Who’s Driving My Car? A Machine Learning based Approach

to Driver Identiﬁcation

Fabio Martinelli

, Francesco Mercaldo

, Vittoria Nardone

, Albina Orlando

and Antonella Santone

Istituto di Informatica e Telematica, Consiglio Nazionale delle Ricerche (CNR), Pisa, Italy

Department of Engineering, University of Sannio, Benevento, Italy

Istituto per le Applicazioni del Calcolo “M. Picone”, Consiglio Nazionale delle Ricerche (CNR), Napoli, Italy

Department of Bioscience and Territory, University of Molise, Pesche (IS), Italy

Keywords:

Car, Can, Obd, Authentication, Machine Learning, Identiﬁcation.

Abstract:

Despite the development of new technologies, in order to prevent the stealing of cars, the number of car thefts

is sharply increasing. With the advent of electronics, new ways to steal cars were found. To avoid auto-theft

attacks, in this paper we propose a machine leaning based method to silently e continuously proﬁle the driver

by analyzing built-in vehicle sensors. We evaluate the efﬁciency of the proposed method in driver identiﬁcation

using 10 different drivers. Results are promising, as a matter of fact we obtain a high precision and a recall

evaluating a dataset containing data extracted from real vehicle.

1 INTRODUCTION AND

BACKGROUND

As highlighted by several studies, car theft is increas-

ing around the globe and the phenomenon does not

appear to stop.

The FBI national crime statistics show that car

theft appears to be on the rise this year in the United

States. While burglary and larceny theft were down

by 10% and 3% respectively, car theft was up by 1%

As a matter of fact, the National Insurance Crime

Bureau (NICB) reports that the Honda Accord was

the most frequently stolen passenger vehicle in 2016,

with 50,427 thefts among all model years of this car,

while among 2016 model year vehicles, the Toyota

Camry was the most frequently stolen vehicle in cal-

endar year 2016, with 1,113 thefts, followed by the

Nissan Altima with 1,063 thefts

In last years, cars are equipped with many com-

puters on board, exposing them to a new type of at-

tacks (Martinelli et al., 2017; Alheeti et al., 2015;

Lyamin et al., 2014). As a matter of fact, operating

systems running on cars, like any other one, are ex-

posed to bug and vulnerabilities (Taylor et al., 2016).

http://www.tracknstop.com/car-theft-in-u-s-on-rise-in-

2016/

http://www.iii.org/fact-statistic/auto-theft

This scenario calls for a plethora of new car theft

possibility (Massaro et al., 2017).

For instance, keyless cars could be at risk from at-

tackers using simply radio transmitters with the aim

to steal vehicles: in order to make evidence of this

issue, the ADAC German company used radio trans-

mitters to evaluate which cars could be broken in to.

The BMW, Audi, Ford, Land Rover, Hyundai Renault

and VW brands were among the manufacturers whose

cars are at risk from hackers

The main used technique consists in breaking into

the vehicle and plugging a laptop into the hidden di-

agnostic socket used by garages to detect and solve

faults: once connected the thieves can access the ve-

hicle’s electronic information, allowing them to drive

it away.

Since cars are evolved with on-board computers,

other developed techniques consist in get owners to

install malicious software into their mobile devices

working as a door lock in order to make the door open.

Researchers in last years proposed several ap-

proaches in order to solve the diver identiﬁcation is-

sue. For instance, authors in (Wakita et al., 2006) pro-

pose a driver identiﬁcation method that is based on

the driving behavior signals that are observed while

http://www.express.co.uk/life-style/cars/806889/Key

less-entry-car-keys-hack-theft-warning

Martinelli, F., Mercaldo, F., Nardone, V., Orlando, A. and Santone, A.

Who’s Driving My Car? A Machine Learning based Approach to Driver Identiﬁcation.

DOI: 10.5220/0006633403670372

In Proceedings of the 4th International Conference on Information Systems Security and Privacy (ICISSP 2018), pages 367-372

ISBN: 978-989-758-282-0

367

the driver is following another vehicle. They analyze

signals, as accelerator pedal, brake pedal, vehicle ve-

locity, and distance from the vehicle in front, were

measured using a driving simulator. The identiﬁca-

tion rates were 81% for twelve drivers using a driving

simulator and 73% for thirty drivers.

Researchers in (Miyajima et al., 2007; Nishiwaki

et al., 2007) model gas and brake pedal operation

patterns with Gaussian mixture model (GMM). They

achieve an identiﬁcation rate of 89.6% for a driving

simulator and 76.8% for a ﬁeld test with 276 drivers,

resulting in 61% and 55% error reduction, respec-

tively, over a driver model based on raw pedal opera-

tion signals without spectral analysis.

Driver behavior is described and modeled in (Choi

et al., 2007) using data from steering wheel angle,

brake status, acceleration status, and vehicle speed

through Hidden Markov Models (HMMs) and GMMs

employed to capture the sequence of driving char-

acteristics acquired from the CAN bus information.

They obtain 69% accuracy for action classiﬁcation,

and 25% accuracy for driver identiﬁcation.

In reference (Meng et al., 2006) features extracted

from the accelerator and brake pedal pressure are con-

sidered as inputs to a fuzzy neural network (FNN)

system to ascertain the identity of the driver. Two

fuzzy neural networks, namely, the evolving fuzzy

neural network (EFuNN) and the adaptive network-

based fuzzy inference system (ANFIS), are used to

demonstrate the viability of the two proposed feature

extraction techniques.

Starting from these considerations, in this paper

we propose a method to detect car theft using machine

learning techniques.

We highlight that our proposed method is able to

reach a precision and a recall equal to 0.992, while the

cited works obtain a detection rate lower than the one

we reached.

Our method permits to deﬁne the driver proﬁle by

merging together information about his behavior, for

this reason it can be useful to discriminate between

car owner and impostors.

Using well-known machine learning algorithms,

we classify the features set obtained from real-world

cars employed in a real environment in order to eval-

uate the effectiveness of the features extracted.

The paper poses the following research question:

• is it possible to characterize the driver behav-

ior through a set features generated by him-

self/herself when he/she is driving?

Below we highlight the main advantages provided by

our method:

• the features can be captured by using the car built-

in sensors without additional hardware;

• the features can be gathered with a good degree of

precision and are not inﬂuenced by external fac-

tors (for instance noises, air impurity);

• the features can be collected while the user is driv-

ing the car: the driver is not required to enter any

image or voice (this is the reason why the method

is called silent).

The paper proceeds as follows: Section 2 deeply

describes and motivates the detection method; Sec-

tion 3 illustrates the results of experiments; ﬁnally,

conclusions are drawn in Section 4.

2 THE METHOD

In this section we describe our method to identify

drivers behavior using data retrieved by CAN bus.

These data are broadcast to all components on

the bus and each component decides whether it is in-

tended for them, although segmented CAN networks

do exist.

In practice, using the CAN protocol the ECU “A”

is able to send data to the ECU “B”, but this is not

enough to realize the communication: it is also neces-

sary that the ECU “B” is able to recognize and use the

data received by ECU “A”, for this reason it is nec-

essary something that make able the two electronic

control units to “speak the same language. This is the

reason why the OBD-II standard (On Board Diagnos-

tics) (Birnbaum and Truglia, 2001) was introduced, in

order to deﬁne a common language that make the var-

ious ECUs able to communicate (of Automotive En-

gineers, 1999).

We consider the full set of real data (Kwak et al.,

2016) processed from the in-vehicle CAN data: to

collect data, the On Board Diagnostics 2 (OBD-II)

and CarbigsP as OBD-II scanner were used. The re-

cent vehicle has many measurement sensors and con-

trol sensors, so the vehicle is managed by ECU in

it. ECU is the device that controls parts of the vehi-

cle such as Engine, Automatic Transmission, and An-

tilock Braking System (i.e., the ABS). OBD refers to

the self-diagnostic and reporting capability by moni-

toring vehicle system in terms of ECU measurement

and vehicle failure. The data are recorded every 1

second during driving and they are related to a recent

model of KIA Motors Corporation in South Korea.

Ten different drivers participated to the experi-

ment by driving, with the same car, 4 different round-

trip path in Seoul (i.e., between Korea University and

SANGAM World Cup Stadium) for about 23 hours of

total driving time.

The driving path consists of three types of city

way, motor way and parking space with the total

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

368

length of about 46 km. The experiment is performed

since July, 28, 2015. The experiments was performed

in the similar time zone from 8 p.m. to 11 p.m.

on weekdays. The ten drivers completed two round

trips for reliable classiﬁcation, while data are col-

lected from totally different road conditions. The city

way has signal lamps and crosswalks, but the motor

way has none. The parking space is required to drive

slowly and cautiously.

The data that we used has total 94,401 records

stored every second with the size of 16.7Mb in total

and it is freely available for research purpose

We designed an experiment in order to evalu-

ate the effectiveness of the feature vector gathered

through the CAN bus we propose, expressed through

the research question RQ stated in the introduction.

More speciﬁcally, the experiment is aimed at ver-

ifying whether the features set is able to discriminate

the car owner by impostors.

We consider the classiﬁcation analysis in order to

assess whether the feature set is able to correctly clas-

sify car owner and impostors.

We adopt the supervised learning approach, con-

sidering that the driver features evaluated in this work

contain the driver labels.

Following classiﬁcation algorithms were used:

J48, J48graft, J48consolidated, RandomTree and

RepTree. These algorithms were applied to all fea-

tures (i.e., to the full feature vector gathered from the

OBD).

The classiﬁcation analysis was accomplished with

Weka

, a suite of machine learning software, largely

employed in data mining for scientiﬁc research.

3 THE EVALUATION

Five metrics were used to evaluate the classiﬁcation

results: FP rate, Precision, Recall, F-Measure and

ROC Area.

The false positive rate is calculated as the ratio

between the number of negative driver traces wrongly

categorized as belonging to the owner (i.e.,the false

positives) and the total number of actual impostor

traces (i.e., the true negatives):

FP rate =

f p

f p+tn

where fp indicates the number of false positives

and tn the number of true negatives.

https://sites.google.com/a/hksecurity.net/ocslab/Data

sets/driving-dataset

http://www.cs.waikato.ac.nz/ml/weka/

The precision has been computed as the propor-

tion of the examples that truly belong to class X

among all those which were assigned to the class. It

is the ratio of the number of relevant records retrieved

to the total number of irrelevant and relevant records

retrieved:

Precision =

t p

t p+ f p

where tp indicates the number of true positives

and fp indicates the number of false positives.

The recall has been computed as the proportion

of examples that were assigned to class X, among all

the examples that truly belong to the class, i.e., how

much part of the class was captured. It is the ratio of

the number of relevant records retrieved to the total

number of relevant records:

Recall =

t p

t p+ f n

where tp indicates the number of true positives

and fn indicates the number of false negatives.

The F-Measure is a measure of a test’s accuracy.

This score can be interpreted as a weighted average

of the precision and recall:

F-Measure = 2 ∗

Precision∗Recall

Precision+Recall

The Roc Area is deﬁned as the probability that a

positive instance randomly chosen is classiﬁed above

a negative randomly chosen.

The classiﬁcation analysis consisted of building

classiﬁers in order to evaluate features accuracy to

distinguish the car owner by an impostor.

We consider two different approaches in order to

build the model starting from the features.

In the ﬁrst one, the multi driver classiﬁcation, for

training the ﬁrst classiﬁer, we deﬁned T as a set of

labeled behavioral traces (BT, l), where each BT is

associated to a label l ∈ {A, B, C, D, E, F, G, H, I, J}.

For training the second classiﬁer, i.e., the binary

one, we deﬁned T as a set of labeled behavioral traces

(BT, l), where each BT is associated to a label l ∈

{impostor, owner}. For each BT we built a feature

vector F ∈ R

, where y is the number of the features

used in training phase (y=51).

For the learning phase, we consider a k-fold cross-

validation (Mitchell, 1999; Refaeilzadeh et al., 2009):

the dataset is randomly partitioned into k subsets. A

single subset is retained as the validation dataset for

testing the model, while the remaining k-1 subsets of

the original dataset are used as training data. We re-

peated the process for k = 10 times; each one of the k

subsets has been used once as the validation dataset.

Who’s Driving My Car? A Machine Learning based Approach to Driver Identiﬁcation

369

To obtain a single estimate, we computed the average

of the k results from the folds.

We evaluated the effectiveness of the classiﬁcation

method with the following procedure:

1. build a training set T ⊂ D;

2. build a testing set T

= D ÷ T ;

3. run the training phase on T;

4. apply the learned classiﬁer to each element of T

Each classiﬁcation was performed using 20% of

the dataset as training dataset and 80% as testing

dataset employing the full feature set.

We deﬁned C

as the set of the classiﬁcations we

performed, where u identiﬁes the driver (1≤u≤10).

For sake of clarity, we explain with an exam-

ple the method we adopted in the binary classiﬁca-

tion: when we perform C

classiﬁcation, we label the

traces related to the driver #2 as owner traces, and the

traces of the other user as impostor, while in the multi

driver classiﬁcation we consider the ten different label

drivers.

The results that we obtained with this procedure

are shown in Table 1.

In the multi driver classiﬁcation (All drivers fam-

ily) we obtain the following best results from the point

of the views of the metrics we considered:

• FP rate equal to 0.001 with the J48, J48graft and

J48consolidated algorithms;

• Precision, Recall and F-Measure equal to 0.992

using the J48 and the J48graft classiﬁcation algo-

rithms;

• Roc Area equal to 0.998 using J48, J48graft,

J48consolidated and RepTree classiﬁcation algo-

rithms.

In the single driver classiﬁcation, we obtain the

following results:

• FPRate ranging from 0 to 0.0018;

• Precision ranging from 0.844 to 0.998;

• Recall ranging between 0.88 and 0.998;

• F-Measure ranging between 0.88 and 0.998;;

• Roc Area ranging between 0.911 and 1.

4 CONCLUSIONS AND FUTURE

WORK

Modern vehicles, differently by older ones, integrate

a lot of sophisticated electronic devices. This increas-

ing technologies permitted to ﬁnd new way to steal

cars, for instance by exploiting the vulnerabilities of

the operating system embedded in today’s car. This

scenario calls for new methodologies in order to stem

the phenomenon resulting from the introduction of

computers in the car, with the consequent vulnerabil-

ity of software used. As a matter of fact, attackers

are developing several way in order to steal vehicles

exploiting the increasing technology currently avail-

able in nowadays cars. In this paper we propose a

method able to discriminate an impostor by the car

owner using a set of characteristics available by the

sensor embedded into the car. Using machine learn-

ing techniques (Cimitile et al., 2017; Mercaldo et al.,

2017; Mercaldo et al., 2016), we design several classi-

ﬁers able to evaluate the effectiveness of our method:

as a matter of fact we obtain in average a precision

and a recall equal to 0.998 in car owner discrimina-

tion. As future work, we plan to take into account in

our model the type of road in order to design a system

able to advise the user about the driving style to adopt.

In addition, we will extend the evaluation considering

features extracted by trucks and motorcycles with the

aim to identify thefts not only cars-related. Finally,

another very interesting research direction involves

the use of heuristic model checking (De Francesco

et al., 2016). This is supported by the very promis-

ing results obtained in other ﬁelds, like for example

in the malware detection area (Battista et al., 2016).

ACKNOWLEDGMENTS

This work has been partially supported by H2020

EU-funded projects NeCS and C3ISP and EIT-Digital

Project HII and PRIN “Governing Adaptive and Un-

planned Systems of Systems” and the EU project Cy-

berSure 734815.

REFERENCES

Alheeti, K. M. A., Gruebler, A., and McDonald-Maier,

K. D. (2015). An intrusion detection system against

malicious attacks on the communication network of

driverless cars. In 2015 12th Annual IEEE Con-

sumer Communications and Networking Conference

(CCNC), pages 916–921. IEEE.

Battista, P., Mercaldo, F., Nardone, V., Santone, A., and

Visaggio, C. A. (2016). Identiﬁcation of android mal-

ware families with model checking. In Proceedings of

the 2nd International Conference on Information Sys-

tems Security and Privacy, ICISSP 2016, Rome, Italy,

February 19-21, 2016., pages 542–547. SciTePress.

Birnbaum, R. and Truglia, J. (2001). Getting to know OBD

II. R. Birnbaum.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

370

Table 1: Classiﬁcation results: FP Rate, Precision, Recall, F-Measure and RocArea for classifying the full drivers dataset

(multi-driver classiﬁcation) and the single one computed with ﬁve different algorithms.

Family Algorithm FP Rate Precision Recall F-Measure Roc Area

J48 0.001 0.992 0.992 0.992 0.998

J48graft 0.001 0.992 0.992 0.992 0.998

All drivers J48consolidated 0.001 0.991 0.991 0.991 0.998

RandomTree 0.014 0.88 0.88 0.88 0.933

RepTree 0.002 0.987 0.987 0.987 0.998

J48 0 0.998 0.997 0.998 0.999

J48graft 0 0.998 0.996 0.997 0.999

Driver A J48consolidated 0.000 0.997 0.995 0.996 0.999

RandomTree 0.004 0.956 0.944 0.95 0.97

RepTree 0 0.997 0.996 0.996 1

J48 0.001 0.991 0.994 0.992 0.998

J48graft 0.002 0.99 0.994 0.992 0.998

Driver B J48consolidated 0.002 0.990 0.990 0.990 0.998

RandomTree 0.015 0.902 0.898 0.9 0.941

RepTree 0.002 0.987 0.986 0.986 0.998

J48 0.001 0.991 0.992 0.991 0.997

J48graft 0.001 0.99 0.991 0.991 0.997

Driver C J48consolidated 0.001 0.985 0.992 0.989 0.997

RandomTree 0.015 0.823 0.826 0.824 0.905

RepTree 0.002 0.977 0.979 0.978 0.998

J48 0.002 0.991 0.988 0.989 0.996

J48graft 0.001 0.992 0.987 0.99 0.996

Driver D J48consolidated 0.002 0.988 0.981 0.984 0.997

RandomTree 0.022 0.862 0.863 0.863 0.92

RepTree 0.003 0.979 0.979 0.979 0.997

J48 0 0.997 0.998 0.997 1

J48graft 0 0.996 0.998 0.997 0.999

Driver E J48consolidated 0.001 0.995 0.997 0.996 0.999

RandomTree 0.005 0.949 0.954 0.952 0.974

RepTree 0 0.996 0.997 0.996 0.999

J48 0.001 0.994 0.996 0.995 0.999

J48graft 0.001 0.993 0.996 0.994 0.999

Driver F J48consolidated 0.001 0.992 0.994 0.993 0.999

RandomTree 0.012 0.913 0.917 0.915 0.953

RepTree 0.001 0.992 0.992 0.992 0.999

J48 0.001 0.992 0.991 0.992 0.997

J48graft 0.001 0.992 0.991 0.992 0.997

Driver G J48consolidated 0.001 0.991 0.990 0.990 0.997

RandomTree 0.01 0.881 0.885 0.883 0.937

RepTree 0.001 0.984 0.984 0.984 0.998

J48 0.001 0.993 0.993 0.993 0.998

J48graft 0.001 0.993 0.993 0.993 0.998

Driver H J48consolidated 0.001 0.990 0.990 0.990 0.998

RandomTree 0.018 0.844 0.852 0.848 0.917

RepTree 0.002 0.986 0.987 0.986 0.998

J48 0.001 0.988 0.988 0.988 0.997

J48graft 0.001 0.99 0.988 0.989 0.997

Driver I J48consolidated 0.001 0.991 0.994 0.993 0.998

RandomTree 0.018 0.808 0.816 0.812 0.899

RepTree 0.001 0.988 0.984 0.986 0.998

J48 0.001 0.99 0.988 0.989 0.997

J48graft 0.001 0.99 0.99 0.99 0.997

Driver J J48consolidated 0.001 0.990 0.990 0.990 0.998

RandomTree 0.015 0.856 0.838 0.846 0.911

RepTree 0.002 0.984 0.986 0.985 0.998

Who’s Driving My Car? A Machine Learning based Approach to Driver Identiﬁcation

371

Choi, S., Kim, J., Kwak, D., Angkititrakul, P., and Hansen,

J. H. (2007). Analysis and classiﬁcation of driver be-

havior using in-vehicle can-bus information. In Bi-

ennial Workshop on DSP for In-Vehicle and Mobile

Systems, pages 17–19.

Cimitile, A., Martinelli, F., and Mercaldo, F. (2017). Ma-

chine learning meets ios malware: Identifying mali-

cious applications on apple environment. In ICISSP,

pages 487–492.

De Francesco, N., Lettieri, G., Santone, A., and Vaglini,

G. (2016). Heuristic search for equivalence checking.

Software and System Modeling, 15(2):513–530.

Kwak, B. I., Woo, J., and Kim, H. K. (2016). Know your

master: Driver proﬁling-based anti-theft method. In

PST 2016.

Lyamin, N., Vinel, A. V., Jonsson, M., and Loo, J. (2014).

Real-time detection of denial-of-service attacks in

ieee 802.11 p vehicular networks. IEEE Communi-

cations letters, 18(1):110–113.

Martinelli, F., Mercaldo, F., Nardone, V., and Santone, A.

(2017). Car hacking identiﬁcation through fuzzy logic

algorithms. In Fuzzy Systems (FUZZ-IEEE), IEEE In-

ternational Conference on. IEEE. IEEE.

Massaro, E., Ahn, C., Ratti, C., Santi, P., Stahlmann, R.,

Lamprecht, A., Roehder, M., and Huber, M. (2017).

The car as an ambient sensing platform. Proceedings

of the IEEE, 105(1):3–7.

Meng, X., Lee, K. K., and Xu, Y. (2006). Human driving

behavior recognition based on hidden markov models.

In Robotics and Biomimetics, 2006. ROBIO’06. IEEE

International Conference on, pages 274–279. IEEE.

Mercaldo, F., Nardone, V., and Santone, A. (2017). Dia-

betes mellitus affected patients classiﬁcation and diag-

nosis through machine learning techniques. Procedia

Computer Science, 112(C):2519–2528.

Mercaldo, F., Visaggio, C. A., Canfora, G., and Cimi-

tile, A. (2016). Mobile malware detection in the real

world. In Software Engineering Companion (ICSE-

C), IEEE/ACM International Conference on, pages

744–746. IEEE.

Mitchell, T. M. (1999). Machine learning and data mining.

Communications of the ACM, 42(11):30–36.

Miyajima, C., Nishiwaki, Y., Ozawa, K., Wakita, T., Itou,

K., Takeda, K., and Itakura, F. (2007). Driver mod-

eling based on driving behavior and its evaluation

in driver identiﬁcation. Proceedings of the IEEE,

95(2):427–437.

Nishiwaki, Y., Ozawa, K., Wakita, T., Miyajima, C., Itou,

K., and Takeda, K. (2007). Driver identiﬁcation based

on spectral analysis of driving behavioral signals. In

Advances for In-Vehicle and Mobile Systems, pages

25–34. Springer.

of Automotive Engineers, S. (1999). On-Board Diagnostics

for Light and Medium Duty Vehicles Standards Man-

ual. Society of Automotive Engineers, US.

Refaeilzadeh, P., Tang, L., and Liu, H. (2009). Cross-

validation. In Encyclopedia of database systems,

pages 532–538. Springer.

Taylor, A., Leblanc, S., and Japkowicz, N. (2016). Anomaly

detection in automobile control network data with

long short-term memory networks. In Data Science

and Advanced Analytics (DSAA), 2016 IEEE Interna-

tional Conference on, pages 130–139. IEEE.

Wakita, T., Ozawa, K., Miyajima, C., Igarashi, K.,

Katunobu, I., Takeda, K., and Itakura, F. (2006).

Driver identiﬁcation using driving behavior signals.

IEICE TRANSACTIONS on Information and Systems,

89(3):1188–1194.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

372
