SENSdesc: Connect Sensor Queries and Context

Dörthe Arndt

, Pieter Bonte

, Alexander Dejonghe

, Ruben Verborgh

Filip De Turck

and Femke Ongenae

IDLab, Department of Electronics and Information Systems, Ghent University – imec, Belgium

IDLab, Department of Information Technology, Ghent University – imec, Belgium

Keywords:

N3, Stream Reasoning, Rule-based Reasoning, Proofs, IoT.

Abstract:

Modern developments confront us with an ever increasing amount of streaming data: different sensors in

environments like hospitals or factories communicate their measurements to other applications. Having this

data at disposal faces us with a new challenge: the data needs to be integrated to existing frameworks. As the

availability of sensors can rapidly change, these need to be ﬂexible enough to easily incorporate new systems

without having to be explicitly conﬁgured. Semantic Web applications offer a solution for that enabling

computers to ‘understand’ data. But for them the pure amount of data and different possible queries which can

be performed on it can form an obstacle. This paper tackles this problem: we present a formalism to describe

stream queries in the ontology context in which they might become relevant. These descriptions enable us to

automatically decide based on the actual setting and the problem to be solved which and how sensors should

be monitored further. This helps us to limit the streaming data taken into account for reasoning tasks and

make stream reasoning more performant. We illustrate our approach on a health-care use case where different

sensors are used to measure data on patients and their surrounding in a hospital.

1 INTRODUCTION

With the development of new technologies and the

possibility to rapidly produce and store more and

many different kinds of data, health care systems have

new opportunities: Next to the classical electronic

health records (EHR) of patients, they can use back-

ground data clarifying diseases, their diagnosis and

possible cure, organisational data (e.g. the availability

and competences of staff members in a hospital) but

also data produced by sensors for example to measure

values on patients (e.g. their blood pressure or pulse),

or to control the patient’s ambience in a hospital

(e.g. the illumination or temperature in his room).

To combine these in a meaningful way, Semantic

Web reasoning systems are particularly well suited:

their declarative approach allows the user to explain

concepts represented by the data and to specify how

for example the known EHR and newly measured

values of a patient relate to each other. If the system

knows how to interpret the values of a speciﬁed kind

of sensor, it is easy to add and remove new instances

of this type. But as most computer systems, Semantic

Web implementations also have to cope with the

challenges of Big data

: if they have to deal with with

a huge volume and different forms of data (variety),

which can come in a high velocity, for example in data

streams, and in different levels of quality (veracity),

the performance of the systems can be rather poor.

In this paper we aim to tackle this problem: in

a setting where many sensors are present and a re-

quest constantly needs to be answered, our approach

ﬁnds the sensors relevant for this speciﬁc goal. These

sensors and their results can then be monitored more

closely while others, not relevant for the problem, can

be ignored. By that, the amount of data taken into ac-

count can be reduced. To do so, we developed a spe-

cial format to describe possible sensor queries con-

sisting of three parts: the context in which a sensor

query becomes relevant, the query itself, and the con-

sequence in terms of the ontology used. Together with

the related knowledge the descriptions enable a rea-

soner to produce a formal proof which we use to ﬁnd

the sensor queries contributing to the goal.

The remainder of this paper is structured as fol-

lows: In Section 2 we illustrate a scenario in which

our application can be used. This serves as a running

http://www.ibmbigdatahub.com/infographic/four-vs-

big-data

Arndt D., Bonte P., Dejonghe A., Verborgh R., De Turck F. and Ongenae F.

SENSdesc: Connect Sensor Queries and Context.

DOI: 10.5220/0006733106710679

In Proceedings of the 11th International Joint Conference on Biomedical Engineering Systems and Technologies (HEALTHINF 2018), pages 671-679

ISBN: 978-989-758-281-3

example throughout the whole paper. In Section 3 we

provide the background knowledge needed to under-

stand our solution. After that, in Section 4 we ex-

plain the details of our implementation including our

new description format and the use of formal proofs

to determine relevant sensor queries. In Section 5 we

discuss the relation of our approach to other research.

We conclude our paper by Section 6.

2 USE CASE

The use case of this paper is set in a hospital. This

hospital is equipped with a large number of differ-

ent sensors to monitor, among others, the tempera-

ture and light intensity in a room, values related to the

patient’s health, e.g. pulse, blood pressure and body

temperature, and the location of staff members and

patients. We want to enable a computer to use this

data in order to answer requests or to detect critical

situations. These situations do not only depend on

the sensor values themselves, but also on their sur-

rounding: patients, their diseases, settings in the hos-

pital like rooms and locations of the sensors and many

more aspects could inﬂuence the decision, whether a

sensor value is normal or alarming. Such surround-

ings can change: patients enter and leave the hospi-

tal, sensors are added or removed. Our system should

thus take the context into account, and easily adapt

to possible changes. We therefore use Semantic Web

technology and describe the data itself and the con-

text of the sensor setting in a machine understandable

way. If the system understands the concept of a light

sensor, it knows how to deal with a new instance of

such a device. Only the new sensor and its surround-

ing need to be described, the concrete use of the sen-

sor, e.g. threshold values, can be deducted from the

knowledge. The ontology we use includes the hospi-

tal and its rooms, the patients and their diseases, and

the descriptions and locations of the different sensors.

We aim to ﬁnd in the current setting all possible kinds

of problems which could be detected by a sensor.

In our ontology, we call these problems faults.

Such faults could be caused by many reasons like an

alarming sensor value (e.g. the luminance, sound or

temperature in a room is a above or below a critical

threshold ), or faulty sensors (e.g. a temperature, lu-

minance or sound sensor does not work properly ).

As stated, faults depend on context like patient pro-

ﬁles and locations or the general sensor set-up in the

hospital: While a pulse of 110/min might be alarm-

ing for a grown-up, it is totally normal for an infant.

Similarly, whether the light in a room is too bright

depends on who is using the room: a patient suffer-

ing from a concussion is more sensitive to light than

a patient treated for Parkinson. In an empty room the

light intensity does not inﬂuence the well-being of the

patients and is therefore irrelevant in our case.

This relevance of context makes the detection of

faults a complex task. While in a small or simple set-

ting where either context is irrelevant or the number of

sensors is small, it is no problem to perform reasoning

on the sensor data whenever a value changes, this is

different for the given situation. Each reasoning task

takes time (depending on its complexity the task can

take seconds on a common computer (Arndt et al.,

2015)) and the performance of computers present in

hospitals is often limited.

We therefore want to ﬁnd out early in the current

setting (e.g. rooms of patients, patients’ diagnosis):

1. Which sensors are relevant to our request, i.e.

which sensors could detect a fault?

2. Which values are critical for these sensors?

This allows us to monitor only these sensors and

queries, and just perform complex reasoning when

critical values are measured.

3 BACKGROUND

This section introduces the background required to

understand the details of our implementation. In par-

ticular these are: the logic employed, N (Berners-

Lee et al., 2008), the notion of proofs in N, and the

possibility of performing OWL reasoning in N.

3.1 N3Logic

Invented about a decade ago by Tim Berners-Lee et

al. (Berners-Lee et al., 2008), NLogic (N) forms a

superset of RDF (Cyganiak et al., 2014). As in RDF,

simple N statements are expressed by triples consist-

ing of URIs, literals and blank nodes (starting with

_:). The latter stand for existentially quantiﬁed vari-

ables. The formula

_:x :likes :ice-cream.

means: ‘There exists someone who likes ice cream.’

Additionally to these existential variables, N sup-

ports universal variables starting with the symbol ?:

?x :likes :ice-cream.

means: ‘Everyone likes ice-cream.’ Universal vari-

ables are mostly used in rules, which we state using

curly brackets { } and the implication symbol =>:

{?x a :Child}=>{?x :likes :ice-cream}. (1)

1 PREFIX : <http://example.org/sensdesc#>

2 PREFIX r:

<http://www.w3.org/2000/10/swap/reason#>

4 <#lemma3 > a r : I n f e r e n c e ;

5 r : g i v e s { : Ben : l i k e s : i c e − c ream . } ;

6 r : e v i d e n c e ( <# lemma2 > ) ;

7 r : r u l e <#lemma1 > .

Listing 1: Example inference step. Formula 3 gets

derived by applying the rule in Formula 1 (lemma 1)

on Formula 2 (lemma 2).

stands for: ‘If x is a child then x likes ice cream.’ or

shorter ‘All children like ice-cream.’ The same nota-

tion of curly brackets can be used to cite formulas:

:Ana :knows {:Ben :likes :ice-cream.}.

This means: ‘Ana knows that Ben likes ice-cream.’ A

more detailed introduction to the syntax and seman-

tics of N can be found in the corresponding speciﬁ-

cation (Berners-Lee and Connolly, 2011).

3.2 Proofs in N3

N expressions as introduced above can be given to a

reasoner which then derives new knowledge from that

and provides a proof. A proof is a description of all

the steps performed to come to a conclusion. Given a

set of triples and rules D, and a goal g, i.e. a formula

which should be veriﬁed, these steps can be: (1) read-

ing a valid formula, i.e. an axiom from D, this formula

can either be a simple triple or rule, or a conjunction

of these, (2) perform conjunction-elimination, i.e. se-

lect one conjunct from a conjunction, (3) apply a rule

to a set of triples (modus ponens), or (4) perform a

conjunction introduction, i.e. form the conjunction of

two or more proven formulas.

The proofs produced by N reasoners are them-

selves given in the N format using the vocabulary

of the Semantic Web Application Platform (SWAP)

(Berners-Lee, 2000). Each step mentioned above has

a name: (1) r:Parsing

. is the name for axiomatiz-

ing, (2) r:Extraction stands for conjunction elimi-

nation, (3) r:Inference refers to the modus ponens,

and (4) r:Conjunction to conjunction introduction.

The connection of these steps to their results is ex-

pressed using the predicate r:gives. The valid for-

mulas directly taken into account for the proof steps

r:Extraction, r:Conjunction and r:Inference

are displayed by referring the reasoning step which

lead to them (r:because, r:component, and the pair

The preﬁx r refers here and for the remainder of

this paper to the name space http://www.w3.org/2000/

10/swap/reason#

1 PREFIX WA: <...WSNextensionAccio.owl#>

2 PREFIX SN: <...SSNiot.owl#>

3 PREFIX owl:<http://www.w3.org/2002/07/owl#>

5 WA: L u mi n a n ce A b o ve T h res h o ldF a u lt

6 a owl : C l a s s ;

7 owl : e q u i v a l e n t C l a s s [

8 a owl : R e s t r i c t i o n ;

9 owl : o n P r o p e r t y SN : hasSymptom ;

10 owl : s omeVal uesFro m

11 WA: Lumi nanc eAbo veTh resholdSympto m

12 ] .

Listing 2: Axiom using owl:someValuesFrom.

r:rule and r:evidence, respectively). In case of

r:Parsing the source is given (using r:source).

As the step r:Inference is particularly important

for our application we consider an example: Listing 1

explains, how the reasoner

applies Rule 1 to the fact:

:Ben a :Child. (2)

and comes to the result

:Ben :likes :ice-cream. (3)

In the example, Rule 1 is obtained by a r:Parsing

and r:Extraction (not displayed here) which to-

gether lead to Lemma 1, the rule is thus the result of

this lemma. The same steps performed on another in-

put lead to Lemma 2 which has Formula 2 as a result.

Listing 1 speciﬁes Lemma 3 which is an instance

of the proof step r:Inference (line 4). This lemma

takes the result of Lemma 2 (i.e. Formula 2) as

input triple. This is indicated using the predicate

r:evidence (line 6). It then applies the rule derived

by Lemma 1 (i.e. Rule 1) on it. This relation is ex-

pressed by using the predicate r:rule (line 7). This

leads to (r:gives) Formula 3 as a conclusion (line 5).

A proof contains all such applications of rules

which contributed to the derivation of the goal. Fur-

ther information about the proof calculus can be

found in our previous work (Verborgh et al., 2017).

3.3 OWL and N3

Next to N and RDF there is a third format typically

used in the Semantic Web to represent knowledge, the

Web Ontology Language (OWL) (Bock et al., 2012).

This Description-Logic-based format is very strong in

its expressiveness but the tableaux algorithm normally

All proofs and proof steps shown in this paper are pro-

duced by the EYE reasoner (Verborgh and De Roo, 2015).

In this and all the following listings the dots (...) in the

preﬁx declaration stand for http://IBCNServices.github.io/

Accio-Ontology/.

1 PREFIX owl:<http://www.w3.org/2002/07/owl#>

3 { ?D owl : e q u i v a l e n t C l a s s ?C .

4 ?C owl : someVal uesFrom ?Y .

5 ?C owl : o n P r o p e r t y ? P .

6 ?U ?P ?V .

7 ?V a ?Y .

8 }= >{?U a ?D} .

Listing 3: OWL RL rule for owl:someValuesFrom.

used to reason on it is rather slow compared to other

mechanisms (Krötzsch, 2012; Arndt et al., 2015).

Our implementation uses OWL ontologies over

which we reason using the rule based logic N. OWL

has the sub-proﬁles (Calvanese et al., 2012), OWL

RL, QL and EL. The proﬁle OWL-RL contains all

constructs expressible by simple Datalog (Abiteboul

et al., 1995) rules. This is natively supported by N

(Arndt et al., 2016). But as N also covers existen-

tial rules, i.e. rules with existentially quantiﬁed vari-

ables in their conclusion, it also supports OWL con-

structs not present in OWL-RL. An example is the

OWL predicate owl:someValuesFrom for which in

OWL RL only supports the subclass version.

The property restriction owl:someValuesFrom

for a predicate p on a class C means, that each in-

stance of C has at least one value connected to it via

p. The object of owl:someValuesFrom determines

the class to which that connected value belongs. To

illustrate that we display the description of the ex-

ample class WA:LuminanceAboveThresholdFault

in Listing 2. This class covers a special kind of

faults and is deﬁned (using owl:equivalentClass)

as the class of all instances which have a symp-

tom (SN:hasSymptom) being an instance of the class

WA:LuminanceAboveThresholdSymptom. Given

:observation1 SN:hasSymptom [

a WA:LuminanceAboveThresholdSymptom]. (4)

the description enables the reasoner to apply the RL

rule in Listing 3 and conclude that

:observation1 a

WA:LuminanceAboveThresholdFault. (5)

But the mechanism also needs to work the other

way around. Given an instance of a class with

a owl:someValuesFrom restriction on a property

p like in Formula 5 where :observation1 is a

WA:LuminanceAboveThresholdFault, it can be de-

rived that there exists an object of the class indicated

In the actual implementation we have extra rules to

handle owl:equivalentClass. We just added its handling

to this rule to make our example self-explaining.

1 PREFIX owl:<http://www.w3.org/2002/07/owl#>

3 { ? x a ?C

4 ?C owl : e q u i v a l e n t C l a s s

5 [ owl : o n P r o p e r t y ? p r o p e r t y ;

6 owl : someVal uesFrom ? from ] .

7 }= >{? x ? p r o p e r t y _ : e . _ : e a ? f rom . } .

Listing 4: Existential rule for owl:someValuesFrom.

in the class axiom which is connected to that in-

stance via p. In our example, that is an instance of

the class WA:LumincanceAboveThresholdSymptom

connected to our :observation1 via the property

SN:hasSymptom. The existential rule displayed in

Listing 4 produces the expected result, it derives For-

mula 4 from Formula 5 and Listing 2. By implement-

ing this and other rules, we extended the set of OWL

concepts supported by our rule based implementation.

4 IMPLEMENTATION

After having explained use case and background

knowledge, we now clarify how we solve the prob-

lem at hand, the identiﬁcation of sensors and sensor

queries which can be used to detect alarming situ-

ations. The basic idea of our approach is, given a

description of the hospital’s setting, to use existen-

tial rules to describe possible sensor queries and their

meaning in terms of the ontology. We call that for-

mat SENSdesc. Together with a general goal, i.e. a

request to be answered, a reasoner can employ all the

knowledge to produce a proof. If this proof contains

the instantiated version of a sensor query, this occur-

rence indicates that in the given context this query is

relevant and needs to be monitored. We explain the

details of this idea below.

4.1 Description of Context

To be able to use the knowledge about context in a

hospital to determine which sensors need to be ob-

served carefully and for which values, this context

knowledge needs to be described in a machine under-

standable way. In our implementation we use the AC-

CIO ontology

(Ongenae et al., 2014). This OWL DL

ontology makes use of other well established ontolo-

gies e.g. the Semantic Sensor Ontology (Compton M.

et al., 2012), and was designed to represent different

aspects of patient care in a continuous care setting. It

covers all concepts relevant to our use case. A simple

Available at: https://github.com/IBCNServices/Accio-

Ontology/tree/gh-pages

1 PREFIX : <http://example.org#>

2 PREFIX Ar: <...RoleCompetenceAccio.owl#>

3 PREFIX Du: <...ontologies/DUL.owl#>

4 PREFIX SN: <...SSNiot.owl#>

5 PREFIX WA: <...WSNextensionAccio.owl#>

7 : bob Du : h asR o l e [ a Ar : P a t i e n t R o l e ] ;

8 Du : h a s L o c a t i o n : room21 ;

9 WA: l i g h t T r e s h o l d 2 0 0 .

11 : l i g h t s e n s o r 1 7

12 Du : h a s L o c a t i o n : room21 ;

13 a SN: L i g h t S e n s o r .

Listing 5: Instance of a patient with a light sensivity

of 200 who is located in a room with a light sensor.

example of the use of the ontology is given in List-

ing 5. We see speciﬁcations about someone named

:bob who is a patient and currently present at a loca-

tion called :room21. In this :room21 there is further-

more a light sensor (:lightsensor17). We also see

that :bob has a light threshold value of 200 assigned.

Such an assignment can either be derived by reason-

ing (e.g. if Bob has a concussion and all patients with

a concussion have this light threshold value) or it can

be set individually to a patient (e.g. by a doctor). Be-

low, we show how our system uses this knowledge.

4.2 Sensor Queries

Our concept, SENSdesc, describes possible sensor

queries via existential rules of the form

{ pre-condition } =>{ query-description.

post-condition. }

where the three parts are as follows:

Pre-condition: This part speciﬁes the kind of sensor

the description is valid for, the situation in which

the query can be done and additional knowledge

relevant for the query.

Query description: This part speciﬁes how exactly

a query has to look like. Additional parameters

relevant for the query can also be added here.

Post-condition: Here we describe the consequences

of the query-result.

For pre- and post-condition it is crucial to use vocabu-

lary speciﬁed in the surrounding ontology. Only with

further background knowledge about the terms and

contexts used, reasoning can take place. We illustrate

the concept of a SENSdesc rule in Listing 6.

The pre-condition (lines 9–14) describes the situ-

ation in which our description is relevant: A patient

has a light threshold deﬁned and there is a light sen-

sor at the same location as the patient. In our example

this is the case for our patient Bob from Listing 5.

1 PREFIX : <http://example.org#>

2 PREFIX Ar: <...RoleCompetenceAccio.owl#>

3 PREFIX Du: <...ontologies/DUL.owl#>

4 PREFIX SN: <...SSNiot.owl#>

5 PREFIX sosa: <http://www.w3.org/ns/sosa/>

6 PREFIX WA: <...WSNextensionAccio.owl#>

8 {

9 #pre-condition

10 ? p Du : h a s Ro l e [ a Ar : P a t i e n t R o l e ] ;

11 Du : h a s L o c a t i o n ? l ;

12 WA: l i g h t T r e s h o l d ? t .

13 ? s Du : h a s L o c a t i o n ? l ;

14 a SN: L i g h t S e n s o r .

15 }=>{

16 #query-description

17 ? s : s e n s o r Q u ery {

18 ? s : v a l u e _ : v .

19 _ : v : g r e a t e r T h a n ? t } .

21 #post-condition

22 ? s s o s a : h a s O b s e r v a t i o n _ : o .

23 _ : o SN: hasSymptom [ a

24 WA: Lum inan ceAb oveT hresholdSympt om ] .

25 } .

Listing 6: Example description. For a patient for

whom a lightThreshold is deﬁned, light sensors at his

location can test whether the light is below this thresh-

old.

The query-description, lines 16–19, states which

query has to be performed to the light sensor. The ex-

ample query here tests if the measured value is above

the threshold. Note that sensor and threshold value are

expressed by universal variables taking values from

pre-condition. Both depend on the context data.

The post-condition, lines 21–24, describes the

consequence of a successful sensor query: if the query

triggers, a WA:LuminanceAboveThresholdSymptom

is observed. In the ontology, the observation of this

symptom can—depending on the further context—

have several consequences. Here, via Listing 2, we

can get a WA:LuminanceAboveThresholdFault.

4.3 Goals

As explained in Section 3.2, an N reasoner is typi-

cally invoked with a goal. This goal is a logical rule

serving as a ﬁlter. If this rule can be applied to the

given input or its logical consequences, the reasoner

provides a formal proof in which the goal is the last

rule applied. As mentioned in Section 2, we want to

know in our example, which faults could be detected

by a sensor using the current data consisting of ontol-

ogy, description of the context and SENSdesc rules to

describe possible sensor queries. To do so, we search

for all instances of the class SN:Fault the reasoner

can detect. The goal for this looks as follows:

{?x a SN:Fault}=>{?x a SN:Fault}. (6)

Here, antecedence and consequence are the same.

The rule is nevertheless not redundant because it is

marked as a goal. The reasoner looks for cases where

this rule can be applied and provides a proof for them.

4.4 Making Use of Proofs

Having the goal, the different SENSdesc descriptions

including the one from above, the OWL ontology and

the N rules to perform OWL reasoning as described

in Section 3.3 at our disposal, we can start an N rea-

soner and produce a proof. This proof enables us to

ﬁnd the sensors and the concrete sensor queries rele-

vant to our problem. We illustrate that idea on our ex-

ample. Additionally to the axioms mentioned above,

our ontology also contains the triple:

WA:LuminanceAboveThresholdFault

rdfs:subClassOf SN:Fault. (7)

This indicates that every instance of the class

WA:LuminanceAboveThresholdFault is also an in-

stance of the class SN:Fault. Using the data dis-

played in this paper and the goal in Formula 6 the rea-

soning process produces the proof in Listing 7. From

the different proof steps (lemmas) composing the

proof, there is one particularly interesting: Lemma 4

(lines 27–38) describes the application of our SENS-

desc rule (r:Inference) leading to:

:lightsensor17 :sensorQuery {

:lightsensor17 :value _:sk_0.

_:sk_0 :greaterThan 200 }.

:lightsensor17 sosa:hasObservation _:sk_1.

_:sk_1 SN:hasSymptom _:sk_2.

_:sk_2 a WA:LuminanceAboveThresholdSymptom.

These triples contain a concrete sensor query to the

sensor :lightsensor17: if the value of this sensor

is greater than 200 we need to add the observation

of a WA:LuminanceAboveThresholdSymptom to the

knowledge. We thus know from the the proof that in

our current setting this particular sensor is important

and needs to be monitored with the indicated value.

This technique of looking for inference steps ap-

plying SENSdesc rules can be generalised: If we

additionally had another sensor in another room

where another patient with a deﬁned light threshold

value was located, this sensor with the corresponding

threshold value would also appear in the proof while

light sensors located in rooms with no patients or with

patients without a deﬁned luminance threshold value

will not be listed. In that way we ﬁnd the sensors and

queries relevant to our particular problem.

5 RELATED WORK

The approach presented in this paper is inﬂuenced

by other research: In previous work, we developed

a format to describe RESTful API calls via existen-

tial rules in N, RESTdesc.

Just as in SENSdesc, we

used existential rules consisting of three parts, pre-

condition, call-description, and post-condition to de-

scribe possible events, in this case possible API calls.

To make plans towards a goal, proofs containing in-

stantiated descriptions of API calls were employed.

We explain this idea in our previous paper (Verborgh

et al., 2017). In this sense this paper can be seen as

an extension of RESTdesc, which was developed for

API calls, to sensor queries. Both formats, RESTdesc

and SENSdesc can be combined in an environment

where APIs and sensors are present.

The use case required to perform OWL reasoning

in a rule-based logic. The idea to do so is not new and

has been implemented in several systems. Classically,

rule-based systems support the OWL RL proﬁle. Ex-

amples are RDFox (Nenov et al., 2015) and OWLIM

(Bishop et al., 2011) or the implementation of OWL

RL rules in Prolog (Almendros-Jiménez, 2011). But

also the other proﬁles have been implemented using

rules: Krötsch discusses the implementation of OWL

EL (Krötzsch, 2011). The support for OWL QL in

OWLIM is implemented using rules (Bishop and Bo-

janov, 2011). In our case the rules had to be in N,

their implementation is based on our previous work

on OWL RL (Arndt et al., 2015; Arndt et al., 2016).

Finally, we discuss the connection between our

work and Semantic Web stream processing and rea-

soning. A complete overview of this topic can be

found in (Dell’Aglio et al., 2017). RDF stream pro-

cessing systems are classically divided into two cat-

egories: Complex Event Processing systems (CEP)

and Data Stream Management Systems (DSMS).

While the former normally have timestamped triples

and the detection of patterns within these as subject,

the latter focus on the data produced in ﬁxed time pe-

riods, so called windows. An overview of systems

can be found at (Margara et al., 2014). To query

on streams, several languages have been developed,

e.g. C-SPARQL, CEQLS and SPARQL

stream

. Re-

cent research aims to unify them into the language

RSP-QL (Dell’Aglio et al., 2015). Our approach is

independent of these languages since reasoning only

happens on top of query results whose consequences

are deﬁned in the SENSdesc descriptions. In that as-

pect it also differs from ontology based data access

(OBDA) on streams such as e.g. (Bienvenu et al.,

2014). OBDA takes sensor queries as input which are

http://restdesc.org/

1 PREFIX owl: <http://www.w3.org/2002/07/owl#>

2 PREFIX SN: <http://IBCNServices.github.io/Accio-OntologySSNiot.owl#>

3 PREFIX sosa: <http://www.w3.org/ns/sosa/>

4 PREFIX WA: <http://IBCNServices.github.io/Accio-OntologyWSNextensionAccio.owl#>

5 PREFIX : <http://example.org#>

6 PREFIX r: <http://www.w3.org/2000/10/swap/reason#>

8 [ ] a r : P roo f , r : C o n j u n c t i o n ;

9 r : compon ent <#lemma1 >;

10 r : g i v e s { _ : sk _1 a SN : F a u l t . } .

12 <#lemma1 > a r : I n f e r e n c e ;

13 r : g i v e s { _ : sk _1 a SN : F a u l t . } ;

14 r : e v i d e n c e ( <# lemma2 > ) ;

15 r : r u l e <#lemma5 > .

17 <#lemma2 > a r : I n f e r e n c e ;

18 r : g i v e s { _ : sk _1 a SN : F a u l t . } ;

19 r : e v i d e n c e ( <# lemma3> <#lemma7 > ) ;

20 r : r u l e <#lemma8 > .

22 <#lemma3 > a r : I n f e r e n c e ;

23 r : g i v e s { _ : sk _1 a WA: L u m ina n c eAb o v eTh r e sh o l d Fa u l t . } ;

24 r : e v i d e n c e ( <# lemma4> <#lemma6 > ) ;

25 r : r u l e <#lemma9 > .

27 <#lemma4 > a r : I n f e r e n c e ;

28 r : g i v e s {

29 : l i g h t s e n s o r 1 7 : s e n s o r Q u e r y {

30 : l i g h t s e n s o r 1 7 : v a l u e _ : s k_0 .

31 _ : s k_ 0 : g r e a t e r T h a n 200

32 } .

33 : l i g h t s e n s o r 1 7 s o s a : h a s O b s e r v a t i o n _ : sk_1 .

34 _ : s k_ 1 SN : hasSymptom _ : sk _2 .

35 _ : s k_ 2 a WA: Lum inan ceAb oveT hresholdSympt om .

36 } ;

37 r : e v i d e n c e ( <# lemma10 > ) ;

38 r : r u l e <#lemma11 >.

40 <#lemma5 > a r : E x t r a c t i o n ;

41 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e <Fo rmula 6 > ] .

42 <#lemma6 > a r : E x t r a c t i o n ;

43 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e < L i s t i n g 2 > ] .

44 <#lemma7 > a r : E x t r a c t i o n ;

45 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e <Fo rmula 7 > ] .

46 <#lemma8 > a r : E x t r a c t i o n ;

47 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e < o w l _ s u b c l a s s _ r u l e . n3 > ] .

48 <#lemma9 > a r : E x t r a c t i o n ;

49 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e < L i s t i n g 3 > ] .

50 <#lemma10 > a r : E x t r a c t i o n ;

51 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e < L i s t i n g 5 > ] .

52 <#lemma11 > a r : E x t r a c t i o n ;

53 r : b e c a u s e [ a r : P a r s i n g ; r : s o u r c e < L i s t i n g 6 > ] .

Listing 7: (Simpliﬁed) Example proof for the goal displayed in Formula 6 taking into account the data from Listings

2–6 and an additional rule to handle owl:subclassOf. Lemma 4 includes an instatiated version of the SENSdesc

description.

rewritten based on ontology knowledge to easier sen-

sor queries to perform on the stream. In our approach,

we do not have a sensor query on top of ontology and

streams, we have a simple goal, which can not directly

contain informations about streams and or windows.

This kind of information can only be expressed in the

query description part of our SENSdesc rules.

6 CONCLUSION AND FUTURE

WORK

In this paper we presented a new format to describe

possible sensor queries and explained how it can be

used together with formal proofs to determine in a

setting where many sensors are available, which sen-

sors and which queries are relevant to keep track of

user deﬁned goals. Once these sensors are known,

they can be carefully monitored and—in case they de-

tect the situations they are looking for—new reason-

ing can be triggered. This strategy saves us from hav-

ing performance problems due to constant reasoning

on the output of all available sensors.

In the future we plan to improve the description of

sensor queries in SENSdesc. Integrating existing for-

mats for stream querying like RSP-QL make it easier

to detect and execute the sensor queries in a proof.

Furthermore, we plan to test our implementation in

bigger settings and contexts where more sensors are

available. Only by this, we can be sure that the per-

formance of our approach does not suffer from the

inclusion of expensive concepts like existential rules.

REFERENCES

Abiteboul, S., Hull, R., and Vianu, V., editors (1995). Foun-

dations of Databases: The Logical Level. Addison-

Wesley.

Almendros-Jiménez, J. M. (2011). A Prolog library for

OWL RL. In Proceedings of the 4th International

Workshop on Logic in Databases, LID ’11, pages 49–

56. ACM.

Arndt, D., De Meester, B., Bonte, P., Schaballie, J.,

Bhatti, J., Dereuddre, W., Verborgh, R., Ongenae,

F., De Turck, F., Van de Walle, R., and Mannens,

E. (2015). Ontology reasoning using rules in an

eHealth context. In Proceedings of the 9th Interna-

tional RuleML Symposium.

Arndt, D., De Meester, B., Bonte, P., Schaballie, J.,

Bhatti, J., Dereuddre, W., Verborgh, R., Ongenae, F.,

De Turck, F., Van de Walle, R., and Mannens, E.

(2016). Improving OWL RL reasoning in N3 by using

specialized rules. In Ontology Engineering: 12th Int.

Experiences and Directions Workshop on OWL.

Berners-Lee, T. (2000). Semantic Web Application Plat-

form. http://www.w3.org/2000/10/swap/.

Berners-Lee, T. and Connolly, D. (2011). Notation3 (N):

A readable RDF syntax. WC Team Submission.

http://www.w3.org/TeamSubmission/n3/.

Berners-Lee, T., Connolly, D., Kagal, L., Scharf, Y., and

Hendler, J. (2008). N3Logic: A logical framework for

the World Wide Web. Theory and Practice of Logic

Programming, 8(3):249–269.

Bienvenu, M., Cate, B. T., Lutz, C., and Wolter, F. (2014).

Ontology-based data access: A study through dis-

junctive Datalog, CSP, and MMSNP. ACM Trans.

Database Syst.

Bishop, B. and Bojanov, S. (2011). Implementing OWL 2

RL and OWL 2 QL rule-sets for OWLIM. In OWLED.

Bishop, B., Kiryakov, A., Ognyanoff, D., Peikov, I., Tashev,

Z., and Velkov, R. (2011). OWLIM: A family of scal-

able semantic repositories. Semantic Web, 2(1):33–42.

Bock, C., Fokoue, A., Haase, P., Hoekstra, R., Horrocks,

I., Ruttenberg, A., Sattler, U., and Smith, M. (2012).

Owl 2 Web Ontology Language. WC Recommenda-

tion. http://www.w3.org/TR/owl2-syntax/.

Calvanese, D., Carroll, J., Di Giacomo, G., Hendler, J., Her-

man, I., Parsia, B., Patel-Schneider, P. F., Ruttenberg,

A., Sattler, U., and Schneider, M. (2012). Owl 2 Web

Ontology Language Proﬁles (second edition). WC

Recommendation. www.w3.org/TR/owl2-proﬁles/.

Compton M. et al. (2012). The SSN ontology of the W3C

semantic sensor network incubator group. Web Se-

mantics: Science, Services and Agents on the World

Wide Web, 17.

Cyganiak, R., Wood, D., and Lanthaler, M. (2014).

RDF 1.1: concepts and abstract syntax.

http://www.w3.org/TR/2014/REC-rdf11-concepts-

20140225/.

Dell’Aglio, D., Calbimonte, J.-P., Della Valle, E., and Cor-

cho, O. (2015). Towards a Uniﬁed Language for RDF

Stream Query Processing.

Dell’Aglio, D., Valle, E. D., van Harmelen, F., and Bern-

stein, A. (2017). Stream reasoning: a survey and out-

look: A summary of ten years of research and a vision

for the next decade. Data Science Journal, 1.

Krötzsch, M. (2011). Efﬁcient rule-based inferencing for

OWL EL. In Proceedings of the Twenty-Second Inter-

national Joint Conference on Artiﬁcial Intelligence.

Krötzsch, M. (2012). OWL 2 proﬁles: An introduction to

lightweight ontology languages. In Proceedings of the

8th Reasoning Web International Summer School.

Margara, A., Urbani, J., van Harmelen, F., and Bal, H.

(2014). Streaming the Web: reasoning over dynamic

data. Journal of Web Semantics.

Nenov, Y., Piro, R., Motik, B., Horrocks, I., Wu, Z., and

Banerjee, J. (2015). RDFox: a highly-scalable RDF

store. In Proc. International Semantic Web Confer-

ence.

Ongenae, F., Duysburgh, P., Sulmon, N., Verstraete, M.,

Bleumers, L., De Zutter, S., Verstichel, S., Ackaert,

A., Jacobs, A., and De Turck, F. (2014). An ontology

co-design method for the co-creation of a continuous

care ontology. Applied Ontology, 9(1):27–64.

Verborgh, R., Arndt, D., Van Hoecke, S., De Roo, J., Mels,

G., Steiner, T., and Gabarró Vallés, J. (2017). The

pragmatic proof: Hypermedia API composition and

execution. Theory and Practice of Logic Program-

ming, 17(1):1–48.

Verborgh, R. and De Roo, J. (2015). Drawing conclu-

sions from Linked Data on the Web. IEEE Software,

32(5):23–27.
