Predicting Attack Prone Software Components using Repository Mined

Change Metrics

Daniel Hein and Hossein Saiedian

Department of Electrical Engineering and Computer Science, University of Kansas, Lawrence, U.S.A.

Keywords:

Secure Software Engineering, Software Vulnerability, Information Security, Vulnerability Prediction Model.

Abstract:

Identiﬁcation of attack-prone entities is a crucial step toward improving the state of information security in

modern software based systems. Recent work in the ﬁelds of empirical software engineering and defect predic-

tion show promise toward identifying and prioritizing attack prone entities using information extracted from

software version control repositories. Equipped with knowledge of the most vulnerable entities, organizations

can efﬁciently allocate resources to more effectively leverage secure software development practices, isolating

and expunging vulnerabilities before they are released in production products. Such practices include security

reviews, automated static analysis, and penetration testing, among others. Efﬁciently focusing secure devel-

opment practices on entities of greatest need can help identify and eliminate vulnerabilities in a more cost

effective manner when compared to wholesale application for large products.

1 INTRODUCTION

Current trends toward an increasingly connected

world highlight the need for improved security and

privacy. In the commercial sector, the cost of improv-

ing security competes directly with the cost of feature

development. Therefore, cost effective approaches

for vulnerability identiﬁcation, prioritization, and re-

moval are needed in order to improve software secu-

rity.

Our research looks to prediction models to help

identify attack-prone software components and selec-

tively prioritize the application of secure development

practices for vulnerability removal. Our goal is to bet-

ter facilitate the adoption and application of secure de-

velopment practices(e.g., review, static analysis, and

penetration testing) in industry by improving the ef-

ﬁciency and effectiveness of their application. First,

we seek to reduce the vulnerability search space in a

given software product by correctly predicting mod-

ules and ﬁles containing exploitable vulnerabilities.

Second, we further consider the practical question of

how to rank prediction results. Inspired by existing

research from defect and vulnerability prediction, we

are researching the feasibility of using historical and

architectural metrics from maintainability literature

for both identiﬁcation and prioritization.

Key intuitions guiding our research are based

on the reality that modern software based products

evolve over time and are composed of different sub-

components of varying maturity. In addition, each of

those sub-components may be modiﬁed by multiple

developers with varying knowledge of the system as

a complete product. As a consequence, we might

expect that unintended side effects are more likely

to result when modifying modules already exhibiting

poor maintainability. For example, we might expect a

higher probability of introducing unintended side ef-

fects when several scattered changes are rapidly made

to tightly coupled modules with poor encapsulation.

2 BACKGROUND

The majority of attacks on modern connected sys-

tems can be traced in one way or another to soft-

ware defects, and in particular, residual vulnerabil-

ities. Residual vulnerabilities are by deﬁnition de-

fects that escape detection and persist in released soft-

ware. Such vulnerabilities range, in both complexity

and severity, from a simple coding error of varying

impact, all the way to some fundamental design ﬂaw

with far reaching implications (e.g., complete lack of

authentication). Because residual vulnerabilities es-

cape detection during development, several experts

have suggested integrating additional secure software

development practices into the software life cycle to

excise these vulnerabilities prior to production re-

554

Hein, D. and Saiedian, H.

Predicting Attack Prone Software Components using Repository Mined Change Metrics.

DOI: 10.5220/0005812905540563

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 554-563

ISBN: 978-989-758-167-0

lease. Popular secure development practices include,

but are not limited to, scanning code with automated

static analysis tools, performing security reviews (for

designs and code), adding additional security-focused

tests, as well as carrying out penetration tests.

The sheer size of many modern systems means

that ﬁnding a single defect among thousands, or even

millions, of lines of code is like trying to ﬁnd the

proverbial “needle in a haystack”. For example, static

analysis tools have shown promise toward identifying

commonly repeated coding errors, but the sheer size

of many systems result in thousands of tool warnings.

The ensuing task of verifying (or “triaging”) these

tool warnings, separating actual defects from false

positives, can be overwhelming in itself–especially if

there is no strategy deﬁned for eliminating the most

critical issues ﬁrst.

One of the most expensive and limited resources

in modern software development is developer time.

Additional review and testing of various software ar-

tifacts (e.g. architectural designs, drivers, libraries,

modules, and application code) is only warranted if

there is reason to believe those artifacts may be attack

prone. Moreover, the supply of time and expertise

from security-competent developers and testers is ar-

guably more restricted due to the specialized knowl-

edge required to unearth security vulnerabilities.

For all of these reasons, and especially because

developer time is limited, it is essential to prioritize

the application of secure software development prac-

tices, focusing efforts on the most attack prone areas

of code that are likely to result in the greatest impact

when exploited. The analogy to resource utilization is

much the same as the surgical laser analogy used jus-

tifying lightweight formal methods: “A surgical laser

has less power and coverage than a traditional light

bulb, but makes the most efﬁcient use of the energy

it uses, with often more impressive results.” (Jackson

and Wing, 1996)

A perquisite is that such attack-prone components

can be identiﬁed. Therefore, identiﬁcation of attack-

prone components is a crucial step toward preventing

vulnerabilities from entering the ﬁeld. Superior pre-

diction models may signiﬁcantly help augment and

complement existing practices for these purposes.

3 MOTIVATION

Change-based fault and vulnerability prediction met-

rics have recently shown promising results for iden-

tifying vulnerable components. Our work builds on

this background, further evaluating whether or not ad-

ditional architectural metrics can be used to prioritize

change-based vulnerability predictions. We hypoth-

esize that changes, already indicative of a vulnera-

ble ﬁle, made to a module of poor maintainability (or

modularity) will be more likely than its peers to posi-

tively correlate with residual vulnerabilities.

Our focus on prediction complements existing

tools and predictive approaches utilizing code-based

metrics as predictors. However, our work more

closely examines evolutionary and architectural as-

pects of the software by:

1. investigating how change metrics correlate with

residual vulnerabilities, and

2. examining how the software module structure ei-

ther exposes or masks residual vulnerabilities.

This work approaches attack-prone prediction

from a contextual and practical perspective. As such,

when compared with other work in vulnerability pre-

diction, the predictors proposed by this work have

the potential to reveal relationships between a prod-

uct’s security (measured by residual vulnerabilities)

and how the product’s code was developed. For ex-

ample, the following questions characterize the types

of questions we might reason about:

• Do rapid and scattered code changes possibly in-

dicate increased development activity under time-

to-market or competitive pressure?

• Do atypically frequent and repeated changes to

a module or ﬁle possibly indicate a poor under-

standing of requirements, or a challenging tech-

nical issue, such that the module or ﬁle requires

ongoing rework?

• Do the environmental conditions implied by the

above factors also correspond to a large number

of security failures?

• Do security failures seem either more severe or

more prevalent for components of poor maintain-

ability?

Additionally,we aspire to relate prediction models

to the attack surface of a system along its boundaries

with the surrounding environment after (Manadhata

and Wing, 2011) and (Younis et al., 2014). That is, re-

alizing that attacker-crafted data often enters a system

along it’s attack surface, we reason that modules ex-

hibiting poor maintainability and that are also reach-

able from said entry-points would be more likely the

targets of a 0-day exploit. Because the modules are

reachable, it is possible for them to process attacker-

crafted data. Because the same modules exhibit poor

maintainability, we reason that they are more likely to

contain exploitable vulnerabilities.

Predicting Attack Prone Software Components using Repository Mined Change Metrics

555

4 RELATED WORK

Our study is informed by similar empirical vulnera-

bility and fault prediction studies by Shin(Shin et al.,

2011), Gimothy et. al. (Gyimothy et al., 2005), and

Bozorgi et. al. (Bozorgi et al., 2010). Our work

is most closely related to that of Shin, as she inves-

tigated coupling metrics as vulnerability predictors.

Shin’s work builds on a long tradition of complexity

metrics used to predict faults. Vulnerability ranking

approaches are informed by the work of Bozorgi et.

al. The following sections more completely describe

related work in the area of metrics based fault predic-

tion, and in particular, predictors based on code met-

rics, as well as predictors based on change metrics.

4.1 Code Metrics

Several studies (Munson and Khoshgoftaar, 1992),

(Nagappan and Ball, 2005), (Chidamber and Ke-

merer, 1994) have examined the relationship between

residual defects and static metrics extracted from

source code. For example, sheer size of a ﬁle in lines

of code (LOC), or more commonly in thousands of

lines of code (KLOC), has been studied as having

a bearing on residual defects based on the premise

that larger more complex code is more difﬁcult to

understand and comprehend. By extension, reviews

of difﬁcult to understand and comprehend code are

less likely to unearth defects. Another popular metric

is McCabe’s Cyclomatic complexity (MCC) which

measures the number of paths through a program. The

premise behind McCabe’s cyclomatic complexity re-

lates to the difﬁculty in achieving adequate branch

and path coverage during testing.

In the area of fault prediction, Gimothy et

al.(Gyimothy et al., 2005) set several precedents for

fault prediction studies: use of large, real-world open

source software, applying linear and logistic analy-

sis, independent evaluation of univariate predictors,

as well as applying machine learning techniques,

and 10-fold cross validation for training and testing.

These staple analysis patterns appear regularly across

fault prediction studies, and by extension, recent vul-

nerability investigation works as well. Gimothy et

al. applied the CK (Chidamber and Kemerer, 1994)

metrics suite for objected oriented (OO) software to

seven versions of Mozilla Firefox, covering 3,192 ex-

tracted classes. They found high correlation between

the CK coupling between objects (CBO) metric and

fault proneness of modules. Their predictive models

based on CBO demonstrated precision and recall val-

ues over 69%.

A related work by Janzen and Saiedian (Janzen

and Saiedian, 2007) considered a large number of

software architecture metrics to examine the impact

of test-driven development (TDD) on software archi-

tecture. Their objective was to provide a comprehen-

sive and empirically sound evidence and evaluation

of the TDD impact on software architecture and in-

ternal design quality. Their research result demon-

strated that software developers applying a TDD ap-

proach are likely to improve some software quality

aspects at minimal cost over a comparable test-last

approach. In particular, their research shows statisti-

cally signiﬁcant differences in the areas of code com-

plexity, size, and testing. These differences can sub-

stantially improve external software quality (defects),

software maintainability, software understandability,

and software reusability. By extension, we reason that

security may also be impacted by software architec-

ture and seek to examine relationships between archi-

tectural metrics and residual vulnerabilities.

4.2 Change Metrics

In the last decade, a large number of studies havegone

past direct code-based attributes to examine how these

attributes change over time as the code is developed.

The difference in these more recent studies is that

they are one level removed, extracting metrics from

the version control system rather than from individ-

ual ﬁles. We refer to such metrics as change metrics

or historical metrics to distinguish them from more

traditional static code metrics, that do not require a

VCS for calculation, being directly obtainable from a

version archive of the source code. Two such change

metrics are churn, introduced by Munson and Elbaum

(Munson and Elbaum, 1998), and change bursts.

Note that churn and change burst metrics each can

be decomposed into various metric suites; that is, the

terms churn and change burst do not themselves de-

ﬁne concrete measures, but apply as a moniker to the

historical traits common to such measures. Below, we

summarize related work in fault prediction and defect

estimation inspires our efforts in the context of vul-

nerability prediction.

Khoshgoftaar et al. (Khoshgoftaar et al., 1996)

used churn relative to bug changes, as the number of

lines added or changed to ﬁx the bug. Khoshgoftaar

used the amount of code changed along with 16 other

static code metrics to build a module fault-proness

predictor. Their case study on two successive releases

of a telecommunications system containing 171 mod-

ules with over 38,000 functions yielded precision and

recall values over 78%.

Nagappan and Ball (Nagappan and Ball, 2005)

demonstrated how to use relative code churn as an es-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

556

timator for system defect density. Their case study on

Windows Server 2003 showed that various churn re-

lated metrics were able to discriminate between fault-

prone and not fault-prone binaries with an accuracy

of 89%.

Moser et al. (Moser et al., 2008) compared 18

change metrics (called process metrics in their work)

to 31 traditional code complexity metrics in Java

source for the Eclipse project. They used a cost-

sensitive prediction model to allow for different costs

in prediction errors. They found that change metrics

outperformed the traditional complexity metrics by a

margin of about 10 percentage points for both true

positive rate and recall when using their cost based

model. In addition, the models based on change met-

rics had nearly half the rate of false positives when

compared to the models based on static code metrics.

Bell, Ostrand, and Weyuker (Ostrand et al., 2010)

studied change metrics related to individual program-

mers. They analyzed change reports ﬁled by 107 pro-

grammers for 16 releases of a system with 1,400,000

LOC and 3100 ﬁles. A “bug ratio” was deﬁned for

programmers, measuring the proportion of faulty ﬁles

in release R out of all ﬁles modiﬁed by the program-

mer in release R-1. The study compared the bug ratios

of individual programmers to the average bug ratio,

and assessed the consistency of the bug ratio across

releases for individual programmers. Their results

found that counts of the cumulative number of dif-

ferent developers changing a ﬁle over its lifetime can

help to improve fault predictions, while other devel-

oper counts were not helpful. They concluded that

information related to particular developers were not

good predictors.

In another study, Bell, Ostrand, and Weyuker (Bell

et al., 2011) examined several churn metrics, such as

lines added, deleted, and modiﬁed, where churn =

added + deleted + changed. They evaluated the in-

dependent predictive capability of several different

types of both relative and absolute churn, using 18

successive releases of a large software system. They

also studied the extent to which faults can be pre-

dicted by the degree of churn alone, as well as in

combination with other code characteristics. Their

ﬁndings indicate that various churn measures have

roughly the same predictive capability. Bell, Ostrand,

and Weyuker conclude that including some change

measure from a prior release, R

i−1

, is a critical fac-

tor in fault prediction models for release R

Change bursts refer to consecutive changes over

a period of time (Nagappan et al., 2010). Change

bursts are described by gap and burst size. The gap is

the minimum distance (e.g., in days) between succes-

sive changes, such that those changes are considered

within the same burst. The burst size is the minimum

number of successive changes required to be consid-

ered a burst. Different change bursts are shown in

Figure 1, taken from Nagappan et al.(Nagappan et al.,

2010).

Figure 1: Example change bursts with varying gap and burst

size parameters (Nagappan et al., 2010).

Recent studies (Nagappan and Ball, 2005),

(Moser et al., 2008) consistently ﬁnd relative code

churn outperforming other more traditional metrics

such as MCC and KLOC. The study on change bursts

in Windows Vista by Nagappan et al. (Nagappan

et al., 2010) was particularly impressive as they found

that change burst metrics outperformed all previous

predictors, such as code complexity, code churn, and

organizational structure as predictors for Windows

Vista. For their study on Windows Vista, they found

that change burst metrics yielded precision and recall

values over 90% (Nagappan et al., 2010).

4.3 Entropy based Software Metrics

Entropy characterizes the average degree of uncer-

tainty in a discrete random variable, X, and this also

translates in different ways to a software project. In

this section, we review entropy metrics from other

works that we utilize as explanatory variables in our

prediction models.

Hassan (Hassan, 2009) presents several complex-

ity metrics based on historical changes, calculating

entropy for the ﬁle modiﬁcations within a change pe-

riod. A change period (or interval) is a period of time

over which ﬁles change as a result of development

progress. A ﬁxed calendar time period (e.g., a week)

offers the most straightforward method to establish

Figure 2: Entropy, H(P), over a change period.

Predicting Attack Prone Software Components using Repository Mined Change Metrics

557

the change period; however, Hassan presents several

different methods for deﬁning the period. The differ-

ent period derivation methods result in the concept of

differing period types. That is, the period types differ

with respect to the method or technique used to deﬁne

the period. Hassan presents the following methods for

change period derivation:

1. Fixed Time: establishing the change period based

on a ﬁxed calendar time (e.g., a week),

2. Number of Modiﬁcations: establishing the

change period over a ﬁxed number of ﬁle modi-

ﬁcations, across all modiﬁed ﬁles, or

3. Burst Pattern: establishing the change period

based on the continuity of successive changes or

lack thereof

Hassan’s entropy based, historically derived mea-

sures were shown to out perform both prior faults

and prior modiﬁcations as a predictor of future faults

for the open source systems he studied(NetBSD,

FreeBSD, OpenBSD, Postgres, KDE, and KOfﬁce).

In addition to his entropy based historical metrics,

Hassan found differences in the prediction capability

of prior faults versus the prediction capability of prior

modiﬁcations; again, the goal being prediction of fu-

ture faults. In particular, for his studied software sub-

jects, Hassan found that prior faults (as opposed to

prior modiﬁcations) were a better predictor of future

faults.

These ﬁndings are notable since Chowdhury

and Zulkernine (Chowdhury and Zulkernine, 2011)

speciﬁcally found that prior vulnerabilities did not

perform well in estimating residual vulnerabilities;

that is, although Hassan found that prior faults were a

good predictor of future faults, Chowdhury and Zulk-

ernine found that prior vulnerabilities were not a good

predictor of future vulnerabilities. Said another way,

accurate and precise fault prediction models do not

always translate to accurate and precise vulnerabil-

ity prediction models. However, Hassan’s historical

complexity metrics have not speciﬁcally been evalu-

ated for vulnerability prediction.

We feel that entropy based metrics may be espe-

cially well suited for vulnerability prediction since:

• entropy based historical change metrics outper-

formed prior faults as a predictor of future faults–

in experiments to date, the notion of prior faults

predicting future faults hasn’t been empirically

supported for vulnerabilities (i.e., past vulnerabil-

ities have not been shown to be predictors of fu-

ture vulnerabilities),

• the level of entropy will increase as changes be-

come more scattered across ﬁles and modules,

• the change period can be determined automati-

cally using change bursts, and

• the presence of said change bursts may them-

selves be indicative of a large development push

or refactoring effort where vulnerabilities may

likely be introduced.

Sarkar et al. (Sarkar et al., 2007) describe a

number of information theoretic metrics that repre-

sent module interactions in a system, or modular-

ity. We submit that the modularity principles out-

lined by Sarkar et al. such as similarity of purpose,

acyclic dependencies, and encapsulation also charac-

terize the classic security design principles of Saltzer

and Schroeder (Saltzer and Schroeder, 1975). The as-

sociations between security design principles and de-

tailed modularity principles enumerated by Sarkar et

al. (Sarkar et al., 2007) are shown in Table 1. For

example, Saltzer and Schroeder’s design principle of

complete mediation, where every object access must

be checked for proper authority, is enabled by a de-

sign that routes all inter-module call trafﬁc through

a well deﬁned API. Sarkar et al.’s Module Interac-

tion Index, (MII), is a modularity metric characteriz-

ing the modularity principle of maximization of API-

based inter-module call trafﬁc–an underlying princi-

ple of encapsulation. MII is the ratio of external calls

made to a module’s API functions relative to the total

number of external calls made to the module. Low

MII could indicate direct usage of shared memory or

direct global memory references. We might expect

MII to inversely correlate with security vulnerabili-

ties manifesting from unmediated changes to global

variables, ultimately characteristic of poor encapsula-

tion.

Table 1: Related security and modularity principles.

Security Design Principle Modularity Principle

Economy of Mechanism Size

Economy of Mechanism Acyclic Dependencies

Economy of Mechanism Unidirectionality

in Layers

Complete Mediation API-based

Inter-Module Calls

Complete Mediation Purpose Dispersion

Complete Mediation Similarity of Purpose

Anan et al. (Anan et al., 2009) discuss how

entropy calculations on software data ﬂow relation-

ships can be used to derive a maintainability pro-

ﬁle for a given software architecture. In their work,

the maintainability proﬁle quantiﬁes the effort needed

to modify a module given a particular architecture.

Code modiﬁcation is modeled uniformly and ran-

domly across modules, with the probability of mod-

iﬁcation for any given module as

, where n is the

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

558

number of modules in the system; however, unin-

tended side effects of that modiﬁcation are estimated

using the probability of information ﬂow by using the

number of incident edges linking the given module

to other modules in the system. This research in-

vestigates if the maintainability of a module can be

used to rank predictions powered by change based

metrics. The intuition is that change based metrics

might generate a number of predictions, based on

frequently changed ﬁles. It seems reasonable that

changes to ﬁles inside of a module, where said mod-

ule already high maintainability score (relative to its

peers), would be more likely to cause unintended side

affects, simply because there are larger data ﬂows di-

rected from it to other modules.

Entropy surfaces again in Abdelmoez et al. (Ab-

delmoez et al., 2004) during analytical derivation

measures for quantifying error propagation probabil-

ity in a given architecture. Assuming an error injected

into a given module, their measure characterizes the

likelihood of it reaching other modules. This is sim-

ilar in spirit to the maintainability metric, but seems

to hold promise for mirroring propagation of attacker

crafted data.

5 VULNERABILITY PREDICTION

We seek to investigate architectural modularity met-

rics that characterize economy of mechanism and

Complete Mediation. We are also interested in infor-

mation ﬂow and entropy metrics, based on the idea

that attacks are often executed by manipulating input

data.

As mentioned previously, a closely related study

for vulnerability prediction was provided by Yonghee

Shin. The results from Shin’s study indicate that cer-

tain change and developer oriented metrics are able

to discriminate between vulnerabilities and the larger

class of standard issue defects. Shin (Shin et al.,

2011), (Shin, 2011) examined churn in addition to

several other change metrics mined from software

projects’ version control systems. Shin’s study was

likewise focused on security and vulnerability predic-

tion. Shin sought to answer whether or not these met-

rics could also be used to identify vulnerable ﬁles.

Shin also examined developer oriented graph metrics.

Shin’s results showed developer oriented metrics and

change metrics yielding the best performance on the

projects she studied.

5.1 Vulnerability Scoring and Ranking

Scoring and ranking vulnerabilities requires expert

knowledge about both the severity and likelihood of

exploitation. Various vulnerability rating systems ex-

ist to distill expert knowledge concerning accessi-

bility, ease of exploitation, and severity into a nu-

meric score or a qualitative classiﬁcation such as

high, medium, or low. Systems administrators use

these scoring systems and advisory services to prior-

itize patches to operational systems. Although var-

ious criticisms exist with respect to using these rat-

ing systems for prioritizing the application of oper-

ational patches to running systems, we consider that

the Common Vulnerability Scoring System (CVSS)

(Mell et al., 2007), despite said criticisms, offers a

metric usable for the purposes of evaluating our rank-

ing approaches.

CVSS scores are often included on security ad-

visories from organizations such as US-CERT, Mi-

crosoft, Cisco, and Secunia. These scores are also

listed in on-line vulnerability databases such as the

National Vulnerability Database (NVD (NIST, )) and

the Open Source Vulnerability Database (OSVDB

(osv, )). Such scores encapsulate expert vulnerabil-

ity knowledge and provide a basis for ranking vulner-

abilities. In particular, the base metric from CVSS

represents intrinsic characteristics of a vulnerability

as six components: access vector, access complex-

ity, authentication, and impact to conﬁdentiality, in-

tegrity, and availability.

We intend to evaluate our vulnerability ranking

techniques based on architectural metrics against the

order imposed by CVSS base scores. We are aware

of the criticisms of CVSS base scores by Bozorgi et.

al. (Bozorgi et al., 2010) as a standard against which

to evaluate ranking, but we submit that our usage is

different in the context of ranking the predictions of

residual vulnerabilities. The following paragraphs re-

capitulate Bozorgi et al.’s critique and then compares

the differences in the context of our application and

intent.

Bozorgi et. al.’s work also provides a critique of

CVSS scores, noting that CVSS is subject to “cate-

gorical magic numbers” and that the score aliases too

many details of the security advisory (from the per-

spective of prioritizing patch application based on ex-

ploitation likelihood). Further, Bozorgi e.t al. note

that derivation of factors in the CVSS base score is

not clear and that there are no empirical investigations

of whether or not CVSS base scores are truly repre-

sentative of exploitation likelihood.

The following are important differences between

our work and that of Bozorgi et.al. (Bozorgi et al.,

2010), considering that their work is concerned with

prioritizing patch selection and application to opera-

tional systems:

Predicting Attack Prone Software Components using Repository Mined Change Metrics

559

Prediction Error: Our prediction models will have

some prediction error, such as a given false pos-

itive rate. This factor doesn’t impact Bozorgi et.

al. since their false positive rate with respect to

this dimension is 0; that is, they already know the

vulnerability exists, as well as the ﬁx.

Time Independence: Bozorgi et. al. notes a signif-

icant difference on exploitation likelihood based

on time.

Bozorgi et. al. (Bozorgi et al., 2010) focus on

the classiﬁcation of a vulnerability as exploited or not

exploited in order to train a support vector machine

(SVM) learner to predict likelihood of exploitation.

Their work is different than ours as their focus is not

on the software itself, but the vulnerability reports,

such as CVE-numbered advisories listed in OSVDB

(osv, ) and NVD (NIST, ). Their work recognizes

that although a vulnerability may be found, there may

be little interest from attackers in developing its ex-

ploit. The interest of their work is in prioritizing the

application of patches by software vendors. Our inter-

est, in contrast, is in prioritizing the creation of those

patches, from the perspective of a software vendor.

Rather than advisory reports, our inputs consist of ar-

chitectural features.

A key difference between our context and that of

Bozorgi et al. discussed above is that of time. In

their work, the age of a vulnerability was a signif-

icant factor in determining exploitation likelihood–

attackers may be less likely to exploit a vulnerabil-

ity the older it gets, since, it is reasonable that system

administrators may have already patched older vul-

nerabilities. In contrast, our context is one where any

vulnerability could potentially be a zero day exploit.

A residual vulnerability is by deﬁnition a vulnerabil-

ity that evades detection and persists in released soft-

ware. Despite the criticisms of CVSS, we submit that

our context is different and propose to use CVSS as

an evaluation of ranking we create utilizing modular-

ity and maintainability metrics.

We conclude this section by reiterating that CVSS

scores are already widely used and are available di-

rectly on, or directly cross-referenced from, various

vulnerability advisory systems. These advisory sys-

tems, along with vulnerability databases such as OS-

VDB and NVD constitute the source of our training

and evaluation data. Therefore, a natural extension

of classiﬁcation (e.g., ﬁle or module is vulnerable)

for vulnerability prediction is to utilize these available

scores, encapsulating expert knowledge, for the pur-

pose of ranking vulnerability predictions generated by

our prediction models.

6 EXPECTED CONTRIBUTIONS

The key contributions anticipated by this research are

as follows:

• Aid security improvement by reducing the search

space for residual vulnerabilities,

• Evaluate the feasibility of using information theo-

retic architectural metrics to further prune and pri-

oritize predictions (i.e. vulnerability indicators),

• Contribute new knowledge to the ﬁeld related to

the relationship among security, complexity, and

architectural quality attributes (modularity and

maintainability),

• Provide open source tools for measuring infor-

mation theoretic architectural metrics describing

modularity and maintainability, and

• Add change burst empirics to the growing body of

literature on defect and vulnerability prediction in

open source projects.

The overall goal of this research is to improve se-

curity of consumer software products by enabling or-

ganizations to more effectively ﬁnd and remove vul-

nerabilities prior to release. This research expects to

make vulnerability identiﬁcation and removal more

tractable and cost effective by reducing the number

of components suggested for extended security re-

view and penetration testing. This work speculates

that organizations developing consumer software will

be more motivated to expend additional effort on a

more feasible and narrowly focused objective. This

is in contrast to taking no action because either (1)

the probability of ﬁnding real vulnerabilities is near

inﬁnitesimal (i.e. wasting time searching for the

proverbial needle in a haystack), or (2) because tool-

predicted vulnerabilities are so numerous that the de-

velopment team is simply overwhelmed. On the lat-

ter point, the sheer number of defects is an issue be-

cause false positive rates of modern tools necessitate

that development teams manually inspect, or “triage”,

each identiﬁed issue. On both points, triage efforts

typically lose out to other development activities such

as ﬁxing observed bugs or developing new features.

The new and novel part of this work is the addition

of suspect prioritization enabled by architectural met-

rics. The re-application of architectural metrics (char-

acterizing modularization and maintainability) pro-

vide the foundation needed for prioritizing predicted

components. Such relative prioritization is largely ab-

sent from existing defect and vulnerability prediction

literature. Nevertheless, establishing priority is im-

portant because it recognizes that not all vulnerabil-

ities are created equal. Paraphrasing a common say-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

560

ing, “Nothing is top priority when everything is top

priority”.

Priority enables an organization to set customized

goals, such as “ﬁx all severe, high-impact vulnera-

bilities”, that better align with near and long term

business strategies. In effect, the addition of priority

better recognizes the socioeconomic realities and hu-

man factors characterizing the environment in which

software is developed. For example, consider how a

start-up may cease to exist if they cannot release a

working product before their seed money expires. In

general, competitive time-to-market pressures, along

with moderncompanies’ need to rapidly innovate,im-

ply that companies will not release perfect software.

It is common practice to release a software product

with known issues, as long as those issues are minor.

This research’s addition of priority would enable such

priority-based go/no-go decisions.

An additional beneﬁt released by developing a rel-

ative ranking among modules, on the basis of their

attack-proneness, is that this ranking is complemen-

tary for use with other techniques. Arelative ranking

at the module level could be extended downward to

contained functions and lines. By extension, the rank-

ing could also be extended to tools that ﬁnd defects at

the line level, such as existing static analysis tools.

A relative module ranking might be used to priori-

tize line level alerts output from a commercial static

analysis tool (e.g., identifying the n top “actionable

alerts”).

Although techniques have been published for cal-

culating various information theoretic metrics from

the structural and development views of a software

architecture (Sarkar et al., 2007), there is currently

no publicly available tool support for doing the same.

Tool support is important for practical technique ap-

plication as well as comparing results via repeatable

and veriﬁable experiments (Gousios, 2012). Avail-

ability of a publicly obtainable tool reduces the bar-

rier to entry for researchers interested in evaluating

the sensitivity and discriminatory power of architec-

tural metrics. Since this work must have access to

such a tool, we intend on building this tool and subse-

quently making it available to others.

7 CONCLUSIONS

The current state of affairs is rather tenuous as soft-

ware continually grows larger and more complex, at

odds with classic security principles such as econ-

omy of mechanism, making software more difﬁcult

to comprehend when making changes, and more dif-

ﬁcult to test completely. Compounding these factors

are the forces vying for limited developer time. Es-

pecially in the commercial sector, security concerns

often take a back seat to the development of market-

differentiating features–the return on investment and

impact to the bottom line is more deterministic for

feature development (McGraw, 1999). It’s not that

the commercial sector doesn’t care about security, but

more about spending resources efﬁciently. Developer

time is a constrained, highly contended, and highly

demanded resource in software development organi-

zations. Management therefore wants to make efﬁ-

cient and effective use of developer time. This is the

larger context and commercial motivations that just

so happen to be aligned against security improvement

rather than with it. That is, given that residual vulner-

abilities are already known to be difﬁcult to detect,

what can be done to motivate commercial develop-

ment organizationsto expend effort, appropriating de-

velopment resources to search for what is commonly

known as “a needle in a haystack”?

The answer, from the perspective of our research,

is to provide superior prediction models and estab-

lish what we refer to as suspect prioritization, such

that the “top 10”, or top suggested vulnerability pre-

dictions are likely to represent vulnerabilities that are

exploitable and have the potential to cause severe se-

curity violations, compromising conﬁdentiality, in-

tegrity, or availability. Ideally, the prioritized “top 10”

should be free of false positives, thereby maximizing

the efﬁcacy of any resulting triage and inspection ef-

forts when applied. We acknowledge that the notion

of ranking vulnerability predictions may be criticized,

since a single overlooked security vulnerability has

the potential for wide reaching impact.

We believe that advances in vulnerability predic-

tion are possible given the carefully selected metrics,

that mirror security considerations and are closely re-

lated to our underlying notions about software evo-

lution and development team dynamics. Moreover,

drawing on the existing body of work on defect pre-

diction, we believe the more specialized study of vul-

nerability prediction research offers the potential for

new discoveries.

With knowledge of the most vulnerable compo-

nents, organizations can more effectively prioritize

the application of secure development practices (e.g.,

security review, static analysis, and penetration test-

ing) where they will have the greatest beneﬁt. The

added scrutiny from a well-focused effort can help to

identify and eliminate vulnerabilities prior to produc-

tion release in a tractable, efﬁcient, and cost effective

manner. The alternative approach is wholesale adop-

tion of secure development practices without a prior-

itized perspective. Not only is such a wholesale alter-

Predicting Attack Prone Software Components using Repository Mined Change Metrics

561

native likely to be less effective, but it is also likely

to be met with political opposition within commer-

cial organizations. A wholesale approach lacks cost-

beneﬁt justiﬁcation and, due to the aforementioned

needle in a haystack phenomenon, becomes progres-

sively more futile and psychologically daunting as a

product grows in size. We believe prediction models

based on change and entropy-based architectural met-

rics may offer a practical means for identifying and

prioritizing attack-prone components.

REFERENCES

OSVDB: Open sourced vulnerability database. osvdb.net

(online). http:// www.osvdb.net/, accessed May 30,

2013.

Abdelmoez, W., Nassar, D. M., Shereshevsky, M., Gradet-

sky, N., Gunnalan, R., Ammar, H. H., Yu, B., and

Mili, A. (2004). Error propagation in software archi-

tectures. In Software Metrics, 2004. Proceedings. 10th

International Symposium on, pages 384–393. IEEE.

Anan, M., Saiedian, H., and Ryoo, J. (2009). An

architecture-centric software maintainability assess-

ment using information theory. J. Softw. Maint. Evol.:

Res. Pract., 21(1):1–18.

Bell, R. M., Ostrand, T. J., and Weyuker, E. J. (2011). Does

measuring code change improve fault prediction? In

Proceedings of the 7th International Conference on

Predictive Models in Software Engineering, Promise

’11, New York, NY, USA. ACM.

Bozorgi, M., Saul, L., Savage, S., and Voelker, G. M.

(2010). Beyond heuristics: Learning to classify vul-

nerabilities and predict exploits. In Proceedings of the

Sixteenth ACM Conference on Knowledge Discovery

and Data Mining (KDD-2010), pages 105–113.

Chidamber, S. R. and Kemerer, C. F. (1994). A metrics

suite for object oriented design. Software Engineer-

ing, IEEE Transactions on, 20(6):476–493.

Chowdhury, I. and Zulkernine, M. (2011). Using complex-

ity, coupling, and cohesion metrics as early indicators

of vulnerabilities. Journal of Systems Architecture,

57(3):294–313.

Gousios, G. (2012). On the importance of tools in software

engineering research. Blog. Accessed: 02/20/2013.

Gyimothy, T., Ferenc, R., and Siket, I. (2005). Empirical

validation of object-oriented metrics on open source

software for fault prediction. Software Engineering,

IEEE Transactions on, 31(10):897–910.

Hassan, A. E. (2009). Predicting faults using the complex-

ity of code changes. In Proceedings of the 31st Inter-

national Conference on Software Engineering, ICSE

’09, pages 78–88, Washington, DC, USA. IEEE Com-

puter Society.

Jackson, D. and Wing, J. (1996). Lightweight formal meth-

ods. IEEE Computer, 29(4):16–30.

Janzen, D. and Saiedian, H. (2007). A leveled examina-

tion of test-driven development acceptance. In Pro-

ceedings of the 29th ACM International Conference

on Software Engineering, pages 719–722. ACM.

Khoshgoftaar, T. M., Allen, E. B., Goel, N., Nandi, A., and

McMullan, J. (1996). Detection of software modules

with high debug code churn in a very large legacy sys-

tem. In Proceedings of the The Seventh International

Symposium on Software Reliability Engineering, IS-

SRE ’96, Washington, DC, USA. IEEE Computer So-

ciety.

Manadhata, P. K. and Wing, J. M. (2011). An attack surface

metric. Software Engineering, IEEE Transactions on,

37(3):371–386.

McGraw, G. (1999). Software assurance for security. Com-

puter, 32(4):103–105.

Mell, P., Scarfone, K., and Romanosky, S. (2007). CVSS:

A Complete Guide to the Common Vulnerability Scor-

ing System Version 2.0. FIRST: Forum of Incident

Response and Security Teams.

Moser, R., Pedrycz, W., and Succi, G. (2008). A compar-

ative analysis of the efﬁciency of change metrics and

static code attributes for defect prediction. In Soft-

ware Engineering, 2008. ICSE ’08. ACM/IEEE 30th

International Conference on, ICSE ’08, pages 181–

190, New York, NY, USA. IEEE.

Munson, J. C. and Elbaum, S. G. (1998). Code churn:

a measure for estimating the impact of code change.

In Proceedings. International Conference on Software

Maintenance (Cat. No. 98CB36272), pages 24–31.

IEEE Computer Society.

Munson, J. C. and Khoshgoftaar, T. M. (1992). The detec-

tion of fault-prone programs. IEEE Transactions on

Software Engineering, 18(5):423–433.

Nagappan, N. and Ball, T. (2005). Use of relative code

churn measures to predict system defect density. In

Proceedings of the 27th international conference on

Software engineering, ICSE ’05, pages 284–292, New

York, NY, USA. ACM.

Nagappan, N., Zeller, A., Zimmermann, T., Herzig, K., and

Murphy, B. (2010). Change bursts as defect predic-

tors. In Software Reliability Engineering (ISSRE),

2010 IEEE 21st International Symposium on, pages

309–318. IEEE.

NIST. NVD:national vulnerability database. National In-

stitute of Science and Technology, online. http://

nvd.nist.gov/, accessed May 30, 2013.

Ostrand, T. J., Weyuker, E. J., and Bell, R. M. (2010).

Programmer-based fault prediction. In Proceedings of

the 6th International Conference on Predictive Mod-

els in Software Engineering, PROMISE ’10, New

York, NY, USA. ACM.

Saltzer, J. H. and Schroeder, M. D. (1975). The Protection

of Information in Computer Systems. Proceedings of

the IEEE, 9(63):1278–1308.

Sarkar, S., Rama, G. M., and Kak, A. C. (2007). API-based

and information-theoretic metrics for measuring the

quality of software modularization. Software Engi-

neering, IEEE Transactions on, 33(1):14–32.

Shin, Y. (2011). Investigating Complexity Metrics as Indi-

cators of Software Vulnerability. PhD thesis, North

Carolina State University, Raleigh, North Carolina.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

562

Shin, Y., Meneely, A., Williams, L., and Osborne, J. A.

(2011). Evaluating complexity, code churn, and devel-

oper activity metrics as indicators of software vulnera-

bilities. Software Engineering, IEEE Transactions on,

37(6):772–787.

Younis, A., Malaiya, Y., and Ray, I. (2014). Using attack

surface entry points and reachability analysis to as-

sess the risk of software vulnerability exploitability. In

High-Assurance Systems Engineering (HASE), 2014

IEEE 15th International Symposium on, pages 1–8.

Predicting Attack Prone Software Components using Repository Mined Change Metrics

563
