Explorative Analysis of Heterogeneous, Unstructured, and

Uncertain Data

A Computer Science Perspective on Biodiversity Research

C. Beckstein

, S. B¨ocker

, M. Bogdan

, H. Bruelheide

3,4

, H. M. B¨ucker

, J. Denzler

, P. Dittrich

I. Grosse

4,5

, A. Hinneburg

, B. K¨onig-Ries

1,4

, F. L¨ofﬂer

, M. Marz

, M. M¨uller-Hannemann

M. Winter

and W. Zimmermann

Institute for Computer Science, Friedrich Schiller University Jena, Ernst-Abbe-Platz 2, 07743 Jena, Germany

Institute of Computer Science, Leipzig University, Augustusplatz 10, 04109 Leipzig, Germany

Institute of Biology, Martin Luther University Halle Wittenberg, Am Kirchtor 1, 06108 Halle (Saale), Germany

German Centre for Integrative Biodiversity Research (iDiv) Halle-Jena-Leipzig,

Deutscher Platz 5e, 04103 Leipzig, Germany

Institute of Computer Science, Martin Luther University Halle Wittenberg,

Von-Seckendorff-Platz 1, 06120 Halle (Saale), Germany

Keywords:

Data Analysis, Biodiversity Informatics, Research Strategy.

Abstract:

We outline a blueprint for the development of new computer science approaches for the management and

analysis of big data problems for biodiversity science. Such problems are characterized by a combination of

different data sources each of which owns at least one of the typical characteristics of big data (volume, variety,

velocity, or veracity). For these problems, we envision a solution that covers different aspects of integrating

data sources and algorithms for their analysis on one of the following three layers: At the data layer, there

are various data archives of heterogeneous, unstructured, and uncertain data. At the functional layer, the data

are analyzed for each archive individually. At the meta-layer, multiple functional archives are combined for

complex analysis.

1 BIG DATA IN BIODIVERSITY

What is the beneﬁt of biological diversity? What are

the follow-up costs of the disappearance of certain

species? How much diversity is needed in an ecosys-

tem to maintain its function in the long term? What

beneﬁts provides an ecosystem for us humans? What

actions must be taken for ecosystem services to guar-

antee stable provisioning of food or drinking water on

a continuing basis? What impact do climate change

and land use have on biodiversity? What does it cost

us today to take measures for biodiversity protection?

What does it cost us tomorrow if we do not do it to-

day?

These and similar questions are increasingly

brought into the light of public consciousness due to

their enormous socio-economic and social relevance.

Given the potential impact of climate change on bio-

diversity,the evaluationof biodiversityand ecosystem

services is of central importance to society. To more

effectively protect biodiversity from overexploitation

and destruction, it is indispensable to understand the

variability of living organisms, their interactions, and

their ecological function. Biodiversity research estab-

lishes the foundations for the description and model-

ing of diversity on different scales and thus for the

understanding of ecosystem functioning as one of the

ultimate goals. To this end, a wealth of data cap-

turing different aspects of diversity is collected and

maintained in various large and heterogeneous data

archives.

In the ongoing and lively discussion on big data,

biodiversity data and their huge potential for the fu-

ture of mankind have so far been largely neglected

within the computer science community (Manyika

et al., 2011). This is particularly surprising because

biodiversity data has all of the standard properties of

big data—in particular, volume, variety, velocity, and

veracity. Moreover, biodiversity data with its cover-

age of multiple scales and its high complexity are a

big challenge for algorithm and software development

in the big data ﬁeld (Hampton et al., 2013; Marx,

2013; Goff et al., 2011).

The big data problems in biodiversity science are

251

Beckstein C., Böcker S., Bogdan M., Bruehlheide H., M. Bücker H., Denzler J., Dittrich P., Grosse I., Hinneburg A., König-Ries B., Löfﬂer F., Marz M.,

Müller-Hannemann M., Winter M. and Zimmermann W..

Explorative Analysis of Heterogeneous, Unstructured, and Uncertain Data - A Computer Science Perspective on Biodiversity Research.

DOI: 10.5220/0005098402510257

In Proceedings of 3rd International Conference on Data Management Technologies and Applications (DATA-2014), pages 251-257

ISBN: 978-989-758-035-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

deﬁned not only by their sheer size and extreme het-

erogeneity, but also by their complex interaction on

different scales. Hence, in this position paper, we ar-

gue that it is necessary to develop a new meta-layer

of data analysis as a novel methodological aspect

of computer science. This meta-layer offers a wide

scope of applicability beyond the area of biodiversity

research. Similar big data problems arise from the

life sciences, economics, and decision support. New

innovative techniques for data analysis need to be de-

veloped on the meta-layer. In addition, the plausibil-

ity of these analyses needs to be evaluated. In particu-

lar, the credibility of the individual data sources needs

to be assessed carefully. We believe this to be the only

way to ensure that complex solutions to complex big

data problems are comprehensible for scientists, pol-

icy makers, and other stakeholders.

The structure of this position paper is as follows.

In Sect. 2, we outline a target application scenario

for the meta-layer of data analysis. By summariz-

ing related work in Sect. 3, we give a sketch of the

current state of scientiﬁc knowledge in this area. In

Sect. 4, we draw a blueprint for data analysis of het-

erogeneous, unstructured, and uncertain data that are

typical for biodiversity science and, ﬁnally, we draw

conclusions in Sect. 5.

2 APPLICATION SCENARIO

Due to global warming, more and more species that

live in southern Europe, Asia Minor, and Africa arrive

in Germany. Take mosquito species as an illustrating

example. Some mosquito species carry diseases from

one part of the world to another part where they cur-

rently do not occur. How large is the risk that these

species and their diseases become established in Ger-

many? Which roles do the existing mosquito species

in facilitating or preventing the spread of these dis-

eases? Can we expect that predation will take care of

the problem or do we have to ﬁnd a technical solution,

such as developing vaccines?

The answers to these questions are of high social

and economic interest. From a computer science per-

spective, they ask for a solution that is also applicable

to other complex big data problems.

Biodiversity data sources available to answer

these questions are in transition: They are comple-

mented with data arising from ongoing digitization

processes of museum collections. This also includes

data originally collected for a different purpose, such

as mobile phone photos taken by citizens being pub-

licly available in social networks (“Citizen Science”).

Climate data are another part of complex and con-

stantly changing data relevant for biodiversity re-

search. The degree of this change can have a signif-

icant impact on the methods used to handle the data.

Returning to the above example, linking genome data

and climate data with current data collected from so-

cial networks on cumulative occurrences of disease-

carrying mosquitoes, e.g., by geo-referenced photos

from mobile phones combined with automatic de-

termination software (if applicable), may allow bet-

ter decisions on overarching questions (Graham et al.,

2011). Ideally, this is done by a complete quantita-

tive integration of different sets of heterogeneous data

and different sets of algorithms for their analysis. The

underlying mathematical methods such as hierarchi-

cal Bayesian modeling are evolving rapidly. At the

same time, algorithms and hardware are now sufﬁ-

ciently developed to make a quantitative integration

possible.

A long-term goal of biodiversity research is to

bring together a plethora of different big data sources.

The data differ in terms of their spatial scale, ranging

from the molecular scale such as genomic data to the

global scale such as remote sensing data. Different

time scales are also relevant such as femtoseconds for

molecular dynamics and decades for CO

concentra-

tions, or even centuries for changing species distri-

butions or evolutionary processes. In addition, bio-

diversity data differ in terms of biological structures.

They range from relatively homogeneous, uniformly-

structured data such as genomic or remote sensing

data to very heterogeneous, semi-structured data.

We envision a software infrastructure that allows

us to exploratively analyze such complex data dis-

tributed over multiple data sources. This architec-

ture must (1) weigh different data sources according

to their relative reliability and (2) connect them as re-

quired for the question of interest. An important re-

quirement is to enable a fast solution of biodiversity

problems when the underlying data change dynami-

cally. To this end, we suggest scientiﬁc workﬂows

that, once deﬁned for the solution of a particular bio-

diversity problem, may be (semi-)automatically re-

executed when data are updated or new data sources

become available.

Furthermore, a simple adaptation of this workﬂow

allows a seamless integration of new data analysis

methods. This functionality is crucial to ensure that

decision makers always ﬁnd support on the basis of

current facts and data analysis methods and that no

recommendations are given based on outdated data or

methods. From a computer science perspective, the

challenge is to enable solutions that are independent

of the data sources and the evaluation methods. This

way, we envision an architecture that is also applica-

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

252

ble to similar application domains beyond biodiver-

sity science.

3 RELATED WORK

Due to its interdisciplinary nature, the problem is rel-

evant to both computer science and biodiversity sci-

ence. In computer science, there is numerous pre-

vious work that considers the problem more or less

independent from the application domain. Here, se-

mantic web services and in particular semantic an-

notations are important. However, to date, these

approaches perform unsatisfactorily when scaling to

larger problems sizes and therefore have not yet

gained any important practical signiﬁcance.

The connection between computer science and

the application domain biodiversity science is estab-

lished by a subdiscipline called biodiversity infor-

matics. This ﬁeld is concerned with the applica-

tion of information technologies to improve the man-

agement of biodiversity data. In particular, it fa-

cilitates the access to biodiversity data archives and

performs relevant data analyses. In recent years,

this discipline has intensively dealt with the sup-

port, integration, and combination of biodiversitydata

(Hardisty et al., 2013). Due to the high level of dif-

ﬁculty, which results from the previously described

data heterogeneity, this integration process is not yet

sufﬁciently advanced. Today, the combination of

data in most cases “only” applies to spatial informa-

tion. Examples include the Global Biodiversity Infor-

mation Facility (GBIF, www.gbif.de), Species 2000

(www.sp2000.org), and the European Biodiversity

Observation Network (EU BON, eubon.eu). GBIF is

a portal with 400 million entries on the occurrence

of species, Species 2000 plans to build an integrated

species list, and the EU project EU BON seeks to in-

crease the interoperability of electronic biodiversity

platforms.

Recently, much effort has been made in biodiver-

sity informatics to formalize established functional

relationships. This way, several Knowledge Organi-

zation Systems (KOS) (Catapano et al., 2011) have

emerged. Their aim is to make the semantic rela-

tionship between data machine-readable. Unfortu-

nately, these systems are currently not mutually com-

patible. Information systems in biodiversity research

increasingly consider alternative subsequent usages

of the data in the collection phase (Nadrowski et al.,

2013). However, the list of projects that follow an

integrated approach to data analysis is less exten-

sive. Here, the Map of Life project (Jetz et al.,

2012), which brought together a variety of different

data types and data analyses, has played a pioneering

role. For plant research, there is the iPlant Collabo-

rative (iPlant) (Goff et al., 2011), a virtual organiza-

tion that provides a platform for storing and analyz-

ing large data sets collaboratively. There are also nu-

merous tools for processing individual big data types,

such as Trinity (http://trinityrnaseq.sourceforge.net),

Velvet (Zerbino and Birne, 2008), segemehl (Hoff-

mann et al., 2009; Otto et al., 2012), Jstacs (Grau

et al., 2012), or NGS read trimming (Hedtke et al.,

2014). Further, text mining tools are useful to process

text documents of scientiﬁc publications that describe

generation, collection, reliability and scope of data

in biodiversity. Such text-mining tools include im-

plementations for particular tasks of natural language

processing (OpenNLP, 2008; Manning et al., 2014),

document clustering and topic modeling (McCallum

and Mimno, 2002; Gohr et al., 2009; Blei, 2012).

Existing initiatives from biodiversity informatics

typically focus on the mere application of informa-

tion technology techniques, not on their development.

Thus, they lack a dedicated focus on fundamental is-

sues of computer science. In the future, however,

computer science can be expected to become a driving

force for the development of new methods that enable

data integration and data analysis in the ﬁrst place.

We believe that the following areas will play a crucial

role in the solution of big data problems from biodi-

versity science: algorithm engineering, bioinformat-

ics, biosystems analysis, data mining, data manage-

ment, high performance computing, image and signal

processing, knowledge representation, machine learn-

ing, parallel processing, software engineering, and vi-

sualization.

On the political side, there is a great need for di-

rect support in decision processes, as formulated by

the Intergovernmental Platform on Biodiversity and

Ecosystem Services (IPBES) (Secretary of IPBES,

2012):

“However, biodiversity and ecosystem

services are declining at an unprecedented

rate, and in order to address this challenge, ad-

equate local, national and international poli-

cies need to be adopted and implemented.

To achieve this, decision makers need sci-

entiﬁcally credible and independent informa-

tion that takes into account the complex re-

lationships between biodiversity, ecosystem

services, and people. They also need effec-

tive methods to interpret this scientiﬁc infor-

mation in order to make informed decisions.

The scientiﬁc community also needs to un-

derstand the needs of decision makers better

in order to provide them with the relevant in-

ExplorativeAnalysisofHeterogeneous,Unstructured,andUncertainData-AComputerSciencePerspectiveon

BiodiversityResearch

253

formation. In essence, the dialogue between

the scientiﬁc community, governments, and

other stakeholders on biodiversity and ecosys-

tem services needs to be strengthened.”

Since there are no such techniques available today, we

argue that a blueprint for data analysis as suggested

in the following section needs to be implemented ur-

gently.

4 DATA ANALYSIS BLUEPRINT

Our main objective is the development of domain-

independent techniques from computer science to

improve the support of complex big data solutions

and their application to biodiversity research. The

blueprint that we sketch in this position paper is bi-

ased by our own previous work. Of course, there are

other options for fulﬁlling this goal. Our approach is

based on a three-layer architecture as shown in Fig. 1.

On the (green) data layer, different data sources

are arrangedalong spatial and biological scales. Tech-

niques of data selection and analysis for an individual

big data source can be applied from the (yellow) func-

tional layer. The blue arrows from the data layer to

the functional layer identify these requests to a single

big data source. The (red) meta-layer, the question

answering layer, then allows the combination of dif-

ferent big data sources. It is this layer where higher-

level questions are asked and solutions to these prob-

lems are returned. The arrows between the func-

tional layer and the question answering layer sym-

bolize these multiple requests that serve to gain com-

bined knowledge from different big data sources or to

conﬁrm, refute, or even invent hypotheses.

All requests must be translated into scientiﬁc

workﬂows that answer these requests. Partial results

from various big data sources can lead to contradic-

tions although the evaluation algorithms operate cor-

rectly. To respond to an overall problem, these con-

tradictions must be detected and weighted in a suit-

able manner on the meta-layer. For this purpose, tools

and methods must be developedthat support complex,

multi-scale research processes on the basis of spa-

tially distributed, heterogeneous,and unstructured big

data sources. To the best of our knowledge, there is

no other approach that uses this three-layer approach

in biodiversity research or in the general ﬁeld of big

data.

An intensive interdisciplinary collaboration be-

tween computer scientists and scientists from appli-

cation domains is essential to consider the three lay-

ers in an integrated way. The task of the applied sci-

ences is the formulation of an actual problem, the de-

velopment of domain-speciﬁc solutions, and the eval-

uation of proof-of-conceptimplementations. The task

of computer science is the generalization of the prob-

lems from a speciﬁc application science, the develop-

ment of domain-independent solutions, and the real-

ization of proof-of-concept implementations. In this

interdisciplinary collaboration, the following contri-

butions are necessary on the three layers.

4.1 Meta-layer

On the meta-layer, domain-speciﬁc languages are

used to formulate a higher-level problem without de-

tailed knowledge of computer science. At the same

time an efﬁcient implementation of the question an-

swering layer needs to be developed. Implementa-

tions will not only involve model-driven code genera-

tion, but rather compiler technology, which is com-

monly considered to be more powerful (Berg and

Zimmermann, 2014). Given our current understand-

ing of application domains of similar complexity as

biodiversity science, workﬂow engines are required

that support (i) nested workﬂows and (ii) packaging

of single workﬂow steps into larger groups that can

be automatically combined to build entire families of

related analysis software packages.

Solid explanations or justiﬁcations of a result in-

clude answers to questions like the following: How

was the result or a part of it produced? Which data and

information were used and how were they used? Why

were certain data classiﬁed as relevant or irrelevant

and therefore explicitly excluded from the analysis?

Which assumptions were based on the process and

at which point? Typical questions for more complex

processes are: How were the results of sub-processes

combined to those of the overall process? How well-

founded is the result and how does it depend on sec-

ondary decision-making processes? How sensitive is

a result with respect to a variation of its input param-

eters? Where and when does a slight change to the

input yield a qualitatively different result?

Evaluation methods and data sources may change

over time. Whenever this happens, it is necessary

to re-evaluate results that were produced before the

change. Given that the decision-making process is en-

coded as a scientiﬁc workﬂow, processes on the meta-

layer can (semi-)automatically analyze which parts of

the process are effected by the change. On the one

hand this allows to generate updated results for big

data problems efﬁciently. On the other hand it is then

possible to algorithmically document, visualize, and

explain the impact of this change to human decision-

makers in a comprehensible way.

Without any doubt, some questions asked on the

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

254

workflow

Scientific

Micro

Macro

Data layer

Genome

Specific

programs

Layers

Metabolome

Transcriptome

Metagenome

Proteome

Occurrence

Functional layer

Images

Phenotype

Environment

Meta-layer

Biological structures

Figure 1: Schema of a three-layer architecture for explorative analysis of heterogeneous, unstructured, and uncertain data

from biodiversity science. Data layer contains originally data and quality information. Existing and novel programs transform

extracted knowledge to useable units in the functional layer. A workﬂow combines a subset of knowledge units to answer a

overarching question in the meta-layer.

meta-layer will not be answerable with the data at

hand, or only with unacceptable large error margins.

One aim of the meta-layer will then be gap identiﬁca-

tion, informing the functional layer, which type and

combination of data would be required to solve the

problem at hand. Such identiﬁed gaps would then ei-

ther result in data mining strategies to ﬁll in the re-

quired information, or more probably, instigate the

collection of new biological primary data.

4.2 Functional Layer

Scientiﬁc workﬂows on the meta-layer can only be

executed efﬁciently if the functional layer provides

results from necessary tools for data analysis and also

a sufﬁcient annotation of these tools. The data layer

consists of a variety of big data sources whose char-

acteristics may vary dramatically. Therefore, there

is a need to investigate to what extent known algo-

rithms for small problem sizes are also applicable to

large problem sizes. Are there convergence problems

with iterative numerical algorithms when increasing

the problem size? Is it sufﬁcient to use existing al-

gorithms with an increased number of digits used in

ﬂoating-point arithmetic, or are completely new algo-

rithms necessary? Which algorithms do not scale to a

high number of processors or are inadequate for high-

latency networks?

Thus, speciﬁc programs are needed to extract

knowledge that is then transferred to the meta-layer.

In Fig. 1, this transfer from the data layer to the func-

tional layer is represented by blue arrows. These pro-

grams might be existing software tools with speciﬁc

parameters, but we also need novel techniques ad-

dressing scalability and reliability (Fortmeier et al.,

2013), in particular for algorithms for the identi-

ﬁcation and calculation of relevant data (Freytag

et al., 2012; Hoffmann et al., 2012; Sp¨uler et al.,

2012). These techniques are to be developed using

modern methods of algorithm engineering (M¨uller-

Hannemann and Schirra, 2010). From these studies

one can expect to ﬁnd generalized results for classes

of algorithms. At the interface between the functional

and the meta-layer, the formal description of the algo-

rithms and their properties plays a crucial role. Only

when algorithms are adequately described, automated

reasoning on the meta-layer is possible at all.

4.3 Data Layer

An equally important task is the annotation of the

characteristics of data sources and individual data at

the data layer. Here, it is necessary to cover both

the meaning of data, e.g., by mapping to existing tax-

ExplorativeAnalysisofHeterogeneous,Unstructured,andUncertainData-AComputerSciencePerspectiveon

BiodiversityResearch

255

onomies, as well as the quality of data sources, e.g.,

its coverage and error rate. It is essential to make

use of extensive expertise in the areas of informa-

tion management for biodiversity data (Lotz et al.,

2012), semantic web (Nadrowski et al., 2013), and

user-generated annotations (Gohr et al., 2010; Gohr

et al., 2011). Due to the sheer size of many data

sources it will only be possible to evaluate them ef-

ﬁciently if the evaluating programs are brought to the

locations of the data (function shipping) rather than,

as usual, copying the data to the respective process-

ing locations. This could be achieved using declar-

ative data description and transformation languages.

Examples of such languages are SQL, SparQL, Dat-

aLog and Map-Reduce. We envision scientiﬁc work-

ﬂows that compose large data queries and transfor-

mation jobs. Using todays database infrastructure,

this would result into jobs consisting of multiple de-

pendent SQL queries or Map-Reduce jobs. In the

text-mining domain, such architectures are used in

the TopicExplorer-System (Hinneburg et al., 2012).

For biodiversity science, the spectrum ranges from

molecular biological data such as genome, transcrip-

tome, proteome, and metabolome data, to observed

data (species, traits, habitats etc.), remote sensing,

and climate data.

4.4 Combining the Layers

The building blocks to be developed at the three lay-

ers are to be merged into a software architecture that

supports scientists in the whole process of knowl-

edge discovery and that records the analysis and the

decision-making processes as follows. First, the sys-

tem searches for the appropriate data, programs, and

its parameters. This is followed by ﬁnding a suitable

combination of multiple data sources and by solving

the big data problem. Finally, the system selects a

suitable way to visualize the results. During this pro-

cedure, all the steps are documented and stored so that

they can ﬁnally be visualized graphically. This way,

the origin of the data and the results are reproducible.

The results can be exported for further processing or

archiving using different ways. In addition, it is possi-

ble to repeat an explorative analysis with minimal hu-

man effort and to easily integrate new scientiﬁc work-

ﬂows. Note that explorative visual analysis goes be-

yond mere result presentation. It allows interactive

explanations and justiﬁcations of results. Therefore,

fast and easy design and composition of visualization

views are necessary to provide interfaces to users that

allow them to explore analysis results, relate them to

observed data and understand their impact.

5 CONCLUDING REMARKS

Biodiversity research has a high societal and eco-

nomic relevance. Many key questions of this disci-

pline can only be answered using big data. However,

up to now, support of big data in this ﬁeld is limited.

Existing approaches address individual aspects, but

not the problem as a whole. We believe that an in-

novative computer science approach is needed here.

For this purpose, we proposed a three-layer architec-

ture connecting data sources and function implemen-

tations to scientiﬁc workﬂows supporting domain-

speciﬁc problem solving.

REFERENCES

Berg, C. and Zimmermann, W. (2014). Evaluierung von

M¨oglichkeiten zur Implementierung von Semanti-

schen Analysen f¨ur Dom¨anenspeziﬁsche Sprachen. In

Software-Engineering 2014, Workshopband Arbeits-

tagung Programmiersprachen ATPS 2014, volume

1129, pages 112–128. CEUR Workshop Proceedings.

Blei, D. M. (2012). Probabilistic topic models. Commun.

ACM, 55(4):77–84.

Catapano, T., Hobern, D., Lapp, H., Morris, R. A., Mor-

rison, N., Noy, N., Schildhauer, M., and Thau, D.

(2011). Recommendations for the use of knowledge

organization systems by GBIF. Global Biodiversity

Information Facility (GBIF), Copenhagen. Available

at http://www.gbif.org/orc.

Fortmeier, O., B¨ucker, H. M., Fagginger Auer, B. O., and

Bisseling, R. H. (2013). A new metric enabling an ex-

act hypergraph model for the communication volume

in distributed-memory parallel applications. Parallel

Computing, 39(8):319–335.

Freytag, A., Rodner, E., Bodesheim, P., and Denzler, J.

(2012). Rapid uncertainty computation with Gaussian

processes and histogram intersection kernels. In Proc.

Asian Conf. Comput. Vis., pages 511–524.

Goff, S. A., Vaughn, M., McKay, S., Lyons, E., Stapleton,

A. E., Gessler, D., Matasci, N., Wang, L., Hanlon,

M., Lenards, A., Muir, A., Merchant, N., Lowry, S.,

Mock, S., Helmke, M., Kubach, A., Narro, M., Hop-

kins, N., Micklos, D., Hilgert, U., Gonzales, M., Jor-

dan, C., Skidmore, E., Dooley, R., Cazes, J., McLay,

R., Lu, Z., Pasternak, S., Koesterke, L., Piel, W. H.,

Grene, R., Noutsos, C., Gendler, K., Feng, X., Tang,

C., Lent, M., Kim, S.-j., Kvilekval, K., Manjunath,

B., Tannen, V., Stamatakis, A., Sanderson, M., Welch,

S. M., Cranston, K., Soltis, P., Soltis, D., O’Meara,

B., Ane, C., Brutnell, T., Kleibenstein, D. J., White,

J. W., Leebens-Mack, J., Donoghue, M. J., Spalding,

E. P., Vision, T. J., Myers, C. R., Lowenthal, D., En-

quist, B. J., Boyle, B., Akoglu, A., Andrews, G., Ram,

S., Ware, D., Stein, L., and Stanzione, D. (2011). The

iPlant collaborative: Cyberinfrastructure for plant bi-

ology. Frontiers in Plant Science, 2(34).

Gohr, A., Hinneburg, A., Schult, R., and Spiliopoulou, M.

(2009). Topic evolution in a stream of documents.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

256

In Proceedings of the SIAM International Conference

on Data Mining, SDM 2009, April 30–May 2, 2009,

Sparks, Nevada, USA, pages 859–872. SIAM.

Gohr, A., Hinneburg, A., Spiliopoulou, M., and Usbeck, R.

(2011). On the distinctiveness of tags in collaborative

tagging systems. In Proc. Int. Conf. Web Intelligence,

Mining and Semantics, WIMS, page 62. ACM.

Gohr, A., Spiliopoulou, M., and Hinneburg, A. (2010). Vi-

sually summarizing the evolution of documents un-

der a social tag. In Proc. of International Conference

on Knowledge Discovery and Information Retrieval,

KDIR.

Graham, E. A., Henderson, S., and Schloss, A. (2011).

Using mobile phones to engage citizen scientists in

research. Eos, Transactions American Geophysical

Union, 92(38):313–315.

Grau, J., Keilwagen, J., Gohr, A., Haldemann, B., Posch,

S., and Grosse, I. (2012). Jstacs: A Java framework

for statistical analysis and classiﬁcation of biological

sequences. Journal of Machine Learning Research,

13:1967–1971.

Hampton, S. E., Strasser, C. A., Tewksbury, J. J., Gram, W.,

Budden, A., Batcheller, A., Duke, C., and Porter, J.

(2013). Big data and the future of ecology. Frontiers

in Ecology and the Environment, 11(3):156–162.

Hardisty, A., Roberts, D., et al. (2013). A decadal view

of biodiversity informatics: Challenges and priorities.

BMC Ecology, 13(1):16.

Hedtke, I., Lemnian, I., M¨uller-Hannemann, M., and Große,

I. (2014). On optimal read trimming in next genera-

tion sequencing and its complexity. In Proceedings

of AlCoB 2014, volume 8542 of LNBI, pages 83–94.

Springer.

Hinneburg, A., Preiss, R., and Schr¨oder, R. (2012). Topic-

explorer: Exploring document collections with topic

models. In Flach, P. A., Bie, T., and Cristianini, N.,

editors, Machine Learning and Knowledge Discovery

in Databases, volume 7524 of Lecture Notes in Com-

puter Science, pages 838–841. Springer Berlin Hei-

delberg.

Hoffmann, J., G¨uttler, F., El-Laithy, K., and Bogdan, M.

(2012). Cyﬁeld-RISP: Generating dynamic instruc-

tion set processors for reconﬁgurable hardware using

OpenCL. In Artiﬁcial Neural Networks and Machine

Learning ICANN 2012, volume 7552 of LNCS, pages

169–176. Springer Berlin Heidelberg.

Hoffmann, S., Otto, C., Kurtz, S., Sharma, C., Khaitovich,

P., Vogel, J., Stadler, P. F., and Hackerm¨uller, J.

(2009). Fast mapping of short sequences with mis-

matches, insertions and deletions using index struc-

tures. PLoS Comp. Biol., 5:e1000502.

Jetz, W., McPherson, J. M., and Guralnick, R. P. (2012). In-

tegrating biodiversity distribution knowledge: Toward

a global map of life. Trends in Ecology & Evolution,

27(3):151–159.

Lotz, T., Nieschulze, J., Bendix, J., Dobbermann, M., and

K¨onig-Ries, B. (2012). Diverse or uniform?—Inter-

comparison of two major German project databases

for interdisciplinary collaborative functional biodiver-

sity research. Ecological Informatics, 8:10–19.

Manning, C., Jurafsky, D., and Liang,

P. (2014). Stanford CoreNLP.

http://nlp.stanford.edu/software/corenlp.shtml.

[Online; accessed 19-May-2014].

Manyika, J., Chui, M., Brown, B., Bughin, J., Dobbs, R.,

Roxburgh, C., and Byers, A. H. (2011). Big data:

The next frontier for innovation, competition, and pro-

ductivity. Report of the Mc Kinsey Global Institute,

Mc Kinsey & Company.

Marx, V. (2013). The big challenges of big data. Nature,

498:255–260.

McCallum, A. K. and Mimno, D. (2002). MAL-

LET: A Machine Learning for Language Toolkit.

http://mallet.cs.umass.edu. [Online; accessed 19-

May-2014].

M¨uller-Hannemann, M. and Schirra, S., editors (2010). Al-

gorithm Engineering: Bridging the Gap between Al-

gorithm Theory and Practice, volume 5971 of LNCS.

Springer.

Nadrowski, K., Ratcliffe, S., B¨onisch, G., Bruelheide, H.,

Kattge, J., Liu, X., Maicher, L., Mi, X., Prilop, M.,

Seifarth, D., Welter, K., Windisch, S., and Wirth, C.

(2013). Harmonizing, annotating and sharing data in

biodiversity–ecosystem functioning research. Meth-

ods in Ecology and Evolution, 4(2):201–205.

OpenNLP (2008). Apache OpenNLP.

https://opennlp.apache.org/. [Online; accessed

19-July-2008].

Otto, C., Stadler, P. F., and Hoffmann, S. (2012). Fast and

sensitive mapping of bisulﬁte-treated sequencing data.

Bioinformatics, 28:1698–1704.

Secretary of IPBES (2012). Intergovernmental platform

on biodiversity and ecosystem services. Bonn.

http://www.ipbes.net/about-ipbes.html.

Sp¨uler, M., Rosenstiel, W., and Bogdan, M. (2012). Adap-

tive SVM-based classiﬁcation increases performance

of a MEG-based Brain-Computer Interface (BCI). In

ICANN 2012, Part I, LNCS 7552, pages 669–676.

Zerbino, D. R. and Birne, E. (2008). Velvet: Algorithms for

de novo short read assembly using de Bruijn graphs.

Genome Research, 18:821–829.

ExplorativeAnalysisofHeterogeneous,Unstructured,andUncertainData-AComputerSciencePerspectiveon

BiodiversityResearch

257
