DEPENDABLE DISTRIBUTED TESTING

Can the Online Proctor be Reliably Computerized?

Ariel J. Frank

Department of Computer Science, Bar-Ilan University, Ramat-Gan, Israel

Keywords: Lockdown Software, Dependable Distributed Testing, Distributed Education, Identity Verification, Online

Proctoring, Secure Online Testing, Test Cheating, Test Integrity, Testing Management System.

Abstract: Distributed Education (DE) enables education, both teaching and learning, anytime, anywhere, using any

media or modality, at any pace. Assessment, especially testing, is a major component in the overall

evaluation of an educational program. However, there still is an important component missing from most

DE programs to enable its full realization in a distributed environment: dependable distributed testing

(DDT). The paper presents a comprehensive risk analysis of dependable distributed testing that classifies

seven (types of) risks, introduces the resultant DoDoT (Dependable observable Distributed online Testing)

reference model, and examines its coverage by three commercial systems. However, these systems are not

yet in use in most DE frameworks and do not have yet full DoDoT coverage. The vision of the DoDoT

reference model is the continued pursuit and adaptation of new, innovative technologies and methods to

make dependable distributed testing increasingly more computerized, reliable, affordable and prevalent.

1 INTRODUCTION

The incessant evolution of the Web has also

accelerated the adaptation of Distributed Education

(DE)

, a generalization of Distance Learning, which

is in wide use nowadays for educational aims (Allen

& Seaman, 2010). DE enables education, both

teaching and learning, anytime, anywhere, using any

media or modality, at any pace.

There are many important topics in education in

general and in distributed education in particular

(Simonson, Smaldino, Albright & Zvacek, 2009).

We concentrate here on the topic of assessment –

of learners by teachers – a major component in the

overall evaluation of an educational program.

Assessment, be it summative or formative, is a

process dealing with control, measurement and the

systematic documenting of learners' achievements so

as to be able to examine to what extent have the

learners advanced towards predefined educational

goals. Learners' assessment can be achieved using

some combination of tools, such as assignments,

papers, projects, quizzes, open and closed tests,

forums, group work, etc.

The focus here is on the classic assessment tool –

the test (exam, quiz), taken by a testee (examinee,

test taker), usually a student, pupil, or trainee,

learning in an organization associated with higher

education, high schools, or business, respectively.

But how can testing security be provided to assure

testing integrity? Obviously, there are people who

will cheat or defraud if the stakes are high enough

and the deterrence too low (Bailie & Jortberg, 2009;

King, Guyette & Piotrowski, 2009; McCabe,

Trevino & Butterfield, 2001; VS1, n.d.).

Tests can be paper-based or computer-based.

Modern educational frameworks (e-learning)

provide for computer-administered testing

(e-testing). However, notwithstanding the significant

growth of DE and its recent ubiquity, there still is an

important component missing from most DE

programs to enable its full realization in a distributed

environment: dependable distributed testing (DDT)

(Bailie & Jortberg, 2009; Graf, 2002; Guess, 2008).

The term “dependable” here means that distance

testing is available to all testees in a secure, reliable

manner that maintains testing integrity. The focus

here is only on the technical aspects of DDT.

The contribution of this paper is in the

comprehensive risk analysis of DDT, in the resultant

DoDoT (Dependable observable Distributed online

Testing) reference model and in examining its

coverage by three commercial systems. The rest of

the paper is structured as follows. The following

section discusses some relevant aspects of

dependable testing. In Section 3, seven (types of)

Frank A. (2010).

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?.

In Proceedings of the International Conference on e-Business, pages 22-31

DOI: 10.5220/0002985500220031

 SciTePress

risks in DDT are analyzed. In Section 4 the resultant

DoDoT reference model is introduced and its

coverage by three commercial systems is examined

in Section 5. We conclude the paper with Section 6.

2 DEPENDABLE TESTING

Before delving into the risk analysis of DDT, the

following subsections review some relevant aspects

of dependable testing: accreditation of DE programs,

in-person proctoring, and testing integrity.

2.1 DE Program Accreditation

Are DE programs as reputable as regular educational

programs? Or more formally, are DE programs

regulated and accredited as non-DE programs are?

Specifically, accreditation requires that an

organization offering an educational program must

positively prove by some documentation that an

enrolled person is the same learner who does the

work leading to graduation (Acxiom, n.d.; VS2, n.d.).

Admittedly, there is a trend in DE not to rely on

high-stakes testing for learners' assessment (Foster,

2008). This trend advocates worry that they will be

forced to use a particular assessment process that

could turn out be too expensive or that would

overemphasize tests. Their driving idea is that DE

teachers should rely more for assessment on written

assignments, threaded discussions, blogs, wikis,

e-portfolios, online quizzes, open tests and capstone

projects. The assumption is that teachers can become

familiar with their learners' working and writing

styles in order to spot cheating and fraudulent work,

and in time be able to individually assess them.

However, educational organizations requiring

high-stakes assessment probably need to depend on

testing (Heubert & Hauser, 1999). The lack of

dependable testing might turn out to be a major

obstacle in complying with required accreditation.

Having such “validated testing” could garner more

respect for DE programs and raise their credibility

with regulators. However, even if distance testing is

provided, it is recommended that learners should not

be forced to take an online test. In the same way that

usually there is a choice if to take an educational

program on-ground or online, so should there be a

choice for test taking.

2.2 In-person Proctored Tests

Dependable testing is usually realized by human

oversight, in the form of proctors who administer the

test. Dependable test delivery, with in-person

proctors, can be realized using one of three options

(Questionmark, n.d.):

1. On-site testing

2. Off-site testing centers

3. One-on-one proctoring.

On-site testing necessitates the physical arrival of all

proctors and testees (and usually their teachers) to

the organization at the same time. With computer-

administered testing, each testee works on a

computer that is organizationally preloaded with the

test and other tools authorized for use. This is a

major undertaking by all involved, though it does

provide dependable testing.

Off-site testing centers necessitate the physical

arrival of proctors and testees to the closest testing

center at similar times (time zone adjusted). This

requires travel of staff and faculty to proctor tests

taken at off-site public facilities or at third-party

testing centers. With computer-administered testing,

the organizational logistics required to support

multiple testing centers in parallel is a complex

effort. It can turn out to be a cumbersome operation,

though it also provides dependable testing.

One-on-one proctoring necessitates the

recruitment of an in-room proctor to supervise a

certain testee at a pre-designated place and time.

That is, the testee usually has to make all

arrangements for selecting a certified proctor

(former teacher, work colleague, librarian, etc.),

which will physically oversee the taking of a secured

test delivered on time to the testee computer.

Overall, this is a burdensome option with a lower

testing dependability, since there is higher

opportunity for collusion between a not-so-reputable

testee and a not-so-reputable proctor.

As aforementioned, each of these in-person

proctoring options requires much planning and

execution, involving relevant DE administrators,

proctors, learners, and teachers, and the appropriate

computer-administered testing infrastructure, to

solve what can turn out to be “a logistical

nightmare”. Any of these options, above and over

the, often repeated, efforts and costs, can also lead to

growing frustration among the distance learners

since these options contradict the core principles of

DE and its full realization.

2.3 Test Integrity

The prevalent assumption is that traditional proctors

and secure logins suffice to ensure honest computer-

administered testing (Carter, 2009). However, any

(testing) security system can be circumvented if the

will is there and the capabilities exist. In-person

proctored tests are also not foolproof. Proctors never

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?

do anything but keep honest testees or uncreative

ones honest. How does one make sure that no one

cheats in an auditorium attended by a large number

of testees? Or as another example, consider a testee

with a hidden pinhole camera on a shirt button that

broadcasts the screen content to an accomplice who

uses a cellphone to advise the testee that wears a

miniature wireless earphone concealed by long hair.

What should be possible is to inhibit testing integrity

risks, not fully prevent them (Graf, 2002; Weippl,

2005).

3 ANALYSIS OF DDT RISKS

Assuming no in-person proctors in DE frameworks

makes dependable distributed testing even tougher

to realize, but does not turn it into “mission

impossible”. The fact that (at least) three

commercial DDT systems are in use is an indication

of a need for such DE systems (Section 5). As part

of a literature survey (see References) and extensive

research leading to the proposed DoDoT reference

model (Section 4), we conducted a comprehensive

risk analysis of the cheating and fraud options

attemptable during tests. Following, we analyze

seven (types of) risks that were identified and

classified: testing mismanagement, impersonator,

PC misuse, forbidden stuff, accomplice, test leakage,

and “electronic warfare”.

3.1 Testing Mismanagement

Dependable distributed testing requires varied

services and tools for test creation, test data

management and archiving, test scheduling, test

delivery, test grading, test reporting and test

security. The potential for testing mismanagement is

huge. Fortunately, the following coupled DE

systems can handle this risk.

DE frameworks are usually based on a Learning

(Content) Management System (LMS/LCMS) – a

software application, usually web-based, for the

administration, documentation, tracking, and

reporting of e-learning programs, classroom and

online events, and educational content (Ellis, 2009).

The companion system, Testing Management

System (TMS), has similar functionalities but

specializes on the testing domain. A TMS can be

integrated into an LMS or be interconnected with

existing one.

The TMS simplifies the entire test management

process while adhering to privacy policies. It should

provide testing security for the entire lifecycle of a

test. Teachers can post tests from anywhere and

learners can take them anywhere with computerized

test delivery and full documentation of the testing

process. The TMS provides teachers with complete

control over and access to the test items, test results

and other test information. It can track testees'

progress throughout the test sessions, reducing the

tension and administrative burdens normally

associated with the test season. A TMS can also be

used to manage other assessments including

unproctored practice tests, quizzes and take-home

tests, but this is not the emphasis here.

To support DDT, a TMS should be rigorously

secured by use of leading-edge test security and

communication technologies or even be run on a

secure network. For example, it should use data

encryption technologies for test information, secure

protocols, firewall protection, etc.

In terms of distributed systems, such a TMS is a

“dependable system” where the dependability

concept covers important requirements such as

availability, reliability, safety, maintainability,

integrity, security and fault tolerance (Kopetz &

Verissimo, 1993). In a similar sense, the term used

here – “dependable distributed testing” – is a

generalization of the often used term of “secure

online testing”.

As aforementioned, there are many components

to a testing management system. The focus here is

on the test delivery aspects of a TMS. Commercial

TMSs include: Perception Secure (Questionmark,

n.d.), Respondus (Respondus, n.d.). Section 5

reviews three commercial DDT systems that are

TMS based: ProctorU (Pupilcity, n.d.), Online

Proctoring (KryterionOLP, n.d.), Remote Proctor

(Securexam, n.d.).

3.2 Impersonator

A serious DDT risk is an impersonator testee. How

to verify that a learner, signed up for a DE program,

is the same one taking the test if the testee is far

away? The identity check required when taking a

test can be realized by testee verification (Acxiom,

n.d.; Bailie & Jortberg, 2009; Schaefer, Barta &

Pavone, 2009; Weippl, 2005). Baseline verification

of testee identity in computer-administered testing

can be achieved by authenticating the username and

password during testee login.

The problem though is how secure are usernames

and passwords? Learners employing someone else to

take their test instead of them would willingly share

their username and password with the impersonator,

regardless of any rules or regulations. Similarly, we

cannot rely on common information about testees

(e.g., identification number, mailing address) or

even something supposedly only testees know but

ICE-B 2010 - International Conference on e-Business

that is a “shared secret” with the TMS (e.g.,

mother’s maiden name, favorite color). The problem

is that “what you know” is easily sharable. We also

cannot rely on some artefact the testees have (e.g.,

driver's license, smartcard, wearable RFID tag), i.e.,

on “what you have”. Note that we should also not

rely on the location of the testees (e.g., IP address,

GPS tracking device), i.e., “where you are”, so as

not to limit the testees in where they take the test.

So how can impersonation be prevented in DE

environments? One solution is to achieve testee

verification using biometric enrollment and

authentication processes (i.e., “what you are”).

There are several biometric verification technologies

that could be considered (Prabhakar, Pankanti &

Jain, 2003). Some are already in use in DE

frameworks: fingerprint verification (Securexam,

n.d.), face verification (Kryterion, n.d.; Securexam,

n.d.), signature verification (StudentPen, n.d.). As

part of the authentication process, there is a need to

decide when (at start, periodic or random) and how

to authenticate the testee and what are the

consequences of failure to authenticate. (These

processes are also important to assure non-

repudiation of test taking.)

Some researchers have coined the term

“behaviometrics” for behavioral biometrics such as

typing rhythms patterns or mouse movements (i.e.,

“what you do”), where this analysis can be done

continuously without interrupting or interfering with

user activities. For example, Webassessor

(Kryterion, n.d.) uses keystroke analysis for

recognizing unique typing styles. It measures the

pattern of keystroke rhythms of a user and develops

a unique biometric template of the user's typing

pattern for future authentication.

Another testee verification option is use of the

challenge questions methodology to inquire on

personal history that only the testee can answer for

(i.e., “what only you know”). For example, Acxiom

Student Identity (Acxiom, n.d.; Bailie & Jortberg,

2009) poses in real-time a few targeted questions

that challenge the testee and scores the answers.

Challenge questions can be based on third-party data

retrieved from large-scale public or private

databases, while maintaining privacy policies.

Strategies can be used to determine which challenge

questions to ask, how many questions, passing

thresholds, and red flags on fraud indicators. For

example, challenge questions could be asked at sign-

on, periodically or also at random. Unlike biometric

and behaviometric authentication, the challenge

questions methodology does not require pre-test

enrollment.

3.3 PC Misuse

Nowadays, most learners have their own personal

computer (PC) or can easily gain access to one for

testing purposes. We assume the testee uses a well-

equipped PC. For purposes like voice verification,

environment sounding, or audio chat, the PC

requires a microphone. In addition, speakers need be

connected to the PC unless the testee wears

headphones. For purposes like face verification,

environment watching, or video chat, the PC

requires a (preferably sound-equipped) webcam.

Moreover, for DE purposes, PCs need broadband

connections to access the Internet from anywhere,

anytime. We do not relate here to mobile learning

(m-learning) and its varied devices and connections.

With computer-administered open tests, the

testee can access local files, use PC applications or

browse the Web. Web browsers are usually designed

to be as open and flexible as possible. The focus

here though is on high-stakes closed tests.

Consequently, when delivering such tests, there is

need for more security than is available on a regular

PC or that a common Web browser provides

(Questionmark, n.d.).

However, with no in-person proctors, how can

the entire test session be secured to ensure the

testing integrity? For example, the testee could have

installed some software on the PC before the test for

the express purpose of defeating the test security. Or

as another example, there is always a temptation to

Google for help. The solution is to use PC lockdown

software to secure the testing environment and its

test contents. However, how can the lockdown

software be securely activated on the PC to ensure

its continued reliable operation? The solution is to

securely access and activate the PC lockdown

software via the TMS and keep them interoperating.

With lockdown software running on the PC, it

can be ensured that the test is only delivered via the

organization’s TMS, after successful biometric

enrollment and authentication processes. PC

lockdown software includes varied tools that enable

lockdown of the desktop, operating system, and Web

browser. The idea is to flexibly restrict or

completely disable testees' access to the

compromising functionalities of these resources.

Besides access to the test questions and use of

authorized files or tools (e.g., word processing,

spreadsheet analysis), the lockdown software

secures the testing PC by preventing print, capture,

copy, or access to other locally stored or Web

accessible files and programs.

PC Lockdown software usually disables (if not

restricts) the following functionalities:

• Cut/copy/paste of data to/from the testing

environment

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?

• Screen capture/printing functions

• Control/function keys/shortcuts

• Task/application start/access/switch

• Right-click menu options

• Menu options or icons activation

• Setting of PC date/time

• Pop-up windows

• Messaging, screen sharing, network monitoring.

In addition, browser lockdown usually disables (if

not restricts) the following functionalities:

• Search/surf the Web

• Browser menu and toolbar options with possible

exception for Back/Forward/Refresh/Stop

• HTML source code viewing

• Cache/store of pages in history/search listings.

Moreover, PC lockdown software can provide

for the following requirements:

• Automatically start at sign-on page of the

organization's TMS.

• Testees cannot commence a test until they are

provided with a special password by the TMS.

• The test questions are displayed in a full-screen

mode that cannot be minimized.

• Following test completion, all test-related files

are automatically submitted back to the TMS.

• Clearing of any cookies, caches, and temporary

files at test session end.

When a test is launched, the testee is locked up into

the testing environment (i.e., cannot suspend or exit

it) until the test is submitted back. The testing

environment should be able to withstand

(un)intentional actions or breakdowns, shutdowns or

restarts, and network disconnections, and be able to

recover the testing environment and contents. With

advanced technologies such as "software as a

service", Web services, virtualization and cloud

computing, such robust testing environments can be

nowadays supported.

As another option, "Remote Desktop" software

can be used to observe the testee screen and even

control the PC if deemed necessary by an online

proctor. It can also be used to assist the testee and

provide technical support if need be. The testee must

have given previous authority for remote access to

the online proctor.

Commercial PC lockdown software include:

Simpliciti (Simpliciti, n.d.), KioWare Lite

(KioWare, n.d.), Perception Secure (Questionmark,

n.d.), Respondus (Respondus, n.d.). There is also an

open-source Safe Exam Browser (SEB, n.d.).

3.4 Forbidden Stuff

In regular closed tests, the testee puts away all

forbidden stuff such as notes, reference sources,

textbooks, computers, cellphones and other devices

(King et al., 2009). But how can this restriction be

enforced in the absence of in-person proctors?

The solution is online monitoring to proctor the

testing environment to detect anything forbidden.

Online monitoring, using real-time audio and video

(A/V), can hear and watch the testees and their

surrounding environment, while they enroll,

authenticate and take the test on their PC. It can be

carried out by (live or random) online proctor

observation or by (continuous) test session recording

that consists of A/V, biometrics and other testing

event data that is sent to the TMS. Online proctors

can observe the testee using one-on-one

videoconferencing technologies. Test session

recording uses streaming technologies where the

A/V stream can also be viewed by an online proctor.

Computerized processes can detect aberrances and

use red flags to real-time alert the online proctor or

indicate need for post-test analysis.

However, with a common webcam, there is a

problem detecting forbidden material displayed at

the room back or hidden behind or below the PC.

We provide a solution for this in the next subsection.

3.5 Accomplice

Another serious DDT risk is a testee accomplice

(Eplion & Keefe, 2007). How can an accomplice be

prevented from aiding the testee? There is a need to

disallow the same accomplice means used in a

regular test such as exchange of notes, use of

cellphones, rendezvous at the toilets, etc. The

distance testee should be required to disconnect all

phones, not leave the room, not let another person

enter the room, etc.

Online monitoring can also be used to detect an

accomplice via a sound-equipped webcam.

However, a regular webcam isn't enough to ensure

testing integrity. For example, a video projector in

back of the room or a hidden (pinhole) camera in

front can project the screen content to an in-room

accomplice standing behind the PC. The accomplice

can in return signal the testee (say for multiple

choice questions), use sign language, or write

answers onto a raised (hand-held) whiteboard.

Asking the testee to physically pan the webcam

around the PC to check on the surroundings is an

awkward process, especially if it has to be repeated

during the test itself. A better solution is to use a

360

webcam. For example, the Securexam Remote

Proctor (SRP) unit (SecureExam, n.d.) encloses a

360

webcam. The unit features a mirrored sphere

suspended above a small pedestal. The sphere

reflects a deep 360

view around the testee, which

ICE-B 2010 - International Conference on e-Business

the webcam picks up. A 360

webcam can be used to

detect an accomplice, as well as use of forbidden

stuff, also behind and below the PC, and red flag

online monitoring that something might be awry. It

is hard to cheat without some suspicious sound or

motion being made by the testee or the accomplice.

Another countermeasure is to detect and obstruct

any (hidden pinhole) camera by use of an

inexpensive, simple laser pointer – not damaging to

humans – to zap (blind) the camera, thereby

generating a camera capture resistant environment

(Naimark, 2002). Similarly, a long video cable or

hidden camera can transmit the screen content to an

off-site accomplice who uses a cellphone to advise

the testee who wears a miniature wireless earphone.

The countermeasure is the use of cellular detectors

and jammers (Wollenhaupt, 2005).

Advanced recognition technologies could also be

put to use. For example, if the testee decides to play

music to relax while taking the test, voice/sound

recognition can disregard it. As another example,

image/object recognition can prevent a false alarm if

a pet suddenly wanders around the room or jumps on

the testee lap.

3.6 Test Leakage

An acute DDT risk is test leakage, especially for

same time tests (Eplion & Keefe, 2007). Although

testees can (try to) memorize (some of) the closed

test's content, at least they should not be able to

compromise it at test time. The use of a secure TMS

and PC lockdown software prevents many of the

options for test leakage. Restrictions enforced for the

accomplice risk also apply. Options to prevent test

leakage via an accomplice have also been covered.

However, in regular closed tests, scrawling is a

natural test activity that is allowed in the test book

(“blue book” in USA). Similarly, scrawling in

computer-administered testing can be allowed in a

digital notebook (“private workspace”) that is part of

the secured testing environment. Forbidden writing

to paper can be detected by online monitoring.

However, indirect recording of test questions by a

testee that seemingly just reads the questions aloud

is hard to detect (if the recording device is hidden),

so such systematic reading aloud should be

disallowed.

To hinder the leakage of a test, its questions and

answers, one or more of the following or similar

methods, collectively named here “Schemed

questioning”, could be considered:

• Use of test banks with random selection of

questions.

• Scrambling the order of questions and answers

(for multiple choice questions).

• Presenting just one question at a time.

• Setting time allotments for question answering

(timed test delivery).

3.7 “Electronic Warfare”

The concern here is with the physical protection of

the PC hardware and devices. How can the PC and

especially its devices such as the camera,

microphone and biometric devices be protected from

tampering? There is a need to detect lost A/V signals

or loss of feed quality. As another problem, the

webcam real-time A/V stream could be substituted

by a pre-recorded one.

The detection of this can be done by online

monitoring. However, to discourage more advanced

“electronic warfare”, i.e., disabling or circumventing

the capability of these devices, a separate hardware

proctoring unit that physically encloses the devices

can be used. To be easy to use, the unit should be

portable and pluggable, say via USB. The proctoring

unit has to be of course first acquired by the learner

before any testing activity. To ensure the testing

integrity, as part of an enrollment process, the unit

should be remotely registered to both the testee and

the PC used for test taking. The proctoring unit itself

should be physically tamperproof, and secured by

the TMS and PC software lockdown so as to red flag

any mishandling of the unit.

4 DoDoT REFERENCE MODEL

Based on the above DDT risk analysis, we introduce

the resultant DoDoT/RM (Dependable observable

Distributed online Testing Reference Model).

(Dodot stands for aunts in Hebrew – it is slang for

the traditional elderly female proctors.) DoDoT/RM

suggests an array of specific methods that can

answer the seven risks (see mapping in Table 1), so

as to enable the reliable computerization of online

proctoring in DDT systems. The paper's author is

unaware of any published similar attempt to define a

dependable distributed testing reference model.

The premises of DoDoT/RM are as follows. To

assure DDT, each and every one the seven (types of)

risks should be covered. Moreover, not just one, but

at least two of the proposed methods should be used

for risk mitigation. The idea is to make cheating and

fraud significantly hard – too expensive for the

testee to make it worthwhile taking the risks. For

example, for testee verification it is recommended to

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?

use two-factor authentication, where two different

factors (out of biometrics, behaviometrics and

challenge questions) are used in conjunction to

deliver a higher level of authentication. Similarly,

both online proctor observation and test session

recording can be used for more reliable monitoring.

However, since most of the suggested methods can

concurrently answer several risks, just a minimal

covering set of methods should be chosen.

The monitoring of the test session should be

online, not just offline, since the test environment

should be real-time observable and the testee be

made aware of it. However, online monitoring does

not necessarily require that a human proctor

continuously observe the testee. Since a human

proctor is an expensive resource, live observation

could be done at test launch, randomly, or if real-

time computerized red flags were raised. It also does

not have to be achieved via a one-on-one

videoconference. The A/V stream of the test session

recording received at the TMS can be observed by

an online proctor. Note also that there is no, or less,

need to repeat authentication processes if there is

test session recording that can be post-test analyzed.

However, how many proctors can be employed

concurrently? And of those, how many are capable

to diligently watch and listen to hours of testees A/V

during or after the test taking with the possibility in

mind that testees might cheat at some point?

Considering the human limitations in continuous

monitoring, the premise of DoDoT/RM is that

computerized processes are preferable in this regard

to human ones. Most, if not all, of the online proctor

observations can be replaced by computerized

processes (possibly adaptive AI agents) that can

deter and detect aberrant events and red flag them as

real-time alerts for the online proctor or as signals

indicating a need for post-test analysis.

The online proctor could then monitor a testee

just a few times during a test to observe if what is

being done matches the sounds and actions on the

testee PC. If there are red flags, the test session

recording can be later analyzed, preferably again by

computerized processes, which provides in addition

the recorded proof of any wrongdoing.

To inhibit the risks of accomplice and test

leakage, it is recommended to use technologies for

hidden devices obstruction such as camera zapping

and cellphone jammers. For sophisticated

computerized monitoring and post-test analysis, use

can be made of advanced recognition technologies

such as voice/sound and image/object recognition.

Post-test analysis of multiple tests can be used to

detect aberrant trends, for example, by data mining.

As aforementioned (Section 3.5), use of a common

webcam is not enough – only a 360

webcam

provides continuous view of the entire testee

surroundings. Moreover, having separate PC devices

such as 360

webcam, biometric devices, camera

zappers and cellphone jammers is problematic

(Section 3.7). Use of a separate proctoring unit to

enclose all the devices is required.

A cost-effectiveness analysis of DoDoT/RM still

needs to be carried out. However, it is assumed that

a covering set of its methods, and specifically the

separate proctoring unit, can be realized in a cost

effective way (subsidized by the organization or

priced at few hundred dollars overall per testee). For

such and further technical considerations refer to

(Acxiom, n.d.; Bailie & Jortberg, 2009; Foster,

2008; Jortberg, 2009). Clearly, when choosing such

a covering set, other relevant aspects such as social,

legal, ethical, economical, and psychological ones

need also be considered (Schaefer, 2009).

5 COMMERCIAL DDT SYSTEMS

For a feasibility check of DoDoT/RM we examine

its coverage by three commercial DDT systems

(Bailie & Jortberg, 2009; Foster, 2008): Pupilcity

ProctorU, Kryterion Online Proctoring, Securexam

Remote Proctor. Due to paper space constraints, the

review focus here is on their outstanding techniques

and services (more detailed information is on their

websites). Note also that no caught cheating rates are

made public by these companies. For each system,

we mark in Table 1 the methods that are in use by a

checkmark and those not in use by a dimmed x.

Subsection 5.4 compares these working DDT

systems regarding their DoDoT/RM coverage.

5.1 Pupilcity ProctorU

ProctorU (Pupilcity, n.d.) allows learners to securely

take tests online by using videoconferencing to

connect one-on-one with live, certified proctors and

follow their instructions. ProctorU was originally

developed for internal use at Andrew Jackson

University (AJU) and was later spun off into a

separate company, Pupilcity (Morgan, 2008).

ProctorU uses the Acxiom Identify-X technology for

a real-time online identity verification service that

uses the challenge questions methodology (Acxiom,

n.d.). This technology was piloted and put to test

several times at National American University

(ANU) (Bailie & Jortberg, 2009). ProctorU is

affiliated with 20 educational institutions.

ICE-B 2010 - International Conference on e-Business

Table 1: DDT risks and methods.

Risks Methods that can answer the seven risks

Pupilcity

ProctorU

Kryterion

OLP

Software

Secure SRP

Testing

Mismanagement

• Testing Management System

• Secure communication

Impersonator

• Biometric authentication

• Behaviometric authentication

• Challenge questions

• Online proctor observation

• Test session recording

PC Misuse

• PC Lockdown Software

• Remote Desktop Software

• Aberrance computerized red flags

Forbidden Stuff

• Online proctor observation

• Test session recording

• Aberrance computerized red flags

Accomplice

• Online proctor observation

• Test session recording

• Use of 360

webcam

• Hidden devices obstruction

• Advanced recognition technologies

Test Leakage

• PC Lockdown Software

• Online proctor observation

• Test session recording

• Use of 360

webcam

• Aberrance computerized red flags

• “Schemed questioning”

“Electronic Warfare”

• Detect lost A/V signal & feed quality

• Separate proctoring unit

Each testee first needs to individually schedule a test

at ProctorU's Online Proctoring Center. There are

four steps in taking the test:

1. Connect – ProctorU automatically connects the

testee to the online proctor.

2. Observe – proctor connects to testee's screen.

3. Prove identity – proctor watches the testee as

he/she authenticates identity.

4. Monitor – proctor observes testee taking test.

ProctorU uses the TokBox video chat and Remote

Desktop software. The online proctor watches the

testee via a webcam as he types away at the

keyboard, observes the screen, and listens for other

sounds in the testing environment. Aberrant actions

can be manually documented in the form of screen

captures and camera shots that are sent to the TMS.

ProctorU does not make use of the other methods

suggested by DoDoT/RM.

5.2 Kryterion Online Proctoring

Webassessor (Kryterion, n.d.) is a secured online

testing platform that provides a wide variety of

testing technologies and services. Kryterion

introduced Webassessor's Online Proctoring (OLP)

system (KryterionOLP, n.d.) in 2007. A series of

OLP pilots was carried out in conjunction with

World Campus, the online arm of the Pennsylvania

State University system (Shearer, Lehman, Hamaty

& Mattoon, 2009).

It uses the Akamai secure network to provide

robust testing delivery. OLP uses the Sentinel

Secure technologies to lockdown the PC and

conduct face verification and keystroke analysis for

testee enrollment and authentication. The testing

environment is continuously monitored and a testing

session recording is generated. OLP utilizes varied

security technologies and processes to deter and

detect aberrance during the testing session and alerts

online proctors when suspicious activities occur.

Kryterion employs certified, online proctors,

called KCOPS, who can remotely observe and listen

to as many as 50 testees at a time. They monitor a

live video feed of each testee in real-time. Previous

testing activity of testees is available to KCOPS for

detecting aberrant behavior. Testee's aberrant

behaviors or response time patterns (e.g., answering

a question too fast or too slow) alert the KCOPS.

OLP uses Real Time Data Forensics (RTDF)

technology to red flag unusual events.

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?

The KCOPS communicate with testees just via

drop down menu options. KCOPS can send

messages to the testee as necessary and take actions

such as pausing, suspending or stopping the test

based on testee behaviors and actions. For “Schemed

questioning”, testees receive questions one at a time

after scrambling the order of test questions.

5.3 Securexam Remote Proctor

Software Secure (SoftwareSecure, n.d.) provides a

suite of tools for secure online testing. The

Securexam Remote Proctor (SRP) (SecureExam,

n.d.) was an initiative of Troy University, which was

commercially developed by Software Secure. It has

been extensively experimented with and is long in

use at Troy University (Powers, 2006; Guess, 2008).

It was used for a pilot at a Small Southern Regional

University (Bedford, Gregg & Clinton, 2009). SRP

is affiliated with 15 educational institutions.

PlanetSSI is their web-based TMS. PC lockdown

software is comprised of the Securexam Student and

Securexam Browser. SRP uses biometric fingerprint

verification and face verification, real-time A/V

monitoring and recording of the testing session.

The SRP device is a separate proctoring unit that

connects to the testee’s PC as a USB plug-in. It

includes a groove for scanning fingerprints, and a

built-in 360

webcam. SRP interconnects with

Securexam Browser and Securexam Student. SRP

verifies the testee’s identity through the use of

finger-scan and face verification. Testees are

recorded during tests and the recorded stream can be

observed online. In addition, computerized filters

can detect any suspicious changes in sound or

motion, and red flag them for post-test analysis.

5.4 Discussion

Pupilcity ProctorU is a technically simple DDT

approach since it mainly depends on online proctor

observation and uses challenge questions for testee

verification (Table 1). Consequently, it has only

partial coverage of DoDoT/RM. ProctorU is more

oriented to individual test taking than to same time

testing. It does not have two-factor authentication

since there is no biometric/ and behaviometric

authentication; it relies solely on challenge

questions. It does not use PC lockdown software, do

test session recording or provide aberrance

computerized red flags. It also does not have a

separate proctoring unit having a 360

webcam.

Kryterion Online Proctoring is a technically rich

DDT approach with good coverage of DoDoT/RM

(Table 1). OLP has two-factor authentication:

biometric (face verification) and behaviometrics

(keystroke analysis). It is noteworthy that this

chosen two-factor authentication scheme requires no

biometric device. OLP supports both online proctor

observation and test session recording so any

required balance between them can be realized. It

has a varied set of computerized processes to real-

time red flag aberrant actions and behaviors.

However, it does not make use of a separate

proctoring unit having a 360

webcam.

SRP has excellent coverage of DoDoT/RM since

it also uses a separate proctoring unit with a 360

webcam (Table 1). However, it has only two-factor

biometric authentication: face and fingerprint

verification. It is noteworthy that SRP emphasizes

test session recording while relying less on online

proctor observation. It uses computerized processes

to red flag suspicious activities by recording A/V

clips for post-test analysis and aberrance proof.

Note that these systems could use more advanced

recognition technologies for sophisticated

computerization of processes to red flag aberrances.

They could also utilize hidden devices obstruction

(Section 4) to inhibit the associated risks. In any

case, a DDT system with full or fuller coverage of

DoDoT/RM has yet to be developed and deployed.

6 CONCLUSIONS

To increase the testing integrity of DE programs,

there is growing need to deliver DDT anytime,

anywhere. Wide deployment of DDT systems to

achieve testing integrity has long been overdue. The

introduced DoDoT/RM is based on a comprehensive

DDT risk analysis. The fact that three commercial

DDT systems are in use is an indication for their

need. Nowadays, due to technological advances and

improved methods, DDT systems can securely

deliver high-stakes tests worldwide. These DDT

systems utilize varied test security methods to deter

and detect cheating and fraud by testees.

However, DDT systems are not yet in use in

most DE frameworks. Moreover, these systems do

not yet provide full DoDoT/RM coverage to enable

reliable computerization of the online proctor – more

experimentation and comprehensive field use is still

needed. The vision of DoDoT/RM is the continued

pursuit and adaptation of new, innovative

technologies and methods to make dependable

distributed testing increasingly more computerized,

reliable, affordable and prevalent.

ACKNOWLEDGEMENTS

Thanks to Tomer Patron for research contributions.

ICE-B 2010 - International Conference on e-Business

REFERENCES

Acxiom (n.d.). Identity Verification to Support Academic

Integrity, Acxiom White Papers.

http://www.acxiom.com/StudentIdentity

Allen, I. E. & Seaman, J. (2010). Learning on Demand:

Online Education in the United States, 2009.

Newburyport, MA: The Sloan Consortium. http://

www.sloanconsortium.org/publications/survey/pdf/lea

rningondemand.pdf

Bailie, J. L. & Jortberg, M. A. (2009). Online Learner

Authentication: Verifying the Identity of Online Users.

MERLOT JOLT, 5(2), 197-207. http://

jolt.merlot.org/vol5no2/bailie_0609.pdf

Bedford, W., Gregg, J. & Clinton, S. (2009).

Implementing Technology to Prevent Online

Cheating: A Case Study at a Small Southern Regional

University (SSRU). MERLOT JOLT, 5(2), 230-238.

http://jolt.merlot.org/vol5no2/gregg_0609.pdf

Carter, D. (2009, July 10). ED OKs Proctors, Secure

Logins for Online Tests. eSchool News. http:/

/www.eschoolnews.com/2009/07/10/ed-oks-proctors-

secure-logins-for-online-tests-2

Ellis, R. K. (2009). Field Guide to Learning Management

Systems. ASTD Learning Circuits. http://

www.astd.org/NR/rdonlyres/12ECDB99-3B91-403E-

9B15-7E597444645D/23395/LMS_fieldguide_20091.pdf

Eplion, D. M. & Keefe, T. J. (2007). Practical Tips for

Preventing Cheating on Online Exams. Faculty Focus.

http://www.magnapubs.com/issues/magnapubs_ff/4_4

/news/600136-1.html.

Foster, A. L. (2008, July 25). New Systems Keep a Close

Eye on Online Students at Home. The Chronicle of Higher

Education, Information Technology, 54(46). http://

chronicle.com/article/New-Systems-Keep-a-Close-

Eye/22559

Graf, F. (2002). Providing Security for eLearning.

Computers & Graphics, 26(2), 355-365.doi:10.1016/

S0097-8493(02)00062-6

Guess, A. (2008, October 8). From Blue Books to Secure

Laptops. Inside Higher Ed. Retrieved Feb 3, 2010,

http://www.insidehighered.com/news/2008/10/08/tests

Heubert, J. P. & Hauser, R. M. (Eds.). (1999). High

Stakes: Testing for Tracking, Promotion, and

Graduation. National Research Council, Washington,

DC: The National Academies Press. http://

www.nap.edu/openbook.php?record_id=6336

Jortberg, M. A. (2009). Student Authentication Solution

Comparison. Online Student Identity blog. http://

mikejortberg.blogspot.com/2009/06/student authentic

cation-solution.html

King, C. G., Guyette, R.W. & Piotrowski, C. (2009).

Online Exams and Cheating: An Empirical Analysis of

Business Students’ Views, The Journal of Educators

Online, 6(1). Retrieved February 3, 2010, http://

www.thejeo.com/Archives/Volume6Number1/Kingeta

lpaper.pdf

KioWare (n.d.). KioWare Browser Lockdown Software.

www.kioware.com/default.aspx?source=kmshowcase

Kopetz, H. & Verissimo, P. (1993). Real Time and

Dependability Concepts, In Mullender, S. (Ed.),

Distributed Systems, Addison-Wesley, 411-446.

Kryterion (n.d.). Webassessor. www.kryteriononline.com

KryterionOLP (n.d.). Kryterion Online Proctoring.

http://www.kryteriononline.com/delivery_options

McCabe, D. L., Trevino., L. K. & Butterfield. K. D.

(2001). Cheating in Academic Institutions: A Decade

of Research. Ethics & Behavior, 11(3), 219-232.

http://www.swarthmore.edu/NatSci/cpurrin1/plagiaris

m/docs/McCabe_et_al.pdf

Morgan, J. (2008). Online Proctoring Perfected, Spun off

by Tech-savvy University. Retrieved February 3, 2010,

www.webwire.com/ViewPressRel.asp?aId=80502

Naimark, M. (2002). How to ZAP a Camera: Using Lasers

to Temporarily Neutralize Camera Sensors. http://

www.naimark.net/projects/zap/howto.html

Powers, E. (2006, June 2). Proctor 2.0. Inside Higher Ed.

www.insidehighered.com/news/2006/06/02/proctor

Prabhakar, S., Pankanti, S. & Jain A. K. (2003). Biometric

Recognition: Security and Privacy Concerns. IEEE

Security & Privacy, 1(2), 33-42. doi:10.1109/

MSECP.2003.1193209

Pupilcity (n.d.). Pupilcity ProctorU. www.proctoru.com

Questionmark (n.d.). Questionmark Perception Secure.

http://www.questionmark.com/us/perception/

Respondus (n.d). LockdownBroswer. www.respondus.com

Schaefer, T., Barta, M. & Pavone, T. (2009). Student

Identity Verification and the Higher Education

Opportunity Act: A Faculty Perspective. Intl. J. of

Instructional Tech. and Distance Learning, 6(8),

51-58. http://itdl.org/Journal/Aug_09/article05.htm

SEB (n.d.). SEB, www.safeexambrowser.org/

Securexam (n.d.). Securexam

Remote Proctor. http://

www.remoteproctor.com/SERP

Shearer, R., Lehman, E., Hamaty, P. & Mattoon, N.

(2009). Online Proctored Exams at a Distance: How

can you Help Assure Academic Integrity?. UCEA 94th

Annual Conference, Boston, Massachusetts.

Simonson, M. R., Smaldino, S. E., Albright, M. & Zvacek,

S. (2009). Teaching and Learning at a Distance:

Foundations of Distance Education. Allyn and Bacon.

Simpliciti (n.d.). Lockdown Solutions. www.simpliciti.biz

SoftwareSecure (n.d.). www.softwaresecure.com

StudentPen (n.d.). Bio-Pen. http://www.studentpen.com

VS1 (n.d.). Integrity in Education Online.

http://www.virtualstudent.com/?page_id=19

VS2 (n.d.). Accreditation in Online Degree Programs.

http://www.virtualstudent.com/?page_id=9

Weippl, E. R. (2005). Security in E-Learning. Advances in

Information Security, Springer, Vol. 16.

Wollenhaupt, G. (2005). How Cell Phone Jammers

Work, www.howstuffworks.com/cell-phone-jammer.

htm

DEPENDABLE DISTRIBUTED TESTING - Can the Online Proctor be Reliably Computerized?
