Model-Driven Development Versus Aspect-Oriented Programming

A Case Study

Uwe Hohenstein

and Christoph Elsner

Siemens AG, Corporate Technology, Otto-Hahn-Ring 6, D-81730 Muenchen, Germany

Siemens AG, Corporate Technology, Wladimirstr 3, D-91058 Erlangen, Germany

Keywords: AOP, Aspectj, MDD, XSL-T, Case Study.

Abstract: This case study compares two different technologies – model-driven development (MDD) and aspect-

oriented programming (AOP) – both trying to avoid redundant code, but with very different approaches. A

real industrial software system, the OpenSOA platform, which had already applied a model-driven

XML/XSL-T approach, is used as the basis for implementation and comparison. For evaluation purpose, we

have re-implemented the XSL-T implemented logic with a corresponding AOP implementation in AspectJ.

Taking into account several criteria, our case study indicates that the AOP implementation reveals its

strengths in avoiding redundancy, better testability, and understandability. However, more advanced tooling

could significantly improve the position of MDD for the latter. MDD is in turn the more flexible approach,

allowing generation of arbitrary artefacts the design demands. As the main issue of the case study, to

generate wrapper classes and boilerplate-code, is rather common, we believe that our results have potential

to be transferred to other problem settings. Furthermore, we think that our evaluation criteria will help

guiding others in making technology choices. We also give an outlook on how combinations of MDD and

AOP may leverage the best of both worlds.

1 INTRODUCTION

Model-driven development (MDD) has the goal to

develop software systems on a higher abstraction

level than code (Stahl and Völter, 2006). Given

some high-level form of input, more concrete output

is generated, maybe even source code. Code

generation not only saves time and effort, but also

avoids programming errors and increases

programmer productivity (Smaragdakis et al., 2004).

Moreover, the input has a higher level of abstraction,

is simpler and shorter than the generated code, and

makes concepts more explicit. One basic idea of

MDD is a voluntary self-restriction, i.e., the input

model uses a limited number of concepts that are

defined by a metamodel. Common forms of input

are domain-specific languages (DSL): graphical,

textual, XML, or UML models. A lot of tooling can

be used such as Xtext (Xtext) or MPS (MPS) or

pure::variants (Beuche,2006).

Aspect-orientation programming (AOP) is quite

a different technology that provides new

mechanisms to handle crosscutting concerns

(CCCs). CCCs are those functionalities that are

typically spread across several classes with

conventional programming. Those CCCs usually

cause duplicated and redundant code. This leads to

lower programming productivity, poor quality and

traceability, and a lower degree of code reuse. AOP

provides new constructs to separate crosscutting

concerns. This separation allows for a better

modularization, thereby avoiding the well-known

symptoms of code tangling and code scattering (Tarr

et al., 1999). Aspect-oriented languages such as

AspectJ (Kiczales, 2001)(AspectJ, 2014) support the

separation of concerns by means of special language

constructs. Even other languages such as Scala or

Ruby are starting to offer means for handling CCCs

such as abstractions or metaprogramming.

Both technologies, MDD and AOP, can be used

to avoid redundant code. As (Normén, 2007) states

“code duplications smell badly”, and should be

avoided. However, there are always cases where

they cannot be avoided using conventional

programming languages. While MDD uses a

generative approach, AOP extends an existing

implementation language and modularizes common

code in an aspect.

133

Hohenstein U. and Elsner C..

Model-Driven Development Versus Aspect-Oriented Programming - A Case Study.

DOI: 10.5220/0004999901330144

In Proceedings of the 9th International Conference on Software Paradigm Trends (ICSOFT-PT-2014), pages 133-144

ISBN: 978-989-758-037-6

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

In this paper, we compare both technologies in a

real industrial application. The comparison is done

for XML-based code generation and the AspectJ

language in the context of the OpenSOA project

(Strunk, 2007). OpenSOA offers a service-oriented

telecommunication middleware platform. It is an

open service platform for the deployment and

provision of communication services such as

capturing user presence, management of calling

domains, notifications, administration functionality

for the underlying switch technology, and so forth.

An OSGi container builds the technical basis.

A specific challenge within the OpenSOA

framework is that several message-based interfaces

have to be kept consistent. These interfaces are

similar, however, having slight differences.

Since the development team spent about 50% of

its time to create and maintain interface code and

inline documentation, an MDD approach has been

implemented to avoid duplicated code in different

layers and to achieve consistency between several

closely related interfaces and Javadoc comments.

The approach relies on XML input and XSL-T

transformations producing Java code, similar to

(Reichel and Oberhauser, 2004). Although the

approach is very helpful, developing and verifying

XSL-T transformations has resulted to be tedious.

The content of this paper is to evaluate and

compare the usage of AOP in such a typical MDD

scenario. We started to re-implement the OpenSOA

system with the language AspectJ to avoid code

generation and to reduce code – even if it follows a

different paradigm. The AspectJ implementation is a

(non-obvious) alternative to the existing XSL-T

code generation. Moreover, it could easily be

integrated into the project infrastructure in contrast

to other approaches. Using this basis, several facets

of both solutions are compared and discussed.

At first, we compare the classical criterion of

“lines of code”. This is an indicator for the manual

work to be done. “Code” does not only mean

Java/AspectJ code but also writing XSL-T

transformations and XML input in case of MDD:

both comprise effort to be done.

We distinguish two major roles: The

implementer provides the generative infrastructure,

i.e., implements XSL-T scripts or codes aspects in

AspectJ. In contrast, the user applies this

infrastructure by providing XML input or defining

pointcuts, respectively.

The more lines of code have to be written, the

more work has to be done. But the code does not

determine exclusively the effort. Therefore, we

qualitatively and quantitatively evaluate several

other measures. Understandability is a further mean

for complexity and maintenance effort: The easier to

apply, understand, and maintain a concept, the less

effort an implementer or user has. Furthermore,

testability is important for the implementer to check

the correctness of the framework. For instance,

XSL-T could generate code that is not accepted by a

Java compiler. Further investigation criteria are

usability, redundancy avoidance, and completeness

of the approach. Our evaluation criteria have a

strong industrial background and have been chosen

due to their relevance for the involved OpenSOA

software developers.

We use the case study to compare in detail the

weaknesses and strengths of both approaches with

regard to those criteria in order to give some guid-

ance for choosing amongst the technologies and to

make the best of both worlds.

In the following, we present in Section 2 the

project OpenSOA, a telecommunication middleware

(Strunk, 2007), we used for our case study. Section 3

describes the model-driven approach, based upon

XML and XSL-T, which was in productive use. We

present in Section 4 an alternative AspectJ solution,

which could serve the same purpose. Both

approaches are compared in Section 5 using the

above mentioned criteria. Moreover, it summarizes

the limitations of both technologies and discusses

what of our experiences can be generalized beyond

the case study. Section 6 presents some related

work, before Section 7 concludes the discussion.

2 THE OpenSOA FRAMEWORK

The OpenSOA framework consists of six services:

DomainManagement, UserManagement, Resource-

Management, ProfileManagement, Application-

Management, and RoleManagement. These services

offer CRUD functionality, i.e., create, find, update,

and delete operations. There are 93 operations in

total, i.e., 15.5 operations per service in average.

For each of these Services, classes

ServiceSkeleton

and ServiceTransSkeleton implement essential

middleware functionality, while a class

ServiceImpl

implements the actual business logic. Figure 1

shows the important parts of these classes for the

UserManagement service.

The classes

ServiceSkeleton provide the entry point

for service invocations. CRUD operations such as

create expect both a dedicated parameter request

object and a service context in its signature:

OpReply

op(OpRequest req, ServiceContext ctx). Depending on

whether persistence in a database is required or not,

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

134

the call either delegates to the method

op(params) of

class

ServiceTransSkeleton or to op(params,em) of class

ServiceImpl. The parameter em provides an OpenJPA

EntityManager to perform database operations. In

both cases, a list of parameters (denoted as

params) is

extracted from the

Request parameter by req.get…().

The

ServiceSkeleton class catches technical exceptions

and throws various service exceptions such as

AuthorizationException or PersistenceDuplicateEntityException.

The

ServiceImpl classes provide a code template to

be filled out with the real business logic.

Classes

ServiceTransSkeleton are used only by

services that handle persistence. The class basically

delegates to the

ServiceImpl methods, but puts some

logic around by a template mechanism, especially to

let the

Impl functionality run in a database session and

transaction. The template is obtained by using the

ServiceSkeleton object and used to execute an

OpenJPACallback. The OpenJPACallback must implement a

doInTransaction method, which invokes the ServiceImpl

method that contains the logic to be executed in a

session and transaction. That is,

execute (OpenJPACall-

back)

opens an database connection (which is repre-

sented by an

EntityManager em in OpenJPA) and starts a

transaction around

doInTransaction. Moreover, when a

database operation fails because of connection

problems or database server crashes, a retry is

performed taking a new connection, maybe from a

failover server in order to achieve high availability.

Further classes

OpRequest and OpReply are used in

the signatures of

ServiceSkeleton For operations Op.

Obviously, similar methods occur in different

classes for one single service, having the same name

but slightly different signatures. This should not be

seen as a deficit of the architecture. A major reason

for choosing the design with different signatures is

to achieve better testability with shorter test cycles,

since

ServiceTransSkeleton/Impl can be tested without an

OSGi container. Another reason for this type of

architecture is to have a class

ServiceTransSkeleton for a

reusable session and transaction handling.

So, although we consider the architecture

appropriate, a lot of method signatures and also code

parts have to be kept consistent.

public final class UserManagementSkeleton extends Service implements UserManagement {

private UserManagementTransSkeleton trans = null; ...

public void create(final CreateUserRequest req, final ServiceRequestContext srvCtx) {

UserIdentity ret = null;

try { if (LOG.isDebugEnabled()) LOG.debug("Operation create started: " + req.toString());

final UserDTO user = req.getUser()

final boolean returnIdentity = req.getReturnIdentity();

ret = trans.create(user, returnIdentity, true);

CreateUserReply reply = new CreateUserReply(ret);

srvCtx.reply(reply);

if (LOG.isDebugEnabled()) LOG.debug("Return: " + reply.toString());

if (LOG.isDebugEnabled()) LOG.debug("Operation create completed successfully");

} catch (DomainValidationException e) {

if (LOG.isDebugEnabled()) LOG.debug("missing or wrong arguments.");

srvCtx.fail(e);

} catch ...

} }

public final class UserManagementTransSkeleton {

private UserManagementSkeleton skeleton;

private UserManagementImpl impl = null;

public UserIdentity create(final UserDTO user, final boolean returnIdentity, final boolean isValidated) {

UserIdentity obj = (UserIdentity) skeleton.getOpenJPAConfiguration().getTemplate().execute (

new OpenJPACallback() { public Object doInTransaction(final EntityManager em) {

UserIdentity result = impl.create(user,returnIdentity,em,isValidated);

return result;

} } );

return obj;

} }

public final class UserManagementImpl {

private UserManagementSkeleton skeleton = null;

public com.siemens.project.identity.UserIdentity create(final UserDTO user,final boolean returnIdentity, final EntityManager em,

final boolean isValidated) {

if (!isValidated) //---------- validate params

DomainValidator.validate(user, "user");

/* business logic to be implemented by the programmer */

} }

Figure 1: Classes ServiceSkeleton, ServiceTransSkeleton and ServiceImpl for the UserManagement service

Model-DrivenDevelopmentVersusAspect-OrientedProgramming-ACaseStudy

135

3 THE MDD APPROACH

To ease the development and to handle consistency,

an MDD approach has been established in the

project. Its goal is to keep related signatures and

documentation headers of different parts of a single

service consistent.

The basic idea consists of specifying services in

an XML-based description language in one place.

The user has to specify a file

Service.xml for each

service. The corresponding meta-model is a pre-

defined XML-Schema. Figure 2 presents such a file.

<service name="UserManagement" persistence="true"

eventing="false">

<operation name="create" id="#User01" deprecated=”false”

transaction="true">

<![CDATA[ * <p>Create a new user with all settings from

UserDTO.</p>

* <p>The working domain is the user's domain</p>]]>

</description>

<description> <![CDATA[returns the identity object of the user

created.]]>

</description>

</return>

<description> <![CDATA[DTO containing all information about

the new user.]]>

</description>

</parameter>

<exception type=

"com.siemens.project.exception.DomainValidationException">

<description> <![CDATA[if an argument value is invalid

* that means also null or empty if not explicitly allowed.]]>

</description>

</logmessage>

</exception>

</operation>

Figure 2: XML sample service description.

This XML input is taken for generating code by

means of several XSL-T scripts. In particular, the

documentation and the Javadoc description of

parameters are generated in a consistent manner.

The XML input specifies an XML element

with a certain name. An attribute

persistence=true

controls the persistence infrastructure for using the

OpenJPA persistence framework to access a DBS.

Similarly,

eventing=true prepares an eventing

mechanism in the business logic.

Each

<service> element specifies <operation>s with

<parameter> types, <return> type, and <exception>s in

XML. Several XML attributes affect the code

generation:



deprecated=true lets @deprecated occur in the Javadoc

behind a parameter.



transaction=true adds a session and transaction

management. We call such an operation

transactional in the following.

 Parameters can be validated by specifying a

such as nullAllowed or emptyAllowed; checks

are added on parameter values, e.g., whether null

or empty strings are allowed.

 A

<description> can be added to most XML parts to

be used in Javadoc documentation.

3.1 XSL-T Scripts for Code Generating

There are three basic XSL-T transformations that are

responsible for generating the code for the three

types of classes mentioned before:



TransSkeleton.xsl generates the complete code for

ServiceTransSkeleton classes.



Skeleton.xsl generates the complete code for

ServiceSkeleton classes.



Impl.xsl generates the code frames for ServiceImpl

classes, which have to be completed with

business logic by programmers.

The overall principle of generation is straight-

forward. Each service in

Service.xml results in three

Java classes ServiceTransSkeleton, ServiceImpl, and

ServiceSkeleton

Each XSL-T implementation simply transforms

XML elements and attributes to Java code and

produces the classes. Each

<operation> results in a

corresponding Java method in each class, however,

having slightly different signatures and

implementations for the classes. The

<parameter>s

describe the signature of methods.

The

<description> is used for adding a consistent

documentation including Javadoc.

<description> can

occur at several levels (<operation>, <exception>,

<parameter>).

Details about the output generated from the

XSL-T scripts are described in the following. Figure

3 presents an excerpt of a script to generate a

signature with documentation. These lines show how

verbose and unreadable the XSL-T code is.

3.2 Classes Serviceimpl

The Java code for ServiceImpl classes and its methods

are directly derived from the XML specification.

ServiceImpl is the only class that is not fully generated.

The user has to implement the business logic. Some

specific points are (cf. Fig. 1):

 Signature changes: The create method obtains two

additional parameters

EntityManager em and boolean

isValidated

if transaction=true and<validation nullAllowed=

"false"/>

, respectively, are specified for any

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

136

<xsl:param name=”svc_name”/>

<xsl:template match=”//service”>

<xsl:text>/* * </xsl:text>

<xsl:value-of select=”$svc_name”/>

...

<xsl:for-each select=”operation”>

<xsl:text /* * Operation definition for message based service

interface. * *

@param req the service method’s request object. *

@param srvCtx the service methos’s context object. *

</xsl:text>

<xsl:if test=@deprecated=”true”>

<xsl:text> * @deprecated </xsl:text>

</xsl:if>

<xsl:text>*/ public void </xsl:text> <xsl:value-of select=”@name”/>

<xsl:text (final </xsl:text> <xsl:value-of select=”@name”/>

<xsl:text Request req, final ServiceRequestContect srvCtx) {

</xsl:text>

<xsl:if test=”return/@type != ‘void’”>

<xsl:value-of select=”return/@type”/> <xsl:text ret;/>

...

</xsl:if>

</for-each>

...

</xsl:template>

Figure 3: XSL-T excerpt from Skeleton.xsl.

operation. The first parameter em enables the

method to use OpenJPA’s

EntityManager

functionality. The second parameter allows in-

vokers to switch a parameter validation on or off.

 Additional code fragments: The validation of

parameters of the form “

if (!isValidated)…“, if turned

on by

<validation>, is added at the beginning of the

method. For instance,

nullAllowed=false checks

whether a parameter is null, then throwing a

DomainValidationException.

 import statements: All required imports are

generated, according to what classes are used.

 JavaDoc: The informal

<description> text occurs in

comments, particularly Javadoc

@param and

@return clauses are filled with the operation’s

<description> text as well as @throws for <exception>

specifications. This avoids checkstyle warnings,

which are reported in quality metrics. If an

operation is marked with

deprecated=true, then

deprecated will be added in Javadoc.

3.3 Classes Servicetransskeleton

This type of class is only required for persistent

classes, i.e., services that are specified as

persistence=true. Their methods are allowed to access

the database via OpenJPA. In contrast to ServiceImpl

classes, the generated classes possess a complete

implementation. The following points are specific:

 Signature changes: The signatures differ since

there is no parameter

em.

 Again, headers with Javadoc are generated,

taking into account the different signature.

 The same holds for import statements.

 Code variants: The XML service description

controls the code generation. For example, if

transaction=true is specified for a method, OpenJPA

is used to execute the database statements, and a

session and transaction template is put around

the logic, which also takes care of a retry in case

connection problems.

3.4 Classes Serviceskeleton

The ServiceSkeleton classes are completely generated

according to the XML service specification, which

controls the code generation. We again mention

some specific points:

 Signature changes: Compared to the other

classes, signatures are changing again, e.g.,

operations possess a

Request-object, which

bundles parameter values instead of having

individual parameters. This means that the

parameters for invoking

trans.create must be

extracted from such a Request. Depending on the

context, the right list of parameters is filled in.

 The relevant import statements are added, too.

Again, headers with Javadoc are generated,

taking into account the different signature.

 Additional class fields: If

persistence=true is set for

a service, then the class is prepared to use

OpenJPA by providing an internal field

OpenJPA-

Configuration

openJPAConf with get/set methods.

Similarly, if

eventing=true is specified for a service,

the class is prepared for handling events by

adding a field

EventingComponent myEC with get/set

methods. Any class with a transactional method

also obtains an internal field

ServiceTransSkeleton

trans.

 Code variants: Transactional methods such as

create basically delegate to trans.create. Non-

transactional methods directly delegate to the

ServiceImpl class.

There are six exception types that can be

specified for a method by means of

<exception>:

DomainValidationException, AuthorizationException, Domain-

PersistenceException

etc. Every specified exception

is caught, logged and re-thrown. Special database

exceptions

DataAccessException and Persistence-

Exception

are handled for transaction=true. In

particular, several subtypes of

PersistenceException

are distinguished in order to throw service-

specific exceptions such as

UserDuplicateEntity-

Exception

or UserEntityNotFoundException.The

<logmessage> element for <exception> is used as text

in LOG.debug().

Model-DrivenDevelopmentVersusAspect-OrientedProgramming-ACaseStudy

137

4 AspectJ APPROACH

The most popular AO language is certainly AspectJ

(AspectJ, 2014). AspectJ programming is essentially

done by adding aspects to Java source code. The

main purpose of aspects is to concentrate cross-

cutting functionality. To this end, an aspect can

intercept certain points of the program flow, called

join points, and add logic by advices. Examples of

join points are method and constructor calls or

executions, attribute accesses, and exceptions.

Join points are syntactically specified by means

of pointcuts. Pointcuts identify join points in the

program flow by means of a signature expression. A

specification can determine exactly one method by

describing the complete signature including

final,

private, static, return and parameter types etc. Or it can

use wildcards to select several methods of several

classes by

* MyClass*.get*(.., String). A star “*” in names

denotes any character sequence. Hence,

get* means

any method that starts with “get”. A type “*” denotes

any type. Parameter types can be fixed or left open (..).

The following aspect has a before advice that

adds logic before executing those methods that are

captured by the pointcut

myPC:

aspect MyAspect {

pointcut myPC():

execution(*MyClass*.get*(..));

before() : myPC() { // advice:

Java

code to be executed before myPC join points }

}

4.1 General Principle

Using AspectJ, we re-implemented the software

system. We were able to replace the code generation

with a pure homogeneous language approach. There

is no XML input and no XSL-T transformation. It is

just AspectJ code.

The basic idea is to let developers start with

manually writing the

ServiceImpl classes instead of

Service.xml descriptions, including Javadocs and the

business logic. The signatures in

ServiceImpl now need

to be specified as required, i.e., including em and

isValidated parameters (which are added by XSL-T, cf.

Section 3.2, if specified). This has to be done only

once in the

Impl classes.

AspectJ is used to add all the missing parts for

the whole implementation. The aspects are described

in more detail in the subsequent subsections.

4.2 One Transskeletonaspect

A TransSkeletonAspect aspect is responsible for

implementing the functionality of

TransSkeleton classes

(see Section 3.4 and Figure 1), which provide the

session and transaction handling. Instead of

specifying

transaction=true for specific methods, a

pointcut

executeInTx() determines the transactional

methods to which the logic of

doInTransaction() should

be applied, i.e., all public methods of

Impl classes that

possess an

EntityManager parameter:

pointcut executeInTx(EntityManager em)

: execution(public *com.siemens.project.*Impl.*(..)) && args(em);

A single around advice can then add the logic:

Object around(EntityManager em) : executeServiceInTx(em) {

Object ret = null;

EntityManagerFactoryImpl emf = openJPAConf.getEMFactory();

em = emf.getEntityManager();

... retry loop around ...

EntityTransaction tx = em.getTransaction();

ret = proceed(em); /* exec Impl-method instead of

doInTransaction(em) */

... commit or rollback on tx

return ret;

}

The advice obtains an EntityManager em, starts and

ends a new transaction, invoking the intercepted

method with

proceed() in between, and putting the

redo logic around (not shown here). Hence, the logic

is done in a central place and becomes much easier

since we get rid of the complicated

OpenJPACallback

template mechanism as shown in Figure 1 and

explained in Section 2. Please note this code is now

defined once and no longer part of every

transactional method. The pointcut defines where the

code has to be executed.

4.3 Skeletonaspect for each Service

In principle, there is no need for Skeleton classes since

it is possible to put the logic around the

Impl methods.

However, we are faced with the problem that the

Skeleton methods are invoked from outside. More-

over, the signatures refer to service-specific

OpRequest and OpReply objects. Thus, we are forced to

keep the

Skeleton classes. However, we are able to

factor out common functionalities in aspects. The

following code remains to be written for the user

management service, for example:

public class UserManagementSkeleton extends Service {

private UserManagementImpl impl = null;

private UserManagementTransSkeleton trans = null;

public void create(final CreateUserRequest req,

final ServiceRequestContext srvCtx) {

if (LOG.isDebugEnabled()) {

LOG.debug("Op create started");

} // -> added by single before advice

UserDTO user = req.getUser();

boolean id = req.getReturnIdentity();

UserIdentity ret = impl.create(user,id,true);

CreateUserReply reply = new CreateUserReply(ret);

srvCtx.reply(reply);

if (LOG.isDebugEnabled()) {

LOG.debug("Op create succeeded");

} // -> added by after return advice

return ret;

} }

This is basically the Skeleton-method without

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

138

logging functionality (see the strikethrough) and

exception handling, both being extracted into

aspects. In the original code, a method of the

Trans-

Skeleton

or Impl is invoked inside depending on the

transactional setting. Here, we call the Impl-method

directly since the

TransSkeleton behaviour (if

necessary) is put around by means of an aspect.

Thus, the reference

TransSkeleton trans is no longer

needed.

It remains to manually specify the signature, un-

pack parameters from a

CreateUserRequest, and invoke

methods

impl.op of ServiceImpl classes.

If persistence is required, get/set methods for

OpenJPAConfiguration and a corresponding internal field

need to be added. This can simply be implemented

in a dedicated superclass

Persistence:

public class Persistence {

private OpenJPAConfiguration openJPAConf = null;

public OpenJPAConfiguration getOpenJPAConfiguration()

{ return this.openJPAConf; }

public void setOpenJPAConfiguration (OpenJPAConfiguration conf)

{ this.openJPAConf = conf; }

}

The following statement puts the Persistence

superclass on top of persistent Skeleton classes and let

derived classes inherit the above functionality:

declare parents: UserManagementSkeleton, ... : Persistence

Similarly, another superclass Eventing and a declare

parents

statement are added if eventing is enabled.

Please note there is no problem with multiple

inheritance: Aspects can add two superclasses,

Persistence and Eventing, to a Skeleton class.

A single SkeletonAspect aspect keeps all these declare

parents

statements and also concentrates the logging

functionality in corresponding

before/afterReturning

advices:

public class SkeletonAspect {

declare parents:

... /* as above */

private static final Logger LOG

= Logger.getLogger(SkeletonAspect.class);

before() : call(public * com.siemens.project.impl.*Skeleton.*(..)) {

if (LOG.isDebugEnabled())

LOG.debug("Operation " + thisJoinPoint.getSignature()

+ " started");

}

afterReturning() { Log.debug() for successful operation ... }

}

4.4 Aspect for Exception Handling

Another aspect takes care of exception handling,

which was originally part of

Skeleton classes. This

aspect defines several advices. Each advice adds a

further try-catch block around the invocation of

Impl

methods:

public aspect ExceptionAspect {

Object around() :

call(... any Skeleton method with a DomainValidationException ...) {

Object ret = null;

ServiceRequestContext srvCtx = (ServiceRequestContext)

thisJoinPoint.getArgs()[1];

try {

ret = proceed();

}

catch(DomainValidationException e) {

if (LOG.isDebugEnabled())

LOG.debug ("missing or wrong arguments.");

srvCtx.fail(e);

}

return ret;

} // ... for other exceptions

}

The ServiceRequestContext, which is used to signal a

failure, is obtained by accessing the second

parameter of the joinpoint by means of

thisJoinpoint.getArgs()[1].

DataAccessException and PersistenceException, which

are thrown in case of transactional methods

(

transaction=true), are handled similarly, however,

transforming exception types:

catch (PersistenceException e) {

if (e instanceof PersistenceDuplicateEntityException) {

if (LOG.isDebugEnabled())

LOG.debug("Domain entity already exists in the database.");

srvCtx.fail(new DomainDuplicateEntityException

(e.getMessage()));

} else if ... other exceptions ...

}

4.5 Validation Logic

Validation logic such as

if (!isValidated) DomainValidator.validate(user,“user”)

is inserted whenever a validation is required. This

adds a check for nullness for the given parameter

name in the method of the

Impl class. In XSL-T, this

is specified for an operation by means of

The same behaviour can be achieved by a before

advice that adds the nullness check before method

execution. The problem is how to get the parameter

object to be checked, i.e.,

user above. As the kinds of

validation checks the programmer would like to

perform is known in advance, we can simplify the

code by only referring to the position of the

parameter in the signature. For example, we provide

pointcuts

validateNotNullAtPositioni that allow for adding a

check for a certain position

i. An advice can access

the parameter at this position:

public aspect ValidationAspect {

pointcut validateNotNullAtPos0 (Object o, boolean isVal) :

execution(...) && args(o,..,isVal);

before(Object o, boolean isVal) : validateNotNullAtPos0(o, isVal) {

if (!isVal) {

MethodSignature sig = (MethodSignature)

thisJoinPointStaticPart.getSignature();

String name = sig.getParameterNames()[0];

DomainValidator.validate(o,name);

} } }

Model-DrivenDevelopmentVersusAspect-OrientedProgramming-ACaseStudy

139

The parameter name, to be added to

Domain-

Validator.validate

, is obtained by means of reflection

(

MethodSignature); the isValidated parameter always

occurs last and can simply be bound to a variable isVal.

To make code more readable, an annotation

@Validate(“user”,nullAllowed=“false”) can mark every method

to be validated: An aspect intercepts any usage of

this annotation and inserts the validation logic. This

makes usage easier.

5 COMPARISON

We compare the originally existing MDD with the

new AOP approach with regard to several

comparison criteria. The criteria have been selected

due to their relevance for the OpenSOA developers.

At first, we investigate the classical quantitative

criterion of “lines of code”. This is a measurement

for the manual work to be done. “Code” here does

not only mean Java or AspectJ code but also XSL-T

transformations and XML input in case of MDD:

This comprises effort to be done as well. Further,

qualitatively evaluated, criteria are usability,

understandability, testability (which all affect

development time), and redundancy. We took those

criteria without any weights since they all together

have an impact on development time and cost. We

asked the developers but did not obtain a precise

weighting.

Please also note we ignored performance since

the performance is mostly affected by database

accesses. Anyway, the types of pointcuts we use are

very simple and usually do not cause performance

issues.

The results are partially subjective in the sense

that the assessment of the original MDD infrastruc-

ture is done by the involved software developers.



5.1 Lines of Code

The XSL-T approach requires XML input files

Service.xml. That is the specification effort for a user to

apply the infrastructure for the six services

ApplicationManagement, DomainManagement etc.

All these XML files have 4339 lines in total.

To provide the generative infrastructure, the

implementer has to implement three XSLT scripts:

TransSkeleton.xsl (220 lines), Skeleton.xsl (499 lines), and

Impl.xsl (384 lines). We have mentioned briefly the

classes Request/Reply for Skeleton operations. These are

generated as well by XSL-T scripts RequestObject.xsl

(205 lines) and

ReplyObject.xsl (113 lines). These are

1421 lines for code generation.

In total, 5760 (= 4339 + 1421) lines are required

for the XSL-T approach.

In the AspectJ solution, an implementer has to

code advices in AspectJ, while a user applies this

infrastructure by defining pointcuts or placing

annotations.

The user has to manually implement a class

ServiceImpl. From a logical point of view, the

specification parts in

Service.xml are directly put into

code in

ServiceImpl.java; These are 1208 lines for 93

methods without business logic (which we do not

count in either approach).

The infrastructure is given by aspects. One

aspect

TransSkeletonAspect handles the transactional

behaviour for transactional methods. The decision

which methods are transactional is done by means of

method pointcuts. An

around advice puts the

transactional logic around the relevant methods of

Impl-classes. This aspect has 259 lines.

A SkeletonAspect aspect adds Persistence and Eventing

super classes by means of two

declare parents

pointcuts. Moreover, the aspect introduces logging

with

before/afterReturning advices. This aspect requires

12 lines of code. The two new superclasses

Persistence

and Eventing have 17 lines (9 and 8 lines).

For each Service, a ServiceSkeleton class must be

implemented due to external usage. These are 93

methods with about 8 lines in average, which sums

up to 744 lines.

ExceptionAspect adds exception handling. It

comprises 2 lines for the aspect declaration itself and

12 lines for each of 6 the exception types. Handling

transactional exceptions requires additional 21 lines.

This sums up to 95 lines.

One

ValidationAspect handles the validation code for

at most two positions: 8 * 2 positions à 13 lines.

These are additional 208 lines.

Hence, the AspectJ approach requires 2543 lines

thus saving more than 3600 lines, i.e., nearly 60%.

Unfortunately, this calculation does not consider

the 94

Request and 57 Reply classes for Skeleton

operations. In the XSL-T approach, these 10418 and

4176 lines of code, respectively, are generated. But

in the AspectJ approach, there is no mean to produce

or to avoid these classes: We have to manually

implement those 14594 lines of code: The

previously calculated advantage of AspectJ is lost!

However, the classes contain a lot of trivial

comments (28 lines for Request and 15 lines for

Reply classes in average), i.e., 3487 lines could be

left out. Since the classes are simple JavaBeans with

a constructor, a get-method, and

toString method,

specifying the attributes is enough; Eclipse or any

other IDE can generate the code by a mouse-click.

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

140

This requires additional time to handle the IDE, but

reduces the lines of code by further 735 lines (94*6

+ 57*3). But the AOP approach still requires 10372

lines for handling Request/Reply-classes.

5.2 Understandability

There is another point that concerns the development

time for providing the infrastructure: under-

standability. It also affects the evolution of the

system.

XSL-T is quite different from an object-oriented

programming language such as Java, since it defines

a set of rules that apply to a given XML document

recursively. Reading those rules and understanding

the overall behaviour is not easy even if one is

familiar with XML and XPath. In particular, the

rule-base approach makes it difficult to write or to

extend XSL-T scripts. Moreover, programmers must

handle a couple of unintuitive and error-prone

details of XSL-T, such as a special handling of zero-

parameter methods or leaving out a “,” after the last

parameter in parameter lists. Other MDD

frameworks such as (Xtend2,XPand) provide a

better support.

These drawbacks are not present in the AspectJ

approach. Indeed, its major advantage is its homo-

geneity: There is one language to learn, AspectJ,

which extends well-known Java by a few constructs

such as pointcuts and advices the semantics of which

is clear and understandable. Advices, in turn, are

implemented in pure Java. Having a little knowledge

about AspectJ, it should be no problem to

understand the advices we have presented.

The disadvantage is that some conceptual points

cannot be handled appropriately. One example is

adding validation logic, which becomes less intuitive

because we cannot directly handle the parameter

position (cf. subsection 4.6). Furthermore, we cannot

generate

Skeleton and Request/Reply classes easily.

These parts must be hand-coded. And finally, import

statements must be added manually or generated by

using IDE support. In contrast, those parts are

completely generated in the XSL-T approach.

5.3 Testability

Testability is the major disadvantage of the XSL-T

approach. Since code is generated, syntactical

correctness is not immediately visible. Thus, the

effort to check correctness is high. Several cycles of

generating code, compilation, testing, and debugging

are necessary in order to check ultimate correctness.

Moreover, debugging of XSL-T is very limited.

Moreover, the correct behaviour must be proven

by unit testing. This means particularly that any

variation within XML service descriptions has to be

checked and unit tested. This is difficult and

increases complexity with the number of possible

combinations. One possible but challenging

approach is to generate unit tests as part of the

XML-based generation. However, also because of

the complexity of the XSL-T language, only manual

testing of main use cases was performed for

OpenSOA. The (inappropriate) strategy, we noticed

in practice, is thus to let developers generate code

and detect problems during tests; having their

feedback, implementers can fix the problems. In

turn, a new rollout of the MDD infrastructure is

required, leading to slow turn-around cycles for

bugfixing.

Using AspectJ, syntactical correctness is

immediately given for both the infrastructural

advices and the pointcuts thanks to special plug-ins

such as AJDT for the Eclipse IDE. As a direct

consequence of the integrated language approach

and corresponding compiler support, any syntax

errors in wildcards or aspects are detected by a

compiler. The plugin also issues a warning if a

pointcut does not match any joinpoint in the code

base. Only the correct behaviour has to be checked,

but can be achieved by running unit tests in an

ordinary Java IDE. Moreover, debugging AspectJ is

similar to Java code thanks to IDE support.

5.4 Usability

In the XSL-T approach, it is very straightforward to

write input .xml files. Moreover, an XML schema

exists and indicates any syntactical errors in input

files. Only the code generator has to be started to

produce Java code.

In AspectJ, applying “code generation” means to

specify corresponding pointcuts, e.g., to apply

exception handling or the transaction template to

methods. Despite not being part of the ordinary Java

language, pointcuts are easy to understand. In fact,

we only use a small subset of AspectJ pointcuts,

more or less using obvious wildcard expressions in

the sense of “all method of a

Service class”. Anyway,

the simplest way is to enumerate methods. Applying

aspects is mostly a one-line pointcut. Moreover,

excellent support of the Eclipse AJDT plugin let one

determine the effect of aspects immediately, e.g.,

where an advice will be inserted. Using annotations

to apply an aspect certainly yields to a better

separation of infrastructure and usage.

Model-DrivenDevelopmentVersusAspect-OrientedProgramming-ACaseStudy

141

5.5 Redundancy

The XSL-T transformations are partially redundant

because the redundancy of signatures moves from

code to XSL-T scripts: Generating similar classes

Impl, Skeleton, TransSkeleton etc. with similar methods

requires similar XSL-T transformations.

Furthermore, the exception handling in the generated

code is crosscutting and scattered around classes in

the final outcome.

AspectJ, from its nature, has a much better

separation of concerns for handling the transaction

skeletons and exception handling. The overall

redundancy is less. There are no longer several

similar classes, it is essentially the

Impl Java class; the

logic of other generated classes becomes part of

aspects. However, there are some limitations. For

instance, the Skeleton methods have to be manually

written (with IDE support for generating import’s).

Even if some common logic can again be

concentrated in aspects, e.g., by putting superclasses

on top of classes, we cannot avoid these classes.

5.6 Completeness

The XSL-T approach allows for generating code

including Javadoc comments and import statements.

In contrast, the AspectJ solution is not able to

handle necessary import statements. The AO

approach simply relies on IDE support such as

“Organize import” functionality; which however

often is just a mouse-click. Similarly, comments and

Javadocs have to be manually added. From a logical

point of view, those parts move from

Service.xml to

ServiceManagementImpl.java, i.e., put directly into code.

In the XSL-T approach, Javadoc is generated into

several classes, but this is not necessary here: There

will be only one Java class, besides additional

aspects.

5.7 Comparison Summary

The results we obtained with our case study indicate

that AspectJ reveals its major strengths in avoiding

redundancy and better testability, while MDD with

XSL-T is a more complete and flexible approach. In

fact, XSL-T allows for generating arbitrary artefacts

the design demands, whereas AspectJ cannot

provide this functionality and would require changes

in the design. AOP in turn is better understandable

and readable, however, we see that other MDD tools

offer more advanced and integrated features.

Table 1 provides a rough summary of the

comparison results.

Table 1: Summary of comparison results.

AspectJ - AOP XSLT - MDD

Lines of Code - (requires add.

OO classes)

o (duplicated

XSLT code)

Under-

standability

+ (straight

forward)

- (complex

syntax/semantic)

Testability + (directly

testable)

o (difficult for

generated code)

Usability o/+ (reasonable) - (difficult)

Redundancy + (nearly not

redundant)

o (partially

redundant)

5.8 Limitations and Generality

As our case study focuses on a specific software

framework, our study cannot serve as an extensive

guide for the selection among the technologies for

arbitrary use cases and software projects.

Nevertheless, we think that our case study results

can be of value for practitioners being in the

situation to choose among them.

As our problem of generating wrapper classes

and boilerplate-code is rather common, we believe

that our results have potential to be transferred to

other problem settings. Furthermore, we think that

the dimensions our evaluation is based on will help

others to guide their decision making when choosing

amongst the technologies or to take benefit from the

best of both worlds.

Whereas in our solution, understandability

speaks in favour of AOP, we see that more advanced

and integrated tooling could significantly improve

the position of MDD here. More advance generator

languages, for example Xtend2 (Xtend2), provide a

more straight forward generation approach, without

recursive generation rules, but with mature editor

support and even debugging functionality.

6 RELATED WORK

There are several case studies and a large body of

papers that either only evaluate the benefits and

liabilities of MDD (e.g., Kapteijns et al., 2009,

Lussenburg et al., 2010) or AOP (e.g., Kästner et al.,

2007). For example, (Kästner et al., 2007) take the

Berkeley DB as a case study and refactored the code

into 38 features. While other studies, e.g., (Lee,

2006), suggested that features of a product line be

implemented by aspects, they find that AspectJ is

not suitable to implement most of their features.

Even if this work is not a comparison, it shows

deficiencies of the language AspectJ, not necessarily

of AO or AOP, with respect to their case study. In

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

142

contrast, (Hohenstein, 2005) shows how to

successfully apply aspects to implement a

persistence framework, which is usually controlled

by code generation based upon annotations or XML.

Our work, in contrast, aims at a comparison of

AOP with MDD, in order to support the selection

among the technologies. Only few work exists that

explicitly makes such a comparison. (Stein and

Hanenberg, 2006) argue that AOSD and MDD are

alike since both adapt an input system in order to

receive an augmented output system, however, using

different approaches, weaving and transformation,

respectively. They discuss the technical differences

by means of an example. (Kaboré and Beugnard,

2007) compares AOP and MDD with regard to a

better separation of concerns. They only investigate

how to describe and how to apply both, concluding

that a model-driven approach offers more flexibility.

(Liu et.al, 2006) use a heart pacemaker product

line to elaborate on modelling crosscutting

variability with AO. They state that AO can benefit

the MDD of product lines. The study identifies

desired characteristics of AO modelling techniques

for product lines and proposes similar evaluation

criteria to ours such as feasibility, degrees of

variability, evolution, tool support, and cost,

however, miss to investigate those in their case

study.

(Anastasopoulos and Muthig, 2004) use a mobile

phone software product line to systematically

evaluate AOP as a product line technology. Their

result is that AOP is especially suitable for

variability across several components. The study

discusses several factors and the effort for various

activities: implementing reusable code, reacting to

evolutionary changes, reusing code, resolving

variations, and testability. Our study discusses

similar points, however, at a deeper level using a

real industrial case study.

Indeed, there is further significant work on

combining AOP and MDD. For instance,

(Henthorne and Tilevich, 2007) notices that the

generated code is not always adequate for a task at

hand, and mentions following in-house coding

conventions and missing import features as

examples. These are particular problems we handle.

Generating AspectJ code helps to give flexibility.

(Pinto et al., 2009) combine both approaches by

describing an MDD approach that generates aspect-

oriented models. That is, aspects are part of the

outcome. This is especially useful to handle unanti-

cipated variabilities by means of aspects as the

MDD/AOP approach of (Völter and Groher, 2007)

illustrates. In our work, we explicitly compare the

two technologies, to avoid increasing the overall

technical complexity and dependencies of the

developed software, in our case, the OpenSOA

framework.

7 CONCLUSION

In this paper, we compared two completely different

approaches, model-driven development (MDD) and

aspect-oriented programming (AOP) with AspectJ,

by means of a real industrial software system and

thus investigating several criteria. While MDD, here

applying XSL-T, is straight forward and well-

understood for code generation, the usage of AOP is

not so obvious, but can serve the same purpose in a

different manner (Stein and Hanenberg, 2006).

We achieved some interesting results during an

aspect-oriented re-implementation of the original

XSL-T system. AOP is principally able to handle

code generation and has some advantages over XSL-

T: AspectJ is better understandable and usable,

especially from an implementer’s point of view.

There is a huge advantage for testing, in particular,

checking the syntactic and semantic correctness. We

also notice a better separation of concerns and

avoidance of redundancy, for instance, if logic is put

around existing code (transactional skeleton) or

after/before (logging). The most striking limitations

appear if new classes have to be introduced. This is

the main reason why the pure AspectJ-based

solution requires more lines of code (LoC).

XSL-T has advantage if several code generators

are producing several output files based upon the

same input file. This leads to the mentioned LoC

advantage. Thus, XSL-T is more extensible and has

potential for creating further classes, in particular

Request/Reply classes in this case study. Finally,

XSL-T results in a rather weak understandability.

This, however, seems to be a consequence of the

technology choice than of the MDD approach in

general. By using MDD approaches with more

intuitive languages and mature IDE support based

around Eclipse Ecore (e.g., (Xtext, Xtend2)), we

believe the implementation and the evaluation would

improve in this category. In particular, there are

tools available that can be used to produce Java

code, at least classes and method signatures as a

model. This can build a basis to take the Java

ServiceImpl file as input and produce Request and

Reply classes. Indeed, (Heidenreich et al., 2009)

even developed an Ecore metamodel for Java 5.0

together with a parser and printer, so that plain Java

statements could be produced.

Model-DrivenDevelopmentVersusAspect-OrientedProgramming-ACaseStudy

143

A combination of XSL-T and AspectJ also seems

to be a promising approach to combine the

advantages of each technology. This particularly fits

smoothly to the existing implementation. That is

why we intend to investigate the combination of

both approaches, i.e., following (Henthorne and

Tilevich, 2007) to generate aspects within the code

to get the best out of both worlds.

REFERENCES

Anastasopoulos, M., Muthig, D., 2004. An Evaluation of

Aspect-Oriented Programming as a Product Line

Implementation Technology. In ICSR 2004.

AspectJ. Eclipse AspectJ Homepage.

http://eclipse.org/aspectj/, visited 2014-03-18.

Beuche, D., 2006. Variant management with

pure::variants. Technical report, pure-systems GmbH,

2006. http://www.pure-systems.com/fileadmin/down-

loads/pv-whitepaper-en-04.pdf, visited 2014-05-25.

Groher, I., Krüger, C., Schwanninger, C., 2008. A Tool-

Based Approach to Managing Croscutting Feature

Implementations. 7th Int. Conf. on AOSD, Brussels

2008.

Hohenstein, U., 2005. Using Aspect-Orientation to Add

Persistency to Applications. Proc. of Datenbank-

systeme in Business, Technologie und Web (BTW),

Karlsruhe 2005.

Heidenreich, F. Johannes, J. Seifert, M. Wende, C., 2009.

Closing the Gap Between modelling and Java. In Proc.

of 2nd Int. Conf. on Software Language Engineering,

Springer, Lecture Notes in Computer Science, 2009.

Henthorne, C., Tilevich, E., 2007. Code Generation on

Steroids: Enhancing Code Generators via Generative

Aspects. 2nd Int. Workshop on Incorporating COTS

Software into Software Systems: Tools and

Techniques (IWICSS’07).

Kästner, C., Apel, S., Batory, D., 2007. A Case Study

Implementing Features Using AspectJ. In Proc. Int.

Software Product Line Conference (SPLC), Kyoto

2007.

Kaboré, C., Beugnard, A., 2007. Interests and Drawbacks

of AOSD compared to MDE – A Position Paper. 3rd

Workshop on Aspects and Models, at 21st ECOOP

2007.

Kapteijns, T., Jansen, S., Houet, H., Barendse, R., 2009. A

Comparative Case Study of Model Driven

Development vs Traditional Development: The

Tortoise or the Hare. In CTIT Proc. of 5th European

Conf. on Model Driven Architecture, 2009.

Kiczales, G. et al., 2001: An overview of AspectJ. Proc. o

ECOOP , 2001.

Lee, K., 2006. Combining Feature-Oriented Analysis and

Aspect-Oriented Programming for Product Line Asset

Development. In Proc. Int. Software Product Line

Conference, 2006.

Liu, J., Lutz, R. Rajan, H., 2006: The Role of Aspects in

Modeling Product Line Variabilities. In Proc. of 1st

Workshop on Aspect-Oriented Product Line

Engineering, GPCE, Portland (Oregon) 2006.

Lussenburg, V., van der Storm, T., Vinju, J., 2010.

Mod4J: A Qualitative Case Study of Model-Driven

Software Development. In: Model Driven Engineering

Languages and Systems. Warmer Lecture Notes in

Computer Science Volume 6395, 2010.

Mezini. M. Ostermann, K., 2004. Variabilility

Management with Feature-Oriented Programming

and Aspects. In Proc. of 12th Int. Symp. On

Foundations of Software Engineering (FSE), Newport

Beach (CA), 2004.

MPS. JetBrains :: Meta Programming System.

http://www.jetbrains.com/mps/, visited 2014- 05-25.

Normén, F., 2007. Remove code smell with AOP.

http://weblogs.asp.net/fredriknormen/archive/2007/11/

29/remove-code-smell-with-aop.aspx, visited 2014-

05-25.

Pinto, M., Fuentes, L. Fernández, L., Valenzuela, J., 2009.

Using AOSD and MDD to Enhance the Architectural

Design Phase. In: Proc. OTM’09.

Reichel, C. Oberhauser, R., 2004. XML-Based

Programming Language Modeling: An Approach to

Software Engineering. In: SEA 2004.

Smaragdakis, Y., Huang, S., Zook, D. 2004. Program

Generators and the Tools to Make Them. In SIGPLAN

Symp. on Partial Evaluation and Semantics-Based

Program Manipulation, ACM Press 2004.

Strunk, W., 2007. The Symphonia Product-Line. Java and

Object-Oriented (JAOO) Conf, Arhus, Denmark, 2007

Stein, D., Hanenberg, S., 2006. Why Aspect-Oriented

Software Development and Model-Driven Develop-

ment are not the Same – A Position Paper. Electr.

Notes Theor. Comput. Sci. 163(1), 2006.

Stahl, T. Völter, M., 2006: Model-Driven Software

Development. Wiley&Sons, 2006.

Tarr, P., Osher, H., Harrison, W., Sutton, S., 1999: N

Degrees of Separation: Multi-Dimensional Separation

of Concerns. In 21st Int. ICSE 1999.

Völter, M., Groher, I., 2007: Product Line Implementation

using Aspect-Oriented and Model-Driven Software

Development. In: 11th Int. Software Product Line

Conference (SPLC), Kyoto (Japan) 2007.

Xtend2. Eclipse Xtend 2 Homepage. http:

//www.eclipse.org/Xtext/#xtend2, visited 2014-03-18.

Xtext. Eclipse Xtext Homepage. http://www.eclipse.

org/Xtext/, visited 2014- 05-25.

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

144
