Sparse Sampling for Real-time Ray Tracing

Timo Viitanen, Matias Koskela, Kalle Immonen,

Markku M

akitalo, Pekka J

askel

ainen and Jarmo Takala

Tampere University of Technology, Tampere, Finland

Keywords:

Ray Tracing, Sparse Sampling, Image Reconstruction.

Abstract:

Ray tracing is an interesting rendering technique, but remains too slow for real-time applications. There are

various algorithmic methods to speed up ray tracing through uneven screen-space sampling, e.g., foveated

rendering where sampling is directed by eye tracking. Uneven sampling methods tend to require at least one

sample per pixel, limiting their use in real-time rendering. We review recent work on image reconstruction

from arbitrarily distributed samples, and argue that these will play major role in the future of real-time ray

tracing, allowing a larger fraction of samples to be focused on regions of interest. Potential implementation

approaches and challenges are discussed.

1 INTRODUCTION

Ray tracing has been long regarded in the graphics

community as a potential real-time rendering tech-

nique of the future (Keller et al., 2013). There has

been extensive research on real-time ray tracing, rang-

ing from algorithms and implementations, to applica-

tions, to hardware architectures. Recently, GPU ray

tracing performance has improved to the point that it

is widely used to render feature ﬁlm computer graph-

ics (CG) (Keller et al., 2015), but still falls short of

competing with conventional rasterization methods in

real-time rendering. A high-end GPU ray tracer can

comfortably render primary rays, or simple Whitted-

style ray tracing (Whitted, 1979) in real time, usu-

ally deﬁned as a frame rate of 30 Hz or more. How-

ever, interesting visual effects such as soft shadows,

glossy reﬂections and indirect illumination require

distribution ray tracing, where several rays are tra-

versed based on a random distribution and averaged

together. Distribution effects remain challenging to

render in real time.

There is a promising set of algorithm-level tech-

niques for reducing the computational effort of ray

tracing, based on uneven sample distributions in

screen space, which concentrate the rendering effort

on regions of interest. These include

• adaptive sampling, where more samples are

placed on regions of the screen with, e.g., high

Monte Carlo variance (Zwicker et al., 2015),

• foveated rendering, where rendering effort is con-

Figure 1: Path traced reference image (top) and error after

16 samples per pixel (bottom; red: high error, blue: low

error).

centrated near the user’s fovea by means of eye

tracking hardware (Weier et al., 2016; Koskela

et al., 2016), and

• sampling based on visual saliency, i.e., the abil-

ity of features to draw the attention of a human

observer (Longhurst et al., 2006).

The example in Fig. 1 illustrates that error is often

concentrated on small areas of the image, therefore,

performance can be signiﬁcantly improved by adap-

tively focusing samples on these areas. Moreover,

there is an extensive literature on noise-reduction

methods (Zwicker et al., 2015) for distribution ray

tracing, which are often combined with adaptive sam-

pling for the best results.

Currently, a basic difﬁculty in speeding up real-

Viitanen, T., Koskela, M., Immonen, K., Mäkitalo, M., Jääskeläinen, P. and Takala, J.

Sparse Sampling for Real-time Ray Tracing.

DOI: 10.5220/0006655802950302

In Proceedings of the 13th International Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2018) - Volume 1: GRAPP, pages

295-302

ISBN: 978-989-758-287-5

295

time rendering with the above methods is that most

of them depend on having at least one sample per

screen pixel. This already takes up most of the com-

pute performance of a high-end GPU with state of the

art real-time ray tracing methods (Schied et al., 2017;

Chaitanya et al., 2017; Mara et al., 2017). Conse-

quently, there is little rendering performance left to

distribute additional samples to regions of interest. In-

tuitively, rendered images often have smooth regions

whose lighting could be reconstructed from sparse

samples, but the literature has not yet converged on

a best method to do so.

Some of the methods tried so far have signiﬁ-

cant limitations. For instance, two recent state of

the art real-time ray tracers—one based on denois-

ing (Schied et al., 2017), and the other on foveated

rendering (Weier et al., 2016)—rely on reproject-

ing samples from previous animation frames to the

current frame. Reprojection makes real-time ray

tracing tractable by cheaply increasing the amount

of available samples, but has difﬁculties with ani-

mated scenes and fast camera movements, as well

as reﬂections and glossy surfaces. Other methods

are prohibitively expensive for real-time use, e.g.,

those based on compressive sensing (Sen and Darabi,

2011).

The problem of reconstructing a grid image from

sparse samples has been studied in digital signal pro-

cessing (DSP) literature, where it is applicable to,

e.g., image warping and stitching. We argue that ap-

plying DSP methods is a promising future direction

for real-time ray tracing. For best results, sparse sam-

pling methods might be modiﬁed to take advantage of

extra information that is available in a ray tracer, e.g.,

depth, normal, and albedo data. In this paper, we ex-

amine the problem of rendering with uneven, sparse

samples and review techniques in the DSP and com-

puter graphics literature that could be applied to the

problem.

This paper is structured as follows. Section 2 re-

views literature on methods to resample sparse data

into grid images. Section 3 summarizes recent work

on real-time ray tracing and its limitations. Section

4 discusses potential approaches to integrate sparse

sampling into real-time ray tracers. Section 5 con-

cludes the paper.

2 SPARSE SAMPLING METHODS

Image interpolation and reconstruction are well un-

derstood when the source image samples are placed

in a regular grid. When the samples are at irregu-

lar positions, these tasks are less well studied. There

are several applications for resampling of this kind,

including, e.g., super-resolution, image compression

and stereo rectiﬁcation. The proposed methods are

often aimed at speciﬁc applications and place special

constraints on their inputs, e.g., the samples may be

constrained to a speciﬁc density, or into a regular grid

with small perturbations.

For adaptive sampling, we are interested in meth-

ods that permit input samples to be sparse and nonuni-

formly distributed, as opposed to sampling on a reg-

ular grid. This section focuses on reviewing meth-

ods evaluated with inputs with the above properties.

Moreover, we omit some classes of methods which

are known to be highly expensive, e.g., exemplar-

based interpolation (Facciolo et al., 2009) and com-

pressive sensing (Sen and Darabi, 2011).

A basic approach is Delaunay triangulation be-

tween samples followed by polynomial interpolation

inside each triangle—this can be nearest-neighbor, bi-

linear or bicubic interpolation. Another simple ap-

proach is inverse distance weighting (IDW), where

pixel colors are averages of nearby samples weighted

with the inverse distance to the pixel center. In nat-

ural neighbor interpolation (Boissonnat and Cazals,

2000) a pixel’s color is interpolated from samples that

are its natural neighbors, i.e., the samples whose vol-

umes are chopped when the pixel is inserted to a De-

launay triangulation of the samples. Parallel imple-

mentations of these algorithms typically require sync-

ing operations or special datastructures, which might

make them out of reach in typical real-time time bud-

gets.

Another classic direction of work has been to as-

sume that the sampled signal is band-limited, and ex-

tend Shannon’s sampling theory to irregularly sam-

pled inputs (Strohmer, 1997). In practice, the recon-

struction quality in band-limited methods drops if the

band-limited assumption does not hold (Seiler et al.,

2015).

2.1 Model Fitting

Several methods attempt to ﬁt models such as

splines (Vazquez et al., 2005) to the observed sam-

ples. The output image can then be sampled from the

model.

A recent generalization of model ﬁtting is

generalized morphological component analysis

(GMCA) (Fadili et al., 2010), where images are

represented as combinations of multiple models.

For example, the countours of an image might be

represented as curvelets and repeating small-scale

texture in frequency form.

GRAPP 2018 - International Conference on Computer Graphics Theory and Applications

296

2.2 Variational Optimization

A set of methods take a variational approach where

the parameters in model ﬁtting are formulated as an

optimization problem. The optimized cost function

consists of an error term comparing the input samples

to the model, and a regularization term to prefer so-

lutions with properties similar to natural images. An

often exploited property is the redundancy typically

present in natural images, with the regularization term

promoting a sparse representation, for example in a

wavelet domain (Elad and Aharon, 2006).

One class of variational methods which is known

to work well with sparse samples uses a model with

splines placed on a grid (Arigovindan et al., 2005).

Interestingly, variational reconstruction was recently

extended to handle generalized, e.g., noisy or blurred,

samples (Bourquard and Unser, 2013).

2.3 Kernel Regression

In the model-ﬁtting technique kernel regression

(KR) (Takeda et al., 2006), the model places kernel

functions, e.g., splines, at each sample and ﬁnds their

parameters locally via least squares optimization. In

contrast, the above spline-based methods tend to place

splines in a regular grid and perform global optimiza-

tion. The technique can be viewed as a generalization

of, e.g., bilateral ﬁltering. Interestingly, KR can be

used for both denoising and resampling.

2.4 Frequency Selective Reconstruction

Downsampling a signal in a regular pattern reﬂects

frequencies below the Nyquist frequency into lower

frequencies, corrupting the spectrum. A recent, high-

quality method of frequency selective reconstruction

(FSR) (Seiler et al., 2015) is based on an observation

that downsampling in an irregular pattern has, con-

versely, the effect of adding noise to the spectrum.

A good approximation of the high-frequency signal

can be obtained by extracting the dominant frequen-

cies one by one. FSR has been recently improved by

adapting the number of iterations per block based on

local texture (Jonscher et al., 2016), and extending the

method to handle samples placed at non-integer posi-

tions (Koloda et al., 2017).

2.5 Super-Resolution Methods

In the task of multi-frame super-resolution (SR), mul-

tiple low-quality frames, taken from slightly differ-

ent positions and directions, are combined into a sin-

gle high-quality image with a better resolution. SR

has been extensively studied, and there are recent sur-

veys (Tian and Ma, 2011). One popular approach to

SR, dubbed interpolation-based SR in Ref. (Tian and

Ma, 2011), works by ﬁrst registering samples from all

low-resolution images to a single coordinate frame,

interpolating between them to form a high-resolution

image, and deblurring the result. In SR methods that

adhere to this model, the interpolation component is

directly applicable to the resampling problem. SR

methods are of interest since they often take into ac-

count signiﬁcant noise in the input images.

2.6 Denoising-based Reconstruction

The above interpolation methods all give some error

compared to an ideal image. In denoising-based re-

construction (Koloda et al., 2015), the error is treated

as noise, and standard denoising algorithms are ap-

plied to remove it. A reliability metric is computed

per pixel and used to adjust denoising strength. In a

later work (Koloda et al., 2016), the reliability metric

is improved to ca. double the image quality improve-

ment.

2.7 Computer Graphics Methods

Sampling has been extensively studied in the com-

puter graphics literature. Research is especially ac-

tive in the efﬁcient generation of sample patterns

with desirable properties, e.g., blue-noise samples via

Poisson disc sampling (Ebeida et al., 2011). Works

that render images from sparse, nonuniform samples

are less common. As in the DSP literature, pro-

posed upsampling methods are often limited to reg-

ular grids (Herzog et al., 2010; Yang et al., 2008).

A very fast approach is to sample a low-resolution

grid, subdivide it in regions where a higher sample

rate is wanted, and ﬁll in missing samples with lin-

ear interpolation (Steinberger et al., 2012; Kim et al.,

2016; Lee et al., 2016). Steinberger et al. (2012) in-

sert subdivisions in a diamond-square pattern based

on a visual saliency model. The adaptive methods of

Kim et al. (2016) and Lee et al. (2016) ﬁrst sample the

low-resolution grid, and then compute similarity mea-

sures between neighboring pixels to decide whether to

sample or interpolate the intermediate value.

Another fast method is pull-push render-

ing (Gortler et al., 1996), recently used as an

inpainting method for foveated rendering (Stengel

et al., 2016). In pull-push the input samples are

splatted onto a grid image and pulled onto a series

of low-resolution approximations, which are then

pushed back to ﬁll in unknown regions of the original

image. Advantages of pull-push are that it is fast,

Sparse Sampling for Real-time Ray Tracing

297

(a) Noisy input (b) Albedo (c) Irradiance (d) Filtered irradiance (e) Final image

Figure 2: Use of auxiliary data in ray tracing reconstruction. The noisy input (a) is decoupled into albedo (b) and irradiance

(c). Denoised irradiance (d) is recoupled with albedo to form the ﬁnal image (e).

Figure 3: Temporal accumulation of samples over multiple

frames in a scene ﬂythrough animation. Accumulation uses

depth data to reproject the previous frame to a new frame’s

camera. Some samples would blur the result and, therefore,

they are rejected based on auxiliary data (green: depth, red:

shading normal). In addition, some parts of the geometry

were outside the image in previous frames, so accumulated

samples are unavailable (white).

works with irregular sampling, and is able to ﬁll the

image from arbitrarily sparse samples.

Multi-pass normalized convolution has also been

used to inpaint in the unknown regions of a sparsely

sampled image (Galea et al., 2014). In adaptive

frameless rendering (Dayal et al., 2005), samples are

unevenly distributed in both space and time, and im-

ages are reconstructed with a spatio-temporal convo-

lutional ﬁlter.

Some sparse sampling methods have been pro-

posed for rasterization pipelines, in order to re-

duce expensive shader executions. An inter-

esting recent technique is coarse pixel shading

(CPS) (Vaidyanathan et al., 2014), where rasterized

primitives are divided into disjoint pixel sets, and

lighting is computed once per set. An advantage of

CPS is that it preserves object silhouette edges while

allowing uneven sample spacing.

Nonuniform samples occur naturally when ren-

dering scenes represented as point clouds. Proposed

point cloud renderers use screen-space interpolation

or reconstruction techniques to ﬁll in a smooth surface

between points, such as pull-push rendering (Mar-

roquim et al., 2008), pixel splatting (Zwicker et al.,

2001) and anisotropic ﬁltering (Pintus et al., 2011).

It should be noted that the aforementioned tech-

niques are all evaluated with noise-free samples,

though the method of Galea et al. (2014) may also

have denoising properties.

3 REAL-TIME RAY TRACING

Classically, real-time ray tracing was restricted to

simple visual effects, as complex distribution effects

require many noisy samples to converge. Recently,

there has been signiﬁcant progress in adaptive sam-

pling, and the reconstruction of high-quality images

from noisy samples, both documented in a recent sur-

vey paper (Zwicker et al., 2015).

This section examines methods used in a re-

cent batch of real-time ray tracers with complex vi-

sual effects, either based on gaze tracking (Weier

et al., 2016) or denoising reconstruction (Schied et al.,

2017; Chaitanya et al., 2017; Mara et al., 2017).

3.1 Noise Filtering

Mara et al. (2017) use performance-optimized bi-

lateral ﬁlters, while Schied et al. (2017) use a hi-

erarchical wavelet transform, similar in principle to

model ﬁtting methods for sparse resampling dis-

cussed above. Larger ﬁlter kernels are used in noisy

regions.

Chaitanya et al. (2017) train a recurrent au-

toencoder based on a convolutional neural network

(CNN) to reconstruct lighting based on a window of

GRAPP 2018 - International Conference on Computer Graphics Theory and Applications

298

noisy samples. The approach is distinct from other

recent machine learning denoisers (Kalantari et al.,

2015; Bako et al., 2017), which use conventional ﬁl-

ters for denoising and determine the ﬁlter parameters

by means of machine learning methods.

3.2 Auxiliary Data

Denoising a rendered image is different from the gen-

eral image processing problem since various noise-

free auxiliary scene data can be cheaply provided to

the renderer, e.g., depth, normal, and albedo buffers.

The recent real-time ray tracers take advantage of

such data in two main ways. The ﬁrst is to sepa-

rate the image into irradiance and albedo components,

and focus on reconstructing the irradiance, as shown

in Fig. 2. This signiﬁcantly simpliﬁes the denoising

problem by, e.g., preventing any blurring of texture

details. Mara et al. (2017) split irradiance into matte

and glossy components, which are ﬁltered separately,

while Schied et al. (2017) similarly separate direct

and indirect lighting. Secondly, noise ﬁltering is di-

rected to avoid blurring across edges in the auxiliary

buffers.

3.3 Temporal Accumulation

Path traced samples are sufﬁciently noisy that recon-

struction from one sample per pixel is challenging.

Most of the recent real-time implementations (Weier

et al., 2016; Schied et al., 2017; Mara et al., 2017)

rely on temporal accumulation from multiple frames

to improve the effective sample count. In this ap-

proach, samples from previous frames are reprojected

to the current frame, as shown in Fig. 3. Extra sam-

ples may be taken to ﬁll image regions that were, e.g.,

occluded in the previous frame. As a drawback, dy-

namic scenes are difﬁcult to handle.

The recurrent autoencoder proposed by Chai-

tanya et al. (2017) takes a different approach of in-

cluding recurrent connections in the CNN model,

which pass hidden data between animation frames.

Moreover, two methods (Chaitanya et al., 2017;

Schied et al., 2017) also employ screen-space tem-

poral antialiasing (Karis, 2014) which is used in com-

puter game engines.

3.4 Nonuniform Sampling

Out of the reviewed works, only Weier et al. (2016)

use nonuniform sampling based on eye tracking. This

is done by ensuring via temporal accumulation that

there is at least one sample per pixel, and placing ad-

ditional samples in the foveal region.

(a) Conventional real-time ray

tracing system

(b) Adaptive ray tracing

Figure 4: Modiﬁcations to adapt a conventional real-time

ray tracer (Schied et al., 2017; Mara et al., 2017; Chaitanya

et al., 2017) to use adaptive sampling.

In contrast, some previous works have rendered

images with sparse nonuniform sampling at interac-

tive or real-time rates (Shevtsov et al., 2010; Galea

et al., 2014; Lee et al., 2016), but, to our best knowl-

edge, only in the easier case of noise-free samples ob-

tained via Whitted-style ray tracing or rasterization.

4 DISCUSSION

The above sections reviewed the rich recent literature

on image resampling from scattered samples to a grid,

as well as state of the art real-time ray tracers. A po-

tential low-hanging fruit in real-time ray tracing is to

incorporate adaptive sampling techniques so that, e.g.,

large ﬂat surfaces receive less than one sample per

pixel. The main technical challenge lies in integrating

denoising with sparse sampling. There are multiple

potential approaches toward this goal:

1. Extension of ray tracing denoising methods to

handle scattered input samples.

2. Extension of sparse resampling methods to per-

form denoising.

3. Sparse resampling followed by denoising.

In each case, sparse resampling would be integrated to

the reconstruction component of a ray tracer as shown

in Fig. 4.

Out of the recent real-time ray tracers, two meth-

ods (Schied et al., 2017; Mara et al., 2017) perform

Sparse Sampling for Real-time Ray Tracing

299

denoising with bilateral ﬁlters, the former using the

ﬁlters as a low-level implementation technique for hi-

erarchical wavelet reconstruction. One method (Chai-

tanya et al., 2017) uses a recurrent autoencoder. To

our best knowledge, there is so far no analysis in

the literature on adapting these methods to sparse in-

puts. Bilateral ﬁltering appears conceptually difﬁ-

cult to adapt since it incorporates radiometric distance

between the target sample and nearby source sam-

ples, which is unavailable if the target pixel was not

sampled—though this is not an issue if only auxil-

iary data is used for edge stopping. Kernel regres-

sion (Takeda et al., 2007) can be viewed as a gen-

eralization of bilateral ﬁltering which handles sparse

inputs.

It may be easier to adapt resampling algorithms,

which often act as denoising ﬁlters, to perform the

reconstruction step. To this end, the resampling al-

gorithm should be adapted to use auxiliary data for

kernel size adjustment and edge stopping. In order to

be useful, a resampling method should be able to run

in real time, handle nonuniformly distributed inputs,

and preferably be able to cope with noise in the inputs.

Empirical evaluation is needed to determine which

methods are suitable. Based on a literature survey,

some interesting candidates in recent work are fre-

quency selective reconstruction (Seiler et al., 2015),

kernel regression (Takeda et al., 2006) and variational

interpolation (Bourquard and Unser, 2013).

The most straightforward approach is to perform

resampling and denoising as separate steps. Care-

ful analysis of noise behavior is then needed to en-

sure that resampling does not harm denoising perfor-

mance. Similar requirements apply to the resampling

method as above.

A separate question is how to distribute the adap-

tive samples. Ofﬂine adaptive ray tracers most often

sample based on Monte Carlo variance from several

previous samples (Zwicker et al., 2015). Variance

might be computed based on temporal accumulation

as is done in recent work (Schied et al., 2017) to de-

termine denoising ﬁlter kernel sizes. Typically, more

samples are needed near edges and ﬁne features in the

image (Overbeck et al., 2009), so a rasterized depth

image could help guide sampling as shown in Fig. 4.

Other auxiliary data might also be used in the spirit of

Lee et al. (2016).

5 CONCLUSION

This position paper argued that a way forward for

real-time ray tracing is to incorporate heavily adap-

tive sampling, placing less than one sample per pixel

in areas that are easy to render, and performing im-

age reconstruction from sparse data. There is a rich

literature on methods to resample from sparse sam-

ples into a grid image, which might be integrated

into ray tracing systems. Three possible implementa-

tion approaches were discussed: extending denoising

methods to take sparse inputs, extending resampling

methods to function as ray tracing oriented denoising

methods, and performing resampling and denoising in

separate steps.

ACKNOWLEDGEMENTS

We would like to thank Frank Meinl for the

Sponza model and Yasutoshi Mori for the Sports

Car model (released under CC BY 4.0 license:

https://creativecommons.org/licenses/by/4.0/)

This work is supported by Tekes — the Finnish

Funding Agency for Innovation under the funding de-

cision 40142/14 (StreamPro) in the FiDiPro program.

REFERENCES

Arigovindan, M., Suhling, M., Hunziker, P., and Unser, M.

(2005). Variational image reconstruction from arbi-

trarily spaced samples: A fast multiresolution spline

solution. IEEE Transactions on Image Processing,

14(4):450–460.

Bako, S., Vogels, T., Mcwilliams, B., Meyer, M., Nov

aK,

J., Harvill, A., Sen, P., Derose, T., and Rousselle, F.

(2017). Kernel-predicting convolutional networks for

denoising monte carlo renderings. ACM Transactions

on Graphics, 36(4):97.

Boissonnat, J.-D. and Cazals, F. (2000). Smooth surface

reconstruction via natural neighbour interpolation of

distance functions. In Proceedings of the Annual Sym-

posium on Computational Geometry, pages 223–232.

Bourquard, A. and Unser, M. (2013). Anisotropic inter-

polation of sparse generalized image samples. IEEE

Transactions on Image Processing, 22(2):459–472.

Chaitanya, C. R. A., Kaplanyan, A. S., Schied, C., Salvi,

M., Lefohn, A., Nowrouzezahrai, D., and Aila, T.

(2017). Interactive reconstruction of Monte Carlo

image sequences using a recurrent denoising autoen-

coder. ACM Transactions on Graphics, 36(4):98.

Dayal, A., Woolley, C., Watson, B., and Luebke, D. (2005).

Adaptive frameless rendering. In Proceedings of the

Eurographics Conference on Rendering Techniques,

pages 265–275.

Ebeida, M. S., Davidson, A. A., Patney, A., Knupp, P. M.,

Mitchell, S. A., and Owens, J. D. (2011). Efﬁcient

maximal poisson-disk sampling. ACM Transactions

on Graphics, 30(4):49.

GRAPP 2018 - International Conference on Computer Graphics Theory and Applications

300

Elad, M. and Aharon, M. (2006). Image denoising via

sparse and redundant representations over learned dic-

tionaries. IEEE Transactions on Image Processing,

15(12):3736–3745.

Facciolo, G., Arias, P., Caselles, V., and Sapiro, G. (2009).

Exemplar-based interpolation of sparsely sampled im-

ages. In Proceedings of the International Conference

on Energy Minimization Methods in Computer Vision

and Pattern Recognition, pages 331–344.

Fadili, M. J., Starck, J.-L., Bobin, J., and Moudden, Y.

(2010). Image decomposition and separation using

sparse representations: an overview. Proceedings of

the IEEE, 98(6):983–994.

Galea, S., Debattista, K., and Spina, S. (2014). GPU-based

selective sparse sampling for interactive high-ﬁdelity

rendering. In Proceedings of the International Con-

ference on Games and Virtual Worlds for Serious Ap-

plications, pages 1–8.

Gortler, S. J., Grzeszczuk, R., Szeliski, R., and Cohen, M. F.

(1996). The lumigraph. In Proceedings of the An-

nual Conference on Computer Graphics and Interac-

tive Techniques, pages 43–54.

Herzog, R., Eisemann, E., Myszkowski, K., and Seidel, H.-

P. (2010). Spatio-temporal upsampling on the GPU.

In Proceedings of the ACM SIGGRAPH symposium

on Interactive 3D Graphics and Games, pages 91–98.

Jonscher, M., Seiler, J., and Kaup, A. (2016). Texture-

dependent frequency selective reconstruction of non-

regularly sampled images. In Proceedings of the Pic-

ture Coding Symposium, pages 1–5.

Kalantari, N. K., Bako, S., and Sen, P. (2015). A machine

learning approach for ﬁltering Monte Carlo noise.

ACM Transactions on Graphics, 34(4):122–1.

Karis, B. (2014). Advances in real-time rendering in games.

SIGGRAPH Courses, 1.

Keller, A., Fascione, L., Fajardo, M., Georgiev, I., Chris-

tensen, P. H., Hanika, J., Eisenacher, C., and Nichols,

G. (2015). The path tracing revolution in the movie

industry. In SIGGRAPH Courses, pages 24–1.

Keller, A., Karras, T., Wald, I., Aila, T., Laine, S., Bikker, J.,

Gribble, C., Lee, W.-J., and McCombe, J. (2013). Ray

tracing is the future and ever will be... In SIGGRAPH

Courses.

Kim, Y., Seo, W., Kim, Y., Lim, Y., Nah, J.-H., and Ihm, I.

(2016). Adaptive undersampling for efﬁcient mobile

ray tracing. The Visual Computer, 32(6-8):801–811.

Koloda, J., Seiler, J., and Kaup, A. (2015). Denoising-

based image reconstruction from pixels located at

non-integer positions. In Proceedings of the IEEE

International Conference on Image Processing, pages

4565–4569.

Koloda, J., Seiler, J., and Kaup, A. (2016). Reliability-based

mesh-to-grid image reconstruction. In Proceedings of

the IEEE International Workshop on Multimedia Sig-

nal Processing, pages 1–5.

Koloda, J., Seiler, J., and Kaup, A. (2017). Frequency se-

lective mesh-to-grid resampling for image communi-

cation. IEEE Transactions on Multimedia, 19:1689–

1701.

Koskela, M., Viitanen, T., J

askel

ainen, P., and Takala, J.

(2016). Foveated path tracing. In Proceedings of the

International Symposium on Visual Computing, pages

723–732.

Lee, W.-J., Hwang, S. J., Shin, Y., Ryu, S., and Ihm, I.

(2016). Adaptive multi-rate ray sampling on mobile

ray tracing GPU. In SIGGRAPH ASIA 2016 Mobile

Graphics and Interactive Applications, page 3.

Longhurst, P., Debattista, K., and Chalmers, A. (2006). A

GPU based saliency map for high-ﬁdelity selective

rendering. In Proceedings of the International Con-

ference on Computer Graphics, Virtual Reality, Visu-

alisation and Interaction in Africa, pages 21–29.

Mara, M., McGuire, M., Bitterli, B., and Jarosz, W. (2017).

An efﬁcient denoising algorithm for global illumina-

tion. In Proceedings of High Performance Graphics,

page 3.

Marroquim, R., Kraus, M., and Cavalcanti, P. R. (2008). Ef-

ﬁcient image reconstruction for point-based and line-

based rendering. Computers & Graphics, 32(2):189–

203.

Overbeck, R. S., Donner, C., and Ramamoorthi, R. (2009).

Adaptive wavelet rendering. ACM Transactions on

Graphics, 28(5):140–1.

Pintus, R., Gobbetti, E., and Agus, M. (2011). Real-time

rendering of massive unstructured raw point clouds

using screen-space operators. In Proceedings of the

International Symposium on Virtual Reality, Archae-

ology and Intelligent Cultural Heritage.

Schied, C., Kaplanyan, A., Wyman, C., Patney, A., Chai-

tanya, C. R. A., Burgess, J., Liu, S., Dachsbacher,

C., Lefohn, A., and Salvi, M. (2017). Spatiotempo-

ral variance-guided ﬁltering: real-time reconstruction

for path-traced global illumination. In Proceedings of

High Performance Graphics, page 2.

Seiler, J., Jonscher, M., Sch

oberl, M., and Kaup, A. (2015).

Resampling images to a regular grid from a non-

regular subset of pixel positions using frequency se-

lective reconstruction. IEEE Transactions on Image

Processing, 24(11):4540–4555.

Sen, P. and Darabi, S. (2011). Compressive rendering: A

rendering application of compressed sensing. IEEE

Transactions on Visualization and Computer Graph-

ics, 17(4):487–499.

Shevtsov, M., Letavin, M., and Rukhlinskiy, A. (2010). Low

cost adaptive anti-aliasing for real-time ray-tracing. In

Proceedings of the International Conference on Com-

puter Graphics and Vision, volume 10, pages 45–49.

Steinberger, M., Kainz, B., Hauswiesner, S., Khlebnikov,

R., Kalkofen, D., and Schmalstieg, D. (2012). Ray pri-

oritization using stylization and visual saliency. Com-

puters & Graphics, 36(6):673–684.

Stengel, M., Grogorick, S., Eisemann, M., and Magnor,

M. (2016). Adaptive image-space sampling for gaze-

contingent real-time rendering. In Computer Graphics

Forum, volume 35, pages 129–139.

Strohmer, T. (1997). Computationally attractive reconstruc-

tion of bandlimited images from irregular samples.

IEEE Transactions on Image Processing, 6(4):540–

548.

Sparse Sampling for Real-time Ray Tracing

301

Takeda, H., Farsiu, S., and Milanfar, P. (2006). Robust ker-

nel regression for restoration and reconstruction of im-

ages from sparse noisy data. In IEEE International

Conference on Image Processing, pages 1257–1260.

Takeda, H., Farsiu, S., and Milanfar, P. (2007). Kernel

regression for image processing and reconstruction.

IEEE Transactions on Image Processing, 16(2):349–

366.

Tian, J. and Ma, K.-K. (2011). A survey on super-

resolution imaging. Signal, Image and Video Process-

ing, 5(3):329–342.

Vaidyanathan, K., Salvi, M., Toth, R., Foley, T., Akenine-

oller, T., Nilsson, J., Munkberg, J., Hasselgren, J.,

Sugihara, M., Clarberg, P., et al. (2014). Coarse pixel

shading. In Proceedings of High Performance Graph-

ics, pages 9–18.

Vazquez, C., Dubois, E., and Konrad, J. (2005). Recon-

struction of nonuniformly sampled images in spline

spaces. IEEE Transactions on Image Processing,

14(6):713–725.

Weier, M., Roth, T., Kruijff, E., Hinkenjann, A., P

erard-

Gayot, A., Slusallek, P., and Li, Y. (2016). Foveated

real-time ray tracing for head-mounted displays. Com-

puter Graphics Forum, 35(7):289–298.

Whitted, T. (1979). An improved illumination model

for shaded display. In ACM SIGGRAPH Computer

Graphics, volume 13, page 14.

Yang, L., Sander, P. V., and Lawrence, J. (2008). Geometry-

aware framebuffer level of detail. Computer Graphics

Forum, 27(4):1183–1188.

Zwicker, M., Jarosz, W., Lehtinen, J., Moon, B., Ra-

mamoorthi, R., Rousselle, F., Sen, P., Soler, C., and

Yoon, S.-E. (2015). Recent advances in adaptive sam-

pling and reconstruction for Monte Carlo rendering.

Computer Graphics Forum, 34(2):667–681.

Zwicker, M., Pﬁster, H., Van Baar, J., and Gross, M. (2001).

Surface splatting. In Proceedings of the Annual Con-

ference on Computer Graphics and Interactive Tech-

niques, pages 371–378.

GRAPP 2018 - International Conference on Computer Graphics Theory and Applications

302
