FEATHERWEIGHT AGENT LANGUAGE

A Core Calculus for Agents and Artifacts

Ferruccio Damiani

Dipartimento di Informatica, Universit`a degli Studi di Torino, Corso Svizzera 185, 10149 Torino, Italy

Paola Giannini

Dipartimento di Informatica, Universit`a del Piemonte Orientale, Via Bellini 25/G, 15100 Alessandria, Italy

Alessandro Ricci, Mirko Viroli

DEIS, Universit`a di Bologna, Via Venezia 52, 47023 Cesena, Italy

Keywords: Multi-agent systems, Concurrency, Core calculi, Type systems.

Abstract:

The widespread diffusion and availability of multicore architectures is going to make more and more aspects

of concurrency and distribution to be part of mainstream programming and software engineering. The SIMPA

framework is a recently proposed library-based extension of JAVA that introduces on top of the OO layer a

new abstraction layer based on agent-oriented concepts. A SIMPA program is organized in terms of dynamic

set of autonomous pro-active task-oriented entities – the agents – that cooperate by exploiting some artifacts,

that represents resources and tools that are dynamically constructed, shared and co-used by agents. In this

paper we promote the applicability of the agent and artifact metamodel in OO programming a step further.

Namely, we propose a core calculus that integrates techniques coming from concurrency theory and from OO

programming languages to provide a ﬁrst basic formal framework for designing agent-oriented languages and

studying properties of agent-oriented programs.

1 INTRODUCTION

Multi-core architectures, Internet-based computing

and Service-Oriented Architectures/Web Services,

are increasingly introducing concurrency issues (and

distribution) in the context of a large class of appli-

cations and systems—up to making them key factors

of almost any complex software system. As noted in

(Sutter and Larus, 2005), even though concurrency

has been studied for about 30 years in the context

of computer science ﬁelds such as programming lan-

guages and software engineering, this research has

not signiﬁcantly impacted on mainstream software

development. However, it appears more and more im-

portant to introduce higher-level abstractions, which

can “help build concurrent programs, just as object-

oriented abstractions help build large component-

based programs” (Sutter and Larus, 2005).

The A&A (Agents and Artifacts) meta-model, re-

cently introduced in the context of agent-oriented

programming and software engineering as a novel

foundational approach for modelling and engineer-

ing complex software systems (Omicini et al., 2009),

goes in this direction. Agents and artifacts are the ba-

sic high-level and coarse-grained abstractions avail-

able in A&A: agents are used to model (pro)-active

and task-oriented components of a system, which

encapsulate the logic and control of their execu-

tion, while artifacts model purely-reactive function-

oriented components of a system, used by agents to

support their (invidual and collective) activities.

In (Ricci and Viroli, 2007) it is introduced SIMPA,

a library-based extension of JAVA providing program-

mers with agent-oriented abstractions on top of the

basic OO layer, to be used as basic building blocks to

deﬁne the architecture of complex (concurrent) appli-

cations. In SIMPA, the underlying OO computational

model of JAVA is still adopted, but only for deﬁning

agents and artifacts programming and data storage,

namely, for deﬁning the purely computational part of

218

Damiani F., Giannini P., Ricci A. and Viroli M. (2009).

FEATHERWEIGHT AGENT LANGUAGE - A Core Calculus for Agents and Artifacts.

In Proceedings of the 4th International Conference on Software and Data Technologies, pages 218-225

DOI: 10.5220/0002257102180225

 SciTePress

applications. On the other hand, agents and artifacts

are used to deﬁne aspects related to system architec-

ture, interaction, and synchronisation.

In this paper we promote the applicability of

A&A metamodel in OO programming a step fur-

ther, by introducing FAL (FEATHERWEIGHT AGENT

LANGUAGE), a core calculus formalizing the key fea-

tures of SIMPA. The formalization is largely inspired

to FJ, (FEATHERWEIGHT JAVA) (Igarashi et al.,

2001), and is based on reduction rules applied at cer-

tain evaluation contexts. On the other hand, being

concurrency-oriented, this calculus uses techniques

coming from concurrency theory, as e.g. in process

algebras. A system conﬁguration is seen as a parallel

composition of agents and artifacts instances (seen as

independent and asynchronous processes), the former

keeping track of a tree of (sub-)activities to be exe-

cuted in autonomy, the latter holding a set of pending

operations to be executed in response to agent actions

over the artifact.

Organisation of the Paper. Section 2 introduces the

SIMPA programming model. Section 3 presents syn-

tax, and operational semantics of the FAL calculus.

Section 4 brieﬂy discusses the properties that result

from type soundness. Section 5 discusses some re-

lated work and Section 6 concludes by outlining pos-

sible directions for further work.

2 THE PROGRAMMING MODEL

In this section we describe an abstract version of

SIMPA programming model by exploiting the syntax

of the FAL calculus.

The Agent Programming Model. In essence, an

agent in SIMPA is a stateful entity whose job is to

pro-actively execute a structured set of activities as

speciﬁed by the agent programmer, including possi-

bly non-terminating activities, which ﬁnally result in

executing sequences of actions, either internal actions

– inspecting/changing its own state – or external ac-

tions – interacting with its environment. All actions

are executed atomically.

The state of an agent is represented by an associa-

tive store, called memo-space, which represents the

long-term memory where the agent can dynamically

attach, associatively read and retrieve chunks of in-

formation called memo. A memo is a tuple, charac-

terised by a label and an ordered set of arguments,

either bound or not to some data object (if some is not

bound, the memo is hence partially speciﬁed). For

instance, the philosopher agent uses a memo

hungry

to take note that its state is now hungry and it needs

the forks, and

stopped

to keep track that it needs to

agent Main {

activity main() { Table t = make Table(new boolean[5]);

spawn Philosopher(0,1,t); spawn Philosopher(1,2,t);

spawn Philosopher(2,3,t); spawn Philosopher(3,4,t);

spawn Philosopher(4,0,t); }

}

artifact Table { boolean[] isBusyFork;

operation getForks(int left, int right)

:guard ((not(.isBusyFork[left]) and (not(.isBusyFork[right])))

{ .isBusyFork[left] = true; .isBusyFork[right] = true;

signal(forks_acquired);

}

operation releaseForks(int left, int right) :guard true

{ .isBusyFork[left] = false; .isBusyFork[right] = false; }

}

agent Philosopher { Sns s;

activity main(int left, int right, Table table)

:agenda ( prepare() :pre true,

living(left,right,table) :pre memo(hungry)

:pers not(memo(stopped)) ) { }

activity prepare() { +memo hungry; }

activity living(int left, int right, Table table)

:agenda ( eating(left,right,table) :pre memo(hungry),

thinking() :pre completed(eating),

shutdown() :pre failed(eating) ) { }

activity thinking() { ... /* think */ +memo hungry; }

activity eating(int left, int right, Table table)

{ use table.getForks(left,right) :sns s

sense s :filter forks_acquired;

... /* eat */

use table.releaseForks(left,right);

-memo(hungry);

}

activity shutdown() { +memo(stopped); }

}

Figure 1: The ﬁve dining philosophers problem.

terminate. A basic set of internal actions is available

to agents to work atomically with the memo-space:

+memo

is used to create a new memo with a speciﬁc

label and a variable number of arguments,

?memo

and

-memo

to get/remove a memo with the speciﬁed label.

The computational behaviour of an agent can be

deﬁned as a hierarchy of activities (corresponding to

the execution of some tasks). Activities can be simple

or structured. A simple activity is composed by just a

ﬂat sequence of actions, as a single control ﬂow, while

structured activities have a non-empty agenda speci-

fying sub-activities, which in turn can be possibly ex-

ecuted in the context of such super-activity—hence

leading to the hierarchical structure of behaviour. At

the language level, simple activities are represented

activity

blocks, providing the name of the activ-

ity and parameters. By default each agent has a

main

activity, which can be either simple or structured.

In the dining philosophers example shown in Fig-

ure 1, the

Philosopher

agent has the simple activ-

ities,

prepare

eating

thinking

, and

shutdown

. A

structured activity has a non-empty agenda, specify-

FEATHERWEIGHT AGENT LANGUAGE - A Core Calculus for Agents and Artifacts

219

ing a set of todos representing sub-activities that must

be executed in the context of the parent activity—also

called super-activity. In the philosophers example,

main

and

living

are structured activities. A todo

contains the name of the sub-activity to be executed, a

precondition overthe inner state of the agent that must

be hold for the speciﬁed sub-activity to start, and at-

tributes related to sub-activity execution, such as per-

sistency. Preconditions are expressed as a boolean

expression over a basic set of predeﬁned predicates.

Essentially, the predicates make it possible to specify

conditions on the current state of the activity agenda,

in particular on (i) the state of the sub-activitities (if

they started, completed, or aborted) and on (ii) the

local inner state of the agent, that is the memo space.

For instance, the predicate

memo(M)

is true if the spec-

iﬁed memo

is found in the memo space. In the ex-

ample, in the structured activity

living

, sub-activity

eating

is executed as soon as a memo

hungry

found in the memo space. When the precondition of

a todo item holds (for an activity in execution list-

ing such todo in the agenda), the todo is removed

from the agenda and an instance of the sub-activity

is created and executed. So, multiple sub-activities

can be executed concurrently and asynchronously, in

the context of the same parent activity. Sub-activities

execution can be then synchronized by properly spec-

ifying preconditions in todos, hence in a declarative

way. If a todo is declared persistent, as soon as the

sub-activity is completed the todo is re-inserted into

the agenda. The persistency attribute can specify also

the condition under which the activity should per-

sist. For instance, the todo item about

living

sub-

activity in philosopher agent is declared persistent un-

til a

stopped

memo is found.

The Artifact Programming Model. An artifact is

composed by three main parts: (i) observable prop-

erties, which are attributes that can be observed by

agents without an explicit agent action towards the

artifact; (ii) a description of the inner non-observable

state, composed by set of state variables analogous to

private instance ﬁelds of objects; and (iii) operations,

which embody the computational behaviour of arti-

facts. The

Table

artifact in the philosopher example

in Figure 1 has no observableproperties, an inner state

variable

isBusyFork

, an array of booleans, and two

operations,

getForks

and

releaseForks

, the ﬁrst

used to acquire two forks and the latter for releasing

forks. Both state variables and observable properties

are declared similarly to instance ﬁelds in objects; ob-

servable properties are preﬁxed by

obsprop

qualiﬁer.

In both cases, a dot notation (e.g.

.isBusyFork

) is

used both for l-valueand r-value, to syntacatically dis-

tinguish them from parameters.

Operations can be deﬁned by method-like blocks

qualiﬁed as

operation

, specifying the name and pa-

rameters of the operation and a computational body.

It is worth noting that no return parameter is speci-

ﬁed, since operations in artifacts are not exactly like

methods in objects. For each

operation

, implicitly

an interface control in the usage interface is deﬁned,

with the speciﬁed signature. Operations can be either

atomic, executed as a single computational step, or

structured, i.e. composed by multiple atomic opera-

tion steps. For sake of space, in this paper we con-

sider only atomic operations. For each operation a

guard can be speciﬁed (

:guard

declaration), repre-

senting the condition that must hold for the related

control in the usage interface to be enabled. For in-

stance, the

getForks

operation in

Table

artifact is

available – i.e. the related control is enabled in the us-

age interface – when the speciﬁed forks are not busy.

To be useful, an artifact typically should pro-

vide some level of observability. This is achieved

both by generating observable events through the

signal

primitive, and by deﬁning observable prop-

erties. In the former case, the primitive generates

observable events that can be observed by the agent

using the artifact – i.e. by the agent which has ex-

ecuted the operation. An observable event is repre-

sented by a labelled tuple, whose label represents the

kind of the event and the information content. For

instance, in the

Table

artifact

getForks

operation

generates the

forks acquired(Left,Right)

tuple.

Actually, the observableevent

op exec completed

automatically generated – without explicit

signals

– as soon as the execution of an operation is com-

pleted. In the latter case, observable properties are

instance variables qualiﬁed as

obsprop

. Any time

the property changes, an observable event of type

prop updated

is ﬁred with the new value of the prop-

erty as a content. The observable events is observed

by all the agents that are focussing (observing) the

artifact (more details in next subsection). An exam-

ple of simple artifact with observable properties is the

Counter

artifact shown in Figure 2: this artifact –

working as an observable counter – has just a single

observable property named

count

and an

inc

oper-

ation to update this count. Each time the operation

is executed, the observable property and the event

prop update(count,Value)

are automatically gen-

erated.

The Agent-artifact Interaction Model. As already

stated, artifact use and observation are the basic form

of interaction between agents and artifacts. Artifact

use by an agent involves two basic aspects: (i) ex-

ecuting operations on the artifact, and (ii) perceiving

throughagent sensors the observableevents generated

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

220

artifact Counter { obsprop int count;

Counter(int c){ .count = c; }

operation inc() { .count = .count+1; }

}

agent Main {

activity main() {

Counter c = make Counter(0);

spawn Observer(c); spawn User(c); spawn User(c); }

}

agent Observer { Sns s;

activity main(Counter c)

:agenda ( prepare(c),

monitoring(c) :pre completed(prepare)

:pers (not memo(finished)) { }

activity prepare(Counter c) { focus (c,s); }

activity monitoring(Counter c) {

sense s :filter prop_updated;

int value = observe c.count;

... // do something

if (value >= 100 ){ +memo(finished); } }

}

agent User {

activity main(Counter c)

:agenda ( usingCount(c) :pers true ) {}

activity usingCount(Counter c) { use c.inc(); }

}

Figure 2: A simple program with an

Observer

agent con-

tinuously observing a

Counter

Artifact, which is concur-

rently used by two

User

agents.

by the artifact. Conceptually sensors represent a kind

of “perceptual memory” of the agent, used to detect

events coming from the environment, organize them

according to some policy – e.g. FIFO and priority-

based – and ﬁnally make them available to the agent.

In the abstract language presented here, sensors used

by an agent are declared at the beginning of the

agent

block.

In order to trigger operation execution, the

use

action is provided, specifying the target artifact, the

operation to execute – or, more precisely, the usage

interface control to act upon, which activates the op-

eration – and optionally, a timeout and the identiﬁer

of the sensor used to collect observable events gener-

ated by the artifact. The action is blocked until either

the action execution succeeds – which means that the

speciﬁed interface control has been ﬁnally selected

and the related operation has been started – or fails,

either because the speciﬁed usage interface control is

invalid (for instance it is not part of the usage inter-

face) or the timeout occurred. If the action execution

fails an exception is generated. In the philosopher

example, a

Philosopher

agent (within its

eating

activity) executes a

use

action so as to execute the

getForks

operation, specifying the

sensor. On the

artifact side, if the forks are busy the

getForks

usage

interface control is not enabled, and the

use

is sus-

pended. As soon as the forks become available the

operation is executed and the

use

action succeeds.

It is important to note that no control coupling ex-

ists between an agent and an artifact while an oper-

ation is executed. However, operation triggering is

a synchronization point between the agent (user) and

the artifact (used): if the use action is successfully

executed, then this means that the execution of the

operation on the artifact has started.

In order to retrieve events collected by a sensor,

the

sense

primitive is provided. The primitive waits

until either an event is collected by the sensor, match-

ing the pattern optionally speciﬁed as a parameter (for

data-driven sensing), or a timeout is reached, option-

ally speciﬁed as a further parameter. As result of a

successful execution of a

sense

, the event is removed

from the sensor and a perception related to that event

is returned. In the philosopher example, after exe-

cuting

getForks

the philosopher agent blocks until a

forks acquired

event is perceived on the sensor

If no perception are sensed for the duration of time

speciﬁed, the action generates an exception. Pattern-

matching can be tuned by specifying custom event-

selection ﬁlter: the default ﬁlter is based on regular-

expression patterns, matched over the event type (a

string).

Besides sensing events generated when explicitly

using an artifact, a support for continuous observa-

tion is provided. If an agent is interested in observ-

ing every event generated by an artifacts – includ-

ing those generated as a result of the interaction with

other agents – two actions can be used,

focus

and

unfocus

. The former is used to start observing the

artifact, specifying a sensor to be used to collect the

events and optionally the ﬁlter to deﬁne the set of

events to observe. The latter one is used to stop ob-

serving the artifact. In the example shown in Figure 2,

Observer

agent continuously observes a

Counter

artifact, which is used by two

User

agents. After exe-

cuting a

focus

on the artifact in the

prepare

activity,

in the

monitoring

activity the observer prints on a

console artifact the value of the observable property

count

as soon as it changes.

3 THE CORE CALCULUS

The syntax of FAL is summarised in Figure 3 where

we assume a set of basic values, ranged over by the

metavariable c. Types for basic values are ranged over

by the metavariable C. We only assume the basic val-

ues true and false (of type Bool) which are used

as the result of the evaluation of preconditions, persis-

tency predicates and guards. We use the overbar se-

FEATHERWEIGHT AGENT LANGUAGE - A Core Calculus for Agents and Artifacts

221

U ::= G | A | C Agent / artifact / basic value types

T ::= U |

Sns

Types

::=

agent

G {

Sns

¯s;

Act

} Agent (class) deﬁnition

Act

::=

activity a

(T x)

:agenda

(

SubAct

) {e;} Activity deﬁnition

SubAct

::=

(e)

:pers

:pre

e Subactivity deﬁnition

::=

artifact

A {U f; U p;

} Artifact (class) deﬁnition

::=

operation

o(U x)

:guard

e {e;} Operation deﬁnition

e ::= x | c Expressions: variable / basic value

spawn

G(e) |

make

A(e) agent and artifact instance creation

| e;e sequential composition

| .f | .f = e artifact-ﬁeld access / update

| .p | .p = e artifact-property access / update

signal

(l(e)) event generation

| .s |

use

e.o(e)

:sns

e |

sense

:filter

l sensor / operation use / event sensing

focus

(e, e) |

unfocus

(e, e) focus / unfocus

observe

e.p get property value

?memo

(l) |

-memo

(l) |

+memo

(l(e)) memo operations

memo

(l) memo predicate

started

(

) |

completed

(

) |

failed

(

) activity state predicates

| fail activity error

Figure 3: Syntax.

quence notation according to (Igarashi et al., 2001).

There are minor differences between the syntax of

the calculus and the one of the language used for the

examples. Namely: instead of tuples for memos in

memo-spaces (and event in sensors) we use values;

and speciﬁers (

:agenda

:pers

:pre

:guard

and

:sns

), that are optional in the language, are manda-

tory in the calculus.

Labels are used as keys for the associative maps

representing the content of sensors and memo-spaces.

The metavariable l range over labels.

The expression fail model failures in activities,

such as the evaluation of

?memo

(l) and

-memo

(l) in

an agent in which the memo-space does not have a

memo with label l. Note that the types of parame-

ters, in artifact operations and the type of ﬁelds and

properties may not be sensors so artifacts. Moreover,

the signal expression,

signal

(l(e)), does not spec-

ify a sensor. Therefore, sensors may not be explicitly

manipulated by artifacts.

The language is provided with a standard type

system enforcing the fact that expressions occur in

the right context (artifact or agent), operation used,

and activities mentioned in todo lists are deﬁned, and

only deﬁned ﬁelds and properties are accessed/modi-

ﬁed.

Operational Semantics. The operational semantics

is described by means of a set of reduction rules that

transform sets of instances of agents/artifacts/sensors.

Each agent/artifact/sensor instance has a unique

identity, provided by a reference. The metavariable γ

ranges over references to instance of agents, α over

artifacts, σ over sensors. Conﬁgurations are non-

empty sets of agent/artifact/sensor instances.

Sensor instances are represented by σ = hlvi

Sns

where σ is the instance identiﬁer, and lv is the queue

of association labels/values representing the events

generated (and not yet perceived) on the sensor.

Agent instances are represented by γ = hl v, σ, Ri

where γ is the agent identiﬁer, G is the type of the

agent, lv is the content of the memo-space, σ is the

sequence of references to the instances of the sensors

that the agent uses to perceive, and R is the state of

the activity,

main

, that was started when the agent was

created. The sensor instances in σ are in one-to-one

correspondence with the sensor variables declared in

the agent and are needed since every agent uses it own

set of sensor instances.

An instance of an activity, R, describes a running ac-

tivity. As explained in Section 2, before evaluating

the body of an activity we have to complete the ex-

ecution of its sub-activities, so we also represent the

state of execution of the sub-activities.

R ::=

(

)[Sr

··· Sr

]{e} | failed

The name of the activity is

, v are the actual pa-

rameters of the current activity instance, Sr

··· Sr

the set of sub-activities running, and e is the state of

evaluation of the body of the activity. (Note that the

evaluation of the body starts only when all the sub-

activities have been fully evaluated.) With failed

we say that activity

has failed. If the evaluation of a

sub-activity is successful then it is removed from the

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

222

set Sr

··· Sr

. So when n = 0 starts the evaluation of

the body e.

For a sub-activity, Sr, the process of evaluating its

precondition (we do not consider the persistency

predicate that would be similar), is represented by

the term,

(v)hei where e is different from true or

false (it is the state of evaluation of the precondi-

tion) when e = true, the term

(v)htruei is replaced

with the initial state of the evaluation of the activity

with parameters v. When e = false the evaluation

of the precondition of

is rescheduled. Therefore:

Sr ::=

(v)hei | R

Artifact instances are represented by α = hf =

v, p = w, σ, O

··· O

where α is the artifact identi-

ﬁer, A the type of the artifact, the sequence of pairs

f v associates a value to each the ﬁeld of A, the se-

quence of pairs p w associates a value to each property

of A, the sequence σ represents the sensors that agents

focusing on A are using, and O

, 1 ≤ i ≤ n, are the op-

erations that are in execution. We consider O

··· O

queue with ﬁrst element O

and last O

. (For simplic-

ity, we do not consider steps in this paper, although

we have a full formalization including them.) Arti-

facts are single threaded and (differently from agents

that may have more activity running at the same time)

only the operation O

is being evaluated.

A running operation, O, is deﬁned as follows.

O ::= (σ, ohei{e

′

})

where σ identiﬁes the sensor associated with the op-

eration which was speciﬁed by the agent containing

the use that started the operation, and that is used to

collect events generated during the execution of the

operation by signal. If the expression hei is differ-

ent from true or false the operation is evaluating its

guard e. If e = true then the operation is evaluating

its body. If e = false then the operation is removed

from the queue and put at the end of it so that when it

will be rescheduled it will restart evaluating its guard.

Reduction Rules by Examples. The initial conﬁgu-

ration for the program in Fig. 1 is:

Main

= h

main







Tablet=make Table(newBool[5]);

spawn Philosopher(0,1,t);

...

spawn Philosopher(4,0,t)







{ }i

Main

The expression

new Bool[5]

reduces to the array

[f,f,f,f,f]

(In the array we use

for false

and

for true.) Then the expression

make

Table([f,f,f,f,f])

reduces to an artifact reference

α and adds to the conﬁguration the initial artifact in-

stance that follows:

The syntax of FAL does not include local variables and

array object values. In this example, we will handle the lo-

cal variable

by replacing, after its declaration/inizializa-

tion, all its occurrences with its value.

α = h

.isBF

[f,f,f,f,f]

Table

After the initialization of the local variable

the agent

instance γ

Main

becomes

Main

= h

main





spawn Philosopher(0,1,

);

...

spawn Philosopher(4,0,

)





{ }i

Main

The ﬁve spawn expressions are evaluated from left

to right. The evaluation of the expressions

spawn

Philosopher(0,1,

)

reduces to γ

and adds to the

conﬁguration the agent instance

(1) γ

= h

0, σ

main

prepare()

htruei ,

living(0,1,

)

memo(hungry)

{ }i

Phil.

and the sensor instance σ

= h

Sns

Similarly, the reduction of the other spawn expres-

sions generates four agent instances and four sensor

instances producing the conﬁguration:

Main

= h...i σ

= h

0i ··· σ

= h

0i α = h...i γ

= h...i · ·· γ

= h...i

in which the agent γ

Main

is inactive, having ﬁnished

the evaluation of its body. The artifact α does not

have any pending operation, and all the agent philoso-

phers may start the execution of the sub-activities of

their main activity (by starting the evaluation of the

preconditions of

prepare

and

living

). Our model-

ing make use of nondeterministic evaluation rules, but

parallel execution could be modeled.

Going back to (1), since the precondition of the run-

time sub-activity

prepare()

of the activity

main

the agent γ

is true the expression prepare() htruei

is replaced by prepare()[ ]{+memo(hungry)} (whose

evaluation causes the insertion of the label

hungry

into

the memo of γ

) and then since the body is fully eval-

uated

prepare

is removed from the sub-activities of

main

, yielding

(2) γ

= h

hungry

, σ

main



living(0,1,

)

hmemo(hungry)i



{ }i

Phil.

If instead of evaluating the sub-activity

prepare

would have evaluated the precondition of the sub-

activity

living

, the result would have being

= h

0, σ

main



prepare()

htruei,

living(0,1,

)

hfalsei



{ }i

Phil.

Next time the sub-activity

living

was scheduled for

execution

living(0,1,

)

hfalsei would have been

replaced with

living(0,1,

)

hmemo(hungry)i.

Continuing from (2) the precondition

memo(hungry)

living

evaluates to

true

and the sub-activity

living(0,1,

)

htruei is replaced by the correspond-

ing run-time activity resulting in the following:

living(0,1,

)







eating(0,1,

)

hmemo(hungry)i ,

thinking()

completed(eating)

shutdown()

failed(eating)







{}

The precondition

memo(hungry)

evaluates to

true

and the sub-activity

eating(0,1,

)

htruei is replaced

by the corresponding run-time activity resulting in

FEATHERWEIGHT AGENT LANGUAGE - A Core Calculus for Agents and Artifacts

223

the following

(3)

eating(0,1,

)[ ]











use

.getForks(0,1) :sns

;

sense

:filter forks acquired

;

/* eat */

use

.releaseForks(0,1)

;

-memo(hungry)











(Note that both

completed(eating)

and

failed(eating)

would evaluate to false.) The

evaluation of the body of

eating

can now start by

reducing the expression

use

.getForks(0,1) :sns

, that schedules the operation

getForks

in the

artifact instance α yielding

α = h

.isBF

[f,f,f,f,f]

0, (σ

, getForks he

′

i {e

})i

Table

where e

′

(not(.isBF[0]) and (not(.isBF[1])))

and e

.isBF[0] = true; .isBF[1] =true; signal(forks acquired)

The guard e

′

reduces to

true

. The reduction of e

updates the array ι to

[t, t, f, f, f]

and adds the

label

forks acquired

to the queue of events of the

sensor instance σ

, yielding σ

= h

forks acquired

Sns

Other agents may schedule operation the artifact

α. For instance, if the agent γ

and γ

invoke the

operation

getForks

on α, when the evaluation of

getForks

for the agent γ

was completed the state of

the artifact would be

α = h

.isBF

[t,t,f,f,f]

(σ

getForks

′

i {e

}) (σ

getForks

′

i {e

})i

Table

So the guard e

′

(

( not(.isBF[1]) and (not(.isBF[2])) )

)

would evaluate to

false

, and the associated operation

would be rescheduled and put at the rear of the queue

yielding the following

α = h

.isBF

[t,t,f,f,f]

(σ

getForks

′

i {e

}) (σ

getForks

′

i {e

})i

Table

so the evaluation of the guard of the

getForks

opera-

tion invoked by γ

may start (and will successfully ac-

quire the forks for γ

). At the same time, the expres-

sion

sense

:filter forks acquired

in (3) could

be evaluated, perceiving the event

forks acquired

and removing it from the sensor instance σ

which

becomes σ

= h

Sns

. The code “

/* eat */

” may

be executed and, at the end of its execution the ex-

pression

use

.releaseForks(0,1)

schedules the op-

eration

releaseForks

on the artifact α and then

-memo(hungry)

removes the label

hungry

from the

memo completing the execution of the sub-activity

eating

. The sub-activity

eating

is discarded and

therefore the predicate

completed(eating)

becomes

true and the sub-activity

thinking

could be executed

resulting in γ

to be:

0, σ

main

[

living(0,1,

)





thinking()[]

{

/* think */ +memo(hungry)

}

shutdown() hfailed(eating)i





{ } ]{ }i

Phil.

(If the evaluation of the predicate

completed(eating)

was done before completion of predicate

eating

the

result would have been

false

, and then its evaluation

rescheduled.) Once the sub-activity

living

completes

its execution, in the example of Fig. 1 it would be

rescheduled (since its persistency condition is

true

4 PROPERTIES

We have deﬁned a type system for FAL – not reported

in the paper for lack of space. The soundness of the

type system implies that the execution of well-typed

agents and artifacts does not get stuck. The following

properties of interaction between well-typed agents

and artifacts, which are useful in concurrent program-

ming with SIMPA, hold: (i) there is no

use

action

specifying an operation control that is not part of the

usage interface of the artifact; (ii) there is no

observe

action specifying an observable property that does not

belong to the speciﬁed artifact; and (iii) an executing

activity may be blocked only in a

sense

action over

a sensor that does not contain the label speciﬁed in

the ﬁlter—i.e., the agent explicitly stops only for syn-

chronization purposes. Moreover, a type restriction

on sensors – not present in the current type system –

may be deﬁned to enforce that there is no

sense

action

indeﬁnitely blocked on sensing event

due to the fact

that the corresponding triggered operation was not de-

signed to generate

5 RELATED WORK

The extension of the OO paradigm toward concur-

rency — i.e. object-oriented concurrent programming

(OOCP) — has been (and indeed still is) one of the

most important and challenging themes in the OO

research. Accordingly, a quite large amount of the-

oretical results and approaches have been proposed

since the beginning of the 80’s, surveyed by works

such as (Briot et al., 1998; Yonezawa and Tokoro,

1986; Agha et al., 1993; Philippsen, 2000). We re-

fer to (Ricci et al., 2008) for a comparison of the

agent and artifact programmingmodel with active ob-

jects (Lavenderand Schmidt, 1996) and actors (Agha,

1986) and with more recent approachesextending OO

with concurrency abstractions, namely POLYPHONIC

C# (Benton et al., 2004) and JOIN JAVA (Itzstein and

Kearney, 2001) (both based on Join Calculus (Four-

net and Gonthier, 1996)). Another recent proposal

is STATEJ (Damiani et al., 2008), that proposes state

classes, a construct for making the state of a concur-

rent object explicit. The objective of our approach is

quite more extensive in a sense, because we introduce

an abstraction layer which aims at providing an effec-

tive support for tackling not only synchronisation and

ICSOFT 2009 - 4th International Conference on Software and Data Technologies

224

coordination issues, but also the engineering of pas-

sive and active parts of the application, avoiding the

direct use of low-level mechanisms such as threads.

6 CONCLUSIONS

We described FAL, a core calculus to provide a rig-

orous formal framework for designing agent-oriented

languages and studying properties of agent-oriented

programs. To authors knowledge, the only attempt

that has been done so far applying OO formal mod-

elling techniques like core calculi to study properties

of agent-oriented programs and of agent-oriented ex-

tensions of object-oriented systems is (Ricci et al.,

2008). A main limitation of the formalization pro-

posed in (Ricci et al., 2008) is the lack of a type sys-

tem that is able to guarantee well-formedness proper-

ties of programs. In this paper we formalized a larger

set of features (including agent agenda and artifact

properties) and provided a type soundness result.

The type system paves the way towards the anal-

ysis of the computational behaviour of agents. Prop-

erties that we are investigating mainly concerns the

correct execution of activities, in particular: (i) there

is no activity which are never executed because of

their pre-condition; (ii) post-conditions for activity

execution can be statically known, expressed as set of

memos that must be part of the memo space as soon as

the activity has completed; (iii) invariants for activity

execution can be statically known, expressed as set of

memos that must be part of the memo space while the

activity is in execution; (iv) there is no internal action

reading or removing memos that has not been previ-

ously inserted. We are investigating the suitable deﬁ-

nition of pre/post/invariant conditions in terms of sets

of memos that must be present or absent in the memo

space, so that it would be possible to represent high-

level properties related to set of activities, such as the

fact that an activity A would be executed always after

an activity A’ or that an activity A and A’ cannot be

executed together. On the artifact side, the computa-

tional model of artifacts ensures a mutually exclusive

access to artifact state by operations executed concur-

rently; more interesting properties could be stated by

considering not only atomic but also structured oper-

ations, not dealt in this paper. We are also planning

of integrating and comparing our approach based on

static analysis with traditional veriﬁcation techniques

such as model-checking.

REFERENCES

Agha, G. (1986). Actors: a model of concurrent compu-

tation in distributed systems. MIT Press, Cambridge,

MA, USA.

Agha, G., Wegner, P., and Yonezawa, A., editors (1993). Re-

search directions in concurrent object-oriented pro-

gramming. MIT Press, Cambridge, MA, USA.

Benton, N., Cardelli, L., and Fournet, C. (2004). Modern

concurrency abstractions for C#. ACM Trans. Pro-

gram. Lang. Syst., 26(5):769–804.

Briot, J.-P., Guerraoui, R., and Lohr, K.-P. (1998). Con-

currency and distribution in object-oriented program-

ming. ACM Comput. Surv., 30(3):291–329.

Damiani, F., Giachino, E., Giannini, P., and Drossopoulou,

S. (2008). A type safe state abstraction for coordi-

nation in java-like languages. Acta Inf., 45(7-8):479–

536.

Fournet, C. and Gonthier, G. (1996). The reﬂexive chemical

abstract machine and the join calculus. In POPL’96,

pages 372–385. ACM.

Igarashi, A., Pierce, B., and Wadler, P. (2001). Feather-

weight Java: A minimal core calculus for Java and

GJ. ACM TOPLAS, 23(3):396–450.

Itzstein, G. S. and Kearney, D. (2001). Join Java: an alterna-

tive concurrency semantics for Java. Technical Report

ACRC-01-001, Univ. of South Australia.

Lavender, R. G. and Schmidt, D. C. (1996). Active ob-

ject: an object behavioral pattern for concurrent pro-

gramming. In Pattern languages of program design 2,

pages 483–499. Addison-Wesley Longman Publish-

ing Co., Inc., Boston, MA, USA.

Omicini, A., Ricci, A., and Viroli, M. (2009). Artifacts in

the A&A meta-model for multi-agent systems. Au-

tonomous Agents and Multi-Agent Systems, 19. Spe-

cial Issue on Foundations, Advanced Topics and In-

dustrial Perspectives of Multi-Agent Systems.

Philippsen, M. (2000). A Survey of Concurrent Object-

Oriented Languages. Concurrency Computat.: Pract.

Exper., 12(10):917–980.

Ricci, A. and Viroli, M. (2007). SIMPA: An agent-oriented

approach for prototyping concurrent applications on

top of java. In PPPJ’07, pages 185–194. ACM.

Ricci, A., Viroli, M., and Cimadamore, M. (2008). Proto-

typing concurrent systems with agents and artifacts:

Framework and core calculus. Electron. Notes Theor.

Comput. Sci., 194(4):111–132.

Sutter, H. and Larus, J. (2005). Software and the concur-

rency revolution. ACM Queue: Tomorrow’s Comput-

ing Today, 3(7):54–62.

Yonezawa, A. and Tokoro, M., editors (1986). Object-

oriented concurrent programming. MIT Press, Cam-

bridge, MA, USA.

FEATHERWEIGHT AGENT LANGUAGE - A Core Calculus for Agents and Artifacts

225
