Extracting Patient Data from Tables in Clinical Literature
Case Study on Extraction of BMI, Weight and Number of Patients
Nikola Milosevic
1
, Cassie Gregson
2
, Robert Hernandez
2
and Goran Nenadic
1,3
1
School of Computer Science, University of Manchester, Manchester, U.K.
2
AstraZeneca plc, Cambridge, U.K.
3
Health e-Research Center, University of Manchester, Manchester, U.K.
Keywords:
Text Mining, Table Mining, Information Extraction, Natural Language Processing, Clinical Trials.
Abstract:
Current biomedical text mining efforts are mostly focused on extracting information from the body of research
articles. However, tables contain important information such as key characteristics of clinical trials. Here, we
examine the feasibility of information extraction from tables. We focus on extracting data about clinical
trial participants. We propose a rule-based method that decomposes tables into cell level structures and then
extracts information from these structures. Our method performed with a F-measure of 83.3% for extraction of
number of patients, 83.7% for extraction of patient’s body mass index and 57.75% for patient’s weight. These
results are promising and show that information extraction from tables in biomedical literature is feasible.
1 INTRODUCTION
The amount of published scientific research is accel-
erating: the number of published papers is growing at
a double-exponential pace (Hunter and Cohen, 2006).
MEDLINE contains over 25 million references
1
and
it is impossible to cope with this amount of published
research.
Text mining provides tools and methods to deal
with large numbers of articles in biomedicine. How-
ever, these efforts have been focused mainly on the
processing of unstructured text and most of them ig-
nored lists, tables and figures.
Tables are used for storing large amounts of fac-
tual or statistical data in a structured, concise and
human-readable way (Tengli et al., 2004). They also
provide a way for storing multidimensional data. The
visual layout of a table often describes relationships
between the items in the table. Because of the vari-
ety of layouts, it is challenging to perform analysis of
data in this form.
In biomedicine, important experimental informa-
tion, such as the settings and the results of experi-
ments, interactions between substances, drug side ef-
fects, information about arms and patients, are usu-
ally stored in tables. In PMC database, more than
72% of research articles contain tables. We manually
1
http://www.ncbi.nlm.nih.gov/pubmed
found that some of the documents in the database do
not contain the whole article in XML format (scanned
documents, containing only parts in XML). Also, we
calculated that the PMC articles contain on average
2.72 tables.
In this paper, we present a method for table de-
composition and a case study on extracting informa-
tion from tables in biomedical literature. The aim of
our study is to examine the feasibility of information
extraction about patients from tables in clinical litera-
ture. Our case study performed extraction of number
of patients, body mass indexes (BMI) and weight of
patients from tables.
2 BACKGROUND
Hurst (Hurst, 2000) was among the first to examine
tables from the text mining perspective. He proposed
a model of tables with five components: graphical,
physical, functional, structural and semantic. Also,
Hurst created one of the first table mining engines.
He split the process of table mining into three parts:
table detection, functional analysis and information
extraction.
The table detection step examines how to cor-
rectly detect tables in the documents. Work has
been done in detecting tables from PDF, HTML and
Milosevic, N., Gregson, C., Hernandez, R. and Nenadic, G.
Extracting Patient Data from Tables in Clinical Literature - Case Study on Extraction of BMI, Weight and Number of Patients.
DOI: 10.5220/0005660102230228
In Proceedings of the 9th International Joint Conference on Biomedical Engineering Systems and Technologies (BIOSTEC 2016) - Volume 5: HEALTHINF, pages 223-228
ISBN: 978-989-758-170-0
Copyright
c
2016 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
223
ASCII documents using Optical Character Recogni-
tion (Kieninger and Strieder, 1999), machine learn-
ing algorithms such as C4.5 decision trees (Ng et al.,
1999) and SVM (Son et al., 2008) or heuristics (Yildiz
et al., 2005).
The second step is functional analysis and it ex-
amines the purpose of areas of the table. The aim of
this step is to identify which cells contain raw data
and which contain navigational data. Approaches
using machine learning methods like C4.5 decision
trees (Chavan and Shirgave, 2011) or CRF (Wei et al.,
2006) were used.
The final step is semantic processing. In this step,
relationships and semantics of the table elements are
analysed. Semantic processing of the tables are used
for information retrieval (Hearst et al., 2007; Divoli
et al., 2010), information extraction (Mulwad et al.,
2010; Wong et al., 2009) and question answering sys-
tems (Wei et al., 2006).
So far, no work has been conducted on extracting
information from tables in clinical literature.
3 METHOD
We aim to extract information from tables about par-
ticipants of the clinical trials such as their num-
ber, BMI and weight. The method we propose is
composed of two parts: table decomposition into
structures that are more suitable for further process-
ing and information extraction. We propose a way
to decompose table into cell-level data structures
while maintaining information about relationships be-
tween elements of the table. Table decomposition,
viewed through Hurst’s model, represent functional
and structural table analysis. The second part con-
siders information extraction from the tables, which
corresponds to semantic analysis in Hurst’s model.
Data
Our dataset had 2517 documents collected as a clin-
ical trial publications from PubMedCentral (PMC)
2
.
Out of these documents 568 had no XML presenta-
tion of tables. They had a reference to the image
of scanned table. The total number of tables in our
dataset was 4141.
Firstly, we conducted a manual analysis on a small
sample of 70 PMC documents with 217 tables. Based
on our analysis we were able to create rules to identify
structure, decompose tables in structured manner and
extract information.
2
http://www.ncbi.nlm.nih.gov/pmc/
3.1 Table Decomposition
Table decomposition contains five steps.
In the first step, the algorithm is locating table with
its meta-data such as caption and footer. These data
are stored in particular XML tags.
In the second step, our algorithm locates headers
and stubs of the table. Cells that are inside the thead
tags are labelled as header cells. The left-most col-
umn cells are labelled as the stub cells. If this column
has row-spanning cells, then the following column is
also labelled as part of the stub. Row-spanning cells
are usually used to group and categorise other stub
cells in the following column. The first column with
no row-spanning cells outside header will be the last
column labelled as the stub. Similarly, complex head-
ers with column-spanning cells are labelled, if there
is no thead tag. If there is no thead tags, our method
is checking whether the table does not have a header
by checking similarity of value types between first
five rows. Since the table might have multiple lay-
ers of headers, five was the optimal number of rows
for this check, since it indicates in an unambiguous
way separation between types. If the cell in the first
row has different type (i.e. text) than the following
rows (i.e. numeric), the first cell is labelled as part of
header. If all five cells have values of same type, the
table has no header. Types of cells could be empty,
numeric (integer or floating point number), partially
numeric (number with special characters and punctu-
ations) and string.
In the third step, spanning cells (recognised by ap-
propriate XML attribute) are split and the content of
the cell is copied to all the newly created cells(Chen
et al., 2000).
The fourth step is classification of the table by
number of dimensions. Navigational paths are read
differently for one, two or multi-dimensional tables.
Our algorithm identifies three types of tables using
heuristics rules. List (one dimensional) tables con-
tain a list of items in one or more columns (space sav-
ing reasons). They can be recognized if it has only
one column, the header is spanning through all the
columns or if there is same header for all the columns.
Matrix (two dimensional) tables contain data ar-
ranged in simple matrix of cells (Example can be seen
in Figure 3). Super-row (multi-dimensional) tables
are similar to matrix tables, but the presence of super-
rows (Tengli et al., 2004) changes the way they are
read (Example can be seen in Figure 1). Super-rows
are usually presented as a row inside data part of the
table that is spanning through all columns or a row
with a value only in one cell.
In the last step, our method is iterating through
all data cells and trying to find the correct navigation
HEALTHINF 2016 - 9th International Conference on Health Informatics
224
Figure 1: Example of the table (PMC29053) and the decomposition XML output for one cell from that table.
path. Navigation path is a path through the naviga-
tional cells (header, stub, super-rows) that logically
annotates the data from the data cell. In list tables
only the header value is part of navigation path. For
matrix tables, the algorithm has to read the header cell
in the same column as the given cell, the stub cell
in the same row as the cell and the header value for
stub’s column. Since the super-row table may have a
number of super-row levels in a tree-like structure, we
created a stack structure that stores current super-row
paths, as the algorithm iterates through the cells. For
this kind of table, our method reads a header value for
the stub (stub’s label), all levels of super-rows above
the item of interest, the stub value and the header
value above the cell.
Data retrieved from the tables are stored in the
XML elements (see Figure 1).
Figure 2: Workflow of table decomposition method.
A work-flow diagram of our method can be seen
in Figure 2.
3.2 Table Information Extraction
We performed two case studies on information extrac-
tion from tables. The first study’s objective was to
extract the total number of patients, while the second
had to extract BMI and weight of patients from a clin-
ical trial publication. In the second task, the partici-
pant group names had to be extracted together with
the appropriate mean BMI or weight. For example,
table shown in Figure 3 has two participant groups.
Figure 3: Example of a clinical trial demographic table that
contains information about patients BMI (PMC58836).
Extracted information will be: [Absolute Risk (n =
232): BMI: 27.4 (4.5)] and [NNT (n = 225): BMI:
27.0 (4.3)].
3.3 Extraction of Number of Trial
Participants
The number of participants is a numerical value and
there is a limited set of trigger words to indicate its
appearance in table. The number of patients could be
presented in different places in the table and it may
not be presented as a single (overall) number, but also
as a number of participants per each arm of trial.
The table caption usually presents the total num-
ber of the clinical trial participants. We extract the
number of participants using two rules. The first rule
is looking for a number, followed by one of the trig-
ger words (subject, patient, person, individual, peo-
ple, infant) in either singular or plural in its vicinity.
The trigger word does not need to be the word next to
the number, since in some cases the authors may want
to specify the participants more (e.g. 16 1-month-old
infants, 1239 blood donors). The second rule is look-
ing for a pattern consisting of letter n, the equals sign
and a number (e.g. n=19).
There are several ways to store the number of clin-
ical trial participants in navigational cells of the ta-
ble. One way is to store the total number of patients
in a stub, while the other is storing it in the header.
Usually, in stubs and headers, the number of patients
Extracting Patient Data from Tables in Clinical Literature - Case Study on Extraction of BMI, Weight and Number of Patients
225
are presented in the form of mathematical expression
(e.g. n = 19). In stubs, we are often expecting the total
number of patients in one cell. Since header may have
values per arm in each column, we created a list of
candidates. Firstly, all the values are added to the list.
If the content of some cell contained the word ”over-
all”, ”total” or the phrase ”all patients”, that value is
considered as the total number of participants. How-
ever, if such cell does not exist, we check if the stub’s
header cell has a value for number of patients. If none
of this is the case, the values from the header columns
are summed (example of this can be seen in Figure 3).
Also, the number of patients may be placed in the
body of the table. Similarly to headers, data cells may
present the number of patients in parts (e.g. per arm),
as single total number, or, in some tables, they may
contain both partial and total numbers. Since the data
cells may contain only numerical values, looking for
trigger words and patterns has to be done in the ap-
propriate stub cells. We have defined trigger phrases
which our method searches for in the stub (Number
of patients, Num. of participants, etc.). If found, val-
ues from the data cells are extracted and added to the
list of candidates. Headers also need to be analysed
(check if header value contain words ”overall”, ”to-
tal” or ”all patients”) in order to determine if there is
some cell presenting the total number of participants.
If there is no such column, the summed value repre-
sents the total number of participants.
3.4 Extracting Body Mass Index and
Weight
The second case study extracts information about
BMI and mean weight of trial participants. This task
is much more complex because we want to extract in-
formation, together with the participant group names
in which these values were measured.
For the BMI extraction, our approach is to look in
the stub of the table for trigger phrases ”body mass
index” or ”bmi”. If a table contains these trigger
phrases, values from the table body are extracted.
However, we also checked whether the value is in
the appropriate range (15-40). If the value is not in
this range, it does not represent mean BMI value,
but other value such as BMI change, standard devi-
ation, etc. If there is more then one column with
BMI values, the headers are probably the names of
the participant groups. To identify header cells that do
not represent participant group names, list of terms is
created with tokens such as ”range”,”p*”,±”,”T”,”p-
value”,”p* value”,”%”,”significance”. Appearance of
these words indicates that the column does not con-
tain BMI values.
Using these heuristics it is not possible to obtain
only arm names, but rather patients groups, since the
authors may create demographic tables where they di-
vide patients either by treatment (placebo, penicillin),
location (Paris, Toulouse), follow-up period (data on
enrolment, 1 week and 1 month after treatment) or
outcomes (survivors, non-survivors).
Similarly, weight of patients was also extracted.
In this case trigger phrases were ”weight” and ”body-
weight”. Since tables can present a number of dif-
ferent measures related to weight, a stop list was in-
troduced, which had the role of discarding entries if
the stub contains a word from the list near the trigger
phrases. Stop list contained words like ”loss”, ”gain”
and ”change”. In this case, we were not able not de-
fine the range of values since values may be in differ-
ent measurement units (g, kg, lb) and a wide variety
of values is possible.
4 RESULTS
4.1 Table Decomposition Results
We have processed all 2517 PMC clinical trial docu-
ments. Our method extracted data from 3573 tables.
The corpus contained 55.24% of matrix, 0.76% of list
and 42.46% of sub-header tables. Since each table has
on average 80 cells, it would be impossible to evalu-
ate the whole dataset. We have chosen 100 random
tables from each type of tables and evaluated the algo-
rithm’s output for them manually by inspecting every
table and its cell structures for correctness. If at least
one XML cell structure is not read correctly, table is
labelled as incorrectly decomposed.
Table 1: Accuracy of table decomposition system.
Class Tables in dataset N. Eval. Accuracy
Matrix tables 1974 (55.24%) 100 89%
Super-row tables 1517 (42.46%) 100 81%
List tables 27 (0.76%) 27 77.7%
Multi-table tables 55 (1.54%) 55 49.1%
Total 3573 282 84.9%
In Table 1, we present the results of our eval-
uation. Matrix tables were easiest for decomposi-
tion and the accuracy would be even higher if our
dataset had perfect markup. Due to the non standard
XML labelling, our method in some cases was not
able to correctly recognize table type or borders of
navigational areas. Some of the mislabelling include
spanning cells (not using the attribute, but rather us-
ing multiple cells) and incorrect labelling of headers
with thead tags (incorrectly tagging something as a
header). Super-row and list tables performed slightly
HEALTHINF 2016 - 9th International Conference on Health Informatics
226
worse. We encountered a small number of tables that
actually presented several similar tables merged to-
gether (we called them multi-tables). We included
a simple algorithm that is able to recognize naviga-
tional paths in them based on presence of horizontal
lines. However, this algorithm was not good enough
to recognize navigational path with high performance.
Due to the small number of these tables, they did not
affect our overall performance. Overall accuracy of
table decomposition was 84.9%.
4.2 Number of Patients Extraction
Results
For the extraction of the number of patients, we pro-
cessed all documents in our dataset. The total num-
ber of participants was extracted from 758 documents.
For evaluation purposes we randomly selected 50
documents. Our system performed with a F-measure
of 83.3%. More detailed statistics can be seen in Ta-
ble 2.
Table 2: Performance of extracting total number of patients.
Precision 73.53%
Recall 96.15%
F-measure 83.3%
4.3 BMI, Weight and Patient Group
Name Extracting Results
For the extraction of BMI and weight, we selected
dataset that contains 113 documents, having in at least
one of the tables token related to BMI or weight.
We separately evaluated the patient group, weight and
BMI extraction. The results are shown in Table 3.
Results for BMI and weight are dependent on how
the participant groups were recognized, because each
extracted value is assigned to the participant group.
Participant groups were extracted with a F-measure
of 71.32%. They are hard to extract correctly be-
cause they may be formed from a wide range of con-
cepts (location, drug, treatment, time, etc.) and may
include acronyms or abbreviations. Complex tables,
with multiple levels of headers may create additional
complexity, since it might be hard to determine where
the name of the group ends and where technical or sta-
tistical separation of the table’s cells starts (ie. mean
and standard deviation columns).
BMI has a higher F-measure than participant
group extraction. This may look strange, because in
order to extract BMIs, the patient group has to be
extracted correctly as well. However, defined BMI
range made a large contribution to discarding false
positives.
Our method for weight extraction performed with
high recall but with very low precision. This is due to
the fact that the method was matching trigger phrases,
but did not have a well crafted stop list, that could help
to distinguish actual patient weight from other weight
related concepts.
5 CONCLUSION
Information extraction from tables is not exten-
sively researched. However, in many fields, such as
biomedicine, it could be useful, due of the importance
of the data presented in tables. Information extrac-
tion from tables can use some of the established text
mining techniques, but due to the challenge of under-
standing the visual layouts, new approaches have to
be developed as well.
We developed a methodology for table decompo-
sition into cell-level data structures. Our method is
able to read table data with associated navigational
information. Using these structures, it is easier to
perform semantic analysis and information extrac-
tion. We performed a case study on extracting num-
ber of trial participants, BMIs and names of the par-
ticipant groups from clinical literature. Although we
used relatively simple rules for information extrac-
tion, our results are promising (F measure for BMI ex-
traction 83.7%, F measure for weight extraction over
57%). Our results indicated that some information
classes may be easier to extract, because it is possi-
ble to model expected values, while the others remain
a challenge.
The results of our case studies are comparable
with state-of-the-art methods in table information ex-
traction. However, not many works report informa-
tion extraction from tables. Hurst (Hurst, 2000) re-
ported the combined task of functional, structural and
relational analysis to have a F score of 83.13%. How-
ever, this task matches our table decomposition task,
which is just first part of our information extraction
method. Gatterbauer et al. (Gatterbauer et al., 2007)
created generic information extraction system, but
they reported F measure of 52%. Tengli et al. (Tengli
et al., 2004) reported the best F measure of 91.4% for
information extraction from tables. However, they ap-
ply a method on The Common Data Set tables, which
is a standardized presentation format for higher edu-
cation data in the United States. Compared to these
tables, tables from PMC are not standardised in any
way.
The performance of our method is quite promising
Extracting Patient Data from Tables in Clinical Literature - Case Study on Extraction of BMI, Weight and Number of Patients
227
Table 3: Performance extracting BMI, weight and patient groups from PMC clinical trial documents (TP - true positives, FP
- false positives, FN - false negatives).
Class TP FP FN Precision Recall F-measure
BMI 72 22 6 76.6% 92.3% 83.7%
Participant group 153 93 27 61.45% 85% 71.32%
Weight 95 133 6 41.66% 94.05% 57.75%
and indicates that information extraction from tables
is a feasible task. However, there is a space for ad-
vancement. There is still the need for the human cu-
rators to control the system and correct mistakes. We
believe our system will reduce data curation time for
medical documents.
6 AVAILABILITY
Our code and annotated corpus is available on
GitHub
3
. Current code is a work in progress and
might be subject to changes. The documents user
were clinical trial articles from PubMedCentral
4
.
REFERENCES
Chavan, M. M. and Shirgave, S. (2011). A methodology
for extracting head contents from meaningful tables in
web pages. In Communication Systems and Network
Technologies (CSNT), 2011 International Conference
on, pages 272–277. IEEE.
Chen, H.-H., Tsai, S.-C., and Tsai, J.-H. (2000). Mining ta-
bles from large scale html texts. In Proceedings of the
18th conference on Computational linguistics-Volume
1, pages 166–172. Association for Computational Lin-
guistics.
Divoli, A., Wooldridge, M. A., and Hearst, M. A. (2010).
Full text and figure display improves bioscience liter-
ature search. PloS one, 5(4):e9619.
Gatterbauer, W., Bohunsky, P., Herzog, M., Kr
¨
upl, B., and
Pollak, B. (2007). Towards domain-independent in-
formation extraction from web tables. In Proceedings
of the 16th international conference on World Wide
Web, pages 71–80. ACM.
Hearst, M. A., Divoli, A., Guturu, H., Ksikes, A., Nakov,
P., Wooldridge, M. A., and Ye, J. (2007). Biotext
search engine: beyond abstract search. Bioinformat-
ics, 23(16):2196–2197.
Hunter, L. and Cohen, K. B. (2006). Biomedical lan-
guage processing: perspective whats beyond pubmed?
Molecular cell, 21(5):589.
Hurst, M. F. (2000). The interpretation of tables in texts.
PhD thesis, University of Edinburgh.
Kieninger, T. G. and Strieder, B. (1999). T-recs table recog-
nition and validation approach. In AAAI Fall Sym-
3
https://github.com/nikolamilosevic86/TableAnnotator
4
http://www.ncbi.nlm.nih.gov/pmc/
posium on Using Layout for the Generation, Under-
standing and Retrieval of Documents.
Mulwad, V., Finin, T., Syed, Z., and Joshi, A. (2010). Using
linked data to interpret tables. COLD, 665.
Ng, H. T., Lim, C. Y., and Koo, J. L. T. (1999). Learn-
ing to recognize tables in free text. In Proceedings of
the 37th annual meeting of the Association for Com-
putational Linguistics on Computational Linguistics,
pages 443–450. Association for Computational Lin-
guistics.
Son, J.-W., Lee, J.-A., Park, S.-B., Song, H.-J., Lee, S.-
J., and Park, S.-Y. (2008). Discriminating meaning-
ful web tables from decorative tables using a compos-
ite kernel. In Web Intelligence and Intelligent Agent
Technology, 2008. WI-IAT’08. IEEE/WIC/ACM Inter-
national Conference on, volume 1, pages 368–371.
IEEE.
Tengli, A., Yang, Y., and Ma, N. L. (2004). Learning table
extraction from examples. In Proceedings of the 20th
international conference on Computational Linguis-
tics, page 987. Association for Computational Lin-
guistics.
Wei, X., Croft, B., and McCallum, A. (2006). Table ex-
traction for answer retrieval. Information retrieval,
9(5):589–611.
Wong, W., Martinez, D., and Cavedon, L. (2009). Extrac-
tion of named entities from tables in gene mutation
literature. In Proceedings of the Workshop on Current
Trends in Biomedical Natural Language Processing,
pages 46–54. Association for Computational Linguis-
tics.
Yildiz, B., Kaiser, K., and Miksch, S. (2005). pdf2table: A
method to extract table information from pdf files. In
IICAI, pages 1773–1785.
HEALTHINF 2016 - 9th International Conference on Health Informatics
228
