A Pragmatic System-failure Assessment and Response Model

Jassim Happa

, Graham Fairclough

, Jason R. C. Nurse

, Ioannis Agrafiotis

Michael Goldsmith

and Sadie Creese

Department of Computer Science, University of Oxford, Oxford, U.K.

Department of Politics and International Relations, University of Oxford, Oxford, U.K.

Keywords: Situational Awareness, Emerging Attack Methods, Triage, Future Threats, Cyber Resilience.

Abstract: Several attack models exist today that attempt to describe cyber-attacks to varying degrees of granularity. Fast

and effective decision-making during cyber-attacks is often vital, especially during incidents in which

reputation, finance and physical damage can have a crippling effect on people and organisations. Such attacks

can render an organisation paralysed, and it may cease to function, we refer to such an incident as a “System

Failure”. In this paper we propose a novel conceptual model to help analysts make pragmatic decisions during

a System Failure. Our model distils the essence of attacks and provides an easy-to-remember framework

intended to help analysts ask relevant questions at the right time, irrespective of what data is available to them.

Using abstraction-based reasoning our model allows enterprises to achieve “some” situational awareness

during a System Failure, but more importantly, enable them to act upon their understanding and to justify

their decisions. Abstraction drives the reasoning process making the approach relevant today and in the future,

unlike several existing models that become deprecated over time (as attacks evolve). In the future, it will be

necessary to trial the model in exercises to assess its value.

1 INTRODUCTION

Quick decision-making is vital during incidents in

which reputation, finance and physical damage can

have a crippling effect on people and organisations.

Such attacks can render an organisation paralyzed,

and it may cease to function. A recent example would

be the Sony “The Interview” attack that rendered the

operational aspects of Sony inoperable. We refer to

such an incident as a “System Failure” in which

hardware or software faults, misconfigurations, or the

intentional work of malicious actors are the reason

behind the system no longer functioning.

In this paper we propose a novel conceptual model

to help analysts make pragmatic decisions during a

System Failure. Our model distils the essence of

attacks and provides an easy-to-remember framework

intended to help analysts ask relevant questions at the

right time, and adopt to the data that is immediately

available – allowing our model to be as relevant today

and in the future, unlike several existing models that

become deprecated as attacks increase in complexity.

Our approach expresses different levels of granularity

on an ad-hoc basis, and complements existing models

as opposed to competing with them.

Our model is derived from a number of existing

models on the topic of attack and response.

Abstraction drives the reasoning process through a

series of “Aspects” (including “Impact”, “Vector”,

“Motives” and “Attribution”) and “Nuances”

(individual properties) of attacks, enabling the model

to be inclusive about what is needed to be considered

during the incident response decision-making

processes. Our model assumes analysts have little

time to explore all theoretical considerations and have

to make the most achievable decisions possible with

scarce data (about the attack) and resources. Due to

abstraction, our model may not yield the best

decisions in all circumstances, but it is likely to lead

to more pragmatic decisions, and more importantly:

actions that can be justified after the attack. Our

method has the advantage of:

• Attempting to “Know the Unknowns”: helping

map out which pieces of the attack puzzle may be

missing.

• Decision Documentation of the incident

response reasons more straightforwardly.

• Prioritising Actions during a System Failure. In

our paper we present a use case example in which

our model could have been used and discuss its

advantages and limitations.

Happa, J., Fairclough, G., Nurse, J., Agraﬁotis, I., Goldsmith, M. and Creese, S.

A Pragmatic System-failure Assessment and Response Model.

DOI: 10.5220/0005795105030508

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 503-508

ISBN: 978-989-758-167-0

503

2 REFLECTING ON ATTACK

AND RESPONSE MODELS

Many attack models and classification schemes tend

to describe cyber-attacks in one of two ways; either

as hierarchical structures or as linear processes.

Hierarchical structures (e.g., attack trees) have the

advantage of describing attacks in terms of their

different properties, but often neglect the temporal

component e.g. AVOIDIT (Simmons et al., 1997),

CAPEC (MITRE, 2015), VERIS (VERIS, 2015),

NIST (NIST, 2015), SANS (SANS, 2015). Linear

processes capture the temporal element since they

assume that actions happen sequentially (Howard and

Longstaff, 1998; Hutchins et al., 2011), however,

may fail to describe lateral movement or cases where

attacks occur in parallel.

Many prior works attempt to outline attacks

comprehensively or provide explanations of the direst

consequences when an attack succeeds. In addition,

they describe ideal solutions, see for instance several

of MITRE’s efforts (2015), FIRST’s efforts (2015)

and VERIS efforts (2015). While these efforts show

substantial progress in tackling cyber-attacks, they

may not be feasible for all circumstances, particularly

when decisions have to be made with limited

resources (regarding information available and time

constraints, e.g. during an electric blackout),

technical and operational common sense has to

prevail when making decisions and incident

responses quickly.

To the best of our knowledge, no truly pragmatic

approach to facilitate understanding of attacks and to

provide a framework to ensure technical and

operational sanity exists. It is worth noting here that

we do not consider practical in terms of convenience,

but in terms of necessity and efficiency (due to

limited resources). No model uses easy-to-grasp

reasoning to aid understanding and response to cyber-

attacks that is able to abstract the technical details of

an attack and simply consider its properties. Other

models that we have considered but are not included

above due to space limitations include (Bishop,

1995); Lough, 2001); (Ten et al., 2010), but were still

considered in our model.

2.1 Commonalities Across Models

From the models we have reviewed, we were able to

identify a number of noteworthy differences and

common factors. For instance, at the core of each of

the attack models, they detail the specific activities

leading to the compromise of some security feature

(whether it be confidentiality, integrity or

availability) of an asset. While some (e.g., the

Killchain) place more emphasis on the types of attack

steps and characterising what goal each step is

seeking to reach, others (such as VERIS (2015))

adopt more general steps and focus on the wider

problem. In terms of attack modelling, possibly the

most representative model is that of Howard's

taxonomy to specify incidents. It captures several of

the actions within an incident but also sheds light on

the reason for an attack (e.g., for financial gain, to

cause system damage, or for political gain).

While attack models allow for a detailed analysis

of an attack, incident response models consider what

attack has been launched, but especially how to

appropriately respond to it. In the NIST model above

(NIST, 2015) for instance, we see a requirement to

detect an attack, but a majority of the life cycle is on

responding to it. Some of the key questions in

incident response target why and how an attack

occurred, and who caused it. Almost identical

questions can be found in the SANS model and

process flow for incidents.

Across the more attack-focused models and those

more geared to incident response, there are notable

commonalities. To start, there is an aim to understand

incidents and clearly define what has been impacted

and the activities that have led to a breach of an

asset’s security. Key questions on motivation may

also inform the choices of actions after attacks.

Our approach shares commonalities with business

continuity/cyber resilience models (for an overview,

see (Gibson and Tarrant, 2010) and (Caralli et al.,

2010), with the key distinction being that our efforts

are mainly attack focused and intended to be used by

Security Operations Centres (SOCs) and Computer

Emergency Response Teams (CERTs).

3 A PRAGMATIC

SYSTEM-FAILURE

ASSESSMENT AND RESPONSE

MODEL (SAM)

Our System-failure Assessment and response Model

(SAM) is a directed human-reasoning approach to

incident handling that uses abstraction as part of the

reasoning process. The decision-making process that

the model promotes is based on deduction and

experience.

A series of high-level observables from very basic

questions are able to provide first-pass indicators of

how to respond. For instance, in the case of

attempting to identify impact of an attack, and

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

504

understand what needs to be fixed immediately. An

overview is shown in Figure 1.

Figure 1: SAM outlines what questions to consider first, as

well as an example timeframe we suspect they have to be

addressed. Note: the timeframe will be relative to each

attack.

Our method is based on identifying common

factors between other attack and incident models led

to the creation of a model that examines cyber-attacks

in a pragmatic manner. In particular, by asking the

question of “what matters the most when disastrous

attacks occur?” It can be considered as a series of

aspects to ask questions about to help identify what

the best incident response strategy might be. At its

core, the structure of our model follows directed

interrogative pronouns in order of importance: What

is being attacked, what’s affected, how is it affected?

(Here known as Impact); How is it being attacked

including when and for how long (namely, attack

Vectors); Why is it being attacked (or Motive); and,

Who conducted the attack (i.e. Attribution)? These are

listed as what we believe to be their importance

during attacks. This approach uses the common

factors identified in prior attack-modelling literature

outlined in Section 2.

By Impact we mean the consequence of an attack,

one that is achieved through a Vector. Vectors

describe the means to achieve a Motive. Several

attack vectors exist in the cyber domain: some are

technically driven (e.g., exploits such as buffer-

overflow attacks, code injection, or use Trojans,

viruses, worms, etc.), others social-engineering (e.g.

phishing attacks). Motives describes the intents of an

attacker. Attribution should describe who is

responsible for the attack.

The first question (i.e., the “What”) fills in the

remainder of the other questions, and is crucial to be

able to answer first. If we do not know what has been

attacked, it is difficult to consider anything else.

While the consequences of an attack however, may

not be immediately clear, identifying what has been

attacked should be the first priority, as it is only after

this that we may be able to determine the level of

damage made. Similar to triage, an estimation of the

damage must be made to assess what can be done

afterwards. It is worth noting that time criticality will

depend on the incident, and the timeframe shown in

Figure 1 should be considered relative. Also, should

another incident happen before reaching the end we

likely have to start again at the Impact aspect, or re-

review whether the initial assessment was correct.

The model attempts to guide analysts and decision

makers alike by providing a framework of key

general questions about attacks. These questions

abstract out the technological component but provide

the basis for which technical aspects can be applied.

By asking basic, easy-to-grasp questions, our

framework can be used to communicate incident-

response decisions quickly to non-technical

audiences as well, such as business managers,

lawyers or policy makers, some of whom will be

responsible of organisation operations. What exactly

these questions are, can be driven by existing

standards and models, however, the choice in

standards available needs to be well-understood by

everyone on the team before any major incident.

Naturally, precision is lost in abstraction.

However, it also means that analysts can choose a

classification scheme or detailed attack model they

believe is most appropriate to describe the attack. In

practice this means concepts such as CIA or models

like Killchain can be used to describe nuances of the

Impact, while CAPEC and Common Vulnerability

Scoring System (CVSS) can be used to describe

details (Nuances) about the Vector, see Figure 2.

Figure 2: SAM's use of abstraction, the uses of more

detailed models or inputs can feed into the main

components of SAM.

4 APPLYING THE MODEL

SAM is an abstraction-based approach to understand

attacks to achieve “some” understanding, quickly, to

help act upon them. The model distils all components

of any attack to their bare minimum, and allows

decision makers to insert details – using their standard

of choice (whether of necessity or preference) –

where appropriate. Examples could include assigning

costs to the Impact of attacks, identifying what

machines have been affected, whether people have

been hurt by the attack (and to what extent), or CIA

to describe the area of the attack (as part of Impact,

e.g. “was integrity affected of any components”?).

CAPEC could be used to describe the attack Vector.

Using SAM, we care about understanding as many

aspects about the attack with as limited resources as

A Pragmatic System-failure Assessment and Response Model

505

possible. This means that details may not matter (or

even be available).

4.1 As a Mnemonic

Our model represents a first stage in constructing a

mnemonic for dealing with a cyber incidents, one we

expect will be refined in the future. In First Aid there

is A (Assess and Airways), B (Bleeding and Breaks),

C (Circulation and Consciousness) and D (Deal). In

dealing with a physical security incident there are the

5Cs: Confirm, Clear, Cordon, Control and Close.

However, unlike the health sector, in cyber systems

there are other considerations to take into account;

some of these are mentioned below.

Triage assumes that a person is being treated, and

determines priority of who to treat first. Despite a

system is being healed, it does not mean is has been

healed permanently. Healing can happen much faster

for cyber systems, but attacks can also persists after

initial incident. Whilst formulating the aspects, the

order of them raises considerable debate. As an

analogy of our model to the real world, we can

express these aspects in the form of responding to a

hostile situation; such as a person who has just been

harmed, in which we might say:

Impact: Identify what has happened, then “stop the

bleeding” and prevent further immediate damage to

happen.

Vectors: Identify what the attack weapon was and

prevent the attack weapon from being used again.

Motives: Identify the likely reason why the person

was attacked, and attempt to demotivate the attacker

to want to find another weapon if the attack was with

intent.

Attribution: Identify who the attacker is and disable

the attacker completely.

If the attacker is malicious, one might say that

preventing the attack weapon from being used again

is more important than stopping the bleeding and

more harm from happening. Having said this, in the

cyber domain, we argue Impact should be addressed

first in most situations because the rate of which

Impact can happen. In most cases in the cyber

domain, we may be able to cut of connection or

isolate the damage relatively quickly (e.g. by

disconnecting the monitored system from the Internet

or local network), and it should be done first to limit

the damage. Then, analysts can investigate the attack

vector, whether it is outward facing or an insider

attack, it will now be considered an outward facing

component to a device or a system. Similarly, the

Motive and Attribution aspects may be swapped – it

may not be possible to understand motives of an

attacker before one understands who the attacker is,

however, in our use cases, our ability to identify

motives was far greater than the ability to identify

who the attacker was. The exact order of aspects, or

means to validate the order is subject to further

research.

4.2 In Operational Environments

SOC-like environments are often overwhelmed by

network and intrusion-detection system alerts every

day, and strive to understand the threat landscape.

There is an important distinction we make between

this model and cyber-incident handling more

generally. This model is intended to be used during

System Failures only, i.e. attacks that have crippled

the monitored system to a point in which even cyber

observables are limited. Our model in an operational

environment follows a feedback loop, as shown in

Figure 3.

Figure 3: SAM in an Operational Environment.

Once a New Incident has happened, an assessment

of the Impact is made by asking the appropriate

questions pertaining to what has been observed.

Decisions are made and executed based on observable

evidence and common sense reasoning related to the

Impact of the system.

After decisions have been made related to the

Impact, we progress in a similar fashion and

reasoning structure until decisions have been made

(and executed) related to Attribution. After an

incident, Post-Incident Analysis can be conducted (if

any are in place), and existing procedures can be

reviewed and implemented, until a New Incident

comes in again, and the loop is repeated. Each answer

gained from the model should allow elucidation of

how best to respond to the attack at that juncture.

There are particularly difficult corner cases such as

reputational damage (i.e. reputational damage is

difficult to measure the long-term impact of), which

we are contemplating for future work.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

506

5 DISCUSSION

Our model is a first version of an approach that is able

to describe attack behaviour in terms of four

constituent components by distilling observables to

their essence and making decisions from this

understanding. The proposition of “first what, then

how, then why, then who” as a pipeline is not a

controversial one. Indeed, we argue that most security

experts naturally respond in the order presented in

SAM anyway. However, with this pipeline happening

across the board informally, and no one having

identified it as such is an observation we believe is

worth sharing to enable analysts to more effectively

communicate through a shared incident-response

mental pipeline model. This helps communication

during incidents, but also helps for planning red

teaming exercises (through storyboarding using our

pipeline), but also allows analysts to identify when

nuances of attacks distinguish themselves from past

incidents. This is helpful in the immediate future as

we’re able to classify those nuances into different

domains describing the attack.

5.1 Strategic Role of SAM

Our model serves as first-pass mechanism to respond

to incidents quickly, by reviewing key, generic

aspects of an attack and being able to ask the right

questions about the attack at the right time, regardless

of type of attack; whether it be a zero-day exploit or

an APT.

The main purpose of SAM is to support the

immediate response to a cyber event the model also

fulfils important strategic functions. Time is of equal

importance to the strategic decision maker as it is to

the tactical cyber analysis trying to deliver a solution.

Both are involved in the damage limitation process.

At this point, focus is not on the detail; it is on the

message that something is wrong. This message is not

just for those at the coalface. Other actors including

system users, senior decision makers and externally

those who may face a similar threat need to be made

aware. This is a task for which SAM is well suited. Its

format provides the means to alert internal and

external audiences. Providing adequate insight to

activate the necessary emergence response within the

challenging time constraints and without

overwhelming recipients with superfluous detail that

is arguably not important at that juncture.

SAM’s dynamic construct allows details to be

obtained, in a structured manner over time. This

accumulation of facts is critical in enabling informed

decision-making. As time progresses the immediacy

of dealing with the reality of the attack transfers to

dealing with its consequences. These consequences

are increasingly both internal and external. Internally,

these might include the extent to which the system

can continue to operate or the level of damage that has

been done. Externally, consequences might involve

mitigation to protect reputation or the need to inform

partners of a potential threat in order to safe guard

their interests. SAM’s ability to establish this

structured feed of detail, whilst maintain simplicity

and the spread of erroneous information is a key

contributor in ensuring appropriate decision-making.

Of great importance will be which recovery and

resilience measures should be activated.

5.2 Red Teaming

Helping cyber-security analyst defend their systems

better during particularly devastating attacks. SOCs

and CERTs are some of the few intended audiences

we have in mind for the model as it currently stands.

We believe, however, it is possible to use the model

to also design Red Team activities (i.e. ethical

hacking to improve the system). Applications of this

might help pen testers storyboard attack scenarios in

a structured, reproducible manner. This may perhaps

be best done by starting the model in the reverse

order: beginning with who is attacking, moving on to

why they are attacking, to how the attack is

implemented (as a means to achieve the why the

attack is taking place), and finally outline the intended

impact. As an activity, it can:

• Provide insight into the threat and hence inform

decisions over the level of risk;

• Act as a mechanism to exercise and assess an

organisation’s emergency response planning,

• Be used to generate options not previously

considered in times of disaster.

5.3 Scoring Systems and Nuances

Conceivably, the model could be implemented

similarly to vulnerability scoring systems such as

CVSS (FIRST, 2015). By having a form that asks a

series of straightforward questions relating to the four

main aspects it may be possible to extrapolate direct

relationships between what has been observed, and

possible remedies (first-pass indicators about what to

do next). In the case of attempting to identify

“Impact”, and what needs fixing “now”, questions

about “Nuances” might help the decision process.

Each of these Nuances should help answer: “What

actions can we do to stop or limit the (aspect)?”

Conceivably, each of these aspects could be

A Pragmatic System-failure Assessment and Response Model

507

formalised and better defined to better process them

in automated systems or deliver precise metrics that

help describe the attacks.

Examples of nuances might be asking questions

about the Measurability of the attack Impact (i.e.

what has been observed as affected? (listing people,

physical items, hardware, software, finance,

reputation etc.)), its Influence (i.e. how is the impact

affecting the system? (e.g., listing CIA per affected

Impact)), the Duration of the Impact or

Transparency of the Impact (i.e., how visible the

Impact is). In the case of Vector, we might be

interested in exploring Nuances such as

Implementation (i.e., “what technologies (hardware

and software) and protocols were involved to

implement the attack?”), Deployment (i.e., “how was

the attack likely deployed?” For example, network

vulnerability exploit or similar.), Distribution (i.e.,

how distributed is the attack? For example, what

physical location in the real-world are affected?), or

Repeatability (i.e. how repeatable is the attack?).

From the Patterns in the Vector or by identifying the

intended Target, it may be possible to obtain

Motives, and finally, we may obtain (likely)

Attribution through an analysis of all of the

aforementioned Aspects and Nuances. Future work

will explore exactly which Nuances to consider, and

how the model could be implemented in a tool.

6 CONCLUSIONS

In this paper we provided a way to organise thinking

and prioritise effort when dealing with system

failures. SAM is intended to be a model through

which technical and non-technical decision makers

can easily communicate and make better decisions

collaboratively during major incidents in which time

is of the essence and information is lacking

significantly.

The model enforces common-sense reasoning,

enables justifiable decision making that are based on

empirical evidence where available. Future

assessment is necessary to say with confidence

whether our model effectively achieves its aims. We

intend to conduct studies with SOC analysts under a

variety of different use case scenarios.

REFERENCES

Bishop, M. (1995). A taxonomy of unix system and

network vulnerabilities. Technical report, Technical

Report CSE-95-10. Department of Computer Science,

University of California at Davis.

Caralli, R.A., Allen, J and White, D. W., (2010). CERT

Resilience Management Model: A Maturity Model for

Managing Operational Resilience. Addison-Wesley

Professional.

Cohen, F. (1997). Information system defences: a

preliminary classification scheme. Computers &

Security, 16(2):94–114.

FIRST. (2005). Common Vulnerability Scoring System.

http://www.first.org/cvss.

FIRST. (2015). FIRST Security Library.

https://www.first.org/library.

Gibson, C.A. and Tarrant, M. (2010). A ‘conceptual

models’ approach to organisational resilience.

Howard, J. D. and Longstaff, T. A. (1998). A common

language for computer security incidents. Sandia

Report: SAND98-8667, Sandia National Laboratories,

http://www.cert.org/research/taxonomy 988667.pdf.

Hutchins, E. M., Cloppert, M. J., and Amin, R. M. (2011).

Intelligence-driven computer network defense

informed by analysis of adversary campaigns and

intrusion kill chains. Leading Issues in Information

Warfare & Security Research, 1:80.

Lough, D. L. (2001). A taxonomy of computer attacks with

applications to wireless networks. PhD thesis.

MITRE. (2015) Common Attack Pattern Enumeration and

Classification. http://capec.mitre.org/MITRE 2015.

Computer Security. http://www.mitre.org/publicationk

eywords/computer-security.

NIST. (2012). Computer security incident handling guide.

Technical report.

SANS (2004). Global information assurance certification

paper. Technical report.

Simmons, C., Shiva, S., Dasgupta, D., and Wu, Q. (2009).

AVOIDIT: A cyber attack taxonomy. University of

Memphis, Technical Report CS-09-003.

Ten, C.W., Manimaran, G., and Liu, C.-C. (2010).

Cybersecurity for critical infrastructures: attack and

defense modeling. Systems, Man and Cybernetics, Part

A: Systems and Humans, IEEE Transactions on,

40(4):853–865.

VERIS. (2015). Vocabulary for Event Recording and

Incident Sharing. http://veriscommunity.net/

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

508
