Data-driven Relevancy Estimation for Event Logs Exploration

and Preprocessing

Pierre Dagnely, Elena Tsiporkova and Tom Tourw

Sirris - Elucidata Lab, Belgium

Keywords:

Event Relevancy Estimation, Data Reduction, Industrial Event Logs, Data Preprocessing.

Abstract:

With the realization of the industrial IoT, more and more industrial assets are continuously monitored by log-

gers that report events (states, warnings and failures) occurring in or around these devices. Unfortunately, the

amount of events in these event logs prevent an efﬁcient exploration, visualization and advanced exploitation

of this data. Therefore, a method that could estimate the relevancy of an event is crucial. In this paper, we

propose 10 methods, inspired from various research ﬁelds, to estimate event relevancy. These methods have

been benchmarked on two industrial datasets composed of event logs from two photovoltaic plants. We have

demonstrated that a combination of methods can detect irrelevant events (which can correspond to up to 90%

of the data). Hence, this is a promising preprocessing step that can help domain experts to explore the logs in

a more efﬁcient way and can optimize the performance of analytical methods by reducing the training dataset

size without losing information.

1 INTRODUCTION

With the realisation of the industrial IoT, more and

more industrial assets are continuously monitored.

These assets are not only instrumented with sensors,

but are also monitored by loggers that report events

occurring within or around the device. This includes

events related to the state of the asset (e.g. whether

it is started, or stopped), warnings and failures. The

event logs represent a valuable source of information

for a company, as they can be explored to learn about

the (normal and abnormal) behaviour of assets in the

ﬁeld, e.g. to discover the root cause for a failure.

Event logs are currently underexploited by most

companies, as they come with several challenges.

(Bose et al., 2013) identiﬁed ﬁve categories of chal-

lenges. For instance, 1) The voluminous amount of

data, 2) The heterogeneity of the data, i.e. the pres-

ence of events from distinct process in the logs or gen-

erated by different and incompatible ﬁrmwares from

different manufacturers, 3) The ﬁne granularity of the

data, i.e. events that are too precise and lack gen-

eralization, 4) Evolutionary changes, i.e. deﬁnitive or

momentary changes in the process that affect the data,

and 5) Quality issues with data that can be missing,

incorrect, imprecise or irrelevant, i.e. related to other

process than the one analyzed. In this paper we focus

on the ”voluminous”, ﬁne granularity and irrelevance

challenges.

The voluminous, and subsequently ﬁne grained

character of event log data prevents its efﬁcient explo-

ration, visualisation and advanced exploitation. For

example, our industrial partner, 3E, monitors, through

its Software-as-a-Service platform SynaptiQ, around

4.000 photovoltaic (PV) plants throughout the world

and receives 1.000.000 events per day on average.

Manually analysing this huge amount of data is no

longer possible and methods that can pinpoint events

or periods of interest are required to support domain

experts. For instance, domain expert would like to

(visually) explore a device’s historical data when a

relevant failure occurs, in order to understand its be-

haviour and identify the failure’s root cause. In this

case, he is interested in a (very limited) subset of the

events only and the vast majority of the events can be

considered as noise that should/could be removed.

Similarly, advanced analytical methods could pre-

dict failures and support a maintenance engineer in

pro-actively planning maintenance. However, train-

ing and validation for such methods can have very

high computation time, as they are directly correlated

to the size of the dataset. In addition, their perfor-

mance suffers signiﬁcantly because of the fact that the

vast majority of the events can actually be considered

as noise. As an example, we have applied sequential

pattern mining (SPM) to event logs in order to iden-

Dagnely, P., Tsiporkova, E. and Tourwé, T.

Data-driven Relevancy Estimation for Event Logs Exploration and Preprocessing.

DOI: 10.5220/0006579503950404

In Proceedings of the 10th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2018) - Volume 2, pages 395-404

ISBN: 978-989-758-275-2

395

tify anomalous behaviour in PV plants and found that

the algorithmic performance was rather poor, both in

terms of running time and in terms of results. A de-

tailed analysis revealed that this was due exactly to the

huge amount of events and hence presence of noise in

the log data.

In this paper, we propose 10 methods that auto-

matically estimate event relevancy and evaluate their

ability to discriminate relevant from irrelevant events.

The deﬁnition of ”relevant” depends of the objective

to achieve and may vary. For example, when ex-

ploring normal behaviour, only the events describ-

ing or representing the regular/normal behavior of a

PV plant (called regular events) are of interest and

the events describing or representing the failures or

underperformances of a PV plant (called irregular

events) should be discarded. On the other hand, when

investigating failures, irregular events are the most in-

teresting to explore and regular events can be consid-

ered noise. For the rest of the paper, we will address

the challenge of labelling the regular events as irrel-

evant (as this is the most common case) since both

cases can be addressed with the same methods and

only differ in how the results are interpreted.

By applying such methods, we can signiﬁcantly

reduce the dataset size without losing information.

For example, we have reduced the computation time

of a SPM algorithm by 83%. The computation time

on the initial dataset was 16 hours and 14 minutes

while it was 2 hours and 40 minutes on the dataset

with only the relevant events. However, the same use-

ful patterns were found.

The 10 methods, inspired by similar techniques

proposed in other domains, are applied to event logs

from 2 PV plants for which one year of historical

data is available (provided by our industrial partner).

They are evaluated using a thorough benchmarking

framework, including an evaluation by domain ex-

perts. Some of our methods are data-driven, i.e. they

are domain-independent and can be applied to any

event log, while others rely on domain knowledge re-

lated to PV event behaviour, and hence would require

tailoring to be applicable in other domains.

The remainder of the paper is structured as fol-

lows. We ﬁrst cover the state of the art of the ﬁelds

from which we draw inspiration for the methods. Sec-

ond, we describe the 10 methods that have been devel-

oped. Then, in Section 4, we explain and motivate the

experimental setup used for the benchmarking. Sec-

tion 5 discusses the results of this benchmarking. Fi-

nally, Section 6 concludes the paper.

2 RELEVANT LITERATURE

The challenges related to the voluminous charac-

ter of event log data have received minimal atten-

tion in literature. The current strategies usually let

the process mining methods deal with it, such as

(Bonchi et al., 2003) who deﬁned Ex-ante, a con-

strained pattern mining method adapted to large data

by adding a pruning of the search space during the tra-

ditional pruning of the frequent itemsets of the APri-

ori method. Nonetheless, we can draw inspiration

from ﬁve domains that have encountered similar chal-

lenges and deﬁned techniques for dealing with them:

1) The process mining domain, 2) The outlier detec-

tion domain, 3) The web log cleaning domain, 4) The

state index pruning domain from the information re-

trieval ﬁeld and 5) The diversity measures in the bio-

logical domain.

For the process mining ﬁeld, we can mention the

research of (Fu et al., 2012), where they applied two

ﬁltering steps on their events logs: 1) Removed the

frequent events, i.e. if the period between two simi-

lar events is below a user deﬁned threshold, they re-

moved the second event, 2) Removed periodic events,

e.g. events produced by a daemon regularly. For each

type of event, they assessed different time intervals

and computed, for each, the number of occurrences of

that event with this time interval between each con-

secutive occurrence. If that number (expressed as a

percentage on the total number of occurrences of that

event) is above a user-deﬁned threshold, they consid-

ered that they had a cycle and only kept the ﬁrst oc-

currence. One drawback of this method is its inability

to ﬁnd cycle with various interval gaps. (Hassan et al.,

2008) used a compression algorithm to detect relevant

periods. They divided the logs in small sequences and

compressed each of them and subsequently, computed

their compression rate CR.

CR = 1 −

size after compression

size before compression

Sequences with low CR should contains sequences

with distinct events making it hard to compress.

Therefore, they only kept these sequences that should

be the most relevant ones.

Outlier detection focusses on the detection of non-

frequent events or patterns. Therefore, some outliers

detection methods can be adapted to this purpose, i.e.

to build datasets of outliers. (Gupta et al., 2014) used

decision tree and clustering methods to learn a model

of the data and removed the events which differ from

it. Similarly, (Conforti et al., 2016) used an automa-

ton to model the system. Every event not ﬁlling the

usual automaton process was considered as outliers

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

396

and discarded. However, these methods require train-

ing a model on a voluminous dataset which is com-

putationally expensive and may not lead to optimal

results due to the amount of noises in the data.

Data pruning is a long-standing topic of the web

log cleaning/pre-processing since the seminal paper

of (Cooley et al., 1999), where they removed jpeg

and other multimedia ﬁles from the event logs. Nev-

ertheless, there has been little progress in this area,

as stated in the review of (Jayaprakash and Balamu-

rugan, 2015). The main cleaning procedures con-

cern the removal of queries other than GET, multi-

media resources, logs created by robots, errors and

some HTTP status codes known as irrelevant. In addi-

tion, methods focusing on user/session identiﬁcation,

path completion, i.e. correction of incomplete URL

or transaction interaction identiﬁcation, i.e. cluster of

meaningful transaction of a user extracted from the

event logs, are now part of the everyday web log pre-

processing. (Srivastava et al., 2015) decreased the

size of the log data by 80% by applying such tech-

niques. However, most of these methods are web cen-

tric and can not be applied to other domains.

Static index pruning is a ﬁeld of the information

retrieval domain. The goal is to reduce the size of

the index of one or several texts by removing the en-

tries that will probably not be needed by the users,

e.g. the index entries of the word ”the” or ”me”, to

reduce the memory size of the index. This ﬁeld ex-

ists since the seminal papers of (Carmel et al., 2001).

Even though some methods are domain speciﬁc, oth-

ers can be adapted to industrial event logs. (Biller-

beck and Zobel, 2004) used TF-IDF to compute the

frequency score of the words by combining the over-

all frequency of the word in all texts and the num-

ber of text in which this word occurs. Given a cor-

pus of texts, e.g. a set of technical documents, this

method will provide a ranking of the word for each

document, e.g. for document A, the word ”inverter”

will have a high score as this word is frequent in

this document but not in the others, which means that

this word is probably discriminative of the document

topic. TF-IDF combines two metrics: 1) The term fre-

quency (TF) that measures the frequency of the term,

i.e. word, in the document. 2) The inverse document

frequency (IDF) that measure the (inverse of the) fre-

quency of the term in the corpus (see formulas below).

T F

# occ. of word w

in document d

# of word in document d

IDF

= log

# of documents in the corpus

# of documents containing the word w

T F − IDF

= T F

∗ IDF

The intuition behind that is to attribute a low score

to terms that occur in most or all of the documents as

they are probably less relevant (words such as ”the”

or ”of”). Billerbeck et al. used TF-IDF to remove

from the index the words with low scores, i.e. fre-

quent words.

(De Moura et al., 2005) adapted this method by

considering the context. They analyzed the non-

frequent sentences, i.e. the sentences containing

non-frequent words and kept the occurrences of the

frequents words occurring in these sentences. All

the other occurrences were removed from the in-

dex. (Jangid et al., 2014) reviewed these methods

and compared TF-IDF to BM25 (Jangid et al., 2014),

BB2 (Jangid et al., 2014) and other methods. TF-IDF

still had (one of) the best accuracy although its com-

putation time was usually superior.

A new promising approach deﬁned by (Chen

et al., 2015) uses the Rnyi divergence (a divergence

measure from the information theory domain). They

redeﬁned the problem as a model induction problem

and looked for the pruned index that minimize its

(Rnyi) divergence with the full index (in terms of re-

trieval performance). However, this method lacks a

proper comparison with other methods.

Diversity measure is a long-standing problem in

the biological and genomic domain. This domain tries

to assess the diversity in, e.g. a DNA sequence or

an environment like a lake. For example, (Fuhrman

et al., 2000) used it to detect DNA subsequences with

high diversity that are worth exploring (the other sub-

sequences are discarded). Popular methods are shan-

non index (also called Shannon-Wiener or Shannon-

Weaver indexs), Simpson index or Berger-Parker in-

dex. Although Shannon index has been criticized for

the difﬁculty to understand and interpret its meaning

(Hill et al., 2003), it’s one of the most used method.

The index is based on the Shannon entropy used

in the information theory and simply computes the

entropy of a sequence. Sequences with the highest

entropy are sequences with the highest diversity (as

the entropy measure the difﬁculty to predict the iden-

tity of the next individual in the sample, a high en-

tropy means that there is a high diversity of potential

individuals that could occur next, i.e. that there is a

high diversity of individuals in the sequence). The

Shannon index is computed using the formula below

where p

is the proportion of individuals belonging to

the ith species, gene, ... in the sequence.

Shannon score (H) = −

∑

log

Data-driven Relevancy Estimation for Event Logs Exploration and Preprocessing

397

3 METHODS DEFINITION

In this section, we present the deﬁnition of 10 meth-

ods for estimating event relevancy based on our liter-

ature study and the characteristics of our data. These

methods have been selected for their effectiveness in

their respective ﬁelds. However, their applicability to

the industrial event log ﬁeld still needs to be assessed.

In addition, these methods, often, can not be directly

applied to industrial event logs and need to be adapted

and tailored.

These methods are either based purely on data

characteristics, hence they are generally applicable,

or they are based on speciﬁc domain knowledge, and

thus require adaptation before they can be applied to

other domains.

In addition, the methods differ in the way events

are ranked. Score-based methods assign a relevancy

score to each event type while boolean-based meth-

ods only classify the events as relevant or not. This

distinction is crucial as boolean-based methods are

simpler to interpret and apply. Score-based methods

offer a ﬁner-grained ranking of the events and pro-

vide more information to the domain experts at the

cost of a higher complexity, as they imply to deﬁne a

threshold that will discriminate between relevant and

irrelevant events, based on domain knowledge.

Finally, some methods encounter the cold start

problem, as they require the suitability of historical

data that could span years in order to train a model

that can discriminate between the events. Such data

is not always available on fresh installations with new

devices and/or conditions which prevents the use of

such methods in these situations. A summary of the

methods characteristics can be found in table 1.

As some methods are based on PV plants char-

acteristics, we ﬁrst explain the PV plant infrastruc-

ture. PV plants are composed of several PV modules

(that convert the irradiation into direct current) con-

nected to one or several inverter(s) (that convert the

direct current to alternative current) which send the

current to the grid. These systems are now continu-

ously monitored (in addition with various on and off-

site sensors). Therefore, a PV plant reports statuses,

i.e. its current state like start, stop or running, but also

events, i.e. speciﬁc events that can represent an out-

age (such as grid fail or string disconnected) or other

phenomena (such as over-temperature or DC current

under threshold). In this context, an outage, i.e. a fail-

ure, is considered as the period where there is enough

irradiation reaching the modules to have electricity

production but there is no yield. Unfortunately, events

can not be trusted to detect all the outages due to some

noises in the logs. Therefore, outages are detected by

combining the data of the irradiation and yield sen-

sors. Periods with irradiation values above 30kwh/m

but yield value null are labelled as outages.

The event logs consist of textual messages con-

taining the ID of the events detected, e.g. 1013 for the

event grid fail, associated with a timestamp. Usually,

an inverter reports 14 events per days (mainly dur-

ing the mornings and evenings when the inverter start

or stop) and a plant contains in average 18 inverters,

but it can go up to 600. The number of events (as

well as the type of events monitored and their ID) re-

ported by an inverter depends of the manufacturers of

the logger-inverter pair, e.g. the inverters of Fronius

combined with the logger system of Solarlog report

in average 19 events per days. The number of events

also increase when outages and events occurs in the

plant. In some case, an inverter can report thousands

of events per days with a granularity of a few seconds.

3.1 Status Method

Some events are status events, i.e. an indication of

the current state of the system such as ”start” or ”run-

ning”. As we focus on labelling regular events as ir-

relevant, and these status events describe regular be-

haviour, they can be discarded. However, the status

of the system can also be a valuable information to

understand some failures.

3.2 Simultaneous Status Method

In some circumstances, e.g. during start and stop se-

quences, the inverter status can change rapidly, i.e.

in a few seconds. This method labels the status that

lasted less than 60 seconds as irrelevant, as the phe-

nomenon that generated it did not have time to impact

the system.

3.3 Consecutive Event Method

Some events are continuously reported every few

minutes by the logger until the problem is ﬁxed. This

artiﬁcially increases the amount of events while only

the ﬁrst and the last occurrences of the events are ac-

tually relevant. All the other occurrences can be con-

sidered as irrelevant. Note that the id of the last oc-

currence should be changed to indicate that it corre-

sponds to the end of the event. In addition, if the dura-

tion or the length of repetition is random or irrelevant

in some industrial cases, it may represent a valuable

information in some other cases, preventing the use of

this method that would remove this information.

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

398

Table 1: Summary of methods’ characteristics.

Method Data-driven based Domain based Score based Boolean based Cold start issue

Status method X X

Simultaneous status method X X

Consecutive event method X X

Morning and evening method X X

TF-IDF method X X

Contextual TF-IDF method X X

Pattern method X X X

Compression method X X

Statistical method X X X

Shannon index method X X

3.4 Morning and Evening Method

In the PV domain, most of the events occur during the

start and stop sequences that occur in the morning and

evening. Those sequences contain therefore events

that can be considered as irrelevant as they indicate

the usual behavior of the system. We have deﬁned the

morning and evening as the operational periods with

an irradiation below 30 kwh/m2. Note that this means

that true failure events occurring during those periods

would be lost, except if they are reported again later.

3.5 TF-IDF Method

TF-IDF can be adapted to industrial event logs, by

considering the event log of one inverter for one day

as one document, called inverter-day document. A

corpus of documents is the inverter-day documents of

a day. In practice, for each day, the event logs of each

inverter are considered as a text and TF is computed

for each (see formula below). IDF is then computed

for the inverter-day documents of that day and TF-

IDF scores are computed by multiplying TF and IDF

scores of each inverter-day documents (the scores are

computed days by days). Hence, a relevancy (TF-

IDF) score is computed for each event type of each

inverter-day document, i.e. each type of event has a

speciﬁc score for each day of each inverter log.

T F

# occ. of event e

in inverter i

for day d

# of events in inverter i

for day d

IDF

= log

# of inverter-days for day d

# of inverter days containing e

for day d

T F − IDF

= T F

∗ IDF

A threshold can then be puts to discriminates ir-

relevant events, i.e. events with low scores as they are

the frequent and probably meaningless events (in the

same way as the words ”the” is irrelevant for text pro-

cessing) . Note that, as the scores are inverter-day spe-

ciﬁc, the list of events types labelled as irrelevant may

vary for one day to another as their score may also

vary. In this way, we have extended the traditional

TF-IDF to time dependent one or, in other words, we

have deﬁned a dynamic TF-IDF score.

3.6 Contextual TF-IDF Method

De Moura et al. (De Moura et al., 2005) extended

the TF-IDF method to take into account the context

of each word. They only removed irrelevant words if

there were no relevant word in their surroundings, i.e.

in the same sentence. We have adapted this method by

retaining irrelevant events that have a relevant event

in the period of 30 minutes before or after their oc-

currence. This time window of one hour have been

selected based on domain knowledge and is therefore

domain speciﬁc.

3.7 Pattern Method

Based on (Gupta et al., 2014) or (Conforti et al.,

2016), another method is to ﬁnd the usual behavior

of the system by e.g. deﬁning an automaton and re-

moving all events that correspond to it. Unfortunately,

methods such as automaton would have been com-

plex to use due to the high heterogeneity of the PV

events logs (as events are often reported at various

conceptual level by different manufacturers, for more

information, we refer to our papers (Dagnely et al.,

2015)). Therefore, we have decided to use Multi-level

sequential pattern mining (MLSPM) methods to ﬁnd

the patterns representing the usual behavior, i.e. the

patterns with high support thresholds in our dataset,

as MLSPM is well suited to address the granularity

issue of the PV events. The events that occur in these

patterns can be classiﬁed as irrelevant.

Data-driven Relevancy Estimation for Event Logs Exploration and Preprocessing

399

3.8 Compression Method

Based on Hassan et al. (Hassan et al., 2008), we have

deﬁned a method that uses a compression algorithm

to detect periods with relevant events. The event logs

of each day of each inverter are compressed. The

compression rate (CR) is then computed and used as

a metric. The intuition is that periods with failures

will have many redundant events and will therefore

be easier to compress. Therefore, the events occur-

ring in periods with low compression rate are labelled

as irrelevant. We have used the same compression

algorithm than Hassan et al. (zlib) and the same com-

pression rate formula.

3.9 Statistical Method

The probability that an event is linked to a failure can

be computed by analyzing which events occurs in nor-

mal and abnormal periods. From the event logs, we

have extracted the days preceding the outages and the

(same amount of) days that are ”the further away” of

any outages, i.e. with the more days between them

and the next or the previous outage. The ﬁrst ones

have been labeled as regular while the later ones have

been labelled as irregular. For each event present in

these datasets, its frequency in both datasets has been

computed and normalized (per dataset) using the min-

max normalization. The probability of an event to be

linked to an outage has then be computed using the

formula:

P(event e

) =

# occ. of event e

in the abnormal dataset

# occ. of event e

in both datasets

Domain experts have selected a threshold of 0.3 as

the more adapted to discriminate the events as relevant

or irrelevant, i.e. event with a probability lower than 0.3

are considered irrelevant. Another threshold could have

been 1, to only classify as relevant the events that never

occurred during the normal behavior. However, this may

be too strict and can remove harmless events that have an

impact on abnormal behavior in combination with ”fail-

ure” events. One drawback of this method is the need of

sufﬁcient historical data to compute a statistically signif-

icant probability. We have used 1 year of historical data

to compute the probabilities.

3.10 Shannon Index Method

The Shannon index has been adapted by using the for-

mula below applied to the log ﬁle of each day of each

inverter. If the Shannon index score of a day is below

a certain threshold, the day is considered as having a

low diversity and therefore is discarded as irrelevant. A

threshold of 2.5 has been selected by domain experts as

an appropriate threshold.

Shannon score (H) = −

∑

log

With p

# occurences of event e

during day d

# events during day d

3.11 Combination of Methods

Methods can also be combined. Two good candidates

are the status and TF-IDF methods. One of the draw-

back of TF-IDF is its computation time which is directly

correlated to the size of the dataset. Therefore, applying

ﬁrst the status method to quickly label some of the events

as irrelevant and therefore decreasing the size of the (rel-

evant) dataset on which applying TF-IDF may dramati-

cally decrease the computation time. The status events

will therefore be removed from the TF-IDF ranking but,

as the status method don’t interferes with the distribution

of the warning and failure events, their TF-IDF ranking

will not be impacted.

The three others domain-based methods only remove

some occurrences of the events and therefore may de-

crease the accuracy of the data-driven methods by creat-

ing biased datasets. For data-driven methods, the pattern

method needs the state events as they play an important

role in the regular patterns. The Shannon index method

has already a low computation time and do not need

preprocessing. Finally, the compression method could

beneﬁt from the status method to reduce its computation

time. Therefore, the two only valid combinations are the

TF-IDF and compression methods combined with the

status method.

4 EXPERIMENTAL SETUP

The event relevancy estimation methods have been eval-

uated in the PV domain. One of the challenges of events

logs in that domain is the lack of consistency (in addi-

tion to the voluminous challenge). Most of the events

represent the usual start and stop sequences of an in-

verter. However, the composition of these sequences

is not ﬁxed. Each manufacturer has deﬁned its speciﬁc

start and stop sequences but even within one manufac-

turer device, the sequences may vary with distinct events

and different time gaps, depending on the external con-

ditions (such as the weather). In addition, outages can

be preceded by none, a few or even more than thou-

sands of events, with continuous repetition of the related

event(s) and start and stop sequences, as the inverter tries

to restart. Nevertheless, the number of events is not an

indication of an outage, as many events can be reported

continuously for simple warnings.

To evaluate these methods, we have benchmarked

them on one year (2016) of data from two PV plants,

one with regular and one with irregular behaviour. The

regular plant is composed of 16 inverters and contains

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

400

84.961 events. This plant is known to have a regular be-

havior with only a few outages due to external factors

such as the weather. The irregular plant is composed

of 26 inverters and contains 133089 events. Over the

year, this plant has suffered of several outages due to var-

ious causes such as Riso low or Ramp fail. Both plants

use the same inverter type and are located in Belgium

(hence they share the same climate conditions). Those

two plants will allow to compare the methods accuracy

in two distinct situations: one with only a few outages

and almost only irrelevant (regular) events and one with

more outages and more relevant (irregular) events (up to

30% of the events). The methods need to be accurate

in both situations which may be especially complex for

methods with cold start issues, i.e. for methods that need

to learn from the data. As the regular plant only contains

a few outages and relevant events, it may be not enough

to properly train these methods. The distribution of the

amount of events occurring in one day can be found in

Figure 1. The usual daily amount of event for both plants

is around 14 but the irregular plant encounters more days

with around 80 events reported.

Figure 1: Distribution of the amount of events occurring in

one day for regular and irregular plants.

Unfortunately, the data is not labelled and as such

we don’t know which events are actually relevant or not.

This problem arises frequently in industrial domains,

where the only way to label event logs is to let domain

experts do it manually, which is obviously not a viable

solution on such large datasets. Actually, it is this lack

of labelled data that motivated this study. Hence, there is

no proper metric that could be used to assess the meth-

ods’ accuracy (other than having domain experts manu-

ally evaluate all methods). Any metric that could allow

to directly assess this labelling would actually be a per-

fect method to label the data and solve the issue. There-

fore, we have developped metrics to indirectly approxi-

mate the methods accuracy based on data characteristics

speciﬁc to our dataset. As a consequence, the compari-

son with other dataset is hampered by the fact that these

metrics are dataset-centered and can only be applied to

datasets with similar behaviour.

First, domain experts have indicated that a regular

plant typically reports around 90% of irrelevant (regular)

events while an irregular plant typically reports between

70% to 80% of irrelevant events. These numbers are an

estimation but can be considered as a correct indication

with a margin of error of around 10% depending of the

plants considered. Second, the failures occurring in a

plant that give rise to the events can be detected by com-

bining two additional datasets: 1) The irradiation sen-

sor values that measure the solar irradiation reaching the

plant, and 2) The yield value that measures the electric-

ity production of the plant. An outage is detected when

there is enough irradiation to have electricity production

but there is no yield.

Based on the above, we can deﬁne two metrics:

1) The percentage of events labelled as irrelevant. As

we have a rough estimation of the expected percent-

age based on domain knowledge, we can evaluate if the

method seems to over- or under-label the events as irrel-

evant. 2) The percentage of outages without explanation,

i.e. without any relevant events during or (up to 45 min-

utes) before its occurrence. A wrong labelling would

increase the number of outages without explanation, be-

cause the over-labelling of relevant events as irrelevant

will lead to outage only preceded by irrelevant events.

Note that these two metrics only provide an approxi-

mate and should be interpreted carefully as they can not

directly assess the labelling accuracy but rather try to

approach it by analyzing over- and under-labelling. To

compensate this, we have also relied on domain experts

who have analyzed the accuracy of the methods on small

data subsets or have analyzed the event ranking of score-

based methods.

The third metric is the computation time. These

methods may need to be applied on datasets on demand

when domain experts and technical staff want to explore

and exploit them. Therefore, the computation time is

crucial to ensure scalability and an industrial applicabil-

ity.

5 RESULTS AND DISCUSSION

Table 2 contains, for each dataset and each method, the

three metrics: the % of events labelled as irrelevant (%

events irr. ), the computation time (comp. time), and the

% of outages whithout explanation (expl. lost).

The observed methods can be split in four character-

istics groups based on their performances: 1) The ﬁrst

group contains the methods which fail for time windows

issues, i.e. the sequences of events have to be split in

windows that are not adapted to the PV event logs. 2)

The second group consists of the methods which fails

due to the lack of sufﬁcient historical data to train the

model. 3) The third group contains the domain-based

methods that, in overall, perform well but only label a

small part of the events. 4) The last group consists of the

methods that perform well.

The ﬁrst group contains the Shannon index and com-

pression methods. The Shannon index method is clearly

not adapted to event logs. For regular event logs, the

method has failed to label the events as irrelevant (only

19% of the events have been labelled as such while most

of them are probably irrelevant). This result can be ex-

plained by the fact that regular days only contain a few

Data-driven Relevancy Estimation for Event Logs Exploration and Preprocessing

401

Table 2: Summary of methods’ efﬁciencies.

Methods Regular plant Irregular plant

% events irr. comp. time expl. lost % events irr. comp. time expl. lost

Status method 90% 3 sec 0% 79% 23 sec 0%

Simultaneous status method 48% 10 min 0% 57% 7 min 0%

Consecutive event method 0.5% 60 sec 0% 14% 4 min 0%

Morning and evening method 98% 14 sec 4.9% 81% 25 sec 4%

TF-IDF method 88% 28 min 0.8% 73% 84 min 0%

Contextual TF-IDF method 88% 30 min 0% 73% 98 min 0%

Pattern method 57% 30 min 1% 39% 66 min 17%

Compression method 83% 7 min 6% 41% 4 h 19%

Statistical method 39% 16 sec 1% 82% 58 sec 0%

Shannon index method 19% 28 sec 2.7% 62% 12 sec 19%

status + TF-IDF methods 90% 17 min 0% 82% 19 min 0%

status + compression methods 99% 64 sec 6% 83% 4 min 18%

distinct types of events. Therefore, the entropy of such

sequence will be high. This method failed as well for

irregular periods as it wrongly labelled events as irrele-

vant and lost information of some outages (19% of the

outages for which there is no explanation).

Similarly, the compression method has failed with

the irregular dataset as the number of outages without

explanation also rose to 19%. This may be because these

two methods analyze periods of 1 day and then label the

whole period as irrelevant. These twenty-four hours time

windows have been selected as they represent physical

periods, i.e. the inverter ”reboots” after the night where

it has stoped. However, by selecting smaller periods it

may be possible to decrease this over-labelling. The dif-

ﬁculty would reside in the choice of the time windows

as a too small time windows may artiﬁcially split out-

age periods into many smaller sub-periods that may de-

crease the method accuracy. The combination of status

and compression methods only reduces the computation

time but keeps the time-windows problems. Hence, this

combination of methods has the same low accuracy than

the compression method alone.

The second group consists of the pattern and statisti-

cal methods that fails due to the lack of sufﬁcient histor-

ical data to train the model on the dataset. The pattern

method suffered a lack of accuracy for irregular periods

(with an increase of 17% of the outages without explana-

tions). Although this method has performed well for the

regular dataset (in all metrics). The patterns were found

with high support thresholds, hence they represent the

(very) frequent patterns common to regular days. How-

ever, some of the less frequent harmless patterns occur-

ring during the less frequent irregular days are missed. It

explains the difference of performance on regular and ir-

regular datasets. A drawback of this method is the com-

putation time (1 hour for the irregular dataset). In ad-

dition, this computation time does not include the time

needed to identify the patterns, which in our experience

could take days, as it is manufacturer speciﬁc. However,

these patterns only need to be found once for a type of

inverters and can then be applied to any plants with that

type.

The statistical method has performed well for irregu-

lar periods but poorly for regular periods. As this method

is based on a probabilistic analysis of the outages, it re-

quires a dataset that contains enough outages to have

statistically signiﬁcant results, which is not the case for

regular datasets. However, this method is still a per-

fect method to quickly analyze irregular periods and rank

the events. In addition, a larger dataset combining sev-

eral plants with devices from the same manufacturer and

close location (hence same behavior) could be used to

compute a ranking of the events speciﬁc to that type of

device (and location). It could then be applied to any

plant with that type of device, without the cold start is-

sue.

The third group contains the domain-based methods,

namely the morning and evening, status, simultaneous

and consecutive event methods. Status and simultane-

ous methods have been both really effective in terms of

events correctly labelled for both datasets and with low

computation time (below 10 minutes). However, they

do not provide any help to analyze the remaining events.

For example, although the status methods labelled as ir-

relevant 79% of the events of the irregular dataset, there

were still 25.140 relevant events in the dataset which can

still be cumbersome to analyze.

The consecutive event method also seems an inter-

esting method for the irregular dataset as 14% of this

dataset is composed of the repetition of one event until

its ﬁx. Therefore, these 14% could easily be removed

without impacting the dataset. Note that this method has

obviously no use for regular dataset where such events

do not occur.

The morning and evening method seems too strict in

its labelling as the amount of events without explanation

increased by 4% (which may, however, be acceptable in

some situations). It indicates that for some periods the

start and stop periods are important and can not be la-

belled as irrelevant as a whole. It is worth noting that for

the regular dataset, 98% of the events occurred within

an hour period of the start and stop sequence (and only

81% of the events are in the same situation for the irreg-

ular dataset).

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

402

Finally, the last group consists of both TF-IDF meth-

ods and the combination of the status method followed

by TF-IDF that performed well. Both of TF-IDF meth-

ods have performed very well for both datasets with re-

spectively 88% and 73% of the events labelled as irrele-

vant with (almost) no losses of information. Therefore,

the contextual TF-IDF method barely improve the accu-

racy of the traditional TF-IDF on event logs. The only

drawback of these methods are their computation times

that went up to one hour and a half for the irregular

dataset.

A combination of the status method followed by TF-

IDF can reduce signiﬁcantly the computation time of

TF-IDF without impacting the accuracy of the method.

The TF-IDF scores were also still similar to the one

found without the application of the status method as

preprocessing step. The computation time on the reg-

ular dataset dropped from 28 minutes to 17 minutes and

was reduced by 65 minutes (77%) on the regular dataset

(from 84 minutes to 19 minutes).

As a conclusion, the methods Shannon index, com-

pression, pattern, contextual TF-IDF and Morning and

evening have not been found addapted for industrial

events logs. A good way to label the events as relevant

or irrelevant is to combine ﬁrst a domain-based method

such as status method to already perform a ﬁrst quick

labelling. Then TF-IDF method can be used to help to

label the remaining events. A statistical method can also

be used for irregular datasets. Both methods are actually

complementary as statistical methods only focus on the

correlation between events and outages while TF-IDF

method sort the event by their relevancy and uniqueness,

without any regard for the outages.

6 CONCLUSION AND FURTHER

RESEARCH

In this paper, we have considered and evaluated 10 meth-

ods (from various research ﬁelds) to estimate the event

relevancy in industrial event logs, to detect irrelevant

events that could be discarded during the preprocessing

of voluminous data. These methods have been bench-

marked on two datasets containing real industrial events

logs from two PV plants. We have found that a combina-

tion of two methods (one removing the state events and

one applying TF-IDF) allows to label up to 90% of the

events as irrelevant with a reasonable computation time

For further research, we intend to evaluate other

score-based methods from the static pruning index ﬁeld,

especially the methods BM25, BB2 or the Rnyi diver-

gence used by (Chen et al., 2015), to benchmark them on

industrial events logs. In addition, the statistical method

can also be applied on device speciﬁc datasets, i.e. on

datasets containing the event logs of devices of same

type from multiple plants. This may allow to create de-

vice speciﬁc ranking that could then be applied on all

devices of that type without pre-processing of the data.

However, a thorough study of these scores would need to

be performed to assess e.g. if the location of the device

has an impact on these events scores.

ACKNOWLEDGEMENTS

This work was subsidised by the Region of Bruxelles-

Capitale - Innoviris.

REFERENCES

Billerbeck, B. and Zobel, J. (2004). Techniques for efﬁ-

cient query expansion. In International Symposium

on String Processing and Information Retrieval, pages

30–42. Springer.

Bonchi, F., Giannotti, F., Mazzanti, A., and Pedreschi, D.

(2003). Exante: Anticipated data reduction in con-

strained pattern mining. In European Conference on

Principles of Data Mining and Knowledge Discovery,

pages 59–70. Springer.

Bose, R. J. C., Mans, R. S., and van der Aalst, W. M. (2013).

Wanna improve process mining results? In Compu-

tational Intelligence and Data Mining (CIDM), 2013

IEEE Symposium on, pages 127–134. IEEE.

Carmel, D., Cohen, D., Fagin, R., Farchi, E., Herscovici,

M., Maarek, Y. S., and Soffer, A. (2001). Static index

pruning for information retrieval systems. In Proceed-

ings of the 24th annual international ACM SIGIR con-

ference on Research and development in information

retrieval, pages 43–50. ACM.

Chen, R.-C., Lee, C.-J., and Croft, W. B. (2015). On diver-

gence measures and static index pruning. In Proceed-

ings of the 2015 International Conference on The The-

ory of Information Retrieval, pages 151–160. ACM.

Conforti, R., La Rosa, M., and ter Hofstede, A. H. (2016).

Filtering out infrequent behavior from business pro-

cess event logs. IEEE Transactions on Knowledge and

Data Engineering.

Cooley, R., Mobasher, B., and Srivastava, J. (1999). Data

preparation for mining world wide web browsing pat-

terns. Knowledge and information systems, 1(1):5–32.

Dagnely, P., Tsiporkova, E., Tourwe, T., Ruette, T., De Bra-

bandere, K., and Assiandi, F. (2015). A semantic

model of events for integrating photovoltaic monitor-

ing data. In Industrial Informatics (INDIN), 2015

IEEE 13th International Conference on, pages 24–30.

De Moura, E. S., dos Santos, C. F., Fernandes, D. R., Silva,

A. S., Calado, P., and Nascimento, M. A. (2005).

Improving web search efﬁciency via a locality based

static pruning method. In Proceedings of the 14th

international conference on World Wide Web, pages

235–244. ACM.

Fu, X., Ren, R., Zhan, J., Zhou, W., Jia, Z., and Lu,

G. (2012). LogMaster: mining event correlations in

logs of large-scale cluster systems. In Reliable Dis-

tributed Systems (SRDS), 2012 IEEE 31st Symposium

on, pages 71–80. IEEE.

Data-driven Relevancy Estimation for Event Logs Exploration and Preprocessing

403

Fuhrman, S., Cunningham, M. J., Wen, X., Zweiger, G.,

Seilhamer, J. J., and Somogyi, R. (2000). The ap-

plication of Shannon entropy in the identiﬁcation of

putative drug targets. Biosystems, 55(1):5–14.

Gupta, M., Gao, J., Aggarwal, C. C., and Han, J. (2014).

Outlier detection for temporal data: A survey. IEEE

Transactions on Knowledge and Data Engineering,

26(9):2250–2267.

Hassan, A., Martin, D., Flora, P., Mansﬁeld, P., and Dietz,

D. (2008). An industrial case study of customizing op-

erational proﬁles using log compression. In Software

Engineering, 2008. ICSE’08. ACM/IEEE 30th Inter-

national Conference on, pages 713–723. IEEE.

Hill, T. C., Walsh, K. A., Harris, J. A., and Moffett, B. F.

(2003). Using ecological diversity measures with

bacterial communities. FEMS microbiology ecology,

43(1):1–11.

Jangid, C. S., Vishwakarma, S. K., and Lakhtaria, K. I.

(2014). Ad-hoc Retrieval on FIRE data set with TF-

IDF and Probabilistic Models. International Journal

of Computer Applications, 93(18).

Jayaprakash, S. and Balamurugan, E. (2015). A Com-

prehensive Survey on Data Preprocessing Methods

in Web Usage Minning. International Journal

of Computer Science and Information Technologies,

6(03):3170–3174.

Srivastava, M., Garg, R., and Mishra, P. K. (2015). Analy-

sis of Data Extraction and Data Cleaning in Web Us-

age Mining. In Proceedings of the 2015 International

Conference on Advanced Research in Computer Sci-

ence Engineering & Technology (ICARCSET 2015),

page 13. ACM.

ICAART 2018 - 10th International Conference on Agents and Artiﬁcial Intelligence

404
