A NEW REDUCTION METHOD OF INTRUSION DETECTION

FALSE ALERTS USING SNORT

Ben Soh, Daniel Bonello

Department of Compugter Science & Computer Engineering, La Trobe Ubiversity

Bundoora, VIC, Australia 3083

Keywords: Intrusion Detection, False Alerts, Snort

Abstract: In this paper, we propose a new approach to red

ucing the high levels of false positives encountered when

deploying an intrusion detection system using Snort in a real live networking environment. We carry out an

analysis of the effectiveness of such method in different networking environments. We conclude that the

level of false positives is reduced considerably with the introduction of our implemented pass rules and that

the rates at which false positives are generated become manageable.

1 INTRODUCTION

Snort (M. Roesch, 1998) is a lightweight network

intrusion detection tool, capable of preforming real-

time traffic analysis and packet logging on IP

networks. It can preform protocol analysis, content

searching/matching and can be used to detect a

variety of attacks and probes.

Snort uses a flexible rules language which

syntactically p

rovides an effective and manageable

means of directly configuring which types of

network traffic should be either passed or collected.

Snort also provides a modular plug-in architecture

which is used by the detection engine along with real

time alerting capabilities through syslog, a user

specified file, UNIX sockets or WinPopup messages

to Windows clients using Samba’s “smbclient”. In

this case study, Snort version 2.0 was used which

monitors TCP, ICMP and UDP traffic.

We used a large network dispersed over many

eographical sites within our metropolitan suburbs.

The network consists of approximately 25 servers

and over 400 client nodes, and provides an excellent

means of which to deploy and test the Snort

intrusion detection system (IDS) (J. McHugh et al.,

200) (Z. Yanchao et al., 2001).

Snort was deployed intentionally to monitor internal

traffic and not external traffic. The orga

nisation

firewall is only permitted to pass through SMTP

traffic on port 25 from any external source.

Internally, the network experiences a range of packet

types from TCP, ICMP and UDP packets to IPX,

ARP and SNMP traffic.

The organisation uses many common software

packa

ges such as Lotus Notes R5, Microsoft

Exchange, Novelle Netware Administrator,

Windows NT 4.0 Client and Server, Citrix Clients

and an email filtering system.

2 MOTIVATION

Upon setting up Snort to initiate as a service and

rebooting, it seems initially that traffic was either

being bypassed all together, or that no actual rule

triggering traffic was experienced. The rule set had

been verified and included in the Snort configuration

file. Although it didn’t take Snort long to begin

alerting on packets which exhibited matches to rules

defined in the rule set.

Initially, it is quite hard to know what to expect from

e first batch of alerted rules. Is the system actually

being attacked the reported number of times? This is

hardly unlikely.

After an initial 34 hour running period, 2604 alerts

were av

ailable for observation through the console.

Effectively, this has provided motive for the purpose

of research. Leaving the system in this state would

prove unmanageable.

Soh B. and Bonello D. (2004).

A NEW REDUCTION METHOD OF INTRUSION DETECTION FALSE ALERTS USING SNORT.

In Proceedings of the First International Conference on E-Business and Telecommunication Networks, pages 46-53

DOI: 10.5220/0001397300460053

 SciTePress

We aim to (i) benchmark (M. Ranum, 2001) the

organisation’s network to achieve a better

understanding of the networking traffic experienced

by the Snort sensor; (ii) propose and test (N. Puketza

et al., 1996) a new reduction method and verify their

effectiveness in reducing the false alerts to

acceptable manageable levels.

3 A NEW FALSE ALERT

REDUCTION METHOD

Common practice has to be adopted in order to

effectively navigate through the initial list of

generated alerts. This would prove useful in dealing

with the many new and sometimes highly numerous

alerts which would be encountered later.

We propose the following common, basic practices:

1. Verify the source IP address and subnet

from which the packet has originated from.

In some cases, the source port is also

observed and verified, making sure traffic

of this type is permitted through the given

port on the source host.

2. Apply the same procedure as above to the

destination section of the packet, making

sure traffic of this type is permitted to a

particular destination on a given port.

3. Acknowledge the packet type and its place

in the networking environment.

4. Research the rule definition and what

networking conditions trigger the

particular alert.

5. Understand the rule and how the

subsequent alert definition is triggered by a

packet.

6. Provide an alert summary to justify why

the alert has been triggered.

7. Understand the alert severity.

8. Understand the amount of times the alert

was triggered.

By applying these steps to each rule and then

effectively to groups of likened alerts, it is possible

to systematically work through the ever growing list

of alerts, with the main goal in mind not to miss an

alert which may in fact report an actual happening of

malicious activity.

To conclude each alert, we have to decide whether

the trigger is a false positive or a false negative. As

the system had just been deployed it was expected

that many if not all alerts were false positives. By

analysing each source in depth, we are able to

provide evidence of rule triggering events, which are

unintentional and hence, do not exhibit malicious

intent.

From the alerts database, a common, manual

reduction method is used, which involves locating

the original Snort rule within the Snort rule set and

applying the necessary changes to it. The method

then re-deploys the edited rule back into the Snort

rule set and enabling it for processing.

For example, the following alert:

alert udp $EXTERNAL_NET any -> $HOME_NET

67 (content:"|01|"; offset:0; depth:1;

byte_test:1,>,6,2; classtype:misc-activity;)

can simply be changed to:

alert udp !192.168.1.32/32, 192.168.1.0/24 any ->

$HOME_NET 67 (content:"|01|"; offset:0; depth:1;

byte_test:1,>,6,2; classtype:misc-activity;)

Here, the original rule has been edited so that the

whole subnet of 192.168.1.0/24 is monitored with

exceptions to a single source IP address of

192.168.1.32 where the rule options do not apply.

This effectively bypasses 192.168.1.32 from

matching the rule options and prohibits the false

positives from being generated from this source.

This flexible rule syntax would then allow all rules

within the rule set to be edited this way, reducing the

total number of false positives without having to

terminate network services and resources. However,

in this method, manually searching through the large

Snort rule set to find the rule that requires editing is

extremely time consuming (Y Qiao et al., 2002).

In this paper, we propose a new reduction method,

which involves creating new rules without having to

locate and edit existing rules. These new rules,

called pass rules, are created in a separate rule set

which are then part of the larger Snort rule set. Snort

requires more configuration work in order to utilize

these new pass rules, as it would be pointless to

trigger on a packet and then pass it. Snort would

then be configured to execute the pass rule set first,

after which, would carry out all other rule

processing.

A NEW REDUCTION METHOD OF INTRUSION DETECTION FALSE ALERTS USING SNORT

Using the previous example, passing UDP traffic

from source 192.168.1.32 which matches the rule

options involved creating the rule below:

pass udp 192.168.1.32/32 any -> $HOME_NET 67

(content:"|01|"; offset:0; depth:1; byte_test:1,>,6,2;

classtype:misc-activity;)

which informs Snort to pass traffic matching the rule

type and options.

Therefore it is quite easy to create pass rules when

required and which are stored locally in a separate

rule set making the overall larger Snort rule set more

organised and hierarchically based on the rules

processing priority.

4 PERFORMANCE EVALUATION

The main objective here is to test trial the

implemented reduction method at different stages

experienced by the network. The organisation’s

network is known to experience different traffic

workload during two distinctive periods. The peak

period is between 8:00am and 5:30pm weekdays,

while the off-peak period is between 5:30pm to

8:00am weekdays and includes all weekends.

During these periods, traffic is analysed as to

understand the types of packets monitored by the

sensor. Once this has been established, pre-

scheduled SYN, FYN and fragmented SYN attacks

will be launched at different times during the

periods. This will provide a means of validating the

sensors ability to detect valid malicious behaviour.

The experiments are carried out with the

implemented pass rules enabled, and then again with

the rules disabled. Doing this provides a direct

means to observe the effectiveness of the rules

implemented.

4.1 Test Case Considerations

The purposes of test cases are to:

• establish a baseline of traffic conditions

experienced by the network during the off-

peak period;

• confirm pre-scheduled attacks are detected

during the experienced traffic conditions;

• understand the types of packets flowing

through the subnet;

• compare between enabled and disabled pass

rules results.

A test case consideration is not to benchmark the

network by generating high traffic loads for the

sensor because this would produce misleading

results. High traffic loads may very well be the

prelude of malicious activity or constitute an actual

attack. Other points which we consider include:

• Only traffic from one subnet is to be

considered when benchmarking.

• Snort is only capable of monitoring three

types of packets : UDP, TCP and ICMP.

• Conditions used for testing are real

environment conditions, which the IDS will

be subjected to.

During execution of each test case, the sensor will

not be used for any other purpose so as not to hinder

benchmarking results.

4.2 Analysing Reduction Methods

through Test Cases

As mentioned previously, the main objective of the

test cases is to measure the effectiveness and need

for reduction methods of false alarms on the

network. To achieve this, the network is

benchmarked at peak and off-peak periods where

pre-scheduled attacks are launched at different

intervals during these periods. This process is done

once with pass rules enabled and then once again

with pass rules disabled.

Knowing exactly how many alerts are triggered by

each launched, pre-scheduled attack, allowed for any

missed attacks during each scenario to be easily

detectable. A complete listing of test cases used is

included in Appendix A.

4.3 Test Case Results and Analysis

For all test cases, the results are recorded and

reported. Each test case is analysed thoroughly and

so is each recorded field. Once all test cases are

successfully executed, the results are compared.

Because of space constraints, we give a sample

result only.

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

Test Case 1 Results

Test Case 1 Off-Peak

Execution Condition : Pass Rules Enabled

Characteristic Value Measured Comments

Packet Count 443,924

Average Packet/sec 7.751

Average Packet Size (bytes) 165.550

Average Bytes/sec 1283.154

Bytes of Traffic 73,491,646

Total Dropped Packets 0

Execution Time (seconds) 57274.24

Packet Types : All Ethernet Frames

Packet Type Extended Packet Type % of Total Packets

Logical – Link Control 44.16

Spanning Tree Protocol 6.43

Internetwork Packet eXchange 37.22

CISCO Discovery Protocol 0.21

NETBIOS 0.03

Datagram Delivery Protocol 0.26

AppleTalk 0.01

Address Resolution Protocol (ARP) 5.73

DEC Spanning Tree Protocol 12.90

Internet Protocol (IP) 4.35

User Datagram Protocol 4.27

Internet Group Management 0.02

Transmission Control Protocol 0.02

Internet Control Message Protocol 0.04

Internetwork Packet eXchange (IPX) 32.83

Service Advertisement Protocol 14.66

IPX Routing Information Protocol 1.08

NETBIOS over IPX 7.41

Simple Network Management

Protocol

4.91

Name Management Protocol over

IPX

2.97

Sequence Packet Exchange 1.80

Data 0.03

A NEW REDUCTION METHOD OF INTRUSION DETECTION FALSE ALERTS USING SNORT

Alerts Detected (Non Pre-Scheduled Attacks)

Aler

Typ

Alert Signature Alert

Severity

Trigger Cause Time/Date of Alert

& Total Number of

Alerts

Alert

Diagnosis

ICM

alert icmp

$EXTERNAL_NET

any -> $HOME_NET

any (itype: 0;

classtype:misc-

activity;)

Medium A host has replied to

an ICMP Echo

request with an ICMP

Echo reply with an

invalid or undefined

ICMP code

Time :17:35:21pm

Date : 16th Sep

This alert was

reported 1 time.

False

Positive

Execution Condition : Pass Rules Disabled

Characteristic Value Measured Comments

Packet Count 389099

Average Packet/sec 7.21

Average Packet Size (bytes) 157.59

Average Bytes/sec 1135.52

Bytes of Traffic 61317293

Total Dropped Packets 0

Execution Time (seconds) 53999.29

Ethereal Statistics: Print Screen 6.3

Kerio Traffic Graph: Traffic Graph 6.3

Packet Types : All Ethernet Frames

Packet Type Extended Packet Type % of Total Packets

Logical – Link Control 46.05

Spanning Tree Protocol 6.92

Internetwork Packet eXchange 38.58

CISCO Discovery Protocol 0.23

NETBIOS 0.04

Datagram Delivery Protocol 0.28

AppleTalk 0

Address Resolution Protocol (ARP) 9.31

DEC Spanning Tree Protocol 13.87

Internet Protocol (IP) 3.92

User Datagram Protocol 3.9

Internet Group Management 0.01

Transmission Control Protocol 0

Internet Control Message Protocol 0.01

Internetwork Packet eXchange (IPX) 26.83

Service Advertisement Protocol 13.73

IPX Routing Information Protocol 0.94

NETBIOS over IPX 3.41

Simple Network Management

Protocol

5.29

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

Name Management Protocol over

IPX

1.52

Sequence Packet Exchange 1.94

Data 0.02

Alerts Detected (Non Pre-Scheduled Attacks)

Aler

Typ

Alert Signature Alert

Severity

Trigger Cause Time/Date of Alert

& Total Number of

Alerts

Alert

Diagnosis

Not detailed as pass rules are disabled and many non-scheduled attacks are expected

During the off-peak experiments, both cases PRE

(pass rules enabled) and PRD (pass rules disabled)

produced traffic conditions which are easily

maintainable with a 100MBit connection,

0.01MBit/sec and 0.009MBit/sec respectively.

With the PRE, only 1 non-scheduled attack alert was

reported in 70.09MB of monitored data compared to

120 alerts reported with the PRD in 58.48MB of

monitored data for the off-peak period. This proves

that it is crucial to have pass rules implemented on

known false positives.

The percentage of packets actually monitored by the

sensor is 4.33% for PRE and 3.92% for PRD of the

total packets flowing passed the sensor in the given

execution time. These low percentages have limited

our experimental work. Future releases of Snort are

to accommodate more packet types such as ARP and

IPX.

Peak analysis stretches the test cases to their limits

and effectively tests the limitations of the systems

specifications and networking connections. Through

the PRE cases, 0.02Mbit/sec traffic was experienced

through 68.05MB of monitored data with no false

positives. PRD shows 0.013MBit.sec with 41.83MB

of monitored data and 1094 extra false positives.

This amount is quite considerable when maintaining

an IDS on a daily basis.

The experiment also shows a significant amount of

missed alerts based on the pre-scheduled attacks. 27

fragmented packets did not generate alerts and were

effectively missed by the sensor. Overall, a total of

216271 packets were dropped, indicative of the low

monitored data result of 41.83MB. The total amount

of dropped data is approximately 36.1MB, based on

the average packet size calculated throughout the

duration of the execution. This has provided

additional evidence showing the importance of

enabling the pass rules during peak network traffic.

The percentage of packets monitored with PRE and

PRD is 4.94% and 18.5% respectively. The higher

percentage of monitored packets for the peak PRD

test case is simply a result of the type of network

usage conducted by the users of the subnet at the

time.

5 CONCLUSION AND FUTURE

WORK

We can see that the level of false positives is

reduced considerably with the introduction of the

implemented pass rules. The rates at which false

positives are generated become manageable. We

find that in peak periods, the PRD results show false

negatives and dropped packets. Yet under the same

conditions with PRE, there are no reported false

negatives or dropped packets. So this has proven yet

again the importance of maintaining and reducing

the high levels of false positives, using our proposed

method.

Future work on the current Snort IDS setup includes

rendering the sensor as an inaccessible network

resource. This has many benefits and must be

considered as attacks on the sensor itself render the

whole network vulnerable to undetectable attacks. A

successful attack on a sensor could see pass rules

edited or the service stopped allowing the attacker to

roam free. There are two known ways of rendering a

sensor inaccessible, the first via registry edits and

the second through physically limiting the

capabilities of the network cable (wiring).

A NEW REDUCTION METHOD OF INTRUSION DETECTION FALSE ALERTS USING SNORT

REFERENCES

M Roesch, “Snort: The Open Source Network Intrusion

Detection System”, http://www.snort.org, December,

1998.

J McHugh et al, “Defending yourself: the role of intrusion

detection systems”, IEEE Software,

September/October 2000.

Z Yanchao et al, “An immunity-based model for network

intrusion detection”, Proceedings of International

Conference on Info-tech and Info-net, Beijing, 2001.

M Ranum, “Experiences benchmarking intrusion detection

systems”, NFR Security Technical Publications,

http://www.nfr.com, December, 2001.

N Puketza et al, “A methodology for testing intrusion

detection systems”, IEEE Transactions on Software

Engineering, October, 1996.

Y Qiao and X Weixin, “A network IDS with low false

positive rate”, Proceedings of the Congress on

Evolutionary Computation, 2002.

APPENDIX A

Test Case 1 : Off Peak

Purpose of Test Description Testing Period Launch Test Attacks

Test network traffic

characteristics during

the off-peak period.

Test ability to detect

attacks during this

network traffic

environment.

Monitor the traffic

passing through the

monitored subnet and

report on various traffic

characteristics. Also

review total alerts

generated.

5:00pm to 8:00am. A

15 hour execution

period which sees the

network in its off peak

state.

Launch Test Case 3.1

with enabled pass rules.

Launch Test Case 3.2

with disabled pass

rules.

Report On

Characteristic Value Reported

Packet Count

Packet Type % of Frames

Average Packet/sec

Average Packet Size

Average Bytes/sec

Bytes of Traffic

Total Dropped Packets

Execution Time (sec)

Alert Reports (Non Pre-Scheduled Attacks)

Alert Type Alert Signature

Alert Severity

Trigger Cause Alert Diagnosis Total Alerts

Comments

• Establish a baseline of traffic conditions experienced by the network during off-peak periods

• Confirm pre-scheduled attacks are detected during the experienced traffic conditions

• Understand the types of packets flowing through the subnet

• Comparisons between enabled and disabled pass rules

ICETE 2004 - SECURITY AND RELIABILITY IN INFORMATION SYSTEMS AND NETWORKS

Test Case 2 : Peak

Purpose of Test Description Testing Period Launch Test Attacks

Test Network Traffic

Characteristics during

peak period.

Test ability to detect

attacks during this

network traffic

environment.

Monitor the traffic

passing through the

monitored subnet and

report on various traffic

characteristics. Also

review total alerts

generated.

8:00am to 5:00pm. A 9

hour testing period

which monitors the

network during peak

usage.

Launch Test Case 3.3

with enabled pass rules.

Launch Test Case 3.4

with disabled pass

rules.

Report On

Characteristic Value Reported Packet Type % of Total Frames

Packet Count

Average Packet/sec

Average Packet Size

Average Bytes/sec

Bytes of Traffic

Total Dropped Packets

Execution Time (sec)

Alert Reports (Non Pre-Scheduled Attacks)

Alert Type

Alert Signature

Alert Severity

Trigger Cause

Alert Diagnosis Total Alerts

A NEW REDUCTION METHOD OF INTRUSION DETECTION FALSE ALERTS USING SNORT
