Human Fall Detection from Sequences of Skeleton Features using Vision
Transformer
Ali Raza
1,2 a
, Muhammad Haroon Yousaf
1,2 b
, Sergio A. Velastin
3,4 c
and Serestina Viriri
5 d
1
Department of Computer Engineering, University of Engineering and Technology, Taxila, Pakistan
2
Swarm Robotics Lab, National Centre of Robotics and Automation (NCRA), Pakistan
3
School of Electronic Engineering and Computer Science, Queen Mary University of London, London E1 4NS, U.K.
4
Department of Computer Engineering, University Carlos III, 28911 Legan
´
es, Spain
5
School of Mathematics, Statistics & Computer Science, University of KwaZulu-Natal, Durban, 4041, South Africa
Keywords:
Computer Vision, Fall Detection, Vision Transformers, Event Recognition.
Abstract:
Detecting human falls is an exciting topic that can be approached in a number of ways. In recent years, several
approaches have been suggested. These methods aim at determining whether a person is walking normally,
standing, or falling, among other activities. The detection of falls in the elderly population is essential for
preventing major medical consequences and early intervention mitigates the effects of such accidents. How-
ever, the medical team must be very vigilant, monitoring people constantly, something that is time consuming,
expensive, intrusive and not always accurate. In this paper, we propose an approach to automatically identify
human fall activity using visual data to timely warn the appropriate caregivers and authorities. The proposed
approach detects human falls using a vision transformer. A Multi-headed transformer encoder model learns
typical human behaviour based on skeletonized human data. The proposed method has been evaluated on the
UR-Fall and UP-Fall datasets, with an accuracy of 96.12%, 97.36% respectively using RP normalization and
linear interpolation comparable to state-of-the-art methods.
1 INTRODUCTION
Human fall detection is a challenging problem that
may be tackled in several ways. To tackle the prob-
lem, several approaches have been suggested in re-
cent years. The majority of the existing methods in-
tend to recognize human actions or activities but not
limited to walking, standing or falling etc. Elderly
fall detection is vital among these activities. Accord-
ing to the World Health Organization, around 37.3
million people worldwide suffer fall-related injuries
that need medical care each year(Organization et al.,
2008). Falls are consistently among leading causes of
death all around the world. Although elderly people
are most in danger of terrible and deadly falls, chil-
dren and younger people are also at high risk when
they sustain fall injuries. A human fall can be inter-
preted as a sudden and significant change in the hu-
man pose.
a
https://orcid.org/0000-0000-0000-0001
b
https://orcid.org/0000-0001-8255-1145
c
https://orcid.org/0000-0001-6775-7137
d
https://orcid.org/0000-0002-2850-8645
Human pose estimation is currently an area of ac-
tive interest for researchers. There are many recent
studies in the literature in this field, especially on the
use of machine learning and computer vision meth-
ods. Various sensor-based approaches can be used
to detect different actions, such as walking, running,
standing, sitting, jumping, and falling. The use of
computer vision algorithms to detect actual falls has
caught interest due to its application in the health-
care sector. Most of the increases in healthcare costs
may be associated to the increases in the aging pop-
ulations in developed countries. This kind of ap-
plication has grown in popularity due to the imple-
mentation of safety measures at high-risk workplaces,
shopping malls, hospitals, nursing homes, and other
places. Falls are one of the most prevalent causes of
injuries, and the elderly are more susceptible to them.
Wearable sensors have been previously used for fall
detection, and barometers, inertial sensors, and gyro-
scopes have been used in some systems to identify
falls. However, the hardware components are expen-
sive, intrusive and not user-friendly to be worn by
people. Computer vision can be considered a more
Raza, A., Yousaf, M., Velastin, S. and Viriri, S.
Human Fall Detection from Sequences of Skeleton Features using Vision Transformer.
DOI: 10.5220/0011678800003417
In Proceedings of the 18th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2023) - Volume 5: VISAPP, pages
591-598
ISBN: 978-989-758-634-7; ISSN: 2184-4321
Copyright
c
2023 by SCITEPRESS Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)
591
flexible approach for fall detection and researchers
have reported many possible techniques and datasets.
Certain studies have demonstrated that videos can be
used to detect human activity in general. Vision-
based on skeletonized data of human joints, derived
from conventional images, are proving popular be-
cause they can protect privacy and be more robust to
varying environmental factors. These methods also
detect falling, walking, running, jumping, jogging,
etc. More people can now be recognized in a single
image. Probabilistic models are used in computer vi-
sion systems to detect falls. A computer vision-based
fall detection system uses deep learning or machine
learning to recognize and predict human falls based
on the human skeleton joint points rather than images
used as training data, reducing training time.
A summary of relevant existing research work in
the domain of human fall detection is given in Table
1. Article references are given in the first column.
The second column shows whether a method can de-
tect activities other than falls. The third column indi-
cates whether a pose detection technique with skele-
ton detection process is employed. The fourth col-
umn indicates whether the algorithm has been imple-
mented to identify activities using image sequences.
The fifth column specifies if the detection technique
includes depth sensors. The sixth column shows the
model/technique applied in each work. The last col-
umn indicates which dataset was used in the respec-
tive research work. It can be observed that 60% of
the surveyed literature uses skeleton data for activity
detection, with OpenPose being the most frequently
pose estimator. Only 20% of the work can detect mul-
tiple activities. The most often chosen public datasets
for testing are UR-Fall 30%, UP-Fall 16%, and per-
sonal datasets 5%, while 70% of recent publications
describe the use of sequences for activity detection.
Considering the complex nature of the human fall
detection problem, this paper presents a vision trans-
former technique to solve the human fall detection
problem in a non-intrusive way. For this purpose,
BlazePose is used as a pose extractor and backbone
(although any other similar pose estimation method
may be used). After that, a vision transformer is
used as the head of the network. The proposed so-
lution eliminates the need to wear any physical sen-
sors. The approach takes less training time, helps pre-
serving users’ privacy, and increases machine learn-
ing algorithm efficiency and accuracy. The proposed
Figure 1: Fall sequence frames.
methodology uses linear interpolation to compen-
sate for missing joint points. A sequence of frames
is utilised to identify pose estimations that a single
frame cannot identify. Figure 1 shows a fall sequence.
The proposed approach uses UR-Fall and UP-Fall and
gives improved results that are compared with state-
of-the-art methods.
Table 1 show the existing literature of the hu-
man fall detection on visual data. Some of the exist-
ing work done using pose estimation and use LSTMs
and/or CNNs, but to the best of our knowledge vision
transformers have not been reported to solve human
fall detection using pose estimation.
The key contributions in this work are:
A vision transformer is proposed for human fall
detection. Specifically, we use a multi-headed
transformer encoder network for the fall detec-
tion.
Blazepose is used for pose estimation. RGB
videos are used to get skeleton features, which are
then fed into a multi-headed transformer encoder.
This encoder takes a sequence as input, uses a way
to pay attention, and can predict where a person
will fall.
When it comes to position normalization and lin-
ear interpolation, missing keypoints in the skele-
tons can be fixed with preprocessing techniques.
The proposed approach is evaluated on the pub-
licly available UR-FALL and UP-FALL datasets,
and results are compared with state-of-the-art
methods.
2 PROPOSED APPROACH
The process flow of the proposed technique is given
in Figure 2. As input, the network gets a series of
video frames, which are then processed by subsequent
blocks. Each of these blocks is explained in more de-
tail below.
2.1 Human Pose Estimation
The first step in determining how people fall is to lo-
cate a person in video frames and determine the loca-
tion of their skeleton joints. Human skeletons behave
differently in the fall compared to conventional ac-
tions. The ability to locate these skeletons can aid the
detection of falls in videos. This work uses Blazepose
as a method for estimating human poses or skeletons.
Blazepose is a machine learning (ML) technique that
uses RGB video frames to figure out 33 landmarks
and a background segmentation mask. This gives a
VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications
592
Table 1: Summary of Human Fall Detection Works using Visual Data.
Ref
Multi
Activity
Skeleton Sequence
Cam
RGB
Model Dataset
(Chhetri et al., 2021a) No No Yes Yes CNN UR-Fall
(Chen and Duan, 2021) No No Yes Yes NanoDet-Lite UR-Fall
(Cai et al., 2021) No No Yes Yes MCCF UR-Fall
(Sultana et al., 2021) No No Yes Depth 2D CNN-GRU UR-Fall
(Leite et al., 2021) No No Yes Depth CNN-SVM UR-Fall
(Keskes and Noumeir, 2021) No No Yes Depth ST-GCN TST-Fall
(Tran et al., 2021) No No No Yes CNN-YOLO CMD-Fall
(Nguyen et al., 2021) No No No Yes KNN-SVM BOMNI
(Berlin and John, 2021) No own Yes Yes LSTM UP-Fall
(Galv
˜
ao et al., 2021) No own Yes Yes AutoEncoder UP-Fall
(Guan et al., 2021) No OpenPose Yes Yes LSTM UP-Fall
(Kang et al., 2021b) No PoseNet Yes Yes GRU UP-Fall
(Lin et al., 2020) No OpenPose Yes Yes LSTM-GRU UP-Fall
(Chhetri et al., 2021b) No OpenPose Yes Yes SVM UP-Fall
(Dentamaro et al., 2021) No OpenPose Yes Yes SVM UP-Fall
(Chang et al., 2021) No OpenPose Yes Yes LSTM CMU
(Liu et al., 2021) No OpenPose Yes Depth RF SDU-Fall
(Kang et al., 2021a) No own Yes Yes GRU SDU-Fall
(Ramirez et al., 2021a) No AlphaPose No Yes KNN UP-Fall
(Wang et al., 2021) Yes(7) Yolov3 Yes Yes 3D CNN PKU-MMD
(Zhu et al., 2021) Yes(4) OpenPose Yes Depth DNN FDD
(Yin et al., 2021a) Yes(8) own Yes Depth MC-LSTM TST-Fall
(Ramirez et al., 2021b) Yes(12) AlphaPose No Yes
RF-SVM
MLP-KNN
UP-Fall
Figure 2: Proposed Approach Pipeline.
good estimate of the body’s pose. Figure 3 illustrates
the 33 landmarks.
Blazepose follows a two-step mechanism. First,
it detects the person. After the person is detected, it
calculates pose. Figure 4 shows a skeleton detected
from a video frame.
Human Fall Detection from Sequences of Skeleton Features using Vision Transformer
593
Figure 3: 33 full body landmarks.
Figure 4: Skeleton detected from a video frame.
2.2 Data Pre-Processing
Pre-processing is useful because data may not be col-
lected in the same unit or format. As a result, the
format must be changed, outliers must be removed,
missing values must be added, and features must be
scaled. Here are the steps that are taken to correct the
data format, normalize the data, and locate the miss-
ing values.
2.2.1 Relative Position Normalization
To improve the model’s accuracy, we use min-max
normalization to scale the data to the interval [0, 1]
to accelerate the model’s convergence. The new X
n
o
m
scale data are defined as.
X
nom
=
X X
min
X
max
X
min
[0, 1] (1)
The original data is represented by X, the lowest value
is represented by X
m
i
n
and the highest value is repre-
sented by X
m
a
x
.
However, the dataset contains missing points.
Even though not all groups have missing data, the
value 0 indicates that X
min
will equal 0. As a result,
the original data distribution will be changed, result-
ing in ambiguous attributes. Consequently, we sug-
gest the following normalization approach to convert
the initial coordinate position to the relative coordi-
nate positions in the f
t
h
frame.
x
f
c
=
W
2
(2)
and
y
f
c
=
H
2
(3)
where W and H are the width and height of the im-
ages, respectively. When x
f
n
or y
f
n
point equals 0, it is
considered to be a missing point and is not calculated.
The calculated center point will replace the missing
center point if it is a missing point. The distances
(x
d
is
, y
d
i
s
) that need to be displaced are defined as
x
f
dis
= x
f
8
x
f
c
(4)
and
y
f
dis
= y
f
8
y
f
c
(5)
The displacement is to the center point where the
eighth joint point is (x
8
f
, y
8
f
) and the central hip
circumference is used as the reference point (x
f
c
,
y
f
c
).When the displacement value is less than zero,
the object moves to the right. When the displacement
value is more than zero, the object goes to the left.
The new joint point coordinates (rx
f
n
, ry
f
n
) for
computing the displacement to the relative location
are then given as
rx
f
n
=
x
f
n
x
f
dis
(6)
and
ry
f
n
=
y
f
n
y
f
dis
(7)
Two advantages can be gained from this method.
First, the original data distribution is preserved, and
secondly the missing points do not need to be com-
puted simultaneously. In addition, any unnecessary
features should be eliminated. Aspects of the human
body displacement process, such as left-right or far-
near walking, fix the human skeleton in the same po-
sition and give continuous motions to facilitate the
training of the model.
As shown in Figure 5, the image is resized to 640
by 480 pixels and its center is located. The human
skeleton will be moved to the image’s center after
displacement,as shown in Figure 5, and the central
hip-joint point will be similar to the position of the
center point. Some joints in the skeleton were con-
sidered irrelevant for distinguishing fall and non-fall
events. Thus, they were eliminated because an exces-
sive number of feature parameters may confuse the
process and diminish the recognition rate. So, the
only significant points that are retained for training
are: the nose, shoulders, elbows, wrists, neck, hips,
knees, and ankles.
VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications
594
Figure 5: After displacement, the location and number of
joint points.
Figure 6: Missing skeleton detected from a video frame.
2.2.2 Settlement for Missing Keypoints
BlazePose uses 2D image features to identify the
skeleton. Therefore, instability and incorrect predic-
tion errors might arise when these points are absent.
As seen in Figure 6, if the human body is obscured
or concealed, its contour is unclear, or if the upper
and lower limbs of the human body are occluded, it
will result in loss and errors during skeleton construc-
tion. The proposed approach uses linear interpola-
tion to adjust for the missing data. To ensure ade-
quate data, we designate 100 images as a group and
use the initial non-missing value data to interpolate
missing values in succeeding images. The interpo-
lation method may estimate the following data value
from the original data. If the initial number of joint
points is inadequate, the predicted missing value and
the real value will differ significantly. Linear inter-
polation calculates the slope between two known data
points using two known data points. The approximate
values for Y are given by,
Y = Y
0
+
Y
1
Y
0
X
1
Y
0
(X X
0
) (8)
Figure 6 shows that the discrepancy between the es-
timated and real value is not statistically significant
when the turning point is not missing. Before RP
normalization, the total dataset’s missing key points
accounted for 22.38%, and after RP-Normalization,
missing key points accounted for 13.4%. Moreover,
after interpolation + RP-Normalization, the missing
key points are only 1.8% of the total.
2.3 Multi-Headed Transformer Encoder
The multi-head self-attention mechanism is the ma-
jor component of the transformer encoder. In the
proposed technique, the transformer perceives the en-
coded representation of the input in the form of a se-
quence vector. Skeleton features are used to encode
the input.
Shape = [S, N, D] (9)
In this case, S represents the sequence dimension
number of each frame in the video, N represents the
stack of multiple videos into a batch, and D represents
the vector dimension, 512 in this case. The multi-
Figure 7: Multi-Head Transformer encoder.
head mechanism processes scaled dot-product atten-
tion numerous times in parallel rather than just once.
The encoder generates an attention-based representa-
tion, which can locate a single piece of data within an
infinitely large context by concatenating and linearly
converting the separate attention outputs.
MultiHead(Q, K, V) = [ head
1
;. . . ; head
h
]W
O
(10)
where head
i
= Attention
QW
Q
i
, KW
K
i
, VW
V
i
(11)
where W
Q
i
, W
K
i
, W
V
i
, and W
O
(12)
2.4 Linear Transformation Layer
In addition to the multiheaded transformer encoder, a
linear transformation layer is applied to the skeleton
regression to predict the output.
3 EXPERIMENTATION AND
RESULTS
3.1 Datasets
The UR-FALL (Alarifi and Alwadain, 2021) and UP-
FALL (Mart
´
ınez-Villase
˜
nor et al., 2019a) datasets are
Human Fall Detection from Sequences of Skeleton Features using Vision Transformer
595
used in this research. Due to varying lighting condi-
tions, occlusion and the size of the dataset, the UR-
Fall dataset is challenging. This dataset is not of
real events but comprises actors performing every-
day activities and falling. It contains 70 sequences
(30 falls and 40 daily life activities). The dataset was
captured using two Microsoft Kinect cameras and an
accelerometer. The UP-FALL dataset is also pub-
licly available and contains 11 activities and different
stages in falls on three of those activities. Both of the
datasets have a frame rate of 25 frames per second,
and the resolution is 320×240 pixels.
3.2 Experimental Setup
The proposed approach is trained and tested on a Core
i7 machine equipped with an NVIDIA Quadro P5000
GPU. The extracted skeletons have 33 joints per hu-
man body and the Pytorch framework is used for the
implementation.
3.3 Results and Discussion
In the proposed approach, skeleton poses are ap-
plied to detect and distinguish between falling and not
falling activities. RP normalization with interpolation
is used to detect missing key points, and it provides
better results than those from the method without nor-
malization and interpolation. Table 3 shows accuracy,
precision, recall, and F1 score without normalization,
min-max normalization, and RP normalization with
interpolation for UR-FALL. In this case, linear inter-
polation + RP normalization increased accuracy, pre-
cision, and F1 score to 96.12%, 96.05%, and 96.04%
respectively.
The proposed approach is also used on the UP-
Fall dataset which gives slightly better results as
compared to the UR-Fall dataset because UR-Fall
dataset include two type of fall sitting from chair
and standing other activities are sitting crouching
down,sitting.On the other hand UP-Fall dataset has
more fall types which include forward using knees
forward,backwards sitting forward using hands other
activities are sitting,picking up an object,jumping lay-
ing,walking,standing and kneel down. Table 4 shows
accuracy, precision, recall, and F1 score without nor-
malization, min-max normalization, and RP normal-
ization with interpolation for UP-FALL. It shows
improvements in accuracy, recall and F1-score to
97.36%, 97.15% and 96.47% respectively.
Figure 9 shows the confusion matrices of all
falls and everyday normal events using different pro-
cesses. For UR-Fall without normalization, accuracy
is 94.87% and after min-max normalization accuracy
Figure 8: Confusion Matrices UR-FALL.
Figure 9: Confusion Matrices UP-FALL.
increases to 95.13% and after RP normalization there
is another small increase to 95.51% and after lin-
ear interpolation and RP normalization accuracy is
higher, 96.12%, as compared to the other methods.
Figure 10 illustrates a prediction of a fall and a daily
life normal activities where Figure 10a shows a ex-
ample of the detection of a human fall and Figure 10b
shows an example of a detection of a normal daily life
activity such as walking.
3.4 Comparison with Existing Work
In Table 4 , fall detection approaches are compared to
other reports in the literature . Chhetr et. al.(Chhetri
et al., 2021a) use a CNN method to detect human
falls. This method was reported to be 95% accurate
on the UR-Fall dataset, which is less accurate than
our method. A multiheaded transformer encoder with
RP normalization and interpolation is used in our pro-
posed approach to estimate human poses from skele-
ton sequences. In comparison with the state of the art
method, this method produces better accuracy results
of 96.12 percent in the UR-Fall dataset and 97.36 per-
cent in the UP-FALL dataset.
VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications
596
Table 2: Evaluation results for the proposed method on UR-FALL Dataset.
Evaluation
Measures
%
No
Normalization
%
Min-Max
Normalization
%
RP
Normalization
%
Linear Interpolation
+RP Normalization
%
Accuracy 94.87 95.13 95.51 96.12
Precision 95.24 94.76 95.83 96.05
Recall 94.40 95.04 96.08 95.09
F1-score 94.82 95.01 95.57 96.04
Table 3: Evaluation results for the proposed method on UP-FALL Dataset.
Evaluation
Measures
%
No
Normalization
%
Min-Max
Normalization
%
RP
Normalization
%
Linear Interpolation
+RP Normalization
%
Accuracy 95.89 96.52 96.98 97.36
Precision 95.54 96.30 96.70 96.61
Recall 95.38 96.00 96.70 97.15
F1-score 95.47 96.15 96.26 96.47
Table 4: Comparison with other methods.
Methods Dataset Methodology
Skeleton
Sequence
Accuracy
%
(Chhetri et al., 2021a)
UR-Fall CNN Yes 95.00
(Chen and Duan, 2021)
UR-Fall NanoDet-Lite X 91.2
(Sultana et al., 2021)
UR-Fall CNN X 94.00
(Leite et al., 2021)
UR-Fall CNN-SVM X 94.96
(Mart
´
ınez-Villase
˜
nor et al., 2019a). UP-Fall
RF,SVM
MLP,KNN
Yes
32.33,34.40
27.08,34.03
(Yin et al., 2021b)
UR-Fall SVM Yes 91.07
(Mart
´
ınez-Villase
˜
nor et al., 2019b)
UP-Fall MLP,CNN X 95.0 ,95.1
Our Proposed UR-Fall
Multiheaded
Vision Transformer
Yes 96.12
Our Proposed UP-Fall
Multiheaded
Vision Transformer
Yes 97.36
Figure 10: Prediction results (a) corresponds to a human fall
sequence and (b) a normal sequence.
4 CONCLUSIONS
This paper has presented a computer vision-based fall
detection method using a vision transformer. A multi-
headed transformer uses skeletons to provide the de-
sired prediction. A multiheaded transformer encoder
network is used to model how a person falls based
on a human skeleton feature vector. Missing joint
points are addressed using min-max normalization,
RP normalization, and instate-of-the-artpared to the
work that has been done so far for the detection of hu-
man falls, we achieved state-of-the-art results. Future
work is planned to use Le2i for training and testing the
proposed network. We also plan to extend the work to
realistic (not acted out) environments including multi-
ple people, like shopping malls, public places, homes,
etc. Implementing an edge platform for real-time pro-
cessing is also in the future pipeline.
REFERENCES
Alarifi, A. and Alwadain, A. (2021). Killer heuristic op-
timized convolution neural network-based fall detec-
tion with wearable iot sensor devices. Measurement,
167:108258.
Berlin, S. J. and John, M. (2021). Vision based human fall
detection with siamese convolutional neural networks.
Journal of Ambient Intelligence and Humanized Com-
puting, pages 1–12.
Human Fall Detection from Sequences of Skeleton Features using Vision Transformer
597
Cai, X., Liu, X., An, M., and Han, G. (2021). Vision-based
fall detection using dense block with multi-channel
convolutional fusion strategy. IEEE Access, 9:18318–
18325.
Chang, W.-J., Hsu, C.-H., and Chen, L.-B. (2021). A pose
estimation-based fall detection methodology using ar-
tificial intelligence edge computing. IEEE Access,
9:129965–129976.
Chen, G. and Duan, X. (2021). Vision-based elderly fall
detection algorithm for mobile robot. In 2021 IEEE
4th International Conference on Electronics Technol-
ogy (ICET), pages 1197–1202. IEEE.
Chhetri, S., Alsadoon, A., Al-Dala’in, T., Prasad, P.,
Rashid, T. A., and Maag, A. (2021a). Deep learn-
ing for vision-based fall detection system: Enhanced
optical dynamic flow. Computational Intelligence,
37(1):578–595.
Chhetri, S., Alsadoon, A., Al-Dala’in, T., Prasad, P.,
Rashid, T. A., and Maag, A. (2021b). Deep learn-
ing for vision-based fall detection system: Enhanced
optical dynamic flow. Computational Intelligence,
37(1):578–595.
Dentamaro, V., Impedovo, D., and Pirlo, G. (2021). Fall de-
tection by human pose estimation and kinematic the-
ory. In 2020 25th International Conference on Pattern
Recognition (ICPR), pages 2328–2335. IEEE.
Galv
˜
ao, Y. M., Portela, L., Ferreira, J., Barros, P., Fagun-
des, O. A. D. A., and Fernandes, B. J. (2021). A
framework for anomaly identification applied on fall
detection. IEEE Access, 9:77264–77274.
Guan, Z., Li, S., Cheng, Y., Man, C., Mao, W., Wong, N.,
and Yu, H. (2021). A video-based fall detection net-
work by spatio-temporal joint-point model on edge
devices. In 2021 Design, Automation & Test in Eu-
rope Conference & Exhibition (DATE), pages 422–
427. IEEE.
Kang, Y., Kang, H., and Kim, J. (2021a). Fall detection
method based on pose estimation using gru. In Inter-
national Conference on Software Engineering, Artifi-
cial Intelligence, Networking and Parallel/Distributed
Computing, pages 169–179. Springer.
Kang, Y. K., Kang, H. Y., and Weon, D. S. (2021b). Hu-
man skeleton keypoints based fall detection using gru.
Journal of the Korea Academia-Industrial Coopera-
tion Society, 22(2):127–133.
Keskes, O. and Noumeir, R. (2021). Vision-based fall de-
tection using st-gcn. IEEE Access, 9:28224–28236.
Leite, G. V., da Silva, G. P., and Pedrini, H. (2021). Three-
stream convolutional neural network for human fall
detection. In Deep Learning Applications, Volume 2,
pages 49–80. Springer.
Lin, C.-B., Dong, Z., Kuan, W.-K., and Huang, Y.-F.
(2020). A framework for fall detection based on open-
pose skeleton and lstm/gru models. Applied Sciences,
11(1):329.
Liu, C., Lv, J., Zhao, X., Li, Z., Yan, Z., and Shi, X.
(2021). A novel key point trajectory model for fall
detection from rgb-d videos. In 2021 IEEE 24th Inter-
national Conference on Computer Supported Coop-
erative Work in Design (CSCWD), pages 1021–1026.
IEEE.
Mart
´
ınez-Villase
˜
nor, L., Ponce, H., Brieva, J., Moya-Albor,
E., N
´
u
˜
nez-Mart
´
ınez, J., and Pe
˜
nafort-Asturiano, C.
(2019a). Up-fall detection dataset: A multimodal ap-
proach. Sensors, 19(9):1988.
Mart
´
ınez-Villase
˜
nor, L., Ponce, H., Brieva, J., Moya-Albor,
E., N
´
u
˜
nez-Mart
´
ınez, J., and Pe
˜
nafort-Asturiano, C.
(2019b). Up-fall detection dataset: A multimodal ap-
proach. Sensors, 19(9):1988.
Nguyen, V. D., Pham, P. N., Nguyen, X. B., Tran, T. M., and
Nguyen, M. Q. (2021). Incorporation of panoramic
view in fall detection using omnidirectional camera.
In The International Conference on Intelligent Sys-
tems & Networks, pages 313–318. Springer.
Organization, W. H., Ageing, W. H. O., and Unit, L. C.
(2008). WHO global report on falls prevention in
older age. World Health Organization.
Ramirez, H., Velastin, S. A., Fabregas, E., Meza, I., Makris,
D., and Farias, G. (2021a). Fall detection using human
skeleton features.
Ramirez, H., Velastin, S. A., Meza, I., Fabregas, E., Makris,
D., and Farias, G. (2021b). Fall detection and activ-
ity recognition using human skeleton features. IEEE
Access, 9:33532–33542.
Sultana, A., Deb, K., Dhar, P. K., and Koshiba, T. (2021).
Classification of indoor human fall events using deep
learning. Entropy, 23(3):328.
Tran, T.-H., Nguyen, D. T., and Nguyen, T. P. (2021). Hu-
man posture classification from multiple viewpoints
and application for fall detection. In 2020 IEEE
Eighth International Conference on Communications
and Electronics (ICCE), pages 262–267. IEEE.
Wang, K., Li, X., Yang, J., Wu, J., and Li, R. (2021).
Temporal action detection based on two-stream you
only look once network for elderly care service robot.
International Journal of Advanced Robotic Systems,
18(4):17298814211038342.
Yin, J., Han, J., Xie, R., Wang, C., Duan, X., Rong, Y.,
Zeng, X., and Tao, J. (2021a). Mc-lstm: Real-time 3d
human action detection system for intelligent health-
care applications. IEEE Transactions on Biomedical
Circuits and Systems, 15(2):259–269.
Yin, J., Han, J., Xie, R., Wang, C., Duan, X., Rong, Y.,
Zeng, X., and Tao, J. (2021b). Mc-lstm: Real-time 3d
human action detection system for intelligent health-
care applications. IEEE Transactions on Biomedical
Circuits and Systems, 15(2):259–269.
Zhu, N., Zhao, G., Zhang, X., and Jin, Z. (2021). Falling
motion detection algorithm based on deep learning.
IET Image Processing.
VISAPP 2023 - 18th International Conference on Computer Vision Theory and Applications
598
