Stochastic Analogues of Invariants

Martingales in Stochastic Event-B

Richard Banach

School of Computer Science, University of Manchester, Manchester, U.K.

Keywords:

Model based Frameworks, Event-B, Stochastic Extensions, Invariants, Martingales.

Abstract:

In conventional formal model based development frameworks, invariants play a key role in controlling the

behaviour of the model (when they contribute to the deﬁnition of the model) or in verifying the model’s

properties (when the model, independently deﬁned, is required to preserve the invariants). However, when

variables take values distributed according to some probability distribution, the possibility of verifying that

system behaviour is, in the long term, conﬁned to some acceptable set of states can be severely diminished

because the system might, in fact, with low probability fail to be thus conﬁned. This short paper proposes

martingales as suitable analogues of invariants for capturing suitable properties of non-terminating systems

whose behaviour is with high probability good, yet where a small chance of poor behaviour remains. The idea

is explored in the context of the well-known Event-B framework.

1 INTRODUCTION

In conventional formal model based development

frameworks invariants play a key role in controlling

the behaviour of the model. In frameworks in which

they are part of the deﬁnition of the model (such as

Z (Spivey, 1992; ISO-Z, 2002)) they restrict the be-

haviour of the rest of the model. In most frameworks

though, and typically in the various dialects of the B-

Method (Abrial, 1989; Abrial, 1996; Abrial, 2010),

invariants are proposed independently of the system

model and then the behaviour of the system as deﬁned

must be provedto conform to the invariants — i.e. the

reachable set, as deﬁned by the system model, must

be a subset of any stated invariant set of states. This

is normally done by an inductive technique which

proves that every state change allowed by the system

model results in an after-state that is within the in-

variant set, provided the before-state was also in the

invariant set.

All of this works ﬁne when variable values are

assigned either deterministically, or in more abstract

settings, nondeterministically. Considering pure non-

determinism, no restriction is placed on the occur-

rence of any allowed value, so any system invariant

must include all the possibilities permitted by all the

nondeterminism in the model in order that the model

preserves the invariant. However, in practice, systems

often have smaller families of states that are visited

frequently, with other permitted states visited much

less frequently. A simple invariant cannot capture the

distinction between the smaller ‘frequently visited’

subset and the infrequently visited ‘outlying states’.

The distinction between frequently visited and in-

frequently visited is quantiﬁed in probabilistic terms.

When the values taken by variables are labelled with

probabilities (implicitly also labelling the transitions

that cause those values to be adopted), then in prin-

ciple, we can make precise statements regarding the

likelihood that the system trajectory remains in a cer-

tain region of the state space. Useful byproducts of

this are statements that the long term behaviour of the

system is predominantly conﬁned to a relatively small

portion of the state space, despite the probability of its

visiting other states being non-zero (though small).

This short paper proposes the martingale concept

from stochastic calculus (see e.g. (Resnick, 1992;

Grimmett and Stirzaker, 2001)) as a suitable analogue

for an invariant in comparable situations. For exam-

ple, it can be used to capture such properties of non-

terminating systems as when their behaviour is with

high probability ‘good’, yet where a limited probabil-

ity of ‘poor’ behaviour remains. The idea is explored

in the context of the well-known Event-B framework,

using a small case study drawn from the Mondex

Electronic Purse problem (Stepney et al., 2000) —

this was the ﬁrst problem in the Veriﬁcation Grand

Challenge, active for a number of years now (Jones

238

Banach R..

Stochastic Analogues of Invariants - Martingales in Stochastic Event-B.

DOI: 10.5220/0005431602380243

In Proceedings of the 10th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2015), pages 238-243

ISBN: 978-989-758-100-7

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

et al., 2006; Woodcock, 2006; Woodcock and Banach,

2007; Jones and Woodcock (eds.), 2008).

In the rest of this paper we do the following. In

Section 2 we give a brief description of Event-B, for

purposes of orientation. In Section 3 we describe a

fragment of the Mondex Purse problem, originally de-

veloped in Z, using Event-B. In Section 4 we give a

short introduction to martingales, in the form we will

need them later. In Section 5 we focus our martingale

discussion on the Mondex problem introduced earlier.

Section 6 concludes, and looks forward to the further

development of the ideas presented here, especially

in their application to hybrid and cyber-physical sys-

tems.

2 EVENT-B

In this section, we brieﬂy review Event-B machines

and their ingredients. Explicit examples of these

things will appear below.

In a nutshell, an Event-B MACHINE has a name,

it SEES one or more static contexts, and it owns

some VARIABLES. The latter are allowed to be up-

dated via EVENTS, but are required to always satisfy

the INVARIANTS (this requirement generating ver-

iﬁcations conditions a.k.a. proof obligations (POs)).

The events can declare their own parameters (which

are bound variables which can be used to reduce in-

ternal nondeterminism, or to carry input values or

output values). Furthermore, each event has one

or more guards which deﬁne when the event is en-

abled, and one or more actions which deﬁnes the state

change to be implemented by the event, speciﬁed via

before-after predicates (or notations such as assign-

ment for simpler cases). Among the events there is an

INITIALISATION, whose guard must be true.

The semantics of Event-B machines, is expressed

via a number of POs. These must be provable in order

for the machine in question to be well deﬁned. We

quote the main ones of interest to us, mentioning the

others more brieﬂy. See (Abrial, 2010; Abrial et al.,

2010) for full details.

For a machine A to be well deﬁned the initialisa-

tion, feasibility and correctness POs must hold:

Init

′

) ⇒ I(u

′

) (1)

I(u) ∧ G

(u) ⇒ (∃u

′

• Ev

(u,u

′

)) (2)

I(u) ∧ G

(u) ∧ Ev

(u,u

′

) ⇒ I(u

′

) (3)

In (1), Init

is the initialisation event and (1) says that

the value u

′

of A’s state variable u established by Init

satisﬁes A’s invariant I(u

′

). Then (2) says that event

is feasible; i.e. when it is enabled in an invariant

state (I(u) ∧ G

(u)) then an after-state u

′

exists so

that Ev

(u,u

′

) can complete successfully. Likewise,

(3) says that for Ev

, if A’s invariant I(u), and Ev

’s

guard G

(u), both hold in the before-state u of the

event, and Ev

’s before-after relation Ev

(u,u

′

) also

holds (for an after-state u

′

whose existence is estab-

lished by (2)), then the after-state will satisfy the in-

variant I once more (i.e. we have invariant preserva-

tion). In (1), (2) and (3) we have suppressed mention

of the details of the static contexts seen by machine

A, and have suppressed mention of any local bound

variables or of inputs or outputs. These would be

easy to include in the before-after relation if desired.

Aside from (1), (2) and (3), the initialisation must also

be feasible, and for non-terminating systems we must

also have deadlock freedom:

I(u) ⇒\/

A,k

′

) (4)

This says that if the invariant I(u) holds in a state u,

then some event Ev

A,k

is enabled. See (Abrial, 2010;

Abrial et al., 2010) for more details. Non-terminating

systems are of particular interest in this paper.

3 THE MONDEX PURSE

The Mondex Electronic Purse (Stepney et al., 2000),

produced by the NatWest Development Team, is a

system of Smartcard-based electronic purses carry-

ing currency for electronic commerce applications.

Clearly, this is a security-critical application. For this

reason, the developers of Mondex (formerly a part of

NatWest Bank U.K.), employed state of the art meth-

ods to ensure the implementation was as robust as

possible. At the time of its creation (in the late 1990s),

the Mondex Purse achieved an ITSEC (D.T.I., 1991)

rating of E6. This requires a formal abstract model,

a formal concrete model, and a proof of correspon-

dence between them. (In the case of Mondex, the cor-

respondence proof was a proof of reﬁnement.) This

was the the highest possible dependability standard

achievable at the time, and the development was a

trailblazer for showing that fully formal techniques

could be applied within realistic time and cost limi-

tations to industrial scale applications.

The abstract model of the Mondex Purse system

describes a world of purses which exchange value

through atomic transactions, and speciﬁes the security

properties: purse authentication, preservation of over-

all system value, and correct processing of both trans-

ferred and lost value. The concrete model describes

a distributed system of purses, transferring value via

an insecure and lossy medium using an n-step pro-

tocol. Security features are implemented locally on

StochasticAnaloguesofInvariants-MartingalesinStochasticEvent-B

239

each purse. In the ﬁeld each purse is self-sufﬁcient,

logging any lost value from failed transactions locally,

for later central archiving and reconciliation.

We have neither the space nor the need to describe

all of the above fully. A good account, from the van-

tage point of the work done on Mondex in the Veri-

ﬁcation Grand Challenge, can be gained from (Jones

and Woodcock (eds.), 2008) in particular.

For us, it will be sufﬁcient to focus on one detail

of Mondex’s operation, the event —to use Event-B

terminology— that updates the sequence number that

each purse maintains to prevent replay attacks. This

event is introduced at the intermediate level of mod-

elling in (Stepney et al., 2000) and is in fact an ab-

straction of a number of internal operations of a real

purse that need the no-replay property. (Evidently an

event that literally does nothing other than increase a

sequence number is rather pointless in a real applica-

tion.) In Event-B notation it can be captured in the

following small machine:

MACHINE Mondex0

VARIABLES

seqno

INVARIANTS

seqno ∈N

EVENTS

INITIALISATION

BEGIN

seqno := 0

END

Increase

ANY inc

WHERE inc ∈N ∧

0 < inc

THEN

seqno :=

seqno+inc

END

In Mondex0, having been initialised to 0, the vari-

able seqno increases by an arbitrary positive integer at

each Increase event (the arbitrariness being intended

to prevent attacks based on predicting the next se-

quence number). More realistically, the increment

will not really be arbitrary, but will be drawn from

a ﬁnite range, say 1 ≤inc ≤10, yielding:

MACHINE Mondex1

... ... ... ...

Increase

ANY inc

WHERE inc ∈N ∧

1 ≤inc ≤ 10

THEN

seqno :=

seqno+ inc

END

In such a case all that we could say with certainty

would be that seqno was not greater than 10 times the

number of Increase calls, nor smaller than one times

the number of Increase calls, a fact that we could ex-

press via an invariant if we introduced a variable to

count the number of calls to Increase.

However, it is reasonable to presume that individ-

ual occurrences of inc in a run would be uniformly

distributed over 1..10 for example. In that case, it is

equally reasonable to deduce that, on average, seqno

would increase by 5

on each Increase call. In fact,

a closer probabilistic analysis reveals that the more

calls to Increase are made, the closer, on average, the

behaviour of seqno adheres to that behaviour. But it is

impossible to express such a fact via a straightforward

state invariant. This observation brings us to the topic

of martingales.

4 MARTINGALES

In this section we give a brief introduction to mar-

tingales. We start with the idea of a stochastic pro-

cess. A stochastic process is a family of random vari-

ables X = X

,.. . indexed by ‘some analogue

of time’. If the analogue of time is a conventional dis-

crete set, such as the natural numbers, then the family

can be written in a form similar to X and we speak

of a discrete stochastic process. Alternatively, if the

analogue of time is, say, a segment of the reals, then

we need a continuous index, and we speak of a con-

tinuous stochastic process. (We will not need the con-

tinuous case in this paper.)

With the family X we associate another family

of random variables S = S

,.. . indexed in the

same way. The family S is a martingale with re-

spect to the family X if two conditions hold. Firstly,

the expectation of the absolute value of each random

variable S

is ﬁnite: E(| S

|) < ∞. Secondly, the ex-

pectation of each ‘next’ S

n+1

, conditional on the val-

ues of all the X

s up to n, is equal to the value of

: E(S

n+1

| X

... X

) = S

. (Of course it is possi-

ble for a family X to be a martingale with respect to

itself, but in most cases of interest this does not quite

work, and we typically need to apply some function

to the members of X before a martingale is derived:

= φ

... X

).)

The intuition behind the martingale concept may

be brieﬂy described as follows. The outcomes of the

random variables S

... S

, being random, are unpre-

dictable. But having arrived at these outcomes, there

are no grounds for expecting the outcome of the next

one in the sequence S

n+1

, to be different, on average,

to the value that has been arrived at thus far. This

comment also helps to explain why we usually need

two sequences, X and S , to deﬁne a martingale. The

sequence most conveniently to hand in an application,

X say, will typically display a ‘drift’ of some kind that

prevents it from being a martingale in its own right;

and so, to obtain a martingale, we modify it in an ap-

propriate way (using functions φ

say) to get a mar-

tingale S .

Why are martingales (which are intensely studied

in probability theory) of interest? The main reason is

that under rather mild restrictions, martingales enjoy

ENASE2015-10thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

240

signiﬁcant convergence properties. (N. B. The pre-

cise details of these properties and of the needed re-

strictions vary according to the speciﬁc convergence

theorem being discussed — we do not delve into the

technical details in this paper.) Although the details

vary from result to result, in general, the restrictions

involve uniform bounds on a low order moment of

the martingale, and promise convergence (in a suit-

able sense) of the martingale sequence to a limiting

random variable S

∞

, i.e. S → S

∞

in a suitable manner.

The convergence to a limiting behaviour given by

∞

is the feature of a martingale S that we identify

as being analogous to an invariant property. It allows

us to neglect transient details in favour of concentrat-

ing on the long term properties of the behaviour that

are often of the greatest interest for practical appli-

cations. Of course, whether it is permissible to ne-

glect such transient details will depend critically on

the application in question, and refers very much to

the requirements pertaining to the transients and to

their signiﬁcance in the application as a whole. When

it is appropriate to do so, the martingale approach can

be expected to give a much tighter quantiﬁcation of

system behaviour than an invariant based approach in

which the invariants must accommodate every possi-

ble outlier, no matter how extreme it is or how rarely

it might occur.

5 THE MONDEX SEQUENCE

NUMBER AS MARTINGALE

With the preceding background, we reexamine our

Mondex sequence number case study. Bearing in

mind the remarks just above concerning require-

ments, we ﬁrst accept that being interested in the

sequence number in terms of its average behaviour

is reasonable. We know from the Mondex0 and

Mondex1 models, that the sequence number is guar-

anteed to increase at each call of Increase, which

would (in an application of more realistic size) help

to ensure the key no-replay safety property.

With this aspect conﬁrmed, we can look at quan-

tifying the average behaviour via a martingale. We

knowfrom our previous discussion that we expect that

the seqno variable will increase by about 5

on each

call of Increase, so we want to turn this behaviour into

a martingale. Obviously the variable seqno by itself

will not do, since it evidently does not approach any

limit. This illustrates rather well the remark made in

Section 4, that often, the most selfevident variables do

not provide a martingale directly, but that some ad-

justment is needed before the requisite convergence

properties emerge.

In our case, we can take the X

random variables

as the successive values of seqno, and one way to ob-

tain convergence is to introduce a suitable analogue

of time. For us, a ‘tick’ variable tk that is incremented

by 1 on each Increase call will do the job. Now we

can divide the successive values of seqno by the cor-

responding value of tk, and the resulting sequence

of values will converge to the mean of a single trial,

namely 5

, as required. These successive values can

be taken as the S

values corresponding to our X

val-

ues. We are not quite done though. Martingale con-

vergence requires that low order moments of S

are

uniformly bounded.

Looking at the successive values of seqno/tk, and

noting that they are successive sums of independent

identically distributed random variables, each drawn

from a ﬁnite distribution, we can use the Central

Limit Theorem to deduce that although the mean of

seqno −5

tk tends to 0, the standard deviation will

grow as the square root of the number of trails, i.e. as

the value of

√

tk. So seqno/tk−5

will tend to 0, and

its standard deviation will tend to 0. In other words

the limiting distribution for seqno/tk will converge(in

probability) to a point mass centred on 5

. This gives

us a martingale derived from the seqno variable’s be-

haviour.

However, the preceding is not the only way of

dealing with this example. The Central Limit The-

orem states that, in distribution, the successive values

of seqno satisfy, in the limit, (seqno −nµ)/

√

nσ

→

N(0,1), where n is the number of increments, σ

the variance of the distribution of a single trial, and

N(0,1) is the standard normal distribution. Applying

this to our situation, we create a martingale as follows.

The X

are as before, but this time the S

are de-

ﬁned as seqno/

√

tk−5

√

tk. By what we said above,

this will converge to N(0,1)/SD, where SD is the

standard deviation of the single trial distribution. This

gives us a second martingale based on the same case

study. The structure of the second martingale displays

a feature that occurs commonly, namely a ‘drift’ term,

this being 5

√

tk, the term that has to be subtracted

from the ‘main’ term seqno/

√

tk in order to gain sta-

bility in the convergence process.

It remains to package these insights into a form

compatible with the structure of Event-B models. We

introduce a fresh syntactic component into an Event-

B machine, the MARTINGALES clause (allowing for

more than one, by analogy with the INVARIANTS

clause). In its most primitive form a syntactic martin-

gale of this kind will consist of four expressions: the

ﬁrst being the ‘raw’ stochastic expression of interest,

In much of the martingale literature it would be referred

to as the compensator.

StochasticAnaloguesofInvariants-MartingalesinStochasticEvent-B

241

and the second being the drift term that has to be sub-

tracted from it. Next, we would have the mean of the

limiting distribution, followed by an additional term

that quantiﬁes the standard deviation of the limiting

distribution.

In this way the ﬁrst martingale we derived would

be expressed thus:

MARTINGALES

[ seqno/tk ; 0 ; 5

; 0 ]

and the second thus:

MARTINGALES

[ seqno/

√

tk ; 5

√

tk ; 0 ; 1/SD ]

The model Mondex2 below shows how these details

have been incorporated into the earlier model. The tk

variable has been included in the model,

and the de-

tails of the two martingales explored above have been

packaged into the MARTINGALES clause, each mar-

tingale’s components being enclosed in square brack-

ets, and each listed, separated by semicolons, in the

order: raw ; drift ; mean ; standard deviation.

MACHINE Mondex2

VARIABLES

seqno

INVARIANTS

seqno ∈N

tk ∈ N

MARTINGALES

[ seqno/tk ;

0 ; 5

; 0 ]

[ seqno/

√

tk ;

√

tk ; 0 ; 1/SD ]

EVENTS

INITIALISATION

BEGIN

seqno := 0

tk := 0

END

Increase

ANY inc

WHERE inc ∈ N ∧

inc ∈U[1..10]

THEN

seqno :=

seqno+ inc

tk := tk+ 1

END

The account just developed may be compared with

the earlier treatment of the sequence number issue

that appeared in (Banach et al., 2005). In (Banach

et al., 2005), the authors considered the Mondex se-

quence number issue from a different perspective,

though based on very similar technical details.

In that work, we were interested in stepping from

a relatively ideal formal description of some of the re-

quirements (including deidealising an ideal model of

the sequence number) to a more realistic one.

So,

An alternative approach would be to incorporate such

an ‘analogue of time’ variable as part of the framework it-

self.

In fact the cited paper was just the ﬁrst element in a

wider study of the imperfect treatment of some Mondex re-

quirements in the formal models of (Stepney et al., 2000),

see (Banach et al., 2005; Banach et al., 2006a; Banach et al.,

there, the idea was to quantify the difference between

the idealised and more realistic treatments of the se-

quence number, in order to produce evidence that the

parameters chosen for the real implementation were

appropriate. The simplest way of doing that involved

a calculation very similar in character to the one in

this paper. However, there, the whole process neces-

sarily resided outside of the formal elements of the

system model. In this paper, the more formal treat-

ment via martingales opens the door to a more generic

and systematic treatment of similar problems.

6 CONCLUSIONS

The familiar invariant based way of specifying and

reasoning about programs has been used for a long

time to bring greater dependability to the systems

constructed using those techniques. However, many

properties of such systems are stochastic in nature

rather than absolute. For those aspects, the invariant

based approach tends to give extremely conservative

results, too conservative to be useful in practice. (This

is particularly so in the case of variables with distribu-

tions which are not bounded; for example if the incre-

ments of seqno were drawn from an exponential dis-

tribution. In such a case the only invariant one could

write regarding such a variable would be true.) What

is desirable for these situations is a more stochastic

analogue of the concept of program invariant. In this

paper we have advanced the idea that the martingale

concept from the theory of stochastic processes is a

plausible such analogue.

In the preceding sections, using a simple example,

we have proposed that martingales can give us an ana-

logue of invariants in situations where the long term

behaviour of a digital system tends to stability, even

though the short term behaviour may admit ﬂuctua-

tions of much greater amplitude.

Of course, probabilistic behaviour in transition

systems is not new and has been studied intensively.

From an extensive literature we cite only (Heerink

and Tretmans, 1996; McIver and Morgan, 2005; van

Breugel and Worrell, 2001). In general, the stochastic

approachdoes not sit very comfortably with the famil-

iar nondeterminism and invariant based one, which

uses nondeterminism to circumscribe unknown as-

pects of system behaviour (rather than probability).

In the majority of the existing probabilistic work

(that focuses on the probabilistic quantiﬁcation of

program behaviour), the focus is on detailed correct-

ness notions, in other words, despite permitting prob-

abilistic behaviour, the concern is with the properties

2006b; Banach et al., 2007).

ENASE2015-10thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

242

of individual steps. This contrasts with our focus,

which permits transient behaviour to be disregarded,

in favour of long term averaged properties.

Of course, the discussion in this paper is but a

ﬁrst step in the incorporation of such ideas into a

generic formal context. A particularly fertile possi-

ble application area for such ideas is in the formal

description of cyberphysical systems, with their un-

avoidable involvement of continuous physical pro-

cesses (Sztipanovits, 2011; Willems, 2007; Sum-

mit Report, 2008; National Science and Technology

Council, 2011). There, the use of martingales for the

description of long term noisy physical components

is even more compelling than for the purely discrete

case, due to the fact that the relevant stochastic pro-

cesses typically enjoy an ‘independent increments on

disjoint intervals of time’ property, something well

captured via the theory of ideal continuous stochas-

tic processes. This makes the martingale behaviour of

stochastic physical variables in stable dynamical situ-

ations into a convincing metaphor for observed phe-

nomena. However, a proper treatment of these will

need an excursion into the more challenging continu-

ous version of martingale theory. This remains as fu-

ture work. Also, with the experience of a more fully

worked out proposal, there will be more clarity re-

garding what are the most useful veriﬁcation condi-

tions that should be generated to support martingale

use in formal model based development.

REFERENCES

Abrial, J.-R. (1989). A Formal Approach to Large Soft-

ware Construction. In van de Snepscheut, editor,

Mathematics of Program Construction, volume 375 of

LNCS, pages 1–20. Springer.

Abrial, J.-R. (1996). The B-Book: Assigning Programs to

Meanings. Cambridge University Press.

Abrial, J.-R. (2010). Modeling in Event-B: System and Soft-

ware Engineering. Cambridge University Press.

Abrial, J.-R., Butler, M., Hallerstede, S., Hoang, T., Mehta,

F., and Voisin, L. (2010). Rodin: an open toolset for

modelling and reasoning in Event-B. Int. J. Software

Tools for Technology Transfer, 12(6):447–466.

Banach, R., Jeske, C., Poppleton, M., and Stepney, S.

(2006a). Retrenching the Purse: Finite Exception

Logs, and Validating the Small. In Hinchey, editor,

Proc. NASA/IEEE SEW-30, pages 234–245, Layola

College Graduate Center, Columbia, MD.

Banach, R., Jeske, C., Poppleton, M., and Stepney, S.

(2006b). Retrenching the Purse: Hashing Injective

CLEAR Codes, and Security Properties. In Steffen,

Margaria, and Philippou, editors, ISOLA-06, Paphos,

Cyprus. IEEE.

Banach, R., Jeske, C., Poppleton, M., and Stepney, S.

(2007). Retrenching the Purse: The Balance Enquiry

Quandary, and Generalised and (1,1) Forward Reﬁne-

ments. Fundamenta Informaticae, 77:29–69.

Banach, R., Poppleton, M., Jeske, C., and Stepney, S.

(2005). Retrenching the Purse: Finite Sequence Num-

bers and the Tower Pattern. In Formal Methods 2005,

pages 382–398.

D.T.I. (1991). Information Technology Security Evalua-

tion Criteria. http://www.cesg.gov.uk/site/iacs/itsec/

media/formal-docs/Itsec.pdf.

Grimmett, G. and Stirzaker, D. (2001). Probability and

Random Processes. O.U.P., 3rd edition.

Heerink, L. and Tretmans, J. (1996). Formal Methods in

Conformance Testing: A Probabilistic Reﬁnement. In

Testing of Communicating Systems, pages 261–276.

Springer.

ISO-Z (2002). Information Technology – Z Formal Speciﬁ-

cation Notation – Syntax, Type System and Semantics:

International Standard. ISO/IEC 13568. http://www.

iso.org/iso/en/ittf/PubliclyAvailableStandards/

c021573

ISO IEC 13568 2002(E).zip.

Jones, C., O’Hearne, P., and Woodcock, J. (2006). Veri-

ﬁed Software: A Grand Challenge. IEEE Computer,

39(4):93–95.

Jones, C. and Woodcock (eds.), J. (2008). FAC Special Is-

sue on the Mondex Veriﬁcation. Formal Aspects of

Computing, 20(1):1–139.

McIver, A. and Morgan, C. (2005). Abstraction, Reﬁnement

and Proof for Probabilistic Systems. Springer.

National Science and Technology Council

(2011). Trustworthy Cyberspace: Strate-

gic plan for the Federal Cybersecurity Re-

search and Development Program. http://

www.whitehouse.gov/sites/default/ﬁles/microsites/

ostp/fed

cybersecurity rd strategic plan 2011.pdf.

Resnick, S. (1992). Adventures in Stochastic Processes.

Birkhauser.

Spivey, J. (1992). The Z Notation: A Reference Manual.

Prentice-Hall, second edition.

Stepney, S., Cooper, D., and Woodcock, J. (2000). An Elec-

tronic Purse: Speciﬁcation, Reﬁnement and Proof.

Technical Report PRG-126, Oxford University Com-

puting Laboratory.

Summit Report (2008). Summit Report: Cyber-Physical

Systems. http://iccps2012.cse.wustl.edu/

doc/

CPS

Summit Report.pdf.

Sztipanovits, J. (2011). Model Integration and Cy-

ber Physical Systems: A Semantics Perspec-

tive. In Butler and Schulte, editors, Proc. FM-

11. Springer, LNCS 6664, p.1, http://sites.lero.ie/

download.aspx?f=Sztipanovits-Keynote.pdf. Invited

talk, FM 2011, Limerick, Ireland.

van Breugel, F. and Worrell, J. (2001). Towards Quantitative

Veriﬁcation of Probabilistic Transition Systems. In

Proc. ALP-01, pages 421–432. Springer LNCS.

Willems, J. (2007). Open Dynamical Systems: Their Aims

and their Origins. Ruberti Lecture, Rome. http://

homes.esat.kuleuven.be/∼jwillems/Lectures/2007/

Rubertilecture.pdf.

Woodcock, J. (2006). First Steps in the The Veriﬁed Soft-

ware Grand Challenge. IEEE Computer, 39(10):57–

64.

Woodcock, J. and Banach, R. (2007). The Veriﬁcation

Grand Challenge. JUCS, 13(5):661–668.

StochasticAnaloguesofInvariants-MartingalesinStochasticEvent-B

243
