SYMBOLIC KNOWLEDGE REPRESENTATION IN

TRANSCRIPT BASED TAXONOMIES

Philip Windridge, Bernadette Sharp

Faculty of Computing, Engineering and Technology, Staffordshire University, Beaconside, Stafford, UK

Geoff Thompson

School of English, University of Liverpool, Liverpool, UK

Keywords: Knowledge Representation, taxonomy, system network transcript analysis, XML

Abstract: This paper introduces a design for the taxonomical re

presentation of participants’ instantial meaning-

making, as the basis for providing a measure of ambiguity and contestation. We use hyponymy and

meronymy as the basis for our taxonomies and adopt the System Network formalism as the basis for their

representation. We achieve an integration of transcript and taxonomy using an XML based ‘satellite’ system

of data storage. Content data forms a ‘Root’ document which can then ‘mapped’ to by an arbitrary number

of ‘Descriptor’ documents. This system represents instantial meanings by mapping Descriptor document

elements to elements in the Root. Part of this mapping also includes the sequence of Root elements,

accommodating the diachronic representation of meaning-making. This diachronic representation provides

the basis for measuring ambiguity and contestation.

1 INTRODUCTION

This research is carried out as part of the Tracker

project (Rayson et al. 2003) which has the aim of

reducing rework through decision management. The

approach described in this paper works with

transcripts to analyse the active negotiation of

meanings. This negotiation can lead to varying

degrees of contestation and/or ambiguity between

participants in the social activity from which the

transcript is produced. Making this explicit, through

a comparison of participants’ meaning-making, has

the potential to augment summative records

associated with a decision, such as sets of minutes.

The purpose of this paper is to introduce Transcript

Based Taxonomies as a novel representation

formalism.

We take a participant’s experiential meaning-

aking as the production and construal of semantic

associations between lexical units that are

attributable to that participant. This aspect of

meaning-making is revealed in the transcribed

utterances of participants. We identify semantic

associations forming dynamic taxonomical relations,

both within and between these utterances, as one

way of reflecting participants’ negotiation of

meanings. Contestation and/or ambiguity is shown

by comparing participants’ taxonomies where their

meaning-making is comparable. The effectiveness

and simplicity of this comparison is facilitated

through the integration of transcript and taxonomy

representations using Extensible Markup Language

(XML) (W3C 2004). Transcript Based Taxonomies

are the result of this integration.

In section 2 we provide a conceptual view of

Tran

script Based Taxonomies. In section 3 we

consider the form that this representation takes by

briefly discussing network based symbolic

knowledge representation. Section 4 describes the

representation of Transcript Based Taxonomies

using XML as an integration of transcript and

taxonomy. Finally, in the conclusion, we discuss this

representation in terms of our research requirements

and look to their future development.

The worked examples in this paper are extracted

fro

m the transcript of one formal meeting involving

eight academics in total. Discussion in the meeting

emphasised how project tasks would be organised

and co-ordinated and included a general discussion

about resource management.

267

Windridge P., Sharp B. and Thompson G. (2005).

SYMBOLIC KNOWLEDGE REPRESENTATION IN TRANSCRIPT BASED TAXONOMIES.

In Proceedings of the Seventh International Conference on Enterprise Information Systems, pages 267-272

DOI: 10.5220/0002521102670272

 SciTePress

2 TRANSCRIPT BASED

TAXONOMIES

Transcript Based Taxonomies represent meaning-

making associated with a participant in a social

activity. They are concerned with the analysis of

transcripts for two reasons. The first is that the

transcript is the most practical way of accessing both

the record of what was spoken and the associated

contextual information affecting the meaning of

utterances. The second reason, given the practicality

of the transcript, is that it is the best means by which

the negotiation of meanings can be analysed.

Our analysis is based on taxonomy relations

between lexical units. Lexical units are realised by

the utterance of one or more words that express a

single concept; for example ‘lexical unit’ or

‘participant’s utterance’. Relations between lexical

units are part of the semantic cohesiveness of the

transcript and form lexical chains that can be

associated with a participant. The particular types of

lexical relation that we concentrate upon are

hyponymy and meronymy. The hyponymy relation

can be understood as the so-called is-a relation. In

Figure 1a ‘management meeting’ and ‘technical

meeting’ both have an is-a relation to ‘meetings’ and

are co-hyponymous to each other. The meronymy

relation can be understood as the part-of relation.

For example, in Figure 1b ‘set of activities’,

‘deliverables’ and ‘milestones’ have been analysed

as being part-of ‘project management’ and therefore

in a co-meronymous relation to each other. It must

be emphasised that the meaning-making we are

describing emphasises the taxonomical

representation of meanings as they are construed in

the transcript rather than referencing any pre-defined

and commonly accepted taxonomies. The meanings

that we derive from the transcript are reflected in a

taxonomical representation which is based upon this

transcript analysis.

The lexical units used in forming Transcript

Based Taxonomies are identified for their function

in experiential meaning. Experiential meaning

(Halliday 1978) can be understood as ‘meaning

based upon an interpretation of our experience’; in

contrast to meanings that establish and maintain

interpersonal relationships and meanings that have a

cohesive function in a given situation. Through

processes of self-reflection and communication

experience is reconstituted through time so that

experiential meanings change. We are apt to ‘change

our minds’ or contradict things that we have said in

the past. Transcript Based Taxonomies must

therefore be understood as dynamic.

The participant in a social activity is an

individual person to whom a taxonomy of lexical

units can be ascribed. This ascription does not

require the utterance of a lexical unit by a participant

but it does require that the participant ‘buy into’ or

accept their meaning. Figure 1b provides an example

of this. The participant ‘JCA’ is asking about

intended tasks and ‘PRA’ refers to existing tasks, but

it can be seen that there is overlap in their respective

lexical chains.

Transcript based taxonomies allow for the

measurement of ambiguity and contestation by

concentrating upon the description of relationships

between lexical units. Where taxonomies can be

derived for two or more participants on a given topic

their comparison provides a measure of their

contestation as contradictory lexical units and/or

lexical unit relationships. For instance, in Figure 1b

there is contestation surrounding ‘operational tasks’

where they have been analysed as either directly

associated with ‘project management’ for the

participant ‘JCA’ or with ‘bid’ for the participant

‘PRA’. Extracting the meaning-making of a

participant for a particular topic allows the analysis

of the participant’s meanings in terms of consistency

both in time and over time. Inconsistency within a

taxonomy representing temporally equivalent

meanings indicates the presence of contradiction as

ambiguity. For example, in Figure 1b ‘PRA’ appears

to accept “the intention to have…deliverables” that

‘JCA’ talks of but then contradicts this by stating

their existence in the bid as “a set of deliverables on

page 16”. There is a contrast between a proposal for

deliverables as an intention and a proposal for

deliverables as an actuality. This temporally

equivalent acceptance and contradiction adds a

degree of ambiguity to “deliverables” as part of

“bid” on the part of ‘PRA’.

Figure 1: Lexical chains showing taxonomy relations

b) Lexical chains showing meronymy (participant ‘JCA’

using black lines, ‘PRA’ using grey lines)

a) Lexical chain showing hyponymy

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

268

3 REPRESENTING KNOWLEDGE

Transcript Based Taxonomies deal with symbols (as

lexical units), and their interrelationships, which

form a representation of participants’ meaning-

making. In Artificial Intelligence the development of

formalisms for this purpose are part of symbolic

knowledge representation. Discussing what a

representation is, Eysenck and Keane state that “it

stands for some thing in the absence of that thing”

(Eysenck & Keane 1995:204). Davis et al. (1993)

concur by saying it acts as a surrogate used for

focussing on particular aspects of a thing. The

knowledge aspect refers to the information that is

contained in the representation with no claim to its

veracity. As Reichgelt puts it, “the fact that some

piece of information has been written down in a

knowledge representation language does not by

itself make it true” (Reichgelt 1991:3); the

knowledge representation makes no claim about the

truth of the original data. This view of knowledge

representation accords with Transcript Based

Taxonomies to the extent that:

– they are intended to represent that aspect of the

social activity concerned with linguistic

meaning-making, and

– they do not seek to make claim to any objective

‘truth’.

Transcript Based Taxonomies, in accordance

with any other knowledge representation, afford a

subjective viewpoint. This subjectivity can be seen

in the inevitable ontological commitments embodied

by the knowledge representation itself, in the way

knowledge is organised, and in how this

representation structure is populated with data when

it is instantiated. The discussion of the ontological

commitments embodied in Transcript Based

Taxonomies, and the discussion of instantiation, is

unfortunately beyond the scope of this paper and

forms the basis for future publications. Here we shall

simply state that Transcript Based Taxonomies are

not concerned with representing ‘objective’ or

commonly shared abstracted truth.

The taxonomical representation of lexical units

lends itself to a network representation such as

semantic networks. This form of symbolic

knowledge representation has already been used to

support natural language processing by embodying a

structural linguistic approach. Simmons, for

instance, considers semantic networks to be “a

computational theory of superficial verbal

understanding in humans” (Simmons 1973:63)

which he uses for the recognition and generation of a

subset of English sentence structures. Woods (1985)

goes further by indicating their use as a means of

understanding and modelling cognitive processes

where they offer a way of “representing the

meanings of sentences inside the brain (of humans

or other intellects) that is not merely a direct

encoding of the English word sequence” (Woods

1985:220). However, in the research reported here

we are not attempting to support natural language

processing, we are only concerned with representing

participants’ meaning-making as they occur in a

transcript. This greatly simplifies the task of

representation in terms of the number of

relationships that are required.

The network representation formalism adopted

in this research is called the system network (Martin

1992; Eggins 1994). Figure 2 shows the system

network version of the lexical chain examples taken

from Figure 1. System networks share many features

with semantic networks. At their most basic level

they are nodes connected by arcs that can be

grouped by the type of relationship they represent in

a similar way to the ‘and/or’ graph. A system

network can be comprised of one or more systems,

with each system defined by one or more entry

conditions and one or more outcomes. For instance,

in Figure 2a ‘project management’ is an example of

an entry condition while ‘set of activities’,

‘deliverables’ and ‘milestones’ are all outcomes. If

‘JCA’ had specified some intended ‘deliverables’

this would have formed a further system as part of

the same system network with the outcome

‘deliverables’ acting as its entry condition.

A system can either represent a meronymy

relation (‘part-of’) indicated by a brace as in Figure

2a or an hyponymy relation (‘is-a’) indicated by a

vertical straight line connector (square bracket) as in

Figure 2b. The use of parentheses, such as those

surrounding ‘set of activities’ in Figure 2a, indicates

that the node value was not directly uttered by the

participant.

Unfortunately, in this basic form, the system

Figure 2: System network taxonomy relations

)

Meron

relations

b) Hyponymy relation

SYMBOLIC KNOWLEDGE REPRESENTATION IN TRANSCRIPT BASED TAXONOMIES

269

network is inadequate to the requirements of

Transcript Based Taxonomies because instantial

meaning is lost as soon as they are abstracted from

the transcript. The system network acts as a

surrogate for the transcript even as the transcript acts

as a surrogate for the social activity from which it is

produced. While it is not possible to have direct

access to a participant’s meanings, because of the

historically specific nature of discourse (Foucault

1972), the question is whether the transcript should

be viewed as an additional layer of abstraction or

whether it should be integral to the taxonomy

structure. Any form of representation introduces the

possibility of misconstrual. As pointed out by Davis

et al “representations are imperfect, and any

imperfection can be a source of error” (Davis et al.

1993:19). The burden on a taxonomy to faithfully

represent meaning-making is increased if the

transcript acts as an intermediary form of

representation. Integration of transcript and

taxonomy, thus removing a level of abstraction, will

act to minimise errors.

4 XML REPRESENTATION

The integration of transcript and taxonomy in a

single representation structure is dependent upon the

way that the data is stored using XML. In the

transcript it relies upon the separation of what we

term the ‘core data content’, which is the written

representation of words uttered by the participants,

from data that adds meaning to or re-interprets the

utterances (metadata). The ‘SLA Descriptor’

contains transcript specific data other than uttered

words and is discussed in section 4.1. The

‘Taxonomy Descriptor’ contains the taxonomy

relations and is discussed in section 4.2.

4.1 Transcripts as XML

There are two main concerns for the representation

of social activities in transcripts:

1. That the representation should be as machine

processable as possible,

2. That the representation should retain the

‘situatedness’ of meaning-making, including

contextual data.

These concerns are not specific to the current

research and have been addressed by a number of

transcription standards. CHAT (MacWhinney 2004),

for instance, is a transcription standard designed to

improve the reliability and shareability of transcripts

through a common, selectable and exhaustive

notation. It allows the inclusion of metadata to be

associated with a transcript in its entirety or to

particular parts down to the lexical unit or below to

the word or morpheme. This inclusion of metadata

facilitates both human and automated linguistic

analysis and processing.

The representation of CHAT transcript data in

XML has been described in Clarke et al. (2003) and

will only briefly be outlined here. The dependency

of the SLA Descriptor on the Root document has

already been mentioned in general terms above. This

dependency takes the form of a link that ‘maps’ the

SLA Descriptor to the Root; Figure 3 shows an

example of how this is achieved. The Root

document uses the <w> element to hold individual

words and the SLA Descriptor maps onto these

elements through their element number (in this case

the element numbers have been added to the Root

document for illustration purposes only). The co-

ordinates for this mapping are identified using the

attributes ‘beg’ and ‘len’. The Root and SLA

Descriptor documents contain enough information to

provide a ‘view’ of the data that conforms to the

CHAT transcription standard.

4.2 Taxonomies as XML

The XML taxonomy representation views the

System Network as comprised of distinct but

interconnected systems. This means that arbitrarily

complex System Network structures can be

represented. Figure 4 shows a simple ‘single system’

example first introduced in Figure 2a above. The

example illustrates the scaleable notation that has

been used which is based upon a simple ‘entry

conditions and outcomes’ template for each system.

Systems are represented by separate <system>

elements under the parent element

ure 3: Reconstructin

CHAT transcri

t from XML

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

270

<systemNetwork>. Adding systems to the

System Network is achieved by an outcome

reference being used as an entry condition reference

for a connected system. Each system contains one or

more entry conditions within the <entry> element

and one or more outcomes within the <outcome>

element. The <outcome> element can either have

an ‘reltype’ attribute value of ‘mer’ indicating

meronymy or a value of ‘hyp’ indicating hyponymy.

Both <entry> and <outcome> elements can

contain <lexicalItem> or <placeholder>

elements. The element can either reference a lexical

unit that has been bought into by the participant or,

in certain circumstances, a lexical unit that has been

analysed as ‘missing’ from the text, for example

where an object is referenced through ostension. As

can be seen in Figure 4 <lexicalItem> and

<placeholder> directly reference sections of

the Root document using the ‘beg’ and ‘len’

attributes in the same way as described in the

previous section. Using this system of pointers to

record where the lexical unit originates within the

transcript has two effects:

1. Sequence and proximity of lexical units are

governed by their mappings to the Root

document, addressing the requirement of

representing diachronic meaning-making.

2. Any contextual data associated with a location in

Root can be accessed in the SLA Descriptor

‘view’; the same applies for the use of any other

Descriptor document as a part of the

representation.

However, in order for the Taxonomy Descriptor

to show contestation it is necessary to extend our

view of the system network. Specifically we need to

show where meanings are contradictory rather than

the legitimate ‘mutual exclusivity’ of meanings

which exists in the co-hyponymy relation. There are

four methods that we have adopted for doing this.

Firstly, where the meaning of an entry condition

is contested between two or more participants, a

‘contesting’ <placeholder> element references

the lexical unit for all participants except the original

utterer where a ‘contesting’ <lexicalItem>

element serves this purpose. An example of this is

shown in Figure 5, following Figure 1b, where the

meaning of ‘project management’ appears to be

introduced by ‘AAL’ referring to hierarchical lines

of communication in the project, ‘JCA’ subsequently

appears to interpret the same lexical unit as referring

to organised activities of the project.

Secondly, where the meaning of an outcome is

contested between two or more participants a

‘contesting’ <placeholder> or

<lexicalItem> element is used as the outcome.

Thirdly, where the meaning of an entry condition

is contested by the same participant a ‘contesting’

<lexicalItem> element ‘re-presents’ the entry

condition for a new system.

Lastly, where the outcomes of a system are

contested by the same participant a new system is

created with an identical entry condition to the

original.

Effectively, the final two methods create parallel

interpretations in the Taxonomy Descriptor. These

interpretations are distinguished by the sequential

occurrence of their lexical units in the Root

document. In a similar approach, the representation

of ambiguity is achieved by using an ‘ambiguity’

<placeholder> or <lexicalItem> element

where appropriate.

Figure 4: A System Network ‘view’ derived from a

Taxonomy Descriptor

a) Taxonomy Descriptor of participant ‘AAL’

b) Taxonomy Descriptor of participant ‘JCA’

Figure 5: Contested network entry conditions

SYMBOLIC KNOWLEDGE REPRESENTATION IN TRANSCRIPT BASED TAXONOMIES

271

5 CONCLUSION AND FURTHER

WORK

In this paper we have discussed the representation of

social activities as a taxonomy of instantial

meanings which have been derived from transcript

analyses. We have highlighted a number of factors

that have formed the basis for this representation and

have indicated their relationship to network based

symbolic knowledge representation. We then

outlined our XML based ‘satellite system’ of storing

data and showed how this system is the basis for

Transcript Based Taxonomies. Finally we showed

how the Taxonomy Descriptor supports a number of

methods for the representation of contestation and

ambiguity which, together with the ability to

represent the sequential development of meaning-

making (see section 4.3 and the brief discussion

below), provides the basis for their measure.

It has been pointed out that, due to the

historically specific nature of participants’ meaning-

making, in addition to what can be described as

subjective interpretation, it is impossible to faithfully

capture intended meanings. Whilst we have accepted

this limitation we have also removed an unnecessary

intermediate layer of abstraction by integrating the

transcript and taxonomy layers using the satellite

system of XML documents. This means that the

taxonomy can take full advantage of the exhaustive

notation, and possibility for simplified machine

processing, offered by the CHAT transcription

standard. In directly mapping either an entry

condition or an outcome to elements in the Root

document they become identified with the instantial

meanings provided by the SLA Descriptor ‘view’

(section 4.3). This instantial meaning is unique and

any Taxonomy Descriptor that uses this mapping

offers a direct and unequivocal comparison with any

other Taxonomy Descriptor that maps the same

point. Furthermore, this mapping carries with it a

sequential order of appearance of elements in the

Root document that affords a dynamic

representation of meaning-making.

The primary task of Transcript Based

Taxonomies is to provide a means for the

comparison of meaning-making and this carries the

concomitant requirement that lexical units should be

associable with their synonyms, antonyms, etc., as

they occur within the transcript. The association of

Transcript Based Taxonomies to separate

participants means that accounting for instantial

synonymy, antonymy, etc., is vital for a valid

comparison to take place; participants may use

different words to describe the same thing, or they

may use a word to directly contest another.

Development of this analysis will increase the

delicacy of our representation.

This work was conducted under the auspices of

the Tracker Project, UK EPSRC grant

(GR/R12176/01).

REFERENCES

Clarke, R. J., Windridge, P. C. & Dong, D. 2003,

'Effective XML Representation for Spoken Language

in Organisations', in 6th International Conference on

Enterprise Information Systems, Porto, Portugal, pp.

486-494.

Davis, R., Shrobe, H. & Szolovits, P. 1993, 'What is

Knowledge Representation', In AI Magazine, vol. 14,

American Association for Artificial Intelligence, pp.

17-33.

Eggins, S. 1994, An Introduction to Systemic Functional

Linguistics, Continuum, London.

Eysenck, M. W. & Keane, M. T. 1995, Cognitive

psychology: a student's handbook, 3rd edn, Lawrence

Erlbaum Associates, Hove.

Foucault, M. 1972, Archaeology of Knowledge,

Routledge, London.

Halliday, M. A. K. 1978, Language as Social Semiotic:

The Social Interpretation of Language and Meaning,

Edward Arnold, London.

MacWhinney, B 2004, CHAT Transcription System

Manual, viewed 8 August 2004,

<http://childes.psy.cmu.edu/manuals/CHAT.pdf>.

Martin, J. R. 1992, English Text: System and Structure,

John Benjamins, Philadelphia.

Rayson, P., Sharp, B., Alderson, A., Cartmell, J.,

Chibelushi, C., Clarke, R., Dix, A., Onditi, V., Quek,

A., Ramduny, D., Salter, A., Shah, H., Sommerville, I.

& Windridge, P. 2003, 'Tracker: A Framework To

Support Reducing Rework Through Decision

Management', in 5th International Conference On

Enterprise Information Systems, École Supérieure d'

Électronique de l' Ouest, Angers, France.

Reichgelt, H. 1991, Knowledge Representation: An AI

Perspective, Ablex Pub. Corp., Norwood, N.J.

Simmons, R. F. 1973, 'Semantic Networks: Their

Computation and Use for Understanding English

Sentences', in Computer Models of Thought and

Language, eds. Schank, R. C. & Colby, K. M., W. H.

Freeman, San Francisco, pp. 63-113.

W3C 2004, Extensible Markup Language (XML) 1.1,

Available: [http://www.w3.org/TR/2004/REC-xml11-

20040204/] (4/4/2004).

Woods, W. A. 1985, 'What's in a Link: Foundations for

Semantic Networks', in Readings in knowledge

representation, eds. Brachman, R. J. & Levesque, H.

J., M. Kaufmann Publishers, Los Altos, Calif., pp.

218-241.

ICEIS 2005 - ARTIFICIAL INTELLIGENCE AND DECISION SUPPORT SYSTEMS

272
