A FRAMEWORK FOR TESTING SOA APPLICATIONS

Samia Oussena

, Balbir Barn

and Dan Sparks

Thames Valley University, U.K.

Middlesex University, U.K.

Keywords: Testing, Test-driven Development, Distributed Architecture, Framework, SOA, BPEL, WSDL, XML.

Abstract: Test driven development (TDD) is emerging as one of the most successful developer productivity aids. A

key feature of TDD is the construction of a robust test harness before implementing code, enabling the

creation of a “virtual contract”. The semantics of that contract are the fully enumerated set of test conditions

for the system under construction. Service Oriented Architecture (SOA) raises a particular challenge in that

there exists no unified method for testing an SOA application, which not only looks at individual artefact of

the SOA application but also the complete application. Further, in SOA, the flexibility and connectivity

provided by loosely coupled services increases both the opportunity for errors and the complexity of the

testing. Given this situation, this paper describes a unified test-driven approach to a ground-up

implementation of an SOA application where testing is seen as central to the development process. The

paper proposes a framework that focuses on process-, configuration-, and service-oriented testing that

provides relatively complete and flexible viewpoints of an SOA artefact’s health. A critical evaluation of

our approach is presented in the context of the development of SOA applications that support core Higher

Education business processes.

1 INTRODUCTION

SOA is gaining industry-wide acceptance and usage.

Typically a system developed in SOA will consist of

a collection of finer grained services put together

through an orchestration. The services themselves

may consist of even more finely-grained web

services. A number of client applications will be

developed to consume the service and interact with

the end user, for example; a web portal, web

application or a fragment of a workflow application.

This loose coupling of SOA services presents

additional challenges to testing.

SOA’s architecture of loosely coupled services

provides increased opportunities for errors and

therefore the complexity of the testing increases

dramatically. Execution patterns are dynamic,

distributed, and by their nature are not easily

repeatable. The orchestration of services within an

SOA system is itself also dynamic i.e. the selection

of services can be done at the run time and therefore

adds further complexity to the testing process.

Few practical attempts have been made to

address the problem of SOA testing. Those that have

been made have mainly addressed Web Service

functionality. Tsai et al (Tsai 2002) proposed

extensions to WSDL to allow for the testing of the

services described by the use of invocation

sequences, input-output dependencies, hierarchical

functional description, and sequence specification.

Other approaches have included multi-phase,

iterative testing (Tsai 2004, Bloomberg 2002), and

so-called rapid testing, involving regression testing,

pattern verification, and group testing (Onoma 98,

Tsai 2003). Lenz et al have proposed a model driven

testing to SOA application, but here as well the main

focus in on the web services (Lenz 2007).

All these investigations, however, have taken a

more focussed approach to individual parts of the

SOA, or even components within those parts, with a

particular focus on the Web Service interface. It is

recognised that there are many parts to the testing of

a Web Service; however, this is still only concerned

with the web services, and each service is only

looked at in isolation. Integration testing is rarely

considered. Orchestrations and how services are

integrated to provide the component parts of an

application should also be taken into account. To

develop a comprehensive testing solution, one must

take into consideration all aspects of SOA. To fail to

Oussena S., Barn B. and Sparks D. (2009).

A FRAMEWORK FOR TESTING SOA APPLICATIONS.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 53-60

DOI: 10.5220/0002257200530060

 SciTePress

consider deployment variables, for instance, is to

only partially address the issues involved even in

testing only a Web Service, and as such we believe

that only a holistic approach can achieve this. Tool

vendors, such as Parasoft and Empirix (Parsoft

2009, Empirix 2009) have started to address the

issues of SOA testing. Persisting problems of

solutions proposed by tool vendors are, in our

opinion, either a lack of integration with open-

source IDEs, or too much integration; tying

developers into one IDE for all development work.

Although for example, Parasoft’s approach is

relatively exhaustive, again there is a focus on Web

Service testing only; BPEL testing is not covered.

The reason may be that a lack of maturity of the

technology coupled with the problems associated

with working with constantly evolving standards and

protocols make testing tool development difficult.

In this paper, we propose a testing framework for

SOA that will provide a holistic approach.

Successful testing needs to have as near to total

coverage as possible of all the artefacts that are

produced in the development of an SOA system.

This framework will be the basis for combined

automated and methodological support in testing

such a system.

Most recent development trends incorporate

some level of unit testing and test first approaches.

Therefore any framework would need to be aligned

with the test-driven development process. The

framework will need to make testing an integral part

of the development. One reason that test-driven

development process has become so widely accepted

is that in addition to the natural integration of the

development and testing, there is provision for

automation support for unit testing. With continuous

integration, as requested by most agile processes

(Beck 2000, Cockburn 2001), automation of unit

tests is a must. The framework has therefore to

provide and identify the expected level of

automation support

2 THE AGILE APPROACH TO

TESTING

Traditionally testing has been done separately from

the development work, by a separate team. Systems

today tend to be developed using iterative

development methodologies, which make the

traditional model of testing costly, and increasingly

ineffective. Agile approaches to testing have strong

links with SOA, coming, as they do, from a heavily

OO-influenced sector. The separate services that the

SOA artefact utilises can be viewed in much the

same way as a software package, module, or

component, and consequently, we feel, should reap

the same benefits from an agile approach. It is

interesting to note how well the technique of test-

first coding, now considered to belong to the realm

of smaller projects using agile development

methods, lends itself to an SOA approach. The most

likely reason for this is that although the domain is a

vast canvas, breaking the domain into service

components implies a modular approach, similar to a

number of smaller projects. The overall management

of the project can only be undertaken with

safeguards, and in particular tests, in place at the

service level.

Such a comprehensive approach to testing may

not be a problem in what is viewed as the ‘target

audience’ for SOA. Much discussion about SOA

concerns the reuse and exposure of Legacy

applications as services. These are systems which

already work. The difficulty in SOA-enabling them

is in wrapping and exposing them via a WSDL

specification, and then orchestrating that via BPEL.

Hopefully, the general programming logic has been

cleared of most (if not all) bugs.

Developing an SOA application from the ground

up, there are many more factors to consider, and

therefore a more comprehensive approach to testing

is required. It is vital to monitor and constantly

assess the health of all newly written artefacts.

Presumably in any reasonably-sized development

there will be teams taking responsibility for different

services, for the exposure via WSDL, and for the

orchestration. Even so, those teams need to ensure

they have testing that covers the entire range of

functionality for their code. All these parts feed into

the orchestration process to identify the bugs with a

minimum of effort and frustration.

Test design, where possible, needs to be

addressed at an early a stage as possible; ideally at

the modelling stage. The automation of some of the

development activities means that it is not always

possible to do this. For example, WSDL creation

must wait until XML schemas have been generated.

This means it is not possible to create full test cases

at the modelling stage.

In summary, there is a parallel between SOA

development and agile development processes. The

need for comprehensive testing in the development

of ground-up web services, should, we feel, be able

to be adequately addressed by an agile, unit-test-

driven approach. This approach, however, must be

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

integrated with the SOA development process to

take into account the automation of artefact creation.

3 REQUIREMENTS FOR A SOA

TESTING FRAMEWORK

The framework has been developed as a result of the

difficulty we faced when developing an SOA

artefact (Barn 2006) and was then refined and used

in two further projects. We have so far identified a

number of requirements due to the nature of SOA

applications. These are:

R1) Our development using SOA involved working

with constantly evolving standards and

protocols. Our framework will therefore require

a modular approach, as well as implementing

different levels of abstraction.

R2) In order to be integrated in a test-driven

development process, the framework needs to

provide and identify the expected level of

automation support.

In the rest of this section we discuss the

requirements of the framework with reference to the

problems we have encountered, and needs we have

identified during our development. We will examine

the testing activities from two perspectives; the

development of the application, and the application

deployment.

3.1 Development Requirements

It is most likely that a variety of Integrated

Development Environments (IDE) will be used. The

different artefacts that make up an SOA application

can often require a specific IDE. In our case, we

needed to work with XML Schema, BPMN

(Business process management notation) and BPEL

processes, WSDL creation and code generation from

the WSDL and Database development

R3) The framework needs to accommodate all the

artefacts (or components) that will be a part of

the SOA application’s development and

deployment.

To successfully deploy our BPEL processes, we

had to use an IDE that supported deployment to the

Oracle BPEL Process Manager (Juric 2006), which

in this case, was Oracle JDeveloper in two projects.

In another project we used Intalio Designer and

Intalio Server of the development and the

deployment of BPMN processes (Barn 2008).

Similarly, we needed to support UML and XML

Schema generation and WSDL to Java code

generation. These capabilities were provided by

IBM Rational Software Architect (Quatrani 2006).

The framework therefore needs to address the fact

that different and indeed incompatible IDEs will be

required during the development.

R4) The design of the framework requires an IDE-

independent approach to be taken. This includes

the automation of test, and test data, creation,

which needs to reach a level congruent with that

expected by developers.

3.2 Deployment Requirements

With distributed elements, deployment of services

will almost certainly not be uniform for an SOA

artefact. As with IDEs, certain services will require

specific server environments. All our web services

have been deployed to a Tomcat 5.5 application

server, running behind an Apache 1.3 web server

(Tomcat 2009), using the mod_jk Tomcat/Apache

module (Mod_jk 2009) as a connector between the

two servers. The advantage of this approach is that

the Apache server routes all requests for web

services to the appropriate application server. It is

consequently possible to change the port or

application server that contains any or all web

services without any client needing to be aware of

such a change. The successful deployment of a web

service in this environment relies not only on

correctness of the component but also each server’s

correct configuration.

R5) The configuration of server environments

therefore also needs to be factored into our

testing framework.

Another key consideration when deploying an

application is the classloading. This is typically done

by either adjusting the server’s startup classpath, or

putting the shared libraries in a special library

directory. Our database was an implementation of

Oracle 10g XML DB (Scardina 2004). The services

that used this needed specific libraries – in addition

to standard JDBC libraries, they needed the XML

DB libraries installed in their server environment

R6) The server’s classpath and libraries

configuration needs consideration within the

testing framework.

Physical deployment of the application

components to the servers might be server specific.

For example, developed BPEL processes are

deployed to local instances of the Oracle BPEL

A FRAMEWORK FOR TESTING SOA APPLICATIONS

Process Manager. This provides a web interface

similar to Tomcat’s where a BPEL suitcase (also

known as a suitecase) JAR (Java Archive) file

containing the packaged BPEL specification and

related code can be uploaded. We found though that

this method of deployment did not deploy the

necessary JSP files needed for User Tasks; this was

achievable by deploying directly from Oracle’s

JDeveloper, which became our IDE of choice for

BPEL development. This was similar for the Intalio

XForms.

R7) Because technologies may require certain

environments, we must be sure to accommodate

them all. Our testing framework must have a

flexible, environment-independent approach.

Having distributed resources and components

require that we test the accessibility of each resource

used by a number of artefacts, including WSDL,

database and BPEL. In our case the schema resides

on the same server as our services, however, this is

not to say that they could not be deployed on a

different server, or servers. Ensuring the availability

of schema is another element of the framework’s

deployment requirements.

As another example, most business processes

will require some human intervention, which is

represented in BPEL by User Tasks, presented to

users in the form of a workflow application.

Supposedly this could be deployed to any server,

though in our case we made use of the Oracle

workflow application provided by the same server

that hosted our BPEL processes.

R8) The accessibility of resources (particularly

where distributed) needs to factored into the

testing framework.

Even in this relatively simple scenario, the

deployment requirements are not trivial. If not taken

care of as seriously as the development

requirements, a simple problem in one part of the

deployment configuration may jeopardize the

reliability of the entire application.

We next present elements of the proposed

framework. Although we present in a pseudo-

chronological order, it is important to take into

account that the testing is iterative, for each stage,

and also for the entire process.

4 THE FRAMEWORK

We have identified that there are a number of testing

requirements that need to be considered to achieve

our holistic testing approach. We now present our

proposed framework (Figure 1) as a series of

elements that can meet these requirements.

Our framework contains the identified testing

elements, contextualised to facilitate understanding

and cohesion of the test-driven development

process. Each element appears individually, but is

also grouped with other elements by criteria

modelled on that used in the Zachman Framework

(Zachaman). Elements are grouped by different

architectural areas. These areas typically require

different and specific types of testing such as data,

function and user interaction.

Elements are further contextualised by their

place within the development lifecycle. While the

process in the framework seems largely linear, we

have allowed for iterations within the process, as

well as the possibility of iterations of the entire

process. The testing ‘checkpoints’, or phases, are

pre-implementation, post-implementation and post-

deployment. These contain the testing elements of

the framework that drive the development of the

next stage. In this way, we lay a foundation for a

comprehensive test-driven SOA development

process.

We show in our diagram that Method Unit Test

Cases should take place at the pre-implementation

phase. They are directly informed by the outputs of

the conceptual and logical phases (in this case a

service or component model), and they in turn drive

the development of the physical phase’s artefacts,

such as service or interface implementation, WSDL,

and generated code. We have also made it clear

within the framework that the purpose of these

particular tests is to meet the functional

requirements of the project.

Figure 1: Framework for testing SOA applications.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

Our identified user interaction configuration

tests, on the other hand, need to be written at pre-

deployment testing status, and this time the

framework indicates that these tests relate to the

project’s user interaction requirements.

Each test element can be similarly interpreted.

The framework provides a clear indication of the

purpose, and function of each test element, and from

this information it will be possible to identify and

allocate resources to, and responsibility for, each

particular area of testing.

4.1 WEB Service Testing

Unit tests were written for each service, testing the

exposed web service methods, but with more of a

focus on internal functionality. Appendix 1 shows a

fragment of code from such a test. This meant that

any changes to code on a service could easily be

checked. On identification of a problem, the

involved services can have their unit tests run

against their code; if the tests pass, the problem is

elsewhere. If a test fails, the problem is easily

located and solved.

Client 'applications' were also developed for each

service, this time with a focus on the exposed

methods of the web service. These applications

could be viewed as 'external test suites', and, when

packaged into an overall test with the internal web

service unit tests, provide a robust and helpful

method of testing a web service. This approach has

been taken further, by integrating the ‘client’ tests

with the WSDL. A schema for a collection of test

results is used to return test results via a WSDL

method. By extending the JUnit framework [JUnit],

we can run the unit tests built for the service whilst

in its deployment environment.

4.2 BPEL Testing

The Oracle BPEL Process Manager provides a

browser-based tool for testing BPEL processes. It is

possible to run individual tests of a process, or to run

a 'stress test', with varying data, to see how the

process holds up under demand. Feedback from the

tests comes in summaries of process states, visual

flows of the processes, identifying places where the

process has failed, and full audit trails of XML

messages and data objects as they are created and

passed back and forth.

This tool is very useful, but not without

limitations. As our scenarios contain User Tasks, the

processes tested need user interaction. From a

testing perspective this is problematic: not only is it

time consuming to have a tester physically involved,

there is also the greatly increased risk of user error.

A mistyped field can have serious consequences on

the output of a given test, resulting in more time lost

to testing, or the false identification of a bug that

does not exist.

During our development process, we examined

the Oracle BPEL API and the Intalio BPEL API

with the aim of mechanising as many of our test

cases as possible. This had the advantage of being

less time consuming, and more error-free than

human-operated testing. The approach was quite

primitive, largely due to the amount of time and

effort needed to ensure that sufficient test data was

in place, and the time and effort required to maintain

the integrity of that test data. We did not invest too

much time as we were aware that in the latest release

of the Oracle Business Process Manager (10.1.3) a

BPEL test framework would be available. This now

includes the automation of some process unit testing.

4.2.1 BPEL Test Framework

The newest version of the Oracle Business Process

Manager (10.1.3) contains the BPEL test

framework. It is possible to build an entire test suite

within JBuilder. The results of these tests can be

created in JUnit format, useful if other

parts of an

SOA application’s testing utilises JUnit.

Creating a test suite is, on a basic level, as simple

as following a click-through wizard. In practice, it is

a little more complicated. External service

interactions are spoofed by the Process Manager

when running the tests, so it is important to ensure

there have been adequate ‘dummy responses’

created for each interaction with an external service.

Of course, these can be created to provide different

responses depending on the data you want to start

the test with.

Advantages to this approach are that the only

thing being tested is the process itself – there is no

confusion over an ambiguous problem being the

fault of either a process or an external service. The

logic of the process can be tested thoroughly without

having to consider any influence from anything not

contained within the BPEL code.

Disadvantages are that the data that one uses to

start a test might not produce anything other than an

error from an external service – the disconnect

between external services and the process being

tested means that it might be the case that the

process is being tested to completion with

completely useless data. Similarly, testing in this

way does not take into consideration such things as

A FRAMEWORK FOR TESTING SOA APPLICATIONS

invoking the correct service method, or even the

correct service – such environmental issues are not

examined by this method and will need to be

explored elsewhere.

The BPEL Process Manager also provides a

means for automated load testing of a process. The

tester completes a small browser-based form

specifying maximum concurrent threads, number of

loops (repetitions of the concurrent thread

execution), and the delay between each invocation,

in milliseconds. Once run, detailed results of the

load test are available. If this interface were to be

extended it could provide a more comprehensive

collection of testing approaches; for example, the

sending of a range of input parameters, rather than

just one. The recently released test framework for

BPEL Process Manager builds upon this

functionality. It is still not perfect – there are issues

where complex processes that loop may fail to

generate successful test cases. The testing is

constantly being refined, however, and if it

continues to do so, BPEL testing will become much

easier, and a great deal less time-consuming.

4.3 UI Testing

Workflow applications, like most web applications,

follow the Model View Controller (MVC) approach.

Our views were programmed as Java Server Pages

(JSPs) and Xforms, The UI testing therefore did not

focus on logical behaviour, instead testing code

which accessed and displayed attributes, loop

iterations for dynamic creation of user input forms

and the dynamic, event-based generation of pages.

At this point, we can use HttpUnit [Httpunit] or a

similar tool to validate HTML pages. Further testing

of web-based interaction can be done through such

applications as AutomationAnywhere (Automation

Anywhere), which allows for the recording and

subsequent replay of browser-based interaction. This

kind of automation software is sparse on detail when

recording the results of testing, and should be used

in conjunction with logging software in order to

identify causes of failure. A detailed description of

web application testing is beyond the scope of this

paper. There are many sources including (Dallaway,

Link 2003) which discuss unit testing of web

applications.

4.4 Database Testing

Persistency plays an important role in most

applications and this is still true for SOA

applications. The creation of unit tests for

persistence mechanisms is often accompanied by

major problems, because both the execution speed

and the large number of dependencies make the

testing approach difficult. It is therefore important

to adopt an architecture that will not hinder testing;

i.e. the persistency layer should not have

unnecessary external dependencies and the ones that

remain should easily be replicated in a test

environment. Our persistency layer implementation

has first followed the DAO pattern (DAO) and later

used Hibernate framework (Hibernate), which are

particularly good at eliminating unnecessary

dependencies.

The other step that we have taken in our testing

is to isolate each test by clearing the database before

each test is run. This has been facilitated by the use

of Dbunit framework (DBunit). Dbunit is an

extension of JUnit that helps simplify testing

database applications. Within this framework the

database can be created and populated from an XML

file, making it easy to manage the test environment.

Here as well a full detailed discussion of

persistency unit testing is beyond the scope of this

paper. There are many sources including (DBUnit,

Freeman) which discuss unit testing the persistency

layer.

4.5 Validation

Any schema or WSDL can also be checked for well-

formedness, however, this will ideally be integrated

within the development environment(s), and

additionally automated. This will ensure that each

time a change is made, any error is identified and a

chance is given to quickly and easily address it. This

is similar to functionality provided by many IDEs,

where code is constantly compiled, and errors are

pointed out to the developer at source.

4.6 Deployment Configuration Testing

While testing of artefacts within their deployed

environment can give an overall picture of

application health, the isolation of the deployment

environment is extremely useful as it allows for

focused examination of deployment issues. Testing

should always identify problems quickly and

efficiently. Assessing deployment configurations

lets us quickly spot problems, or otherwise disregard

the environment as being a cause of a problem. This

has the beneficial effect of narrowing our

investigation scope and guiding us to the cause of

the fault we are investigating.

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

Within an SOA artefact, there are a great deal of

factors to be tested relating to deployment. We have

already identified these in our requirements analysis,

and here we provide our approaches to the testing of

two of these; the need for a server to contain the

required libraries, and resource naming and lookup.

4.6.1 Library Configuration Testing

The machines running certain servers, database

implementations, and services, require specific

libraries. These libraries are in turn required by

specific server such as database, or service

implementations, though any combination of these

may share libraries. While this may appear to be an

administrative nightmare, the unit test approach

provides a simple and manageable solution.

For each library, tests can be written that call a

method or methods from the library. If these tests

pass, it can be assumed that the library is installed

correctly in the environment. Each test can then

integrated into a deployment test suite for a specific

server, database, or service. This may provide some

redundancy, but in this case this is not necessarily a

bad thing, as it removes the burden of test

reconfiguration with each deployment of a new

service, database or server to an environment.

Instead, we can provide specific test cases which can

be combined as required, allowing for a greater

degree of flexibility.

The automation of this approach, for example

some kind of linking between an artefact’s classpath

and the deployment tests required for it, will add

more value to the process in terms of flexibility, ease

of use, and reduced test configuration and

implementation time. We intend to explore this

further in future work.

4.6.2 Resource Naming and Lookup

Configuration Testing

We have identified that, in addition to library

requirements, deployment environment testing needs

to address correct resource naming and lookup.

Similarly to library testing, resource testing is

specific to the environment as a whole, and to

individual service, database, and server

implementations, and again, a unit testing approach

can achieve the flexible and comprehensive testing

solution required.

Again, the approach adopted for library testing

can be used. This approach is modular not only in

terms of one aspect of the deployment testing, be it

library or resource configuration testing, but also for

the deployment testing overall. The test suites, in

addition, can be combined to provide views of

overall artefact deployment health, and again these

views can be combined with previously discussed

approaches to provide the needed holistic, multi-

layered, multi view solution to SOA testing.

5 CONCLUSIONS

Testing methods for SOA are underdeveloped. In

this paper, we have proposed a unified approach to

SOA testing. It is our opinion that such a testing

framework could have a significant impact on the

SOA development community.

Providing a framework with divisional foci

allows for analysis at varying levels. Because we

can take different views, it is possible to quickly

identify and isolate causes of problems. This also

helps the development process; the test cases

provide requirements, which inform the

development of artefacts. The integration of

artefacts is supported because tests for each artefact

already exist, and can be used in varying

combinations for different integrations.

Additionally, the iterative SOA development process

is made easier.

Recognising that we have only looked at the

functionality of SOA applications, our future work

will consider expanding the framework to take into

account non-functional aspects such as quality of

service, security, and performance. We are also

considering implementing the framework and

providing a model driven approach to testing.

REFERENCES

Apache Server http://httpd.apache.org

AutomationAnywhere http://www.automationanywhere.

com

Barn B.S Oussena S (2008) "BPMN, Toolsets and

Methodology: A case study of business process

management in higher education" In: ISD’08

conference

Barn, B.S., Dexter, H., Oussena, S. Petch, J.: An

Approach to Creating Reference Models for SOA

from Multiple Processes. In: IADIS Conference on

Applied Computing, Spain 2006.

Beck, K. Extreme Programming Explained: Embrace

Change, Boston: Addison-Wesley, 2000

Beck, K., Test-Driven Development: By Example. Boston:

Addison-Wesley, 2003

Bloomberg, J., Web services testing: Beyond SOAP,

ZapThink LLC, Sep 2002

A FRAMEWORK FOR TESTING SOA APPLICATIONS

Cockburn, A. Agile Software Development, Boston:

Addison-Wesley 2001

Dallaway, R., JSP test http://www.dallaway.com/jsptest/

DAO Pattern http://java.sun.com/blueprints/corej2

eepatterns/Patterns/DataAccessObject.html

DBUnit http://sourceforge.net/projects/dbunit/

Empirix, http://www.empirix.com/

Freeman,S., Developing Jdbc Applications Test-First

http://www.mockobjects.com/DevelopingJdbcApplica

tionsTestFirst.html

Hibernate: http://docs.jboss.org/ejb3/app-server/

Hibernate3/reference/en/pdf/hibernate_reference.pdf

HttpUnit http://httpunit.sourceforge.net/

JUnit http://www.junit.org

Juric., M. Business Process Execution Language for Web

Service, 2

ed., Birmingham, Packt, 2006.

Lenz C., Chimiak-Opoka,, J. Breu R..

“Model driven testing of soa-based software”

In Daniel Luebke, editor, Proceedings of the

SEMSOA Workshop 2007 on Software Engineering

Methods for Service-Oriented Architecture, volume

244 of CEUR Workshop Proceedings (ISSN 1613-

0073), pages 99-110, Hannover, Germany, May 2007

Link, J. and Frohlich, P., Unit Testing in Java: How Tests

Drive the Code, Morgan Kaufmann Publishers, 2003

mod_jk Tomcat Connector

http://tomcat.apache.org/connectors-doc/

Onoma A.K., Tasi W.T., Poonawala M. and Sugama H.

Regression testing in an Industrial Environment,

Communication of ACM, Vol. 41, No 5, 1998, 81-86

Parasoft, www.parasoft.com

Tsai, W. T., Paul, R., Wang, Y., Fan C., and Wang D.,

“Extending WSDL to Facilitate Web Services

Testing”, Proc. of IEEE HASE, 2002, pp. 171-172.

Quatrani, T. and Palistrant, J. Visual Modeling with IBM

Rational Software Architect and UML, Pearson

Education, 2006

Scardina, M., Chang, B., and Wang, J., Oracle Database

10g XML & SQL: Design, Build, and Manage XML

Applications in Java, C, C++ & PL/SQL, McGraw-

Hill, 2004

Tsai W. T., Zhang D., Chen Y., Huang H., Paul R., and

Liao N., “A Software Reliability Model for Web

Services”, the 8th IASTED International Conference

on Software Engineering and Applications,

Cambridge, MA, November 2004, pp. 144-149.

Tsai W. T., Paul R., Yu L., Saimi A., and Cao Z.,

“Scenario-Based Web Service Testing with

Distributed Agents”, IEICE Transactions on

Information and Systems, 2003, Vol. E86-D, No. 10,

2003, pp. 2130-2144

Tomcat Server http://tomcat.apache.org

Zachman Institute for Framework Advancement

http://www.zifa.com

ICSOFT 2009 - 4th International Conference on Software and Data Technologies
