Error Correction for Information Retrieval of Czech Documents

ı Mart

ınek

and Pavel Kr

1,2

Dept. of Computer Science & Engineering, Faculty of Applied Sciences,

University of West Bohemia, Plze

n, Czech Republic

NTIS - New Technologies for the Information Society, Faculty of Applied Sciences,

University of West Bohemia, Plze

n, Czech Republic

Keywords:

Czech, Error Correction, Fulltext, Language Model, OCR.

Abstract:

This paper proposes a novel system for information retrieval over a set of scanned documents in the Czech

language. The documents are in the form of raster images and thus they are ﬁrst converted into the text form

by optical character recognition (OCR). Then OCR errors are corrected and the corrected texts are indexed

and stored into a fulltext database. The database provides a possibility of searching over these documents.

This paper describes all components of the above mentioned system with a particular focus on the proposed

OCR correction method. We experimentally show that the proposed approach is efﬁcient, because it corrects

a signiﬁcant number of errors. We also create a small Czech corpus to evaluate OCR error correction methods

which represent another contribution of this paper.

1 INTRODUCTION

At present, a number of printed documents are

scanned into electronic form. These scans are cre-

ated for instance in order to save historical docu-

ments, to reduce the manipulation labours during doc-

ument manipulation/management, to fulﬁll some gov-

ernment laws which order digitization, etc. Unfortu-

nately, the documents are usually saved in the form

of raster images and it is thus impossible to search

appropriate information. Therefore, optical character

recognition (OCR) techniques emerged and the docu-

ments are converted into plaintext form.

Unfortunately, despite the claims of many com-

mercial OCR players, the resulting results are far from

perfect and therefore error correction methods are

beneﬁcial. There are many projects dealing with OCR

correction techniques. These projects are usually fo-

cused on English or other speciﬁc language such as

Arabic or Chinese. However, to the best of our knowl-

edge, only few work deals with Czech. Moreover,

there is no system able to search information in a set

of pdf documents in a form of raster images.

Therefore, the main goal of this paper consists in

proposing of a novel system to handle this issue and

searching information over scanned documents in the

Czech language. The scanned documents are ﬁrst

converted to plaintext and then OCR errors are cor-

rected using a method proposed below. These texts

are indexed and saved into a fulltext database. This

paper describes all components of the above men-

tioned system with a particular focus on the OCR cor-

rection approach.

We also created a small Czech corpus for eval-

uation of error correction methods. This corpus is

freely available for research purposes at http://ocr-

corpus.kiv.zcu.cz and represents another contribution

of this paper.

The rest of the paper is organized as follows. The

following section describes some interesting OCR

correction approaches. Section 3 deals with the archi-

tecture of the proposed system, while Section 4 de-

tails the proposed approach for error correction. Sec-

tion 5 ﬁrst describes our document collection and then

presents the results of experiments realized on this

data. The last section concludes the paper and pro-

poses some future research directions.

2 SHORT REVIEW OF OCR

ERROR CORRECTION

There are several ways to improve accuracy of the

OCR systems. The simplest approaches are rule-

based and use a set of manually deﬁned rules. An-

other group of methods uses for error correction man-

ually deﬁned lexicons followed by a distance mea-

630

Martínek, J. and Král, P.

Error Correction for Information Retrieval of Czech Documents.

DOI: 10.5220/0006661906300634

In Proceedings of the 10th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2018) - Volume 2, pages 630-634

ISBN: 978-989-758-275-2

sure to choice a closest word for replacing. The third

group of methods use usually statistical methods with

machine learning. The above mentioned approaches

are brieﬂy described for instance in a survey (Kukich,

1992). We describe next more in detail some interest-

ing methods.

Zhidong et al. propose in (Zhidong et al., 1999)

a language-independent OCR system which recog-

nizes text from most of the world’s languages. Their

approach uses hidden Markov models (HMM) to

model each character. The authors empoy unsuper-

vised adaptation techniques to provide the language

independence. The paper also describes the relation-

ship between speech recognition and OCR.

Perez-Cortes et al. describe in (Perez-Cortes et al.,

2000) an interesting method to post-process the OCR

results in order to improve the accuracy. The authors

propose a solution based on ﬁnite-state Markov model

and modiﬁed Viterbi algorithm.

Another approach (Pal et al., 2000) focuses on the

Indian language and non–word errors. The authors

use for OCR error correction morphological parsing.

A set of rules for the morphological analysis is pre-

sented. Unfortunately, is is not clear, whether this ap-

proach is applicable for any language OCR.

The authors of (Aﬂi et al., 2016) use language

models and statistical machine translation (SMT).

This work is focused on historical texts. The purpose

of the SMT is to translate words in source language

into another words in a target language. The main

idea is to translate OCR outputs into corrected texts

using both language models.

Kissos and Dershowitz propose (Kissos and

Dershowitz, 2016) a method involving a lexical

spellchecker, a confusion matrix and a regression

model. The confusion matrix and regression model

are used for choosing good correction candidates.

3 SYSTEM ARCHITECTURE

The proposed system has a modular architecture as

depicted in Figure 1 and is composed of three main

modules.

The ﬁrst module is used for OCR conversion of

the document in the raster image form. Tesseract open

source OCR Engine

is used as a core of our OCR

analysis. The input of this module are raster images

and the output is a so called conﬁdence matrix which

contains the possible recognized characters with con-

ﬁdence values.

The second module is dedicated to the correction

https://github.com/tesseract-ocr

of the OCR errors. Its input is the conﬁdence matrix

provided by the previous module and the output is the

corrected text. This module combines probabilities

of character language model with the values from the

conﬁdence matrix. A rule-based approach with Lev-

enstein distance is also implemented in this module.

The methods integrated in this module are described

more in details in the following section.

The last module is used for document storage, in-

dexing and retrieval. The open source search engine

Apache Solr

is used for this task. The input is the

corrected text obtained by the previous module. This

module provides the possibilities of searching over

the pdf data.

Corrected

text

Raster

image in

pdf form

3. Full-text

Apache Solr

2. Error correction

Proposed method

Plain text

with errors

1. OCR

Tesseract

Figure 1: Modular architecture of the proposed system.

4 PROPOSED METHOD

The proposed error correction method is at the char-

acter level. It uses ﬁrst a rule-based approach for cor-

rection of the regular errors. Then, we use a statistical

algorithm which combines the output of the Tesser-

act with language models. The last step consists in

using dictionary-based Levenstein method as a post-

processing of the previous step.

4.1 Rule-based Approach

This approach employs a set of manually deﬁned rules

to replace some characters by the other ones. For ex-

ample the in-word character “0” (zero) is replaced

by the character “O” or the character “1” (one) is

replaced by the character “l”, etc. Then, the result

is checked against the manually deﬁned dictionary.

This approach can reduce a set of incorrect words and

speed up the whole correction process.

http://lucene.apache.org/solr/

Error Correction for Information Retrieval of Czech Documents

631

4.2 Statistical Algorithm

This approach combines the scores of statistical n-

gram language models with the conﬁdence matrix

values obtained by the Tesseract system using linear

combination:

δ = wT + (1 − w)π (1)

where w is the weight of the conﬁdence matrix

(w ∈ [0;1]), T is the character conﬁdence obtained by

the Tesseract system and π is the character probabil-

ity provided by the language model. We use 3-gram

language models with smoothing trained on Czech

Wikipedia corpus (csWiki) (Suchomel, 2012).

We must identity the best (highest) probability

values for all characters in the analyzed word. We use

Viterbi algorithm (Forney, 1973) for this task. This

algorithm creates several character possibilities dur-

ing the forward step. The most probable character

sequence is determined during the backward step by

chosing the maximal value for each node. This is de-

picted in Figure 2.

72.3

81.9

83.6

72.0

79.0

81.5

79.4

77.6

89.2

83.1

81.4

71.9

91.2

79.6

83.1

77.6

86.0

79.4

87.4

86.4

88.2

72.3

75.9

79.0

83.1

87.1

93.4

68.4

79.4

90.2

Figure 2: Viterbi algorithm.

This ﬁgure shows several possibilities in the char-

acter space. Viterbi algorithm then choices the best

path (blue colour with maximal values) in this lattice.

4.3 Dictionary-based Levenstein

Method

If a word is not contained in the dictionary, we can use

Levenstein distance (Levenshtein, 1966) for a further

correction. This metric computes a distance between

the corrected and the dictionary words as the mini-

mum number of insertions, deletions or substitutions

required to change the target word into the source one.

Then, we replace the corrected word by the closest

one (i.e. with minimum distance) from our dictionary.

Note, that this last step is optional.

5 EXPERIMENTS

5.1 Czech Document Dataset

Unfortunately, there is no Czech freely available

dataset to evaluate error correction methods.

Therefore, we collected the documents from the

Czech Wikipedia. Every document was printed and

scanned. The scanning was done with the different

resolution, we chose 150, 300 and 600 DPI, respec-

tively. For each scan we saved the correct text from

the Wikipedia, which will be used as gold data for

evaluation of our methods.

The ﬁnal corpus is composed of the scans of 20

Czech documents in the pdf format. The documents

have maximum one page of the text and differ in word

number. The longest document has 523 words, while

the shortest one has 119 words only. The average

word number is 299.

This corpus is freely available for research pur-

poses at http://ocr-corpus.kiv.zcu.cz and represents

another contribution of this paper.

5.2 Evaluation Metrics

The main metric used for evaluation of the experi-

ments is the standard Word error rate (WER). It is

deﬁned as follows:

W ER =

S + D + I

(2)

where S is the number of substitutions, D is the

number of deletions, I is the number of insertions and

N is the number of all words in the gold data.

Another metric is the Word accuracy deﬁned as

1 −W ER.

We further use the Character error rate (CER)

which is computed similarly as WER, however the

words are replaced by the characters.

The last metric used in this paper is the Accuracy.

It is calculated as the number of correctly recognized

words divided by the number of all words in the ref-

erence data.

5.3 Impact of the Document Resolution

According to the Tesseract documentation the resolu-

tion of the documents should be at least 300 DPI

In the ﬁrst experiment, we would like thus to val-

idate this claim and determine the optimal resolution

of the scanned documents in the Czech language. An-

other important property strictly related to the docu-

ment resolution is execution time. Therefore, we also

https://github.com/tesseract-ocr/tesseract/wiki/FAQ

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

632

measure and report this value. The results of this ex-

periments are shown in Table 1.

Table 1: Tesseract OCR results depending on the document

resolution.

Resolution [DPI] 150 300 600

WER [%] 24.6 19.6 19.5

Execution time [ms] 10 575 8569 8405

This table shows that Tesseract achieves the worst

results for the document resolution 150 DPI. On the

other hand the documents in resolutions 300 and 600

DPI achieve comparable WER. However, document

with 600 DPI is in average 4 times bigger than doc-

ument with 300 DPI which represents an important

issue for data storage.

This table further shows that the time for process-

ing of the images in resolution 300 and 600 DPI are

comparable, however for conversion of images in res-

olution 150 DPI is needed signiﬁcantly more of time.

This experiment proved that the resolution 300

DPI is sufﬁcient for Tesseract OCR system and there-

fore we chose this value for the following experi-

ments.

5.4 Evaluation of Error Correction

In the second experiment, we would like to evaluate

the performance of the proposed OCR error correc-

tion module.

First we would like to ﬁnd the optimal weight w

(see Equation 1) of the combination of the Tesser-

act and the language models. We explore the values

of w ∈ [0; 1] where the extreme value 0 means that

only the language models are used, while the 1 value

signiﬁes that only the Tesseract output is used. The

following two ﬁgures show the results of this experi-

ment. Figure 3 shows the results with the Levenshtein

distance correction, while Figure 4 depicts the results

without this correction.

This experiment shows that the curves in both ﬁg-

ures have very similar behaviour and that the best re-

sults are in both cases achieved by using the w = 0.7.

These ﬁgures also shows that the impact of the

Tesseract system is more important, than of the lan-

guage models. However, it is also evident that the

usage of language models plays a positive role for er-

ror correction. The Word Accuracy is improved in

both cases by 7% in absolute value (from 57.0% to

64.4% in the case without Levenstein distance and

from 68.0% to 75.0% with Levenstein method).

This experiment also shows, that Levenstein dis-

tance plays a positive role for error reduction. The

best obtained Word Accuracy is about 75.0% with

Levenstein distance.

0 0.1 0.2 0.3 0.4

0.5 0.6

0.7 0.8 0.9 1

0.2

0.4

0.6

0.8

Error rate & Accuracy

Accuracy

Word Accuracy

Word Error Rate

Character Error Rate

Figure 3: OCR results depending on the w value. Leven-

stein distance is used.

0 0.1 0.2 0.3 0.4

0.5 0.6

0.7 0.8 0.9 1

0.2

0.4

0.6

0.8

Error rate & Accuracy

Accuracy

Word Accuracy

Word Error Rate

Character Error Rate

Figure 4: OCR results depending on the w value without

Levenstein distance.

6 CONCLUSIONS & FUTURE

WORK

In this paper, we describe a novel system for infor-

mation retrieval over a set of scanned documents in

Czech language with a particular focus on the OCR

error correction. We have experimentally shown that

the proposed approach is efﬁcient, because it corrects

a signiﬁcant number of errors.

Error Correction for Information Retrieval of Czech Documents

633

Another contribution of this paper represents

a new small Czech corpus which we created for eval-

uation of our OCR error correction method. This cor-

pus is freely available for research purposes.

Our current document dataset is very small.

Therefore, our ﬁrst perspective consists in the exten-

sion of this corpus by other raster documents. The

documents can be classiﬁed into several classes as for

instance invoices, contracts, agreements, etc. Another

perspective thus consists in creation of the class de-

pendent language models. We assume that these lan-

guage models should correct better OCR errors, be-

cause they will be adapted to the document types.

ACKNOWLEDGEMENTS

This work has been partly supported by the project

LO1506 of the Czech Ministry of Education, Youth

and Sports and by Grant No. SGS-2016-018 Data and

Software Engineering for Advanced Applications.

REFERENCES

Aﬂi, H., Qiu, Z., Way, A., and Sheridan, P. (2016). Us-

ing smt for ocr error correction of historical texts. In

LREC.

Forney, G. D. (1973). The viterbi algorithm. Proceedings

of the IEEE, 61(3):268–278.

Kissos, I. and Dershowitz, N. (2016). Ocr error correc-

tion using character correction and feature-based word

classiﬁcation. In Document Analysis Systems (DAS),

2016 12th IAPR Workshop on, pages 198–203. IEEE.

Kukich, K. (1992). Techniques for automatically correct-

ing words in text. ACM Computing Surveys (CSUR),

24(4):377–439.

Levenshtein, V. I. (1966). Binary codes capable of cor-

recting deletions, insertions, and reversals. In Soviet

physics doklady, volume 10, pages 707–710.

Pal, U., Kundu, P. K., and Chaudhuri, B. B. (2000). Ocr er-

ror correction of an inﬂectional indian language using

morphological parsing. J. Inf. Sci. Eng., 16(6):903–

922.

Perez-Cortes, J. C., Amengual, J.-C., Arlandis, J., and Llo-

bet, R. (2000). Stochastic error-correcting parsing for

ocr post-processing. In Pattern Recognition, 2000.

Proceedings. 15th International Conference on, vol-

ume 4, pages 405–408. IEEE.

Suchomel, V. (2012). Recent czech web corpora. In 6th

Workshop on Recent Advances in Slavonic Natural

Language Processing, Brno, Tribun EU, pages 77–83.

Zhidong, L., Issam, B., Kornai, A., John, M., Prem, N., and

Richard, S. (1999). A robust, language-independent

ocr system.

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

634
