STRATEGIC: Opening New Horizons in the Secure and

Privacy Friendly Migration, Adaptation, Governance and

Development of Public Cloud Services

Konstantinos Kalaboukas

, Giannis Ledakis

, Nuria Rodriguez Dominguez

Fotis Karayannis

, Ilja Livenson

and Joshua Daniel

SingularLogic, Al. Panagouli & Siniosoglou, Nea Ionia, 14234, Athens, Greece

kkalaboukas@singularlogic.eu, g.ledakis@gmail.com

Atos Spain, C/Albarracín 25, 28037 Madrid, Spain

nuria.rodriguez@atos.net

Uranus Computing Ltd., 145 - 157 St. John Street, London EC1V 4PW, UK

f.karayannis@uranuscomputing.com

National Institute of Chemical Physics and Biophysics,

Akadeemia tee 23, 12618 Tallinn, Estonia

ilja@kbfi.ee

British Telecommunications Public Limited Company,

Newgate st. 41, EC1A7AJ London, U.K.

joshua.daniel@bt.com

Abstract. In this paper, STRATEGIC project is presented, in the scope of

providing an overview understandable to both technical and non-technical

reader. For this reason the project key goals, the stakeholders and the added

value offered by STRATEGIC are described. In slight more technical approach,

the requirements that have been identified and the decisions that have been

drawn in the frames of the design of STRATEGIC framework are presented.

The study that leads to this design has been conducted in a purely top-down

approach i.e. architectural decisions have been made based on the technical

requirements that have been raised by three different European Municipalities

which will adopt STRATEGIC outcomes and findings.

1 Introduction

Cloud computing services (including public cloud services) hold the promise to

deliver a host of benefits to both public sector organizations and enterprises, including

reduced Capital Expenses (CAPEX), improved performance and scalability, enhanced

reliability, as well as an overall reduced Total Cost of Ownership (TCO) for their ICT

infrastructures and services. These benefits are particularly important for public

bodies all over the EU, but despite this importance, the adoption of public cloud

services within public organizations is still low, which is a significant lost

opportunity. This sets the main goal of STRATEGIC of boosting the adoption of

public cloud services, notably within public sector organizations.

Public cloud infrastructures are generally made available to the general public or

even large industrial groups and are usually owned by organizations providing/selling

Karayannis F., Daniel J., Livenson I., Dominguez N., Konstantinos K. and Ledakis G.

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public Cloud Services.

DOI: 10.5220/0006144300030015

In European IST Projects - The Quest for Excellence Towards 2020 (EPS Vienna 2014), pages 3-15

ISBN: 978-989-758-101-4

cloud services

. Nowadays, privately held as well as public Cloud computing services

hold the promise to deliver a host of benefits to both public sector organizations and

enterprises, including reduced Capital Expenses, improved performance and

scalability, enhanced reliability, as well as an overall reduced Total Cost of

Ownership for their ICT infrastructures and services. At the same time, the ability to

combine public cloud services could open new horizons for the development of a next

generation of innovative cloud services that fully leverage existing services and APIs.

These benefits are particularly important for public bodies, especially for

governmental agencies, municipalities and regions, all over the EU; the adoption of

public cloud services as part of their numerous e-government transactions is expected

to have a significant economic and social impact

Despite these potential benefits, their penetration within public sector

organizations is still low

. Furthermore, cloud use in the public sector is usually

confined to the use of simple on-line back-office services (e.g., document

management, document sharing, mobile access to document), with only few instances

of use of e-government services by European citizens. Furthermore, security and

privacy management mechanisms (along with related policies) are not yet fully

integrated into public cloud services. This is a significant lost opportunity in an era

where governments are under extreme pressure to reduce operational budgets, while

at the same time citizens seek opportunities for increased satisfaction at less time and

lower cost.

However the current state of the art of cloud computing is slowing finding its way

to public sector. Governments are replacing their legacy IT systems with cloud

computing technologies and implementing new cloud-based tools for collaboration

and information sharing across agencies and units. Cloud Computing provides a great

opportunity for enabling reliable e-Governance quickly and at lower costs, while if

the needs have to be covered in-house they will have to cover peak demands (at

specific points of time) paying for over provisioning and leaving part of the

infrastructure unused for significant amounts of time. Cloud computing features like

application virtualisation, end-to-end service management, instant deployment and

ease of maintenance are catalysts, that jumpstart application deployment on the

Cloud. The biggest benefit of the Cloud is that it helps consolidate all data centres and

optimize resource utilisation, reducing support and maintenance costs by more than

half, without compromising on performance, availability and reliability of

applications

Centralising data storage and processing offers economies of scale that even the

largest organisations cannot achieve by themselves. Cloud computing therefore

represents considerable savings in IT budgets, and the end of headaches linked to

older computing methods. Private sector businesses using cloud computing report 10-

20% lower IT costs, while cloud computing can also help the public sector improve

efficiencies and lower costs, according to European Commission

According to European Union Agency for Network and Information Security

(ENISA), public bodies can be a key player in Cloud computing area as it offers

scalability, elasticity, high performance, resilience and security, together with cost

efficiency while at the same time it can enable and simplify citizen interaction with

government by reducing information processing time, lowering the cost of

government services and enhancing citizen data security. Governmental Clouds offer

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

to the public bodies, including ministries, governmental agencies and public

administrations (PAs), the potential to manage security and resilience in traditional

ICT environments and strengthen their national Cloud strategy

ENISA also identified the Member States with operational government Cloud

infrastructures and underlines the diversity of Cloud adoption in the public sector in

Europe, while suggesting solutions to overcome those barriers, and to sharing best

practices paving the way for a common set of requirements for all Member States

(MS).The ENISA study

showed that, while there is no common agreement on a

definition of Governmental Cloud, a common concept exists:

 A gov-Cloud (or G-Cloud) is an environment running services compliant with

governmental and EU legislations on security, privacy and resilience.

 A gov-Cloud is a secure and trustworthy way (private Cloud or public Cloud) to

run services under public body governance (how)

 A gov-Cloud is a deployment model to build and deliver services to state agencies

(internal delivery of services), to citizens and to enterprises (external delivery of

services to society) (for who)

After the examination of the wide and heterogeneous landscape of the EU countries a

governmental Cloud classification is presented based on basic criteria:

 the existence of a legal background to support the implementation of Cloud

computing in administrative systems, i.e. national Cloud strategy or digital

agenda,

 and the advancement of the governmental Cloud implementation (design,

implementation, projects running etc.).

The purpose of this paper is to describe the STRATEGIC project approach on the

aforementioned facts. The approach followed by STRATEGIC is described in terms

of objectives and expected results and also in terms of technical achievements.

2 STRATEGIC Approach

STRATEGIC defines a framework of interconnected solutions and services that offer

a cloud enablement on various infrastructures while offering a set of services related

to public bodies, opening new horizons in the secure and privacy friendly migration,

adaptation, governance and development of public cloud services.

2.1 STRATEGIC Objectives

In this context, STRATEGIC emerges from leading edge R&D results (Optimis

Toolkit, STORK and Semiramis projects) in order to open new horizons in the secure

and privacy friendly migration, adaptation, governance and development of public

cloud services, notably in terms of e-government services operated and used by public

bodies.

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services

The primary goal of STRATEGIC is to boost the adoption of public cloud

services, particularly within public sector organizations, through working towards

three complementary directions

 The migration/porting of existing on-line services to the Cloud (i.e., the cloud-

enablement of existing services). The cloud-enablement of existing on-line

distributed services (i.e. the vast majority of public bodies in the EU) can on the

one hand, facilitate public bodies to leverage the benefits of cloud computing,

while on the other hand, it can also significantly enhance the number of public

cloud services that could become readily available for replication and (re)use by

other public bodies.

 Replication and re)use of existing services i.e. of services which have been already

successfully deployed across EU countries and regions. This migration and

customization effort is required in order to adapt the services to different legal,

ethical and governance requirements, while also including the necessary

localization effort.

 Composition of new value-added services. Successful public cloud services can

also serve as a basis for building innovative value-added services, thereby

extending the pool of available services and encouraging end-users (i.e. business

and citizens) to use them. As a result, the ability to compose and integrate novel

public cloud services based on other existing/legacy services could allow public

administrations to streamline their processes thereby reducing overheads,

alleviating bureaucracy and overall improve citizens’ benefits and satisfaction.

STRATEGIC focuses on the provision of tools and techniques for the interoperable

migration and replication of public cloud services across different EU countries and

their regions. STRATEGIC will emphasize and demonstrate the importance (and the

merit) of a unified homogeneous marketplace of public services, thereby alleviating

the high fragmentation of the market.

To this end, the project will systematically study processes and needs associated

with the secure and privacy-friendly replication, migration and extension of public

cloud services and will accordingly integrate a novel cloud-based framework

(including various tools, other EU project outcomes and techniques) that will

successfully address these needs for a number of stakeholders including public

bodies, cloud application developers, cloud service providers and ISVs. This unified

framework will comprise security-by-design principles that will ensure the effective

management of authorizations for security and trust and will be integrated on the basis

of mature readily available R&D results from background projects of the partners.

2.2 STRATEGIC Identified Requirements and Functionalities

In order to come up with a proposed solution for public cloud services, the

requirements of the target communities were identified after analyzing a diverse set of

public and private sector organisations. Public sector ones include governmental

agencies (central government), municipalities and other regional or local

governments, while private sector ones include cloud application developers, cloud

solution providers, cloud services providers, cloud solution integrators, Independent

Software Vendors (ISVs) and more. Both requirements and business strategies were

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

considered. Diversity in terms of cloud maturity was also taken into account, ranging

from cloud-“immature” to cloud-“mature”.

The identified methodology comprised two main axes: the state of the art review

in the area of e-Government/public cloud services and the development of a

questionnaire supported by few selected interviews in order to get input from a

diverse set of stakeholders, both cloud users and providers (including cloud

developers, integrators, brokers, and software vendors). The state of the art review

identified several key findings that are analysed further below. A list of about 155

stakeholders was created. The questionnaire

was opened on 11.3.2014 and remained

open for roughly one month. A total of 117 responses was received, however 112

usable responses were gathered. The conclusions from both the state of the art review

and the questionnaires are presented in the next subsection.

Fig. 1. Overview of the adopted methodology.

2.2.1 Main Findings

Focusing mostly on e-Government Cloud and other relevant initiatives, and despite

the fact that many of them are rather new, there are some important messages and

requirements that can be extracted from both the state of the art review and the

questionnaire/interviews analysis.

1. Limited Provision of Cloud Services by the Public Sector – Use of Services

(Consuming Services) however is at a Good Level - STRATEGIC in the Heart of

the Problem. First of all the provision of Cloud computing in public administrations

is limited or in many cases even non-existent. Although there are cases that can be

considered early adopters, especially at national level (having G-Cloud initiatives

such as the UK G-Cloud), these are still the minority and most countries are still in

the investigation, planning or pilot phase. Furthermore, at local level (e.g.

municipalities), even for those early adopting countries, cloud services do not exist

and are mostly at planning or pilot phase. The use of Cloud services (consuming

Cloud services) is at a much better position, and only a 12,5% of questionnaire

respondents state that they do not use or plan to use the Cloud. This first finding

amplifies the role of STRATEGIC, which has a rather modest, but important scope of

“cloudifying” current solutions, reusing solutions from other providers or creating

new cloud services.

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services

2. Preference on “Cloudification” of Existing Services and Development of New

Services, rather than Reuse of Cloud Services Running in other Providers.

Regarding the requirements on the STRATEGIC possible services (with multiple

answers allowed) 61% of Cloud providers opted for “Cloudification” of existing

services running locally, only 20% of re-using-adapting “foreign” services, and 51%

for development of new services. It has to be better understood why providers do not

want to adapt/localise Cloud services running elsewhere (only 13% condensed to

100% sum). Either providers underestimate this opportunity or they assess that

adapting maybe sometimes more complex than rebuilding the services from scratch.

3. Trends in Cloud Service and Deployment Models Show that “Private” and

“SaaS” are Dominant respectively, while a Distribution of Customer Target

Groups (from Internal to External) can be observed. Both state of the art and

questionnaire analysis lean towards a “Private” service model. The questionnaire

analysis shows indeed the “Private” model dominating (close to 50%), while

“Hybrid” is following (~30%) and “Public” last (with around 20%). The state of the

art review shows national G-Cloud early adopters have taken different paths in

choosing for their cloud solutions. Although there are a few countries that have opted

for public solutions, it appears that most countries currently working or planning

towards a G-cloud lean towards Private cloud (i.e. a governmental agency hosting the

G-cloud services with own-resources). Regarding the deployment model “Software as

a Service”(SaaS) again appears to be the most favourite approach, although a

combination of other models (Infrastructure as a Service - IaaS, Platform as a Service

-PaaS and SaaS) is also common (especially if there is a need for the agency hosting

the G-cloud to provide resources (at the IaaS or PaaS level to other governmental

agencies). Regarding the target audiences of Cloud services, the trend appears to be

clearly towards servicing all players, i.e. citizens, business and governments, i.e.

B2C/G2C, B2B/G2B, G2G.

4. Regarding Specific Requirements that need to be taken on-Board by the

STRATEGIC Solution, there are Requirements that have been confirmed by

both the State of the Art and Questionnaire-interviews Analyses (such as Privacy

and Security), while there are Others that are not confirmed by Both (such as

Interoperable and Standard Interfaces). The most important confirmed

requirements from both state of the art and questionnaire analyses are:

 Security and privacy

 Lowering costs

 Performance and availability

Conflicting requirements from the two analyses are:

 Interoperability

 Portability

 Standard interfaces.

In the state of the art review interoperability, standards and portability where deemed

quite important, while the questionnaire answers do not confirm this view. Either it is

felt that moving between providers is not a great effort and thus interoperability or

standards are not that important or this requirement has been underestimated in the

questionnaire analysis. In the first option, we have to also take into account that more

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

than half of the respondents are public bodies for who standards and vendor lock-in

may not be a priority/issue.

5. Main Benefits for Public Entities in using the Cloud:

 Reducing costs for their information system infrastructures, platforms and services

 Embracing new (cloud-based) service delivery models to accelerate innovation

and benefit from economies of scale as these become available

 Sharing resources and experiences, and integrate services with other local

authorities or other countries, again to reduce costs and share support and

knowledge

 Making use of national G-Cloud services as they become available

 Increasing the effectiveness, scalability and elasticity of current online services

and invoke some new ones

6. Marketplace and Brokerage Services. The role and importance of marketplace

and brokerage services all together will raise in the future. Premium paid on top of

provider prices are mostly 1-10% but in some cases providers are willing to pay up to

20%.

7. Other findings:

 There is an absolute need for data privacy (both the vast majority of Cloud users

and providers deem it as important or very important )

 There is need for a central user directory, both for internal users (with higher

importance) and external users (with lower importance)

 Single Sign On is a second priority requirement, mostly for internal users (50%)

 An API for the management of cloud resources by the customers is also a second

priority requirement (~50% of cloud providers)

 Electronic Identity (eID) for authentication is also a second priority requirement.

Fig. 2. STRATEGIC conceptual architecture.

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services

2.3 STRATEGIC Conceptual Architecture

Based on the requirements and functionalities identified an initial identification of

services and core concepts that STRATEGIC should entail have been identified. The

produced STRATEGIC conceptual architecture is presented in the following figure

and focus on the layers that compose STRATEGIC framework

Each layer of STRATEGIC framework is described in the following list.

 STRATEGIC Portal, Toolkit and Marketplace of Public Services.

STRATEGIC marketplace of public services is the main interaction point between

STRATEGIC and its users. It supports the co-existence and operation of multiple

cloud services that can also be re-used or combined for the creation of new cloud

services. These services are offered through the marketplace and can be instantiated

monitored and managed with a unified way. Development tools for the preparation of

the services that will be published to the marketplace are offered.

 Set of STRATEGIC APIs. This layer includes APIs (Client API, Appliance API

and Service) that are defined and are providing the connection between

STRATEGIC Marketplace and internal services that are provided through

STRATEGIC.

 Set of Internal Tools & Services. This layer includes various tools that are

provided from STRATEGIC as services to end user of STRATEGIC, and are

focused on governmental bodies. (e.g. adaptation, localization, cross-border

authentication and data exchange and multi-cloud security services: data, server

and application protection)

 Brokerage Services Layer. Brokerage capabilities layer encapsulates the

functionalities required in order to allow the discovery, access and negotiation

between cloud services published in the Marketplace and the cloud infrastructure

providers.

 Interoperability Layer. Interoperability layer makes possible the deployment of

public cloud services to different infrastructure options. It is used by Brokerage

layer and Marketplace as well.

 Infrastructure Layer. Interoperability layer includes all IaaS solutions that are

supported from STRATEGIC

2.4 High Level Description of Components Functionality

Taking under consideration the aforementioned technical requirements and the

conceptual architecture of the framework, the high-level architecture has been

designed. The following figure summarizes the STRATEGIC architecture and the

main components needed for its implementation.

The high level architecture consists mainly of a Packaged Application Repository,

Configuration Recipes Repository, an Application Instantiation Workflow

Component, a Governance Component, a Credential Management Component, a

Configuration Server and a Billing Component. Moreover, the Cloud Orchestrator is

accompanied by two external Services; the Threat Intelligence Service and the

Monitoring Service.

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

Fig. 3. STRATEGIC High Level architecture.

The Packaged-Applications Repository contains all applications that can be

instantiated in an IaaS environment. The critical aspect regarding the repository is the

formulation of an expressive enough application-packaging schema. Such schema has

to cover all the aspects that have been introduced in the requirements section (i.e.

configuration abstraction, dependency management scalability). In addition to the

previous repository, an OS Virtual Machines (VM) Template Repository contains the

available Operating Systems that can be instantiated by various IaaS environments. It

should be noted that the Packaged Applications Repository can be also addressed as

Marketplace.

The Application instantiation Workflow contains a workflow engine that

coordinates the initialization of a deployment to an IaaS infrastructure. The

instantiation process combines information that is user-oriented (what type of

application, what type of guest OS etc) with information that is system-imposed (what

monitoring and security hooks should be configured before and after the deployment)

in order to keep track of all the steps that are required in order for a successful

deployment to be performed. Beyond deployment this workflow engine should take

under consideration all governance aspects such as undeployment, start, stop, pause

etc.

The Credential Management Component is responsible to persistently store the

credentials of an end-user, as far as the various IaaS providers are concerned. The

Application Instantiation Workflow coordinates the deployment of an Application to

an IaaS provider. This implies the selection of the proper host-OS (based on the

application packaging information), the target-IaaS and the initialization of the

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services

configuration-logic that is dependent to the application.

One of the most crucial components is the Configuration Recipes Repository that

contains the available configuration templates that can be applied after an Application

instantiation. A configuration template is valuable only in the frames of the adoption

of a holistic Configuration Management Framework. Therefore, although a

Configuration Server is not an organic part of the Orchestrator , it constitutes a critical

point since it assures that running instances maintain during runtime a proper-

configuration. Beyond that, the Configuration Framework is extremely valuable for

an additional reason; it acts a single point of reference for any functionality that has to

be horizontally integrated. Indicative functionalities that are subjected to horizontal

integration are Monitoring and Security.

Indeed, there are many Monitoring and SLA enforcement frameworks (Nagios,

Zabbix etc) which can be used as-a-service. To do so, specific agents have to be

initialized, configured and patched in the deployment unit that will be hosted in the

IaaS. In a production scenario the communication between the monitoring Agents and

the Monitoring Server should be secured at the application and transport level. All

these actions can be achieved with the usage of a Configuration Server. For the sake

of the reference implementation Puppet Server will be selected.

Finally, the Governance Component is responsible to interact (start, stop, pause

etc) with several underlying IaaS providers. To do so it has to rely on an abstraction

layer between the Orchestrator and the various Hypervisors. Since the risk of vendor-

lock-in is high, the exploitation of OCCI interfaces is imperative. At his point the

reference implementation of the architecture is realized. It is meaningful, to provide

the Application Packaging schema that will be adopted.

2.5 Pilots of STRATEGIC

During the course of the project the STRATEGIC framework focus on being

validated and evaluated on the basis of real service and real stakeholders. For these

reason three pilot public bodies (London Borough of Camden, City of Genoa and

Municipality of Stari Grad

) are used for the contribution of several services, and also

horizontal services deployed on the marketplace (on intelligent protection and secure

cloud storage) will be contributed by project partner BT. Furthermore, the project’s

pilot operations are able take advantage of public cloud infrastructures established and

operated by partners BT and SILO. Following the end of the project, the partners will

endeavor to sustain the services of the pilot sites, while at the same time executing an

ambitious exploitation plan, which foresees the radical expansion of the use of the

STRATEGIC framework, both in terms of additional services that will be deployed in

the marketplace, but also in terms of additional cloud services providers that will

interface to the marketplace.

The sustainability of the project’s infrastructures will be pursued as part of the

joint exploitation strategy of the partners, but also as part of their individual

exploitation plans, which foresee the expansion of their activities in the market of

public cloud services.

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

3 Discussion

3.1 Expected Results

As aforementioned STRATEGIC will primarily address the need of organizations

(notably public sector bodies) to adopt cloud computing and to leverage the benefits

of public cloud services. Thus, the STRATEGIC framework will comprise cloud

infrastructures and tools that will ease public sector organizations to flexibly and

effectively migrate their services to the cloud.

Using the STRATEGIC framework, public bodies will be able to cloud-enable

their services, but also to adapt and localize «best practice» services that have been

successfully deployed by other public bodies in other EU countries and regions. These

adaptation and localization functionalities will greatly benefit (cloud «newcomer»)

public bodies that have no cloud deployments at all, since they will offer them with a

readily available bundle of public services that they could directly adopt.

While the emphasis of the project will be on public bodies, the public

administration and e-government services, several of the services of the project (and

the associated benefits) will be applicable to private enterprises as well. In this way,

STRATEGIC addresses also cloud application developers, cloud services integrators,

independent software vendors (ISVs) and cloud services providers (including

providers of hosting services) as follows:

 Cloud service developers and ISVs will be offered with tools and techniques for

developing public cloud services, but also for adapting and localizing existing

ones. In this way, they will have the opportunity to undertake such adaptation and

localization task for a wide range of public bodies in their territories, thereby

increasing their customer portfolios and revenues.

 Cloud services providers (including providers of hosting services) will have

opportunities to offer cloud hosting services to the proliferating public sector

organizations that will be gradually adopting public cloud services. The

STRATEGIC framework will offer a rich set of opportunities to cloud providers

wishing to offer «last mile» services associated with the adaptation and

localization of public cloud services to local conditions

STRATEGIC will contribute to the provision of more effective services for citizens

an enterprises, give public administrations the opportunity to benefit from the

experience of other public entities and to provide cost-efficient and improved quality

electronic services as well as offer the technology community a secure framework for

the migration of online public services to cloud.

STRATEGIC project’s goal is to improve the field of public sector IT

administration by offering a cloud framework that will provide services to public

sector. These services include interactions with multiple stakeholders – a list of the

targeted stakeholders and the value proposition for each of them has been described

below.

Citizens - End-users of Public Cloud Services. Citizens will be the end-users of the

cloud services deployed through the STRATEGIC framework. These services may

include governmental services, as well as services provided by public sector third

party providers. Citizens will be able to use ‘cloudified’ versions of existing on-line

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services

services, as well as replicated versions of best practice services. Therefore they will

directly benefit from their ability to use effective governmental services, as well as

from the reliability and cost-effectiveness of the various services.

Public Bodies - Local/Regional/National Government Agencies. Government

agencies are the major stakeholders of the STRATEGIC framework with capabilities

to cloud-enable existing services, migrate existing services across providers and

develop new cloud-based services (in collaboration with ISVs acting on their behalf).

On the basis of the enablement, migration and development processes outlined above,

government agencies will be able to benefit from the elasticity, cost-efficiency and

reliability of the cloud. At the same time they have the opportunity to create new

proven services and processes based on the existing solutions in other public bodies.

Note that STRATEGIC can provide benefits to a lot of public bodies with a very low

degree of cloud adoption, given that it will provide them with the means to deploy IT

services from a set of readily available functionalities over many cloud services.

Cloud Application Developers, Solution Providers and ISVs. Cloud application

developers and ISVs have access to STRATEGIC marketplace and can publish new

or migrated public services for re-use by the public bodies. ISVs may also leverage

services from the marketplace, along with STRATEGIC tools, in order to develop and

deploy workflows of services that combine governmental and business processes to

the benefit of enterprises.

Cloud Services Providers. STRATEGIC offers a simple way for cloud services

providers, both from a public and private sector, to integrate with a common

marketplace. In this way they will have opportunities for new customers and revenue

streams, through offering hosting services to the users of the STRATEGIC. Note that

STRATEGIC offers extended capabilities for end-users to select a target cloud service

based on the reliability and other non-functional requirements of the applications.

Cloud Broker. Another role and stakeholder within the STRATEGIC framework is

the role of the cloud broker, who will be in charge of operating the brokerage and

marketplace services. It is envisaged that the cloud broker will provide not only

infrastructure, but also services associated with the negotiation of access to public

sector Cloud resources (i.e. access and integration to governmental services) as well.

Note that cloud brokerage services be provided by governmental or EU agencies, or

alternatively provided in collaboration (partnership) with these agencies in order to

ensure a high level of security, data protection, privacy and availability.

4 Conclusions

The rationale of this paper is to provide an overview of STATEGIC project. For this

reason a brief description of STRATEGIC main goals, the expected results and the

value proposition of the project is provided. For the conception of the proposed

solution, a detailed analysis of the stakeholders has been done and their requirements

have been identified. Based on these findings, conceptual and high level architecture

have been briefly described.

EPS Vienna 2014 2014 - European IST Projects - The Quest for Excellence Towards 2020

Acknowledgements

The work performed in the frames of this paper is funded by the Strategic CIP-PSP

Project (http://www.strategic-project.eu).

References

1. Mell, Peter & Grance, Timothy: The NIST Definition of Cloud Computing. s.l. NIST-July

2009.

2. Neelie Kroes Vice-President of the European Commission (speech): Digital democracy:

how ICT tools can change the relationship between citizens and governments. 18 October

2012.

3. Carsten Bruhn: European public sector failing to embrace cloud computing. Public Service

Europe, January 2013

4. http://www.imaginea.com/images/resources/white-papers/white%20paper%201.pdf

5. https://ec.europa.eu/digital-agenda/about-cloud-computing

6. www.enisa.europa.eu: Good Practice Guide for securely deploying Governmental Clouds,

2013

7. Description of Work of “STRATEGIC: Service disTRibution network And Tools for

intEroperable proGrammable, and UnIfied public Cloud services”

8. http://strategic-project.eu/strategic_public_files/deliverables/STRATEGIC_D2.%201_Repor

t%20on%20Stakeholders%20Requirements_v1.0-public.pdf

9. Dr. Milan Markovic: STRATEGIC project presentation, 29 August 2014

STRATEGIC: Opening New Horizons in the Secure and Privacy Friendly Migration, Adaptation, Governance and Development of Public

Cloud Services
