A METHODOLOGY FOR INTELLIGENT E-MAIL

MANAGEMENT

Francisco P. Romero,

Soluziona Software Factory, R+D Center Soluziona-UCLM, Ronda de Toledo, s/n, 13071 Ciudad Real, SPAIN

Jose A. Olivas

Dep. Of Computer Science, University of Castilla La Mancha,Paseo de la Universidad 4, 13071 Ciudad Real, SPAIN

Pablo Garcés

Dep. Of Computer Science. University of Alicante,Carretera San Vicente del Raspeig, s/n, 03080 Alicante, SPAIN

Keywords: e-mail, soft-computing, fuzzy logic, automatic classification, clustering.

Abstract: We present, in the context of the intelligent Information Retrieval, a soft-computing based methodology that

enables the efficient e-mail management. We use fuzzy logic technologies and a data mining process for

automatic classification of large amounts of e-mails in a folder organization. It is also presented a process to

deal with the incoming messages to keep the achieved structure. The aim is to make possible an optimum

exploitation of the information contained in these messages. Therefore, we apply Fuzzy Deformable

Prototypes for the knowledge representation. The effectiveness of the method has been proved by applying

these techniques in an IR system. The documents considered are composed by a set of e-mail messages

produced by some distribution lists with different subjects and languages.

1 INTRODUCTION

Every day e-mail becomes more important as a

method for global communication. The Wordtalk

Corporation (Harrys, 2002), estimates that 60

million professionals use e-mail. According to a

report from technology analysts IDC, on an average

day in 2000, 9.7 billion e-mail messages were sent

worldwide. By the year 2005 that number will grow

to 35 billion.

Along with the increase in messages size and

traffic, c

omes an increase in users’ expectations.

People send e-mail to communicate critical

information across continents and time zones: they

expect their information to get through. E-mail

glitches are high profile events, generating negative

press for the organization, frustrated users, loss of

productivity, and most importantly loss of business.

Every stored message contains information that,

depe

nding on the circumstances, may become

relevant. To make the recovery of the messages

received in the previous weeks, months or years

easier, the mail management programs allow the

organization of them in specific folders well-defined

by the user.

The most common thing for a user is to have

from

ten to a hundred folders hierarchically

organized. Moving a message to its proper folder

involves a considerable effort and a waste of time.

Some commercial programs allow the definition of

simple rules to help in this task, but these rules only

cover a very small percentage of the range of

messages received, generating lots of erroneous

classifications, irrelevant for the user. The task of

managing the information inherent in the messages

of a list with a great amount of daily entries is quite

complex.

This study is concerned with Web mining. This

erm is used to describe three different types of data

mining, namely content mining, usage mining and

P. Romero F., A. Olivas J. and Garcés P. (2005).

A METHODOLOGY FOR INTELLIGENT E-MAIL MANAGEMENT.

In Proceedings of the Seventh International Conference on Enterpr ise Information Systems, pages 11-16

DOI: 10.5220/0002533000110016

 SciTePress

structure mining. The mining of textual data is a

common web mining task, often for the purposes of

information retrieval. This type of mining is

becoming increasingly necessary as finding

information on the Web is almost impossible

without automated assistance.

In this context, the most of the related work are

based on Naive-Bayes classifiers applied to the

documental categorization (Turenne, 2003). Also it

is necessary to mention the classic works of

electronic mail processing (Sahami, 1998),

(Kiritchenko, 2002), or the application of supervised

learning to this problem (Joachims, 1998).

In this study, a methodology based on different

soft-computing techniques (Nikravesh, 2001) to

manage great amounts of e-mails is proposed. The

aim is to solve a specific problem in the control of

the e-mail system: The management of distribution

lists. A distribution list is nothing but a list of users

who are associated in order to exchange information

related to a specific subject by using the e-mail.

The main targets to reach are the following:

– Hierarchical (and fuzzy) organization of a large

amount of messages received (1.500 messages

approx.) based on the concepts they involve.

– Automatic sorting of the incoming mail on the

list from their contents and without the

intervention of the user.

– Navigational or conceptual searching inside the

messages of the distribution list.

To test the effectiveness of the techniques and

make the necessary adjustments, diverse methods

have been used (outliers, similarity degree…).

Studies about distribution list concerning both

technological domains and general and historical

matters have been made. The aim is to show the

different problems present in e-mail management

tasks and the general applicability of the proposed

method.

The rest of this paper is organized as follows. In

Section 2, we present a methodology for fuzzy

hierarchical e-mail classification and we introduce

and explain a method to deal with the incoming

messages to keep the achieved structure. We explain

the experimental results in Section 3 and finally, we

conclude this work in Section 4.

2 A METHODOLOGY OF E-MAIL

MANAGEMENT

The quantity of received messages in the distribution

list is frequently very large. This means that the

organization to be build should be the most efficient

possible to make the later exploitation optimum. The

characteristics of the later results will be the

following:

1. Hierarchical organization of the messages in

folders following the criteria based both on the

“conceptual” content of the message and its

structured fields. The conceptual representation

will allow us to achieve a concept based search.

2. Definition of the folders through relevant

terms/concepts and membership functions.

3. Possibility for a message to get stored in more

than one group, depending on its contents.

4. Every message should have a degree of affinity

(or membership) with each of the groups into

which it is sorted. There should exist the

opportunity to arrange the messages from every

group according to this degree of membership.

5. Basic “matching” mechanism between

documents and folders. It will be used to store an

incoming message in one or more folders

depending on the affinity with the different ones.

The construction process is based on the

following stages: linguistic pre-process, conceptual

representation, message clustering, post-process and

results (Figure 1).

Figure 1: Building the new structure

2.1 Linguistic pre-process

The Linguistic Preprocess consists of the following

tree steps: previous transformation, lexical analysis,

stoplist word removal and stemming, and candidate

keyword detection.

• The Previous Transformation has been

performed in the separation of the structured

fields (subject, sender, etc.) of the contents of

the message. Also we are grouping (“starred” in

gmail tool) the messages according to

conversations, meaning groups of messages

related to the same subject (ignoring Re:, Rv:

and other particles) and uniformly arranged in

sequences.

• The Lexical Analysis is the process of

converting an input stream of characters into a

stream of words or tokens (Frakes, 1992).

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

Lexical analysis tasks are: management of

numbers, punctuation, singulars, special words

and proper nouns. This stage produces

candidate terms that are further checked and

retained if they are not in a stoplist.

• Stoplist Word Removal: Stoplist is a list of

words that are most frequent in a text corpus

and are not discriminative of a message

contents, such as prepositions, pronouns and

conjunctions.

• Stemming: Stemming is the process of suffix

removal to generate word stems. Several

different methods for automatic stemming are

described in (Frakes, 92). One of them, Porter

stemming algorithm, is the most common and it

was used in the system.

• Ranking Candidate KeyWords: a candidate

keyword had to appear in at least three

documents and in no more than the 33% of all

documents. Only the candidate keywords are

useful for the following stages.

2.2 Conceptual Representation

To be able to work with the messages in an abstract

way, securing a logical representation of them is

essential. The vector space model and its extensions

(Pasi, 2002) have been used traditionally. FIS-CRM

(Olivas, 2003) can be considered as an extension of

this traditional model, in charge of the

representation, within the vector attached to the

document, of the concepts inherent in the words

displayed.

Therefore FIS-CRM, is based on two main

points:

a) If a word appears in a document, its synonyms

that represent the same concept underlie it.

b) If a word appears in a document, the words that

represent a more general concept underlie it.

The fundamental basis of FIS-CRM is to “share”

the occurrences of a contained word among the

fuzzy synonyms that represent the same concept,

and to “give” a fuzzy weight to the words that

represent a more general concept that the contained

one. To obtain this aim, documents must be first

represented by their base weight vectors (based on

the occurrences of the contained words) and

afterwards, a weight readjustment process is made to

obtain a new vector (based on concept occurrences).

In this way, a word may have a fuzzy weight in the

new vector even if it is not contained in it, as long as

the referenced concept underlies the document.

To carry out the readjustment, the synonymy and

generality fuzzy interrelations has to be taken into

account, respectively obtained from a fuzzy

dictionary of synonyms (Fernandez-Lanza, 2001)

and an ontological (Kiryakov, 1999) one. The

process to be used in the conceptual representation

of already pre-processed e-mail messages on a

distribution list consists of the following steps:

1) Indexation of all the terms obtained in the pre-

process.

2) Building synonymy and ontology matrices by

storing synonymy and generality degrees from

each pair of words in the index.

3) Representation of the messages using the classic

vector space model.

4) Readjustment of the vector weights using the

FIS-CRM formulae group.

a) The vector readjustment made using the

synonymy interrelation is hindered by the

fact that there are lots of polysemic words

(words with several meanings).

b) The vector readjustment made using the

generality interrelation is linear and

proportional to the generality degree

between term A and term B.

5) Generation of the similarity matrix which will

store the degree of similarity from every pair of

messages in the collection. The matrix will be

the input to the later clustering process.

6) Storage of the essential information as meta-

data to allow the management of later incoming

messages.

2.3 Messages Clustering

Using the clustering process we will achieve the

splitting up of the collection of messages in a

reduced number of groups made up of messages

with enough conceptual similarity. Each group will

contain one or more relevant terms which will make

it different from the rest.

In this work, a hierarchical fuzzy clustering

approach is presented. The clustering procedure is

implemented by two connected and adapted

algorithm. It uses a fuzzy hierarchical clustering

algorithm to determine an initial clustering which is

then refined using the SISC (King-Ip, 2001)

clustering algorithm used in FISS meta-searcher

structure.

This algorithm is characterized by creating an

initial number (automatically calculated) of centroid

clusters, followed by an iterative process that

includes each document in the clusters whose

average similarity is upper than the threshold of

similarity (automatically calculated, but user

specified if wanted). The algorithm also considers

merging clusters and removing documents for

clusters when their average similarity decreases

under the threshold. In order to get a hierarchical

structure, big clusters and the bag cluster (formed by

A METHODOLOGY FOR INTELLIGENT E-MAIL MANAGEMENT

the less similar documents) are reprocessed with the

same method.

The resulting organization is hierarchical, so,

from a large mailbox we will obtain a tree folders

organization. It will also be a fuzzy organization in

which the messages will be located in more than one

group with different degrees of connection to each

one.

2.4 Post-Process and Results

The results obtained in the clustering process should

be completed to give way to a new organization of

folders which carries out the required characteristics.

This process is divided into different tasks.

• Securing the complete definition of each folder:

identification, most relevant terms and

hierarchical relations.

• Processing the results to achieve the complete

definition of the folder using Fuzzy Deformable

Prototypes (Olivas, 2000) which will make both

analysis of the incoming messages and structure

updating easier.

The update of the structure is accomplished by

order of the user because disorganization of the

mailbox or changes in his preference criteria.

Periodically, in a batch clustering process, the

structure can be re-built reapplying the clustering

process and reusing the previous organization.

2.5 Administration of Incoming

Messages

The task of classifying each incoming message

automatically and correctly is complex so it is

essential that the analysis and sorting operations are

carried out in a process which is clear to the user,

who only has to be aware of the secured results,

without delays or loss of effectiveness.

The process to deal with each of the incoming

messages is the following:

1. Linguistic pre-process of the message:

Elimination of stop words and stop zones, and

stemming. Determination of its being within an

open conversation.

2. Construction of conceptual representation using

FIS-CRM techniques and matrices calculated in

the previous process.

3. Comparison between the characteristics of the

message and the characteristics of each folder. If

the message were within a conversation, the

comparison would be made with a subgroup of

folders and not with all of them. To calculate the

connection to each folder, one should use

inference with Fuzzy Deformable Prototypes

(Olivas, 2000).

4. Storage of the message in those folders in which

has been reached a positive relation. Updating of

the model if the amount of incoming messages

or the state of the mailbox (folders which are too

overloaded) require it.

3 EXPERIMENTAL RESULTS

3.1 Linguistic Pre-process

In this stage, the reduction achieved can be observed

through the steps already explained: conversations

grouping, elimination of superfluous elements and

reduction to significant lexemes through stemming.

These results will allow a later management of

the relevant aspects of the messages (Figure 2 and

Table 1).

200

400

600

800

1000

1200

1400

1600

ervl

et-

Jsp

MS-J

Cap

. A

latr

iste

d B

rsy

ems

1000

2000

3000

4000

5000

6000

Messages

Conversations

Detected Terms

Processed

Terms

Figure 2: Pre-processing Results.

Table 1: Preprocessing results.

Collections MessagesConvers. Detected

terms

Processed

terms

Servlet-Jsp 1468 521 3958 2746

MS-Java 516 192 4960 2909

Alatriste 270 81 1545 1087

Send Box 1218 881 1890 1367

Intersystems 436 176 2376 1541

3.2 Conceptual Representation

The use of FIS-CRM as a conceptual representation

method generates an increase in the degree of

similarity between messages (see table 2). We used

two metrics:

• Mean similarity of each element with the rest of

the set.

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

• Number of Outliers: An outlier is an element

that has no similes (or a low number), and it is

difficult to conveniently group it.

In this study, the synonyms dictionary presented

in (Fernandez-Lanza, 2001) and put into practice in

FISS (Olivas, 2003) has been used in collections of

messages in Spanish. At the same time, the

management of distribution lists whose subject

matter was the JAVA technology has also supported

itself on ontologies generated in a semi-automatic

way.

Table 2: Similarity Differences.

Collections Similarity

without

FISS.

Similarity

with FISS

Outliers

without

FISS.

Outlier

FISS

Servlet-Jsp 14,53 38,89 489 242

MS-Java 12,82 21,87 181 48

Alatriste 14,06 20,02 133 23

Send Box 10,05 17,36 529 311

Intersystems 8,77 13,67 145 72

3.3 Clustering

The number of obtained groups and their average

depth is given in the following table (table 3).

All groups cover a particular but not disjunctive

subset from that of the messages in the distribution

list domain. At the same time, we can observe that

the number of associations remains within several

limits in which the user can keep his message

collections controlled.

Table 3: Clustering results.

Collections Root

Groups

Total

Groups

Unclassified

Servlet-Jsp 12 35 110

MS-Java 6 11 50

Alatriste 6 14 12

Send Box 24 51 87

Intersystems 10 18 28

3.4 Post-process and results

The obtained message folders become easier to use

and more significant than the folders to be built

through user rules. Each folder has a complete

definition of its characteristics which will allow the

processing of incoming messages.

3.5 Administration of incoming

messages

In the following table, the management of a

particular case (in Spanish) is shown (table 4):

Table 4: Management of a particular message.

INCOMING

MESSAGE

Error Message in Tomcat

: hola amigos

de la lista: alguno sabe la manera de

personalizar las páginas de mensajes de

error de status HTTP en tomcat 4.1.12 en

particular me interesan los mensajes

correspondientes a acceso denegado((403)

recurso inexistente (404)

PREPROCESSSING

Messages 12 tok.

Subject(3 tol.)

Keys (4)

stemming: 12

Sin./ Ont: 20

3. CONCEPTUAL REPRESENTATION: FIS-CRM

Relevant Terms: Tomcat, error,

access, resource,

status, HTTP

4. MATCHING

Comparison between the characteristics

of the message and the characteristics of

each folder.

Apache Tomcat 80% 5. RESULTS

Errors 60%

To test the real utility of the obtained structure, it

has been used the rest of the collections of messages

(over the 33% of the messages used in the training

process).

To evaluate the automatic classification process,

the “Number of correct classifications (NC)” has

been used as a discriminator metric. It separates the

number of correct classifications at level 1 (NC1), at

level 2 (NC2) or at end groups level (NCH). For all

of them it is used the number of well classified

messages divided into the total of messages

processed. The obtained results for each one of the

collections can be observed in Table 5.

Table 5: Results of the load test.

Collections Messages NC1 NC2 NC3

Servlet-Jsp 387 81,8% 78,8% 62,73%

MS-Java 163 75,4% 66,7% 54,12%

Capt. Alatriste 113 85,6% 79,8% 64,56%

Send Box 320 83,2% 66,7% 63,19%

Intersystems 143 77,4% 57,6% 43.29%

The performance of the management of

incoming messages process is acceptable if it

happens within the period of time from the moment

the message comes into the server to that of its

discharge by the user. The obtained classification

generates practically no changes in the folders

structure obtained in the initial process; this means

that the set of initial messages was relevant and the

obtained organization close to the optimum one.

A METHODOLOGY FOR INTELLIGENT E-MAIL MANAGEMENT

4 CONCLUSION AND FUTURE

WORK

In this exposition, a working method to solve the

administration problems of overloaded e-mailboxes

has been presented. To do so, linguistic pre-

processing, advanced conceptual representation

using FIS-CRM and soft clustering algorithms

specifically modified for this task have been used.

At the end of the process we have a hierarchically

structured e-mailbox that allows the highest degree

of exploitation with a minimum effort.

The validity of the method has been tested

through experimentation on e-mail messages from

mail distribution lists of different kinds and

languages.

Compared with other similar systems, the

proposed methodology provides a richer hierarchical

structure due to the use of fuzzy logic and fuzzy

interrelations in its construction. Concerning the

performance, the use of an improved iterative

clustering algorithm and the FIS-CRM based

conceptual representation processes make the

performance closer to responses based on classic

algorithms such as fuzzy c-means or k-means.

For its practical use, a user-friendly Web tool,

that allows users the administration of their

messages in an efficient way, has been built. The

building process of this tool is based on top

technologies like Java and XML. Its flexibility and

portability makes it useful in any environment.

Nevertheless, there are several points in which

the process needs improvement, so further studies

are essential. Some main points are the following:

• Linguistic functions for the management of

specific characteristics of the messages and

spelling correction of terms.

• Improvements in identification of the language

used in the messages and inclusion of

Multilanguage dictionaries.

• Improvements in conceptual representation

through the exploitation of context and other

factors.

• More efficient clustering algorithms using

improvements and/or adaptations of traditional

algorithms such as fuzzy c-means and Kohonen

Maps.

• Widening of the direct, conceptual and

navigational search with the possibility of a

phonetic search.

REFERENCES

Fernandez-Lanza, S., 2001. A contribution to the

automatic processing of the synonymy using Prolog,

PhD Thesis, University of Santiago de Compostela.

Frakes, W. B., & Baeza-Yates, R., 1992. Information

Retrieval: Data Structures & Algorithms. Prentice

Hall. Englewood Clifss, N. J.

Harrys, D. & Heather C. 2002. Wordtalk releases first

Internet e-mail corporate usage report; concludes e-

mail abuse at epidemic levels.

http://www.wordtalk.com.

Joachims, T., 1998. Text Categorization with Support

Vector Machines: Learning with Many Relevant

Features, Proceedings of the European Conference on

Machine Learning, Germany.

King-ip L., Ravikumar, K., 2001. A similarity-based soft

clustering algorithm for documents. Proc. of the

Seventh Int. Conf. on Database Sys. for Advanced

Applications.

Kiritchenko, S. & Matwin, S. 2002. Email Classification

with Co-training, Proceedings of the CASCON'02

(IBM Centre for Advanced Studies Conference ),

Toronto.

Kiryakov A. K. & Simov K. I., 1999. Ontologically

supported semantic matching, Proceedings of

NODALIDA'99: Nordic Conference on

Computational Linguistics.

Nikravesh, M. & Azvine, B. (eds.), 2001. Proceedings of

the 2001 BISC International Workshop on Fuzzy

Logic and the Internet, University of California-

Berkeley.

Olivas, J. A.; Garcés, P.; Romero, F. P.,2003. An

application of the FIS-CRM model to the FISS

metasearcher: Using fuzzy synonymy and fuzzy

generality for representing concepts in documents. Int.

Jour. of Approx. Reasoning (Soft Computing in

Recognition and Search).

Olivas, J. A., 2000. Contribution to the experimental study

of the prediction based on Fuzzy Deformable

Categories, PhD Thesis, University of Castilla-La

Mancha, Spain.

Pasi, G., 2002. Flexible information retrieval: some

research trends. Mathware & Soft Computing.

Sahami, M. et al. 1998. A Bayesian Approach to Filtering

Junk E-Mail, in Proceedings of the AAAI Symposium.

Turene, Nicolas, 2003. Learning Semantic Classes for

improving Email Classification, Proceeding of the

Text Link Conference.

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS
