THE THREAT-VICTIM TABLE

A Security Prioritisation Framework For Diverse WLAN Network Topographies

Jonny Milliken and Alan Marshall

Department of Electrical & Electronic Engineering, Queens University Belfast, Northern Ireland, U.K.

Keywords: WLAN, 802.11, Intrusion Detection Systems, Network Security, Kismet.

Abstract: At present there is no common means for establishing the security performance of wireless local area

networks (WLANs) against threats. Furthermore, there has been little investigation into whether security

performance is reliant on network topography. Consequently this paper advocates that for a range of WLAN

infrastructure topographies (home, enterprise & open-access) there can be significant diversity in terms of

resources, equipment, users and most importantly security, which can in turn influence attack detection

performance. In order to demonstrate these detection differences, a novel framework for evaluating network

security performance (the Threat-Victim Table) is developed. This framework is applied to a range of

WLAN topographies using an open source (Kismet) Wireless Intrusion Detection System. Three Kismet

components are utilised; client, server and drone, to represent typical IDS deployment configurations for

these topographies. Analysis of the security capability of Kismet is derived as an example of this

framework, for qualifying network security performance against security threats and also to assess the

priority level of these vulnerabilities.

1 INTRODUCTION

Wireless network deployments can differ between

installations depending on the needs and resources

of the user or network. While this is evident in the

distinctions between the protocols of mesh or

infrastructure networks it is less evident within an

infrastructure network. In particular infrastructure

networks are often separated into home, enterprise &

open access scenarios (Microsoft Windows Help,

2007) even if the delimiting factors between them

have not been rigidly defined.

Each of these networks is subject to a multitude

of attacks, across many layers, with different attack

objectives and often competing defence strategies

(Mirkovic & Reiher, 2004). Due to this variation it

can be difficult to establish, for a given network or

user, what the key threats and defences needs to be.

In order to protect these networks many

strategies are employed such as firewalls, anti-virus

software and Intrusion Detection Systems (IDS).

IDSs can vary according to different networks

(Crainicu, 2008), or focus on different layers or

equipment. Currently the trend is towards Cross

Layer monitoring (Thamilarasu & Sridhar, 2007).

However at present there is no standardised

means of determining a network’s security

capabilities against threats or between security

systems (Ibrahim, et al., 2008). As a consequence

there has been little investigation into whether this

security performance is dependent on deployment

topography.

To address these issues this paper outlines a

framework for representing attack detection

capabilities. As a demonstration of this framework

an example is developed using an 802.11 WLAN

network and the Kismet layer 2 Wireless Intrusion

Detection System (WIDS) software. This example

demonstrates how the framework can be used to

evaluate the detection performance of an IDS across

different topographies. The results of this evaluation

advocate a case for considering infrastructure

networks as diverse as home, enterprise & open

access; using characteristics such as resource

availability, equipment, security and threat priority.

2 WLAN THREATS & KISMET

The convenience of 802.11 WLANs has led to their

widespread deployment; however as their

Milliken J. and Marshall A. (2010).

THE THREAT-VICTIM TABLE - A Security Prioritisation Framework For Diverse WLAN Network Topographies.

In Proceedings of the International Conference on Security and Cryptography, pages 37-42

DOI: 10.5220/0002935400370042

 SciTePress

deployment has expanded the security issues and the

threat of attacks on them increases (Turab &

Moldoveanu, 2009). These arise largely from the

insecurity of MAC management frames and the

unpredictability of the medium, meaning that it is

very difficult to distinguish attack heuristics from

common interference or legitimate activity.

As a result, WLAN security is an area of active

research and a number of specific threats have been

well studied and commented upon in the public

domain (BBC Watchdog, 2009). This growing

exposure qualifies 802.11 WLAN as a good

candidate for high level security visualisation and

suitable as a use case of the proposed framework.

Investigations in (Ref, 2009) & (Gill et al, 2006)

have determined that common attacks against

WLANs can be distilled into 4 categories:

 Client Denial of Service Attacks: Adversary

spoofs packets from the Client seeking to

deauthenticate or disassociate the user from

the Access Point (AP).

 Broadcast Denial of Service Attacks:

Adversary spoofs packets from the AP, then

broadcasts to all connected clients,

deauthenticating /disassociating them from the

AP.

 Masquerade Attacks: Adversary broadcasts

packets with forged headers advertising

themselves as a legitimate or open AP.

 WEP / WPA Attacks: Adversary attempts to

bypass the encryption by breaking the WEP /

WPA key and gaining access to the channel.

These are the attack categories that this paper

considers to be main threats against an 802.11

WLAN, although some are amalgamations of

several exploits. Any IDS that purports to defend

against such intrusions should recognise or detect

these attacks. This does not represent an attack

taxonomy but is an accurate categorisation.

2.1 Kismet

For the purposes of the research it is assumed that a

typical IDS needs to fulfil some critical criteria; free

& open source, modular and well known in the area.

However these criteria are difficult to realise in

practice due to the sparsity of WLAN IDS options.

For example, Snort, (Snort, 2010) the most prevalent

free IDS, has had the development of its wireless

extension (snort-wireless) mothballed since 2005.

The option chosen here is Kismet, one of the

foundation tools of wireless hacking, developed by

Mike Kershaw and released under GNU licence

(Kismet, 2010). The software provides passive,

wireless traffic sniffing and network discovery

features which are well documented and used within

the war-X-ing communities. Of particular benefit is

the modular structure of Kismet; with a Client,

Server and Drone architecture that has the flexibility

to represent any number of networks. In this sense it

fulfils all the original criteria for the investigation.

2.2 Kismet Detection Performance

A generic Kismet configuration was set up to

monitor a test network while each of the identified

WLAN attacks were carried out on either the AP or

additional clients connected to the AP. This Kismet

module contains all the detection thresholds and

signature details of the software and is an accurate

representation of its total abilities. Upon detection

the software brings up a text alert for the watching

admin to indicate that there is illegitimate or

suspicious activity and which MAC addresses are

associated with it. Kismet detection performance for

these threats is shown in Table 1 below.

Table 1: Kismet Detection Performance under threat from

WLAN specific intrusions.

Threat Detection Alerts

User DoS Yes

Deauth Flood & 10seconds

between data & deauth

Broadcast DoS Yes

Deauth Flood and

Broadcast Deauth

WEP Crack No None

WPA / WPA2 No None

Masquerade On action

Channel Changed / BSS

Timestamp

Although the individual alerts do not indicate the

attacks explicitly, it is possible to identify each

positive detection from a combination of alerts.

The results indicate that Kismet could not detect

either WEP or WPA channel encryption attacks,

however it was able to identify both DoS attacks and

distinguish between them depending on the alerts

generated. It was also able to identify a

masquerading adversary under certain conditions,

i.e. when an SSID impersonated another legitimate

AP or changed broadcast information.

Detection performance information such as the

kind provided here is not readily available or

verifiable for most IDS. This raises two issues:

 It is difficult to establish the detection

performance of an IDS.

 It is difficult to directly compare the

performance of IDSs against each other.

SECRYPT 2010 - International Conference on Security and Cryptography

Often some detection information is provided

but these tend to be inconsistent between

descriptions and incompatible across software. A

common framework for identifying the performance

of IDSs would alleviate these issues.

3 DETECTION PERFORMANCE

FRAMEWORK FOR IDS

In an environment with a multitude of attacks these

threats are usually distinct but not necessarily

immune to classification. There must be common

elements that connect them, the foremost of which

being the domain in which they operate. Since each

domain has a finite number of protocols and devices

operating within it there will naturally be an overlap

between processes and attacks.

One means of classifying these threats within a

framework is by identifying two parameters:

 What services are under threat? i.e. what is the

motivation of the adversary

 On what device does the service run? i.e. who

is the intended victim of the attack

“Devices” here indicate autonomous equipment

while a “service” is any facility provided to or by the

device. In a sense the devices are nodes in the

system while the services are the means in which

they connect to each other; it is evident that any

network can be made up of these primitives. If an

adversary was to attack both devices and services

this will not disrupt the classification, as these

actions can be decomposed into two individual

attacks being carried out simultaneously.

An attack on a service leaves devices free to

avail of other services while an attack on a device

allows the service to continue operating for others.

The challenge is to identify these devices and

services, given that the quantity and their nature can

differ. As an example use-case, this framework is

applied to the WLAN domain and is applied to

Kismet to exhibit its use in security applications.

3.1 802.11 WLAN Threat-Victim (T-V)

Detection Table

The attacks identified in Section II can be said to

threaten two distinct network services. Both DoS

attacks degrade or render unavailable the link that

exists between devices, while the Masquerade and

Encryption attacks can be said to threaten or

compromise the security of the link. A DoS attack

will stop communication between devices but the

security of data or access will remain unaffected,

while an adversary wishing to bypass security has no

vested interest in collapsing the link.

Considering the devices in the network, attacks

can be classified based on an adversary’s intended

victim. An adversary could be attacking either the

users of the network, or the network infrastructure

itself. An infrastructure device here will consist of

an AP which will likely service a collection of user

devices making links to or through it.

Having identified two device classes and two

services under threat we can develop these

parameters into a Threat – Victim Detection Table

focussed on WLANs, as in Table 2.

Table 2: WLAN Threat-Victim Description Table.

Victim

User Infrastructure

Threat

Link

C DoS B Dos

Security

Masquerade Encryption

Referencing the table we can conclude that in a

given deployment the adversary could seek to:

 Perform a DoS attack against a user link to

gain resource preference in a congested

channel by either delaying or discouraging the

victim from connecting.

 Perform a DoS attack against an

infrastructure link (e.g. the AP) as sabotage /

nuisance.

 Create a false identity to lure users to connect,

bypassing security in order to utilise phishing

or information theft.

 Attack and bypass encryption in order to gain

internet / document / resource access on an

otherwise restricted secure infrastructure.

3.2 Kismet T-V Table

Applying the T-V Table generated by this

framework to the IDS detection performance of

Kismet results in Table 3, a combination of Tables 1

& 2. Using colour coding to identify detection

performance leads to a three dimensional table,

where:

 The green area gives a concise summary of

Kismet detection performance.

 The orange area shows the fields which

require configuration or policy changes.

THE THREAT-VICTIM TABLE - A Security Prioritisation Framework For Diverse WLAN Network Topographies

 The red area represents the areas not covered

by Kismet and thus the threats that a system

that uses Kismet is still vulnerable to.

Table 3: Kismet WIDS Evaluation using T-V Tables.

Key

Green : Light

Orange : Stripe

Red: Dark

Victim

User Infrastructure

Threat

Link

C DoS B Dos

Security

Masquerade Encryption

The T-V table allows the framework to qualify

individual IDS performance; if there is more than

one IDS under consideration then it can also be used

for comparison. Depending on the areas that are

colour coded it is possible to evaluate the

performance of different IDSs and IDS

configurations.

Since no IDS exists which will perfectly detect

every attack at every layer, the network security

designer would have to make the choice between

different performance abilities in their IDS selection.

This decision creates the idea of threat prioritisation

for network security, i.e. given imperfect systems

how can one determine the best IDS or configuration

for the deployment?

4 NETWORK TOPOGRAPHIES

When choosing an IDS there needs to be a method

of determining the relative importance, or

prioritisation, for the network in question. The issue

is that this prioritisation will not be fixed in every

instance, each network is different and depending on

the goals of the deployment some threats may be

more dangerous than others.

The T-V table can be applied to solve this

problem, working not as an IDS evaluation tool but

as a security prioritisation tool. In order to justify

this assertion we must establish the characteristics of

different types of infrastructure networks and their

impact on security. Kismet is again used, leveraging

the modularity and flexibility of the software.

Each WLAN is unique in many respects such as

usage patterns, access methods and physical

resource availability, and ideally the WIDS should

be tailored to these characteristics. There are

generally three distinct WLAN topographies in

operation today: home, enterprise & open access.

These cover most WLAN deployments.

4.1 Kismet Architecture

The modularity of Kismet’s Client, Drone & Server

system is used to construct these networks. Each of

the components can be implemented in a number of

connected, distributed fashions within average user

equipment and / or APs. The key features of each

module are:

 Client: Front-end interactive GUI with

detection notification and network discovery.

Suitable as a stand-alone detector.

 Server: Similar to Client minus the front-end

GUI and network tracking.

 Drone: Distributable component which must

connect to either a Server or a Client to

provide detection and network discovery

information

4.2 WLAN Topographies

Each of the infrastructure topographies are different

in resource scarcity, structure and equipment

availability and so the optimal IDS deployment

architecture is expected to reflect this:

Table 4: Summary of Network Topography Differences.

Char Home Enterprise Open

Acces

s Info

Physical Always Always No

Network Always Often No

User

Behaviour

Number Low(<5) High(10+) Variable

Data Usage

High &

unstable

High &

stable

Low &

unstable

# Admins All users Med Low

Equipment

Coverage

Area

Low Med - High

Med –

Low

# APs / #

Channels

1 / 1 x / ≈ 3 1-2 / 1-2

Threats

Secure

Data?

Some Yes No

Outside

Network

Encrypt.

/ C & B

DoS

Encrypt. Masq.

Inside

Network

None Masq.

Masq.,

C DoS

Home: Within a common home network there

are two considerations: availability and reliability.

The network is likely to be constructed of various

portable or unreliable devices that might be turned

on or off arbitrarily. The only technological constant

here is the AP or router. A WIDS deployment in this

environment could only rely on the router for

reliability and guaranteed availability for a WLAN

SECRYPT 2010 - International Conference on Security and Cryptography

to exist. For Kismet, a Server component embedded

within the router is the optimal solution.

Enterprise: In an enterprise installation there

will be at least one administrator. In commercial

deployments the standard tactic is to employ an

independent network of distributed sensors so that

security is not dependent on non-admin personnel.

A WIDS deployment in this environment would

be optimally implemented with a Drone in available

APs connected to one or more administrator

terminals running the Client for monitoring. The

Client over Server permits monitoring connections

and within the bounds of the enterprise, the

connection to external networks can be restricted.

Open Access: A typical open access deployment

will often be one router with one PC available

locally for office or business admin tasks which is

reliably active during operating hours.

A WIDS deployment in this environment would

most likely benefit from a Drone module within the

router and a Server running on the background

office PC. The justification for the Server over the

Client is that network tracking and connection

monitoring / logging is turned off due to the greater

likelihood for neighbouring networks and the quasi-

legal aspect of eavesdropping these connections.

Varying the Kismet architecture over these

network topographies has shown that each

deployment will have different physical hardware

resources to utilise, and the WIDS implementation

must change accordingly.

4.3 T-V Table Prioritisation

Table 4 identifies the variation in threats with

differing network topography; the T-V table can

then be used to determine the associated threat

priorities. From this it is possible to create a new set

of tables where the colour coding is used to signify

the threat priority level. To demonstrate this, the

following TV tables can be derived for each of the

infrastructure topographies (the colour coding uses

blue to signify a HIGH priority and yellow to signify

a LOW priority):

Table 5: Home Network Security Prioritisation TV Table.

Key

Yellow : Light

Blue : Dark

Victim

User Infrastructure

Threat

Link

C DoS B Dos

Security

Masquerade Encryption

The Home network is chiefly concerned with threats

to the connection as well as the encryption integrity.

Theft of connection through subverting encryption

would be less of an issue yet the possibility of

accessing shared files is a danger. Since there will

typically be one router within the network and the

adversary effort required to accurately mimic the

network is high the danger of a Masquerade

intrusion is less of a concern.

Table 6: Enterprise Security Prioritisation TV Table.

Key

Yellow : Light

Blue : Dark

Victim

User Infrastructure

Threat

Link

C DoS B Dos

Security

Masquerade Encryption

The enterprise network is chiefly concerned with

security threats rather than connection threats; it

would be more damaging to have data stolen or

information gathered on employees than a temporary

loss of network access.

Table 7: Open Access Security Prioritisation TV Table.

Key

Yellow : Light

Blue : Dark

Victim

User Infrastructure

Threat

Link

C DoS B Dos

Security

Masquerade Encryption

Due to the customer orientated aspect of this

network, the major concern will be what threats or

attacks can disenfranchise the users of the network

and threaten their confidence in the service

provided. Thus link degradation or AP spoofing

would be chief concerns in this topography.

However a user gaining free access from breaking

encryption would be ranked lower since there should

be no shared files or resources to protect.

The result of these tables is the assertion that not

only are the networks distinct in equipment and

resources, they are also distinct in types of security

threats & security priorities as well. This threat

prioritisation is useful for practical security as well

as indicating that IDS research may need to address

the security implications of differing topologies.

5 RELATED & FUTURE WORK

There is no research work to date which develops a

network security prioritisation framework for

THE THREAT-VICTIM TABLE - A Security Prioritisation Framework For Diverse WLAN Network Topographies

WLANs. (Prasad, 2007) proposes a threat

identification methodology applied to a Personal

Network (PN), however the approach relies on the

user having expert knowledge and assumes that all

vulnerabilities will be identified through

brainstorming.

Another framework taking a similar approach is

(Hernan et al, 2007). The procedure takes

structurally similar steps but arrives at a table

(Microsoft SDL Blog, 2007) which works more as a

guide to a set of bins in which to store brainstorming

ideas. It is also primarily for software development

rather than at a network infrastructure level.

Future work will seek to enhance the T-V table

to include additional factors such as bandwidth,

latency, routing devices, network elements etc.

6 CONCLUSIONS

At present there is no coherent means of

representing the detection performance of IDS

systems for wireless area networks (Ibrahim, et al.,

2008), making selection of IDS for these networks a

problem. This paper presents a novel evaluation

framework which provides the capability to evaluate

and compare the attack detection of a range of

network topographies. Such performance evaluation

tools will aid the proliferation of IDS as well as help

evaluate network threats.

It is demonstrated that there is a difference in

attributes for network topographies even within

infrastructure environments. This difference exists in

resource usage and security, two important tenets of

an Intrusion Detection System. This highlights the

requirement that future IDS research and security

tactics need to adapt to network deployment

strategies in both a technology and logistics sense

(e.g. resources, equipment, users).

Both issues are addressed by the development of

a novel Threat-Victim (T-V) Detection Table

framework which provides rapid, visual detection

performance evaluation and comparison of relative

IDS performance. A number of typical WLAN

topographies are explored using a well-known open

source IDS (Kismet). Kismet’s modularity is useful

in research scenarios and utilising this it is shown

that any WIDS needs to be tailored according to the

topography of the network deployment. The T-V

tables can also be used to allow network security

designers to choose the most appropriate IDS for

their network depending on its detection features,

their own prioritisation and on the topography of the

network.

REFERENCES

BBC Watchdog, 2009. Is your Wifi Secure? BBC Online,

[online] 29 October. Available at http://

www.bbc.co.uk/blogs/watchdog/2009/10/wifi_hot_spo

ts_not_secure.html [accessed 30 October 2009]

Crainicu, B., 2008. Wireless LAN Security Mechanisms at

the Enterprise and Home Level. Novel Algorithms and

Techniques in Telecommunications, Automation and

Industrial Electronics, pp. 306-310

Gill, R., et al, 2006. Specification-Based Intrusion

Detection in WLANs. 22

Annual Computer Security

Applications Conference (ACSAC’06).

Hernan, S et al, 2007. Uncover Security Design Flaws

Using The STRIDE Approach[online]. Available at

http://msdn.microsoft.com/en/gb/magazine/cc163519.

aspx

Ibrahim, T., et al, 2008. Assessing the challenges of

Intrusion Detection Systems,Available at: http://

www.intrusiononline.net/ docs/cisnrAC_IDS.pdf

[Accessed 15 November 2009]

Kershaw, M., 2010. Kismet [online]. Available at: http://

www.kismetwireless.net/

Microsoft SDL Blog. 2007. STRIDE Chart. [online].

Available at http://blogs.msdn.com/sdl/archive/

2007/09/11/ stride-chart.aspx

Microsoft Windows Help. 2007. Choosing a Network

Location. [online]. Available at http://windows.

microsoft.com/en-us/windows-vista/Choosing-a-

network-location

Ref, 2009. Removed

Mirkovic, J., Reiher, P., 2004. A Taxonomy of DDoS

Attack and DDoS Defence Mechanisms. ACM

SIGCOMM Computer Communication Review (34/2)

pp.39-53

Prasad, N. R., 2007. Threat Model Framework and

Methodology for Personal Networks (PNs). In

Communication Systems Software and Middleware,

2007 (COMSWARE 2007).

Snort IDS, 2010. [online] Available at: http://

www.snort.org/

Thamilarasu, G., Sridhar, R., 2007. Exploring Cross-layer

techniques for Security: Challenges and Opportunities

in Wireless Networks. In MILCOM 2007.

Turab, N., Moldoveanu, F., 2009. A Comparison Between

Wireless LAN Security Protocols. [online] University

Politehnica of Bucharest. Available at: http://www.

scientificbulletin.upb.ro/rev_docs/arhiva/full7970.pdf

SECRYPT 2010 - International Conference on Security and Cryptography
