Distribution Data Across Multiple Cloud Storage using Reinforcement

Learning Method

Abdullah Algarni and Daniel Kudenko

Department of Computer Science, University of York, Deramore Lane, Heslington, YO10 5GH, York, U.K.

Keywords:

Machine Learning, Reinforcement Learning, Multiple Cloud Computing Storage, File Access Pattern.

Abstract:

Storing data on a single cloud storage service may cause several potential problems for the data owner such as

service continuity, availability, performance, security, and the risk of vendor lock-in. A promising solution to

tackle some of these issues is to distribute the data across multiple cloud storage services (MCSS). However,

the distinguishing characteristics of different cloud providers, in terms of pricing schemes and service perfor-

mance, make it difﬁcult to optimise the cost and the performance concurrently on MCSS. This paper proposes

a framework for automatically tuning the data distribution policies across MCSS from the client side based on

ﬁle access patterns. The aim of this work is to optimise the average cost and the average service performance

(mainly latency time) on MCSS. To achieve this goal, two different machine learning algorithms are used in

this work: (1) supervised learning to predict ﬁle access patterns, and (2) reinforcement learning to control data

distribution parameters based on the prediction of ﬁle access pattern. The framework was tested on a cloud

storage emulator, where its was set to act like several common cloud storage services. The result of testing this

framework shows a signiﬁcant improvement in the cost and performance of storing data in multiple clouds, as

compared to the commonly used uniform ﬁle distribution.

1 INTRODUCTION

Cloud storage allows users to store data on a remote

storage, where it can be accessed through the Internet.

It offers many advantages for users such as increased

work efﬁciency and reduced operational costs in the

long-run. One of the major beneﬁts of cloud stor-

age is the scalability and elasticity, allowing organi-

sations to improve the management of growth of stor-

age capacity demand in their physical storage, which

are increasing dramatically overtime (Rebello, 2012).

Despite these advantages, there are some underlying

concerns about cloud storage:

• Cloud performance: This usually refers to net-

work latency, which is the time a packet takes to

travel from the client-side until it is completely

stored on the cloud provider’s servers. Typically,

the latency is inﬂuenced by the distance between

locations of client and cloud service, besides net-

work throughput (Solomon et al., 2014).

• Cloud vendor lock-in: Every cloud provider

has speciﬁc API (Application Programming Inter-

face) requirements that allow users’ applications

to interact with their services. This means that

cloud users must build their applications based on

these requirements. The divergence between API

requirements poses the risk of locking a users’

data to a particular cloud provider (Mu et al.,

2012). Several uniﬁed APIs have been imple-

mented for interacting with many of the popular

cloud service providers such as Libcloud (Lib-

clouds, 2016) and Jcloud (Jclouds, 2016), which

allow users to move from one cloud to another

without changing their applications and also allow

them to adopt multiple cloud services.

• Service continuity: cloud services may suffer

outages or even go out of business at any time (see

(Marshall, 2013), (Brinkmann, 2016), (Armbrust

et al., 2010), (Tsidulko, 2015), (Bort, 2016) for

prominent examples).

Some researchers haveaddressed the aboveissues and

suggested to use the RAID principle (Redundant Ar-

ray of Independent Disks) to distribute data across

multiple cloud storage instead of relying on a sin-

gle one. Typically, RAID has been used in traditional

storage to avoid problems with a single hard-disk by

Algarni A. and Kudenko D.

Distribution Data Across Multiple Cloud Storage using Reinforcement Learning Method.

DOI: 10.5220/0006124804310438

In Proceedings of the 9th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2017), pages 431-438

ISBN: 978-989-758-220-2

431

distributing data on multiple hard disks. The main ob-

jectives of using RAID: (1) improve the performance

of reading from and writing onto hard-disks and (2)

provide some level of fault tolerance in case one of

the hard disks fails. However, the case with multiple

cloud storage is different, because each cloud service

has different characteristics that affect the connectiv-

ity between client and cloud services. Furthermore,

the ﬁle access patterns along with ﬁle size play a key

role in the cost of cloud services. More speciﬁcally,

the cost of cloud storage is computed mainly from

the number of operations (typically: read, write, and

delete), network usage, and the lifetime and size of

ﬁles. Moreover, the ﬁle size directly affects the la-

tency time.

Optimising cost and latency on different cloud ser-

vices are made difﬁcult because of the differences

in service performance and pricing schemes of each

cloud storage provider. Besides, the prices scheme

and performance in any cloud provider are not sta-

tionary, i.e. the cost may change automatically based

on how much data is stored or transferred through the

network. Thus, the optimisation should ideally ac-

count for long-term cost and performance, rather than

just optimising the current state. Accordingly, it is

important to ﬁnd a dynamic solution that is capable of

optimising cost and latency time and adapt to changes

in the states of the different cloud storage services.

This paper demonstrates that reinforcement learn-

ing is a suitable technique to deal with these chal-

lenges because of its ability to maximise the expected

long-term utilities. Furthermore, we show how su-

pervised learning can be used to generate predictive

models of ﬁle access pattern within large enterprise

workﬂows.

The overall contribution of this paper is an intel-

ligent framework for optimising the cost and latency

on MCSS. The framework has a novel design to over-

come the problem of service continuity, availability

and vendor lock-in. The development of this frame-

work combines two machine learning methodologies:

(1) a new method of reinforcement learning to deter-

mine the percentage of ﬁle data that should be located

in each cloud storage based on ﬁle access patterns and

(2) supervised learning to predict these access pat-

terns for each ﬁle.

2 CLOUD COMPUTING

OVERVIEW

Cloud Computing has become a signiﬁcant business

trend recently. In its broadest sense cloud computing

represents computing resources delivered as services

over the Internet. One of these services is cloud stor-

age service, which is getting much attention as a result

of the increasing of data capacity volume every year

in organisation data centres.

Broadly, there are two categories of ”on-line” stor-

age, both often referred to as cloud storage. The ﬁrst

category is designed to be a personal on-line storage

for private consumers. This category usually offers

limited free storage and a ﬁxed price per month for

any extra space. Examples of this kind of storage in-

cluding GoogleDrive and OneDirve. The second cat-

egory is designed to work as utility services, mainly

for enterprises. This type is called Cloud Storage Ser-

vice. It provides unlimited storage space and charges

users via a pay-as-you-go method. This category is

intended to be accessed primarily through an API.

Cloud storage services are more attractive to busi-

nesses since they offer many beneﬁts, such as ﬂexi-

bility, scalability, and a reduction in spending on tech-

nology infrastructure. (Furht, 2010; Thakur and Lead,

2010). Examples of this type include Google Cloud

Storage , Amazon S3 , Microsoft Azure Storage, and

Rackspace File Cloud. Usually, users of this type are

charged based on three factors: (1) the amount of data

stored, (2) the amount of network bandwidth used,

and (3) the number of operations such as read, write,

and delete.

This paper focus on the second type only (cloud

storage services), which is most relevant to our target

domain of data-intensive enterprises.

3 RELATED WORK

Several researchers have addressed the issue of de-

pending on a single cloud storage service. An useful

approach for tackling the problems associated with

a dependence on a single cloud provider is adopt-

ing MCSS. Although the distribution of data among

MCSS increases availability, and reduces the proba-

bility of losing data, it may increase the cost and not

guarantee to enhance the performance because it is re-

stricted to the lowest performance of cloud services.

Scalia (Papaioannou et al., 2012) presented a

cloud brokerage solution that continuously adapts the

placement of data, based on ﬁles access statistics

among several cloud storage services to minimise the

storage cost, improve the data availability, and elim-

inate vendor lock-in risk. However, the work does

not evaluate the impact of the system on the latency

time. HAIL (Bowers et al., 2009) used the princi-

ple of RAID to distribute ﬁles across a collection of

cloud storage to enhance the availability of data and

remotely manage data security risks in the cloud by

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

432

Table 1: A comparison between our framework LOMCSS and other work, where S.Cost is Storage Cost, N.Cost is Network

Cost (i.e Transaction cost), O.Cost is Operation Cost (read, write, and delete).

Framework

the goal is to optimise Tackling problems of # clouds

S.Cost N.Cost O.Cost Latency time Vendor lock-in Availability Multiple

HAIL X x x x X X X

Scalia X x x x X X X

MCDB x x x x X X X

µLibCloud x x x X X X X

DepSky x x x X X X X

Deco X x x X x x x

LOMCSS X X X X X X X

employing the Proofs of Retrievability (PORs) sys-

tem. Although this work shows a reduction of storage

cost, they do not consider the effect of access patterns

on the network cost. Besides, they assume that the ﬁle

is static, such as backup ﬁles and archives. MCDB

(AlZain et al., 2011) is a multi-cloud database mod-

ule, which employs Shamers secret sharing algorithm

(Shamir, 1979) to reduce the data integrity, data in-

trusion, and service availability. (Mu et al., 2012)

have designed a prototype system called µLibCloud

that leverages RAID to improve the availability, read

and write performance, global access experience of

clouds, along with fault tolerance of cloud storage

services. However, their work is subject to reason-

able extra costs. In other research, (Bessani et al.,

2011) presented a system called DepSky that employs

a cryptographic secret sharing scheme with erasure

codes to avoid vendor lock-in and enhance the avail-

ability and efﬁciency of distributed data. Although

DepSky shows an improvement of performance, the

cost doubles on average compared to a single cloud

storage.All above mentioned solutions do not con-

sider the differences in cloud services network char-

acteristics that have an impact on the connectivity be-

tween client and cloud storage services. Each cloud

storage possesses a different network architecture and

access policies that affect the performance (latency

time) of reading and writing the data. Moreover, no

one, to the best of our knowledge, has proposed a so-

lution to optimise the cost and performance together

in the distribution of ﬁles across MCSS. However, it

is worth mentioning here that there is one work by

(Zhou et al., 2015) who proposed a system called

”Deco” to optimise cost while keeping performance

at reasonable levels . But, they designed their sys-

tem for distributing processes tasks across multiple

instances (not storage) in a single cloud for workload

purpose. Besides, they did not take account of net-

work and operational cost in their system. Further-

more, the efﬁciency of their solution will be restricted

by the slowest cloud service used, if they implement

it on MCSS. In this paper, we propose a framework

(we call it Learning to Optimise Multiple Cloud Stor-

age Services, for short LOMCSS ) to optimise the

performance of multiple cloud storage, while keep-

ing the overall cloud storage cost low. Table (1) sum-

marises the differences between the various solutions

mentioned above compared to LOMCSS.

4 FRAMEWORK

ARCHITECTURE

Figure (1) demonstrates an overview of the pro-

posed framework. It comprises two machine learning

methodologies: (1) Reinforcement Learning that de-

cides how to distribute ﬁles across multi-clouds based

on the variance between cloud storage services and

the prediction of ﬁle access patterns; (2) supervised

learning that predicts the access pattern for each ﬁle,

which we call it ”Access Pattern Prediction Model”

(APPM). Before discussing these algorithms, we will

ﬁrst give a brief description of the RAID technology.

APPM

File

RL Agent

RAID

File Attributes

Access pattern

attributes

Distribution Parameters

ﬁle fragment

Figure 1: A high level of the Distribution Framework Struc-

ture, where APPM is estimating ﬁle access pattern; the RL

decide how much proportion of each ﬁle size will be located

in each cloud; RAID is the distribution manager; C

,and

are cloud storages.

Distribution Data Across Multiple Cloud Storage using Reinforcement Learning Method

433

4.1 RAID Controller

RAID stands for Redundant Array of Independent

Disks, which is a technology that combines several

hard disks into a single logical drive. It was devel-

oped to overcome the performance and availability is-

sues in traditional data centre hard disks. There are

several ways of using RAID to spread data across

multiple hard drives, which have been standardised

into various levels (Buyya et al., 2002). In this work,

we use the principle of RAID level 5 because it is

the most common RAID conﬁguration for business

servers (LYNN, 2014) and it offers appropriate per-

formance and fault-tolerance.

Although employing RAID for MCSS can im-

prove the reliability, it is hard to optimise overall per-

formance while reading and writing to different cloud

storage services concurrently. Many factors impact

the performance such as the distance, the cloud net-

work structure and policies, and throughput. Conse-

quently, the overall performance is restricted by the

slower cloud services. In this work, we address this

challenge.

4.2 Access Pattern Predictive Model

The goal of this module is to predict the lifetime of the

ﬁle (lifespan) and how many times a ﬁle will be read

and updated in the future. Prediction is performed us-

ing numeric linear regression , which expresses the

inputs as a linear combination of attributes with pre-

determined parameters (usually called weights). As

the name implies , this technique use regression anal-

ysis to optimise the parameters over training.

In LOMCSS, ﬁle attributes are used as an in-

put vector for three linear regression models, each

of which predicts one of the following access pattern

characteristics: (1) Lifetime which indicates to how

many days the ﬁle will be active.; (2) Number of read

operations which shows how ; (3) Number of write

operations which is the number of times the ﬁle will

be updated during its lifetime. For our experiments,

we trained the algorithm on a ﬁle access log, based

on the business workﬂow of a large organisation. The

training set iscomposed of six input patterns and three

desired outputs.

4.3 Reinforcement Learning Agent

Reinforcement Learning (RL) is a machine learning

method that is used to tackle sequential decision-

making problems through a trial-and-error technique

(Sutton and Barto, 1998). In the broadest sense, RL

States

action-selection

policy

Representation

Learning

Algorithm

RL Agent

Environment

t+1

Figure 2: The reinforcement learning paradigm consists of

an agent interacting with an environment. At each discrete

time t, the agent observes s

and performs a

in order to

transition to state subsequent s

t+1

, and receives a reward

r(t+1).

agent interacts with a single environment by observ-

ing the state of its environment, selecting an action,

and receiving a scalar reward for that action, as de-

picted in ﬁgure 2. The reward from the environ-

ment provides an indication of the utility of the ac-

tion in a given state. More speciﬁcally, the environ-

ment is characterised by a set of states S in which

every state is constructed from a vector of state fea-

tures, and the agent decides which action(s) to be per-

formed from a set of admissible actions A based on an

action-selection policy. Over time, an RL agent can

learn how to behave in its environment through the

search for the optimal policy (denoted π

∗

) of choosing

an action in a respective state. Many methodologies

have been used to learn an optimal policy in RL prob-

lems. These methodologies can be categorised into

three groups (Konda and Tsitsiklis, 2003): actor-only,

critic-only , and actor-critic methods. Critic refers the

state-value function, where actor refers to the policy

structure. Most of the RL applications use methods

that estimate the value function (critic-only), which

determines the value of the agent to be in a given state

V : S → R or the value of performing an action in a

particular state Q : S × A → R, which called Q-value.

Broadly, the value of each state is computed as the

sum of discounted rewards accumulated when start-

ing from state s, acting under a policy π for a horizon

of t time steps, which takes the following form:

, a

) = E



∞

∑

t=0

γr

= s, a

= a



(1)

Where 0 ≤ γ < 1 is a factor used to discount the

future reward, and E

is the expectation assuming the

RL agent follows policy π. The goal of the agent is to

learn the optimal policy π

∗

that maximises the cumu-

lative rewards starting a given state s.

The best way to represent the Q-value is via a

parametrised function approximation such as a lin-

ear regression and neural network. In this work we

use neural network with back-propagation that to op-

timise the network parameters with Temporal Differ-

ence error (TD error) function that evaluate the Q-

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

434

value function, which takes the below form:

TD =



+ γQ(s

t+1

, a

t+1

)



− Q(s

, a

) (2)

Despite the wide use of the critic-only method,

employing this method in a continuous state and ac-

tion spaces can be non-trivial and time-consuming

(Hasselt, 2012). In such case, actor-critics methods

have been demonstrated to be more successful (Has-

selt, 2012). Actor-critics methods rely on two func-

tions: (1) the actor function which is used to imple-

ment a stochastic policy that maps states to actions,

and (2) the critic or the value function as described

above. This method , also, uses TD-error function (2)

to evaluation and update critic value and adjusting the

action probabilities.

Recall that the action of the RL agent, in this work,

is to decide on the proportion of each ﬁle to be stored

in each cloud storage service to optimise the cost and

latency time. This implies that the RL agent must

execute multiple continuous actions simultaneously,

where each action is dependent on other action val-

ues since they all have to sum up to 100 percent.

Moreover, in this work, the RL agent interacts with

multiple independent environments (the cloud storage

providers) and receives various reward values, which

means we havemultiple states values at each time step

The reward function incorporates two factors: (1)

latency time and (2) total cost of each cloud service

including storage, network, and operation cost. These

factors are subject to change at any time which means

that the reward is non-stationary. With all these chal-

lenges, we developed a new algorithm specially de-

signed for this problem.

The new algorithm is an on-policy algorithm be-

cause it is based on the state value function that is

evaluated based on the TD-error. Unlike critic-only

algorithms, it does not have a discrete action space.

Also, in contrast to actor-critic algorithms, it does not

have an independent actor function. However, actions

are generated directly from the state value function.

This algorithm can be thought of as a value and ac-

tions approximation based on a neural network. More

speciﬁcally, the neural network produces a number of

output values equal to the number of cloud services

and then transforms these value to actions, i.e. a list

of percentage values corresponding to the ﬁle propor-

tion to be stored on each cloud service provider re-

spectively. Also, unlike other applications of neural

networks in RL, in this work, the number of output

values in the neural network is not ﬁxed because the

number of cloud services available can change over

time. This means that the number of output values

can be increased or decreased at any time, which is

another contribution in this work. More details about

our algorithm are provided in the following section.

4.3.1 Learning to Optimise Multiple Cloud

Storage Services (LOMCSS)

Our framework (LOMCSS) is based on neural net-

works, which is a powerful mathematical method ca-

pable of representing complex linear and non-linear

functions (Whiteson, 2012). It has been used widely

in machine learning applications. The basic struc-

ture of a neural network is a feed-forward network.

Usually, neural network applications use the back-

propagation (BP) algorithm to adjust the connection

weights using the gradient descent method. In most

RL applications, there are two methods to approxi-

mate V(s) or Q(s,a) using a neural network. The

ﬁrst is that the neural network takes the state vec-

tor s as input, and output a single number that repre-

sents V(s). The second method is to produce multiple

outputs, where each output is interpreted as Q(s,a)

denoting the value of action a in the given state s.

Then the RL agent chooses a single action that sat-

isﬁes the policy π(s, a) = argmax(Q(s,a)). After-

wards, the agent computes the TD-error for each out-

put value separately and applies back-propagation to

update the weights, ignoring the rest of the output

nodes. This method requires a ﬁxed number of output

nodes, which does not fulﬁl our requirement in this

work. For this reason, we design a new method for the

neural network that fulﬁlls our target, as illustrated in

ﬁgure 3. The goal of this new design is to allow an

RL agent to interact with each cloud independently

and produce multiple output values, where each one

of them represents the value of the state in the differ-

ent environment. For example, suppose we have three

cloud storages, each of which has its state space S.

The neural network takes all the state features from

APPM as the input vector and produces three out-

put values, each one corresponding to a single cloud.

Each one of these values can be interpreted asV(s) for

the state of the ﬁle on that cloud. As shown in ﬁgure 3,

each output value will be transformed into a single nu-

merical action, considering the value of other actions,

as shown in Algorithm ?? (line #8). After executing

all actions, the RL agent receives a reward from each

environment, which is used to compute the multiple

TD-error functions. Each of these errors is used to

evaluate the state value for each cloud within the BP

algorithm. However, it is worth mentioning that the

cost is an accumulative function based on usage rate,

which means it rises over time within the billing pe-

riod. Thus, optimising the cost of cloud storage after

each action is tricky. On top of that, as aforemen-

tioned, the reward function is non-stationary. Thus,

Distribution Data Across Multiple Cloud Storage using Reinforcement Learning Method

435

Input layer

(i ∈ R

)

Hidden Layer

(j ∈ R

)

Transfer

function

Output Layer

(k ∈ R

)

Transfer

function

V(s)

Action

Values

Weights

v[i, j]

Weights

w[ j, k]

BP function

State Features X

Figure 3: At each discrete time t, the agent receives ﬁle access pattern arbitrates (from APPM) that represent the state features

X, which will be passed through neural network to produce different outputs. Each output will be transformed to proportion

of the ﬁle size that will be stored in each cloud a

. Afterwards, the agent receives rewards from each cloud r

, which will be

used by the TD-error (TD

). Then, the back-propagation function (BP) updates the connection weights.

we compute the cost with respect to the amount used

of data as expressed below:

cost =

∑

i=0

(

otc

otu

) (3)

Where sc is the cost of storing data (su) into cloud

i per US dollar, su is the amount of data stored in

cloud i per GB, nc is the network usage cost, nu the

amount of transferring data to cloud, otc is the cost

of performing a number of operations (otu) on cloud

provider i. n denotes to the number of cloud providers

available. In short, by given the network the pre-

dicted attributes of each ﬁle (as discussed in section

4.2) along with the ﬁle size, the network produces

multiple output values corresponding to the number

of cloud storage services available at a time t. The

output values represent the value of storing the ﬁle on

each cloud. Based on that, the RL agent decides how

much proportions of the ﬁle size is going to be sent to

each cloud. Afterwards, the decisions will be evalu-

ated and tuned using TD-error and back-propagation.

One of the strengths of the proposed frameworkis that

the number of outputs of the network is ﬂexible, cor-

responding to the number of cloud storage providers

available at each time step. This feature gives the

framework the ability to overcome the issue of ser-

vice availability and continuity. For example, if one

of the cloud providers is not available for any reason,

or the data owner has added new cloud storage, the

number of output nodes can be changed accordingly,

without the need to reset the agent.

5 EXPERIMENT SET-UP

In this section, we show how the proposed framework

was evaluated. First of all, we have designed and

implemented a cloud storage emulator, especially for

this work to emulate performance and costs. The em-

ulator is ﬂexible and capable of emulating any num-

ber of cloud storages, simultaneously. The perfor-

mances of the providers in this emulator have been

set up to act as a number of cloud providers: Google

Cloud storage services, Amazon S3, Microsoft Azure

Storage, and Rackspace Cloud File. The performance

of these providers has been measured using the per-

formance analysis services of ”cloudharmony.com”.

Then, APPM has been trained based on an access log

ﬁle for several department systems of a large organi-

sation (SFD, www.sfd.gov.sa), which has been gener-

ated based on the ﬁle workﬂow of the systems for va-

cations, payroll, ﬁnancial reporting, and budget. Re-

call, that the goal of APPM is to predict access pat-

tern attributes for each ﬁle which includes expected

lifetime, the number of read operations, and a num-

ber of write operations. After the APMM has trained,

we used the following statistical methods to evaluate

the overall quality of the APMM(1) Correlation co-

efﬁcient ( denoted as r), and (2) Root Mean Squared

Error (as RMSE).(3) Mean Absolute Error ( denoted

as MAE).

The settings for the RL agent and the neural net-

work are shown in table 2. Most of these settings

have been chosen based on (Gatti, 2015). Finally, the

whole framework has been evaluated by distributing

2874 ﬁles with a total size 261 GB.

In order to test the ﬂexibility of the framework(i.e.

how the RL agent adapts with a dynamically changing

of number of cloud providers), we deﬁned three sce-

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

436

Table 2: Neural network and RL parameters sittings.

parameters values

# input nodes 4

# hidden nodes 16

# output nodes

= # cloud storages

Transfer function

1+e

−x

β 0.0007

0.5

α 0.001

0.7

γ 0.75

Figure 4: comparison between the cost and latency time in

each cloud individually and between the Standard RAID.

narios: Scenario #1: the number of cloud providers

are ﬁxed and does not change during the learning pro-

cess. Scenario #2: one of the cloud providers is re-

moved out of the cloud storage array in the middle

of the learning process. Scenario #3: a new cloud

provider is added to the storage array in the midst of

the learning process.

6 EXPERIMENT RESULTS

The results of the training data that performed to train

the APPM are shown in Table 3. Also, To evaluate our

approach, we ﬁrst measured latency time and the total

cost for each cloud provider individually by sending

the whole ﬁles to each one (i.e. without distribution)

. Therefore we distributed the entire data into each

cloud providers individually. Then we re-distribute

them using the standard principle of RAID. When us-

ing RAID, the average latency time was 11.22 sec-

onds for all ﬁles and the total cost was $36.13. After

that, we tested LOMCSS on the same data and the

same cloud storage provider settings. The bar chart

in ﬁgure 4 illustrates the differences in total cost and

average latency times in four different clouds. In ad-

dition, the graph shows the cost and average latency

of distributing ﬁles using RAID and LOMCSS.

The result indicates that, by using LOMCSS, the

total cost decreased by % 22 which amounted to

Table 3: APPM, measurement evaluation.

Lifetime # of read # of write

r 0.9761 0.9228 0.9889

MAE 0.9621 0.5648 0.0418

RMSE 1.3025 1.143 0.2119

$28.1. and the average latency time was signiﬁcantly

reduced by more than %66 (to 3.78 seconds), com-

paring to RAID. In fact, The RL agent learned how to

optimise both latency and cost by applying different

weight to cost and latency based on the importance of

the ﬁle which is extracted from the ﬁle access pat-

tern attributes. Additionally, the experiments show

that the framework is ﬂexible and adaptable when

changing the number of clouds or the behaviour of a

cloud. Figures 5 6 demonstrate how the agent’s learn-

ing curve changes when the number of availablecloud

providers is reduced increased based on the scenarios

that we described in the previous section.

0 50 100 150 200 250 300 350 400 450 500

Episode

Cost per $

Scenario #1

Scenario #2

Scenario #3

Figure 5: Cost Scenarios, cost slightly decreases when a

one of cloud was removed, and raised up as one cloud was

removed , then start gone down over learning.

0 50 100 150 200 250 300 350 400 450 500

Episode

Latency Time per seconds

Scenario #1

Scenario #2

Scenario #3

Figure 6: Latency Scenario , cost raised up as one cloud

was removed , then start gone down over learning.

7 CONCLUSION

This paper presented a framework for automatically

tuning distribution parameters over multi-cloud stor-

age services to optimise long-term cost and latency

time. The framework combines two machine learn-

ing methods: supervised learning for predicting the

Distribution Data Across Multiple Cloud Storage using Reinforcement Learning Method

437

access patterns for each ﬁle and RL for tuning the

distribution parameters based on the predicted access

patterns. We empirically demonstrated the beneﬁts

of the framework by performing experiments on a

cloud storage emulator. The main challenges that

were tackled are how to interact with multiple envi-

ronments, execute a non-ﬁxed number of actions si-

multaneously, and deal with non-stationary multiple

rewards signal. Therefore, the learning algorithm in

RL has been designed in a unique way to satisfy the

goal of this work. The empirical evaluation showed

that the proposed framework is capable to signiﬁ-

cantly reduce both the cost and average latency time

in MCSS.

REFERENCES

AlZain, M., Soh, B., and Pardede, E. (2011). Mcdb: Us-

ing multi-clouds to ensure security in cloud comput-

ing. In Dependable, Autonomic and Secure Comput-

ing (DASC), 2011 IEEE Ninth International Confer-

ence on, pages 784–791. IEEE.

Armbrust, M., Fox, A., Grifﬁth, R., Joseph, A. D., Katz,

R., Konwinski, A., Lee, G., Patterson, D., Rabkin, A.,

Stoica, I., and Zaharia, M. (2010). A view of cloud

computing. Commun. ACM, 53:50–58.

Bessani, A., Correia, M., Quaresma, B., Andr, F., and

Sousa, P. (2011). Depsky: Dependable and secure

storage in a cloud-of-clouds. In Proceedings of the

Sixth Conference on Computer Systems, EuroSys ’11,

pages 31–46, New York, NY, USA. ACM.

Bort, J. (2016). Google apologizes for cloud outage that one

person describes as a comedy of errors.

Bowers, K. D., Juels, A., and Oprea, A. (2009). Hail: A

high-availability and integrity layer for cloud storage.

In Proceedings of the 16th ACM Conference on Com-

puter and Communications Security, pages 187–198,

New York, NY, USA. ACM.

Brinkmann, M. (2016). Copy cloud stor-

age services life ends on may 1, 2016.

http://www.ghacks.net/2016/02/02/copy-cloud-

storage-services-life-ends-on-may-1-201. Online;

accessed 19-10-2016.

Buyya, R., Cortes, T., and Jin, H. (2002). A Case for Redun-

dant Arrays of Inexpensive Disks (RAID), pages 2–14.

Wiley-IEEE Press.

Furht, B. (2010). Cloud Computing Fundamentals, chap-

ter 1. Springer.

Gatti, C. (2015). Design of Experiments for Reinforcement

Learning. Springer, Heidelberg New York Dordrecht

London.

Hasselt, H. (2012). Reinforcement Learning in Continuous

State And action Spaces, pages 207–251. Springer,

Heidelberg New York Dordrecht London.

Jclouds, A. (2016). The java multi-cloud toolkit.

http://jclouds.apache.org. Online; accessed 08-07-

2014.

Konda, V. R. and Tsitsiklis, J. N. (2003). On actor-critic al-

gorithms. SIAM J. Control Optim., 42(4):1143–1166.

Libclouds, A. (2016). One interface to rule them all.

https://libcloud.apache.org. Online; accessed 08-07-

2014.

LYNN, S. (2014). Raid levels explained.

Marshall, D. (2013). Cloud storage

provider nirvanix is closing its doors.

http://www.infoworld.com/article/2612299/cloud-

storage/cloud- storage-provider-nirvanix-is-closing-

its-doors.html. Online; accessed 19-10-2016.

Mu, S., Chen, K., Gao, P., Ye, F., Wu, Y., and Zheng, W.

(2012). libcloud: Providing high available and uni-

form accessing to multiple cloud storages. In Grid

Computing (GRID), 2012 ACM/IEEE 13th Interna-

tional Conference on, pages 201–208, Beijing. IEEE.

Papaioannou, T., Bonvin, N., and Aberer, K. (2012). Scalia:

An adaptive scheme for efﬁcient multi-cloud storage.

In High Performance Computing, Networking, Stor-

age and Analysis (SC), 2012 International Confer-

ence, pages 1–10. ACM.

Rebello, J. (2012). Subscriptions to cloud storage services

to reach half-billion level this year.

Shamir, A. (1979). How to share a secret. Commun. ACM,

22:612–613.

Solomon, M. G., Kim, D., and Carrell, J. L. (2014). Funda-

mentals Of Communications And Networking. Jones

and Bartlett Publishers, Inc., USA, 2nd edition.

Sutton, R. S. and Barto, A. G. (1998). Reinforcement learn-

ing: An introduction. MIT press.

Thakur, N. and Lead, Q. (2010). Performance testing in

cloud. Citeseer A pragmatic approach.

Tsidulko, J. (2015). Overnight aws outage reminds world

how important aws stability really is. CRN. Online;

accessed 01-06-2016.

Whiteson, S. (2012). Evolutionary Computation for Rein-

forcement Learning, pages 325–355. Springer, Hei-

delberg New York Dordrecht London.

Zhou, A. C., He, B., Cheng, X., and Lau, C. T. (2015).

A declarative optimization engine for resource pro-

visioning of scientiﬁc workﬂows in iaas clouds. In

Proceedings of the 24th International Symposium on

High-Performance Parallel and Distributed Comput-

ing, HPDC ’15, pages 223–234, New York, NY, USA.

ACM.

ICAART 2017 - 9th International Conference on Agents and Artiﬁcial Intelligence

438
