On the Application of Bio-Inspired Optimization Algorithms to Fuzzy

C-Means Clustering of Time Series

Muhammad Marwan Muhammad Fuad

Forskningsparken 3, Institutt for kjemi, NorStruct

The University of Tromsø - The Arctic University of Norway, NO-9037 Tromsø, Norway

Keywords: Data Mining, Differential Evolution, Distance Metrics, Fuzzy C-Means Clustering, Genetic Algorithms,

Overfitting, Particle Swarm Optimization, Time Series.

Abstract: Fuzzy c-means clustering (FCM) is a clustering method which is based on the partial membership concept.

As with the other clustering methods, FCM applies a distance to cluster the data. While the Euclidean

distance is widely-used to perform the clustering task, other distances have been suggested in the literature.

In this paper we study the use of a weighted combination of metrics in FCM clustering of time series where

the weights in the combination are the outcome of an optimization process using differential evolution,

genetic algorithms, and particle swarm optimization as optimizers. We show how the overfitting

phenomenon interferes in the optimization process that the optimal results obtained during the training stage

degrade during the testing stage as a result of overfitting.

1 INTRODUCTION

A time series is an ordered collection of

observations at intervals of time points. These

observations are real-valued measurements of a

particular phenomenon.

Time series arise in disciplines ranging from

medicine, and finance to meteorology, and

engineering, to name a few. For this reason, time

series data mining has received increasing attention

over the last two decades.

Time series data mining handles several tasks

such as classification, clustering, similarity search,

motif discovery, anomaly detection, and others. All

these tasks are based on the concept of similarity

which is measured using a similarity measure or a

distance metric.

Bio-inspired Optimization, also called nature-

inspired Optimization, is a branch of optimization

which, as the name suggests, is inspired by natural

phenomena. It has diverse applications in

engineering, finance, economics and other domains.

In computer science bio-inspired optimization has

been applied in several fields such as networking,

data mining, and software engineering.

As with other fields of computer science,

different papers have proposed applying bio-inspired

optimization to data mining tasks (Muhammad Fuad,

2012a, 2012b, 2014a).

In this work we study the application of three

well-known bio-inspired optimization algorithms:

differential evolution, genetic algorithms, and

particle swarm optimization, to the task of FCM

clustering of time series where these optimizers are

used to obtain the optimal values of the weights

assigned to the distances that constitute a

combination of metrics used in the FCM clustering

task.

The rest of the paper is organized as follows; in

Section 2 we present background on time series,

clustering, similarity measures, and overfitting. In

Section 3 we introduce the proposed method which

we test in Section 4. The results of the experiments

are discussed in Section 5. We conclude this paper

with Section 6.

2 BACKGROUND

A time series is an ordered collection of observed

data. Formally, a time series S of length n is defined

as;

nnn

tvstvstvsS ,,....,,,,

222111



These values can be real numbers or multi-

dimensional vectors.

348

Muhammad Fuad M..

On the Application of Bio-Inspired Optimization Algorithms to Fuzzy C-Means Clustering of Time Series.

DOI: 10.5220/0005276203480353

In Proceedings of the International Conference on Pattern Recognition Applications and Methods (ICPRAM-2015), pages 348-353

ISBN: 978-989-758-076-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

Data mining is the analysis of data with the goal

of uncovering hidden knowledge in it. Data mining

includes several tasks such as classification,

clustering, anomaly detection, and others.

Processing these different tasks usually requires

extensive computing.

Clustering is a fundamental data mining task.

Clustering seeks for the grouping tendencies of the

data. Clustering can be defined as the process of

finding natural groups, called clusters, in a dataset.

The objective of the clustering task is to find the

most homogeneous clusters that are as distinct as

possible from other clusters. This grouping should

maximize inter-cluster variance while minimizing

intra-cluster variance (Esling and Agon, 2012).

There are several basic clustering methods, those

which concern time series data are Partition-based

Clustering, Hierarchical-based Clustering, and

Model-based Clustering (Liao, 2005). Figure 1

shows the general scheme of the partition-based

clustering algorithm.

Fuzzy c-means Clustering (FCM), is a partition-

based clustering method. FCM is based on the

concept of Partial Membership where the allocation

of the data point to the centers becomes a matter of

degree – the higher the membership value, the

stronger its bond to the cluster (Krzysztof et al,

2007).

The objective of FCM clustering is to minimize

the measure:



pim

xzduE ,







(1)

Where u is the fuzzy membership and m is fuzzy

exponent. In the following we present a brief

description of FCM (Maulik et al, 2011). FCM starts

with random c initial cluster centers. In the

following step, and at every iteration, the algorithm

finds the fuzzy membership of each data object to

every cluster using the following equation:























xzd

(2)

for 1 ≤ p ≤ c, 1 ≤ i ≤ n.

orithm Clustering

Require c

he number of clusters,

n data objects.

(

Randomly) initialize the

cluster centers.

or each data object, and

for each center, comput

he distance between this

ata object and the cluster

enter, assign the data

bject to the closest

center.

3. Update the cluster centers.

4. Repeat steps 2-3 until

convergence.

Figure 1: The partition-based clustering algorithm.

Based on the membership values, the cluster centers

are recomputed using the following equation:







(3)

1 ≤ p ≤ c

The algorithm continues until a stopping condition

terminates it.

2.1 Overfitting

One of the frequent problems encountered when

generating a data mining model is overfitting.

Overfitting results when the provisional model tries

to account for every possible trend or structure in the

training set. In overfitting the algorithm memorizes

the training set at the expense of generalizability to

the validation set (Larose, 2005). There are several

reasons for overfitting, and overfitting-avoidance is

an important research topic in data mining. The

question of overfitting is particularly important

when applying bio-inspired algorithms to perform

data mining tasks (Muhammad Fuad, 2014b).

2.2 Similarity Measures

Measuring the similarity between two time series, on

which clustering and other data mining tasks are

based, is not a trivial task. There have been several

distance metrics and similarity measures proposed in

OntheApplicationofBio-InspiredOptimizationAlgorithmstoFuzzyC-MeansClusteringofTimeSeries

349

the literature. The most common distance metric,

however, is the Minkowski distance, which is

defined between two time series S and T as:



iip

tsTSL







),(

(4)

If p =1, the distance is called the Manhattan distance

or the city block distance. If p = ∞, it is called the

infinity distance or the chessboard distance, and if p

= 2 we get the widely-known Euclidean distance.

Applying any of these distances takes linear time in

the length of the series.

3 APPLYING A COMBINATION

OF DISTANCES TO FCM

CLUSTERING

The idea of applying a combination of distance

metrics or similarity measures to handle data mining

tasks has been proposed by different researchers. In

(Bustos and Skopal, 2006) the authors propose using

a weighted combination of several metrics to handle

the similarity search problem. The novelty of our

work is that we address this as an optimization

problem. More formally, we FCM cluster the time

using a weighted combination of distance metrics

defined as:

 





T,SdT,Sd



(5)

where



1,0





In order to perform this optimization process,

and for comparison reasons, we choose to use three

of the most powerful bio-inspired optimization

algorithms which are Differential Evolution, Particle

Swam Optimization, and Genetic Algorithms.

3.1 Differential Evolution

Differential Evolution (DE) is an evolutionary

optimization algorithm which is particularly adapted

to solve continuous optimization problems.

DE starts with a population of PopSize vectors

each of which is of nbp dimensions, where nbp is the

number of parameters (in our problem, nbp is the

number of distances in the combination given by

equation (5)). In the next step for each individual



(called the target vector) of the population three

mutually distinct individuals



and

different from



are chosen randomly from the

population. The donor vector



is formed as a

weighted difference of two of



, added

to the third; i.e.





3r2r1r

VVFVD





 .

is called

the mutation factor.

The trial vector



is formed from elements of

the target vector



and elements of the donor

vector



according to different schemes. In this

paper we choose the crossover scheme presented in

(Feoktistov, 2006). In this scheme an integer

Rnd is

chosen randomly among the dimensions



nbp,1 .

Then the trial vector



is formed as follows:



























otherwiset

iRndC,randifttFt

j,i

rj,ir,ir,ir,i

321

(6)

where

nbp,...,i 1



C is the crossover constant. In

the next step DE selects which of the trial vector and

the target vector will survive in the next generation

and which will die out. This selection is based on

which of



and R



yields a better value of the fitness

function. DE continues for a number of generations

NrGen.

3.2 The Genetic Algorithm

The Genetic Algorithm (GA) is another member of

the evolutionary algorithms family. GA has the

following elements: a population of individuals,

selection according to fitness, crossover to produce

new offspring, and random mutation of the new

offspring (Mitchell, 1996).

The first step of GA is defining the problem

variables and the fitness function. A particular

configuration of variables produces a certain value

of the fitness function and the objective of GA is to

find the values of the parameters that optimize the

fitness function. As with DE, GA starts with a

population of

PopSize vectors (also called

chromosomes) each of which is of nbp dimensions.

Each chromosome represents a possible solution to

the problem at hand. The fitness function of each

chromosome is evaluated. The next step is

selection.

The purpose of this process is to determine which

chromosomes are fit enough to survive and possibly

produce offspring and which will die out. This is

decided according to the fitness function of each

chromosome. The percentage of chromosomes

selected for mating is denoted by

sRate. Crossover is

the next step in which offspring of two parents are

produced to enrich the population with fitter

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

350

Table 1: The FCM clustering errors on the training sets and testing sets for DE, PSO, and GA, together with the FCM

clustering errors for L

, L

∞

Dataset L

∞

DE PSO GA

train

test

train

test

train

test

Beef 0.49 0.49 0.45 0.36 0.48 0.36 0.46 0.36 0.49

CBF 0.48 0.50 0.51 0.30 0.51 0.30 0.51 0.30 0.49

CinC_ECG_torso 0.75 0.77 0.77 0.42 0.69 0.51 0.75 0.51 0.76

Coffee 0.50 0.50 0.46 0.36 0.51 0.36 0.50 0.36 0.50

ECG200 0.30 0.28 0.25 0.22 0.28 0.26 0.30 0.25 0.26

ECGFiveDays 0.50 0.48 0.46 0.45 0.50 0.45 0.49 0.45 0.50

FaceFour 0.43 0.57 0.68 0.24 0.56 0.26 0.57 0.29 0.46

FISH 0.67 0.64 0.69 0.56 0.62 0.57 0.63 0.57 0.63

Gun_Point 0.47 0.48 0.46 0.36 0.47 0.36 0.47 0.38 0.48

Lighting7 0.67 0.82 0.67 0.54 0.64 0.60 0.70 0.58 0.66

MedicalImages 0.84 0.79 0.72 0.70 0.82 0.72 0.82 0.72 0.79

MoteStrain 0.17 0.16 0.27 0.10 0.17 0.15 0.15 0.15 0.17

OliveOil 0.52 0.33 0.30 0.14 0.46 0.22 0.39 0.25 0.36

OSULeaf 0.80 0.82 0.86 0.71 0.79 0.74 0.83 0.74 0.80

SonyAIBORobotSurfaceII 0.23 0.22 0.23 0.15 0.23 0.15 0.23 0.15 0.23

SwedishLeaf 0.77 0.80 0.88 0.69 0.71 0.70 0.81 0.70 0.80

Symbols 0.38 0.39 0.29 0.09 0.40 0.14 0.40 0.14 0.38

synthetic_control 0.54 0.53 0.47 0.35 0.57 0.39 0.54 0.42 0.51

Trace 0.48 0.48 0.43 0.38 0.48 0.39 0.45 0.39 0.46

TwoLeadECG 0.47 0.47 0.47 0.31 0.47 0.35 0.49 0.35 0.47

yoga 0.48 0.49 0.48 0.43 0.48 0.43 0.48 0.48 0.48

chromosomes. GA also applies a mechanism called

mutation through which a percentage mRate of

genes is randomly altered. The above steps repeat

for

NrGen generations.

3.3 Particle Swarm Optimization

Particle Swarm Optimization (PSO) is a member of

a family of naturally-inspired optimization

algorithms called

Swarm Intelligence (SI). PSO is

inspired by the social behavior of some animals,

such as bird flocking or fish schooling (Haupt and

Haupt, 2004). In PSO individuals, called

particles,

follow three rules a)

Separation: each particle avoids

getting too close to its neighbors. b) Alignment: each

particle steers towards the general heading of its

neighbors, and c)

Cohesion: each particle moves

towards the average position of its neighbors.

PSO starts by initializing a swarm of

PopSize

particles at random positions



and velocities



where



PopSizei ,..,1

. In the next step the

fitness function of each position, and for each

iteration, is evaluated. The positions

1k



and

velocities

1k



are updated at time step ( 1



k )

according to the following formulae:









XLXGV.V











VXX





1

(8)

where

GGG

ar .





LLL

ar .







1,0, Urr





aa ,,





is the best position found by

particle i,



is the global best position found by the

whole swarm,



is called the inertia ,

a is called

the local acceleration , and

a is called the global

acceleration. The algorithm continues for a number

of iterations.

4 EXPERIMENTS

The objective of our experiments is to see if a

weighted combination of the Euclidean distance, the

Manhattan distance, and the infinity distance will

give better FCM clustering results than when each of

these distances is used as a stand-alone distance.

More formally, we FCM cluster the data using the

following combination:









T,SLT,SLT,SLT,Sd

32211 







(9)

As indicated earlier the weights



are obtained

OntheApplicationofBio-InspiredOptimizationAlgorithmstoFuzzyC-MeansClusteringofTimeSeries

351

through an optimization process that minimizes the

FCM cluttering error as given by equation (1).

We tested our method on a variety of time series

datasets from the UCR archive (Keogh et al, 2011).

We meant to choose datasets of different sizes and

lengths to get unbiased results.

In our experiments we compared the three

optimizers presented in Section 3 in terms of FCM

clustering error.

We used the same control parameters for the

three optimizers (except for those which are proper

to that certain optimizer). PopSize was set to 16 and

NrGen was set to 100.

For each dataset, and for each optimizer, the

experiment consists of two stages; the training stage

and the testing stage. In the training stage we

perform an optimization process where the

parameters of the optimization problem are the

weights



3,2,1; i



. The outcome of this

optimization problem is the weights ω

which yield

the minimum FCM clustering error. These optimal

values are then applied to the testing sets. In Table 1

we present the results of our experiments.

Taking into account that the optimization process

was applied to the training datasets, we see that the

three optimizers did improve the FCM clustering as

the FCM clustering errors of the training datasets for

all the datasets, and whatever optimizer is used, are

smaller than the errors resulting from using L

, L

or L

∞

, as stand-alone distances. However, when

comparing the FCM clustering errors on the testing

datasets we see that these errors are larger than those

obtained when using L

, L

, or L

∞

, as stand-alone

distances.

In order to understand this phenomenon, we

investigate whether the learning process has

undergone overfitting.

There are several measures in the literature to

measure overfitting. We opted for the following

simple measure:

testtrain

EEOF 

(10)

Where E

train

,, E

test

, are the FCM clustering errors on

the training set and the testing set, respectively, OF

is the overfitting value.

In Table 2 we report the overfitting measures of

the three optimizers and for all the datasets on which

we conducted our experiments. The results show

that there exits evidence of overfitting happening

during the learning process. Of the three compared

optimizers, GA seems to have suffered the least

from overfitting whereas DE has suffered the most.

We have to point out, however, that for each dataset

Table 2: The overfitting values of DE, PSO, and GA.

Dataset DE PSO GA

Beef 0.12 0.10 0.13

CBF 0.21 0.21 0.19

CinC_ECG_torso 0.27 0.24 0.25

Coffee 0.15 0.14 0.14

ECG200 0.06 0.04 0.01

ECGFiveDays 0.05 0.04 0.05

FaceFour 0.32 0.31 0.17

FISH 0.06 0.06 0.06

Gun_Point 0.11 0.11 0.10

Lighting7 0.10 0.10 0.08

MedicalImages 0.12 0.10 0.07

MoteStrain 0.07 0.00 0.02

OliveOil 0.32 0.17 0.11

OSULeaf 0.08 0.09 0.06

SonyAIBORobotSurfaceII 0.08 0.08 0.08

SwedishLeaf 0.02 0.11 0.10

Symbols 031 0.26 0.24

synthetic_control 0.22 0.15 0.09

Trace 0.10 0.06 0.07

TwoLeadECG 0.16 0.14 0.12

yoga 0.05 0.05 0.00

the three optimizers have suffered from overfitting

in a similar way (to a certain degree), so the

explanation of the results presented in Table 1 can

finally be attributed to differences between the

training sets and the testing sets.

We have to mention here that during the

experiments we also recorded execution time, but

we did not report these results for space restrictions.

The execution time was clearly in favor of PSO,

whereas DE and GA ran at similar speeds.

5 DISCUSSION

There are several counter measures to avoid

overfitting. In (Witten and Frank, 2009) the authors

suggest using a simplest-first search and stopping

when a sufficiently complex concept description is

found. In the language of bio-inspired optimization

this is translated as terminating the search algorithm

earlier, or using fewer parameters. As for the latter

idea, the parameters we are using are intrinsic to the

problem and their number cannot be reduced.

Besides, the number of the parameters in our

problem, 3, is already small. As for the former idea,

we did conduct experiments (which we did not

report here) where NrGen was set to 10 and to 20,

but we did not see a significant difference in

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

352

performance between the results we obtained for

these values and those we reported in this paper for

which NrGen was set to 100. The reasons for the

overfitting of the solutions resulting from the FCM

clustering might be the nature of the application

itself (Muhammad Fuad, 2013)

6 CONCLUSIONS

The application of bio-inspired optimization

algorithms to data mining tasks is not trivial given

the complexity of these tasks and the stochastic

behavior of bio-inspired algorithms. In this paper we

applied three widely-used bio-inspired optimization

algorithms: differential evolution, genetic

algorithms, and particle swarm optimization, to the

task of fuzzy c-means clustering of time series data,

where the aforementioned optimizers were used to

obtain the optimal values of the weights assigned to

a combination of distance metrics that was used in

the FCM clustering of the time series. We showed in

the experiments we conducted how, while all the

optimizers managed to improve the performance on

the training datasets, the improvement dropped when

the optimized values of the weights were applied to

the testing datasets as a result of the overfitting

problem which appeared during the optimization

process.

REFERENCES

Bustos, B. and Skopal, T., 2006. Dynamic similarity

search in multi-metric spaces. Proceedings of the ACM

Multimedia, MIR Workshop. ACM Press, New York,

NY.

Esling, P., and Agon, C., 2012. Time-series data mining

.ACM Comput. Surv.

Feoktistov, V. , 2006. Differential evolution: in search of

solutions (Springer Optimization and Its

Applications). Secaucus, NJ, USA. Springer- Verlag

New York, Inc.

Krzysztof, J.C., Pedrycz, W., Swiniarski, R.W., Kurgan,

L.A., 2007. Data mining: a knowledge discovery

approach. Springer-Verlag New York, Inc. Secaucus,

New Jersey.

Haupt, R.L., Haupt, S. E., 2004. Practical genetic

algorithms with CD-ROM. Wiley-Interscience.

Keogh, E., Zhu, Q., Hu, B., Hao. Y., Xi, X., Wei, L. &

Ratanamahatana C. A.. 2011.: The UCR time series

classification/clustering homepage: www.cs.ucr.edu/

~eamonn/time_series_data/

Larose, D., 2005. Discovering knowledge in data: an

introduction to data mining, Wiley, Hoboken, NJ.

Liao, T., 2005. Clustering of time series data–a survey.

Pattern Recognition.

Maulik, U., Bandyopadhyay, S., Mukhopadhyay, A.,2011.

Multiobjective genetic algorithms for clustering:

applications in data mining and bioinformatics.

Springer.

Mitchell, M., 1996. An introduction to genetic algorithms,

MIT Press, Cambridge, MA.

Muhammad Fuad, M.M., 2014a. A synergy of artificial

bee colony and genetic algorithms to determine the

parameters of the Σ-Gram distance. In DEXA 2014,

Munich, Germany. Lecture Notes in Computer Science

Volume 8645, 2014, pp 147-154.

Muhammad Fuad, M.M. , 2012a. Differential evolution

versus genetic algorithms: towards symbolic aggregate

approximation of non-normalized time series. In

IDEAS’12 , Prague, Czech Republic, Published by

BytePress/ACM.

Muhammad Fuad, M.M., 2014b. One-step or two-step

optimization and the overfitting phenomenon: a case

study on time series classification. In ICAART 2014.

Muhammad Fuad, M.M., 2012b. Using differential

evolution to set weights to segments with different

information content in the piecewise aggregate

approximation. In KES 2012, San Sebastian, Spain,

(FAIA). IOS Press.

Muhammad Fuad, M.Mm 2013. When optimization is just

an illusion. In ADMA 2013, Part I. LNCS, vol. 8346,

pp. 121–132. Springer, Heidelberg(2013).

Witten, I.H., Frank, E., 2009. Data mining practical

machine learning tools and techniques, second

edition, Elsevier.

OntheApplicationofBio-InspiredOptimizationAlgorithmstoFuzzyC-MeansClusteringofTimeSeries

353
