Formal Veriﬁcation for Advanced Sensing Applications:

Data Pre-processing in the INSPEX System

Joseph Razavi

, Richard Banach

, Suzanne Lesecq

, Olivier Debicki

, Nicolas Mareau

Julie Foucault

, Marc Correvon

and Gabriela Dudnik

School of Computer Science, University of Manchester, Oxford Road, Manchester, M13 9PL, U.K.

CEA, LETI, Minatec Campus, 17 Rue des Martyrs, F-38054 Grenoble Cedex, France

CSEM SA, 2002 Neuchatel, Switzerland

Keywords:

Formal Modelling, Sensor Processing, Embedded Devices, Wearable Technology, Assistive Technology.

Abstract:

The INSPEX project aims to miniaturize state-of-the-art obstacle detection technology comprising heteroge-

neous sensors and advanced processing, so that it can be used for wearable devices. The project focuses on

enhancing the white cane used by some visually impaired and blind people. Due to high demand for reliabi-

lity and performance, the project is a good candidate for the use of formal methods. In this paper, we report

lessons we have learned from formal modelling exercises related to the pre-processing of sensor information

in INSPEX.

1 INTRODUCTION

At rare and exciting moments, progress in informa-

tion technology makes an impact on everyday life so

great that everybody feels that things have changed.

In this generation, innovations in sensing technolo-

gies, machine learning, and the wide availability of

portable computing in the form of smartphones are

making the kind of revolutionary changes that perso-

nal computing and the internet did a generation ago.

One such prominent change is in the application

of sensors in the automotive industry, in such con-

texts as assisted parking and automatic management

of headlights, not to mention autonomous driving.

Another is in the realm of assistive technology. In

this paper, we describe some aspects of work on the

INSPEX project, which aims to bring state-of-the-art

obstacle detection capabilities to domains requiring

small, light, power efﬁcient hardware. The project’s

particular focus is on assistive technology for visually

impaired and blind people, and thus it also incorpo-

rates new techniques for the presentation of obstacle

information suited to this use. The goal is to produce

a prototype system which can be mounted on a white

cane as traditionally used by many visually impaired

people. The speciﬁc aim of this paper is to discuss

the application of formal methods in this area. We at-

tend principally to those aspects concerning the pre-

processing of sensor data.

We begin by motivating this use case as one

for which the application of advances in sensing,

data processing, and information presentation are ger-

mane. We then brieﬂy describe the details of the pro-

ject, and describe the relevance of formal methods to

the project’s goals. We go on to describe lessons lear-

ned about the application of formal techniques in this

domain, gleaned from our experience so far, ﬁnishing

by using a simpliﬁed example from INSPEX to high-

light one aspect of this.

1.1 Augmenting the Capabilities of the

White Cane

A number of attempts by students and researchers to

attach sensors to the white canes which are an esta-

blished tool for visually impaired and blind people

are visible in the literature (Connoly, 2012; Wang and

Kuchenbecker, 2012). Indeed, there are already com-

mercially available white canes enhanced by the addi-

tion of sensors (UlraCane, 2012; SmartCane, 2018).

One might wonder why a piece of equipment with

such a long history of successful use needs modiﬁca-

tion, but in fact the argument is compelling. While vi-

664

Razavi, J., Banach, R., Lesecq, S., Debicki, O., Mareau, N., Foucault, J., Correvon, M. and Dudnik, G.

Formal Veriﬁcation for Advanced Sensing Applications: Data Pre-processing in the INSPEX System.

DOI: 10.5220/0006906906640671

In Proceedings of the 13th International Conference on Software Technologies (ICSOFT 2018), pages 664-671

ISBN: 978-989-758-320-9

sually impaired people are experts at using the tactile

feedback from the cane to understand their surroun-

dings at ground level, a white cane, by its nature,

can not give any warning about obstacles at chest or

head level. Whether they are low branches in natu-

ral settings, or signs, cordons, or temporary fences in

an urban environment, such obstacles are extremely

common, and an unexpected collision with them has

the potential to cause serious injury. This represents

an unfortunate constraint on personal independence,

since it means proceeding with great caution, and pos-

sibly making use of a guide dog, a sighted friend or

assistant, or otherwise unwanted hats or similar head-

wear.

The addition of a range sensor to the cane which

points upwards can help with this problem. As the

user sweeps the cane, receiving tactile feedback from

the ground, they also receive feedback from the sensor

about the distance to the nearest obstacle at a higher

level.

To advance the state of the art we should therefore

ask: how can the next generation of this technology

improve on what currently exists? There are lots of

possibilities. A crucial one is that what exists today

typically relies on a single sensor, say one based on

sonar, radar, or a laser. Each type of sensor has its

own strengths and weaknesses. Sensors may perform

poorly for surfaces with certain reﬂectivities, curva-

tures or other properties, or in conditions of varying

ambient light and humidity, whereas other sensors are

likely to have complementary capabilities. Similarly,

some sensors are well suited to resolving small or dis-

tant objects, but have a narrow ﬁeld of view, whereas

others may resolve detail less well, but cover a broad

area.

Another important potential improvement is in the

cognitive load placed on the user. When the feedback

presented to the user is in the form of relatively direct

range readings from the sensor, the user’s brain must

do the work of interpreting this information and re-

constructing the three dimensional environment. This

may involve getting used to the quirks and idiosyncra-

sies of the sensor. In a system with multiple sensors,

this problem would be compounded. The user must

then combine this with their model of the ground-

level situation, their plans and route, and their kno-

wledge of contextual issues such as the location of

pedestrian crossings and amenities.

By combining the inputs of multiple sensors, and

processing them to make the most useful informa-

tion more salient to the user, the usefulness of cane-

mounted sensors could be greatly improved: these are

the prospects identiﬁed by the INSPEX project; its

aim is to realize them. This entails that signiﬁcant

technical challenges be met.

In INSPEX, the feedback given to the visually

impaired user is presented via 3D immersive sound,

transmitted to the user via binaural headphones. In

order to be convincing for the user, the sound picture

must be stable with respect to a 3D inertial frame, so

as well as the issues of cognitive load etc., discus-

sed above, the INSPEX system must be aware of the

user’s head movements, in order to achieve the nee-

ded spatial stability for the sound image. This adds

another technical challenge.

1.2 The INSPEX Project

The INSPEX project (INSPEX Homepage, 2017) is

an international collaboration with the goal of deve-

loping a small, lightweight system which combines

the inputs of multiple sensors and integrates their rea-

dings into a three dimensional model of the obstacles

in its surroundings. Such a system would have multi-

ple potential applications, including autonomous dro-

nes and ﬁre-ﬁghters working in low-visibility condi-

tions. The main focus, however, is on the use case

of assistive technology which could be attached to a

white cane, as described above.

Achieving this ambition means facing several fun-

damental obstacles. To be a useful tool to a visually

impaired person, INSPEX must provide reliable, high

performance functionality over the course of many

hours. If the user is required to stop several times

per day to re-charge batteries, then their independence

and quality of life will not have been signiﬁcantly im-

proved. At the same time, the system must be held

in the hand and moved continuously by the muscles

of the wrist for long stretches of time. This implies

that the system must be lightweight; otherwise, rather

than enhancing their day-to-day life, the system could

cause injury to the user. These requirements translate

into a number of technical challenges.

First, the sensors themselves need to be signiﬁ-

cantly miniaturized, and their weight and power con-

sumption must be reduced. Concomitantly, the com-

putation power needed for processing must be tightly

controlled, so that lighter, more efﬁcient processors

can be used. For this reason, the standard Occupancy

Grid algorithm used for obstacle detection in the auto-

motive domain has had to be signiﬁcantly optimized

for architectures with fewer facilities than its usual

implementations (Dia et al., 2017). This constraint

also implies that clever optimizations will be requi-

red throughout the basic utility systems which under-

pin the advanced data processing. These will have

to function with minimal memory, and will have to

share hardware resources with other parts of the sy-

Formal Veriﬁcation for Advanced Sensing Applications: Data Pre-processing in the INSPEX System

665

stem, requiring them to be robust against competition

for resources.

Second, power must be managed in a sophistica-

ted way. The needs of the data processing algorithms

for a supply of frequent, timely data must be balan-

ced against the overall requirement to conserve po-

wer. Sensors and communication facilities cannot be

allowed to operate when they are not needed, yet they

must function at the proper time when their functiona-

lity is required. This means that power management

cannot be treated as a simple matter, and some of the

system’s scarce computing power must be used to de-

termine when to supply power to which subsystem.

Finally, the system must be robust, and guarantee

a certain level of performance. The project will not be

a success if it is possible, even under rare conditions,

for the user to rely on the system only to be stranded

by crashing, deadlock, or because of incorrect power

consumption estimates. This must be true for long-

term use every day, in which one should assume that

all possible conditions will eventually be encounte-

red. To play a role in the user’s life which is as fun-

damental as that played by a traditional white cane,

an obstacle detection system must be as dependable

as that simple, effective piece of technology. This re-

quirement is in tension with the need for highly op-

timized code with advanced functionality in a highly

concurrent environment. Experts know well that it is

easy to introduce subtle bugs under such conditions.

These circumstances indicate the possibility for for-

mal methods to have a useful impact.

2 FORMAL METHODS

2.1 Applying Formal Methods in

Innovative Sensing Applications

Formal methods are a class of techniques which allow

software to be compared against mathematical mo-

dels, providing an improved ability to detect subtle

functional and logical bugs, and, under good condi-

tions, prove that a system is free from certain clas-

ses of problems. Formal methods are nowadays well-

established for safety-critical systems and mission-

critical infrastructure in industrial applications. These

techniques are becoming mature in settings wherein

the function of the system is well-deﬁned. In the IN-

SPEX system, and in similar sensing applications, the

requirement for highly reliable, but sophisticated soft-

ware is a motivation to pursue the use of formal met-

hods. However, the nature of an innovative project

focussing on sensing means that it is more difﬁcult

to give a ﬁxed, precise description of correct system

functioning a priori. This creates opportunities to le-

arn interesting methodological lessons in the applica-

tion of formal techniques.

2.1.1 Functioning under Conditions of

Uncertainty

One difﬁculty in attempting formal veriﬁcation of

such systems is that usually their main function is to

perform advanced statistical inference on incoming

data, or to apply novel heuristics to improve perfor-

mance in a complex, ill-deﬁned domain. While one

can certainly employ static analysis to catch low-level

bugs, and one could attempt to show that the imple-

mentation code is a faithful version of the intended

algorithms, it may appear that beyond this, innovative

sensing applications are rather sterile from the point

of view of applied formal methods. After all, one can

as little hope to prove that INSPEX correctly identi-

ﬁes all obstacles in an environment as to prove that a

spam ﬁlter catches all and only spam email.

However, even in the example of a spam ﬁlter,

one can still hope to prove that, for example, email

from whitelisted or blacklisted addresses is allowed

or blocked as appropriate. In the context of a sensing

application, there is a lot of scope to prove that the

data being supplied to the statistical analysis is of a

good quality and freshness, and satisﬁes any pertinent

constraints.

For example, many sensing systems require inco-

ming data to be pre-processed into a form suitable for

further computation. One could imagine that this pre-

processing consists of computing a function f (x, y)

of heterogeneous input data as frequently as possible,

but under certain constraints. We might imagine that y

values represent crucial readings, while x values give

contextual information. Thus, while x values may be

re-used, y values must be used at most once. Moreo-

ver, a timing constraint must hold between the times

when x and y values which are to be combined were

received, to ensure that the contextual information x is

really relevant to the reading y. Of course, in real ap-

plications, these values x and y are likely themselves

to be composed of data from various heterogeneous

sources under constraints of their own, and so on.

One easily foresees that under strict memory li-

mitations, and in the presence of autonomous sensors

providing information asynchronously, these types of

constraints can lead to difﬁcult problems. One wants

to show that as long as the system receives enough

input information of the correct types, it outputs the

pre-processed data for statistical analysis with a rea-

sonable frequency. This could fail to happen if, for

example, small internal buffers become full, preven-

ICSOFT 2018 - 13th International Conference on Software Technologies

666

ting the storage of new input data. This blocked data

might be precisely what is required to produce out-

put satisfying the operating constraints and thus dis-

charge some of the held data. The result of this si-

tuation would be deadlock. Conversely, if contextual

data is overwritten by incoming readings which rely

on it in order to be processed, this too will cause no

output ever to be produced. Finally, it is possible that

fresh data are discarded in order to ﬁnish processing

old data. This can impact the frequency and freshness

of the data used for analysis, and consequently the

quality of information ultimately delivered to the user.

Intermediate between simple low-level bug de-

tection and issues of data frequency and quality are

problems related to basic underpinning functionality.

For example, wherever there is communication, it is

likely that there are systems which must maintain a

degree of synchrony with each other. They may have

to do this under conditions in which they may be inter-

rupted, since they compete for scarce processor time

with other aspects of the system. One must show that

the algorithms used to maintain the required level of

synchrony can withstand these interruptions and con-

tinue to operate with reasonable performance. The

presence of communication also implies issues of en-

coding and decoding. For example, transmitted data

is frequently processed such that certain special se-

quences never occur. These sequences may be used

as delimiters or framing markers in packet-oriented

communication. Alternatively, they may be command

characters, which are common for hardware devices

such as low-power bluetooth modules: these often

have only one input line for both control commands

and data, using a special data sequence to switch from

one mode to another. This implies, at least, the appli-

cation of bit-stufﬁng, byte-stufﬁng, or string escaping

algorithms (Cheshire and Baker, 1999) which must be

correctly applied at one end of a communication, and

correctly inverted at the other.

These examples show that the main function of an

advanced sensing system is usually underpinned by

many subsystems which do have clearly deﬁned ro-

les and correctness conditions. Veriﬁcation of condi-

tions of this type can build upon existing work which

has been done to verify operating-system level com-

ponents. For example, there is a body of work related

to the veriﬁcation of the real-time operating system

FreeRTOS (FreeRTOS, 2011; Divakaran et al., 2015),

which is widely used in this type of application. From

our point of view, it is interesting that this work uses

a multi-tool approach, starting with reﬁnement based

tools to relate overall system requirements to those

of speciﬁc subsystems, and then transitioning to tools

designed to verify C code in order to check that these

subsystems correctly perform their function.

2.1.2 Formal Methods and Design-rich Projects

Another source of difﬁculty in applying formal met-

hods to cutting-edge applications relates to projects

which have a signiﬁcant element of ongoing design

activity. Such projects seek to discover the extent to

which innovative techniques can improve the state of

the art in their domain. At the start of the project,

it is not clear what level of performance is possible,

and what level of performance is necessary in order to

achieve meaningful success. Indeed, the whole point

of such exploratory development is that this is to be

discovered while the project is ongoing. This implies

that many aspects of the design will be open to modi-

ﬁcation throughout the project, as lessons are learned

from the implementation effort. This gives rise to se-

veral challenges.

First, there may be requirements which appear

to be related to optimization, but which ultimately

turn out to be necessary for proper functioning. For

example, suppose one is working with a statistical

algorithm which performs best when its input is a

sparse matrix. During pre-processing, various heu-

ristics may be applied to try to ﬁnd a representation

in which the data has this sparse form. At the out-

set, this appears to be a non-functional optimization.

However, it may be discovered that it is critical that

this step always attains some minimal level of per-

formance; otherwise, the later processing stages may

not perform well enough for the system to provide

the functionality needed. A similar situation occurs

for power management. A wide variety of tricks may

be employed to make power consumption as small as

possible, but it may not be known what level of power

consumption is acceptable. This can pose a challenge

not only for formal modelling, but also for require-

ments gathering.

Engineers will have invested a signiﬁcant amount

of ingenuity in trying to make performance as good

as possible, and the properties of the output which are

thereby aimed for may be the focus of their explana-

tion of certain subsystems. It may very well be un-

clear which of these properties are necessary to avoid

crashes or deadlocks, which are required for a usable

level of functionality, and which are enhancements

which stretch the frontier of the possible. While it

is important to try to elicit this distinction from dom-

ain experts, it is equally important to recognize that

when the success of a project consists in improving

on the state of the art, the issue is not as clear cut as

we might like.

To deal with challenges of this type, two strategies

can be employed. Thus, one can try from the outset

Formal Veriﬁcation for Advanced Sensing Applications: Data Pre-processing in the INSPEX System

667

to prove that these optimizations achieve a bare mini-

mum of performance, such as universally improving

over the un-optimized situation. Furthermore, one

can again make use of a multi-tool approach, using

a tool such as PRISM (Kwiatkowska et al., 2011) to

ﬁnd bounds on performance, possibly using conserva-

tively simpliﬁed models. If engineers are happy with

these bounds, other tools could be used to conﬁrm that

the detailed design and implemented code adhere to

them.

A second set of challenges which proceed from

the innovative nature of cutting-edge projects relates

to the fact that these projects will often not start from

a blank slate, but instead proceed by modiﬁcation of

previous work. One ought not to think of this as an

error; instead, it arises from the nature of invention.

Out of the inﬁnity of possible human wants, the pro-

ductive innovator must choose to pursue those which

are realistically achievable. The best guide to this is

a cultivated sense of the directions in which existing

work admits modiﬁcation. This precludes an ideali-

zed version of formal development, in which code is

derived from abstract models. It necessitates a prag-

matic approach, where models are derived partly from

existing code, as well as feedback from engineers

about the intended functioning of the system.

A crucial observation is that these systems are also

often developed in an iterative fashion, via a series

of prototypes. This is unavoidable in work where it

is unknown whether the proposed method will really

work, and lessons may have to be drawn from the ini-

tial attempts which guide the ﬁnal development. This

means that the effort put into discovering abstract mo-

dels of the initial version can be put to use to guide

the development of subsequent iterations. Indeed, ab-

stract models can provide a valuable alternative view

of the situation to that revealed by code. This is parti-

cularly useful because the low-level details may have

to be radically different in different prototypes of a sy-

stem, once constraints coming from fundamental har-

dware issues are discovered. For efﬁciency reasons,

logically separate concerns may not be well separated

in the original code, and these may need to be teased

apart if the underlying structure of the system chan-

ges. In addition, elements which were necessary in

one version may become obsolete in another, but this

may not be visible in highly-optimized code. On the

other hand, an abstract view of the system can make

this clear. A simpliﬁed example of this type of phe-

nomenon is discussed in the next section.

2.2 Formal Modelling in INSPEX

In the INSPEX system, we ﬁnd many opportunities

for the fruitful application of formal techniques. Ex-

amples abound in the power management ﬁrmware

relating, for example, to the need for circuits which

operate a high-power subsystem to always be swit-

ched on when the system they manage is. In this

section, we focus on an example based on the sensor

pre-processing stage.

We imagine a system with multiple sensors, each

of which may transmit a reading to an acquisition mo-

dule at any time. The acquisition module then per-

forms a computation along the lines of that descri-

bed above, integrating the heterogeneous data recei-

ved into a form suitable for further processing. This

data is then encoded and transmitted to the main pro-

cessing platform which decodes it and works through

the items one by one.

Since memory usage is a critical issue, it is freed

as soon as possible. In the acquisition system, this

occurs once the data it contains has successfully been

transmitted. In the main processor, this occurs once it

has been used by the analysis algorithm.

It would be tempting to model these two subsys-

tems individually, as separate veriﬁcation projects —

but this would be a mistake. One reason is visible

from the point of view of modelling in itself. The in-

puts or outputs of these systems, corresponding to the

transmitted information, are quite complex, even if

one abstracts from the precise details of the encoding.

Furthermore, if it is ultimately decided that these mo-

dels should be combined to reason about global beha-

viour, then one would have to grapple with ensuring

that reﬁnements adding in these low-level details in-

teract well with shared events. This suggests consi-

dering the encoding, transmission, and decoding to-

gether as a conceptual unit. It operates on much sim-

pler data and, conceptually, implements the fetching

of pre-computed data by the main algorithm. This

simple subsystem could be decomposed, if required,

at a much later stage of reﬁnement.

A more application oriented reason to leave out

this aspect in the abstract models of the system is

that the underlying connectivity of the hardware may

well change in a more advanced prototype. Since we

would like our abstract models to guide the transition

from one prototype to another, at an abstract level they

should express what such systems must have in com-

mon.

Therefore, in our abstract system, we have three

main kinds of events: sensors transmitting raw data,

pre-processing to compute combined values, and the

main algorithm consuming these pre-processed va-

ICSOFT 2018 - 13th International Conference on Software Technologies

668

lues. In addition, we have the action of freeing the

memory used to store these resources. In this paper,

we ignore how the memory related to raw values is

managed, focussing on when combined values may

be freed. In the abstract system, this can be done only

after they are used by the main algorithm.

In the INSPEX project, the majority of the for-

mal modelling is done using Event-B (Abrial, 2010)

via the Rodin tool (Abrial et al., 2010), though ot-

her techniques also contribute. In Event-B, the above

could be modelled as follows. We assume the state of

the abstract system is given by a set messages repre-

senting the set of all integrated messages ever com-

puted by the pre-processing stage. We model the me-

mory status of messages and whether they have been

consumed by the main algorithm using two variable

functions, inMemory and used. These map elements

of messages to booleans. All three of these variables

are initialized to the empty set. We ignore the ot-

her aspects of the state, which relate to the collection

and integration of raw messages received, although

one would include them in a complete model. Focus-

sing on the consumption and deallocation of proces-

sed messages, there are two corresponding events in

the abstract system, which we call consume and f ree.

We write these events in the Event-B formalism as

follows.

EVENTS

consume

ANY m

WHEN

m ∈ messages

inMemory(m) = T RUE

used(m) = FALSE

THEN

used(m) := T RUE

END

f ree

ANY m

WHEN

m ∈ messages

inMemory(m) = T RUE

used(m) = T RUE

THEN

inMemory(m) := FALSE

END

The ‘ANY’ clause of an event speciﬁes its parame-

ters: in the case of both events above this is just the

message m which is to be consumed by the main al-

gorithm or deallocated. The ‘WHEN’ clause speciﬁes

guards, conditions which must hold for the event to

take place; these are simply boolean conditions on the

parameters and the state variables of the model. The

‘THEN’ clause determines what the effect of the event

on the variables describing the system’s state is. For

both events above, this takes the form of changing the

value of a variable function on one of its arguments to

a new value. For example, in the event consume we

set used(m) to T RUE.

This abstract model might seem wrong, because

we know that in our concrete system, it is safe for

the pre-processing subsystem to free the data once it

has been transmitted to the main processor. Howe-

ver, the ‘memory’ of the abstract system is, in reality,

the combined memories of the two components of the

concrete system. To be freed in the abstract system

is, in some sense, no longer to exist in the memory of

either module. This guides the way we understand the

relationship between concrete and abstract systems in

reﬁnement.

For this reason, it makes sense for the model to

remember every piece of data which is ever received,

even those which have been deallocated. Those which

are still in memory are marked as such, and a precon-

dition of any event which makes use of them must

then be that they are present in memory.

Performing one step of reﬁnement, we would re-

ﬁne the action by which the pre-processor makes data

available to the main algorithm so that it now includes

the step of transmission. This could be subsequently

reﬁned to model the encoding and decoding, issues of

synchronization, and ﬁnally even bit-level modelling

of the sequence of transmitted signals.

In the concrete system, the notion of being pre-

sent in memory is elaborated so as to specify that an

item is present in the pre-processing subsystem or the

main processor (or both). The abstract notion of being

present in memory is simply the disjunction of these

conditions. The guards of various actions in the con-

crete system must specify which subsystem they re-

quire their data to be present on, thus strengthening

the abstract guards. At this intermediate level of ab-

straction, the transmission action essentially copies

data from one subsystem to another. This makes it

available for the second subsystem to use, but also

means that the ﬁrst is free to deallocate it without dis-

turbing the abstract invariant that it be present somew-

here in the system. It is this which explains why the

logic of deallocating transmitted information makes

sense.

In Event-B, we model the concrete system by re-

placing the inMemory function with two functions

inMainMemory and inPreMemory to represent being

in the memory of the main module and the pre-

processing module respectively. We also add a new

function transmitted from messages to booleans to

model whether a message has been sent from the pre-

processing module to the main module.

Formal Veriﬁcation for Advanced Sensing Applications: Data Pre-processing in the INSPEX System

669

Since we have removed the function inMemory,

we have to describe how this abstract variable can be

recovered from the concrete data. Following the rea-

soning above, we add an invariant, a property of the

state variables which must be true in every state, indi-

cating the intended relationship.

INVARIANTS

∀m · m ∈ messages =⇒

inMemory(m) = T RUE ⇐⇒

(inPreMemory(m) = T RUE ∨

inMainMemory(m) = T RUE)

Unlike a normal invariant, which is a boolean ex-

pression involving only the state variables of the mo-

del it is part of, this invariant involves variables from

both the concrete system and the abstract system.

This special type of invariant is called a glueing in-

variant. The fact that we intend the concrete system

to reﬁne the abstract system must be made explicit,

and this is done by using the ‘REFINES’ keyword at

the appropriate place.

The consume and f ree events must now be mo-

diﬁed so as to refer to the variables of the concrete

system. The f ree event is to be reﬁned by multiple

events, which involves some subtlety. However, the

concrete version of the consume event is straightfor-

ward:

EVENTS

consume

REFINES consume

ANY m

WHEN

m ∈ messages

inMainMemory(m) = T RUE

used(m) = FALSE

THEN

used(m) := T RUE

END

We also add a new event transmit which models sen-

ding a message from the pre-processing module to the

main module.

transmit

ANY m

WHEN

m ∈ messages

inPreMemory(m) = T RU E

transmitted(m) = FALSE

THEN

transmitted(m) := T RUE

inMainMemory(m) := T RUE

END

Note that as transmit does not reﬁne any events of

the abstract system it must not have any effect on the

variables of the abstract system. This is true because

inMemory(m) is true whenever the event is triggered,

(because of the guard inPreMemory(m) = T RUE),

and it remains true afterwards.

We now turn to reﬁning the f ree event. Conceptu-

ally, we replace this by two events, one to free trans-

mitted messages in the pre-processing module, and

one to free consumed messages in the main module.

However, a concrete event must either reﬁne an ab-

stract event or else it must leave the abstract state un-

changed. To reﬁne a abstract event, the guards of the

corresponding concrete event must imply those of the

abstract event, and the glueing invariant must be pre-

served by the concrete event if the abstract state is

changed simultaneously by the abstract event it reﬁ-

nes.

However, deallocating a message on just one of

the modules sometimes has no effect on the abstract

state (if the message is present in the memory of the

other module) or else it changes the state of inMemory

(if the other module has already deallocated the mes-

sage). For this reason, each of the two f ree operations

has two cases, one reﬁning the abstract f ree and one

which does not affect the abstract state. Since the two

cases are very similar, it sufﬁces to consider the ope-

ration of deallocation on the pre-processing module.

pre only f ree

ANY m

WHEN

m ∈ messages

inPreMemory(m) = T RUE

transmitted(m) = T RUE

inMainMemory(m) = T RUE

THEN

inPreMemory(m) := FALSE

END

pre

last f ree

REFINES f ree

ANY m

WHEN

m ∈ messages

inPreMemory(m) = T RUE

transmitted(m) = T RUE

inMainMemory(m) = FALSE

THEN

inPreMemory(m) := FALSE

END

The fact that the guards of these events refer to the

state of the main module means that some care must

be taken when modelling each subsystem in isolation.

However, in practice the problems are not too severe,

since the effect on the local state of the preprocessing

module is the same in either case.

ICSOFT 2018 - 13th International Conference on Software Technologies

670

3 CONCLUSIONS

In this paper, we describe the application of formal

methods in the INSPEX project. This project aims to

develop a small, light and power efﬁcient obstacle de-

tection system which incorporates heterogeneous sen-

sors and provides feedback to the user in the form of

three dimensional immersive sound.

We have set this work in the context of the pro-

blem of applying formal methods to projects featu-

ring continuously ongoing design, particularly in the

sensing domain. We hope that this report of our ex-

periences will be useful for others facing the need

for the increased dependability that formal techniques

can bring, in contexts where the design is volatile to

a signiﬁcant degree. As applications of this type be-

come increasingly common, it is important to empha-

size the beneﬁts of formal methods in such settings.

ACKNOWLEDGEMENTS

This project has received funding from the

European Union’s Horizon 2020 research

and innovation programme under grant agreement

No. 730953. The work was also supported in part by

the Swiss Secretariat for Education, Research and In-

novation (SERI) under Grant 16.0136 730953. We

thank them for their support.

REFERENCES

Abrial, J.-R. (2010). Modeling in Event-B: System and Soft-

ware Engineering. CUP.

Abrial, J.-R., Butler, M., Hallerstede, S., Hoang, T. S., Me-

hta, F., and Voisin, L. (2010). Rodin: an open toolset

for modelling and reasoning in Event-B. Internatio-

nal Journal on Software Tools for Technology Trans-

fer, 12(6):447–466.

Cheshire, S. and Baker, M. (1999). Consistent overhead

byte stufﬁng. IEEE/ACM Transactions on Networ-

king, 7(2):159–172.

Connoly, D. (2012). Grade 9 science fair wunderkind

creates a smarter white cane. Engineering.com,

http://www.engineering.com/DesignerEdge/

DesignerEdgeArticles/ArticleID/16419/Grade-9-

Science-Fair-Wunderkind-Creates-a-Smarter-White-

Cane.aspx.

Dia, R., Mottin, J., Rakotavao, T., Puschini, D., and Le-

secq, S. (2017). Evaluation of Occupancy Grid Re-

solution through a Novel Approach for Inverse Sen-

sor Modeling. In Proc. IFAC World Congress, FAC-

PapersOnLine, volume 50, pages 13841–13847.

Divakaran, S., D’Souza, D., Kushwah, A., Sampath, P.,

Sridhar, N., and Woodcock, J. (2015). Reﬁnement-

Based Veriﬁcation of the FreeRTOS Scheduler in

VCC. In Butler, Conchon, and Zaidi, editors, Proc.

ICFEM-15, volume 9407 of LNCS, pages 170–186.

Springer.

FreeRTOS (2011). https://www.freertos.org/.

INSPEX Homepage (2017). http://www.inspex-ssi.eu/.

Kwiatkowska, M., Norman, G., and Parker, D. (2011).

PRISM 4.0: Veriﬁcation of probabilistic real-time sy-

stems. In Gopalakrishnan, G. and Qadeer, S., editors,

Proc. 23rd International Conference on Computer Ai-

ded Veriﬁcation (CAV’11), volume 6806 of LNCS, pa-

ges 585–591. Springer.

SmartCane (2018). http://smartcane.saksham.org/.

UlraCane (2012). https://www.ultracane.com/.

Wang, Y. and Kuchenbecker, K. (2012). Halo: Haptic alerts

for low-hanging obstacles in white cane navigation.

In 2012 IEEE Haptics Symposium (HAPTICS), pages

527–532.

Formal Veriﬁcation for Advanced Sensing Applications: Data Pre-processing in the INSPEX System

671
