A Security Analysis, and a Fix,

of a Code-Corrupted Honeywords System

Ziya Alper Genc¸, Gabriele Lenzini, Peter Y. A. Ryan and Itzel Vazquez Sandoval

Interdisciplinary Centre for Security, Reliability and Trust (SnT), University of Luxembourg, Luxembourg

Keywords:

Honeywords, Password-based Authentication, Secure Protocols Design, Formal Analysis, ProVerif.

Abstract:

In 2013 Juels and Rivest introduced the Honeywords System, a password-based authentication system desig-

ned to detect when a password ﬁle has been stolen. A Honeywords System stores passwords together with

indistinguishable decoy words so when an intruder steals the ﬁle, retrieves the words, and tries to log-in, he

does not know which one is the password. By guessing one from the decoy words, he may not be lucky and

reveal the leak. Juels and Rivest left a problem open: how to make the system secure even when the intruder

corrupted the login server’s code. In this paper we study and solve the problem. However, since “code cor-

ruption” is a powerful attack, we ﬁrst deﬁne rigorously the threat and set a few assumptions under which the

problem is still solvable, before showing meaningful attacks against the original Honeywords System. Then

we elicit a fundamental security requirement, implementing which, we are able to restore the Honeywords

System’s security despite a corrupted login service. We verify the new protocol’s security formally, using

ProVerif for this task. We also implement the protocol and test its performance. Finally, at the light of our

ﬁndings, we discuss whether it is still worth using a ﬁxed honeywords-based system against such a power-

ful threat, or whether it is better, in order to be resilient against code corruption attacks, to design afresh a

completely different password-based authentication solution.

1 INTRODUCTION

Password-based authentication is the most used met-

hod to validate users (Furnell et al., 2000). For users

is very simple: they type username and password

and submit the pair by pressing the return key or a

mouse’s button. For servers, it is easy as well: they

check the credentials against a database of legitimate

user-password pairs and grant access if the search

succeeds.

The authentication process is trustworthy only if

passwords remain secret. Users are expected to keep

them safe, they are supposedly transmitted over en-

crypted channels, and servers are expected not to store

them in cleartext but rather to keep them hashed (usu-

ally with some “salt”) in a ﬁle called the password

ﬁle.

Keeping passwords safe never works perfectly.

Users can (or can be lured to) reveal their creden-

tials, and servers can be hacked and have the pass-

word ﬁle stolen, exposing the hashed passwords to

ofﬂine dictionary attacks. In both cases, intruders

will gain, illegitimately, an authorized access. Re-

cent news reports on the extent of the problem. In

2016, the NY Times wrote: “Yahoo!, already reeling

from its September disclosure that 500 million user

accounts had been hacked in 2014, disclosed Wednes-

day that a different attack in 2013 compromised more

than 1 billion accounts” (Goel and Perlroth, 2016). In

the month in which we wrote this paper, Oct. 2017,

Yahoo admitted that indeed the number of accounts

affected by the data breach in 2013 is above 3 bil-

lion (Newman, 2017). As well in 2016, Mashable re-

ported: “MySpace and Tumblr have recently joined

LinkedIn on the list of websites that had millions of

than 64 million Tumblr accounts and more than 360

million MySpace accounts were affected by the data

breaches.” (Beck, 2016). The theft was discovered in

2016 when someone tried to sell the credentials in the

black market. In these examples, what hits as drama-

tic as the number of passwords lost is the large delay

that has passed between an attack and its detection.

Failing to detect a password breakage on time wor-

sens the problem. It delays the application of coun-

termeasures to limit the damage.

To improve the awareness of password(s) theft,

computer security research has proposed solutions.

Genç, Z., Lenzini, G., Ryan, P. and Sandoval, I.

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System.

DOI: 10.5220/0006609100830095

In Proceedings of the 4th International Conference on Information Systems Security and Privacy (ICISSP 2018), pages 83-95

ISBN: 978-989-758-282-0

For instance, Google monitors suspicious activities

and invites users to review from what device and from

which location they have accessed their account. But

of course, more critical is to ensure that a service be-

come aware of the theft of a password ﬁle because,

from it, a great deal of passwords is exposed at once.

This is what we discuss next.

2 RESEARCH CONTEXT

In 2013, Juels and Rivest proposed to modify the

classical password-based authentication scheme (Ju-

els and Rivest, 2013). They called the new system,

the Honeywords System.

A Honeywords System hides and stores a user

(hashed) password in a list of decoy words, called ho-

neywords. Honeywords are to mimic the password,

so that the password cannot be distinguished from

them. So, “redsun3” is a good honeyword for “whi-

temoon5”. A sweetword should have the same pro-

bability to be guessed e.g., by dictionary search as

the original password, enjoying a property called ﬂat-

ness (Juels and Rivest, 2013; Erguler, 2016). Several

algorithms to generate (ﬂat) honeyword’s are extensi-

vely discussed in (Juels and Rivest, 2013). The rele-

vant point is that, since it is very unlikely that a user

types a honeyword purely by chance, any attempt to

dicates that the password ﬁle has been leaked. In that

case, the system ﬂags the event and contingency acti-

ons are taken (e.g., system administrators are alerted,

monitors are activated, user’s execution rights are re-

duced, user’s actions are run in a sandbox, and so on).

The Honeywords System’s architecture is logi-

cally organized in two modules: (1) a “computer sy-

stem” which, according to Juels and Rivest, is “any

system that allows a user to ‘log in’ after she has pro-

vided a username and a password” (ibid) and which

we call the Login Server (LS); (2) an auxiliary har-

dened secure server that assists with the use of hone-

ywords, which Juels and Rivest call the Honeychec-

ker (HC).

For each registered user u, LS keeps (in the pas-

sword ﬁle) the ordered list of u’s sweetwords (so are

called collectively honeywords and passwords), deno-

ted here by [h(w

)]

, for x ∈ [1,k] where k is the ﬁxed

number of sweetwords. In turn, HC stores c

, the in-

dex of u’s password in the list.

At authentication, the system runs a simple proto-

col: LS receives (u,w); then, it searches the hashed

version of w, in the list of (hashed) sweetwords of u.

If no match is found, login is denied. Otherwise the

LS sends to the HC the message (u, j), where j is

u,w

[h(w

)]

u,w

j ← IndexOf



h(w),[h(w

)]





u, j



resp ← ( j = c

resp

If ( j 6= ⊥)If ( j 6= ⊥)

resp

Figure 1: Honeywords System Protocol.

the found position. This communication occurs over

dedicated and/or encrypted and authenticated chan-

nels. The HC checks whether j = c

. In case the

test succeeds, access is granted. In case the test fails,

it is up to the HC to decide what to do. Juels and

Rivest say: “Depending on the policy chosen, the ho-

neychecker may or may not reply to the computer sy-

stem when a login is attempted. When it detects that

something is amiss with the login attempt, it could

signal to the computer system that login should be de-

nied. On the other hand it may merely signal a ‘silent

alarm’ to an administrator, and let the login on the

computer system proceed. In the latter case, we could

perhaps call the honeychecker a ‘login monitor’ rat-

her than a ‘honeychecker’.”(ibid). Figure 1 illustrates

the protocol considering a responsive honeychecker.

The Honeywords System does not impede that a

password ﬁle is stolen nor it avoids impersonation:

an intruder who has retrieved by an ofﬂine dictionary

attack the sweetwords can still succeed in guessing

the correct password of a user by random choice.

Contribution. Juels and Rivest have left open se-

veral problems. One of them reads as follows (the

italics is ours):

“How can a Honeywords System best be de-

signed to withstand active attacks e.g., malici-

ous messages issued by a compromised com-

puter system or code modiﬁcation of the com-

puter system?’ (ibid).

Here we take on the task to discuss the part of the

problem regarding “to withstand code modiﬁcation of

the computer system”, which we remind is the module

that we call the LS. The corruption of this compo-

nent poses indeed the interesting case: it is discussed

in (Juels and Rivest, 2013) where the authors state:

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

“compromising only the honeychecker at worst redu-

ces security to the level it was before the introduction

of honeywords and the honeychecker”. Instead, the

situation worsens if HC and LS were both corrupted.

In this case we are inclined to believe that there is no

way to detect the leakage of password ﬁle whereas the

intruder has a way to gain access unnoticed, but only a

rigorous analysis, out of scope but suitable for future

work, can provide evidence to this claim.

Thus, we study security of the Honeywords Sy-

stem against an adversary that has succeeded in “code

modifying the LS” and we propose a solution for

it. However, since the notion of “code modiﬁcation”

was left informal in Juels and Rivest’s work and it is

not clear enough to understand the real nature of the

threat, we ﬁrst need to critically discuss it.

In §3 we give a rigorous deﬁnition for the threat

“code modiﬁcation”, which we rename “code cor-

ruption” to stress its maliciousness. We also state a

few foundational assumptions before thoroughly gi-

ving the analysis of security of the original Honey-

words System under the threat.

In §4 we prove the Honeywords System insecure,

illustrating an attack that works when the LS’s code

has been corrupted according to our model and under

our assumptions. The attack reveals that when con-

fronted against the threat, the original Honeywords

System has a core weakness. From studying the root

cause of the attack we elicit a security requirement

and by fulﬁlling it we are able to provide a solution to

the problem.

In §5 we describe a new cryptographic protocol

which we argue that removes the weakness and so re-

stores security. We sustain this statement formally in

§7. We model in ProVerif the protocol together with

the code-corrupting adversary and we run an automa-

tic analysis. The results of the veriﬁcation conﬁrm

that the previous attack is no more possible. Actually,

we prove that there are no more attacks against the

new protocol, in the given model.

Our solution is meant to be primarily of theoreti-

cal interest, but because its cryptographic primitives

rely on a generous use of exponentiation, we thought

useful to implement the protocol and benchmark its

performance with respect to the original Honeywords

System. The results of the tests are reported in §8:

they show that although slower than the original Ho-

neywords System, the loss in performance is linear

in k, the number of sweetwords. Roughly speaking,

our scheme can handle a few hundred authentication

requests per second on a laptop with the service run-

ning on a virtual machine. It is reasonable to expect

better results on more performing servers.

At the end, in §9, we discuss our solution in a wi-

der perspective. We look at it from distance to con-

clude that, although it solves the open problem and

works against the code-corruption threat that we have

deﬁned, it actually suggests a completely innova-

tive design for password-based authentication stron-

ger than that of the ﬁxed Honeywords System.

3 ADVERSARY MODELS

What is a reasonable goal for an adversary that in-

tends to code corrupt the system? What is code cor-

ruption? What levels of corruption are interesting to

study?

We have to answer these questions to fully under-

stand the threat. And understanding code corruption

requires also introducing assumptions that limit the

extension of the threat. Code corruption can be very

disruptive and not all its instances are interesting, in

the sense that they do not bring to insights that help

up understanding fundamental weaknesses of the sy-

stem design. What understanding do we gain from a

code corruption that, for instance, causes a shut-down

of the entire systems? In short, we have to deﬁne ri-

gorously our adversary model.

We start with an obvious assumption that follows

from the original Juels and Rivest’s paper:

Assumption 1. The adversary, before code-

corrupting the LS, knows the sweetwords but not the

passwords.

Assumption 1 says that the adversary has stolen

the password ﬁle and has reverse-engineered all the k

sweetwords of, say, user u: yet, he does not know

which one among u’s sweetwords is the password.

The adversary can try to guess it and log in with that

guess, which means that his probability to log in wit-

hout the HC’s raising an alarm is 1/k in the worst

case, when the intruder na

ıvely picks at random a

sweetword. Additional factors, such as knowing so-

cial information about a speciﬁc user, might be used

to increase the probability of guessing the password.

Let us call this event a “successful log-in”.

Let us now start answering the ﬁrst question:

“what is a reasonable goal for an adversary that in-

tends to code corrupt the system?”. We will consider

as the answer that a reasonable goal is to increase the

intruder’s probability of a successful log-in to a value

higher than that the intruder would have by guessing

the password and with an honest LS.

Deﬁnition 1. The goal of a code corruption attack is

to increase the adversary’s probability to successfully

password among the sweetwords retrieved from the

passwords ﬁle.

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System

We answer the second question “what is code cor-

ruption?” gradually. We start with a very general

and powerful deﬁnition, but we will later constrain

it while answering the last question “what levels of

corruption are reasonable to consider”?

Deﬁnition 2. Let ls.exe be the code that deﬁnes the

protocol executed by the LS. Code corruption of LS

means changing ls.exe.

With its code corrupted, the LS’s working can

change completely. An intruder can reprogram it to

do whatever, e.g., to play chess.

However, we are

not interested in attacks that change the functionality

of the LS, for the reason that they do not help the ad-

versary to increase its probability of successful log-

ging in. For a similar reason, we are not interested in

attacks that shut-down the systems or cause Denial-

of-Service. These are important attacks from which

to seek defense, but out-of-scope in this study.

We also exclude attacks such as those consisting

in changing ls.exe to always grant access. Actually,

there is a technical reason for this choice. The origi-

nal paper does not give full detail of the architecture

of the “computer system”, our LS, but it seems reaso-

nable to assume that Honeywords System implements

a separation of duties (Botha and Eloff, 2001). And

the duty of LS is only to search the proffered pass-

word in the password ﬁle, to consult the HC, and pos-

sibly to report the decision to the user, but not to grant

or deny accesses.

So, what is a reasonable code corruption? We con-

sider here a particular type of corruption, as much as

possible “undetectable”, that is working without rai-

sing suspect of LS’s misbehaving into the other modu-

les. This can be achieved by changing ls.exe in such

a way that LS’s behaviour remains the same from the

point of view of the modules it interacts with, mainly

from the viewpoint of who can raise alarms, primarily

the HC and, secondarily, the system administrators.

Assumption 2. A code corruption against LS does

not change the LS’s observable behaviour.

The rationale of this assumption is that, if the ad-

versary changes the observable behaviour of LS, this

would result in an anomaly that can be detected, trig-

gering an alert in response to which a safe version of

the ls.exe can be restored. Since the adversary may

have a once-in-lifetime opportunity to corrupt LS’s

code, he may not want to see his efforts vanishing in

this way. Of course not all attackers will be so concer-

ned about being undetected. They can be satisﬁed by

managing to log in and say ex-ﬁltrate sensitive data

This is what R. Gonggrijp did when, in 2006, proved

insecure a Dutch electronic voting machine.

might be ﬁne, even if this leaves a trail. But we de-

cided to scope our analysis only within the context of

Assumption 2.

However, even under Assumption 2 there are sub-

tleties that need to be addressed. Interpreted strictly it

does not allow the creation of any back door between

the adversary and the LS that this last can use at any-

time to leak information. This is because, interpre-

ting strictly the term “undetectability”, an exchange

of messages from the LS towards the adversary and

outside the protocol’s message ﬂow can be eventu-

ally detected (e.g., by monitoring the net trafﬁc), lea-

ding to have a safe version of the ls.exe re-installed.

Thus according to this interpretation, Assumption 2

says that if the intruder wants to communicate with

the corrupted LS, it must use the same channels from

which legitimate users log in, and must respect the

message ﬂow of the honest protocol. This does not

exclude that, when re-coding ls.exe, the adversary

can use the knowledge he has gained from having hac-

ked the password ﬁle in the ﬁrst place. It can use the

user’s IDs and sweetwords, and it can hard-code this

information in the corrupted ls.exe.

Still, if we take Assumption 2 less strictly, it ad-

mits that some information can ﬂow back to the ad-

versary, for example, in message resp. And, as we

will discuss in detail in §4, letting LS to communicate

back to the adversary leads to a powerful attack that

breaks the original Honeywords System. In short, the

attack works because LS can learn u’s password (or

the hash of it). This is a feature more than a vulnera-

bility but a feature that a collusive adversary able to

invert the hash can exploit to know the password. So,

an incentive for code corrupting the LS is exactly to

create this retroactive communication and we cannot

exclude this possibility in our analysis. We propose

thus the following methodology. By default we inter-

pret Assumption 2 strictly but, separately, we always

discuss what happens if we relax this constraint and

let LS leak information to the intruder.

Notably, the new protocol that we describe in §5,

although designed to secure the Honeywords System

under an Assumption 2 interpreted strictly turns out to

be efﬁcient also when we relax it. The new protocol

will not impede the leak nor stop the adversary from

learning u’s password, but will make that information

useless for the adversary because it will not be able

reduces considerably the role of the password as the

only authentication token.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

4 ATTACKS

As future reference, we write down how ls.exe looks

like. Algorithm 1 shows it in pseudo-code, using a

notation whose commands are self-explanatory. Here,

passwd is the password ﬁle, passwd

is the row of

user u, and H is a hash function (e.g., SHA-3 (NIST,

2015)). We also assume that u is a legitimate user’s

name.

Algorithm 1: Login Server Authentication.

1: procedure ls.exe(passwd)

2: while true do;

3: ReceiveFrom(U;(u,w));

4: j ← IndexOf(H(w),passwd

);

5: SendTo(HC;(u, j));

6: ReceiveFrom(HC;resp);

7: SendTo(U;resp);

Algorithm 2: Code Corrupted LS.

1: procedure ls

.exe(passwd)

2: (u

) ← (⊥,⊥)  init good (u,w)

3: while true do;

4: ReceiveFrom(U;(u,w));

5: if (u

6= ⊥) ∧ (u = Mallory) then

6: (u,w) ← (u

)

7: j ← IndexOf(H(w),passwd

);

8: SendTo(HC;(u, j));

9: ReceiveFrom(HC;resp);

10: if (resp = granted) then

11: (u

) ← (u,w)  good (u,w)

12: SendTo(U;resp);

If the adversary can corrupt ls.exe, even under our

Assumption 2 taken strictly, there is an obvious at-

tack. The corrupted ls

.exe is reported in Algorithm 2.

It stores a good user’s password when LS sees it, and

then it reuses that knowledge to let the adversary gain

access, when the adversary reveals itself at the log-in

with a speciﬁc user name (e.g., “Mallory”).

Actually, LS could remember only the valid j

(in step 11) and, in a next round, skip searching the

passwd

(step 7), and send that j to the HC (step 8).

But the corrupted ls.exe outlined above mimics the

behaviour of LS more faithfully and shows also that

LS gets knowledge of a user’s valid password. This,

we will see, is the root of serious vulnerability.

Algorithm 2 represents an ideal attack. Not al-

ways, in instruction 10, the LS learns u’s password

with certainty. This may happen, for instance, when

the HC follows a contingency policy that dictate to re-

spond by granting access even when he sees a sweet-

word, as suggested in the original work (see also our

quote of it in §2). However, the following strategy

gives the LS at least a good chance to guess the pass-

word, especially when the strategy is coordinated with

the adversary: since the adversary is the only one that

can submit honeywords, it refrains itself from trying

to access for a certain time. During this interval, the

only requests that arrive to the LS pretending to be

from user u are actually from the legitimate u; all the

w that come with the requests then must be the u’s

legitimate password. Surely, the user can sometimes

misspell the password, but that will never collide with

a honeyword (because honeywords are ﬂat, see §2).

It is therefore possible for the LS, purely by statisti-

cal analysis and by cross comparison between what

u submits, to infer the u’s real password and at that

moment the LS can so help the adversary as we illus-

trated in our ideal version of the attack. The adversary

has raised its probability to gain a successful access to

values higher than 1/k.

This attack is already serious but under a relaxed

Assumption 2, LS can further send the password back

to the adversary, who now can use the u’s credentials

at any time.

Discussion. The root cause of the attack seems the-

refore to lie in the fact that LS knows u’s password.

Only hashing the password will not help, since the LS

can search the position in the password ﬁle or, under

a relaxed Assumption 2, send the hash back to the ad-

versary who can reserve the hash. The main problems

seem then rooted into three concomitant facts: (a) LS

receives username and password in clear; (b) LS can

query HC as an oracle to know whether that submitted

password is the user u’s valid password (in this way it

also get to know the hash of the password); (c) LS can

retrieve the index of the password in passwd

. So, if

a solution exists that makes the system secure despite

a corrupted ls.exe then it would be such that it avoids

that LS could perform all these three actions (a)-(c)

together. We state this ﬁnding as a requirement:

Requirement 1. A solution for a LS resilient to code

corruption should not (1) let the LS receive userna-

mes and (tentative) passwords in clear, (2) let it know

when the typed input refers to a valid password, and

(3) allow it to reuse that pair to retrieve a valid index

at any moment that is not when a legitimate user logs

in.

5 TOWARDS A SOLUTION

In searching for a solution we are not interested in

pragmatic ﬁxes like checking regularly the integrity

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System

of ls.exe and reinstalling a safe copy. Our lack of

interest is not because solutions like that are not fully

effective (e.g., the intruder can still execute its attack

before any integrity check is performed) but because

such pragmatic ﬁxes do not give any insights about

the real weakness of the system. The same argument

holds for best practices like forcing users changing the

password frequently. Thus, if a solution exists then it

must be searched in a strategy that satisﬁes our requi-

rement’s items (1)-(3).

One way to comply with them is by implementing

the following countermeasures: (i) passwd

is shuf-

ﬂed each time LS queries HC: this avoids that LS can

reuse an index j that it has learned to be the index

of u’s password; (ii) passwd

is re-hashed each time

LS queries HC: this avoids that LS can search again

for the index of a typed password that it got to know

being a valid u’s password; (iii) let the LS know what

to search in passwd

only when user u is logging in:

this precaution is to avoid that LS can perform off-line

searches on passwd

The countermeasures (i)-(ii), and so requirements

(1)-(2), can be implemented leaving HC in charge of

shufﬂing and re-hashing the password ﬁle each time

that a user logs in and that the LS questions the HC

about index j.

The shufﬂing does not require particular explana-

tion. It must be randomized but is a standard step: gi-

ven a row [w

,. ..,w

], and a permutation π, it returns

π(1)

,. ..,w

π(k)

The re-hashing, instead, needs to be explained. It

is implemented by cryptographic exponentiation. For

each user, HC possesses g, a generator of a multipli-

cative subgroup G of order q (so, actually, g should

be written g

, but to lighten the notation we omit the

index u). When ﬁrst the list of sweetwords is genera-

ted, the ﬁle is initially hashed using g

, where r

∈

{1,· ·· ,q − 1} is a random number. The u’s row of

the ﬁle is therefore [g

·w

,. ..,g

·w

], which we write

)

,. ..,h

)

] to stress that this is a hashing.

More synthetically we also write it as h

(w).

To rehash the row and obtain h

(w), HC choses a

new random number r

∈ {1,··· ,q− 1} and, for each

element w

of the row, it calculates

)

= (g

·w

)

= g

·w

= g

·w

The process can be iterated: to re-hash token h

(w),

HC selects another number r

n+1

∈ {1,· ·· ,q − 1} and

computes (h

(w))

n+1

which is the re-hashed token

n+1

(w).

In fact, HC reshufﬂes and re-hashes passwd

one single step as shown in Figure 2.

So far, we are envisioning a message ﬂow as fol-

lows: when HC receives from LS a check query, it

π(1)

)

π(k)

)

n+1

(1)

)

n+1

(k)

)

(c)

Figure 2: Shufﬂing/re-hashing w’s and updating c.

also receives passwd

, which it shufﬂes using a new

ordering π

, and re-hashes using a freshly generated

n+1

. The re-hashed, re-shufﬂed row of u, passwd

, is

therefore [h

u,π

(i)

)]

i∈{1,...,k}

, which we write com-

pactly as passwd

n+1

. HC performs these three steps

indivisibly: the passwd

should not be accessed by

concurrent versions of the HC before it has been shuf-

ﬂed and re-hashed.

What explained so far implements countermeasu-

res (i) and (ii). However, each n

time that a user u

logs in and submits the password w, LS needs ﬁrst to

calculate h

(w) = g

·w

before being able to search

for w’s index in passwd

Letting LS to do this while avoiding that it gets to

know u’s password (i.e., by taking advantage of kno-

wing the re-hashed password ﬁle passwd

and the re-

hashed h

(w), so anticipating the search and using

HC as an oracle) is not obvious. We need to imple-

ment countermeasure (iii) and prevent LS from sear-

ching the ﬁle at any time that is not when a legitimate

user u logs in.

Our ﬁnal solution is explained in §6 and its work-

ﬂow is illustrated in Figure 3. Its core idea is to inform

the HC when a user is logging in, but without passing

through the LS which may otherwise interfere with

the communication. Because of the risk of man-in-

the-middle attacks, this communication should not be

over the Internet either. Instead, it must happen on a

secure second channel between the user and the HC,

which we suggest to be the ether and implement by

letting them use a One-Time-Password (OTP) device.

We are aware that, introduced without an adequate ex-

planation, the need of a second channel and our sug-

gestion to use an OTP may appear arbitrary and un-

justiﬁed. They are not. Thus, in the next section we

brieﬂy explain our reasons, but the reader interested

only in the new protocol can skip it, and restart the

reading from §6.

Why a Second Channel? Before concluding that

we need a second channel between the user and the

HC we tried to comply with countermeasure (iii) by

other ways. One attempt was to add a module, called

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Keys Register (KR), to keep r

. Abstractly, this sug-

gests to outsource the calculation of the hash of the

submitted password out from the LS. In particular,

we let KR receive (u, w) and calculate the h

(w). The

token is thus forwarded to the LS, who also receives

the username u. Notably, KR’s role cannot be played

by LS itself. This would lead it to know the hash of

the password and so its valid index, consequently ena-

bling an attack as we have described previously. KR’s

role apart, the authentication process is not different

from what we described before, with the HC that also

shufﬂes, re-hashes, and returns the password ﬁle to

the LS, but at the end the HC sends the new r

n+1

only

to the KR, which is ready for a new session.

This solution works i.e., it is secure, but only if KR

cannot be code-corrupted. This is not an assumption

that we intend to take easily. According to Juels and

Rivest, the only component that is hardened secure is

the HC. Thus, KR should be considered corruptible.

And if it is so, the intermediate solution has a ﬂaw. An

adversary can compromise both kr.exe and ls.exe and,

even under a strict Assumption2 with no back doors,

manage to successfully log in. The attack is imple-

mented by the following corrupted code, where we

assume h

and passwd

be updates of h and passwd

The corrupted instructions are in red:

Algorithm 3: Code Corrupted KR.

1: procedure kr

.exe(r

)

2: while true do;

3: ReceiveFrom(U;(u,w);

4: SendTo(LS;h

(w));

5: ReceiveFrom(HC;r

n+1

);

6: SendTo(LS;h

n+1

(w));

KR resends the last w, re-hashed using the new

n+1

received from HC. KR does not know whether

w is a valid password, but a corrupted LS does. The

attack works because LS gets pieces of information

beforehand, using which, he can anticipate querying

the new password ﬁle and get a valid j that can be

used to let the adversary in.

Alternative ways to implement (iii), such as

using timestamps from the user’s side as a proof of

freshness do not work either since LS stands in the

middle and can compromise those messages. For all

this follows our conclusion that if there must be a “sy-

nchronization” between users and the HC, it must be

happening over a channel that is not under the control

on any module of the Honeywords System nor of the

adversary.

6 THE NEW PROTOCOL

One way to realize requirement’s items (i)-(iii) in

agreement with the Honeywords System solution, is

to empower the user (i.e., the user’s browser) with the

ability to hash his password w with g

using the same

that is generated by the HC. It is (almost) equiva-

lent to let the user play the role of KR.

However, letting HC send r directly to the user

over the Internet leaves the channel exposed to man-

in-the-middle attacks and introduces other issues such

as that of ensuring authentication of the user. The

channel through which the HC “communicates” with

the user must be a second channel and not in the In-

ternet. We already justiﬁed this choice in the previous

section.

The solution that we are about to discuss now and

prove secure in the next section requires that the HC

and the user share an OTP device. This is employed to

generate a new seed r each time that the OTP is used,

a seed which is also the same for the user and the HC.

The protocol message sequence diagram is detailed in

Figure 3.

The OTP serves as pseudo-random generator but

also as proof of freshness, since what it generates is

synchronized with what the OTP generates by the HC.

Here we talk of an OTP that generates a new seed each

time that it is pressed.

In Figure 3, we have indicated with OTP(n) the

action of using the OTP for the n

time (step 1). The

user sends to the LS, the username u and the hashed

version of its password, h

(w), where the hashing

takes the n

OTP-generated number r

as parameter

(step 2).

Then, the protocol follows as expected: the LS

searches for an index in the password ﬁle (step 3); the

ﬁle has been reshufﬂed and re-hashed in a previous

session by the HC, which has used in anticipation the

same OTP number that the user has now used to hash

the password (we will discuss in §6 how to handle

when a user “burns” a generated number by pressing

the OTP accidentally outside the login). The found

index j is submitted together with the username and

the row of the password ﬁle that LS has just used in

the search (step 4).

The HC checks ﬁrst j against c

(i.e., the index

of the user’s password) to determine whether to grant

access or not (step 5), then shufﬂes and re-hashes the

password ﬁle’s row. It also updates the c

considering

the index’s re-ordering (steps 6). The shufﬂed and

re-hashed ﬁle is returned to the LS (step 7) and LS

notiﬁes the user (step 8).

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System

Informal Security Analysis. We argue that there is

no corruption of the LS that under our assumptions

can lead to a successful attack. In particular, even if

the LS learns that a particular h

(w) is a valid pas-

sword, LS cannot make any use of it to anticipate

the index that w will have in the new reshufﬂed and

re-hashed password ﬁle. LS could retain an old ﬁle,

but the index retrieved from it is not the new c

that

the HC now holds. It could send to the HC the user-

name and sweetwords ﬁle’s row of another user and

so have this later reshufﬂed and re-hashed. The only

gain is that LS will likely have the request rejected

without never get to know whether that hashed hone-

yword (and consequently the j calculated) were good

for access. Note that even if two users use the same

password, it is very unlikely that the hashes are the

same if we assume that each user has its own OTP.

LS can send the username u and password ﬁle’s row

of another user to know the answer about the correct-

ness of j without having the ﬁle’s row of u reshufﬂed

and re-hashed. But then, HC changes c

and so the

LS will not be able to take advantage of what he has

learned; besides, the effect seems to be disastrous in

terms of compromising the integrity of a future check,

when u logs in again. This counts as a Denial-of-

Service (DoS) but not as an attack according to De-

ﬁnition 1 since it does not increase the probability of

the adversary to gain access, which remains 1/k.

Finally, our protocol is secure even under a re-

laxed Assumption 2. Even if the LS, learned that a

particular h

(w) is a valid password, sends it back to

the adversary which in turn retrieves the w, the adver-

sary cannot use either w or the token h

(w) to gain

access. He needs the token h

n+1

(w) which he cannot

generate without holding also the OTP.

Before concluding, we comment on what to do if

the user accidentally burns some of the valid OTPs. A

classic solution is that the HC anticipates new versi-

ons of the password ﬁle using a certain number, say

m, of the next OTPs. The ﬁle’s row for user u beco-

mes a matrix where each row is ordered with the same







u,π

(1)

), ·· · , h

u,π

(k)

)

n+m

u,π

(1)

), · ·· , h

n+m

u,π

(k)

)







The HC stores one c

as before, but when shufﬂing

and re-hashing the matrix for the new run, it discards

all the rows that correspond to the OTP numbers that

the user has accidentally burned, including the one

used in the current submission (which HC receives

from LS).

7 FORMAL ANALYSIS

We modeled the original protocol and our proposal

(Fig. 3) in the applied-π calculus and used ProVe-

rif (Blanchet, 2001) to formally verify their secu-

rity. ProVerif is an automatic veriﬁer for crypto-

graphic protocols under the Dolev-Yao model. The

code for and results of the analysis are available at

https://github.com/codeCorruption/HoneywordsM.

Analysis of the Original System. We start by ana-

lyzing the original Honeywords System. We know al-

ready that there is an attack, but our aim is to test the

proper way to model a LS that has been code corrup-

ted according to Assumption 2. Moreover, we need to

correctly interpret the results, discarding attacks ori-

ginated from stronger attackers than the one deﬁned

in our threat model.

Our design is based in the following decisions.

There are three parties: the User (U), the LS and the

HC. The LS is an active attacker since it is able to

read and send messages from and to the HC; the chan-

nel between LS and HC is thus public. In contrast,

the channel between U and LS is private, otherwise

the attacker can learn a correct pair of user and pas-

sword from the beginning, contradicting Assumption

1. Note that this decision together with the fact that

the password is never transmitted in the public chan-

nel, prevents the attacker to know the submitted pass-

word at any time. It also rules out the simplest gues-

sing (password) attack, which is the ﬁrst one that Pro-

Verif ﬁnds in the analysis, allowing the veriﬁer to ﬁnd

attacks more related to the protocol’s ﬂow. We know

already that a guessing attack is always possible, since

Honeywords System is not designed to avoid it.

The attack described in §4 violates the security

property:

correctIndex(u, j) =⇒ injct(indexFound(u, p, j))

&& injct(usrLogged(u, p))

It expresses that, whenever the HC sends a posi-

tive answer to the LS for a submitted pair of user and

index (u, j), all of these three actions occurred: (1) a

user logged in with a pair of credentials (u, p) (2) the

index j found by the LS corresponds to (u, p) and (3)

the value stored in HC for u is equal to j. Injectivity

in the expression (injct) captures the fact of HC pro-

cessing only once each request that LS submits after

events (1) and (2), to prevent interaction between LS

and HC in the absence of a user.

Result. As expected, the veriﬁcation indicates that

the property does not hold. The attack found shows

how once the attacker (in this case the LS) gets a posi-

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

u,w,OTP(·)

π(i)

)]

,OTP(·)

1 : r

← OTP(n)

2: u,h

(w)

3 : j ← IndexOf



(w),[h

u,π(i)

)]





u,[h

u,π(i)

)]

, j



5 : resp ← ( j = c

)

6 :

← OTP(n)

n+1

← OTP(n + 1)

← r

n+1

u,π

(i)

)]

← Shuffle&Encrypt([h

u,π(i)

)]

)

← π

)

If ( j = c

)

7: resp,[h

n+1

u,π

(i)

)]

If ( j 6= ⊥)If ( j 6= ⊥)

8: resp

Figure 3: The new protocol.

tive answer from the HC, it is able to send a new check

request to HC with the correct user and index, gaining

access to the system and thus contradicting injectivity,

because there was not a new usrLogged(u, p) event

for that second request. These observations support

our model design for code-corruption and provide for-

mal evidence that a Honeywords System resilient to

the ﬂaw must satisfy Requirement 1.

Analysis of our Solution. We are now ready to ap-

ply the analysis to the new protocol. In this ProVerif

model, all channels are public since the LS can send

requests at any time and can learn the inputs from U

and HC. We choose this design to discover any at-

tack using any information available. Conversely, the

LS’s function that retrieves the index of a sweetword

is private, because LS can get information from the

password’s ﬁle but cannot modify it.

Unlike in the original, in this protocol each in-

stance of U is synchronized with a HC instance by

a seed, representing that both parts generate the same

OTP at the beginning of a round; the HC knows as

well the index of the password. Then, to give LS the

opportunity to attempt an attack using the knowledge

gained during the run of the protocol, we model the

fact that HC keeps running with the updated index

after reshufﬂing. The LS is almost as in the origi-

nal protocol, except that this time it receives a hashed

password parametrized by the OTP, instead of a plain

password. An index is a term determined by the has-

hed word searched and the row of sweetwords where

it is searched. Our expanded representation in ProVe-

rif is

indexOfHw(hashWord(w, getOTP(n)),

shufﬂeNhash(u,n))

where hashWord is the hash of the plain submitted

word w calculated with the seed n; shufﬂeNhash is

the sweetwords’ row for user u hashed with seed n.

Our equational theory relies on the checkEqual

function in the HC, which returns true only when all

the parameters in the indexes under comparison are

equal. After a successful match, the index hold by

the HC is affected by the next seed value, becoming

indexOfHw(...getOTP(next(n)),...(u,next(n))).

Therefore, after this point the evaluation of

checkEqual will be false for any submitted in-

dex not obtained with the new seed.

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System

The property that we want to prove is the same as

for the original Honeywords System:

correctIndex(u, j) =⇒ injct(usrLogged(u, p)) &&

injct(indexFound( j,

hashWord(p,x),

shufﬂeNhash(u,y)))

It states that every time an index j is equal to the one

in the HC’s database for u, then (a) the owner u of j

logged in with password p and (b) j corresponds to

the index of the hashed value of p in the sweetwords

row for u. The conjunction ensures the execution of

every step in the protocol; the injectivity ensures that

each is executed only once.

In addition, we introduce the property

event(unreachable) to verify that LS cannot re-

trieve a sweetword’s index of a word not submitted

by a user; the event unreachable is triggered if the

HC’s check function returns true after shufﬂing and

rehashing, when applied to a previously submitted

hashed password.

The model also assumes, as we stated in §5, that

HC must process LS’s requests atomically, ﬁnishing a

request before starting the next. Failing to implement

HC this way, leads to an attack as we are going to

explain in the next section, which prove that atomicity

is in fact necessary.

Result. All properties were veriﬁed to be true al-

most immediately. It follows that even knowing that a

certain hashWord(p,getOTP(n)) is a valid password,

LS cannot use it to anticipate the new good index,

since it depends on the seed value possessed only by

U and HC.

The analysis also proves that event unreachable is

actually unreachable and this implies that LS cannot

get any advantage even if using HC as an oracle if

using messages obtained from previous runs with U

and HC.

We also veriﬁed that it is necessary for the HC

to process parallel requests coming from the same

user u without breaking the indivisibility of the up-

date of passwd

. Removing this constrain reveals an

attack. The attack is as follows: let HC

and HC

be parallel runs of the HC, then (1) After a LS re-

quest, HC

veriﬁes that the submitted index is correct

and sends the answer to LS (2) LS submits again the

correct index, HC

processes it, ﬁnishes the protocol

and grants access (3) HC

continues its execution and

grants access as well.

8 COMPLEXITY AND

PERFORMANCE

The contribution of this research is mainly theoreti-

cal but we judged useful to test the performance of

what we propose. We sketch a complexity analysis

and we benchmark an implementation of our protocol

both, with respect to the original system and by using

different parameter for the elliptic curve (EC) multi-

plication which we used to execute the main operation

of our protocol: exponentiation.

Complexity Analysis. The analysis assumes that an

elliptic curve multiplication takes constant time t

CURVE

(which depends on the employed CURVE): this pro-

tects implementations against remote timing attacks

(Brumley and Tuveri, 2011).

Let us now consider the operations that affect the

performance. Once received the password, LS calls

IndexOf to search the index of the submitted pass-

word among the sweetwords. Given that the sweet-

words are not ordered and also are constantly reshuf-

ﬂed, this is a linear search. In the worst case it can be

done in O(k) time, where k is the number of sweet-

words per user. In case of a match, the HC checks the

validity of the index in O(1) time. Next, the HC calls

Shuffle&Hash; this function shufﬂes the sweetwords

in O (k) time and performs k times an EC multiplica-

tion in k · t

CURVE

time. The last equation is linear in k

for a ﬁxed CURVE. Since each of the previous opera-

tions takes at most O (k) time, the time complexity of

the new protocol is O(k). As well, for a ﬁxed k, the

execution time increases linearly as t

CURVE

grows. Mo-

reover, EC multiplication is CPU intensive and domi-

nates the total execution time. This is also conﬁrmed

by our empirical results (see Fig. 4(a)).

Communication Cost. In the original Honeywords

system, the communication cost per login comes from

messages (u, j) and resp. We denote the number of

bytes required to encode (u, j) and resp by |(u, j)| and

|resp| accordingly, and obtain the data transfer rate per

C = |(u, j)| + |resp|

While the data ﬂow remains the same, our protocol

brings the following communication overhead to the

original Honeywords system: LS sends the sweet-

word hashes [h

n+1

u,π

(i)

)]

i=1

and receives the up-

dated ones. The number of bytes required to encode a

password hash depends on the employed curve and is

denoted by H

CURVE

. Thus, LS sends |(u, j)| + kH

CURVE

bytes and receives |resp|+ kH

CURVE

bytes per login. As

a result, the total data transfer rate per login between

LS and HC is computed as C + 2kH

CURVE

bytes.

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

Since k, the number of sweetwords, is a constant

deﬁned by the system, and H

CURVE

is constant too, the

overload in communication is bounded. We have not

simulated nor evaluated how much this may affect a

server’s ability to process a great number of log-in at-

tempts per unit of time, but we are inclined to believe

that this loss in performance is not so dramatic. Of

course one may will to discuss whether the solution

that emerges from our analysis by ﬁtting our require-

ments is not actually an overkill in itself. This is a

legitimate question which we discuss in § 9.

Implementation. We implemented our solution in

C# atop the Microsoft .NET framework.

Elliptic

curve operations are performed using Bouncy Castle

Cryptographic Library, although a faster version may

be obtained by native language implementations or li-

braries.

In our implementation, u, j and resp are imple-

mented as integers, hence C equals 12 bytes and

CURVE

takes 57, 65, 97, and 133 bytes for P-224,

P-256, P-384 and P-521 accordingly. Fig. 4(c) com-

pares data transfer rates with different settings.

Performance Analysis. We measured the efﬁ-

ciency of our proposed protocol with two questions in

mind: How does number of veriﬁcations per second

correlates with the number of honeywords? What is

the impact of the selected curve on veriﬁcation speed?

The results presented have been performed on note-

books with Intel Core i7 CPU and 8GB of RAM over

an idle network. We measured the total execution

time on server side computations and communication

over the network separately. Roughly speaking, our

prototype reaches a decision for each login request

below 9 ms. Table 1 summarizes the overall perfor-

mance with different settings.

Another performance consideration is the cost of

avoiding login failures due to out-of-synchronization

of OTPs. System policies may follow the strategy dis-

cussed in Section 6. The computational overhead of

both, Login Server and Honeychecker, increases line-

arly on the number of copies in the password ﬁle.

It is reasonable to expect that the time required for

re-encryption directly depend on the number of hone-

ywords for a user. Fig. 4 illustrates the time measure-

ments. It can be seen that the time required for veri-

fying a single user increases linearly with the number

of honeywords per user. The Honeychecker performs

one EC multiplication for each honeyword, which is

the most expensive part of its function, and the result

Source code is available under GPLv3 at https:// git-

hub.com/codeCorruption/HoneywordsM.

Table 1: Performance results of our implementation. Lo-

gin Server and Honeychecker columns display the time in

milliseconds for a single authentication on LS and HC, re-

spectively. Throughput column shows the maximum num-

ber of veriﬁcations per second. Round-Trip Time (RTT) is

the network delay during the experiments.

k Curve

(ms)

Honeychecker

(ms)

Throughput

(login/s)

RTT

(ms)

5 P-224 0.011 1.709 581 24.446

5 P-256 0.009 1.796 554 28.917

5 P-384 0.009 2.242 444 31.502

5 P-521 0.010 2.541 392 30.812

10 P-224 0.009 2.680 372 24.534

10 P-256 0.009 3.317 301 29.885

10 P-384 0.010 4.365 229 34.918

10 P-521 0.010 4.793 208 29.414

15 P-224 0.009 3.856 259 27.063

15 P-256 0.010 4.868 205 30.896

15 P-384 0.009 6.240 160 36.253

15 P-521 0.010 6.842 146 31.445

20 P-224 0.009 5.016 199 26.867

20 P-256 0.010 6.301 158 29.355

20 P-384 0.010 8.220 122 32.724

20 P-521 0.011 8.965 111 31.944

is aligned with our theoretical expectations. Our so-

lution preserves the computational characteristics of

the original honeywords protocol: performance is li-

nearly dependent on the number of honeywords. On

the other hand, we can see from Fig. 4 (and from Ta-

ble 1) that the time to run the employed curves incre-

ases with the number of honeywords.

Figure 4(b) compares our protocol with the re-

ference implementation. The client side latency of

both, original and improved protocols stays almost

constant. Considering the delays caused by the net-

work, the computational overhead of our protocol is

relatively small. It might not be even noticed by the

clients.

9 DISCUSSION

This paper takes inspiration from a challenge left open

in (Juels and Rivest, 2013). There, Juels and Ri-

vest propose a password-based authentication system,

called Honeywords System, meant to detect when a

password ﬁle has been stolen. User passwords are

hidden among a list of honeywords and an attacker

that knows all of them cannot do better than guessing

which one is the rightful password. This reduces its

probability of success while revealing the leak when

the attacker types one of the supposed secret honey-

words instead. The open problem is how to make this

concept work even when a key component of the Ho-

neywords System, the Login Server (LS), has its code

corrupted by an adversary.

We deﬁned rigorously the notion of code-

corruption, which is too powerful if taken literally.

Constrained to become tractable, the adversary mo-

del results to be a less powerful version than a Dolev-

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System

Number of honeywords

Time (ms)

Server Side Execution Time

P-224

P-256

P-384

P-521

(a)

Number of honeywords

Time (ms)

Client Side Latency

Original

Improved

(b)

Number of honeywords

Amount of Data (kbyte)

Data Transferred

P-224

P-256

P-384

P-521

(c)

Figure 4: (a) CPU time required to verify a user depending on the number of honeywords and employed curve. (b) Client

side latency comparison between original protocol and our proposal with NIST Curve P-256. (c) The amount of the data (in

kilobytes) transferred between the Login Server and the Honeychecker.

Yao, but such that gives the attacker a better proba-

bility of success than guessing the password from the

set of honeywords. The root cause of such attacks

lays in the LS knowing eventually a user’s valid (has-

hed) password. The solution that we propose avoids

that, but at a price that seems unavoidable. It pre-

vents the LS to make, off-session, any good use of

what he knows, but the new protocol, according to

the requirements that we elicited from studying at-

tacks on the original Honeywords System, consists

in shufﬂing and rehashing the password (plus hone-

ywords) after any user’s attempt to log in. The new

solution also avoids that the LS can receive a token

with which it can search in the password ﬁle at any

moment distinct from when a legitimate user is log-

ging in, but this last requirement implies that the user

and the Honeychecker (HC) somehow get synchroni-

zed by using a second channel that is not controlled

by the LS or by a man-in-the-middle. We propose

One-Time-Passwords (OTPs) for this purpose. The

solution is secure as we proved formally in ProVerif.

Although our result has meaning mainly for its

theoretical insights, it performs reasonably well as we

show in a benchmark analysis we did on a prototype

that we have implemented in C#.

Our protocol works in the original Juels and Ri-

vest’s intention to let an attacker steal a password ﬁle,

run an off-line dictionary attack on it, and have some

chance to get into the system by guessing the rightful

password. However, our solution seems making this

attack useless. The intruder does not gain anything

from knowing a user’s password because however he

does not possess the OTP with which to create the

authentication token (i.e., the hash of the password).

This is the credential that let the system grant access.

At the light of this last observation we further com-

ment that even if the adversary communicates with

the LS and gets to know the user password, (as we

explained in §3), the adversary cannot manage to log

in. Our ﬁx, at least for the new Honeywords System,

nulliﬁes the adversary’s possibility to exploit the pas-

sword usefully to log in, although of course leaking

a password is still a serious weakness because users

may reuse the same password across different sites.

Still the strategy that we proposed for our new pro-

tocol suggests a completely new direction for pass-

word authentication, a procedure that is resilient even

if a password is lost. Thus, at this point, one may

want to go one step ahead and rethink a new system

afresh where an intruder could not take any advan-

tage after knowing the right password. This is an

interesting question that goes beyond what we think

was the proposal of Juels and Rivest, since it would

render a Honeywords System approach completely

superﬂuous. Instead, it suggests a wholly reviewed

password-based authentication process where users

still type their passwords but where the token that the

LS checks in the password ﬁle is one-time-valid. If a

solution exists, still it differs from current OTP-based

solutions that are used today e.g., in home-banking,

because of the assumption that it must work even

when the LS has been code-corrupted. This is for

us an interesting future work and an open problem in

password-base authentication.

ACKNOWLEDGEMENTS

This research has been supported by pEp Security

S.A./SnT PPP, within the project “Security Protocols

for Private Communications”.

REFERENCES

Beck, K. (2016). Hackers are selling account credentials

for 400 million Tumblr and MySpace users. Ma-

ICISSP 2018 - 4th International Conference on Information Systems Security and Privacy

chable. http://mashable.com/2016/05/31/myspace-

tumblr-hack (last access: 4th September 2017).

Blanchet, B. (2001). An efﬁcient cryptographic protocol

veriﬁer based on prolog rules. In 14th IEEE Computer

Security Foundations Workshop, pages 82–96. IEEE.

Botha, R. A. and Eloff, J. H. P. (2001). Separation of duties

for access control enforcement in workﬂow environ-

ments. IBM Systems Journal, 40(3):666–682.

Brumley, B. B. and Tuveri, N. (2011). Remote timing

attacks are still practical. In European Symposium

on Research in Computer Security, pages 355–371.

Springer.

Erguler, I. (2016). Achieving ﬂatness: Selecting the honey-

words from existing user passwords. IEEE Transact.

on Dependable and Secure Computing, 13(2):284–

295.

Furnell, S. M., Dowland, P., Illingworth, H., and Rey-

nolds, P. L. (2000). Authentication and supervision:

A survey of user attitudes. Computers & Security,

19(6):529–539.

Goel, V. and Perlroth, N. (2016). Yahoo Says 1 Billion

User Accounts Were Hacked. NT Times Online.

https://www.nytimes.com/2016/12/14/technology/

yahoo-hack.html (last access: 4th September 2017).

Juels, A. and Rivest, R. L. (2013). Honeywords: Making

password-cracking detectable. In Proceedings of the

2013 ACM SIGSAC conference on Computer & com-

munications security, pages 145–160. ACM.

Newman, L. H. (2017). Yahoo’s 2013 email hack ac-

tually compromised three billion accounts. Wi-

red. https://www.wired.com/story/yahoo-breach-

three-billion-accounts/.

NIST (2015). SHA-3 Standard: Permutation-Based Hash

and Extendable-Output Functions.

A Security Analysis, and a Fix, of a Code-Corrupted Honeywords System
