16,17,18,19,20,21,22] although Java Card designers ﬁrst thought it was im-

possible to embed a veriﬁer because of the resource constraints of smart cards. Among

the different solutions that have been proposed, three of them (i.e. the defensive VM,

the veriﬁer based on code transformation and the stand-alone veriﬁer) allow to with-

draw the signature step of the applet without jeopardizing the card security and thus

allow everybody to freely load his/her own applet – i.e. anyone can still load a rogue

applet but it will eventually be rejected by the veriﬁer or blocked by the defensive VM.

Note that the veriﬁer based on code transformation [18,19] requires an off-card pro-

gram to normalize the applet whereas the two others (i.e. the defensive VM [20] and

the stand-alone veriﬁer [22]) are stand-alone. We only consider as open Java Cards the

Java Cards based on one of these two stand-alone solutions. Both are equivalent [21]

but the defensive VM dynamically checks each executed bytecode whereas the stand-

alone veriﬁer statically checks the applet once at load time and it is associated with an

offensive VM that does not check the bytecode at execution time. Even if these open

Java Cards are not yet available on the market they most probably are the future of Java

Cards.

4 Internal attacks

Obviously one of the main problems of the open Java Cards is the possibility to create

internal attacks since it is possible to load a malicious applet. Such an applet may:

– identify services present on the card and then try to deduce the possible behavior

of an ofﬁcial

applet (since it can only use services available on the card!). For

an applet installed by some trustworthy organization, e.g. a banking applet.

333

example an applet can try to use all the cryptographic services deﬁned in the Java

Card speciﬁcations [2] in order to work out if they are present on the card or not.

– collect information on the card to elaborate hardware and software attacks. For

example, an applet can be loaded to gather information about the applets already

installed on the card.

– attack the VM and the ﬁrewall. For example two attacks against the ﬁrewall mech-

anism (AID impersonation and illegal reference casting that provides access to all

interface methods of a class) are described in [23] and attacks against the VM based

on type confusion are shown in [24]. There also exist attacks coming from problems

in the speciﬁcations such as those presented in [25].

5 Characterization method

Once the available services have been identiﬁed, an interesting possibility consists in

observing their signature. The main physical signals that can be observed are issued

from the side channels such as the power consumption, the electromagnetic emissions

or the execution time consumption. For instance we can use a cryptographic service

and determine the characteristics of the physical signals emitted during the execution

of this service (e.g. duration, location of the best electromagnetic emissions, power

consumption, etc.). This characterization can be targeted to the use of a whole service

or to an elementary operation, e.g. the interpretation of a single bytecode or a sequence

of bytecodes.

In this section we present an efﬁcient and simple way to to determine the signature

of services on open Java Cards using glitches on the I/O channel of the card. This

method consists in surrounding the pattern to observe with events that are visible for

an observer outside the smart card. Fig. 2 shows the trace of a normal execution of an

applet that includes a pattern to observe. Obviously it is difﬁcult to isolate this pattern

from all those composing the trace.

Hardware

Application

the command APDU

Arrival of

Layers

Time

ISO7816 interface

Pattern to observe

the response APDU

Departure of

Fig.2. Trace of a normal execution in the layers.

The only event visible to an external observer that the card can produce is the emis-

sion of bytes on the communication channel. If the execution is glitched using this

event, it is easier to ﬁnd the pattern in the trace (cf. Fig. 3). The code inserted to trigger

the glitches causes an overhead and thus the pattern to observe does not appear at the

exact same instant in the ﬁrst trace and in the second trace.

Another advantage of this approach is that the trace to save is shorter (because the

area to observe is smaller) and thus it is possible to get a better sampling of the signal,

still producing the same amount of data.

334

Hardware

Application

Pattern to observe

Bytes of

synchronization

the command APDU

Arrival of

Layers

Time

ISO7816 interface

the response APDU

Departure of

Fig.3. Trace of a glitched execution in the layers.

5.1 Using the time extension request

The ISO 7816-3 standard [3] deﬁnes a special mechanism that allows a smart card to

request a time extension to the reader i.e. let it know that it should wait a bit more be-

fore receiving a result (to prevent a timeout). This mechanism depends on the transport

protocol (e.g. T=0 or T=1) and allows the reader to know that the smart card is not mute

and still works. For instance for the T=0 protocol this mechanism consists in sending

the NULL procedure byte (i.e. the byte 0x60) to the reader. In Java Card the method

invoked to use this mechanism is apdu.waitExtension(). Listing 1.1 shows an

example using the waitExtension() glitches to surround an encryption.

Listing 1.1. Encryption surrounded by waitExtension() glitches

apdu ) { . . .

/ / Request a time extension that puts data on the I/O (glitch 1).

apdu . w ai tE xt en si on ( ) ;

cipherLength = cipher . doFinal(clearData, ( short) 0 ,

clearData.length,

cipherData , ( short ) 0 ) ;

/ / Request again a time extension (glitch 2).

apdu . w ai tE xt en si on ( ) ;

. . .

}

In recent implementations of many manufacturers the waitExtension()method

is deactivated at user level. The necessary time extension requests are automatically

managed by the platform.

5.2 Using the standard card communication method

The second solution uses the standard card communication method. It is possible to use

it to generate an event used as a glitch by sending the card response in several pieces.

Normally the communication model from the smart card to the host consists in sending

all the data of the response at once. We propose to send a pseudo response in two

times, the ﬁrst piece being sent before the pattern to observe and the second piece being

sent after. Listing 1.2 shows an example using response based glitches to surround an

encryption.

This method was successfully tested on many Java Cards and it should work on

any card supporting ISO7816-3–4. People often think that it does not work because

they reason at APDU level and they think that the emissions (e.g. sendBytes(...))

are batched. But APDUs (i.e. ISO7816-4 [4]) are achieved by a sequence of TPDU

The TPDU (Transmission Protocol Data Unit) is the communication unit between a reader and

a card at the transmission level

335

Listing 1.2. Encryption surrounded by data glitches

public void process(APDU apdu) {

byte [ ] buffer = apdu. getBuffer( ) ;

. . .

buffer[ 0] = ( byte)0xFF;

apdu.setOutgoing( ) ;

apdu.setOutgoingLength( (short ) 2 ) ;

/ / Send the synchro ... means the beginning of the process (glitch 1)

apdu . sendB ytes ( ( s ho rt ) 0 , ( s hor t ) 1 ) ;

cipherLength = cipher . doFinal(clearData, ( short) 0 ,

(short ) clearData. length,

cipherData , ( short ) 0 ) ;

/ / Send the synchro ... means the end of the process (glitch 2)

apdu . sendB ytes ( ( s ho rt ) 0 , ( s ho rt ) 1 ) ;

. . .

}

exchanges (i.e. ISO7816-3). Besides this can be confused due to APDU class in Java

Card is not really an APDU representation and is only an APDU emulation (e.g. with

T=0 cards the mandatory call to getBuffer() sends a TPDU response to the reader

in order to inform it can send the TPDU with the data ﬁeld of the APDU to the card).

5.3 Possible improvements

Using the above method, it is possible to target a big pattern but sometimes we wish

to enhance the precision of the target. Let us consider an example. The sequence of

bytecodes of listing 1.3 corresponds to the result of the compilation and conversion of

the three last lines of listing 1.2.

Listing 1.3. Generated bytecodes for the encryption invocation surrounded by glitches

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 x6 / / g l itch 1 ( r eal g l i tch )

getfield_a_this 0x0

getfield_a_this 0x1

sconst_0

getfield_a_this 0x1

arraylength

getfield_a_this 0x2

sconst_0

invokevirtual 0x0 0xa / / pattern to observe (real encryption)

sstore_2

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 x6 / / g l itch 2 ( r eal g l i tch )

It makes it clear that it is possible by working at the bytecode level to improve the

precision of the observation. The sequence of bytecodes presented in listing 1.3 can be

modiﬁed as shown listing 1.4 and still have the same global behavior but with a better

accuracy regarding the surrounding of the encryption by the glitches (cf. the Appendix).

This improvement is also possible when using the waitExtension() method

when the platform makes it available.

One of the problems when working at the bytecode level is that a minor modiﬁca-

tion in the CAP

ﬁle implies to change many other parts. For instance changes in the

The standard binary ﬁle format of the Java Card platform.

336

Listing 1.4. Improved pattern surrounding

aloa d_1

sc on st _0

sc on st _1

getfield_a_this 0x0

getfield_a_this 0x1

sconst_0

getfield_a_this 0x1

arraylength

getfield_a_this 0x2

sconst_0

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 x6 / / g l itch 1 ( r eal g l i tch )

invokevirtual 0x0 0xa / / pattern to observe (real encryption)

sstore_2

i nvo ke vi rt ua l 0x0 0 x6 / / g l itch 2 ( r eal g l i tch )

array of bytecodes of the Method component of the CAP ﬁle often implies to modify

the information related to the maximum size of the stack and the maximum number of

local variables of the frame of the modiﬁed method. The ReferenceLocation compo-

nent and its size should also often be modiﬁed. These modiﬁcations furthermore imply

modiﬁcations of the Directory component. To simplify these operations, we have devel-

oped a tool provided with the JCatools suite [26,27] to modify the Method component

of a CAP ﬁle. The JCatools suite was developed during the Java Card Security project

between the LaBRI and the ITSEF of SERMA Technologies. This suite of tools mainly

consists in a Java Card Emulator and additional facilities. More information is available

in the Appendix.

Note that if the manufacturers ﬁnd countermeasures against this method, it will still

be possible to locate the pattern by surrounding it with something that induces high

power consumption (a cryptographic operation, etc.) to still produce an event visible

from the outside.

6 Quickly evaluating the feasibility of an attack

Based on the characterization method presented above it is possible to quickly evaluate

the feasibility of an attack against an ofﬁcial applet since a hacker can possibly set up

physical attacks [12,13,14] on the pattern identiﬁed in her own applet. Indeed she is in

the best experimental position to easily and quickly attack a card implementation (e.g.

to try to bypass the access conditions or perturb a cryptographic algorithm) avoiding

to perform many useless tests and saving a lot of time. If her attacks succeed then she

can attack the ofﬁcial applet or the platform. For instance if she knows a way to attack

cryptographic algorithm that the ofﬁcial applet uses, she can try to set up the attack

against this algorithm by calling it from her own applet and surrounding it by glitches

to quickly test its implementation security. It is also possible to add a glitch just before

accessing data of another applet so as to synchronize a physical attack to bypass the

checks of the ﬁrewall thanks to the disturbance of the hardware component.

337

7 Experiments

The method presented in this paper and some improved versions are used by the ITSEF

of SERMA Technologies to test Java Card platforms, applets and their service for in-

stance for a Common Criteria evaluation [28]. Attacks described in the previous section

were already successfully used during real evaluations. The technical details of their

implementation and the results are conﬁdential but the main principles are published

in this paper. Most of the time they are used with the theoretical assumption that the

attacker could load her applet (the Java Cards that are evaluated are not yet open). Ob-

viously this assumption is taken into account in the quotation of the attacks to know if

they exceed the desired evaluation assurance level.

8 Conclusion and future work

This paper describes a way to quickly test the security of the next generation of Java

Cards. The majority of the problems and attacks presented in this paper (i.e. sections 5

and 6) were unpublished till now and we hope that sharing our experience with others

interested in the area will help to secure the future open Java Cards. Even if the problems

raised may seem obvious, we have already used them successfully during a real product

evaluation to quickly set up attacks.

Appendix: Methodology to modify a CAP ﬁle

In this appendix we show in details the method used to set up trace based identiﬁcation

of operations by working at the bytecode level.

– First, write a code that uses the pattern to observe or a dummy Java code that will

be replaced by the pattern to observe. In this last case the dummy sequence should

generate a large enough sequence of bytecodes so that it can be replaced by the

pattern to observe. For instance to observe the bytecode sxor, write the Java code

of listing 1.5.

Listing 1.5. Dummy code

. . .

apdu.setOutgoing( ) ;

apdu.setOutgoingLength( (short ) 2 ) ;

apdu . sendB ytes ( ( s ho rt ) 0 , ( s hor t ) 1 ) ; / / g l i t ch 1

/ / Here introduce the interesting pattern to observe

short s = ( short) 0 ; / / Dummy

s ^ = ( short ) 1 ; / / Dummy

apdu . sendB ytes ( ( s ho rt ) 0 , ( s hor t ) 1 ) ; / / g l i t ch 2

. . .

– Compile and convert it to produce a CAP formated ﬁle. Then use the parseCom-

ponent tool of the JCatools suite to get the methods of the CAP ﬁle in a human

readable format. The interesting part including the dummy code of the ﬁle obtained

by parseComponent is detailed listing 1.6.

338

Listing 1.6. Bytecodes generated from the dummy code

. . .

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 xc / / g l i tch 1

sconst_0 / /

sstore_3 / / The

sload_3 / / generated

sconst_1 / / dummy

sxor / / bytecodes

sstore_3 / /

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 xc / / g l i tch 2

. . .

– Modify the generated bytecode sequence so as to improve the position of the glitches

or to replace the dummy sequence by the proper bytecodes. Listing 1.7 shows how

we update the listing 1.6 to set the sxor pattern surrounded by glitches with the

best accuracy.

– Modify the maximum size of the stack and the maximum number of local variables.

– Use the methodRewriter tool available in the JCatools suite to rewrite the Method

component of the CAP ﬁle. It also modiﬁes the ReferenceLocation component and

if needed the Directory component.

Listing 1.7. Pattern to observe surrounded by glitches

. . .

nop / / The nop bytecodes do nothing

nop / / and we use them to reach the same

nop / / size for the bytecodes array as

nop / / previously to simplify the modiﬁcation process.

aloa d_1

sc on st _0

sconst_0 / / TIP: the result of the sxor

sconst_1 / / will be the third argument

aloa d_1

sc on st _0

sc on st _1

i nvo ke vi rt ua l 0x0 0 xc / / g l i tch 1

sxor / / pattern to observe

i nvo ke vi rt ua l 0x0 0 xc / / g l i tch 2

. . .

The resulting CAP ﬁle is still valid for the veriﬁer and the defensive VM and can be

uploaded to a Java Card.

Listing 1.7 shows that in some cases it is possible to isolate a single bytecode. It

uses a tip to avoid the addition of a bytecode (e.g. pop, sstore, etc.) just after sxor

that would remove the short value resulting of the sxor operation from the stack.

References

1. Chen, Z.: Java Card

Technology for Smart Cards: Architecture and Programmer’s Guide.

Addison-Wesley (2000)

2. Sun microsystems: Java Card

2.2.1 Speciﬁcations. Sun microsystems (2003)

3. International Organization for Standardization: Information technology – Identiﬁcation cards

– Integrated circuit(s) cards with contacts – Part 3: Electronic signals and transmission pro-

tocols. (ISO)

339

4. International Organization for Standardization: Information technology – Identiﬁcation cards

– Integrated circuit(s) cards with contacts – Part 4: Interindustry comands for interchange.

(ISO)

5. Muir, J.A.: Techniques of Side Channel Cryptanalysis. Master’s thesis, University of Water-

loo, Ontario, Canada (2001) Master of Mathematics in Combinatorics and Optimization.

6. Kocher, P.: Timing attacks on implementations of difﬁe-hellman, rsa, dss, and other systems.

In: Proceedings of the 16th Annual International Cryptology Conference on Advances in

Cryptology, Springer-Verlag (1996) 104–113

7. Kocher, P., Jaffe, J., Jun, B.: Differential Power Analysis. In: Proceedings of the 19th

Annual International Cryptology Conference on Advances in Cryptology, Springer-Verlag

(1999) 388–397

8. Coron, J.S., Kocher, P., Naccache, D.: Statistics and Secret Leakage. In: Proceedings of

Financial Cryptography (FC2000). Volume 1962 of Lecture Notes in Computer Science.,

Springer-Verlag (2001) 157–173

9. Quisquater, J.J., Samyde, D.: ElectroMagnetic Analysis (EMA): Measures and Countermea-

sures for Smart Cards. In: Proceedings of E-smart 2001. Volume 2140 of Lecture Notes in

Computer Science., Springer-Verlag (2001) 200–210

10. Gandol, K., Mourtel, C., Olivier, F.: ElectroMagnetic Analysis: Concrete Results. In: Pro-

ceedings of CHES’2001. Volume 2162 of Lecture Notes in Computer Science., Springer-

Verlag (2001) 251–261

11. Kömmerling, O., Kuhn, M.G.: Design Principles for Tamper-Resistant Smartcard Proces-

sors. In: Proceedings of the USENIX Workshop on Smartcard Technology (Smartcard ’99),

Chicago, Illinois, USA (1999) 9–20

12. Bar-El, H., Choukri, H., Naccache, D., Tunstall, M., Whelan, C.: The Sorcerer’s Apprentice

Guide to Fault Attacks. In: Proceedings of Workshop on Fault Detection and Tolerance in

Cryptography, Italy (2004)

13. Giraud, C., Thiebeauld, H.: A survey on fault attacks. In: Proceedings of CARDIS’04,

Smart Card Research and Advanced Applications VI, Toulouse, France, Kluwer academic

publisher (2004) 159–176

14. Skorobogatov, S., Anderson, R.: Optical Fault Induction Attacks. In: Proceedings of Work-

shop on Cryptographic Hardware and Embedded Systmes (CHES 2002), San Francisco Bay

(Redwood City), USA (2002)

15. GlobalPlatform: GlobalPlatform. (http://www.globalplatform.org/)

16. Rose, E., Rose, K.: Lightweight bytecode veriﬁcation. In: In Workshop on Fundamental

Underpinnings of Java, OOPSLA ’98 Workshop., Vancouver, Canada (1998)

17. Casset, L., Burdy, L., Requet, A.: Formal Development of an embedded veriﬁer for Java Card

Byte Code. In: Proceedings of the IEEE International Conference on Dependable Systems

& Networks, Washington, D.C., USA (2002)

18. Leroy, X.: On-Card Bytecode Veriﬁcation for Java Card. In: Proceedings of the International

Conference on Research in Smart Cards, E-Smart 2001, Springer-Verlag (2001) 150–164

19. Leroy, X.: Bytecode veriﬁcation on Java smart cards. Software-Practice & Experience 32

(2002) 319–340

20. Cohen, R.M.: Defensive Java Virtual Machine Version 0.5 alpha. (1997)

21. Barthe, G., Dufay, G., Jakubiec, L., Melo de Sousa, S.: A Formal Correspondence between

Offensive and Defensive JavaCard Virtual Machines. In: Proceedings of VMCAI’02. Volume

2294 of Lecture Notes in Computer Science., Venice, Italy, Springer-Verlag (2002) 32–45

22. Deville, D., Grimaud, G.: Building an “impossible” veriﬁer on a Java Card. In: 2

USENIX

Workshop on Industrial Experiences with Systems Software, Boston, USA (2002)

23. Montgomery, M., Krishna, K.: Secure Object Sharing in Java Card. In: Proceedings of

the USENIX Workshop on Smartcard Technology (Smartcard ’99), Chicago, Illinois, USA

(1999)

340

24. Witteman, M.: Java card security. Information Security Bulletin 8 (2003) 291–298

25. Betarte, G., Giménez, E., Chetali, B., Loiseaux, C.: FORMAVIE: Formal Modelling and

Veriﬁcation of Java Card 2.1.1 Security Architecture. In: Proceedings of E-Smart 2002,

Nice, France (2002) 215–229

26. Chaumette, S., Hatchondo, I., Sauveron, D.: JCAT: An environment for attack and test on

Java Card. In: Proceedings of CCCT’03 and 9th ISAS’03. Volume 1., Orlando, FL, USA

(2003) 270–275

27. Hatchondo, I., Sauveron, D.: The JCatools website.

(http://sourceforge.net/projects/jcatools/)

28. CCIMB: International Common Criteria home page.

(http://www.commoncriteriaportal.org/)

341

342
