A User Data Location Control Model for Cloud Services

Kaniz Fatema

, Philip D. Healy

, Vincent C. Emeakaroha

, John P. Morrison

and Theo Lynn

Irish Centre for Cloud Computing & Commerce, University College Cork, Cork, Ireland

Irish Centre for Cloud Computing & Commerce, Dublin City University, Dublin, Ireland

Keywords:

Authorization System, Access Control, Data Location, XACML, Cloud Computing.

Abstract:

A data location control model for Cloud services is presented that uses an authorization system as its core

control element. The model is intended for use by enterprises that collect personal data from end users that can

potentially be stored and processed at multiple geographic locations. By adhering to the model’s authorization

decisions, the enterprise can address end users’ concerns about the location of their data by incorporating their

preferences about the location of their personal data into an authorization policy. The model also ensures

that the end users have visibility into the location of their data and are informed when the location of their

data changes. A prototype of the model has been implemented that provides the data owner with an interface

that allows their location preferences to be expressed. These preferences are stored internally as XACML

policy documents. Thereafter, movements or remote duplications of the data must be authorized by submitting

requests to an ISO/IEC 10181-3:1996 compliant policy enforcement point. End users can, at any time, view

up-to-date information on the locations where their data is stored via a web interface. Furthermore, XACML

obligations are used to ensure that end users are informed whenever the location of their data changes.

1 INTRODUCTION

Cloud Computing offers a new style of computing

that allows consumers to pay only for the services

used and frees them from the management overhead

of the underlying infrastructure. Although Cloud

Computing has gained signiﬁcant traction in recent

years, surveys have consistently shown that con-

sumers’ concerns around security and loss of con-

trol over data are hindering adoption (Subashini and

Kavitha, 2011; Chen and Zhao, 2012). Additionally,

the physical location of data can have an impact on its

vulnerability to disclosure and can have implications

for service quality and legal consequences (Albeshri

et al., 2012; Gondree and Peterson, 2013). Many reg-

ulations such as HIPAA and the EU Data Protection

Directive impose restrictions on the movement of data

between geographical locations. Data location there-

fore represents a sensitive issue for enterprises that

offer cloud services. Existing and potential customers

seek assurance that the enterprise will act as faithful

stewards of information entrusted to them, and the en-

terprise itself wishes to avoid falling foul of data pro-

tection rules and other regulations.

However, these concerns must be balanced against

the enterprise’s desire to maintain redundancy and op-

erational efﬁciency. There are a number of valid rea-

sons for copying data to geographically dispersed lo-

cations. These may include:

• Risk Mitigation Copying data to more than one

physical location provides a hedge against lo-

calised catastrophic events such as ﬁres and nat-

ural disasters.

• Operational Expenditure Due to the geographi-

cally variable nature of overheads, such as energy

costs, it may be cheaper to store and/or process

data at a location other than where it was stored

originally.

• Storage Capacity If a data centre has limited ca-

pacity it might be helpful to ofﬂoad some storage

to another location.

• Maintenance Data may sometimes need to be

moved temporarily in order to facilitate data cen-

tre maintenance, upgrade or relocation.

• Localised Caching Content delivery networks,

such as Akamai and Amazon CloudFront, repli-

cate data to edge servers in order to improveusers’

quality of experience.

Enterprises that offer Cloud services must therefore

balance the beneﬁts of migrating data against con-

cerns relating to trustworthiness in the eyes of users

and regulatory compliance.

476

Fatema K., Healy P., C. Emeakaroha V., P. Morrison J. and Lynn T..

A User Data Location Control Model for Cloud Services.

DOI: 10.5220/0004855404760488

In Proceedings of the 4th International Conference on Cloud Computing and Services Science (CLOSER-2014), pages 476-488

ISBN: 978-989-758-019-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Users’ concerns about how their data is dissem-

inated and used can be addressed by allowing them

to specify policies about how they wish their data to

be used and assuring them of the enforcement of this

policy. In the context of data location, this assurance

can be provided in two ways (a) with a transparency

mechanism that allows users to view the locations

where their data is being stored and (b) with a noti-

ﬁcation mechanism that informs them when there is a

change to the status quo. If the users’ policies are to

carry any weight then they must be consulted before

operations are performed that would result in move-

ment or remote duplication so that violations can be

avoided.

A means of addressing this challenge is to imple-

ment an authorization system that inputs queries re-

lating to data relocation and returns results that in-

dicate the permissibility of the proposed actions. Of

course, such a system is of little value unless it is ap-

propriately integrated into the service provider’s in-

ternal processes and mechanisms. As such, there is

a residual trustworthiness issue in that the users must

trust that this integration has taken place and that the

decisions of the authorization system are being hon-

oured. These issues could be addressed through inde-

pendent veriﬁcation mechanisms such as trustmarks,

audits and assurance services (Lynn et al., 2013).

Although the basic concept of an authorization

system (di Vimercati et al., 2005; ISO, 1996) is to pro-

tect access to secured resources, the functionality of

existing authorization systems can be extended to per-

form other operations such as enforcing obligations

(Park and Sandhu, 2004; Demchenko et al., 2008) and

verifying credentials (Chadwick et al., 2008). In this

paper, we propose a Cloud data location assurance

control model that is based on authorization systems.

The ISO/IEC 10181-3:1996 standard access control

framework is used as the technological foundation.

The following issues are addressed:

1. Capturing users’ location preferences as policies

that can be automatically consulted

2. Providing an authorization mechanism for data

movement decisions that takes user-speciﬁc poli-

cies into account

3. Providing users with visibility into the location of

their data

4. Ensuring that users are informed when the loca-

tion of their data changes

The remainder of this paper is organized as fol-

lows: Section 2 presents an analysis of related work.

Section 3 provides background information on autho-

rization systems, XACML policies and their evalua-

tion process and how they can play a role in Cloud

data management. Section 4 presents the design of

the proposed location control model while Section 5

provides some technical details along with the result

of validation tests. Finally, Section 6 concludes the

paper and suggests future research directions.

2 RELATED WORK

Geolocation is a technique that can be used post

facto to determine where data is being served from,

and hence whether the data is being hosted from an

undesirable location. Most Geolocation techniques

make use of network latency as a proxy for distance

(Katz-Bassett et al., 2006). The techniques include:

geo ping, in which a server is pinged from a num-

ber of landmarks to identify how close the server is

to each landmark and hence determine the location;

constraint-based geolocation, which uses a triangula-

tion technique to determine the position of a server

that is possibly between landmarks; and topology-

based geolocation, which considers trace route, topol-

ogy and per hop latency. These techniques are used to

estimate the geolocation of a Cloud data centre based

on network latency and comparing it using heuristics

to expected latencies from known distances (Benson

et al., 2011; Ries et al., 2011; Peterson et al., 2011).

Ries et al. proposed a geolocation approach based on

network coordinate systems to identify location pol-

icy violations (Ries et al., 2011). They found the ac-

curacy of the geolocation-basedapproachesto be only

52% at best. Albeshri et al. proposed an architec-

ture for data geolocation based on a Proof of Storage

(POS) protocol and timing-based distance bounding

protocol (Albeshri et al., 2012). The POS protocol

is used to provide proof to the client that the server

is holding the data and that it has not been modiﬁed.

The delay in response is used to determine the proba-

ble location of the data. A similar approach has been

proposed (Peterson et al., 2011; Gondree and Peter-

son, 2013) that uses a challenge-response protocol

based provable data possession technique combined

with a geolocation-based solution. However, deter-

mining the location of data based on response time

has been shown to be inaccurate (Ries et al., 2011).

Given the inaccuracy and post facto nature of geolo-

cation techniques, we decided against using this ap-

proach for our purposes. However, geolocation could

have a role as an independent audit mechanism for

conﬁrming that users’ location preferences are being

honoured.

The Data Location Assurance Service proposed

by Noman et al. is based on an approach where the

Cloud service provider sends regular updates to en-

AUserDataLocationControlModelforCloudServices

477

terprises about the location of their data (Noman and

Adams, 2012). The enterprise in turn provides loca-

tion assurance to users by providing information on

whether the data are in their preferred location in a

simple yes/no format. This approach relies heavily

on the trustworthiness of the Cloud service provider.

Massonet et al. describe how negotiation can be used

to integrate service providers’ policies with those of

infrastructure providers in a federated Cloud envi-

ronment (Massonet et al., 2011). The infrastucture

provider’s security policy states the availability of

logging facilies, logging type and monitoring, while

the servuce provider’s policy states its security re-

quirements. A virtual machine is migrated to a site

only if its security policy matches with the security

requirements of the service provider. An audit log

is created from the collaboration of between service

provider and infrastructure provider. The location of

data is identiﬁed through the presence of data centre’s

certiﬁcate in the audit log. Neither of these systems

allow for detailed location preferences, such as multi-

ple preferred geographic regions, to be collected from

end users and enforced automatically.

Numerous implementations of policy-based au-

thorization have been proposed in order to protect ac-

cess to sensitive data in the Cloud (Iskander et al.,

2011; Basescu et al., 2011; Chadwick and Fatema,

2012). A distributed authorization system architec-

ture for Cloud services was proposed by Almutairi

et al. where each Cloud layer has a virtual resource

manager that protects access to the virtualized re-

sources of its layer using an access control mod-

ule (Almutairi et al., 2012). Ries et al. proposed a

policy-based approach to location issues (Ries et al.,

2011). However, they did not elaborate on how to in-

corporate location into policy or how to enforce poli-

cies.

A number of policy languages – such as P3P

(Cranor, 2003), EPAL (Ashley et al., 2003), PER-

MIS (Chadwick et al., 2008), FlexDDPL (Spill-

ner and Schill, 2012) and XACML (Godik et al.,

2002) – have become available for various purposes.

P3P (Cranor, 2003) deﬁnes a machine interpretable

format for websites to express their privacy practices.

The notice and consent model of P3P allows web-

sites to describe their privacy policies and users can

read these policies and can choose to interact with the

websites and thus provide their consent to the poli-

cies. P3P provides: human readable versions of the

policies; automated comparison of users preferences

with policies; automated reports in the event of a mis-

match; and incorporation of users preferences when

viewing and changing policies. A drawback of P3P

is that it simply checks whether the users preferences

match with the organisations stated privacy policies;

it does not ensure that the organisations actually en-

force their stated privacy policies. FlexDDPL deﬁnes

a policy language for data distribution which speci-

ﬁes who under what conditions is allowed to store

what data, how and where. FlexDDPL policies can be

expressed independently from storage controller and

gateway implementations and be mapped onto those

as part of administration process. However, how these

two independent policies can be combined and how

the conﬂicts between those can be resolved is not de-

ﬁned. Moreover their current implementation does

not include location.

On the other hand, XACML (an OASIS standard)

provides both a policy language and an access control

decision request/response language and also speciﬁes

a policy evaluation engine. Chadwick et al. have

modiﬁed the XACML model to allow multiple pol-

icy languages and multiple policies of independent

authorities to be supported by the model, making it

suitable for use in Cloud scenarios (Chadwick and

Fatema, 2012). The current implementation of it sup-

ports both XACML and PERMIS policy languages

and is available under an open source license. How-

ever it still uses the XACML request and response

language and keeps the policydecision points (see be-

low) for each policy language unchanged. We chose

to adopt XACML for our location control model due

to its standardised format and built-in enforcement

mechanism. It is also the most widely used language

for deﬁning security policy (Turkmen and Crispo,

2008).

3 BACKGROUND INFORMATION

In this section, we present some background informa-

tion on authorization systems and how they can be

integrated with Cloud deployments. Furthermore, we

describe a use case model that highlights the usability

of the proposed Cloud data location control mecha-

nism. We also specify the scope and constraints of

our solution.

3.1 Authorization Systems

Access control/authorization is a process of determin-

ing whether a request to access (e.g. read, write,

delete, copy, etc.) a resource object (e.g. ﬁle,

database, program, system component) by a subject

(e.g. user, system or process) should be granted or

denied. The access control/authorization system can

grant or deny the request based on whether or not cer-

tain policy constrains have been satisﬁed. ISO/IEC

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

478

10181- 3:1996 (ISO, 1996) deﬁnes a generic Access

Control Framework (ACF) as shown in Figure 1. It

consists of four components: (i) initiators (subjects),

(ii) targets (resource objects), (iii) Access control En-

forcement Functions (AEFs) – commonly known as

Policy Enforcement Points (PEPs) – and (iv) Ac-

cess control Decision Functions (ADFs) – commonly

known as Policy Decision Points (PDPs). The initia-

tors submit access requests (also known as user re-

quests) that specify the operation to be performed on

the target. The AEF transforms the request into one

or more decision requests (also known as authoriza-

tion queries) and sends these to the ADF. The ADF

decides whether a decision request should be granted

or denied based on the provided policies and sends the

decision back to the AEF.

Initiator

ADF/PDP

Target

AEF/PEP

Submit

Access

Request

Decision

Request

Decision

Present

Access

Request

Figure 1: ISO/IEC 10181-3 access control framework

(ACF).

An access decision can contain obligations, such

as sending e-mail to the data subject or recording the

permitted access in a log. These obligations are en-

forced by the PEP while executing the access deci-

sion. Authorization systems may play an important

role in Cloud data management since Cloud service

deliverycan involve signiﬁcant amounts of data trans-

mission and storage. SaaS providers offering ser-

vices, such as web applications, may accumulate a

large amount of personal data like names, addresses,

medical records, purchase history and so on during

the execution of the service. The management, pro-

cessing and storage of such data while considering

customers’ data location choices is challenging. In

this paper, we aim to develop a mechanism for SaaS

providers, who might be using services from IaaS and

PaaS layers, to incorporate the location choices of

their customers while managing and storing data in

Clouds.

3.2 XACML Policy Structure and

Evaluation

This section provides a brief description of XACML

policy structure and its evaluation strategy.

3.2.1 XACML Policy Structure

XACML policies are constructed with the following

components: policy set (PS), policy (P), rule (R), tar-

get (t), policy combining algorithm (PCA) and rule

combining algorithm (RCA). A target t is composed

of four types of attributes: subjects (S), resources

(Rs), actions (A) and environments (En). A rule is

deﬁned as a tuple, r = (id, t, e, c), where id is a rule

ID, t is a rule target, e ∈ {Permit, Deny} is an effect

and c is a condition which is an optional element and

is evaluated to a Boolean value. A policy is deﬁned

as a tuple, p = (id, t, R, RCA, O), where id is a policy

ID, t is a policy target, R = {r

, r

, . . . , r

} is the set of

rules and RCA is the rule combining algorithm and O

is an optional set of obligations.

A policy set is deﬁned as tuple PS =

(id, t, P, PAC, O), where id is the policy set ID, t

is the policy set target, P = {p

, p

, . . . , p

} is the set

of policies, PCA is the policy combining algorithm

and O is an optional set of obligations. An access

request in XACML v2 is deﬁned as a set of attributes,

= (s, rs, a, en), where s is a set of subject at-

tributes, rs is a set of resource attributes, a is a set

of action attributes and en is a set of environment or

context attributes. Each attribute set describes the

corresponding object. The request means that the

subject described by s is asking to be perform the

action described by a on the resource described by rs

in the presence of the context described by en.

3.2.2 Evaluation of a Request

An authorisation decision is performed by the

XACML PDP by matching the values of the request

with the values in the policies. A target element of

XACML is evaluated as Match if all the elements

speciﬁed in the target match with the values presented

in the request context. If any one of the elements spec-

iﬁed in the target is indeterminate, then the target is

evaluated as indeterminate. Otherwise, the target is

evaluated as no-match. The condition element repre-

sents a Boolean expression. When the target element

of an XACML policy evaluates to Match and the con-

dition element evaluates to True, the rule evaluates

to Effect and when the target element of an XACML

policy evaluates to Match and the condition element

evaluates to False the rule evaluates to NotApplica-

ble (Anderson, 2005). The standard policy combin-

ing algorithms of XACML v2 (Anderson, 2005) and

v3 (Rissanen, 2013) are deﬁned as:

1. Deny-overrides (Ordered and Unordered in v3),

2. Permit-overrides (Ordered and Unordered in v3),

3. First-applicable and

AUserDataLocationControlModelforCloudServices

479

4. Only-one-applicable.

In the case of the deny-overrides algorithm, if a sin-

gle policy element evaluates to “Deny”, then, regard-

less of the evaluation result of the other policy ele-

ments, the combined result is “Deny”. For ordered

deny-overrides the behaviour of the algorithm is the

same except that the order in which the collection of

policies is evaluated will match the order as listed in

the policy set. Similarly, in the case of the permit-

overrides algorithm, if a single “Permit” result is en-

countered, regardless of the evaluation result of the

other policy elements, the combined result is “Permit”

and for the ordered permit-overrides the behaviour

of the algorithm is the same except that the order

in which the collection of policies is evaluated will

match the order as listed in the policy set. In the

case of the “First-applicable” combining algorithm,

the ﬁrst decision encountered by the policy element in

the list becomes the ﬁnal decision accompanied by its

obligations (if any). The only-one-applicable policy-

combining algorithm ensures that only one policy is

applicable by virtue of its target. The result of the

combining algorithm is the result of evaluating the

single applicable policy. If more than one policy is

applicable, then the result is “Indeterminate”. In the

XACML v3 speciﬁcation some other combining al-

gorithms are also deﬁned, such as deny-unless-permit

(which returns “Deny” only if no “Permit” result is

encountered) and permit-unless-deny (which returns

“Permit only” if no “Deny” result is encountered).

3.3 Use Case

To contextualize our approach in this paper, we

present a use case that exempliﬁes the scope of our

approach. Figure 2 shows an overview of our sys-

tem model and how it integrates with Cloud deploy-

ments. The model considers interactions among three

different groups of stakeholders: (i) Cloud service

providers, (ii) enterprises and (iii) end users.

Availability Zone 1

Region 1 Region 2

Virtualized Resource

Physical Resource

Availability Zone 2

Virtualized Resource

Physical Resource

Availability Zone 3

Virtualized Resource

Physical Resource

Region 1 Service Access Point

Enterprise Cloud Service

Region 2 Service Access Point

Cloud Service Provider

li Z 1

A il bili

End User

Figure 2: Location aware Cloud usage model.

Cloud Service Providers – For the purposes of this

use case, we assume that the Cloud service providers

are either IaaS or PaaS providers who offer virtualized

resources/environment to the enterprises as services.

The services are offered in separate regions, as shown

in Figure 2. They deploy resource instances and data

according to the instructions of their customers and

do not move data without being instructed by the cus-

tomers. For example, Amazon EC2 provisioning cur-

rently works in this manner. Each region is identiﬁed

by a unique name and is accessed via speciﬁed access

points that act as a gateways to the service. Each re-

gion may consist of a number of availability zones, as

shown in Figure 2, where the instances and data can

be copied to provide better availability in the event of

a failure. Customers can choose one or more avail-

ability zones where their data and service instances

can be replicated.

Enterprises are the customers of IaaS and PaaS

services. They compose their SaaS services over the

IaaS or PaaS services to offer them to the end users.

These services may be designed to collect and pro-

cess the end users’ personal data. Depending on their

organizational needs, an enterprise can choose to put

their services in more than one regions and a num-

ber of availability zones in each region. Enterprises

manage the customers’ data and are responsible for

instructing the Cloud providers correctly about which

data is to be stored in which region.

End users/data owners – End users are the per-

sons who are consuming the service. Enterprises may

collect personal data from end users which are later

stored and processed in the Cloud environment. The

end users who are sharing their personal data with the

enterprise are referred to as data owners.

This model assumes data to be of any format

which should have two properties: i) it should be

identiﬁed by one uniquely identiﬁable name, DataID,

and ii) it is expected to be treated as one unit while ac-

tions (e.g. copy, read, write) are performed on it. The

idea of having a unique identiﬁer within a Cloud is

not an impractical assumption as each Cloud user has

a unique account which can be used or combined to

form the unique identiﬁer. In federated scenarios in-

volving multiple participants a number of Cloud and

identiﬁer linking mechanisms can be used to create a

globally unique identiﬁer.

The granularity of data that is protected by the pol-

icy depends on the enterprise’s application scenario.

It can be applied to a ﬁle or a set of ﬁles grouped under

one folder, or a database entry. The unique identiﬁer

of the data, DataID, and the identiﬁer of the policy,

PolicyID, that is applicable for protecting the data is

linked together by the model. This linking will allow

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

480

the policy that is relevant for that data to be evaluated

while a request for performing an action (e.g. copy,

read, write) on a data is received. As policy is linked

to a DataID regardless of the format of data the model

will protect the access of any type of data based on

the relevant policy.

We use a loyalty card program, as offered by

many retail chains, to exemplify this use case. Dur-

ing the sign up process, the customer gives some per-

sonal information such as her name, address and con-

tact information (e-mail/telephone number). The cus-

tomer uses the card while purchasing products from

the retailer and may be offered discounts based on

the purchase history. Each loyalty card can be rep-

resented electronically as an XML infoset containing

a unique Loyalty Card number (which can be used as

DataID)and other elements, such as a personal infor-

mation element containing name, address, age; and a

purchase history element, which can grow over time

based on the number of purchases. To improve avail-

ability and quality of experience for their customers,

the retailers use multiple Cloud services with different

location and regions. The retailer accesses the ser-

vices and data in these regions via the access points

offered by the Cloud Service provider.

The data owners are given the opportunity by the

retailer to choose one of the locations as a primary lo-

cation for storing their data initially. They can also

choose other locations where their data can be moved

if necessary. They can also activate an option to re-

ceive e-mail when the location changes. The retailer

ensures that the Cloud providers deploy the data to

the correct region according to the preference of the

data owner. In case of data movement, the data owner

receives a notiﬁcation if required by her policy.

4 DATA LOCATION CONTROL

The core of our approach is an enterprise Cloud ser-

vice manager (ECSM) that manages access to all

Cloud data and services using an authorization sys-

tem. The authorization system evaluates two types of

policies for making an access decision upon an access

request. The ﬁrst is the organizational administrative

policy that speciﬁes the enterprise roles and their at-

tributed actions on services or data (e.g., a marketing

ofﬁcer can execute a service, read the data and so on)

or the roles of other external services to perform ac-

tions on their protected data. This administrative pol-

icy is executed for all access requests. The second

type of policy consulted is the data owner’s speciﬁc

policy. All the data owners’ policies are stored in the

data owners’ policy store.

Enterprise Cloud Service Manager

Authz

System

Region

Information

Region 1 Service

data

Admin

Policy

Cloud Service of Region 1

Region 2 Service

data

Cloud Service of Region 2

Authentication

Information

Region Service Manager

yste

Data - Policy

Linking Table

Data

Owners

Policy

Figure 3: The enterprise Cloud service manager (ECSM)

manages services and data in different Cloud regions.

The enterprise service manager also includes a

user authentication information table for managing

user authentications, a region information table that

details the regions where each data set identiﬁed by a

DataID is stored and a data-policy linking table that

correlates each PolicyID to a DataID in order to re-

trieve the correct policy of the data owner for a spe-

ciﬁc data set. Figure 3 depicts how the region service

manager receives instructions from the authorization

system on where to store or retrieve data.

4.1 Intra-service Interaction Strategy

This section shows the interaction strategy to manage

data locations within the same enterprise. The discus-

sion is partitioned into four catagories: inputting data,

accessing data, updating data location and checking

location.

Data Input – To use the enterprise Cloud service,

the end users ﬁrst need to register for it. During the

registration process, the user speciﬁes authentication

information (typically a user name and password or

credentials) that is stored by the service provider to

identify the user. The authentication information pro-

vided by each user is associated with a DataID that

identiﬁes the data of this user. In our example use

case scenario it would be the loyalty card number.

The user provides a policy expressing her preferred

primary location for storing the data. It also speci-

ﬁes alternative locations where data can be moved for

different reasons, for example, to achieve better per-

formance or cheaper cost. The data owner’s policy

is provided with a PolicyID, which is also linked to

the DataID in the data-policy linking table as shown

in Figure 3. Each DataID is linked to a region infor-

mation table that contains the current locations of the

data identiﬁed by the DataID. This information is up-

dated whenever the data location changes.

Accessing Data – All the requests for accessing

AUserDataLocationControlModelforCloudServices

481

data (e.g. reading the data or processing the data) goes

to the ECSM’s authorization system. The ECSM ﬁrst

gets the data owner’s PolicyID in the data-policy link-

ing table and retrieves the policy from the data own-

ers’ policy store. The administrative policy and the

data owner’s policy are evaluated against the access

request. If the policies evaluations are successful, the

requested access is granted. The enterprise authoriza-

tion system can be conﬁgured with various static con-

ﬂict resolution strategies (Godik et al., 2002) or can

obtain the conﬂict resolution strategy dynamically

(Mohan and Blough, 2010) to resolve the conﬂicts

between the administrative policy and data owner’s

policy.

Updating Data Location – The enterprise Cloud

service administrator continuously monitors the per-

formance of the services. If there is a need to copy the

data to another location, she places a permission re-

quest to the ECSM authorization system. The ECSM

accesses the data owner’s policy and the administra-

tive policy to evaluate them as described previously.

If the policy allows for copying to the new location,

then the data are copied and the region information ta-

ble is updated to reﬂect these changes. If the user re-

quires notiﬁcation upon data location change, then the

authorization system enforces this through the obliga-

tion enforcer. If the copy request is rejected then the

data location remains unchanged.

Checking Location – When a user wants to query

the location of her data, she ﬁrst logs in to the ser-

vice with her access credentials so that the service can

identify the data she owns. To allow the user access

the region information, either the administrator policy

or the data owner policy has to allow it as the autho-

rization system evaluates these policies to determine

the access right. If any of the policies return “Grant”

then the user is given the resquested information.

4.2 Inter-cloud Data Outsourcing

To achieve better efﬁciency and scalability, enter-

prises may need to outsource the processing of end

users’ data. For example, the retailer in our use case

scenario might outsource the processing of the pur-

chasing history to an analytics service. To realise this

strategy, the enterprise maintains an external cloud

information table to store the information of the ex-

ternal Cloud services with copies of the the data for

each DataID. This table is linked with the region in-

formation table that contains the information of re-

gions where the enterprise host its own service and

originally stores the data, as seen in Figure 4.

The enterprise’s administrative policy expresses

which external services are allowed to access their

protected data and each data owner’s policy speci-

ﬁes the allowed locations where his/her data can be

copied. When an external service requests permission

from the ECSM’s authorization system to transferring

data to a certain location of their Cloud, the admin-

istrative policy along with each data owner’s policy

are evaluated. If the administrative policy or the data

owner policy does not allow data transfer to the speci-

ﬁed locations, then the permission is denied. If the re-

quest is accepted, the data along with the policy of the

data owner are sent to the external service. A Service

Level Agreement (SLA) negotiation process may take

place between the enterprise and the external service

provider in order to ensure that the data owner policy

is respected upon any access request to the data. The

external service provider may use the same PolicyID

and DataID or may assign new IDs according to its or-

ganizational format. When assigning new IDs, there

must be a link to the old ones for traceability. The ex-

ternal service provider maintains the outsourced data

location similar to the approach described in Section

4.1. However, in this case access is granted based

on the data owner’s policy since the external service

provider might have a different administrative policy.

A scheme similar to that for viewing location in-

formation as mentioned in Section 4.1 is provided

to allow data owners to view their data location en-

tries in the external cloud information table. To view

the data location information, there are two options.

The end user (data owner) can access this information

through the default enterprise originally hosting her

data. The default enterprise is then responsible for

acquiring this information from the external service

provider. The external service provider’s administra-

tive policy can be written in a way to allow this access.

This can be speciﬁed in the SLA document with the

external service provider. Alternatively, since the ex-

ternal service provider evaluates the data owners pol-

icy upon receipt of an access request for a user’s data,

the data owner’s policy can be used to allow the nec-

essary access to the data location information. Figure

4 shows how data location can be controlled by the

ECSM’s authorization systems for two different ser-

vice managers.

5 IMPLEMENTATION

This section presents the technical details required for

a practical implementation of the proposed location

control model. This section also includes a descrip-

tion of a prototype implementation and testbed that

used to perform validation tests of the location con-

trol model.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

482

Authz

System

data

Admin

Policy

Enterprise 1 Cloud service

Region info

External

Cloud info

Internal communication

External communication

Enterprise 2 Cloud service

Data -

Policy

Linking

Table

Data

Owners

Policy

Region Service

Manager

data

Authz

System

Enterprise 1 Cloud service Manager

Authz

System

data

Admin

Policy

Region info

External

Cloud info

Authz

System

Data -

Policy

Linking

Table

Data

Owners

Policy

Region Service

Manager

data

Enterprise 2 Cloud service Manager

Figure 4: Controlling data location across multiple Clouds.

5.1 Data Presentation

Our model assumes that each end user’s data is

uniquely identiﬁed by a DataID. For our loyalty card

use case scenario, XML is chosen as the representa-

tion format as it allows the data to be easily structured

in separate elements which can be easily identiﬁed,

modiﬁed and extended. However, alternate represen-

tation schemes, such as database tables or NoSQL en-

tries could also be used. An example of the loyalty

card XML format is given in Listing 1, which con-

sists of two main elements: PersonalInfo, describing

the personal identiﬁcation information for a customer,

and PurchaseHistory which encapsulates a list of the

customer’s purchases. Additional elements could be

added based on the details of the speciﬁc loyalty card

programme offered by the enterprise.

Listing 1: Loyalty Card Example.

<Sex>Female</Sex>

</PersonalInfo>

<ProductName >Bread</ProductName >

<DateOfPurchase>23.3.2013 </

DateOfPurchase>

</Product>

</Purchase>

</PurchaseHistory>

5.2 Policy Creation

Although the policies expressed as XML are human

readable to an extent but are not particularly user-

friendly, and it is unreasonable to expect end users to

be able to write policies with these policy languages.

Therefore, some form of user-friendly interface and

translation mechanism is required. In our model, the

data owner is presented with a web interface (imple-

mented with PHP) for indicating location preferences.

The interface works like a template for policy; the

policy document is created automatically based on the

locations that the user selects. The prototype imple-

mentation of the interface can be found in online

After the customer’s location preferences have been

entered the resulting XACML request context con-

taining user’s policy (as PolicyContents element) is

generated. This request context is then sent to the au-

thorization system via a SOAP call. Depending on

the enterprise’s application scenario a default policy

can be created when the user does not choose any lo-

cation. In our prototype implementation the end user

has to choose at least one location where she data to

be stored initially and if the end user does not choose

any optional locations then the created policy contains

only the initial location.

The XACML policy language is used for the in-

ternal representation of policies as it is an OASIS

standard and is the most widely used language for

deﬁning security policy (Turkmen and Crispo, 2008).

XACML allows various types of attributes to be ex-

pressed, such as Subject, Resource, Action and En-

vironment. The attributes presented in a policy are

matched against the attributes presented in a request

context by the PDP (see Section 3) when making an

authorization decision. We have deﬁned Location

as an Environment attribute in our XACML policy

which requires the request context to specify an ap-

propriate value to be evaluated by the policy. An

example of a policy document derived from a data

owner’s input is presented in Listing 2, allowing

store/copy/transferto Region 1 and Region 2 and obli-

gating that an e-mail be sent to him/her when the lo-

cation changes.

Listing 2: Data owner’s policy example.

<PolicySet PolicyCombiningAlgId="deny-

overrides">

<Policy PolicyId="UserAccessPolicy1"

RuleCombiningAlgId="deny-overrides">

http://143.239.71.90:8013/data

location/

User

registration.html

AUserDataLocationControlModelforCloudServices

483

<Description >My data can be copied/

stored/transferred in Region 1 and

Region 2

</Description >

<Apply FunctionId=

"string -at-least -one-member -of">

<ActionAttributeDesignator AttributeId =

"action -id" DataType="string"/>

COPY </AttributeValue>

STORE </AttributeValue>

TRANSFER </AttributeValue>

</Apply> </Apply>

<Apply FunctionId=

"string -at-least -one-member -of">

<EnvironmentAttributeDesignator

AttributeId ="Location"

DataType="string"/>

Region 1 </AttributeValue>

Region 2 </AttributeValue>

</Apply></Apply></Apply>

</Condition >

</Rule>

<Obligation

ObligationId="Email -to-AB@gmail.com"

FulfillOn="Permit"/>

</Obligations >

</Policy>

</PolicySet >

Note: Some prefixes from XACML elements

are removed for readability .

5.3 Visibility for Data Owners

As described in Section 4, the location information for

each user’s data is referenced in the region informa-

tion table of the ECSM. As the policies that are evalu-

ated against an access request decide whether the ac-

cess request should be granted or not, there needs to

be a policy to allow the data owner to access the en-

tries in the region information table for his/her data.

This can be placed either inside the Cloud administra-

tive policy set or the data owner’s policy set. When it

is stored in the Cloud Administrator’spolicy set, it has

to be written in a generic way without requiring each

individual user’s credential to be speciﬁed in the pol-

icy. An example of such a policy is: If the credential

of the requester matches the data owner’s credential

then allow access to the Region Information of that

speciﬁc data. The result of such a generic policy is

that there will exist only one policy for this purpose

in the system. This policy will match the creden-

tial of the data owner, which is passed to the autho-

rization system from the Authentication Information

table, with the credential presented by the requester

while making an access request to the service.

Alternatively, the policy to allow data owners to

access the region information of their data can be

placed in the data owners’ policy sets. The policy

would allow the requester presenting the appropri-

ate credential to access region information for his/her

data. A drawback with this approach is that the size

of policy for each data owner will be increased which

may lead to signiﬁcant growth in the size of the over-

all policy store. On the other hand, a beneﬁt of this ap-

proach is that it would ease the process of distributed

enforcement of the data owner’s policy in a remote

Cloud as the data owner’s policy will be passed to the

remote Cloud service and no extra mechanism will be

needed to identify the data owner.

With the ﬁrst approach, the user credential and the

administrative policy would also need to be passed to

the remote service in order to allow the user to access

location information from an external Cloud. The re-

mote service would need to make sure that these user

credentials are stored correctly and passed to the re-

quest contexts and would also need to integrate the

received administrative policy with its own admin-

istrative policy. We therefore chose the second ap-

proach to ease the distributed enforcement of our lo-

cation control model. Listing 3 shows an example

policy which is placed inside the data owner’s pol-

icy to allow access to the Region Information table. It

speciﬁes the UserName and Password that are to be

matched to allow the access.

Listing 3: Data owner’s policy example to permit access to

region information.

<Policy PolicyId="UserAccessPolicy2"

RuleCombiningAlgId="deny-overrides">

<Description >Requester presenting the

specified credential can access the

region information </Description >

<Apply FunctionId=

"string -at-least -one-member -of">

<SubjectAttributeDesignator

AttributeId ="UserName"

DataType="string"/>

Alice

</AttributeValue>

</Apply></Apply>

<Apply FunctionId=

"string -at-least -one-member -of">

<SubjectAttributeDesignator

AttributeId ="Password"

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

484

DataType="string"/>

AlicePassword

</AttributeValue>

</Apply></Apply>

<Apply FunctionId=

"string -at-least -one-member -of">

<ResourceAttributeDesignator

AttributeId="ResourceType"

DataType="string"/>

RegionInformation

</AttributeValue>

</Apply></Apply>

</Apply>

</Condition >

</Rule>

</Policy>

5.4 ECSM Implementation

The enterprise cloud service manager for the proto-

type was implemented using PHP. It in turn uses an

open source authorization system that is implemented

in Java as a web service and is available online

. This

authorization system receives requests as XACMLAu-

thzDecisionQuery elements of the SAML proﬁle of

XACML and returns decisions in the form of XACM-

LAuthzDecisionStatementType elements. The system

can store policy that comes with the request context

and allows the policy of the data owner to be stored.

It maintains the data-policy linking table for the pro-

vided DataID and PolicyID. It can return obligations

if conﬁgured appropriately in the policy and can re-

trieve policy for a relevant DataID which is passed by

the ECSM to remote authorization systems via SOAP

calls. The remote authorization system receiving a re-

quest based on its policy either accepts the request and

stores the policy or rejects the request. The authoriza-

tion system can be conﬁgured to use various conﬂict

resolution rules for combining the decisions of admin-

istrative policy and data owners’ policy. The details of

the conﬂict resolution rules can be found in (Fatema

et al., 2011). In this instance, the deny-overrides con-

ﬂict resolution rule is used. The rationale behind this

choice is that it will ensure that if either the admin-

istrative policy or the data owner’s policy returns a

“Deny” the ﬁnal decision will be a “Deny”. The ﬁnal

decision will be a “Grant” only if one of the policies

returns a ”Grant” but no other policy has returned a

“Deny”.

We have implemented the Authentication Infor-

mation table and Region Information table as MySQL

http://sec.cs.kent.ac.uk/permis/downloads/Level3/

standalone.shtml

tables. In the prototype implementation the Region

Service Manager stores the data in different remote

directories based on the speciﬁed region using the

SSH SCP protocol to copy the data. An example of

request context showing a copy request by an enter-

prise role Admin for a data to a certain location is

presented in Listing 4 and the corresponding response

from the authorization system is presented in Listing

5. For readability, the preﬁxes of some elements are

removed.

Listing 4: Copy request by Admin.

<soapenv:Envelope xmlns:soapenv="http://

schemas.xmlsoap.org/soap/envelope/">

<soapenv:Header/>

<soapenv:Body>

<xacml-context:Request>

<xacml-context:Subject>

<xacml-context:Attribute

AttributeId ="Role"

DataType="string">

<xacml-context:AttributeValue>

Admin

</xacml -context:AttributeValue>

</xacml -context:Attribute>

</xacml -context:Subject>

<xacml-context:Resource>

<xacml-context:Attribute

AttributeId ="rid"

DataType="string">

<xacml-context:AttributeValue>

LC001

</xacml -context:AttributeValue>

</xacml -context:Attribute>

</xacml -context:Resource>

<xacml-context:Action>

<xacml-context:Attribute

AttributeId="action:action -id"

DataType="string">

<xacml-context:AttributeValue>

COPY

</xacml -context:AttributeValue>

</xacml -context:Attribute>

</xacml -context:Action>

<xacml-context:Environment>

<xacml-context:Attribute

AttributeId="Location"

DataType="string">

<xacml-context:AttributeValue>

Region1

</xacml -context:AttributeValue>

</xacml -context:Attribute>

</xacml -context:Environment>

</xacml -context:Request>

</XACMLAuthzDecisionQuery>

</soapenv:Body>

</soapenv:Envelope>

Listing 5: Response to copy request.

<soapenv:Envelope xmlns:soapenv="http://

schemas.xmlsoap.org/soap/envelope/">

<soapenv:Body>

<xacml -context:Response xmlns:xacml -

context=

"urn:oasis:names:tc:xacml:2

AUserDataLocationControlModelforCloudServices

485

.0:context:schema:os">

<xacml-context:Result

ResourceId="ou=some,o=service,c=gb">

<xacml-context:Decision>

Permit

</xacml -context:Decision>

<xacml-context:Status>

<xacml-context:StatusCode

Value="

urn:oasis:names:tc:xacml:1

.0:status:ok "

</xacml -context:Status>

<xacml:Obligations xmlns:xacml =

"urn:oasis:names:tc:xacml:2.0

:policy:schema:os">

<xacml:Obligation ObligationId=

"Email -to-AB@gmail.com"

FulfillOn="Permit"/>

</xacml:Obligations>

</xacml -context:Result>

</xacml -context:Response>

</soapenv:Body>

</soapenv:Envelope>

5.5 Validation

Validation testing of the prototype was performed in

order to conﬁrm the correctness of the following func-

tionality:

1. Data owners’ location preferences are correctly

translated into policy.

2. Data and policy are both stored correctly.

3. When a copy request is sent by an administrator

to a region that is accepted by the data owner’s

policy, a “Grant” response is returned and an obli-

gation to e-mail the data owner is created. On re-

ceiving a “Grant” response the data is retrieved

from its current region and sent to the approved

region and the region information table is updated

accordingly.

4. When a copy request is sent by an administrator to

a region that is not permitted by the data owner’s

policy, a “Deny” response is returned and the data

is not copied in that case.

5. Requests by a data owner for region information

with valid credentials are accepted and the data

owner is given the region information only for her

data.

6. When a transfer request is sent by an administra-

tor to a remote Cloud service in a region that is

accepted by the data owner’s policy, a “Grant” re-

sponse, along with the data owner’s policy is re-

ceived from the authorization system.

7. Remote services correctly store the data along

with the data owner’s policy after data has been

transferred.

An additional objective was to determine the perfor-

mance overhead of the system.

The validation work was performed using an in-

stance of the prototype implementation deployed on

a virtual machine running in a vSphere private cloud

with ESXi host. The virtual machine was conﬁgured

with one virtual core Intel Xeon E5620 CPU running

at 2.4 GHz with 2GB of memory. Another virtual

machine with an identical conﬁguration was used to

mimic a remote storage location. All of the func-

tionality described above was found to operate cor-

rectly. By averaging over the response times of 100

requests in total it was found that it takes approxi-

mately 0.04s in order to process a transaction that (a)

identiﬁes the correct data location and actions to per-

form on that data; and (b) queries the authorization

system, obtains a response and updates the database

accordingly; which indicates that at least 25 requests

can be handled per sec by the current implementation

of the model. In contrast, a 0.2s overhead was ob-

served for connecting to the remote storage via SSH

and transferring a ﬁle containing an XML representa-

tion of a loyalty card of size less than 1KB via SCP.

Therefore, for this particular scenario the overhead of

using the location control model was found to be neg-

ligible compared to the overall cost of performing re-

mote data transfers.

6 CONCLUSION AND FUTURE

WORK

The data location control model presented here al-

lows enterprises to manage location of end users’ data

based on their preferences. It also empowers users

with the ability to get up-to-date location information

for their data and the assurance that they will be no-

tiﬁed when their data changes location. A drawback

of this approach is that it relies on the trustworthi-

ness of the provider who must be trusted to integrating

requests to the authorization system into their soft-

ware and procedures and honour the resulting output.

Hence, end users cannot verify that location informa-

tion provided to them is actually true. However, these

issues could be addressed by trustmarks and other

third-party veriﬁcation methods. Crytographic tech-

niques could also be used to enhance the trustworthi-

ness of the model. For example, the data could be en-

crypted using a key that can must be obtained through

a request to the authorization system.

For convenience, our prototype stored the data to

be protected as ﬁles in XML format. However, the

model could also be used to protect access to collec-

tions of ﬁles, such as medical records composed of a

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

486

variety of ﬁles in various formats. Future work will

focus on improving the granularity of policies to al-

low for selective disclosure of data. This granularity

could be extended to database entries where the one

single row can be identiﬁed by DataID and selective

disclosure can be provided for various items repre-

sented by columns of that row. A private cloud was

used as a testbed to perform the validation of the sys-

tem. Future work will examine the issues around run-

ning the authorization system on public clouds. For

example, in a federated cloud scenario, how well do

the region boundaries of each provider correlate with

those of the others?

Future work will also focus on how to integrate

location awareness into open cloud platforms such

as OpenStack. For OpenStack, obvious integration

points include: Horizon, the web-based dashboard

that controls all OpenStack components; Keystone,

which manages the authentication and authorization

of services and users; Swift, which provides object

store funtionality; and Cinder, which provides block

storage. OpenStack supports the concepts of geo-

graphically dispersed regions with separate endpoints

(Jackson, 2012), providing a good ﬁt with the data

control model described in Section 4. Under this sce-

nario, one Keystone and Horizon is shared between

the regions to provide a common access control and

dashboard, while distributed Swift and Cinder com-

ponents allow for complete separation of storage by

region. The object storage functionality provided by

Swift provides an easier starting point for the integra-

tion of location control compared to Cinder as it deals

with named, atomic units of data. A ﬁrst step will

to be to allow location preferences to be associated

with users and Swift objects, and to provide an API

that allows developers to check the permissibility of

copying objects from one region to another.

ACKNOWLEDGEMENTS

The research work described in this paper was sup-

ported by the Irish Centre for Cloud Computing

and Commerce, an Irish national Technology Centre

funded by Enterprise Ireland and the Irish Industrial

Development Authority.

REFERENCES

Albeshri, A., Boyd, C., and Nieto, J. (2012). Geoproof:

Proofs of geographic location for cloud computing en-

vironment. In Distributed Computing Systems Work-

shops (ICDCSW), 2012 32nd International Confer-

ence on, pages 506–514.

Almutairi, A., Sarfraz, M., Basalamah, S., Aref, W., and

Ghafoor, A. (2012). A distributed access control

architecture for cloud computing. Software, IEEE,

29(2):36–44.

Anderson, A. (2005). OASIS extensible access control

markup language (XACML) version 2.0. OASIS Stan-

dard, 1.

Ashley, P., Hada, S., Karjoth, G., Powers, C., and Schunter,

M. (2003). Enterprise privacy authorization language

(epal 1.2). Submission to W3C.

Basescu, C., Carpen-Amarie, A., Leordeanu, C., Costan,

A., and Antoniu, G. (2011). Managing data access on

clouds: A generic framework for enforcing security

policies. In Advanced Information Networking and

Applications (AINA), 2011 IEEE International Con-

ference on, pages 459–466.

Benson, K., Dowsley, R., and Shacham, H. (2011). Do you

know where your cloud ﬁles are? In Proceedings of

the 3rd ACM workshop on Cloud computing security

workshop, pages 73–82. ACM.

Chadwick, D., Zhao, G., Otenko, S., Laborde, R., Su, L.,

and Nguyen, T. A. (2008). PERMIS: a modular au-

thorization infrastructure. Concurrency and Compu-

tation: Practice and Experience, 20(11):1341–1357.

Chadwick, D. W. and Fatema, K. (2012). A privacy pre-

serving authorisation system for the cloud. Journal of

Computer and System Sciences, 78(5):1359–1373.

Chen, D. and Zhao, H. (2012). Data security and privacy

protection issues in cloud computing. In Computer

Science and Electronics Engineering (ICCSEE), 2012

International Conference on, volume 1, pages 647–

651. IEEE.

Cranor, L. F. (2003). P3P: Making privacy policies more

useful. Security & Privacy, IEEE, 1(6):50–55.

Demchenko, Y., Koeroo, O., de Laat, C., and Sagehaug,

H. (2008). Extending XACML authorisation model

to support policy obligations handling in distributed

application. In Proceedings of the 6th international

workshop on Middleware for grid computing, page 5.

ACM.

di Vimercati, S. D. C., Samarati, P., and Jajodia, S. (2005).

Policies, models, and languages for access control. In

Databases in Networked Information Systems, pages

225–237. Springer.

Fatema, K., Chadwick, D. W., and Lievens, S. (2011). A

multi-privacy policy enforcement system. In Privacy

and Identity Management for Life, pages 297–310.

Springer.

Godik, S., Anderson, A., Parducci, B., Humenn, P., and Va-

jjhala, S. (2002). Oasis extensible access control 2

markup language (xacml) 3. Technical report, Tech.

rep., OASIS.

Gondree, M. and Peterson, Z. N. (2013). Geolocation of

data in the cloud. In Proceedings of the third ACM

conference on Data and application security and pri-

vacy, pages 25–36. ACM.

Iskander, M. K., Wilkinson, D. W., Lee, A. J., and Chrysan-

this, P. K. (2011). Enforcing policy and data consis-

AUserDataLocationControlModelforCloudServices

487

tency of cloud transactions. In Distributed Comput-

ing Systems Workshops (ICDCSW), 2011 31st Inter-

national Conference on, pages 253–262. IEEE.

ISO (1996). Information technology – open systems inter-

connection – security frameworks for open systems:

Access control framework.

Jackson, K. (2012). OpenStack Cloud Computing Cook-

book. Packt.

Katz-Bassett, E., John, J. P., Krishnamurthy, A., Wether-

all, D., Anderson, T., and Chawathe, Y. (2006). To-

wards IP geolocation using delay and topology mea-

surements. In Proceedings of the 6th ACM SIGCOMM

conference on Internet measurement, pages 71–84.

ACM.

Lynn, T., Healy, P., McClatchey, R., Morrison, J., Pahl, C.,

and Lee, B. (2013). The case for cloud service trust-

marks and assurance-as-a-service. In Intl. Conference

on Cloud Computing and Services Science Closer’13.

Massonet, P., Naqvi, S., Ponsard, C., Latanicki, J., Rochw-

erger, B., and Villari, M. (2011). A monitoring and

audit logging architecture for data location compli-

ance in federated cloud infrastructures. In Parallel

and Distributed Processing Workshops and Phd Fo-

rum (IPDPSW), 2011 IEEE International Symposium

on, pages 1510–1517.

Mohan, A. and Blough, D. M. (2010). An attribute-based

authorization policy framework with dynamic conﬂict

resolution. In Proceedings of the 9th Symposium on

Identity and Trust on the Internet, pages 37–50. ACM.

Noman, A. and Adams, C. (2012). DLAS: Data location as-

surance service for cloud computing environments. In

Privacy, Security and Trust (PST), 2012 Tenth Annual

International Conference on, pages 225–228. IEEE.

Park, J. and Sandhu, R. (2004). The UCON ABC usage

control model. ACM Transactions on Information and

System Security (TISSEC), 7(1):128–174.

Peterson, Z. N., Gondree, M., and Beverly, R. (2011). A

position paper on data sovereignty: The importance

of geolocating data in the cloud. In Proceedings of the

8th USENIX conference on Networked systems design

and implementation.

Ries, T., Fusenig, V., Vilbois, C., and Engel, T. (2011). Ver-

iﬁcation of data location in cloud networking. In Util-

ity and Cloud Computing (UCC), 2011 Fourth IEEE

International Conference on, pages 439–444. IEEE.

Rissanen, E. (2013). OASIS extensible access control

markup(XACML) version 3.0. OASIS Standard, 1.

Spillner, J. and Schill, A. (2012). Flexible data dis-

tribution policy language and gateway architecture.

In Cloud Computing and Communications (LATIN-

CLOUD), 2012 IEEE Latin America Conference on,

pages 1–6. IEEE.

Subashini, S. and Kavitha, V. (2011). A survey on secu-

rity issues in service delivery models of cloud comput-

ing. Journal of Network and Computer Applications,

34(1):1–11.

Turkmen, F. and Crispo, B. (2008). Performance evaluation

of XACML PDP implementations. In Proceedings

of the 2008 ACM workshop on Secure web services,

pages 37–44. ACM.

CLOSER2014-4thInternationalConferenceonCloudComputingandServicesScience

488
