Specifying Complex Correspondences Between Relational Schemas in a

Data Integration Environment

Val´eria Pequeno

and Helena Galhardas

INESC-ID, Taguspark, Lisbon, Portugal

DEI, Instituto Superior T´ecnico and INESC-ID, Taguspark, Lisbon, Portugal

Keywords:

Schema Matching, Correspondence Assertions, Data Integration, Relational Model.

Abstract:

When dealing with the data integration problem, the designer usually encounters incompatible data models

characterized by differences in structure and semantics, even in the context of the same organization. In

this work, we propose a declarative and formal approach to specify 1-to-1, 1-m, and m-to-n correspondences

between relational schema components. Differently from usual correspondences, our Correspondence Asser-

tions (CAs) have semantics and can deal with joins, outer-joins, and data-metadata relationships. Finally, we

demonstrate how we can generate mapping expressions in the form of SQL queries from CAs.

1 INTRODUCTION

A Data Integration (DI) system aims at integrating a

variety of data obtained from different data sources,

usually autonomous and heterogeneous, and provid-

ing a uniﬁed view of these data, often using a global

schema (also named mediation schema). The global

schema makes a bridge between the data sources and

the applications that access the DI system. Data in a

DI system can be physically reconciled in a repository

(materialized data integration approach), or can re-

main at data sources and is only consolidated when a

query is posed to the DI system (virtual data integra-

tion approach). A data warehouse system (Kimball

et al., 2008) is a typical example of the ﬁrst approach.

As examples of the second approach, we can cite fed-

erated information systems (Popﬁnger, 2006) and me-

diator systems (Langegger et al., 2008). In the present

work, both scenarios can be used, but in this paper we

will focus on the materialized integration approach.

One of the hardest problems to solve in DI is to de-

ﬁne mappings between the global schema (the target)

and each data source schema, known as the schema

mapping problem. It consists of two main tasks: i)

schema matching to deﬁne/generate correspondences

(a.k.a. matches) between schema elements (e.g., at-

tributes, relation, XML tags, etc.); and ii) schema

mapping to ﬁnd data transformations that, given data

instances of a source schema, obtain data instances of

the target schema.

The result of schema matching is a set of corre-

spondences that relate elements of a source schema

to elements of the target schema, where an element

can be a relation name or attribute in the relational

model. Each correspondence speciﬁes the elements

that refer to the same real world entity (Doan et al.,

2012). These correspondences can be described us-

ing a Local-as-view (LAV), a Global-as-view (GAV),

or a Global and Local-as-view (GLAV) language. In

summary, in a LAV approach, each data source is de-

scribed as a view over the global schema. In a GAV

approach, the global schema is expressed as a view

over the data sources. Finally, the GLAV combines

the expressivepower of both GAV and LAV. Once the

schema matching is performed, the correspondences

are used to generate the schema mappings. For ex-

ample, a schema mapping can be codiﬁed through an

SQL query that transforms data from the source into

data that can be stored in the target.

Extensive research on schema matching has been

carried out in recent years (Cruz et al., 2009; Selig-

man et al., 2010; Bellahsene et al., 2011). The ma-

jority of the works on this subject identiﬁes 1-1 cor-

respondences between elements of two schemas. For

example, a 1-1 correspondence can specify that ele-

ment title in one schema matches element ﬁlm in an-

other schema, or that relation GENRE matches relation

CATEGORY

. This kind of schema matching is known

in the literature as basic matching. Goods surveys can

We use bold to represent attribute names and UPPER-

CASE to represent relation names.

Pequeno V. and Galhardas H..

Specifying Complex Correspondences Between Relational Schemas in a Data Integration Environment.

DOI: 10.5220/0004870200180029

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 18-29

ISBN: 978-989-758-027-7

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

be found in (Rahm and Bernstein, 2001; Shvaiko and

Euzenat, 2005).

While basic matching is common, it leaves out nu-

merous correspondences of practical interest, in par-

ticular when we consider DI systems. Thus, more

complex matches are necessary. A complex matching

speciﬁes 1:n, m:n, or n:1 correspondences between

elements of two schemas. For example, it may spec-

ify that totalPrice corresponds to unitPrice * quan-

tity; or that name matches concatenate(ﬁrstName,

lastName), where concatenate is a function that ap-

plies to two strings and returns a concatenated string;

or even that the average departmental salary avg-

Wage corresponds to grouping the salaries (salary)

of all employees (emp) by department (dept). (Doan,

2002; Massmann et al., 2011; Mork et al., 2008) are

examples of approaches that propose formalisms to

specify complex matches.

Some researchers go beyond dealing with com-

plex matches and add semantics to the correspon-

dences, in order to improve the overallmatching qual-

ity. In the Section 2, we explain more about complex

matches and present a motivation example for the cur-

rent work. The remainder of the paper is structured as

follows. In Section 3, we present the necessary back-

ground in Correspondence Assertions (CAs), the for-

malism used in this work to specify correspondences

between elements of schemas. In Section 4, we pro-

pose new CAs to deal with join operators and meta-

data. Section 5 shows how to generate mapping ex-

pressions from CAs. Section ?? describes the related

work. Finally, Section 7 concludes and describes fu-

ture work.

2 MOTIVATING EXAMPLE

Consider a motivating example with the source

schemas S

and S

in Figure 1, which contain infor-

mation about movies. S

keeps a catalog of movies

with information about different types of media (dvd,

blue rays, etc.) in which the movies are available. The

names of the relations and attributes are mostly self-

explanatory. The attributes in S

have the following

meaning: id is the movie identiﬁer, year is the year

of a movie, ﬁlm is the title of a movie, number is

the tape identiﬁer, format is the type of the tape (dvd,

blu-ray, etc.), name can be a producer or a director

name, and role is the role of a professional of the

show business: producer or director. FK1 and FK2

are foreign keys. We use, as in (Vidal et al., 2013),

the notation FK(R:L, S:K) to denote a foreign key,

named FK, where R and S are relation names and

L and K are list of attributes from R and S, respec-

* Schema S

MOVIE(id, ﬁlm, year, summary)

TAPE(number

, format, id)

FK1(TAPE, hidi, MOVIE, hidi)

MOVIEMAKERS(id, name, role)

FK2(MOVIEMAKERS, hidi, MOVIE, hidi)

* Schema S

FILM(id

,title, year, rate)

SHOWTIME(id

, location, time, city)

FK3(SHOWTIME, hidi, FILM, hidi)

* Schema M

MOVIE(title

, genre, year, description)

FILMMAKERS(movie

, producer, director)

FK4(FILMMAKERS, hmoviei, MOVIE, htitlei)

SCHEDULE(movie

, cinema, startTime)

FK5(SCHEDULE, hmoviei, MOVIE, htitlei)

REMAKES(title

, nvYear, ovYear)

FK6(REMAKES, htitlei, MOVIE, htitlei)

RATING(rate

, quantity)

Figure 1: Example of source schemas and a global schema.

tively, with the same length. FK1 is the foreign key of

TAPE that refers to MOVIE and FK2 is the foreign key

of MOVIEMAKERS that refers to MOVIE. S

stores

general information about movies and the places (in

different cities) where movies are being shown. We

assume that S

can store older movies than S

. The

attributes in S

have the following meaning: id is

the movie identiﬁer, year is the year of a movie, ti-

tle is the title of a movie, rate is the classiﬁcation of

the movie with regard the audience, location and city

are, respectively, the cinema and the name of the city

where the movie is shown, and time is the date when

the movie is shown.

The global schema M, also shown in Figure 1,

provides a uniﬁed user view of movies currently

shown in cinemas of Lisbon. It is populated by in-

formation from schemas S

and S

. The relation

M.MOVIE stores movies shown currently at a cin-

ema

. The relation M.FILMMAKERS keeps informa-

tion about professionals of show businesses. The re-

lation M.SCHEDULE contains information about the

schedule of movies shown in Lisbon. The relation

M.REMAKES keeps the years of movies for which

there is at least one remake. The relation M.RATING

stores the classiﬁcation of movies with regard to

suitability audience. Some non-self-explanatory at-

We use a path representation: an attribute A of a given

relation R in a given database schema D is referred to as

D.R.A. For simplicity, we omit the database schema when

the context is clear.

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment

tributes in M have the following meaning: descrip-

tion is the summary of a movie, genre is the cate-

gory of a movie, nvYear is the year of the most recent

version of a movie, ovYear is the year of the older

versions of a movie, rate is the classiﬁcation of the

movie with regard to the audience (M/4, M/6, etc. in

the Portuguese classiﬁcation), and quantity is the to-

tal of movies with the same rating.

Given the schemas S

, S

, and M, we can

consider the correspondences between the source

schemas S

and S

, and the target schema M. In a

ﬁrst example, we can state that M.SCHEDULE cor-

responds to S

.SHOWTIME, because both relations

store information regarding the same real world con-

cept. However, in this correspondence, it is not

clear that M.SCHEDULE only keeps schedules about

movies shown in Lisbon. The additional information:

M.SCHEDULE corresponds to S

.SHOWTIME when

.SHOWTIME.city = “Lisbon”, speciﬁes better the

matching.

As a second example, consider the attributes

.SHOWTIME.id and M.SCHEDULE.movie, which

uniquely identify a movie in the corresponding re-

lations. The domain of the former is an integer

(the identiﬁer of the movie id), while the domain of

the latter is a string (the title of the movie movie).

Since M.SCHEDULE corresponds to S

.SHOWTIME,

we need to relate M.SCHEDULE.movie to an element

of S

.SHOWTIME that identiﬁes a movie. However,

.SHOWTIME does not store the title of movies.

Moreover, S

.SHOWTIME.id, which is used to iden-

tify a movie in S

.SHOWTIME, has a type and

a domain different from the type and domain of

M.SCHEDULE.movie. Thus, S

.SHOWTIME.id and

M.SCHEDULE.movie cannot be matched. Knowing

that S

.SHOWTIME.id is a foreign key that refers

to S

.FILM and that S

.FILM.title stores the title

of a movie, the correct matching would then be:

M.SCHEDULE.movie corresponds to S

.FILM.title,

when S

.SHOWTIME.id = S

.FILM.id.

The works reported in (Pequeno and Pires, 2009;

Bohannon et al., 2006; Pequeno, 2011; Vidal and

L´oscio, 1999) and (Bellahsene et al., 2011)(chap. 3)

propose schema matching approaches that can spec-

ify correspondencesto deal with situations as required

in the ﬁrst example, while (Pequeno and Pires, 2009;

Pequeno, 2011; Vidal and L´oscio, 1999) propose cor-

respondences to deal with the matching required in

the second example. The reader can see other propos-

als to add semantics to schema matching in (Mass-

mann et al., 2011; Dhamankar et al., 2004; Magnani

et al., 2005). However, the following situations have

not been fully covered yet:

1. Correspondences Between Relations Involving a

Join with Inequality Conditions: Consider the

relation M.REMAKES that keeps a list of re-

makes with the years of the oldest versions.

Knowing that S

.FILM keeps current movies and

.MOVIE may contain older versions of the same

movie, we want to indicate which of the current

movies are remakes and store this information

in M.REMAKES. The correspondence between

these relations can be speciﬁed as: M.REMAKES

corresponds to S

.FILM join S

.MOVIE where

.FILM.title = S

.MOVIE.ﬁlm and S

.FILM.year

> S

.MOVIE.year. Usual schema matching ap-

proaches cannot specify this correspondence, be-

cause join conditions are not explicitly deﬁned

in schema matching. Moreover, join paths are

normally automatically discovered in the schema

mapping phase (Yan et al., 2001), and the algo-

rithms used can only ﬁnd equi-join conditions, so

they cannot automatically discover the condition

.FILM.year > S

.MOVIE.year. Hence, we need

a schema matching approach that makes it possi-

ble to specify the join between relations and al-

lows general join conditions containing operators

different from equality.

2. Correspondences Between Relations Involving

Outer-joins (Full, Left, or Right): We want to in-

dicate how M.MOVIE is related to source schemas

and S

.M.MOVIE and S

.FILM represent the

same concept of the real world (i.e., both rela-

tions store current movies shown at some cin-

ema). However, it is not enough to specify that

M.MOVIE matches S

.FILM, because there are at-

tributes in S

.MOVIE (namely, category and sum-

mary) that contain information required in the

schema of M.MOVIE. Hence, we should spec-

ify that M.MOVIE is related to both S

.MOVIE

and S

.FILM. However, it is not correct we

simply match M.MOVIE to S

.MOVIE because

.MOVIE can store movies that are not be-

ing shown in a cinema anymore and M.MOVIE

can store recent movies that are not available

in dvds yet. In summary, we should specify

that: M.MOVIE corresponds to S

.FILM left outer-

join S

.MOVIE on S

.FILM.title = S

.MOVIE.ﬁlm

and S

.FILM.year = S

.MOVIE.year. Note that

the condition S

.FILM.title = S

.MOVIE.ﬁlm and

.FILM.year = S

.MOVIE.year guarantees that

we refer to a same movie stored in both S

.MOVIE

and S

.FILM. Again, we cannot specify this

type of correspondence since joins (and their vari-

ants) are not explicitly deﬁned in current schema

matching approaches.

3. Correspondences Between Data and Meta-

data: Consider the relations S

.MOVIEMAKERS

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

and M.FILMMAKERS. Both keep informa-

tion about the relationship between a movie,

a producer, and a director. We want to in-

dicate that M.FILMMAKERS corresponds to

.MOVIEMAKERS since they represent the

same concept in the real world. In addition,

we want to specify the correspondences be-

tween the attributes of these relations. Knowing

that S

.MOVIEMAKERS.name can be a pro-

ducer name or a director name, we would

like to specify that M.FILMMAKERS.producer

corresponds to S

.MOVIEMAKERS.name

when S

.MOVIEMAKERS.role = “producer”

and that M.FILMMAKERS.director corre-

sponds to S

.MOVIEMAKERS.name when

.MOVIEMAKERS.role = “director”. However,

we cannot specify these correspondences using

traditional schema matching approaches, because

these correspondences involve semantics not cov-

ered yet by these approaches. Actually, we can

only specify that M.FILMMAKERS.producer

matches to S

.MOVIEMAKERS.name

and M.FILMMAKERS.director matches to

.MOVIEMAKERS.name.

In order to deal with these situations, we propose

to use a formalism based on CAs (Pequeno and Pires,

2009; Pequeno and Apar´ıcio, 2005; Pequeno, 2011).

Using CAs, we can declaratively specify basic and

complex matchings with semantics. We propose to

adapt CAs to be able to express schema matching be-

tween relational schemas, as well as to extend this

formalism with new types of CAs to deal with joins,

outer-joins, and data-metadata relationships. Finally,

we demonstrate how mapping expressions in the form

of SQL queries can be generated from CAs.

3 BACKGROUND

In this section, we present the basic terminology used

in this paper. We also review the different classes of

CAs, and adapt them to the Relational Data Model

(RDM)

3.1 Basic Concept and Notation

We assume that the reader is familiar with the re-

lational concepts. We denote a relation schema as

R(A

, A

, .. ., A

), and a foreign key as FK(R:L, S:K)

(see Section 2). We say that FK relates R and S.

In this work, the information sources and global

schemas are deﬁned using the RDM as proposed by Codd

in (Codd, 1970) that only allows ﬁrst normal form relations.

A relational schema is a pair S= (R , Ω), where R

is a set of relation schemas and Ω is a set of relational

constraints such that: (i) Ω has a unique primary key

for each relation schema in R ; (ii) if Ω has a foreign

key of the form FK(R:L, S: K), then Ω also has a con-

straint indicating that K is the primary key of S. Given

a relation schema R(A

, A

, ..., A

) and a tuple vari-

able t over R, we use t[A

] to denote the projection of

t over A

Let S= (R , Ω) be a relational schema and R and

T be relation names of relation schemas in R . We

denote ρ = FK

• FK

• · ··• FK

n−1

a path from R to

T iff there is a list R

, .. ., R

of relation schemas in

S such that R

= R, R

= T, and FK

relates R

and

i+1

. We say that tuples of R reference tuples of T

through ρ.

3.2 Correspondence Assertions

We use Correspondence Assertions (CAs) in order to

express schema matchings between schema elements.

CAs are formal expressions of the general form ψ:

T ← S , where ψ is the name of the CA, T is an ex-

pression formed by elements of the targetschema, and

S is an expression formed by elements of a source

schema. The symbol “←” means “is matched from”.

In accordance to (Pequeno and Pires, 2009; Pe-

queno, 2011), there are four types of CAs: Relation

Correspondence Assertion (RCA), Attribute Corre-

spondence Assertion (ACA), Summation Correspon-

dence Assertion (SCA), and Grouping Correspon-

dence Assertion (GCA). RCAs and SCAs specify

the relationship between relations of distinct schemas,

while ACAs and GCAs specify the relationship be-

tween attributes of relations of distinct schemas. We

now shortly describe each type of CA, adapting them

to the RDM. In the remainder of this Section, con-

sider: S

= (R

, Ω

) be relational schemas for 1 ≤ i ≤

n, with R

being relation names of relation schemas in

Deﬁnition 1. Let σ be a selection over R

. A Relation

Correspondence Assertion (RCA) is an expression of

one of the following forms:

1. ψ: S

] ← S

2. ψ: S

] ← S

σ].

3. ψ: S

] ← S

] − S

4. ψ: S

] ← S

] ∪ S

] ∪ ··· ∪ S

5. ψ: S

] ← S

] ∩ S

] ∩ ··· ∩ S

We say that ψ matches R

and R

, 2 ≤ j ≤ n. 

RCAs express the different kinds of semantic

equivalent relationships. Two relations R

and R

are

semantically equivalent if they represent the same real

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment

concept and there is a one-to-one correspondence be-

tween their instances. For instance, ψ

, shown in Fig-

ure 2, is an example of a RCA.

: M[SCHEDULE] ←S

[SHOWTIME(city = “Lisbon”)]

: M[SCHEDULE]•movie ←S

[SHOWTIME]• FK

/title

Figure 2: Examples of 1:1 correspondence assertions.

speciﬁes that M.SCHEDULE is semantically

equivalent to S

.SHOWTIME when the condition

.SHOWTIME.city = “Lisbon” is satisﬁed. This

means that only a subset of tuples of S

.SHOWTIME,

those that satisfy the condition S

.SHOWTIME.city =

“Lisbon”, are involved in the match.

Before we deﬁne an Attribute Correspondence

Assertion (ACA), we need introduce the concept of

attribute expression, as follows:

Deﬁnition 2. Let R

and T be relation names in R

with A being an attribute of R

and B an attribute

of T. Let also ρ be a path from R

to T. An attribute

expression E over R

is an expression with one of the

following forms:

1. S

] • A;

2. S

] • ρ/B. 

Deﬁnition 3. Let A

be attributes of R

(for 1 ≤ i ≤

n). Let also E

, for 1 ≤ j ≤ m, be attribute expres-

sions over R

. An Attribute Correspondence Asser-

tion (ACA) is an expression of one of the following

forms:

1. ψ: S

] • A

← E

2. ψ: S

] • A

← ϕ(E

,. .. , E

3. ψ: S

] • A

← (E

);. .. ;(E

); v.

4. ψ: S

](A

,. .. , A

) ← (E

,. .. , E

Where ϕ is a function over attributes of R

, p

(for

1 ≤ j ≤ m) are boolean conditions over attributes of

, and v is a value. We say that ψ matches R

and

. 

ACAs specify the relationship between the at-

tributes of relations that are matched by a RCA.

They allow to deﬁne 1:1, 1:n, n:1, or m:n rela-

tionships between attributes of relations of different

schemas. For example see the ACA ψ

presented

in Figure 2. It speciﬁes the correspondence between

M.SCHEDULE.movie and S

.FILM.title through a path

from SHOWTIME to FILM.

Deﬁnition 4. Let σ be a selection over R

. Let also

A’

attributes of R

(for 1 ≤ i ≤ m). A Summation

Correspondence Assertion (SCA) is an expression of

one of the following forms:

1. ψ: S

] ⇐ groupby(S

](A

′

,. .. , A

′

)).

2. ψ: S

] ⇐ groupby(S

σ](A

′

,. .. , A

′

)).

We say that ψ matches R

and R

. 

SCAs specify 1:n, n:1, m:n relationships between

relations with distinct schemas. Here we use the sym-

bol “⇐” instead of “←” in order to emphasize that

the correspondence is not 1:1 as is usual in the most

part of schema matching approaches. SCAs are used

to describe the summary of a relation whose tuples

are related to the tuples of another relation by gather-

ing them into logical groups. This means that a SCA

has only the necessary information to indicate which

grouping ﬁeld is involved in the relationship and the

process used to grouping the tuples. ψ

shown in Fig-

ure 3 is a simple example of a SCA.

: M[RATING] ⇐ groupby(S

[FILM](rate))

: M[RATING] • quantity ⇐ count(S

[FILM] • rate)

Figure 3: Examples of m:n correspondence assertions.

GCAs specify the relationship 1:1, 1:n, n:1, or m:n

between attributes of relations that are matched by a

SCA.

Deﬁnition 5. Let A be an attribute of R

. Let also

, for 1 ≤ i ≤ m, be attribute expressions over R

A Grouping Correspondence Assertion (GCA) is an

expression of one of the following forms:

1. ψ: S

] • A ⇐ E

2. ψ: S

] • A ⇐ ϕ(E

,. .. , E

3. ψ: S

] • A ⇐ (E

);. .. ;(E

); v.

4. ψ: S

] • A ⇐ γ(E

5. ψ: S

] • A ⇐ γ(ϕ(E

,. .. , E

)).

6. ψ: S

] • A ⇐ γ(E

,p).

7. ψ: S

] • A ⇐ γ(ϕ(E

,. .. , E

),p).

Where ϕ is a function over attributes of R

, p

(for

1 ≤ j ≤ m) are boolean conditions over attributes of

, v is a value, and γ is one of the aggregate func-

tions: sum (summation), max (maximum), min (mini-

mum), avg (average), or count. We say that ψ matches

and R

. 

Consider the relations S

.FILM and M.RATING.

, represented in Figure 3, speciﬁes that

M.RATING.quantity corresponds to the counting

of all distinct values of S

.FILM.rate.

Deﬁnition 6. Let S

, S

,. .. , S

and T be relational

schemas; R

be a relation schema of T, and R

a re-

lation schema of some S

, 1 ≤ i ≤ n. Let also E

(for

1 ≤ j ≤ m) be expressions with one of the following

forms: i) S

] • A

; or ii) S

] • ρ/A

, with A

being an attribute of R

, ρ a path from R

to R

, and

an attribute of R

. A schema matching between

schemas S

, S

, ..., S

and the schema T is a set M

of CAs such that:

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

1. if M has an ACA ψ such that ψ matches R

and

, then M has a RCA ψ

′

that matches R

and

2. if M has a GCA ψ such that ψ matches R

and

, then M has a SCA ψ

′

that matches R

and

3. if M has a RCA ψ such that ψ matches R

and R

then M has an ACA ψ

′

: S

](A

,. .. , A

) ←

,. .. ,E

) that matches R

and R

. 

4 SPECIFYING NEW CAs

In Section 1, we identiﬁed the following types of re-

lationships between schemas elements that are not

properly handled in current schema matching ap-

proaches: 1) matches involving explicit join con-

ditions; 2) matches involving outer-joins; and 3)

matches involving data-metadata. Join (and outer-

join) relationships can express one-to-one or many-

to-many correspondences between the relations in-

volved. Matches involving data-metadata can express

many-to-manycorrespondencesbetween the relations

involved. So, we extend our previous deﬁnitions of

RCA and SCA in order to better specify these types of

matchings. In the following text consider S

relational

schemas, R

relation schemes of S

(for 1 ≤ i ≤ 3), θ

a join condition between R

and R

, and A

attributes

of R

(for 1 ≤ j ≤ n)

Deﬁnition 7. A Relation Correspondence Assertion

(RCA) is an expression of one of the following forms:

1. Expressions as those presented in Deﬁnition 1.

2. ψ: S

] ← S

] ⊲⊳ S

]θ.

3. ψ: S

] ← S

] ⊐⊲⊳ S

]θ.

4. ψ: S

] ← S

] ⊲⊳⊏ S

]θ.

5. ψ: S

] ← S

] ⊐⊲⊳⊏ S

]θ.



Deﬁnition 8. A Summation Correspondence Asser-

tion (SCA) is an expression of one of the following

forms:

1. Expressions as those presented in Deﬁnition 4.

2. ψ: S

] ⇐ S

] ⊲⊳ S

]θ.

3. ψ: S

] ⇐ S

] ⊐⊲⊳ S

]θ.

4. ψ: S

] ⇐ S

] ⊲⊳⊏ S

]θ.

5. ψ: S

] ⇐ S

] ⊐⊲⊳⊏ S

]θ.

6. ψ: S

] ⇐ metadata(S

](A

,. .. ,A

)).



Consider the three examples about join, outer-

join, and data-metadata correspondences described in

Section 1. The correspondence between M.REMAKES

and both S

.MOVIES and S

.FILM can be speciﬁed

by the SCA ψ

shown in Figure 4. ψ

speci-

ﬁes that M.REMAKES corresponds to a join between

.MOVIES and S

.FILM where the join condition:

.FILM.title= S

.MOVIE.ﬁlm and S

.FILM.year >

.MOVIE.year is satisﬁed.

:M[REMAKES]⇐S

[FILM]⊲⊳S

[MOVIE](S

[FILM].title=

[MOVIE].ﬁlm and S

[FILM].year > S

[MOVIE].year )

:M[MOVIE]←S

[FILM]⊐⊲⊳S

[MOVIE](S

[FILM].title=

= S

[MOVIE].ﬁlm and S

[FILM].year = S

[MOVIE].year)

:M[FILMMAKERS] ⇐

⇐ metadata (S

[MOVIEMAKERS](id))

Figure 4: Examples of CAs involving joins, outer-joins and

data-metadata.

The correspondence between M.MOVIE and both

.FILM and S

.MOVIE can be speciﬁed by the RCA

, shown in Figure 4. ψ

speciﬁes that M.MOVIE

corresponds to a left outer-join between S

.FILM and

.MOVIE.

The correspondence between M.FILMMAKERS

and S

.MOVIEMAKERS can be speciﬁed by the

SCA ψ

, shown in Figure 4. ψ

speci-

ﬁes that M.FILMMAKERS corresponds to grouping

.MOVIEMAKERS by the attribute id, being that a

data-metadata translation should be performed (i.e.,

some data should be converted into metadata).

Once the schema matching is ﬁnished, the CAs

generated can be used, for example, to generate map-

ping expressions that convert data sources into data

target. We propose that the mapping expressions are

automatically generated in the form of SQL queries,

which are used to load the relations (the materialized

views) of the global schema.

5 FROM CAs TO MAPPING

EXPRESSIONS

In our proposal, the process to create queries to trans-

form data from a schema to another one consists of

three steps:

1. Indicate the source schemas and the global

schema using a high-leveldata model. In our case,

we use the RDM.

2. Deﬁne the CAs that formally specify the relation-

ships between the global schema and the source

schemas.

3. Generate a set of queries based on the CAs gener-

ated in step 2, in order to populate the relations of

the global schema.

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment

In order to illustrate our approach, consider the

global schema M and the sources schemas S

and S

shown in Figure 1.

Now, we should deﬁne CAs between M and S

and CAs between M and S

. In our work, the CAs are

speciﬁed using a GAV approach rather than a LAV

one. Our choice was due to two facts: 1) the GAV ap-

proach forces an exact association between the global

schema and the data sources (i.e., for each relation

and attribute of the global schema it should exists a

corresponding matching involving at least a relation

and an attribute of the source schemas); and 2) the

GAV approach makes the query answering easier than

LAV one, both in materialized and in virtual integra-

tion approaches.

The process to generate the CAs consists of the

following steps:

1. To each relation R

of the target T do:

(a) Identify the correspondences at a relation level

(i.e., if there is a RCA or a SCA matching a

target relation R

and some source relation R

(b) Identify the correspondences at an attribute

level: 1) identify the ACAs between the at-

tributesof R

and R

(if there is a RCA between

and R

); 2) identify the GCAs between the

attributes of R

and R

(if there is a SCA be-

tween R

and R

bined to form a single CA.

In the current work, CAs were manually speciﬁed.

However, we can use traditional schema matching

tools, such as COMA (Massmann et al., 2011) or OII

Harmony (Seligman et al., 2010; Mork et al., 2008),

as a starting point to ﬁnd basic matchings. Then these

basic matchings can be enriched through our formal-

ism (using the CAs).

Some examples of RCAs, ACAs, SCAs, and

GCAs between elements of M and the source schemas

and S

can be found in Figures 4 and 5. The ﬁnal

:M[MOVIE]•title ← S

[FILM]• title

:M[MOVIE]•year ← S

[FILM]• year

:M[MOVIE]•genre ← S

[MOVIE]• category

:M[MOVIE]•description←S

[MOVIE]• summary

:M[FILMMAKERS]•producer⇐(S

[MOVIEMAKERS]•

•nameS

[MOVIEMAKERS]• role = “producer”)

:M[FILMMAKERS]•director⇐(S

[MOVIEMAKERS]•

•name,S

[MOVIEMAKERS]• role = “director”)

:M[FILMMAKERS]• movie ⇐ S

[MOVIEMAKERS]•

•FK4/ﬁlm

Figure 5: Examples of ACAs and GCAs.

step in the process of creating queries to transform

data from a schema to another is the generation of the

queries. In our proposal, they are deﬁned based on

the deﬁnition of the schemas and the CAs. Here we

use SQL syntax of MySQL, since MySQL is an open

source database that allows to combine the informa-

tion from many databases in a single query. However,

our CAs can be used to generate queries in any SQL

syntax or even other federating queries languages as

SchemaSQL (Lakshmanan et al., 1996).

Let M be a set of CAs that deﬁnes a matching

between the source schemas S

, S

and the global

schema G, that is, M satisﬁes the conditions stated

in Deﬁnition 6. Algorithm 1 shows the procedure to

automatically generate the statements of SQL queries

from the CAs in M .

Algorithm 1: Generate the SQL query to load the relation

schemas of a global schema G.

for all relation schema R

in G do

N = R

; S =[ ]; J =[ ]; LA =[ ]; O =[ ]; RJ =[ ]; JAux =[ ]; Aux =[ ];

Let ψ

be a RCA or SCA of R

if ψ

is a RCA then G

SQL ACA( R

)

else

SQL GCA( R

)

end if

switch ψ

case ψ

: G[R

] ← S[R]

add [S.R as R] to S

if J = [ ] then

Use template T1 with parameters (N, Att(R

),LA, S)

else

Use template T3 with parameters (N, Att(R

), LA, S, J)

end if

case ψ

: G[R

] ← S

] ⊐⊲⊳ S

]θ

add [S

as R

] to S

add [S

as R

] to RJ

if J = [ ] then

Use template T5 with pars. (N, Att(R

),LA, S, RJ, θ)

else

Use template T6 with pars. (N, Att(R

), LA, S, RJ, θ, J)

end if

case ψ

: G[R

] ⇐ metadata(S[R](A))

add [S.R as R] to S

add [R.A as ID] to AL

if J = [ ] then

Use template T13 with parameters:

(N, Att(R

),LA, S, JAux, Aux)

else

Use template T4 with parameters:

(N, Att(R

), LA, S, JAux, Aux,J)

end if

end switch

end for

In Algorithm 1, we assume that N is a variable to

keep a relation name; S, J, LA, O, and RJ are lists

to keep, respectively, the relation schemas that will

be included in the FROM clause, the join conditions

that will be included in the WHERE clause, the at-

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

tributes that will be included in the SELECT clause,

the join attributes that will be included in the ON

clause, and the relation schema that will be included

in (inner, outer, left, or right) JOIN clause. JAux, and

Aux are lists used only when it is necessary to cre-

ate temporary tables in SQL. This occurs when the

SQL query is created from a SCA of metadata. JAux

stores the joins that will be included in the WHERE

clause of the temporary table, while Aux keeps the re-

lation schema that will be the alias of the temporary

table. Att() is a function that returns the list of at-

tribute names of a relation schema. We use the short

word outer join to emulate a UNION of a LEFT JOIN

and a RIGHT JOIN, since MySQL does not support

directly full outer-joins.

The algorithm 1 generates a set of SQL queries,

one for each relation schema R

in the global schema.

First it spans all ACAs and GCAs that relates at-

tributes of R

, and puts the correct value in lists

LA, S, J, in accordance to the type of the CA.

This is performed by procedures G

SQL ACA() and

G SQL GCA() shown, respectively, in Algorithms 2

and 3 . After, the algorithm spans the RCAs, or SCAs,

of R

, in order to create the SQL query to load R

using templates in Table 1. Due to space limitations,

Algorithms 1, 2, and 3, as well as the Table 1, do not

cover the whole set of CAs as deﬁned in Deﬁnitions 3,

5, 7, and 8.

Algorithm 2: G SQL ACA().

Input: R

for all attribute A

in R

Let ψ

be an ACA of A

if ψ

: G[R

] • A

← S[R] •A

then

add [R.A

as A

] to LA

end if

if ψ

: G[R

] • A

← (S[R] • A

);... ;(S[R] • A

);v then

add [case when p

then R.A

when p

then ... else v end ‘A

’]

to LA

end if

end for

In Algorithms 2 and 3, we assumed that ϕ() is

a pre-deﬁned SQL function or a user-deﬁned func-

tion on SQL. The symbol v indicates a value (integer,

string, ﬂoat, etc.), and p

, .. ., p

are boolean condi-

tions.

The SQL queries generated by our algorithms can

be used to compute the data target once, and to recom-

pute them at pre-stablished times in order to maintain

the target data up-to-date (this approach is named re-

materialization). Generally, a more efﬁcient approach

is to periodically modify only part of the target data to

reﬂect updates in data sources (this approach is named

incremental maintenance). Rematerialization is ade-

Algorithm 3: G SQL GCA( ).

Input: R

for all attribute A

in R

Let ψ

be an GCA of A

and ψ

be a SCA of A

if ψ

: G[R

] • A

← S[R] •A

then

add [R.A

as A

] to LA

end if

if ψ

: G[R

] • A

← S[R] •ρ/B

then

for all FK in ρ do

Let R

and R

be relation schemas related by FK

Let [a

,.. . ,a

] be the list of key attributes of R

Let [b

,.. . ,b

] be the list of key attributes of R

add [S.R

as R

, S.R

as R

] to S

add [R

= R

, ... , R

= R

] to J

add [R

.B as A

] to LA

end for

end if

if ψ

:G[R

] • A

← (S[R] • A

) and ψ

is of metadata then

add [R.A

as A

] to LA

add [T

R] to Aux

add [p

] to JAux

end if

end for

quate, for example, when the global schema is ﬁrstly

populated, or in situations involving complex opera-

tions.

Figure 6 presents the SQL query to transform data

from S

.MOVIE and S

.FILM to M.MOVIE from the

RCA ψ

and ACAs ψ

,ψ

, and ψ

. The “se-

lect” clause (in line 2) is derived based on ACAs ψ

, ψ

and ψ

. The “from” clause (in line 3) imple-

ments a join operation as speciﬁed by RCA ψ

. The

“on” clause (in line 4) is based on the join condition

indicated in the end of ψ

MOVIE

01. insert into M.MOVIE(title,year,genre,description)

02. select FILM.title as title, FILM.year as year, MOVIE.category as genre,

MOVIE.summary as description

03. from S

.FILM as FILM left join S

.MOVIE as MOVIE

04. on FILM.title = MOVIE.ﬁlm and FILM.year = MOVIE.year;

Figure 6: Query deﬁnition to populate M.MOVIE from

.FILM and S

.MOVIE.

Figure 7 presents the deﬁnition of the query

to transform data from S

.MOVIEMAKERS to

M.FILMMAKERS. For this query, we have to deﬁne

a nested select statement to each case-base GCA that

relates attributes of S

.MOVIEMAKERS to attributes

of M.FILMMAKERS. Each nested select statement

must be joined through an outer-join in order to guar-

antee both: i) that duplicate tuples will be merged

properly, and 2) not duplicate tuples will be stored

in M.FILMMAKERS. Thus, the clauses “from” (line

3), “outer join” (line 7), and “on” (line 12) correctly

implement the data-metadata relationship speciﬁed by

the SCA ψ

. The “on” clause (line 12) is based on the

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment

Table 1: Templates to generate SQL Statements induced by RCAs and ACAs.

T1 insert into N (ATT[1], ATT[2], ... , ATT[n])

ψ: S

] ← S

]select LA[1], LA[2], ... , LA[n] from S[1]

T3 insert into N (ATT[1], ATT[2], ... , ATT[n])

ψ: S

] ← S

]

select LA[1], LA[2], ... , LA[n]

from S[1], S[2], ... , S[m]

where J[1] and J[2] and .. . and J[t]

T5 insert into N (ATT[1], ATT[2], ... , ATT[n])

ψ: S

] ← S

] ⊐⊲⊳ S

]θ

select LA[1], LA[2], ... , LA[n]

from S[1], S[2], ... , S[m]

left join RJ[1] on θ

T6 insert into N (ATT[1], ATT[2], ... , ATT[n])

ψ: S

] ← S

] ⊐⊲⊳ S

]θselect LA[1], LA[2], ... , LA[n]

ψ: S

] ← S

] − S

]from S[1], S[2], ... , S[m]

left join RJ[1] on θ

where J[1] and J[2] and .. . and J[t]

T13 insert into N (ATT[1], ATT[2], . .., ATT[n])

ψ: S

] ⇐ metadata(S

](A

)

select ATT[1], ATT[2], . .., A TT[n]

from (select LA[1], LA[2], .. ., LA[w]

from S[1]

where JAux[1] ) as Aux[1])

outer join (select LA[1], LA[2], ... , LA[w]

from S[1]

where JAux[2] ) as Aux[2])

on (Aux[1].ID = Aux[2].ID)

T14 insert into N (ATT[1], ATT[2], . .., ATT[n])

ψ: S

] ⇐ metadata(S

](A

)

select ATT[1], ATT[2], . .., A TT[n]

from

(select LA[1], LA[2], ... , LA[w]

from S[1], S[2], ... , S[m]

where J[1] and . . . and J[t] and JAux[1] ) as Aux[1])

outer join

(select LA[1], LA[2], ... , LA[w]

from S[1], S[2], ... , S[m]

where J[1] and . . . and J[t] and JAux[2] ) as Aux[2])

on (Aux[1].ID = Aux[2].ID)

FILMMAKERS

01. insert into M.FILMMAKERS(movie, producer, director)

02. select movie, producer, director

03. from

04. (select MOVIE.ﬁlm as movie,MOVIEMAKERS.name as producer,

MOVIEMAKERS.id as ID

05. from S

.MOVIEMAKERS as MOVIEMAKERS, S

.MOVIE as MOVIE

06. where MOVIEMAKERS.id=MOVIE.id

and MOVIEMAKERS.role = ‘producer’) as T1

MOVIEMAKERS

07. outer join

08. (select MOVIE.ﬁlm as movie,MOVIEMAKERS.name as director,

MOVIEMAKERS.id as ID

09. from S

.MOVIEMAKERS as MOVIEMAKERS, S

.MOVIE as MOVIE

10. where MOVIEMAKERS.id=MOVIE.id

11. and MOVIEMAKERS.role = ‘director’) as T2

MOVIEMAKERS

12. on (T1

MOVIEMAKERS.ID = T2 MOVIEMAKERS.ID);

Figure 7: Query deﬁnition to populate M.FILMMAKERS

from S

.MOVIEMAKERS.

attribute indicated in ψ

. The ﬁrst nested select state-

ment (lines 4 to 6) is deﬁned based on the GCAs ψ

and ψ

. The second nested select statement (lines 8

to 11) is similar to the ﬁrst one, but now it is based on

and ψ

. The “select” clause in line 2 is based on

the left-hand side of GCAs ψ

, ψ

and ψ

6 RELATED WORK

Schema matching is an important step of the data in-

tegration process (Filho et al., 2010). Typically, 1:1

correspondences between two different schemas are

manually deﬁned using a GUI or are (semi-) auto-

matically discovered using matchers (usually through

heuristics). Each correspondence, in general, only

speciﬁes which elements refer to a same attribute or

relation in the real world (Doan et al., 2012). Cu-

pid (Madhavan et al., 2001), AgreementMaker (Cruz

et al., 2009), and OII Harmony (Seligman et al., 2010;

Mork et al., 2008) are some examples of tools for

schema matching. Cupid (Madhavan et al., 2001) is

a generic schema matching that only consider schema

information to generate the correspondences. Agree-

mentMaker (Cruz et al., 2009) can match schemas

and ontologies using schema information as well as

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

instance-level data to generate the correspondences.

OII Harmony (Seligman et al., 2010; Mork et al.,

2008) supports XML schemas, Entity-Relationship

schemas, and relational schemas. It combines mul-

tiple matchers algorithms, each of which identiﬁes

correspondences using a different strategy, in order to

generate correspondences with high quality matching

between attributes of the compared schemas. (Bellah-

sene et al., 2011)(chap. 1) provides a brief compari-

son of some matching tools, while (Bellahsene et al.,

2011)(chap. 9) presents, in a systematic way, some

metrics to evaluate matching and mapping tools.

Correspondences such as those deﬁned/generated

in (Cruz et al., 2009; Seligman et al., 2010; Mork

et al., 2008; Madhavan et al., 2001) do not pro-

vide the necessary information for discovering ex-

pressions to transform data sources in data target

(i.e., the mapping expressions), the next phase in the

schema mapping process. Richer models for specify-

ing correspondencesbetween schemas were proposed

by (Doan, 2002; Massmann et al., 2011; Bohannon

et al., 2006; Vidal and L´oscio, 1999; Dhamankar

et al., 2004; Magnani et al., 2005; Giunchiglia et al.,

2005) and (Bellahsene et al., 2011)(chap. 3). These

approaches allowto deﬁne one-to-one or many-to-one

attribute correspondences (i.e., association between

attributes of two schemas). (Doan, 2002; Dhamankar

et al., 2004) allow to semi-automatically match one

attribute to various attributes (e.g., totalPrice matches

to unitPrice*quantity), incorporating machine learn-

ing, statistics, and heuristics to evaluate candidate

matches. COMA and COMA++ (Massmann et al.,

2011) are generic prototypes for schema and on-

tology matching, schema-based and instance-based,

and support a semi-automatic or manual enrichment

of simple 1:1 correspondences into more complex

mapping expressions including functions to support

data transformations. (Dhamankar et al., 2004) de-

scribes the IMAP system, which semi-automatically

discovers basic and complex matches. Each match

in (Dhamankar et al., 2004) discovers speciﬁc types

of complex matches, using different kinds of informa-

tion such as domain knowledge, and domain integrity

constraints to improve matching accuracy. (Bellah-

sene et al., 2011)(chap. 3) and (Bohannon et al.,

2006) allow to express conditional correspondences

(i.e., the value of an attribute A is the same of an at-

tribute B if a given condition is satisﬁed).

(Giunchiglia et al., 2005) and (Magnani et al.,

2005) set correspondences with semantic relation-

ships, such as equivalence, containment, subsump-

tion, disjointness, and unknown (a special relation-

ship returned by the matching algorithm when none

of the others relationships hold). More closely to

our approach is the work in (Vidal and L´oscio, 1999)

and (Vidal et al., 2013). In (Vidal and L´oscio, 1999),

the authors allow to manually specify one-to-one cor-

respondence assertions between elements of Entity

Relationship models. Although they cannot specify

many-to-many matches, their correspondences have

some semantic and allow to specify relationships such

as: equivalence, union, intersection, and ﬁltering

(there named selection). In (Vidal et al., 2013), the

authors allow to specify correspondences between re-

lational schemas and RDF schemas, but they are ba-

sically 1-to-1 correspondences referring to project-

selection-equijoin queries. The unique 1:m corre-

spondence that they deal with relates one attribute to

various attributes through concatenation.

(Pequeno and Pires, 2009; Pequeno, 2011) spec-

ify one-to-one and many-to-many basic, complex,

and semantic matches between elements of object-

relational schemas. They can specify most part of

the correspondences speciﬁed in (Vidal and L´oscio,

1999) and other more complex. For example, they

can deal with aggregate functions, denormalisations,

and grouping (i.e., group by in SQL). Joins and outer-

joins are implicitly deﬁned based on the integrity con-

straints or match functions

. A distinguished fea-

ture of the approach proposed in (Pequeno and Pires,

2009; Pequeno, 2011) is that it allows to match, in the

same correspondence, relations and attributes of two

or more schemas. Yet, the information they provide is

not sufﬁcient, since they do not explicitly enable the

speciﬁcation of join paths and its variants, nor to deal

with data-metadata relationships.

Data-metadata translations between elements of

different relational schemas have been studied ex-

tensively. SchemaSQL (Lakshmanan et al., 1996)

and FIRA/FISQL (Wyss and Robertson, 2005)

are the most notable works on this subject.

SchemaSQL (Lakshmanan et al., 1996) is a SQL-

like metadata query language that uses view state-

ments to restructure one column of values of a rela-

tion into metadata in another one. FISQL (Wyss and

Robertson, 2005) is a sucessor of SchemaSQL. It is

a query language that expresses data-metadata trans-

formations using metavariables that range over rela-

tion names and column names. In addition, FISQL is

equivalent to the query algebra FIRA. FIRA, in addi-

tion to the usual relational operators, deﬁnes simple

operators for data-metadata querying such as: “↑” to

promote metadata, “↓” to demote metadata, and “→”

to dereference data. Furthermore, FIRA/FISQL are

capable of producing fully dynamic output schemas,

Match functions are functions that determine if two

different instances represent the same concept in the real

world.

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment

where the exact name of the relation schema or the

attribute name is only known at run-time. Both

SchemaSQL and FIRA/FISQL were proposed to pro-

vide interoperability in relational multi-database sys-

tems. Our new SCA of metadata was based on the

promote metadata operator of FIRA.

In other proposals, such as those in (Haas et al.,

2005; Bonifati et al., 2008), correspondences are

basic matching (although sometimes they allow to

specify selection conditions and combination of at-

tributes) and the aim is automatically generate map-

ping expressions from the correspondences. Both

Clio in (Haas et al., 2005) and Spicy in (Bonifati et al.,

2008) deﬁne mapping expressions as logical formu-

las (tuple-generated dependences - tgds, and equality-

generated dependences - egds). A drawback of ap-

proaches that create tgds automatically, as in (Haas

et al., 2005) and (Bonifati et al., 2008), is that tgds

do not deal with, for example, groupings, aggrega-

tions, many-to-many attribute correspondences, and

data-metadata transformations. In addition, the qual-

ity of the mapping generated depends on the quality

of the correspondences.

Clip (Rafﬁo et al., 2008) (an extension of Clio) and

++Spicy (Marnette et al., 2011) (an extension of

spicy) proposed extensions to tgds, named nested

tgds, in order to be used in hierarchical data (i.e.,

XML instances). Their proposal enables to generate

mappings between relational and XML schemas and

allow to express grouping, aggregation and many-to-

many attribute correspondences. Yet, they do not deal

with data-metadata relationships, nor specify the con-

dition that can be used for combining relations as well

as join variants (e.g., right outer join and left outer

join). Mad mapping (Papotti and Torlone, 2009) is an

extension of Clio that deals with data-metadata rela-

tionships. Its approach is similar to the SchemaSQL

approach (Lakshmanan et al., 1996), and, in some as-

pects to the FISQL. Since the correspondences used

as input do not provide the necessary information

for deriving the mappings that encode the semantic

desired by the user, the solution proposed in (Raf-

ﬁo et al., 2008), (Marnette et al., 2011) and (Papotti

and Torlone, 2009) can generate mapping expressions

which populate a target relation with duplicate infor-

mation. In our proposal, we specify correspondences

that provide information that is sufﬁcient for deter-

mining and deriving the desired schema mappings. In

addition, differently from most approaches of schema

matching and schema mapping, CAs allow to specify,

in a same correspondence, the relationships between

several source schemas and one target schema. This

contributes to reduce the number of duplicate infor-

mation in the target schema.

7 CONCLUSION

This paper focused on present Correspondence As-

sertions (CAs) that deal with 1:1 and m:n matchings

between schemas components, including correspon-

dences involving aggregations, joins, and metadata.

We emphasize that, in our approach, the CAs can

specify basic and complex correspondences with se-

mantics. Using CAs, we shown how SQL queries

can be automatically generated to populate relations

(views) of a global schema.

Our CAs were described using a GAV approach,

rather than a LAV one. GAV approach has the advan-

tage of making the query answering easier, since there

is an exact association between the global schema and

the data sources. However, GAV-based systems do

not facilitate the addition of a new data source to the

system. When a new data source is added or changed,

the designer must modify the corresponding match-

ings/mappings. The semantically rich and formal rep-

resentation of our Correspondence Assertions (CAs)

enable to generate mapping expressions that are easy

to reuse and maintain when some change occurs in a

schema deﬁnition.

We are currently working on the development of a

mechanism to discover new CAs from previous ones

using inferences and heuristics. This mechanism in-

tends to help the designer in the deﬁnition of new

CAs, given insights and suggestions in an interactive

way.

ACKNOWLEDGEMENTS

This work was partially supported by national funds

through FCT - Fundac¸˜ao para a Ciˆencia e a Tecnolo-

gia, under the project PEst-OE/EEI/LA0021/2013

and the grant SFRH/BPD/76024/2011. We are espe-

cially grateful to Vania Vidal (UFC, Brazil) and Jo˜ao

Moura Pires (UNL, Portugal) for valuable discussion

and comments.

REFERENCES

Bellahsene, Z., Bonifati, A., and Rahm, E., editors (2011).

Schema Matching and Mapping. Data-Centric Sys-

tems and Applications. Springer.

Bohannon, P., Elnahrawy, E., Fan, W., and Flaster, M.

(2006). Putting context into schema matching. In

VLDB, pages 307–318.

Bonifati, A., Mecca, G., Pappalardo, A., Raunich, S., and

Summa, G. (2008). Schema mapping veriﬁcation: the

spicy way. In EDBT’08, 11th Intl. Conf. on Extending

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

Database Technology: Advances in Database Tech-

nology, pages 85–96. ACM.

Codd, E. F. (1970). A relational model of data for large

shared data banks. Communications of the ACM,

13(6):377–387.

Cruz, I. F., Antonelli, F. P., and Stroe, C. (2009). Agree-

mentmaker: Efﬁcient matching for large real-world

schemas and ontologies. Proc. VLDB Endow.,

2(2):1586–1589.

Dhamankar, R., Lee, Y., Doan, A., Halevy, A. Y., and

Domingos, P. (2004). IMAP: Discovering complex

mappings between database schemas. In ACM SIG-

MOD, pages 383–394.

Doan, A. (2002). Learning to Map between Structured Rep-

resentations of Data. PhD thesis, University of Wash-

ington.

Doan, A., Halevy, A., and Ives, Z. (2012). Principles of

Data Integration. Morgan Kaufmann.

Filho, F., L´oscio, B., and Macˆedo, J. A. (2010). Gerac¸˜ao

incremental de correspondˆencias e mapeamentos en-

tre ontologias. In X Workshop de Teses e Dissertac¸˜oes

em Banco de Dados.

Giunchiglia, F., Shvaiko, P., Yatskevich, M., Giunchiglia,

F., Shvaiko, P., and Yatskevich, M. (2005). Seman-

tic schema matching. In On the Move to Meaningful

Internet Systems: CoopIS, DOA, and ODBASE, pages

347–365.

Haas, L. M., Hern´andez, M. A., Ho, H., Popa, L., and Roth,

M. (2005). Clio grows up: from research prototype to

industrial tool. In ACM SIGMOD, pages 805–810.

Kimball, R., Ross, M., Thornthwaite, W., Mundy, J., and

Becker, B. (2008). The Data Warehouse Lifecycle

Tookit. Wiley Publishing, 2nd edition.

Lakshmanan, L. V. S., Sadri, F., and Subramanian, I. N.

(1996). SchemaSQL - a language for interoperability

in relational multi-database systems. In VLDB, pages

239–250. Morgan Kaufmann Publishers Inc.

Langegger, A., W¨oß, W., and Bl¨ochl, M. (2008). A Se-

mantic Web Middleware for Virtual Data Integration

on the Web, volume The Semantic Web: Research and

Applications 5021 of Lecture Notes in Computer Sci-

ence, pages 493–507. Springer.

Madhavan, J., Bernstein, P. A., and Rahm, E. (2001).

Generic schema matching with cupid. In VLDB, pages

49–58. Morgan Kaufmann Publishers Inc.

Magnani, M., Rizopoulos, N., Mc.Brien, P., and Montesi,

D. (2005). Schema integration based on uncertain se-

mantic mappings. In ER 2005, Conceptual Modeling,

volume 3716 of Lecture Notes in Computer Science,

pages 31–46. Springer Berlin / Heidelberg.

Marnette, B., Mecca, G., Papotti, P., Raunich, S., and

Santoro, D. (2011). ++spicy: an opensource tool

for second-generation schema mapping and data ex-

change. Proc. VLDB Endow., 4(12):1438–1441.

Massmann, S., Raunich, S., Aumueller, D., Arnold, P., and

Rahm, E. (2011). Evolution of the COMA match sys-

tem. In The 6th Intl. Workshop on Ontology Matching.

Mork, P., Seligman, L., Rosenthal, A., Korb, J., and Wolf,

C. (2008). The Harmony integration workbench. J.

Data Semantics, 11:65–93.

Papotti, P. and Torlone, R. (2009). Schema exchange:

Generic mappings for transforming data and meta-

data. Data Knowl. Eng., 68(7):665–682.

Pequeno, V. M. (2011). Using Perspective Schema and a

Reference Model to Design the ETL Process. PhD the-

sis, Universidade Nova de Lisboa.

Pequeno, V. M. and Apar´ıcio, J. N. (2005). Using corre-

spondence assertions to specify the semantics of views

in an object-relational data warehouse. In ICEIS’05,

7th Enterprise Information Systems, pages 219–225.

Pequeno, V. M. and Pires, J. C. M. (2009). Using per-

spective schemata to model the ETL process. In

ICMIS’09, Intl. Conf. on Management Information

Systems, pages 332–339. World Academy of Science,

Engineering and Technology.

Popﬁnger, C. (2006). Enhanced Active Databases for Fed-

erated Information Systems. PhD thesis, Heinrich

Heine University D¨usseldorf.

Rafﬁo, A., Braga, D., Ceri, S., Papotti, P., and Hernandez,

M. (2008). Clip: a visual language for explicit schema

mappings. In ICDE’08, Intl. Conf. on Data Engineer-

ing, pages 30–39. IEEE.

Rahm, E. and Bernstein, P. A. (2001). A survey of ap-

proaches to automatic schema matching. The VLDB

Journal, 10(4):334–350.

Seligman, L., Mork, P., Halevy, A., Smith, K., Carey, M. J.,

Chen, K., Wolf, C., Madhavan, J., Kannan, A., and

Burdick, D. (2010). OpenII: an open source infor-

mation integration toolkit. In ACM SIGMOD, pages

1057–1060.

Shvaiko, P. and Euzenat, J. (2005). A survey of schema-

based matching approaches. Journal on Data Seman-

tics IV, 3730:146–171.

Vidal, V. M. P., Casanova, M. A., and Cardoso, D. S. (2013).

Incremental maintenance of RDF views of relational

data. In ODBASE’13, 12th Intl. Conf. on Ontologies,

DataBases, and Applications of Semantics.

Vidal, V. M. P. and L´oscio, B. F. (1999). Updating multiple

databases through mediators. In ICEIS’99, Intl. Conf.

on Enterprise Information Systems, pages 163–170.

Wyss, C. M. and Robertson, E. L. (2005). Relational

languages for metadata integration. ACM Trans.

Database Syst., 30:624–660.

Yan, L. L., Miller, R. J., Haas, L. M., and Fagin, R. (2001).

Data-driven understanding and reﬁnement of schema

mappings. In ACM SIGMOD, pages 485–496. ACM.

SpecifyingComplexCorrespondencesBetweenRelationalSchemasinaDataIntegrationEnvironment
