ENHANCING HIGH PRECISION BY COMBINING OKAPI BM25

WITH STRUCTURAL SIMILARITY IN AN INFORMATION

RETRIEVAL SYSTEM

Yaël Champclaux, Taoufiq Dkaki and Josiane Mothe

IRIT, équipe SIG, Université de Toulouse, 118 Route de Narbonne Toulouse, France

Keywords: Information Retrieval, Structural similarity, Graph comparison, Term weighting.

Abstract: In this paper, we present a new similarity measure in the context of Information Retrieval (IR). The main

objective of IR systems is to select relevant documents, related to a user’s information need, from a

collection of documents. Traditional approaches for document/query comparison use surface similarity, i.e.

the comparison engine uses surface attributes (indexing terms). We propose a new method which combines

the use of both surface and structural similarities with the aim of enhancing precision of top retrieved

documents. In a previous work, we showed that the use of structural similarity in combination with cosine

improves bare cosine ranking. In this paper, we compare our method to Okapi based on BM25 on the

Cranfield collection. We show that structural similarities improve average precision and precision at top 10

retrieved documents about 50%. Experiments also address the term weighting influences on system

performances.

1 INTRODUCTION

Many applications require the use of similarity

measures. This is the case for information retrieval

(IR), where determining whether or not a given

piece of information corresponds to a user needs is

mainly based on uncovering similarities between

documents and queries -queries are the expressions

of the user needs whereas documents are the

information sources handled by information retrieval

systems (IRS). This central issue in IR involves a

complex task that aims at determining if a document

is sufficiently similar to a user's query to be

retrieved.

However, similarity is a difficult concept to

define and to use in the context of IR, as it is in

many areas related to cognition as in pattern

recognition, clustering and categorization (Jones,

1993)(Medin, 1990), case-based reasoning and

generalization. Similarity is the cornerstone of the

understanding of these areas and of the

implementation of related-applications. In IR,

similarity is a component that shapes IR models. An

IRS compares documents against a query to select

those documents that may be useful to the user. The

comparison is usually performed on some document

and query representations rather than on the primary

documents and queries. Representation space and

comparison method define the IR model.

The graph-based model we present in this paper

is an algebraic model closely related to the vector

space model (Salton, 1975). A vector space model

considers each document as a vector in the space

defined by the set of terms that the system collects

during the indexing phase. Each vector coordinate is

a value representing the importance of the term in

the document or in the query that the vector

represents. Many similarity measures such as the

cosine measure, the Jaccard measure, the Dice

coefficient… are used to determine how well a

document corresponds to a query. Such measures

determine local similarities between a document and

a query on the basis of the terms they have in

common. Our goal is to exploit another type of

similarities called structural similarities. These

similarities identify resemblances between two

elements on the basis of their relationships to the

remaining elements (Halford, 1988). The relational

structure that we use originates from the fact that

documents contain words and that words are

contained in documents. The idea is to compare

these documents through the similarities between the

279

Champclaux Y., Dkaki T. and Mothe J. (2009).

ENHANCING HIGH PRECISION BY COMBINING OKAPI BM25 WITH STRUCTURAL SIMILARITY IN AN INFORMATION RETRIEVAL SYSTEM.

In Proceedings of the 11th International Conference on Enterprise Information Systems - Information Systems Analysis and Speciﬁcation, pages

279-285

DOI: 10.5220/0002017202790285

 SciTePress

words they contain while similarities between words

are themselves dependent on similarities between

the documents they are contained in. In our first

paper (Champclaux, 2007), we have shown that the

only use of the structural similarity we proposed was

not sufficient to improve the performance of an IRS.

Then in a later paper (Champclaux, 2008), we

presented a different model that combines the use of

both structural and surface similarities, and we

showed that our SimRank measure combined with

the cosine can improve the high precision. In this

paper, we experiment our SimRank measure in

combination with a more efficient measure namely

Okapi.

The remainder of this paper is structured as

follows: Section 2 presents related works in graph

theory when used in IR and management fields. In

section 3, we describe our approach. Section 4 deals

with the evaluation of our method, section 5

comments and discusses the results we obtain. This

paper will be concluded by giving some perspectives

to our work.

2 RELATED WORKS

The earliest paper on graph theory is said to be the

one by Leonhard Euler in (Euler 1736) where he

discusses whether or not it is possible to stroll

around the town of Konigsberg crossing each of its

bridges across the river exactly once. Euler gave the

necessary conditions to do so. Two century later,

Claude Berge lays the groundwork of this field in his

book (Berge, 1958).From the sixties to the present,

graphs have been used to model real world

problems, especially those related to networks:

electric circuits, biological network, social network,

transport network, computer network, World Wide

Web.

Modeling problems with graphs have paved the

way to new approaches to solve them. We use a sub-

field of graph theory –namely graph comparison- to

provide new solutions for IR.

In (Blondel, 2004), Vincent Blondel laid the

ground for graph comparison in the context of

information management. Blondel’s method

compares each node of a graph to every node of

another graph. The approach in (Blondel, 2004) is

presented as a generalization of Kleinberg’s method

(Kleinberg, 1999) which associates authority and

hub scores to web pages to enhance web search

accuracy. Blondel’s comparison is based on a

similarity measure that takes into account the

neighboring nodes of the compared nodes in the

graph they belong to. This makes it possible to

determine which node of a graph being analyzed

behaves like a given node of a graph considered as a

model. This method has been successfully applied to

web searching and synonym extraction (Blondel,

2004).

More generally, graph comparison has been used

in many fields such as biological networks

comparison using phylogenetic trees from metabolic

pathway data (Heymans 2003); Social network

mapping and small world related phenomenon

(Milgram, 1967)(Watts, 1999); Chemical structure

matching and similar structures uncovering from a

chemical database (Hattori, 2003). Our method

could be related to Latent Semantic Indexing

(Deerwester, 1990), or neural network (NN) (Belew,

1989). Indeed, both methods try to capture the

added-value of documents-terms interrelationship.

The LSI method decomposes the document-term

matrix in a combination of three matrices which

represent the information of the original matrix in a

different space where similar documents and similar

terms are closer as a direct consequence of the

underlying space reduction. Our method creates

links between pairs of objects when each element of

the pair is related to an element of a previously

linked pair. As in the LSI, we can build similarity

measures between documents, between terms and

between documents and terms. The aim of our

method is not to reduce the representation space,

but, rather, to find all indirect similarities that exist

with the queries. Regarding NN, the retrieval

mechanism is based on the neural activation that is

propagated from query nodes to document nodes

through the network synapses. In our approach,

terms nodes and documents nodes are directly

related to each other under indexing considerations

whereas, in IR based on NN, they are related to each

other following an a priori heuristic that may involve

a hidden neuron layer. In our approach there is a

back and forth calculation of documents and terms

similarities. At the initial step of our method, we

consider that the similarity between any pair of

separate documents (resp. terms) is nil; then we

evaluate the similarity between terms on the basis of

the similarity between documents they index

(calculated similarity). After this, we evaluate the

document to document similarity on the basis of the

previously calculated term similarities, and then

repeat those steps until convergence is reached. This

is a back and forth automatic similarity refining.

Sophisticated neural approaches (Mothe, 1994) does

propagate and retro propagate neural activation just

once. Hyperspace Analog to Language (Burges,

ICEIS 2009 - International Conference on Enterprise Information Systems

280

1998), Latent Semantic Analysis (Landauer, 1998)

and the Correlated Occurrence Analog to Lexical

Semantics (Rhode, 2004) are models based on the

assumption that words are similar if they co-occur in

similar contexts. The models tabulate co-occurrence

in a matrix, in which each row vector codes the co-

occurrence frequency of one word with every other

word in a 4-word window (COALS), in a 10-word

window (HAL) or within a single document (LSA).

Those models exploit lexical co-occurrence

information to represent a certain type of similarity

between words: the contextual co occurrence. The

focus of these models is on word-similarity. Our

method can also be used as a word similarity

measure but structural rather than contextual. The

common concept of these applications is similarity

which defines in what regard objects or items are

alike.

3 OUR METHOD

We use graphs to define structural similarities for IR

purposes. Our method uses graph structure to

capture structural information of documents and

queries. As structural similarities are known to

enhance retrieval precision (Forbus, 1995), we

expect that our method which is based on graph

comparison will have lead to good high precision

information retrieval system.

Figure 1: A two-phase ranking process.

The method we propose consists of two stages: first,

documents are filtered using the Okapi BM25

ranking function (Robertson, 1994) and a prefixed

threshold

; then the selected documents and the

query are stored in the corpus graph then sorted

using a SimRank-based score. We call this 2-stages

method OkaSim.

In practice, we chose zero as a threshold.

3.1 Phase 1: Okapi Sorting

First, we rank documents using the Okapi BM25

similarity measure which is one of the most popular

functions used in IR. Okapi BM25 not only

considers the frequency of the query terms, but also

the average length of the whole collection and the

length of the document under evaluation.



∑

log





·









































































 (1)

Where Q is a query containing term t

N is the number of documents in the collection

n is the number of documents containing the term

tf is the frequency of occurrence of term t within a

specific document

is the frequency of the term i within the query.

dl and avdl are the length of document d and the

average document length for the whole collection

The variable k1 is a positive tuning parameter

that calibrates the document term frequency scaling.

A k

value of 0 corresponds to a binary model (no

term frequency), and a large value corresponds to

using raw term frequency.

b is another tuning parameter (0<= b <1) which

determines the scaling by document length: b=1

corresponds to fully scaling the term weight by the

document length, while b=0 corresponds to no

length normalization.

being another positive tuning parameter that

this time calibrates term frequency scaling of the

query.

We choose k

=1.2; b=0.75; k

=7.0. Further

information about Okapi measure is available in

(Spark Jones, 2000).

We use the Okapi ranking function to filter the

documents: only the documents for which the Okapi

similarity value is superior to a threshold (RSV(d,q)

> τ) are retained. We then apply phase 2 in order to

sort those documents using the method SimRank

(Champclaux

, 2007).

3.2 Phase 2: SimRank Sorting

The aim of this step is to find documents that are

structurally relied to the query. We consider the

bipartite graph where documents and terms are

nodes and where each edge between a document and

a term reflects the fact that this term indexes that

document. As shown in figure 2, the query is viewed

as a document-type node of the bipartite graph.

To compute the structural similarity between a

query and the documents, we iterate an algorithm

which initialize a document to document similarity

Indexed

Corpus

Indexed

Query

Documents

with

positive

BM25

Relevant

Documents

ENHANCING HIGH PRECISION BY COMBINING OKAPI BM25 WITH STRUCTURAL SIMILARITY IN AN

INFORMATION RETRIEVAL SYSTEM

281

Figure 2: Corpus as a bipartite graph.

matrix, then calculate the term to term similarity

matrix using the built graph. We follow the idea that

a term is similar to another one if they appear in

similar documents and a document is similar to

another document if they are related to similar terms.

The similarity function between two documents

(Sd) which updates the similarity values in the

document to document matrix and the similarity

function between two terms (St) which updates de

similarity values in the term to term matrix are

expressed as follows:











,











|





||





∑∑

















,



























(2)











,





























∑∑

















,

























(3)

Where d

is the i

document of the document

collection,

is the i

indexing term,

| (resp. |T

|) is the number of terms in document

i (resp. j),

| (resp. |D

|) is the number of documents in

which t

(resp. t

) appears,

and C

are two propagation coefficients, which

values are between 0 and 1. C

(resp. C

) is used to

moderate the similarity between two terms (resp.

documents) which is calculated as an average

similarity between documents (resp. terms)

containing (resp. contained in) the compared terms

(resp. documents). In (Champclaux, 2007), we

choose to use C

= C

=0,95 to not have too small

values.

(2) defines the similarity between two documents as

a function of similarity measures between the

indexing terms they are related to. Symmetrically,

(3) defines the similarity between terms as a

function of the similarity measures between the

documents they are related to. Thus, for a given

query, we compute the similarity to each document

in the collection, on the basis of the similarities

between the indexing terms; then we compute the

similarity between the terms on the basis of the

previously computed similarities between the

documents. This represents a first iteration; which is

repeated a given number of times. At each iteration

similarities are updated taking into account the

similarities computed during the previous iteration.

This process is stopped when computed similarities

do not change anymore (or when the changes are

below a given threshold). Then, the system retrieves

all documents sorted according to their similarity to

the query. The (2) and (3) formulas could be written

in form of matrix multiplication way as follow

(n>1):











∑





,



∑

,

..





..



(4)











/

∑





,



∑

,

..



..



(5)

(4)

reflects the similarity between two documents at

iteration 









,



.

(5) reflects the similarity between two terms at n

iteration 









,



.

W is the document-term matrix representing corpus

and query, W

is the weight of term j in document i.

is the term to term square matrix at n

iteration,

is the transposed T.

is the document to document square matrix at n

iteration.

is the number of terms

is the number of documents

4 EVALUATION

4.1 Test Collection and Experiments

To evaluate our method, we used the Cranfield

corpus. This corpus consists of 1400 documents and

225 queries. A document from that corpus has an

average number of 53 terms and a query an average

number of 9 terms. 69% of all documents are

composed of terms having a term frequency equal to

one, 95% of terms’ query have a term frequency

equal to 1. 19 queries do not provide an answer (no

documents retrieved) after Okapi ranking; we

choose not to take those queries into account

Document indexing for phase 1 is processed with

Lemur Index Builder. Document indexing for phase

2 is based on IR principles: terms are extracted from

each document, stop words are removed using the

http://www.dcs.gla.ac.uk/idom/ir_resources/test_collections/cran

removed queries : 15 48 68 71 90 97 109 140 141 142 143 153

192 198 200 202 203 204 211

documents

directly

linked to Q

structurally

linked to Q

indexing

terms

…

ICEIS 2009 - International Conference on Enterprise Information Systems

282

SMART stop list of 571 English stop words

, and

the remaining terms are stemmed in order to limit

the variations in syntax. This is performed through

the Snowball algorithm [Porter, 1980]. We filter

again stems and suppress stems for which collection

frequency and term frequency are equal, this

because they do not link two documents, so are not

useful for our method. It also permits to reduce the

data size. Finally, terms are weighted according to

four different weighting schemes from [Salton,

1988]. We ran four different experiments to rerank

the Okapi ranking with four different term weighting

methods:

- OkaSim bxx-bxx (OSb): terms from the documents

(resp. queries) are weighted with 1 if term is present

in the document (resp. query) and 0 otherwise.

- OkaSim txx-txx (OStf): terms from the documents

(resp. queries) are weighted with their term

frequency i.e. the number of times the term occurs in

the document (resp. query).

- OkaSim tfx-txx (OStf.idf): terms from documents

are weighted using tf.idf (multiply original tf factor

by an inverse collection frequency factor) and terms

from queries are weighted by their term frequency.

- OkaSim tfc-nfx (OStfc-nfx): Namely the “Best fully

weighted system” in which terms are weighted using

tf.idf and a cosine normalization. Terms from

queries are weighted using augmented normalized

term frequency (tf factor normalized by maximum

tf, and further normalized to lie between 0.5 and

1.0).

4.2 Evaluation Criteria

To evaluate our method we consider both MAP and

precision at top n retrieved document.

The mean average precision (MAP) is used for

assessing the accuracy of retrieval engines. It

measures the average of precision computed after

each relevant document is retrieved. MAP is defined

as follows:

MAP =





∑















Where N is the collection size: the total number of

the documents

n is the number of relevant documents retrieved

R(i) = 1 if document i is relevant and R(i) = 0 if

document i isn’t relevant

Smart’s English stoplist:

ftp://ftp.cs.cornell.edu/pub/smart/english.stop

p(i) 







with Pert

as the set of relevant

documents after the i

document is retrieved.

Recall is the proportion of relevant document

retrieved in regard of all relevant documents existing

in the given collection.

We’ll use Precision-Recall curves to show how

behave precision for different recall points (i.e. when

0, 10%, 20% … 100% of documents are retrieved).

We use the rank of relevant documents to analyze

their behavior in our system. In order to compare

OkaSim runs to Okapi, we represent the average

rank’s evolution of relevant document

s over all

documents.

5 RESULTS

Table 1: Average MAP and average precision when 10

documents returned for the 5 methods.

Tests MAP Gain%

 Gain%

Okap

0,1156  0,0956

0,1868 61 0,1582 65

0,2343 102 0,1951 104

OStf.id

0,2608 125 0,2165 126

tfc‐n

0,2627 127 0,2131 122

We can see at first glance that our method clearly

enhances the original results of Okapi method. That

is a case for all different term weighting. The second

positive result is that our method is sensitive to term

weighting. The bxx-bxx weighting already overcome

the Okapi method. This suggests that pure structural

information can be useful for IRS. Indeed, the only

use of a term’s presence to relate documents can

already bring relevant documents closer to the top of

the ranking, as we can see with the precision when

10 documents are returned. The txx-txx results show

that the use of term frequency instead of simple

term’s presence improves the Okapi’s results by

100%, and bxx-bxx results by 25%. A better

knowledge on the term’s importance seems useful to

our method, it participates to the quality of links

between documents and terms, and thus, to the

quality of the analysis we can process on the corpus

structure. The MAP result presents the tfc-nfx

method as the best weighting for our system

accuracy. If we take into account the precision when

10 documents are retrieved, the tf.idf weighting

seems a better compromise. For precision when 10

documents are retrieved, OkaSim bxx-bxx do better

ENHANCING HIGH PRECISION BY COMBINING OKAPI BM25 WITH STRUCTURAL SIMILARITY IN AN

INFORMATION RETRIEVAL SYSTEM

283

or equal for 174 queries over the 206, OkaSim tfx-txx

do better or equal for 194 queries over the 206.

Queries n° 34, 52, 122, 186, 191, 199, 202 and 204

are never improved with our methods.

Figure 3: Precision/Recall curves for the 5 methods.

The figure above show precision at different recall

points, it permits us to see how evolves precision

when recall varies from 0,1 to 1.0. If we look at the

precision/recall curve we can see that all curves have

the same shape, methods become closer when recall

is near to 1. We can notice the same method ranking

as for MAP and precision; the tf.idf weighting seems

to be the best weighting when recall is under 0, 1.

We also can see that the tfc-nfx and tfx-txx (tf.idf)

curves are quasi identical.

Figure 4: Average rank of first 10 documents returned for

Okapi and OkaSim using tf.idf.

On Cranfield corpus, the 206 chosen queries have an

average number of relevant documents equal to 8

(between 2 and 29). Okapi return an average of 486

documents per queries in phase 1. Our aim when

reranking is to ensure the rank of relevant

documents. On Figure3 we draw the average rank

(y=axis) for the 10 first relevant documents returned

(x=axis) for all queries to compare original okapi

and OkaSim using tf.idf. We show that our method

has clearly ensured the relevant document ranking.

The three first returned documents ensure their

ranking about 75 places, and the 8

, 9

, 10

returned document about 200 places.

6 CONCLUSIONS

The re-ranking method we propose works well with

the Cranfield corpus and Okapi BM25 measure. The

power of our method is to retrieve documents

indirectly related to the query; this is performed

through the use of the structural similarity that

acknowledges the relationship between documents,

between documents and words as well as between

words.

The main limitation of our method is its high

computational complexity: max,



, t

number of terms and d number of documents. As a

consequence it cannot be used in a real-time

retrieval process, and the use of such method on

bigger corpora will certainly requires optimization

techniques.

In the meantime, it certainly will be interesting to

conduct more testing and assessment that involve

different other corpus. It will also be interesting to

use SimRank in combination with other ranking

measures different from Okapi. We intend to do this

in the context of TREC7 ad-hoc task

. We plan to

use runs submitted to different past TREC tracks to

see if our method will enhance the inputted rankings.

REFERENCES

R. K. Belew, 1989. Adaptive information retrieval. In

Proceedings of the Twelfth Annual International

ACM/SIGIR Conference on Research and

Development in Information Retrieval, pages 11-20,

Cambridge, MA, June 25-28.

Berge, Claude, 1958. Théorie des graphes et ses

applications -Paris : Dunod.

Burgess, C., Livesay, K., & Lund, K. 1998. Explorations

in context space: Words, sentences, discourse.

Discourse Processes, 25, 211-257.

Blondel, V.D, et al., 2004. Measure of Similarity between

Graph vertices: Application to synonym extraction and

web searching, SIAM Rev. 46(4):647-666.

Champclaux Y., Dkaki T., Mothe J. 2007. Utilisation des

similarités structurelles pour l’évaluation de la

pertinence en Recherche d’information. Dans:

Colloque VSST 2007, Marrakech (Maroc)

Champclaux Y., Dkaki T., Mothe J. 2008. Enhancing high

precision using structural similarities. Dans : IADIS

International Conference WWW/Internet, Freiburg,

Germany, 13-OCT-08-15-OCT-08, IADIS, p. 494-498.

S. Deerwester, et al., 1990. Indexing by Latent Semantic

Analysis, in Journal of the Society for Information

Science, 41, p. 391-407.

http://trec.nist.gov

0,2

0,4

0,6

0,8

0 0,1 0,2 0,3 0,4 0,5 0,6 0,7 0,8 0,9 1

Okapi OSb

OStf OStf.idf

OStfc‐nfx

100

200

300

12345678910

Okapi

OkaSimtf.idf

ICEIS 2009 - International Conference on Enterprise Information Systems

284

Euler, 1736, Solutio problematis ad geometriam situs

pertinentis, Commetarii Academiae Scientiarum

Imperialis Petropolitanae 8(1736), 128-140.

Forbus K D Gentner, D &Law, K. 1995. MAC/FAC A

model of similarity-based retrieval. Cognitive Science,

19, 141-205.

Halford, G. S., 1992. Analogical reasoning and conceptual

complexity in cognitive development. Human

Development, 35, 193-217.

Hattori, et al., 2003. Development of a chemical structure

comparison method for integrated analysis of chemical

and genomic information in the metabolic pathways, J.

Am. Chem. Soc., 125(39):11853–11865.

Heymans M., Singh A. K., 2003. Deriving phylogenetic

trees from the similarity analysis of metabolic

pathways. Bioinformatics 19, Suppl. 1, 138--146. 1.

Jones, S. S. and Smith, L. B., 1993. The place of

perception in children's concepts. Cognitive

Development, 8, 113-139.

Kleinberg, J.M., 1999. Authoritative Sources in a

hyperlinked environnement, Journal of the ACM,

46(5):604-632.

Landauer, T. K., Foltz, P. W., & Laham, D. 1998. An

introduction to latent semantic analysis. Discourse

Processes, 25, 259-284.

D.L. Medin, R.L. Goldstone, and D. Gentner, 1990

‘Similarity involving attributes and relations:

Judgments of similarity and difference are not

inverses’, Psychological Science, 1(1): 64-69.

Milgram, S., 1967. The Small world problem. Psychology

today 1(61).

Mothe, J. 1994. Search mechanisms using a neural

network-Comparison with the vector space model. 4th

RIAO Intelligent Multimedia Information Retrieval

Systems and Management, Vol.1, pages 275-294, New

York.

Porter, M.F., 1980. An algorithm for suffix stripping,

Program, vol. 14, no 3, p.130-137.

Robertson S. E., Walker S., Jones S., Hancock-Beaulieu

M., and Gatford M.. 1994. Okapi at TREC-3. In

Proceedings of the Third Text REtrieval Conference

Gaithersburg, USA.

Rohde, D. L. T., Gonnerman, L. M., & Plaut, D. C. 2004.

An improved model of semantic similarity based on

lexical co-occurrence. Cognitive Science. (submitted).

Salton G., Wong A.; Yang, 1975. Vector-Space model for

automatic indexing. Communication of the ACM

18(11):613-620.

Salton, Chris Buckley; 1988. Term-Weighting Approaches

in Automatic Text Retrieval. Inf. Process. Manage.

24(5): 513-523.

SpärckJones, Karen, S.Walker,and Stephen E.Robertson

2000. A probabilistic model of information retrieval:

Development and comparative experiments.

Information Processing and Management pp.779–808,

809–840.

Watts, D.J., 1999. Small Worlds

, Princetown University

Press.

ENHANCING HIGH PRECISION BY COMBINING OKAPI BM25 WITH STRUCTURAL SIMILARITY IN AN

INFORMATION RETRIEVAL SYSTEM

285
