Automating XSS Vulnerability Testing Using Reinforcement Learning

Kento Hasegawa

, Seira Hidano and Kazuhide Fukushima

KDDI Research, Inc., 2-1-15, Ohara, Fujimino, Saitama, Japan

Keywords:

Cross-Site Scripting, Reinforcement Learning, Vulnerability Testing.

Abstract:

Cross-site scripting (XSS) is a frequently exploited vulnerability in web applications. Existing XSS testing

tools utilize a brute-force or heuristic approach to discover vulnerabilities, which increases the testing time

and load of the target system. Reinforcement learning (RL) is expected to decrease the burden on humans and

enhance the efﬁciency of the testing task. This paper proposes a method to automate XSS vulnerability testing

using RL. RL is employed to obtain an efﬁcient policy to compose test strings for XSS vulnerabilities. Based

on an observed state, an agent composes a test string that exploits an XSS vulnerability and passes the string to

a target web page. A training environment XSS Gym is developed to provide a variety of XSS vulnerabilities

during training. The proposed method signiﬁcantly decreases the number of requests to the target web page

during the testing process by acquiring an efﬁcient policy with RL. Experimental results demonstrate that the

proposed method effectively discovers XSS vulnerabilities with the fewest requests compared to the existing

open-source tools.

1 INTRODUCTION

Since recent computer systems have become more

complicated, security protection is a growing con-

cern. The cyber-space attacks are also becoming more

sophisticated, and the defense of computer systems

must be enhanced. From the defender’s viewpoint,

reinforcement learning (RL) is expected to provide

the opportunity for prior vulnerability testing (Song

and Alves-Foss, 2015; Avgerinos et al., 2018). Thus,

applying RL to cybersecurity, such as autonomous at-

tacks and vulnerability detection, has emerged as a

key research topic in recent years (Meyer et al., 2021;

Nguyen and Reddi, 2021).

In this paper, we focus on vulnerability testing

in network-attached devices. A well-known vulner-

ability is cross-site scripting (XSS), which is recog-

nized as one of the most frequent threats (OWASP

Top 10 team, 2021). XSS vulnerabilities allow attack-

ers to execute malicious scripts on the web application

of unsuspecting users by improperly handling exter-

nal input strings. Existing XSS vulnerability testing

tools utilize brute-force or heuristic methods based on

known attack patterns, which increases the number of

requests to the target web page, thus increasing the

testing time and load on the web server. Consider-

https://orcid.org/0000-0002-6517-1703

https://orcid.org/0000-0003-2571-0116

ing the increase in network-attached devices, such as

IoT devices with limited computational resources, an

efﬁcient vulnerability testing method must be estab-

lished.

This paper proposes a method to automate XSS

vulnerability testing using RL to understand the na-

ture of autonomous attacks. Here, an autonomous at-

tack represents that a policy in an RL agent is trained

using a training environment to select an efﬁcient

attacking action that is adapted to a target environ-

ment. The proposed method composes a test string

that exploits a vulnerability by combining known at-

tack string fragments used in XSS attacks and state

observation by parsing the source code of the target

web page. RL is employed to obtain an efﬁcient pol-

icy to autonomously compose the test string without

human intervention. The experimental results demon-

strate that the proposed method can discover vulnera-

bilities with the fewest requests compared to existing

open-source tools.

The contributions of the paper can be summarized

as follows:

• We deﬁne state observations by parsing the source

code of a target web page, agent actions by the

string combination, and reward by the current

state observation to implement an XSS vulnera-

bility testing method using RL.

• Based on the state, action, and reward, we propose

Hasegawa, K., Hidano, S. and Fukushima, K.

Automating XSS Vulnerability Testing Using Reinforcement Learning.

DOI: 10.5220/0011653600003405

In Proceedings of the 9th International Conference on Information Systems Security and Privacy (ICISSP 2023), pages 70-80

ISBN: 978-989-758-624-8; ISSN: 2184-4356

 2023 by SCITEPRESS – Science and Technology Publications, Lda. Under CC license (CC BY-NC-ND 4.0)

an XSS vulnerability testing method using RL.

• We develop a training environment called XSS

Gym that randomly provides vulnerable web

pages based on pre-deﬁned templates and param-

eters. XSS Gym facilitates the RL agent to experi-

ence a large number of XSS vulnerability patterns

compared to manually setting up static vulnerable

pages.

• We experimentally demonstrate that the proposed

method discovers XSS vulnerabilities with the

fewest requests compared to existing open-source

tools.

2 BACKGROUND

This section presents the background of RL and XSS

vulnerabilities.

2.1 Reinforcement Learning (RL)

RL represents an algorithm aimed at obtaining the

optimal policy by maximizing the expected reward

passed from the environment. The environment is

often modeled as a Markov decision process (MDP),

which is deﬁned using the following elements:

• state space S that the environment can take;

• action space A, including all actions that the agent

can perform;

• state transition function P : S × A × S → [0, 1],

which is the probability of transition to state s

t+1

when action a

is performed in state s

at time t;

• immediate reward function R : S × A → R;

• reward discount factor γ ∈ [0,1].

π(a | s) is the policy in which action a can be per-

formed in state s. The goal of RL is to maximize the

expected discount cumulative reward under policy π

through the interaction of the environment and agent.

2.2 Cross-Site Scripting (XSS)

XSS is a vulnerability in a web application in which a

malicious script can be injected into the web applica-

tion, and the vulnerability allows attackers to execute

the malicious script on the web application. An at-

tacker exploits the XSS vulnerabilities to execute an

arbitrary script, payload, on the system of the web ap-

plication users and may steal conﬁdential information

or perform malicious actions unintentionally.

<textarea>__USER_INPUT__</textarea>

<textarea></textarea><script>alert(1);</script></textarea>

(a) Response when the user input is “__USER_INPUT__.”

(b) Response in which a JavaScript code can be executed due to the XSS vulnerability.

Figure 1: Example of an XSS attack.

Figure 1 shows an example of the XSS attack.

Figure 1 (a) shows the response of a web applica-

tion when the user input is ‘__USER_INPUT__.’ Fig-

ure 1 (b) shows the attack case: a malicious attacker

inputs the underlined red string, which is a JavaScript

code with a closing tag of textarea. The closing

tag of textarea at the beginning of the input string

closes the textarea context, and the next script tag

is valid as an HTML code. Thus, the JavaScript code,

‘alert(1);’ is executed in the web application. Such

an input string to a web application can be passed as

the parameter of a GET request or payload of a POST

request. Suppose an attacker embeds a malicious code

into a URL as a GET parameter and distributes the

URL. In this case, a user who accesses the URL will

execute the malicious code injected into the web ap-

plication.

XSS is classiﬁed into three types: reﬂected,

stored, and DOM-based. In reﬂected XSS, a part of

an input string is directly reﬂected on a web server

output. In stored XSS, the input string is provided

to the web application and stored, for instance, in a

database. DOM-based XSS is the case in which the

input string is directly reﬂected on the content with-

out being passed through the web server. The nature

of the XSS vulnerability is the same across the three

types. This paper focuses on reﬂected and DOM-

based XSS attacks because the test strings are imme-

diately reﬂected on target applications.

Although XSS attacks can be prevented by a san-

itization process for the input queries, vulnerability

may remain due to the lack of security awareness or

potential bugs in external software libraries. A web

application ﬁrewall (WAF) can protect a web applica-

tion from several XSS attacks. However, WAF protec-

tion cannot address DOM-based attacks, and the pro-

cessing of WAF service may be heavy for resource-

limited devices. Therefore, vulnerability testing be-

fore deployment is required.

2.3 Autonomous Attack Using RL

Existing XSS vulnerability testing tools often adopt

a brute-force or heuristic approach to check whether

an attack string exploits the vulnerability. The brute-

force approach can exhaustively examine the vulnera-

bility, but the load on the web server and testing time

may increase. Although the impact on the server load

Automating XSS Vulnerability Testing Using Reinforcement Learning

may be negligible in the case of recently developed

high-performance web servers, the load is signiﬁcant

for IoT devices with web interfaces to conﬁgure the

device and monitor the sensors. Such web interfaces

may be vulnerable to XSS attacks because of the low

cost and low performance of devices. In this situa-

tion, vulnerability testing with numerous requests is

impractical. Thus, it is necessary to decrease the load

on the devices and testing time.

Autonomous attack methods have been recently

studied (Zennaro and Erdodi, 2020; Erdödi and Zen-

naro, 2022; Erdödi et al., 2021; Caturano et al., 2021;

Demetrio et al., 2020). These methods try to access

hidden ﬁles that can be recognized from the URLs

speciﬁc to open-source or popular web applications,

exploit vulnerabilities of the target system, or launch

SQL injection attacks. Furthermore, RL can be ap-

plied for penetration testing on network systems (Hu

et al., 2020; Bland et al., 2020; Chowdary et al., 2020;

Ghanem and Chen, 2020).

In (Frempong et al., 2021), an automated exploit

generation method for a JavaScript XSS vulnerability,

called HIJaX, is proposed. Although HIJaX can gen-

erate various XSS attack codes, the algorithm does

not consider ﬁlter evasion that is adapted to the web

page being inspected.

In (Caturano et al., 2021), a reﬂected-XSS attack

method by crafting attack strings using RL is pro-

posed. This method divides an attack string into ﬁve

sections, and a list of attack string fragments is com-

posed based on known attack strings. The Q-learning

algorithm obtains the policy to compose the appro-

priate attack string for the target web application by

combining the attack string fragments in the ﬁve sec-

tions. In (Caturano et al., 2021), the number of re-

quests to detect reﬂected-XSS vulnerabilities is sig-

niﬁcantly smaller than that in the existing open-source

tools for XSS testing. However, human interaction is

required to observe the state during training because

the method is based on the human-in-the-loop tech-

nique. Therefore, a person with expert knowledge of

XSS is necessary. These problems must be solved to

realize completely autonomous testing.

Our Goal: Our goal is to automate XSS vulnerability

testing with a few attempts such that defenders can

test their web applications efﬁciently without expert

knowledge. RL can be used to compose test strings

autonomously and efﬁciently. However, the settings

for an RL agent and preparation of the training envi-

ronment are the problems. In this paper, we propose

a method to automate XSS vulnerability testing and a

training environment.

3 PROPOSED METHOD

This section presents a method to automate XSS vul-

nerability testing using RL.

3.1 Overview

We establish an XSS vulnerability testing method us-

ing RL. The proposed method uses RL to obtain an

efﬁcient policy to compose test strings autonomously

through string-combining operations and state obser-

vations based on the parsing of web pages.

Attackers must add strings before and after the

payload such that the payload is reﬂected in a web

application content as an executable script. Then,

the payload becomes executable, and the XSS attack

succeeds. We deﬁne the complete string obtained

through such an operation as the test string.

As mentioned in Section 2.1, the RL algorithm

can obtain the optimal policy π in the environment

that follows a Markov decision process or can approx-

imate it. Therefore, it is necessary to determine the

action A, state S, and reward r to obtain an efﬁcient

policy. This paper deﬁnes these items as follows (de-

tails are presented in the following sections):

• a ∈ A: an operation of composing a test string.

• s ∈ S : a parser state for the payload string.

• r: determined based on the number of steps re-

quired to achieve the goal.

Figure 2 shows an overview of the proposed method.

The action selection, state observation, and reward ac-

quisition are repeatedly performed between the agent

and environment (Section 3.2, Section 3.3, and Sec-

tion 3.4). The agent implements RL and involves the

policy that determines the next action based on the

current state (Section 3.5). The environment is the

target web application to be tested. A training envi-

ronment, called XSS Gym, is proposed in Section 3.6.

The proposed method aims to acquire an efﬁcient pol-

icy to compose the test string that successfully ex-

ploits XSS vulnerability.

3.2 Action

The key task in the proposed method is the composi-

tion of the test string by adding strings before and af-

ter the payload script. First, the test string is split into

four sections. Next, the operations on the sections are

deﬁned as actions to compose the test string.

3.2.1 Sections of a Test String

The test string is split into four sections to simplify

the composition of a test string.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

Environment (Target web application)

<div> alert(1); </div>

Test string:

[Section 3.6] Training Environment

Agent (Test string composition)

alert(1);

Payload

PreString

*/</style>, -->,

'>, ">, </script>

PrePayload

javascript:,

onerror='

</script>

PostPayload

;/*, ;//, ", ‘,

[Section 3.5]

Algorithm using RL

Parse

Concatenate

[Section 3.3] State 



：Data state

[Section 3.4] Reward 



：



[Section 3.2] Action 



(iii, (<script>, </script>))

(Output content)

<div> alert(1); </div>

(Test string)

alert(1);

Output content:

Figure 2: Overview of the proposed method.

</textarea> <script> alert(1); </script>

PreString PrePayload

Payload PostPayload

Test string: </textarea><script>alert(1);</script>

Split into four sections.

Figure 3: Sections of a test string.

1. PreString: The string in this section closes the

previous context.

2. PrePayload: The string in this section starts the

new context for rendering the payload executable.

3. Payload: The string in this section is an arbitrary

script to be executed on the web application.

4. PostPayload: The string in this section closes the

context of the payload.

Figure 3 shows an example of a test string and its sec-

tions. In the test string, ‘alert(1);’ is the payload

script, which belongs to the Payload section. The

script tag encloses the payload script. According

to the section deﬁnitions, the starting tag ‘<script>’

belongs to the PrePayload section, and the closing tag

‘</script>’ belongs to the PostPayload section. The

ﬁrst piece of the test string ‘</textarea>’ closes the

textarea context that is originally displayed by the

web application and belongs to the PreString section.

3.2.2 Components of an Action

The operations on the four sections are deﬁned as ac-

tions to compose the test string. An action a ∈ A is

deﬁned as the tuple (target, content). The target ele-

ment shows the target section to be operated on. The

content element shows the content of the operation.

The remaining section describes the target and con-

tent elements.

Target of an Action. In terms of the target of an ac-

tion, this paper deﬁnes ﬁve targets based on the four

sections introduced above. Because an attacker ar-

bitrarily determines the script of the Payload section,

our algorithm does not change this section. Other sec-

tions, a pair of sections, and the whole string are the

targets for the actions.

1. Target 1: PreString: The action targeting this

section closes the previous context and changes

the context of the following sections.

2. Target 2: PrePayload: The action targeting this

section changes the current context to the new

context for the Payload section.

3. Target 3: PrePayload and PostPayload: The ac-

tion targeting these sections encloses the Payload

section with a speciﬁed tag and can change to a

different context with only one operation.

4. Target 4: PostPayload: The action targeting this

section closes the context of the Payload section.

5. Target 5: Whole String: This action converts

(e.g., encodes) the whole string.

Targets 1, 2, and 4 focus on the PreString, PrePay-

load, and PostPayload sections, respectively. Tar-

Automating XSS Vulnerability Testing Using Reinforcement Learning

get 3 simultaneously focuses on the PrePayload and

PostPayload sections. It is useful to consider that a

pair of sections are simultaneously changed because

the PrePayload and PostPayload sections often corre-

lated according to the known test strings for XSS vul-

nerabilities. For example, when we wish to enclose

the Payload section with the script tag, it is neces-

sary to set ‘<script>’ for the PrePayload section and

‘</script>’ for the PostPayload section. Target 5

corresponds to the conversion of the whole text, such

as changing the text encoding to another one. The

text encoding can be changed to fake the XSS detec-

tor and is effective in evading the pattern-matching

mechanism.

Content of an Action. In terms of the content of

action, a test string can be composed by replacing the

string in the speciﬁed section(s) with another string.

The string in the target section deﬁned in the previous

section is replaced with another string. To prepare the

strings to be placed in each section, the string frag-

ments are collected from the known test strings, and

the string fragment list is generated. The string frag-

ment list stores string fragments and their correspond-

ing targets. The string fragments include null strings

for each section to remove the string in a target.

Another operation is converting the string in the

target section(s) to the speciﬁed encoding method.

For example, the UTF-7 encoding expresses the char-

acter ‘<’ and ‘>’ as ‘+ADw-’ and ‘+AD4-’, respectively.

Thus, the starting tag of the script context ‘<script>’

is converted to ‘+AD-script+AD4-.’ Therefore, pat-

tern matching protection can be evaded by this con-

version. Although this exploit does not work for mod-

ern web browsers with an ordinal situation, several

old systems might still be vulnerable.

3.2.3 Action Space

An action in the action space is represented by the

tuple of the target and content, as discussed. The ac-

tion space is constructed before the training based on

a training dataset.

3.3 State

The state deﬁnition is of signiﬁcance to efﬁciently ob-

tain an optimal policy by RL. It is desirable to be able

to mechanically represent the state of the source code

of a web page. This paper introduces the parsing of

the source code to represent states. Furthermore, the

states are deﬁned to efﬁciently estimate the reward

discussed later.

3.3.1 State Deﬁnition Based on Parsing

In the proposed method, the source code obtained as

a response from the target web application is parsed.

Through parsing, the state of the payload script (the

string in the Payload section) is observed for RL.

Table 1 shows examples of the parsing states for

the payload script, ‘alert(1);.’ The second column

lists the responses from a web server, and the third

column lists the states of the payload script (the fourth

column is introduced later). In this table, we refer to

the HTML5 speciﬁcation (WHATWG, ) to recognize

the state.

In row (a), the user’s input is reﬂected inside the

div tag in the response. The div tags are often used

to divide the sections of the contents on the web page.

According to the HTML5 speciﬁcation, the string di-

rectly inside the div tag is identiﬁed as ‘Data state.’

The string at ‘Data state’ is displayed as text and is

not executable.

In row (b), the user’s input is reﬂected inside the

textarea tag in the response. The textarea tags

are used to provide an input box that accepts multi-

line strings from users. The string directly inside the

textarea tag is identiﬁed as the ‘RCDATA state’ ac-

cording to the HTML5 speciﬁcation. The string at

the ‘RCDATA state’ is displayed as text and is not

executable. In contrast to those in the ‘Data state,’

the ‘RCDATA state’ strings are no longer parsed as

an HTML code until the end of the ‘RCDATA state,’

whereas HTML tags inside the ‘Data state’ strings are

recognized. Therefore, even if the user’s input con-

tains the script tag with a payload script, it is dis-

played inside the textarea tag.

In row (c), the user’s input is reﬂected inside the

script tag in the response. The string directly inside

the script tag is identiﬁed as the ‘Script data state.’

The string at the ‘Script data state’ is executable as a

script on the web application. Therefore, if a mali-

cious script is included in the user’s input and iden-

tiﬁed as ‘Script data state,’ it is unintentionally exe-

cuted by the user.

As described, the parser state can help identify

whether the payload script is executable or not. In

the proposed method, the parser state is observed and

used as a state for RL. A simple method to realize

autonomous XSS vulnerability testing is to generate

a test string that actually exploits an XSS vulnerabil-

ity. Thus, we aim to ensure that the payload string is

executable as a script.

3.3.2 State Sets

To systematically consider the parser states, they are

classiﬁed into sets based on the steps to the state at

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

Table 1: Examples of states.

Response State of alert(1); State set Executable? Reward

(a) <div>alert(1);</div> Data state S

prepare

(b) <textarea>alert(1);</textarea> RCDATA state S

other

= S

X r

goal

which the payload script is executable.

As mentioned, our goal is to ensure that the pay-

load string is in the state in which the string is exe-

cutable. This state, known as the goal state, is deﬁned

as follows:

Deﬁnition 1 (Goal State). S

is a set of goal states

that are parser states in which a string is executable

as a script on the web application.

Hereafter, our goal is to ensure that the payload

string is in a set of goal states S

Next, the parser states other than the goal states

are classiﬁed. When the proposed method composes

a test string, it is helpful to estimate how many steps

are needed to achieve one of the goal states.

Deﬁnition 2 (Distance to the Goal State). S

is a set

of states whose steps to any goal state are d. Here,

= S

and s

∈ S

. s

∈ S

is recursively deﬁned as

follows:

• s is a state, and goal state s

∈ S

is reached after

action a is applied from s. If s /∈ S

, the number of

steps to any goal state d is 1, and s is an element

of S

, s

,d = 1).

• s is a state, and state s

∈ S

is reached after ac-

tion a is applied from s. If s /∈ S

,0 ≤ i ≤ n, the

number of steps to any goal state d is n +1, and s

is an element of S

n+1

, s

n+1

,d = n + 1).

The fourth column in Table 1 shows the steps to any

goal state. The ‘Data state’ in row (a) is catego-

rized as S

because enclosing the payload script with

a script tag renders the script executable. The ‘RC-

DATA state’ in row (b) is categorized as S

. In the

‘RCDATA state,’ even if the payload script is enclosed

with a script tag, the script does not become ex-

ecutable. The textarea context must be closed to

render the script executable. Since the operation in-

volves two steps, the ‘RCDATA state’ is categorized

as S

. The ‘Script data state’ in row (c) is categorized

as S

(i.e., S

) because the script has already been ex-

ecutable, as shown in the ﬁfth column.

3.4 Reward

As described in the previous section, the state sets are

deﬁned based on the steps to the goal state. It is help-

ful to estimate the step to the goal state. In this sec-

tion, the reward for RL is deﬁned based on the state

sets.

The reward types are deﬁned as follows:

• r

goal

: reward when the environment achieves any

goal state s

∈ S

• r

prepare

: reward when the environment achieves

state s

∈ S

where the minimum number of steps

to any goal state is 1.

• r

other

: reward when the environment achieves

state s

∈ S

,i ≥ 2 where at least two steps are re-

quired to achieve any goal state.

Real values are assigned to the rewards. The relation-

ship between the rewards is deﬁned as follows:

goal

> r

prepare

> r

other

(1)

The reward values used in the experiment are shown

in Section 4.

The simplest way to determine the reward is to

assign a reward only if an attack actually exploits a

vulnerability. However, many test strings must be

considered until any XSS vulnerability is exploited.

Therefore, this paper considers the state sets deﬁned

in the previous section to determine the reward efﬁ-

ciently. Table 1 lists the examples of the relationship

between the state and reward. Row (a) is the ‘Data

state’ that is categorized as S

. This state requires

only one step to a goal state. As shown in the sixth

column, the reward becomes r

prepare

, according to the

deﬁnition. Similarly, the rewards of rows (b) and (c)

are determined as r

other

and r

goal

, respectively.

3.5 Agent

An agent can be enhanced to search for an optimal

policy by applying the two mechanisms.

One mechanism is an LSTM-based policy. As

mentioned in Section 2.1, an environment is often

modeled as MDP for RL. Although the observation

states are carefully set up, completely observing the

internal state of an environment is difﬁcult. A par-

tially observable MDP (POMDP), in which an agent

can observe a part of an actual internal state, can

be employed in security. In a POMDP, an observa-

tion implies several states probabilistically. Since the

probabilities can be estimated based on the trajectory

Automating XSS Vulnerability Testing Using Reinforcement Learning

contents:

html_href:

variables:

quote: ["", "'", '"']

content:

(a) Configuration for XSS Gym (YAML format).

XSS Gym

<body>

<p>Vulnerable Page</p>

</body>

Load configurations

Generate contents randomly

Figure 4: Example of XSS Gym.

of observations, an LSTM-based policy is used to pre-

dict the current internal state.

The second mechanism is an intrinsic curiosity

module (ICM) (Pathak et al., 2017). The module

makes the agent explore unpredicted responses from

the environment. We compare the training results

with or without the ICM in Section 4.

3.6 Training Environment: XSS Gym

We propose a training environment for XSS vulner-

ability testing, called XSS Gym, to effectively learn

various XSS vulnerabilities.

The training environment must behave in a man-

ner that mimics real-world web applications. How-

ever, the training web applications for security begin-

ners provide only a limited number of vulnerable web

pages. To solve the problem, XSS Gym provides var-

ious web pages that are randomly conﬁgured based

on several templates and parameters. First, a set T of

web page templates in which a given string is shown

as a content is prepared. Each template τ ∈ T has

several parameters P

. Figure 4 shows an example

of XSS Gym. Figure 4 (a) shows a conﬁguration for

XSS Gym that is described in a YAML format. In the

conﬁguration, ‘content’ shows a template τ, and ‘vari-

ables’ shows a list of parameters P

for the template

τ. In the example, the string __QUOTE__ in the tem-

plate is randomly replaced with either (no character),

’, or ". Then, a content is generated as shown in Fig-

ures 4 (b) and (c), in which __USER_INPUT__ in the

template is replaced with an user input ‘xxx.’

During the training of RL, XSS Gym continuously

provides web pages. At the beginning of an episode,

XSS Gym randomly chooses a template τ ∈ T and

conﬁgures the web page with parameters ρ ∈ P

. The

template and parameters are not changed during the

episode. The agent sends a signal to XSS Gym at the

beginning and end of the episode for cooperation.

To mimic the real-world situations in which an

XSS sanitization is partially applied, a set F of ﬁl-

ter conﬁgurations is also prepared. The web page be-

haves differently by randomly applying several vari-

ations of XSS ﬁlters, even if the content looks the

same.

3.7 Vulnerability Testing

The RL model is trained based on the action, state,

and reward. However, the introduced model does not

completely follow the Markov model. Speciﬁcally,

the transition function P is stochastic and not deter-

ministic because several web applications often ﬁlter

out test strings. This aspect must be considered to es-

tablish a vulnerability testing algorithm using RL.

Algorithm 1: XSS vulnerability testing.

Input: Trained model M , Environment E , Payload

string X

Output: Test string T

1: T ← X, H ←

0, s ← Initial state

2: while s /∈ S

3: L ← {(a, p) | p = π(a | s), a ∈ A} // Obtain

next actions and their probabilities from model

M .

4: Sort L with respect to p in descending order.

5: i ← 0, (a, p) ← L[i]

6: while (s,a) ∈ H and i < |L| do

7: i ← i + 1

8: (a, p) ← L[i]

9: end while

10: if i == |L| then

11: return null // Not found

12: end if

13: H ← H ∪ {(s, a)}

14: Perform action a and update T .

15: s ← Observe a state from environment E.

16: end while

17: return T

Before vulnerability testing, the agent learns the

training dataset and obtains a policy. Training can

be performed through the normal RL process. In the

training phase, an agent performs an action accord-

ing to the current policy and composes a test string.

The test string is provided to the target web appli-

cation, and the web application returns the response.

The agent observes the state of the payload string and

obtains the reward according to the state. This pro-

cess is repeated multiple times for various target web

pages. Finally, a model that obtains an efﬁcient policy

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

for composing a test string is established.

Algorithm 1 describes the process ﬂow for XSS

vulnerability testing. This algorithm repeatedly com-

poses a test string and attempts to exploit the vulner-

ability using the string. If an exploit is successful, the

algorithm returns the successful test string. If the al-

gorithm cannot ﬁnd the appropriate test string within

a speciﬁed number of iterations, the algorithm returns

null and notiﬁes the user that no XSS vulnerabilities

are discovered.

4 EVALUATION

This section describes the evaluation of the proposed

method using a vulnerable web application. As men-

tioned in Section 2, our goal is to automate XSS

vulnerability testing. The proposed method uses RL

to compose test strings autonomously and efﬁciently.

The experiments aim to answer the following research

questions:

RQ1: Does XSS Gym provides appropriate samples

for training an RL agent?

RQ2: Does the agent obtain an efﬁcient policy to

compose a test string?

4.1 Setup

The programs are implemented in Python.

PPO (Schulman et al., 2017) is applied as an

RL algorithm. In the experiments, we use the Ray

library to implement a PPO algorithm.

Training. We train RL agent using XSS Gym. The

template and parameters are prepared based on the

existing vulnerable web pages in WAVSEP (Chen,

2014) and Webseclab (Yahoo Inc., 2020). The pro-

gram and vulnerability testing tools run as Docker

containers and are connected via a virtual network.

We prepare four settings. Random uses XSS Gym

as a training environment and an LSTM network as

a policy network in RL. Weighted uses a weighted

version of XSS Gym, in which XSS Gym gives prior-

ity to providing the templates that have not yet been

selected or for which an agent takes a large num-

ber of requests in previous episodes. Random+ICM

(resp. Weighted+ICM) is conﬁgured based on Ran-

dom (resp. Weighted), but an ICM is employed when

exploration.

The model is trained for 100k steps with a batch

size of 1000 steps. The learning rate is 0.001, and

https://github.com/ray-project/ray

Table 2: Open-source tools used in the experiments.

Tool URL

XSpear https://github.com/hahwul/XSpear

XSSer https://github.com/epsylon/xsser

XSSMap https://github.com/Jewel591/xssmap

Wapiti https://github.com/wapiti-scanner/wapiti

w3af https://github.com/andresriancho/w3af

the GAE parameter in (Schulman et al., 2017) is 0.95.

Other parameters are set to the default settings of Ray.

For the reward values, we assign a positive value

to r

goal

and 0 to r

prepare

. r

other

is set to a negative value

that is decreased as the number of steps in an episode

increases.

Testing. Algorithm 1 is performed using the trained

model. Since the agent produces the same test string

several times in certain cases, we count the number

of unique requests during the evaluation. The open-

source tools that scan XSS vulnerabilities in web

pages are used in the experiments to conﬁrm that the

proposed method can obtain an efﬁcient policy. We

select the tools that are available online for free and

maintained in 2020 or later. Table 2 lists the tools

used in the experiments. We count the number of re-

quests until a vulnerability is detected.

We use 19 web pages in Webseclab (Yahoo Inc.,

2020), which contains several web pages vulnerable

to XSS, as target web pages.

4.2 Results

4.2.1 Training Using XSS Gym

To answer RQ1, we evaluate XSS Gym. We trained

the agent using XSS Gym. Figure 5 shows the suc-

cess rate of exploiting an XSS vulnerability on a tar-

get web page. The x-axis shows the episode num-

ber, and the y-axis shows the success rate during the

last 500 episodes. In Figure 5, all plots show a trend

of increasing success rate. In particular, Random

and Random+ICM slightly outperform the Weighted

(with and without ICM) settings. This is because the

agents with the weighted version of a training envi-

ronment train intuitively difﬁcult web pages to exploit

XSS vulnerabilities due to the weighting mechanism

of XSS Gym. In any case, the agent could improve

the success rates as the number of episodes increases.

From the results, XSS Gym provides appropriate vul-

nerable web pages for training an RL agent.

4.2.2 Evaluation on Vulnerable Web Pages

To answer RQ2, we evaluate the proposed method us-

ing the Webseclab pages. The Webseclab pages, all

Automating XSS Vulnerability Testing Using Reinforcement Learning

1000 2000 3000 4000 5000 6000 7000 8000

Episode

0.65

0.70

0.75

0.80

0.85

Success rate (mean)

Random

Weighted

Random+ICM

Weighted+ICM

Figure 5: Success rate when training.

Table 3: Average results of each setting (ﬁve trials).

Setting Requests (s.d.) Success rate

Random 160.0 (11.4) 0.853

Weighted 149.2 (25.1) 0.874

Random+ICM 175.2 (58.5) 0.863

Weighted+ICM 122.4 (16.7) 0.884

of which have XSS vulnerabilities, are tested with the

trained agent.

We evaluated the agents with four settings in Sec-

tion 4.1. We tried ﬁve trials with different random

seed numbers and obtained the averaged results. Ta-

ble 3 shows the averaged number of requests and suc-

cess rates to exploit the web pages in Webseclab. As

shown in Table 3, Weighted+ICM shows the fewest

requests and obtained the largest success rate in ex-

ploiting XSS vulnerabilities in the tested web page.

We focus on the agent setting with the best result

in the previous evaluation. Table 4 shows the target

pages accessed in the experiment and the unique num-

ber of requests with the Weighted+ICM setting. As

shown in Table 4, the agent exploits XSS vulnerabil-

ities in each page within 33 requests. The proposed

method requires less than ten requests for 16 pages to

detect the XSS vulnerability. The trained agent suc-

cessfully obtains an efﬁcient policy and selects attack-

ing actions that are adapted to a target web page.

Figure 6 and Figure 7 show the comparison re-

sults of the proposed method with the open-source

tools. Figure 6 shows the total number of requests to

complete the testing process. Since the open-source

tools aim to cover all XSS vulnerabilities in the test-

ing, a number of test strings are queried. Although

this strategy covers many XSS vulnerabilities, several

test strings are inapplicable to the target content. In

contrast, the proposed method requests the most suit-

able test string considering the state of the content.

Therefore, the total number of requests is consider-

ably smaller than the other tools.

We count the minimum requests to detect at least

one XSS vulnerability by the open-source tools. Here,

0 10000 20000 30000

XSspear

XSSer

XSSMap

Wapiti

w3af

Ours

4978

24567

1841

486

736

134

Figure 6: Total number of requests.

10 15 20

XSspear

XSSer

XSSMap

Wapiti

w3af

Ours

>15.0

>17.0

>20.0

>12.6

>20.0

7.1

Figure 7: Average minimum number of requests.

we average the count over the 19 web pages. The

number is considered to be 20 when more than 20

requests are required to exploit an XSS vulnerabil-

ity in existing tools. Figure 7 shows the results of

the average minimum requests. The sign ‘>’ shows

that one or more cases require more than 20 requests.

Therefore, the actual average counts are larger than

the shown counts. As shown in Figure 7, the pro-

posed method shows the fewest requests among the

open-source tools. This ﬁnding implies that the pro-

posed method obtains an efﬁcient policy during the

training phase and thus, successfully detects an XSS

vulnerability with the fewest requests compared to the

recent open-source tools.

4.3 Limitation

Since the agent composes the test string based on

the pre-deﬁned action space, it cannot address un-

known XSS vulnerabilities. Introducing a natural

language processing technique, which is applied in

(Frempong et al., 2021), and using a generative ad-

versarial network would be solutions to address the

problem. However, how to efﬁciently integrate such

techniques must be considered.

The quality of the obtained policy depends on

the training dataset. Typically, RL can learn experi-

enced actions and corresponding rewards. Therefore,

web pages that involve various XSS vulnerabilities

are needed. XSS Gym partially solves the problem

by randomly generating vulnerable web pages based

on given templates and parameters. However, how to

prepare the templates and parameters is remained to

be considered. Collecting real-world web application

logs and analyzing XSS exploitations from them can

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy

Table 4: Number of requests pertaining to the proposed method.

Page Requests Page Requests

backslash1 3 js6_sq_combo1 4

basic 2 js_script_close 13

basic_in_tag 2 oneclick1 24

doubq1 6 onmouseover 9

enc2 33 onmouseover_div_unquoted 6

full1 2 onmouseover_unquoted 8

js3 1 rs1 2

js3_notags 1 textarea1 4

js4_dq 6 textarea2 4

js6_sq 4

be a solution. More work is still needed to enhance

training environments.

5 CONCLUSION

This paper presents an XSS vulnerability testing

method using RL and a training environment, XSS

Gym. The proposed method trains an RL agent to

autonomously compose test strings by replacing the

fragments of known test strings and observing the

parsing of the target web page. Since RL obtains an

efﬁcient policy for composing test strings, the num-

ber of requests for testing web pages is drastically de-

creased. The experimental results demonstrate that an

RL agent can be trained using XSS Gym and the pro-

posed method discovers vulnerabilities in web pages

with the fewest requests compared to other existing

vulnerability testing tools.

REFERENCES

Avgerinos, T., Brumley, D., Davis, J., Goulden, R., Nigh-

swander, T., Rebert, A., and Williamson, N. (2018).

The mayhem cyber reasoning system. IEEE Security

& Privacy, 16(2):52–60.

Bland, J. A., Petty, M. D., Whitaker, T. S., Maxwell, K. P.,

and Cantrell, W. A. (2020). Machine learning cy-

berattack and defense strategies. Comput. Secur.,

92:101738.

Caturano, F., Perrone, G., and Romano, S. P. (2021). Dis-

covering reﬂected cross-site scripting vulnerabilities

using a multiobjective reinforcement learning envi-

ronment. Computers & Security, 103(102204).

Chen, S. (2014). WAVSEP - the web application vulnera-

bility scanner evaluation project.

Chowdary, A., Huang, D., Mahendran, J. S., Romo, D.,

Deng, Y., and Sabur, A. (2020). Autonomous secu-

rity analysis and penetration testing. In Proc. Interna-

tional Conference on Mobility, Sensing and Network-

ing.

Demetrio, L., Valenza, A., Costa, G., and Lagorio, G.

(2020). Waf-a-mole: Evading web application ﬁre-

walls through adversarial machine learning. In Pro-

ceedings of the 35th Annual ACM Symposium on Ap-

plied Computing, pages 1745–1752. Association for

Computing Machinery.

Erdödi, L., Åvald Åslaugson Sommervoll, and Zennaro,

F. M. (2021). Simulating sql injection vulnerability

exploitation using q-learning reinforcement learning

agents. Journal of Information Security and Applica-

tions, 61:102903.

Erdödi, L. and Zennaro, F. M. (2022). The agent web

model: modeling web hacking for reinforcement

learning. International Journal of Information Secu-

rity, 21(2):293–309.

Frempong, Y., Snyder, Y., Al-Hossami, E., Sridhar, M., and

Shaikh, S. (2021). HIJaX: Human intent javascript xss

generator. In SECRYPT, pages 798–805.

Ghanem, M. C. and Chen, T. M. (2020). Reinforcement

learning for efﬁcient network penetration testing. In-

formation, 11(1):6.

Hu, Z., Beuran, R., and Tan, Y. (2020). Automated pene-

tration testing using deep reinforcement learning. In

Proc. EuroS&P Workshops, pages 2–10.

Meyer, T., Kaloudi, N., and Li, J. (2021). A systematic liter-

ature review on malicious use of reinforcement learn-

ing. In 2021 IEEE/ACM 2nd International Workshop

on Engineering and Cybersecurity of Critical Systems

(EnCyCriS), pages 21–28.

Nguyen, T. T. and Reddi, V. J. (2021). Deep reinforce-

ment learning for cyber security. IEEE Transactions

on Neural Networks and Learning Systems, pages 1–

17.

OWASP Top 10 team (2021). OWASP Top 10:2021. https:

//owasp.org/Top10/.

Pathak, D., Agrawal, P., Efros, A. A., and Darrell, T. (2017).

Curiosity-driven exploration by self-supervised pre-

diction. In International Conference on Machine

Learning, pages 2778–2787.

Schulman, J., Wolski, F., Dhariwal, P., Radford, A., and

Klimov, O. (2017). Proximal policy optimization al-

gorithms.

Song, J. and Alves-Foss, J. (2015). The darpa cyber grand

challenge: A competitor’s perspective. IEEE Security

& Privacy, 13:72–76.

Automating XSS Vulnerability Testing Using Reinforcement Learning

WHATWG. HTML Standard. https://html.spec.whatwg.

org/.

Yahoo Inc. (2020). Webseclab. https://github.com/yahoo/

webseclab.

Zennaro, F. M. and Erdodi, L. (2020). Modeling penetration

testing with reinforcement learning using capture-the-

ﬂag challenges and tabular q-learning.

ICISSP 2023 - 9th International Conference on Information Systems Security and Privacy
