Facilitating the Reactive Web

A Condition Action System using Node.js

Alexander Gr

oﬂin, Dominic Bosch, Martin Guggisberg and Helmar Burkhart

High Performance and Web Computing Group, University of Basel, Spiegelgasse 1, CH-4051 Basel, Switzerland

Keywords:

Reactive Web, Condition Action System, Event Aggregation, Node.js.

Abstract:

The orchestration of the Web is a big issue for Web users all around the world. Web users have a high interest

in services, which are able to personalise and customise the Web. However, for Web reactivity there exists only

a few limited solutions that allow the aggregation of Web resources. This paper takes a look at existing event-

based methods that build upon Event-Condition-Action (ECA) Rules and Complex Event Processing (CEP).

Moreover, this paper illustrates the architecture of a fully functioning Condition Action System prototype for

the creation of reactivity in between Web resources. In a proof of concept, we could detect and determine the

change interval of electronic newspaper headlines. With the proposed system, we are able to orchestrate Web

resources e.g. Detecting Web Changes.

1 INTRODUCTION

The invention of the Web is without doubt one of the

most inﬂuencing technological developments with re-

spect to economy, education and social life. While the

ﬁrst decade of Web existence is characterised by the

proliferation of home and business websites includ-

ing web-shops, the last decade transformed the Web

to a manifold information service. Service-Oriented

Architectures (SOA) and Web services have been pro-

posed for quite a time. While business services turned

out to be successful from the economic side, the Web

still has unused potentials in terms of programmable

automation, customisation and personalisation.

Web users ﬁnd themselves mashing up data and

functionality from different Web resources and ser-

vices manually, e.g. a press release provokes a Twit-

ter post. Consequently, Web users use the Web with-

out full automation. Manual use of services always

implies a delay of reaction; real-time orchestration of

services is limited. Great value would be added for

Web users if speciﬁc interaction had been automat-

ically achieved e.g. detecting and reacting on cer-

tain updates. This would require an instrument for

the identiﬁcation and ﬁltering of changes, the adop-

tion of time constraints, composition and placement

of the outcome in the users preferred Web resource or

service (Windley, 2012).

To achieve this reactivity, users need Mashup plat-

forms and tools with which they are able to auto-

mate tedious tasks and to react on certain events in

a predeﬁned way. There have been several steps un-

dertaken to create such tools and platforms in or-

der to tackle basic automation (Akbar et al., 2014).

For example, IFTTT (https://ifttt.com/) or Zapier

(https://zapier.com) focus on a one to one connection

between Web services at the same time e.g. weather

change triggers a Twitter tweet. A shortcoming of

these platforms is that events, which have occurred in

several distributed systems, cannot be detected as part

of one rule. It is certainly not possible to create cus-

tom event listeners and actions. For additional cus-

tomisation, these service providers have to set up such

a service connection for each Web resource them-

selves. Furthermore, selecting more actions on one

single trigger is not possible. They rather create a

tunnel from one Web service to another, than creat-

ing reactivity in between several resources.

A variety of languages for Web service orches-

tration has been reported in the last years, e.g. (Di-

jkman et al., 2008), (Wohed et al., 2003). Most of

these languages address workﬂows, business collabo-

rations and long running interactions for well-deﬁned

processes. Our goal was to create a Condition Ac-

tion System with focus on real-time reaction, which

allows inbuilt coding for the reactivity between Web

resources (Blackstock and Lea, 2014).

In this paper, we assess event-based technologies

to create a reactive system, which is able to orches-

trate Web resources. In addition, we demonstrate the

Gröﬂin A., Bosch D., Guggisberg M. and Burkhart H..

Facilitating the Reactive Web - A Condition Action System using Node.js.

DOI: 10.5220/0005446800890095

In Proceedings of the 11th International Conference on Web Information Systems and Technologies (WEBIST-2015), pages 89-95

ISBN: 978-989-758-106-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Proposed scheme of a system in which a user

aggregates Web resources. Observed changes in these re-

sources form events that are processed in a reactivity entity.

The output is an action that control Web resources. Person-

alised settings allow a user-speciﬁc orchestration of Web

resources e.g. Facebook, Google Mail, and Twitter etc.

architecture of a prototype system, show web tech-

nologies used, and address the issue how to create

and to detect events for a more efﬁcient Web expe-

rience. Our approach takes the direction towards the

reactive Web. In Section 2, we outline the need for

an orchestration of Web resources and describe the

Event-Condition-Action (ECA) paradigm. Section 3

describes a particular use case. In Section 4, we

present the architecture of our Condition Action Sys-

tem prototype, its functionalities and a proof of con-

cept. Conclusively, Section 6 speciﬁes a conclusion.

2 AGGREGATION OF WEB

RESOURCES

In recent years, many mashup tools and platforms ap-

peared on the Web that enable Web users to create

reactive behaviour. One of the earliest attempts is Ya-

hoo! Pipes, which deﬁnes itself as a data mashup

tool (Yahoo!, 2010). It aggregates content from dif-

ferent RSS feeds. Desired data are selected from dif-

ferent feeds; the output also consists of a RSS feed or

data in JavaScript Object Notation (JSON). This also

means that the ﬁeld of application is also very lim-

ited because it uses RSS as input. Real mashup tools

for example IFTTT or Zapier focus on directing the

data ﬂow from one Web service to another. By or-

chestrating Web APIs real reactivity is being created

(Ovadia, 2014). Such an approach opens up the pos-

sibilities of automation in between different Web ser-

vices. However, the key problem with this conception

is that they do not offer generic access to any arbitrary

Web resource. Unfortunately, not every Web resource

has an accessible interface in these tools. This means

that these platforms have to provide the interface to

the desired Web services. Another problem of Web

mashups like IFTTT is the restricted programmabil-

ity. IFTTT does not allow Boolean operators, which

hinders solving expressive problems. Sometimes it

would be useful to react on more complex rules than

the simple If This Then That scheme. Concluding,

these services rather interconnect existing services

and remove the need for any coding (Blackstock and

Lea, 2014).

2.1 Event-Condition-Action (ECA)

Paradigm

Increasing amount of literature emerges on reactivity

related to the Web (Paschke, 2014), (Hausmann and

Bry, 2013), (Paschke et al., 2012). The rationale be-

hind these studies is an event-based system, which in

turn rely on ECA Rules. ECA Rules consist of three

different parts:

• Event: An identiﬁer which detects events

• Condition: An expression which determines

whether an action should be triggered or not

• Action: A set of instructions which describe the

reactive behaviour

Event-based characteristics allow users to make

use of loosely coupled Web services, which signiﬁ-

cantly improves scalability in information exchange

and distributed workﬂows. It semantically decouples

space, time and synchronisation between event pro-

ducer and event consumer (Hasan et al., 2012). Thus,

the resulting goal is to remove ”explicit dependencies

between the interacting participants” (Eugster et al.,

2003). Simple events occur at a single point in time

(e.g. a website update). Event-based systems may re-

act on simple events, but this is often not enough to

detect meaningful situations among different Web re-

sources. A composition of events reﬂects a complex

event, which is multi-layered and has a distinct dura-

tion. It would enable Web users to detect meaningful

situations consisting of simple events and reacting on

them.

2.2 Retrieving Events using Webhooks

Webhooks are services, which report state changes

in a push manner (Trifa et al., 2010). Thus,

they allow real-time propagation of events. Exist-

ing manifestations of Webhooks are available for

server to browser communication, such as Comet

(Duquennoy et al., 2009) or Server-Sent Events

(http://dev.w3.org/html5/eventsource/). The instant

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

delivery of information whenever it gets available

makes this notion valuable for real-time handling.

In principle, Webhooks consist of an URI, which

points to a Web resource and a sender. It forwards

data as soon as it gets available within the pub-

lish/subscribe pattern (Eugster et al., 2003). When-

ever an event occurs, new data is delivered via a Web-

hook, which passes it along to a speciﬁc URI. There-

fore, Webhooks use Web services as callbacks on re-

mote Web APIs (Benslimane et al., 2008) e.g. de-

livering event data to predeﬁned Web resources. An

open server-to-server publish/subscribe protocol is

PubSubHubbub (https://code.google.com/p/pub sub-

hubbub/), which uses Webhooks to announce updates

from other servers with interesting content. Through

push notiﬁcations and instant event propagation it is

possible to create a reactive real-time system.

2.3 Evolutionary Event Aggregation

Complex Event Processing (CEP) is rather important

for event aggregation (Anicic et al., 2010) and may

be used for event compositions. CEP focuses on pre-

deﬁned relations and temporal patterns, typically on

different streams of data or events. CEP processes

complex event patterns; in other words, it may de-

rive complex events from simple events. However,

we believe in an asynchrony event aggregation to-

gether with ECA Rules. This enables processing large

amounts of data and assembling compositions in real-

time.

ECA

Rules

Action

Dispatcher

Events Actions

Rule

Engine

Event

Trigger

Data

Event

Aggregation

ECA

Rules

Event

Listener

Web

Service

Web

Service

Web

Service

Figure 2: Condition Action System connects to Web ser-

vices. Web services deliver data to the Event Trigger or

events to the Event Listener. Subsequently, the Rule Engine

processes events according to predeﬁned ECA Rules and

instructs the Action Dispatcher for further actions.

After all, ECA Rules may help the Rule Engine

to detect aggregated data changes in order to dispatch

predeﬁned actions. The last piece in our scheme is

the Action Dispatcher, which is responsible for the

binding of data ﬂow and actions between heteroge-

neous Web resources. An Action Dispatcher allows

ﬂexible coupling with Web Resources, similar to the

Event Trigger module. Event Trigger and Action Dis-

patcher are abstractions of the communication ﬂow in

between Web services and resources.

3 CONDITION ACTION SYSTEM

IMPLEMENTATION

We have developed a Condition Action System proto-

type, which fulﬁls our architectural model for a re-

active Web. Since Web service communication is

latency-driven, we assumed asynchronous commu-

nication and scalability mechanisms to be core fea-

tures for our prototype system. Another key aspect

is the programmability of Events, which means that

JavaScript code can be programmed and ran in the

system straightaway (See 3.2 Web Change Detection

Rule).

Figure 3: Web users create Event Rules in order to deﬁne

the desired reaction out of all available Events. Speciﬁc

Conditions and Actions are programmable during the cre-

ation of an Event Rule. Administrators may either create

(program) Events or Actions.

3.1 Detection Interval

New information confronts us all over the Web. Un-

fortunately, we waste a lot of time until we realise

that these updates have happened. The challenge re-

mains to be the fastest to know about these updates.

Manual capturing of this knowledge implies a mas-

sive delay in reaction and it is certainly not in real-

time. Great value would be added for academics and

businesses but also for Web users if desired informa-

tion from any source had been automatically retrieved

within seconds of a change. Detecting and reacting

to Web changes would require an instrument for the

FacilitatingtheReactiveWeb-AConditionActionSystemusingNode.js

identiﬁcation, the capturing, the aggregation and the

placement of knowledge in the users preferred way.

Sometimes Web users become aware of knowl-

edge within seconds. More frequently, new informa-

tion stays undetected for several hours when not days

e.g. a deadline extension. To capture such events our

Condition Action System provides reaction mecha-

nisms regarding time.

Figure 4: The Condition Action System focuses on reac-

tion times within the red boundaries. An interval time must

be set for the detection of events and is limited to seconds,

minutes, hours or days. Different areas are in scope of the

system e.g. reports, weather forecast and press releases.

3.2 Web Change Detection Rule

Many documents in the Web are dynamically modi-

ﬁed over time. Some might change in an interval of

a few minutes e.g. reports on news portals (minutes),

while other content changes much slower e.g. entries

on encyclopaedia sites such as Wikipedia (days). To

detect these changes, a Condition Action System must

keep track of the document for example with the help

of a history. This would allow to compare Web re-

sources and in case of a speciﬁc change, it would trig-

ger an action.

Consequently, Web users have to set up a detec-

tion rule, which checks a website (URI) for changes.

The idea is to detect for example a paper submission

deadline for a conference. On a date change on the

website, the system sends the new submission date to

an email address.

The rule has to use an Event Trigger, we name

it DetectWebsiteChange, which actually identiﬁes

changes on a deﬁned website. The rule only encom-

passes the URI and the HTML tag e.g. an id or a class.

If the Condition Action System detects a change, a

mail will be sent to the provided email address. Be-

low the Web change detection rule is represented in

the JSON format:

{

"id": "Web Detection Rule",

"event": {

"DetectWebsiteChange->byId": {

"uri": "http://webist.org",

"id": "DOM element"

}

"conditions": [],

"actions": {

"OnWebsiteChange->writemail": {

"receipient": "mail@address.com",

"text": "Deadline has changed!"

}

The JSON rule code requests the Event Trig-

ger DetectWebsiteChange to look for changes on the

given URI and selects the HTML element with the

given id attribute. As soon as a change in this partic-

ular HTML element is detected, it is pushed forward

as an event. In this case, conditions and actions are

taking over. If for example the action write mail is

correctly conﬁgured for this rule, a mail will be sent

with the changed deadline. For the means of customi-

sation, actions can also access data from events.

3.3 Condition Action System

Architecture

The Condition Action System prototype consists of

ﬁve modules (see Figure 5):

• Poller: Loads Event Trigger modules and for-

wards their emitted events to the Event Queue.

Event Trigger modules poll for changes in the

Web and transform them into events.

• Event Listener: Listens on local URIs of active

Webhooks for events and forwards them to the

Event Queue.

• Event Queue: Acts as an event buffer.

• Rules Engine: Processes events from the Event

Queue whenever they get available.

• User Request Handler: The user interfaces to ad-

ministrate Event Triggers, Webhooks, Rules and

Action Dispatchers.

These modules deal with event and action objects.

An event object has a time and source attribute while

an action has a target URI and additional conﬁgura-

tion parameters. Condition objects consist of a logical

statement with on event based parameters.

On start-up, the Condition Action System loads all

stored rules and for each rule it loads all related Ac-

tion Dispatchers. The system also notiﬁes the Poller

in case of a new rule, which in turn loads an Event

Trigger. Subsequently, the Event Listener loads all

stored Webhooks and starts to listen for new events.

At this stage, the Condition Action System is up and

running and accepts administration requests for Event

Triggers, Webhooks, Rules and Action Dispatchers.

If an event occurs, data is forwarded to the Event

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

Passively

Retrieve Events

Dispatch

Actions

Dequeue

Events

Enqueue

Events

Actively

Detect Events

Create / edit

Action Dispatchers

Action Dispatcher

Administration

Load Event Triggers

for new / updated Rules

Event

Listener

Poller

Create / edit

Event Triggers

Store / load

Event Trigger

Administration

New / updated Rule

notification

Create / edit

Rules

Store / load Store / load

Load Action Dispatchers

for new / updated Rules

Web

Event

Triggers

Rules

Action

Dispatchers

User Request

Handler

Rules Engine

Rules

Administration

Webhooks

Store / load

Load Rules

on Startup

Load Webhooks

on Startup

Create / edit

Webhooks

Create new

Webhooks

Webhook

Administration

Event

Queue

Figure 5: Architecture of the Condition Action System. In the upper part of the ﬁgure, the core functionalities of the Condition

Action System are shown. Poller and Event Listener forward events to the Event Queue. The Rules Engine evaluates events

one after the other. In the middle of the ﬁgure, the personalised conﬁguration is persisted in databases. Conﬁguration of the

whole system is manageable via a user interface, which is shown in the lower part.

Queue. Whenever a rule is met, the Poller and the

Rule Engine start up the required Event Triggers or

Action Dispatchers. The Event Queue processes all

incoming events in which ECA Rules may be applied.

3.4 Technologies Used

XML and JSON are standard formats for information

exchange between Web services. Both formats de-

scribe data in tree structures, which our Condition Ac-

tion System can use. Furthermore, it is a communica-

tion format, which the system uses for the structure of

events. The event-driven architecture was built upon

the recent adoption of server side JavaScript through

Node.js and its both human and machine-readable

JSON communication format.

Three platforms for the prototype system were

tested. Early testing instances were on a 64-bit, i5 2.3

GHz dual-core system with 3GB of DDR3 SDRAM

and 100GB of storage capacity running with Linux

3.2 kernel, Node.js version 0.8.24 and the in-memory

key-value store database redis 2.7.105.

One instance was running on a virtual machine

with 64-bit Intel Xeon 2 GHz single-core CPU, 1GB

RAM and 120GB disk space as well as Node.js ver-

sion 0.8.24 and redis 2.7.105. The prototype system is

running on Amazon Elastic Compute Cloud Instance

with a single-core 64-bit CPU, 1GB of memory and

8GB of attached storage, which runs on a Linux 3.2

kernel, Node.js version 0.10.2 and redis 2.8.7.

As shown in the architecture schema below, the

prototype system is a centralised solution. Thanks to

the asynchronous communication paradigm, an im-

plementation of several parallel running systems in

the amazon cloud will be a minor next step and bring

scalability for a larger use.

A list of important node.js libraries used for the

prototype is given here:

• Cheerio: Parsing of a webpage and access to its

structure, similar to jQuery.

FacilitatingtheReactiveWeb-AConditionActionSystemusingNode.js

• CoffeeScript: Domain speciﬁc programming lan-

guage used as a transcompiler to JavaScript.

• Express: Eased running of a server instance in

terms of request mapping to handler functions and

folder structures.

• Gulp: Stream-based workﬂow automation.

• Import.io: Webpage querying over their API with

helps of personalised masked generated via their

own browser.

• JS-select: Selectors for data nodes in tree struc-

tures.

• Request: Enables communication between

servers.

3.5 Proof of Concept

One key problem with Web resources is that users

(customers) cannot verify the quality of these ser-

vices. With the help of our prototype system, a mea-

surement can be realised. Such a system may check

whether the website is reachable and may pay atten-

tion to relevant changes. As a result, a reactive system

creates a reliable source for the quality of Web appli-

cations and services e.g. uptime and downtime.

The prototype system has been used to test vari-

ous scenarios. A ﬁrst proof of concept has focused

on two Swiss electronic newspapers. Over a period

of one week, the Condition Action System collected

data from their websites in order to observe the fre-

quency of headline changes. What is interesting in

this particular data set is that the headline of the clas-

sical newspaper, which is available on the Web and

as well on ordinary paper, changed on average after

two to six hours. The other news website, which has

a web presence only, tends to change the headline on

average within two hours and therefore in a higher fre-

quency. In addition, we were also able to determine a

webserver failure of one news portal, which lead to a

20-minute long service disruption. This example out-

lines the potentials of the web change detection sce-

nario (see Section 3.2).

Many documents in the Web are dynamically

modiﬁed over time. Some might change in an inter-

val of a few minutes e.g. news on news portals, while

other content changes much slower e.g. entries on en-

cyclopaedia sites such as Wikipedia. To detect these

changes, our prototype system must keep track of the

document history. An Event Listener monitors Web

resources and as soon as differences are detected, an

action is triggered. Consequently, the user is able to

set up a rule, which checks whether changes are re-

lated to a certain category of interest or not. More-

over, it could highlight certain areas of interest or an-

other speciﬁed website and compare how signiﬁcant

these changes are. If for example a Wikipedia arti-

cle has been changed in more than 10% of its original

content, a moderator should be informed to revise the

article. Thus, the system is able to directly inform the

moderator via mail.

4 CONCLUSION

Existing Condition Action Systems are limited to

Web services and discourage Web users from pro-

gramming own program code. Our goal was to cre-

ate a Condition Action System with both options;

inbuilt programming window and already existing

Event Rules. However, the system has qualiﬁed for

future performance tests against existing Condition

Action Systems.

Novelties have their greatest value if they are per-

ceived immediately, in the best case in real-time. Re-

activity stands for the focal point in instantly notifying

users or creating something new out of changes in the

Web e.g. a tweet on Twitter. Such a Reactivity en-

tity in the Web may help users in orchestrating such

behaviour.

This paper has addressed promises of a Condition

Action System that can be valuable for Web users in

orchestrating tedious tasks of Web services. Based

on one scenario, the system architecture has been as-

sessed in detecting Web changes; the system is run-

ning for more than half a year. Moreover, the pro-

posed architecture of the Condition Action System

is very powerful for the measurement of all kinds of

Web resources. Difﬁculties arise, however, when an

attempt is made to store data by using the architec-

ture. Event Triggers, Webhooks, Rules and Action

Dispatchers are stored in a database, the changes on

the Web, which create an event are not. It might be

interesting in future to store data of these changes in

order to use it for further data mining.

REFERENCES

Akbar, Z., Garca, J., Toma, I., and Fensel, D. (2014). On

Using Semantically-Aware Rules for Efﬁcient Online

Communication, volume 8620 of Lecture Notes in

Computer Science. Springer International Publishing.

Anicic, D., Fodor, P., Rudolph, S., Sthmer, R., Stojanovic,

N., and Studer, R. (2010). A Rule-Based Language

for Complex Event Processing and Reasoning, volume

6333 of Lecture Notes in Computer Science. Springer

Berlin Heidelberg.

Benslimane, D., Dustdar, S., and Sheth, A. (2008). Services

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

mashups: The new generation of web applications. In-

ternet Computing, IEEE, 12(5):13–15.

Blackstock, M. and Lea, R. (2014). Towards a distributed

data ﬂow platform for the web of things. 5th Inter-

national Workshop on the Web of Things, 2014, pages

1–6.

Dijkman, R. M., Dumas, M., and Ouyang, C. (2008).

Semantics and analysis of business process models

in bpmn. Information and Software Technology,

50(12):1281 – 1294.

Duquennoy, S., Grimaud, G., and Vandewalle, J.-J. (2009).

Consistency and scalability in event notiﬁcation for

embedded web applications. In Web Systems Evolu-

tion (WSE), 2009 11th IEEE International Symposium

on, pages 89–98.

Eugster, P. T., Felber, P. A., Guerraoui, R., and Kermarrec,

A.-M. (2003). The many faces of publish/subscribe.

ACM Comput. Surv., 35(2):114–131.

Hasan, S., O’Riain, S., and Curry, E. (2012). Approximate

semantic matching of heterogeneous events. In Pro-

ceedings of the 6th ACM International Conference on

Distributed Event-Based Systems, DEBS ’12, pages

252–263, New York, NY, USA. ACM.

Hausmann, S. and Bry, F. (2013). Towards complex ac-

tions for complex event processing. In Proceedings

of the 7th ACM International Conference on Dis-

tributed Event-based Systems, DEBS ’13, pages 135–

146, New York, NY, USA. ACM.

Ovadia, S. (2014). Automate the internet with if this then

that (ifttt). Behavioral & Social Sciences Librarian,

33(4):208–211.

Paschke, A. (2014). Reaction ruleml 1.0 for rules, events

and actions in semantic complex event processing.

In Rules on the Web. From Theory to Applications,

volume 8620 of Lecture Notes in Computer Science,

pages 1–21. Springer International Publishing.

Paschke, A., Boley, H., Zhao, Z., Teymourian, K., and

Athan, T. (2012). Reaction ruleml 1.0: Standard-

ized semantic reaction rules. In Rules on the Web:

Research and Applications, volume 7438 of Lecture

Notes in Computer Science, pages 100–119. Springer

Berlin Heidelberg.

Trifa, V., Guinard, D., Davidovski, V., Kamilaris, A., and

Delchev, I. (2010). Web messaging for open and scal-

able distributed sensing applications. In Proceedings

of the 10th International Conference on Web Engi-

neering, ICWE’10, pages 129–143, Berlin, Heidel-

berg. Springer-Verlag.

Windley, P. (2012). The Live Web: Building Event-Based

Connections in the Cloud. Course Technology.

Wohed, P., van der Aalst, W., Dumas, M., and ter Hofstede,

A. (2003). Analysis of web services composition lan-

guages: The case of bpel4ws. In Conceptual Modeling

- ER 2003, volume 2813 of Lecture Notes in Computer

Science, pages 200–215. Springer Berlin Heidelberg.

Yahoo! (2010). Pipes [www document],

http://pipes.yahoo.com/pipes/docs?doc=overview

(accessed 18.12.14).

FacilitatingtheReactiveWeb-AConditionActionSystemusingNode.js
